used PROFI PRESS pp

pressure: 80 t throat: 250 mm stroke: 10 - 115 mm no. of strokes: 60 Hub/min dayligth: 285 mm distance table - lower edge of ram: 400 mm ram adjustment: 50 mm table-size: 500 x 750 mm ram head dimension: 340 x 440 mm work height max.: 700 mm table hole: 220 mm ram hole: 45 mm total power requirement: 5,5 kW weight of the machine ca.: 4 t dimensions of the machine ca.: 1,5 x 1,4 x 2,5 m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. This high  ...

pressure: 30 t throat: 180 mm stroke: 10 - 75 mm no. of strokes: 125 Hub/min dayligth: 225 mm distance table - lower edge of ram: 300 mm ram adjustment: 50 mm table-size: 360 x 560 mm ram head dimension: 260 x 340 mm work height max.: 670 mm table hole: 140 mm ram hole: 35 mm total power requirement: 2,2 kW weight of the machine ca.: 2,8 t dimensions of the machine ca.: 1,1 x 1,3 x 2,0 m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. This hig ...

pressure: 125 t throat: 300 mm stroke: 10 - 135 mm no. of strokes: 50 Hub/min dayligth: 315 mm distance table - lower edge of ram: 450 mm ram adjustment: 60 mm table-size: 600 x 900 mm ram head dimension: 315 x 550 mm work height max.: 800 mm table hole: 250 mm ram hole: 50 mm total power requirement: 11,0 kW weight of the machine ca.: 5,5 t dimensions of the machine ca.: 1,65 x 1,68 x 2,87 m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. Thi ...

pressure: 100 t distance between columns: 1100 mm stroke: 380 mm working feed: 2,47 mm/sec : 950 adjustment of press crosshead: 1100 mm slide adjustment -horizontal: 2150 mm tank capacity: min 30 l feed speeds: 7,54 mm/sec return speed: 9,06 mm/sec Pressure power: 258 bar table-size: 1740 x 996 mm total power requirement: 2,2 kW weight of the machine ca.: 1,65 t dimensions of the machine ca.: 1,1 x 0,7 x 0,72 m This Profi Press portal press with a manually movable portal is made in the Netherlands and has a 160 tons capacity. The quality of these hydraulic portal presses is very high and the operation of the press is similar to the operation of our well-known motorised workshop presses (they are made in the same factory). Please find the technical specifications of this type of Profi Press below and do not hesitate to request a free quotation or to contact us for any further information. ...

pressure: 60 t throat: 235 mm stroke: 10 - 100 mm no. of strokes: 60 Hub/min dayligth: 270 mm distance table - lower edge of ram: 370 mm ram adjustment: 50 mm table-size: 470 x 700 mm ram head dimension: 310 x 410 mm work height max.: 670 mm table hole: 190 mm ram hole: 40 mm total power requirement: 4,0 kW weight of the machine ca.: 3,5 t dimensions of the machine ca.: 1,23 x 1,46 x 2,35 m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. This  ...

pressure: 160 t distance between columns: 1100 / 1500 (Option) mm stroke: 400 mm working feed: 2,4 mm/sec : 700 slide adjustment -horizontal: 2150 mm tank capacity: min 30 l feed speeds: 7,48 mm/sec pressing speed: 2,4 mm/sec return speed: 9,35 mm/sec Pressure power: 255 bar table-size: 1740 x 996 mm total power requirement: 3 kW weight of the machine ca.: 2185 t dimensions of the machine ca.: 1,74 x 1,73 x 2,185 m This Profi Press portal press with a manually movable portal is made in the Netherlands and has a 160 tons capacity. The quality of these hydraulic portal presses is very high and the operation of the press is similar to the operation of our well-known motorised workshop presses (they are made in the same factory). Please find the technical specifications of this type of Profi Press below and do not hesitate to request a free quotation or to contact us for any further informat ...

pressure: 160 t distance between columns: 1500 mm stroke: 400 mm working feed: 2,4 mm/sec : 700 slide adjustment -horizontal: 2150 mm tank capacity: min 30 l feed speeds: 7,48 mm/sec pressing speed: 2,4 mm/sec return speed: 9,35 mm/sec Pressure power: 255 bar table-size: 1740 x 996 mm total power requirement: 3 kW weight of the machine ca.: 2,65 t dimensions of the machine ca.: 1,74 x 1,73 x 2,185 m This Profi Press portal press with a manually movable portal is made in the Netherlands and has a 160 tons capacity. The quality of these hydraulic portal presses is very high and the operation of the press is similar to the operation of our well-known motorised workshop presses (they are made in the same factory). Please find the technical specifications of this type of Profi Press below and do not hesitate to request a free quotation or to contact us for any further information. The data  ...

pressure: 150 t distance between columns: 1565 mm stroke: 450 mm : 700 mm adjustment of press crosshead: 1100 mm slide adjustment -horizontal: 2150 mm feed speeds: 9,0 mm/sec pressing speed: 2,0 mm/sec return speed: 15,4 mm/sec Pressure power: 320 bar table-size: 1550 x 3000 mm table height: 600 mm total power requirement: 15,4 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3250 x 2500 x 2550 m This 150 ton gantry press is eminently suitable for straightening large and heavy structures and sheets. These Profi Press portal presses have a movable frame and a movable cylinder. Thanks to these features you have an easy access the different pressing and straightening points of the material. The longitudinal displacement of the frame is carried out by a frequency inverter and cogged belt to ensure precise slides. The lateral movement of the cylinder / headstock is motorised ...

Press capacity: 60 ton Stroke: 400 mm Daylight: 500 mm Table surface area : 500 x 500 mm Slide area: 500 x 500 mm Table height over floor: 850 mm Approach speed: 100 mm / sec Working speed: 10 mm / sec Return speed: 150 mm / sec Required power: 7,5 kW Dimensions L x W x H: 1500 x 1400 x 2600 mm Weight of machine approx.: 3,5 ton

Press capacity: 30 ton Stroke: 400 mm Daylight: 500 mm Table surface area : 500 x 500 mm Slide area: 500 x 500 mm Table height over floor: 850 mm Approach speed: 100 mm / sec Working speed: 10 mm / sec Return speed: 150 mm / sec Required power: 7,5 kW Dimensions L x W x H: 1500 x 1400 x 2600 mm Weight of machine approx.: 2,5 ton

pressure: 100 t distance between columns: 1500 mm stroke: 380 mm working feed: 2,47 mm/sec : 700 adjustment of press crosshead: 1500 mm slide adjustment -horizontal: 1740 mm feed speeds: 7,54 mm/sec return speed: 9,06 mm/sec Pressure power: 258 bar table-size: 1740 x 1396 mm total power requirement: 2,2 kW weight of the machine ca.: 2060 kg dimensions of the machine ca.: 1,74 x 2,07 x 2,04 m This 100 ton straightening press has a manually movable portal and is exclusively made in the Netherlands. Thanks to the movable portal and cylinder you can easily reach every point of the ‘to be pressed’ surface. The design of this portal press makes it possible to place heavy material on the large working table with a crane and to slide the portal over the material when the pressing starts. The quality of these hydraulic straightening presses is very high. Furthermore, the hydraulic unit is equ ...

pressure: 300 t distance between columns: 2560 mm stroke: 400 mm working feed: 3,8 mm/sec piston stroke: 300 mm : 700 mm adjustment of press crosshead: 2000 mm slide adjustment -horizontal: 3000 mm tank capacity: min 30 l feed speeds: 9 mm/min pressing speed: 2 mm/sec return speed: 15 mm/sec total power requirement: 10 kW weight of the machine ca.: 13 t dimensions of the machine ca.: 3,5 x 3,05 x 2,9 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 220 t distance between columns: 2065 mm stroke: 400 mm working feed: 3,8 mm/sec piston stroke: 300 mm : 700 mm adjustment of press crosshead: 1500 mm slide adjustment -horizontal: 2500 mm tank capacity: min 30 l feed speeds: 13 mm/sec pressing speed: 2,7 mm/sec return speed: 24 mm/sec total power requirement: 10 kW weight of the machine ca.: 13 t dimensions of the machine ca.: 3,5 x 3,05 x 2,9 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Press capacity: 100 ton Stroke: 400 mm Daylight: 500 mm Table surface area : 800 x 500 mm Slide area: 800 x 500 mm Table height over floor: 850 mm Approach speed: 100 mm / sec Working speed: 10 mm / sec Return speed: 160 mm / sec Required power: 7,5 kW Dimensions L x W x H: 1600 x 1700 x 2930 mm Weight of machine approx.: 5,5 ton

Press capacity: 50 ton Throat depth: 265 mm Stroke: 250 mm Daylight: 400 mm Table surface area : 700 x 450 mm Slide area: 550 x 300 mm Table height over floor: 850 mm Approach speed: 32 mm / sec Working speed: 6,3 mm / sec Return speed: 42 mm / sec Required power: 4 kW Dimensions L x W x H: 1290 x 1160 x 2085 mm Weight of machine approx.: 1,75 ton

pressure: 28 t stroke: 180 mm table-size: 300 x 550 mm total power requirement: 4 kW weight of the machine ca.: 0,650 t diameter of piston: 180 mm working feed: 2 mm/sec return speed: 20 mm/sec pressure capacity max.: 200 bar toolpiece height min.: 200 mm dimensions of the machine ca.: 1150 x 750 x 1103 mm This horizontal straightening press is designed for a wide variety of bending, profiling and straightening operations. ? ?The application of this Profi Press horizontal bending / straightening press varies depending on the accessories that can be installed on the worktable, on the tool mount and in the punch- and pin holes. This Profi Press model, the HB-28, is equipped with an angular graduation on the worktable for easy bend measurements and this horizontal press can be delivered with several tools (for example block punches) that can be mounted on the tool mount and tools that can b ...

: 50 mm roll diameter: 150 mm revolutions per minute: 10 U/min voltage: 400 V / 50 V adjustment movement hydraulic up to: 120 mm motor speed: 1400 U/min total power requirement: 1,5 kW weight of the machine ca.: 430 kg dimensions of the machine ca.: 1200 x 800 x 1750 mm Horizontal and vertical position, optionally two or three driven rollers, standard roller set, lateral guide rollers, foot pedal with safety button, according to CE, operating instructions, The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 50 mm roll diameter: 150 mm revolutions per minute: 10 U/min adjustments: 120 mm total power requirement: 1,5 kW weight of the machine ca.: 430 kg dimensions of the machine ca.: 1,2 x 0,8 x 1,75 mm The PB 50-3 H is a hydraulic profile bending machine: we produce thisprofilebender in Europe and deliver it directly from our stock. This hydraulic profile bending machine has a shaft diameter of 50 mm and 3 driven rolls. It is easy to switch between working with two or three driven rolls via the gearshift on the side of the machine. Operation of the profile bender is done by a foot pedal and with the pedals you choose the turning direction of the rolls. Our PB 50-3 H has a handpump to adjust the position of the upper / centre roll with hydraulics. The position of this upper roll can be read out on a scale and on the digital display (0,1 mm). Furthermore, our Profi Bend machines can work in  ...

: 50 mm roll diameter: 148 mm revolutions per minute: 13,6/27,2 U/min total power requirement: 1/1,4 kW weight of the machine ca.: 420 kg dimensions of the machine ca.: 800x920x1450 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 16 t plate thickness: 4 mm no. of strokes: 70 Hub/min stroke speeds: 1,7 sec. working feed: 2/9.8 mm/sec return speed: 20 mm/sec piston stroke: 70 mm arm length:: 160 mm total power requirement: 2,2 kW weight of the machine ca.: 350 kg dimensions of the machine ca.: 0,8 x 0,45 x 1,43 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 10 t plate thickness: 4 mm no. of strokes: 26,6 Hub/min stroke speeds: 1,7 sec. total power requirement: 2,2 kW weight of the machine ca.: 190 kg dimensions of the machine ca.: 0,68 x 0,44 x 1,214 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 10 t stroke: 30 mm table surface area: 105 x 366 mm distance between columns: 366 mm column daylight: 70 mm : 32 mm total power requirement: - kW weight of the machine ca.: 55 kg dimensions of the machine ca.: 500 x 700 x 1030 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 15 t stroke: 160 mm press capacity: 147,15 kn Pressure power: 382,2 bar column daylight: 555 mm : 80 tank capacity: 1,5 l distance between columns: 134 mm weight of the machine ca.: 134 kg dimensions of the machine ca.: 825 x 600 x 1880 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 300 t stroke: 450 mm throat: 450 mm work speed: 2,1 m/min ajustment speed: 10 mm/sec return speed: 16 mm/sec pressure: 320 bar diameter of piston: 60 mm opening stroke: 900 mm table-size: hinten / back 2500 x 750 mm Table dimensions: Main 750 x 750 mm total power requirement: 7,5 kW weight of the machine ca.: 15,3 t dimensions of the machine ca.: 3,35 x 2,5 x 1,6 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t stroke: 400 mm tank capacity: 51 l pressing speed: 2,40 mm/sec column daylight: 1500 mm feed speeds: 7,48 mm/sec return speed: 9,35 mm/sec Pressure power: 255 bar engine output: 3,0 kW speeds:: 2 : 280 mm range L-W-H: 2125 x 935 x 2270 mm weight of the machine ca.: 1430 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
