3 PROFIROLL BAD DUEBEN thread rolling machines used machines

pressure: 0,2-40 t max. workpiece diameter: 70 mm threading length: 120 mm Control: total power requirement: 29 kW weight of the machine ca.: 9,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 20 - 300 kN adjustment of rolling slide: 50 mm diameter of rolling spindle: 120 mm roll spindle height over machine bed: 200 mm Control: SIN 840 taper length of the roll spindle: 200 mm rolling spindle turning speeds: 0 - 50 1/min torque per rolling spindle: 2700 Nm power capacity: 2 x 8,4 kW distance between rolling spindles: min. 271 / max. 368 mm rolling tool outer diameter: max. 300 mm total power requirement: 26 kW weight of the machine ca.: 7,1 t dimensions of the machine ca.: 9,70 x 4,50 x 3,80 m CNC machine for gear cold rolling Promot loader cell Complete housing The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 20 - 600 kN adjustment of rolling slide: 2 x 90 mm diameter of rolling spindle: 120 mm roll spindle height over machine bed: 200 mm Control: SIN 840 D taper length of the roll spindle: 200 mm rolling spindle turning speeds: 0 - 34 1/min torque per rolling spindle: 6.160 Nm power capacity: 2 x 8,4 kW distance between rolling spindles: min. 271 / max. 368 mm rolling tool outer diameter: max. 300 mm total power requirement: 26 kW weight of the machine ca.: 7,1 t dimensions of the machine ca.: 9,70 x 4,50 x 3,80 m CNC machine for gear cold rolling / thread rolling Felsomat loader cell Complete housing The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

UPW 25x100 Thread rolling machine Available 2 machines. Pressure 25TONS Max. Workpiece Diameter 100mm Min. Workpiece Diameter 10mm Thread Length at Plunge Operation 180mm Thread Length at Continuous Operation 2000mm/80mm Distance Of Roll Spindles 150/325mm Length Of Roll Spindle Fixtures 180mm Dia. Of Rolling Tool 230mm Roll Spindle Turning Speed Range 20-90 U/Min Shaft Dia 63mm Weight 3,25 tons

Inv. Num. : 5148 Type: URWA 250 Producer: Profiroll Created: 2004 Parameters: Rolling force: 800 kN Max. workpiece diameter: 250 mm Workpiece width: 80 mm Spindle diameter: 110 mm Spindle speed: 100-800 1/min Mandrel diameter: 45-100 mm Length: 2400 mm Width: 2400 mm Height: 2400 mm Weight: 4900 kg

Control: SINUMERIK 840 D rolling power: 800 kn diameter max.: Werkstück: 250 mm work piece width: 80 mm spindle diameter: 110 mm : 100-700 1/min power capacity: 110 kW length: 2600 mm width: 2600 mm height: 2600 mm weight: 12,5 t Mandrel diameter: 45–100 mmScope of deliveryCentral lubrication, stepless speed control, proportional measuring system, linear mandrel guide, process monitoring for the mandrel, process data management, rolling equipment, distributor 130–190 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 7918 Type: UPW 12,5 Producer: VEB Wema Bad Düben DDR Created: 1984, GO 2006 Parameters: Rolling force: 12.5 t Max. workpiece diameter: 70 mm Workpiece width: 2000 mm Power consumption: 4 kW Length: 1125 mm Width: 1400 mm Height: 1150 mm Weight: 2100 kg Equipment: Thread Rollers Ring magazine for automatic operation Support ruler

Inv. Num. : 7920 Type: UPW 12,5 Producer: VEB Wema Bad Düben DDR Created: 1980-GO 1998 Parameters: Rolling force: 12.5 t Max. workpiece diameter: 70 mm Workpiece width: 200 mm Power consumption: 4 kW Length: 1125 mm Width: 1400 mm Height: 1150 mm Weight: 2100 kg Equipment: Thread Rollers Ring magazine for automatic operation Support ruler

diameter range 10-24 mm Forging power 7-20 to thread length plunge method 195 mm daylight 160 mm max. pitch 3,5 mm roller bore 80 mm roller width 235 mm roller length 195 mm

sheet width: 125 mm coil weight: 2x 0,8 t coil internal dia.: 300-500 mm coil outside dia.: 1200 mm weight of the machine ca.: 0,7 t dimensions of the machine ca.: BxTxH 2000x2000x1800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Antenna cable, extension cable -Manufacturer: Bad Blankenburg -Type: AZ118LL -Length: 4 m -Number: 39 cables available -Price: per piece -Minimum order quantity: 3 pieces -Weight: 0.18 kg/piece

plate width: 125 mm plate thickness: 2 mm straightening feed: 5-30 m/min total power requirement: 1,5 kW weight of the machine ca.: 460 t Sheet width: 125 mm Sheet thickness: 2 mm Straightening speed: 5 – 30 m/min Total power requirement: 1.5 kW Machine weight: approx. 460 kg (The value 460 t is almost certainly a typo, based on this machine size, 460 kg is the plausible specification.) Strip infeed height: 1,250 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

material width:250 mm material thickness:0,2 - 2,0 mm no. of straightening rolls:7 straightening roll diameter:60 mm run-in height:1250 mm power capacity:4,0 kW weight:0,65 t Dimensions (WxDxH):1,05 x 1,25 x 1,5 m

material width:250 mm material thickness:0,2 - 2,0 mm no. of straightening rolls:7 straightening roll diameter:60 mm run-in height:1250 mm power capacity:4,0 kW weight:0,65 t Dimensions (WxDxH):1,05 x 1,25 x 1,5 m

material width:250 mm material thickness:0,2 - 2,0 mm no. of straightening rolls:7 straightening roll diameter:60 mm run-in height:1250 mm power capacity:4,0 kW weight:0,65 t Dimensions (WxDxH):1,05 x 1,25 x 1,5 m

Makes: Hilgeland / EW Menn / Ingramatic Diameter ranges 1mm - 20mm

We can offer several thread rolling machines with cylindrical dies, any size.

Fliss bohrer and thread rolling NC machine. Machine was rebuilded in 2019, complete Hardwere, and pneumatic components, and part from electric. Machine can be used for serial tube production, can be aded Robot for manipulating. Machine will be able to connect with a handling robot for fast delivery and high productiion.

CNC Thread rolling and gear burnishing machine ESCOFIER P440 CN CNC Siemens New 2004 - like new 2-roll 2 moving heads 4000 daN rolling pressure workpiece diameter: 100mm max. tool diameter: 180-245mm Swiveling: +/-6°, forward speed: 0.1-20mm/s, reverse speed: 0.1-30mm/s motor power: 8.6kW New: 2004 Condition: like new

ORT 3RP48 CN CNC / PLC thread rolling machine scaffolding sleeves threading, shelves studs threading electronic overhaul/retrofit Under power in our warehouse in Gussago BS. Test run possible Mimu Machine Tools

MAX CAPASITY 20 T

Inv. Num. : 7925 Type: UPW 25.1 Producer: VEB Created: 1988 Parameters: Rolling force: 25 t Cylinder width: 250 mm Shaft diameter: 80 mm Rise: 0.5-5 mm Weight: 2900 kg Equipment: Support ruler Boundary rings Set of threading cylinders Infinitely adjustable spindle speed

Laminating pressure: 100 kN, Ø Pieces: 2mm min; 40mm max, Passed: 3.5mm max, Grooving step: 1.75mm max, Roller width: 70mm, Ø roller: 80mm min; 120mm max, Speed of roller shafts: 32 51 95 150 rpm, Ø roller bearing shaft: 40 standard, Wheelbase: 80mm min; 165mm max, Work career: 7 min, Advance: from 0.5mm/s to 6mm/s, Laminating time: from 0.1s to 100s, Break time: from 0.1s to 100s, main engine: 3 Kw, Electrical power consumed: 4.68 Kw, Tank capacity: 80 L, Weight approx.: 750 Kg

Laminating pressure: 70 Kn, Ø Pieces: 2mm min; 30mm max, Passed: 3mm max, Grooving step: 1.75mm max, Roller width: 50mm max, Ø roller: 73mm min; 110mm max, Speed of roller shafts: 90 rpm, Ø roller bearing shaft: 40mm standard, Wheelbase: 80mm min; 135mm max, Work career: 5 min max, Advance: from 0.5mm/s to 3mm/s, main engine: 3 Kw, Electrical power consumed: 3.18 Kw, Tank capacity: 80 L, Weight approx.: 670 Kg

Laminating pressure: 70 Kn, Ø Pieces: 2mm min; 30mm max, Passed: 3mm max, Grooving step: 1.75mm max, Roller width: 50mm max, Ø roller: 73mm min; 110mm max, Speed of roller shafts: 90 rpm, Ø roller bearing shaft: 40mm standard, Wheelbase: 80mm min; 135mm max, Work career: 5 min max, Advance: from 0.5mm/s to 3mm/s, main engine: 3 Kw, Electrical power consumed: 3.18 Kw, Tank capacity: 80 L, Weight approx.: 670 Kg
