Main spindle: Spindle bore (I.D.): 80 mm Spindle nose: ASA A2-8 Revolver: Automatic 4-cavity turret SQT-190-87-C Lining (front): 3-jaw universal chuck ASA8 Diameter: Ø 315 mm Speed: 1250 rpm Inner Passage (I.D.): 103 mm Accessories: Set of 3 basic jaws Ø 315 mm Accessories: Set of 3 hard top jaws Ø 315 mm Accessories: Set of 3 soft top jaws Ø 315 mm Lining (back): 3-jaw universal chuck (rear) Diameter: Ø 315 Inner Passage (I.D.): 103 mm
Digital Turning diameter 120 mm Turning length 700 mm Spindle speed 2000 min-1 Tailstock
Key data: 400 mm, 1000 mm
Pinacho Mustang 200 - CNC lathe - Fagor 8055 CNC control - Operating modes: manual/cycle-controlled - 8-cavity tool turret - Year of construction 2001 Specifications Capacity: - Center height: 200 mm - Center width: 1000 mm - Permissible Ø over guide bed: 400 mm - Permissible Ø over longitudinal slide: 370 mm - Permissible Ø over cross slide: 210 mm - Bed width: 300 mm Headstock: - Bore main spindle: 65 mm - Main spindle nose: Camlock-n°6 / DIN 55027-n°6 - Morse taper of the main spindle: MK5 - Spindle speeds: 2 - Constant cutting speed: 0-750 / 750-3000 rpm Feeds: - Working thrust Z/X: 0 - 7000 mm/min - Rapid traverses Z/X: 10 m/min Tailstock: - Tailstock Ø: 58 mm - Tailstock shaft travel: 155 mm - Morse taper tailstock: 4 Engines: - Power main motor: 7.5 kW - Power DC motor Z-axis: 6.8 Nm - Power DC motor X-axis: 3.4 Nm - Motor pump power: 0.57 ...
Details Turning diameter 165 mm Turning length 1000 mm Total power requirement 2 kW Turning diameter over bed 335 mm Rotary diameter via tool carriage 310 mm large turning diameter via cross slide 168 mm Bed width 250 mm Main spindle diameter 42 mm Main spindle nose CAMLOCK n-5 - DIN 55027 Morse taper 4 Spindle speeds 9 Speed range: 60-2000 rpm max. working feed 0-5000 mm/sec Rapid traverse 5 m/min Shaft diameter 48 mm Tailstock-Spindle Travel 140 mm Machine weight approx. 1100 kg Control CNC Control Name FANUC 21i/210i
Universal CNC cycle separation machine of the brand Pinacho suitable for tooling, fixture construction, training and mold making Circumferential diameter 360mm Center width 1000mm Control Fagor 8055 Tailstock MK 3 Tool station Barufaldi 6-fold Speed 1-4000rpm Connection 380V - 5.5 KW
Universal CNC cycle separation machine of the brand Pinacho suitable for tooling, fixture construction, training and mold making Circumferential diameter 360mm Center width 1000mm Control Fagor 8055 Tailstock MK 3 Tool station Barufaldi 6-fold Speed 1-4000rpm Connection 380V - 5.5 KW
Key data: 400 mm, 1000 mm
Pinacho Mustang 200 - CNC lathe - Fagor 8055 CNC control - Operating modes: manual/cycle-controlled - 8-cavity tool turret - Year of construction 2003 Specifications Capacity: - Center height: 200 mm - Center width: 1000 mm - Permissible Ø over guide bed: 400 mm - Permissible Ø over longitudinal slide: 370 mm - Permissible Ø over cross slide: 210 mm - Bed width: 300 mm Headstock: - Bore main spindle: 65 mm - Main spindle nose: Camlock-n°6 / DIN 55027-n°6 - Morse taper of the main spindle: 5 - Spindle speeds: 2 - Constant cutting speed: 0-700 / 700-3000 rpm Feeds: - Working thrust Z/X: 0 - 7000 mm/min - Rapid traverses Z/X: 10 m/min Tailstock: - Tailstock Ø: 58 mm - Tailstock shaft travel: 155 mm - Morse taper tailstock: 4 Engines: - Power main motor: 7.5 kW G0Cmy7Z - Power DC motor Z-axis: 12 Nm - Power DC motor X-axis: 4 Nm - Motor pump power: ...
Pinacho Lathe S-90/180 - With digital display - Width: 200 cm - Depth: 85 cm - Height: 160 cm - With operating instructions Good condition, fully functional, can be viewed and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article can be viewed and tested under power before purchase in order to rule out misunderstandings. Please ask questions before purchasing to avoid confusion. If you have any general questions or would like to make an appointment for a viewing, I can be reached at any time on the telephone number below or above. Errors in the description and prior sale excepted. VAT is shown separately on my invoices. Shipping with forwarding agent.
Inv. Num. : 6889 Type: Taurus 260 Producer: Pinacho Created: 2000 Parameters: Control system: FAGOR Maximum turning length: 1500 mm Maximum turning diameter: 520 mm Maximum main spindle power: 11 kW Minimum main spindle speed: 40 1/min Maximum spindle speed: 2500 1/min Number of tools: 8 pieces Spindle bore: 80 mm Length: 4000 mm Width: 1800 mm Height: 1850 mm Weight: 3500 kg Equipment: Bezels (2 pieces)
This Pinacho STH 400-105Ã3000 was manufactured in 2017. A robust horizontal turning machine with a swing over bed of 400 mm and a distance between centers of 3000 mm. Features a high-torque spindle and CNC-controlled feed for precise heavy-duty turning. Ideal for machining shafts, pipes, and flanges. Consider the opportunity to buy this Pinacho STH 400-105Ã3000 horizontal turning machine. Contact us for more information.
turning diameter:570 mm turning length:- mm control:- Diameter of rotation above the bed slide:360 mm Maximum width:2.000 mm revolutions per minute:max. 2500 U/min :11 kW max. longitudinal feed:7,5 m/min max. transverse feed:7,5 m/min rapid traverse longitudinal:12 m/min rapid traverse cross:15 m/min Pinole diameter:95 mm Pinolenhub:220 mm Pinolen intake: MK 5 weight of the machine ca.:2,97 t dimensions of the machine ca.:3,8m x 1,3m x 2m m Technical description: - Tool turret - automatic - 8-fold (see also options) - CAPTO Revolver Disc - Machine bed - made of perlite casting GG-26 - high stiffness due to strong ribbing - Bed slides - guideways hardened and ground - automatic lubrication of the bed rail - Reitstock - manual - Quick clamp - Operator station - two movable handwheels on the operator panel - a movable handwheel - Control - "Siemens 828 D" CNC control - Siemens "Comfort" (in ...
Manufacturer: Pinacho Model: SP/250 Machine Type:Lathe Year of Manufacture: October 2002 CE marked Find more here - / Contact us at -
Variabele snelheid met frequentie verzenden Distance between centers: 1000 mm Swing over bed: 402 mm Swing over cross-slide: 380 mm Swing in gap: 560 mm Diametre of main spindle bore: 42 mm Power on main spindle: 4 kW Number of speeds: 40 > 2800 rpm Digital screen: yes Length: 2390 mm Width : 910 mm Height: 1625 mm Weight: 1190 kg
This Pinacho Taurus 260 was manufactured in 2000. A robust horizontal turning machine, it features a maximum turning length of 1500 mm and a diameter of 520 mm. Equipped with a spindle speed of up to 2500 1/min and a main spindle power of 11 kW, it includes accessories like steady rests, a hydraulic chuck, and tool holders. Consider the opportunity to buy this Pinacho Taurus 260 horizontal turning machine. Contact us for more information about this machine.
This Pinacho Smart Turn 180/42 1000 was manufactured in 2012. A robust horizontal turning machine featuring a turning length of 1000mm, spindle clearance of 42mm, and a turning diameter of 360mm. It includes an 8-fold tool changer and Fagor 8055tc control. Dimensions are 2.5 x 1.15 x 1.65 m, weighing approximately 1.2t. Consider the opportunity to buy this Pinacho Smart Turn 180/42 1000 horizontal turning machine. Contact us for more information.
This Pinacho SMART 360 was manufactured in 2007. A horizontal turning machine, it represents a solid choice for those in need of reliable turning operations. Contact us for more information.
This Pinacho SMART 260 was manufactured in 2008. A reliable horizontal turning machine, it offers consistent performance for various machining tasks. Ideal for workshops requiring precision in turning operations. Contact us for more information.
This Pinacho SE325 was manufactured in 2018. A reliable horizontal turning machine, it offers consistent performance for various machining tasks. Ideal for workshops seeking a dependable solution for turning operations. Contact us for more information.
Manufacturer: Pinacho Model: Smart Turn 6/180 Power: 7.5 kW Frequency: 50 Hz Control: FANUC CAPACITY • Center height: 180 mm • Center width: 750–1000 mm • Permissible diameter over bed: 360 mm • Permissible diameter over longitudinal slide: 335 mm • Permissible diameter over cross slide: 198 mm • Bed width: 250 mm SPINDLE • Spindle bore: 42 mm • Spindle nose: CAMLOCK no. 5 (DIN 55027 no. 5) • Spindle taper: Morse taper no. 4 • Number of spindle speeds: 1 • Cutting speed (constant surface speed): 0–4000 U/min FEED • Working feed Z,X (mm/min): 0–10000 mm/min • Rapid traverse Z,X (m/min): 10 m/min TAILSTOCK • Tailstock quill diameter: 58 mm • Tailstock quill travel: 200 mm • Tailstock taper: Morse taper no. 3 MOTORS • Main motor power: 5.5 kW • Feed force longitudinal (N): 4500 N • Feed force cross (N): 3500 N • Cool ...
weight of the machine ca.: 3,9 t : 50 control: Fanuc changer: 6 fach centre distance: 1500 mm spindle bore: 80 mm available since 22th of september: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Pinacho SC 200 Ø 402 x 1000 mm Distance between centers: 1000 mm Swing over bed: 402 mm Swing over cross-slide: 380 mm Swing in gap: 560 mm Diametre of main spindle bore: 42 mm Power on main spindle: 4 kW Number of speeds: 40 > 2800 rpm Digital screen: yes Length: 2390 mm Width : 910 mm Height: 1625 mm Weight: 1190 kg
Center width: 1000mm, turning diameter over bed/crank/trolley: 360mm/510mm/205mm, spindle bore: 42mm, speed: 2100rpm, machine dimensions X/Y/Z: approx. 1950mm/900mm/1350mm, weight: approx. 750kg. On-site inspection is possible.
turning diameter: 10/300 mm turning length: 1500mm +/-0.1mm mm control: serial number: 53364 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
A Pinacho CNC precision parallel lathe is available. Center height: 180mm, center width: 750mm-1000mm, turning diameter over guide bed/longitudinal slide/cross slide: 360mm/335mm/198mm, bed width: 250mm, bore: 42mm, speed: 4000rpm, feed X/Z: 10m/min, rapid traverse X/Z: 10m/min. Tailstock shank diameter: 58mm, tailstock shank length: 200mm, Morse taper: MK3, min. travel of moving/fixed steady rest: 10mm, max. travel of moving/fixed steady rest: 70mm/114mm, control: Fanuc 0i. Documentation available. On-site inspection is possible
Type: DH 132S 8/4 2,2/3,3 kW 720/1440 rpm For Pinacho lathe SP 90 / 165
Ref. -No.: 10314 Manufacturer: PINACHO Year of construction: 2005 Type of control: Konventionell Storage location: Halberstadt Country of origin: Spain Travel quill: 180 mm Turning Diameter: 630 mm Turning Length: 3000 mm Turning Diameter Over Bed: 620 mm Cross Movement. (X-Axis): 365 mm Tailstock Quill Diameter: 72 mm Turning diameter over cross slide: 880 mm
