used MONFORTS rnc

Key data: 380 mm, 500 mm, 6000 1/min

CNC machine Monforts type RNC 3 The RNC 3 was in operation until September, in good condition, immediately available. Specifications - max length to rotate : 500 [mm] - max diameter to rotate : 380 [mm] - Spindle motor : 15 [kW] - Rotation speed : 6000 [rpm] - Number of VDI30 tools on turret : 12 - Rod passage : 65 [mm] Accessories - CNC FANUC 11T control - Pincer chuck -Conveyor The machine can be viewed at any time. Free loading. Transport possible throughout Europe If you have any questions, just write or call Maschinenhandel Nord Gerstenstraße 2 17034 Neubrandenburg Tel. 016096679844 Technical specifications are non-binding. Errors excepted.

Key data: 380 mm, 500 mm, 6000 1/min

CNC machine Monforts type RNC 5 The RNC 5 was in operation until September, in good condition, immediately available. Specifications - max length to rotate : 500 [mm] - max diameter to rotate : 380 [mm] - Spindle motor : 15 [kW] - Rotation speed : 6000 [rpm] - Number of VDI30 tools on turret : 12 - Rod passage : 65 [mm] Accessories - CNC FANUC 11T control - Pincer chuck -Conveyor The machine can be viewed at any time.

Monforts RNC7 Type of machine: CNC lathe Manufacturer: Monforts Model: RNC 7 Year of manufacture: 1991 Control: Fanuc Technical data: Travel X/Z 415/1100mm, tool measurement, tailstock, Röhm lathe chuck, spindle speed 4000 min-1, disc turret with VDI60 interface, number of tool places: 12, turning length (max.) 1000mm, revolving Ø over bed (max.) 720mm, revolving Ø over radial slide (max.) 550mm, dimensions: 4930x2790x2200mm without chip conveyor, weight: approx. 12000kg

Key data: 425 mm, 1000 mm, 4000 1/min

CNC lathe Monforts RNC 5 at call The reliable RNC5 machine has a spindle bore of 40 mm and a diameter of 180 mm. Manufacturer: MONFORTS Model: RNC5 Width: 3500 MM Depth: 2340 MM Height: 1960 MM Weight: 8500 KG Main drive Spindle bore: 40 MM MOVEMENT X-AXIS : 270 MM Z-AXIS : 1020 MM Total power requirement: 32 KW Chip conveyor included - TURNING LENGTH 1000MM - SPINDLE DIAMETER 180MM - TOOLS 12 - CIRCULATING DIAMETER VIA CROSS SLIDE 425MM - ROTARY CUTTER OVER BED 600MM The machine can be viewed at any time. Free loading. Transport possible throughout Europe

Machine Details Stock number 1105-03806 Machine type CNC lathe - inclined bed machine Make MONFORTS Type RNC 400 AC Year of construction 2001 Control type CNC Control SIEMENS 810 D Storage location FRANCE Country of origin Germany Delivery time by arrangement Freight base from HAGUENAU FRANCE Technical details Turning diameter 420 mm Turning length 600 mm Control SIEMENS 810 D Speed range 70 - 4000 rpm Information With C axis and driven tool holders Tool carrier disc turret VDI 40 (12pcs), bore 40 mm; Power clamping futte DIA 315 MM, chip conveyor coolant device, TAILSTOCK CNC SIEMENS 810 D 24 KW 4000 RPM good condition WITH ACCESSORIES

Key data: 380 mm, 500 mm, 6000 1/min

CNC machine Monforts type RNC 3 generally good condition, but currently not ready for use due to a defective electric motor. The machine has always been serviced and was in operation until recently. Sold as a spare parts donor. Specifications - max length to rotate : 500 [mm] - max diameter to rotate : 380 [mm] - Spindle motor : 15 [kW] - Rotation speed : 6000 [rpm] - Number of VDI30 tools on turret : 12 - Rod passage : 65 [mm] Accessories - CNC FANUC 11T control - Pincer chuck -Conveyor The machine can be viewed at any time. Free loading. Transport possible throughout Europe If you have any questions, just write or call Maschinenhandel Nord Gerstenstraße 2 17034 Neubrandenburg Tel. 016096679844

Max. turning diameter: 200mm Max. turning length: 650mm Spindle opening: 65mm Control: SIEMENS 810D Dimensions(L x W x H): 6500mm x 3500mm x 2500mm Weight: 10t.

Turning length (max.) 1000 mm Circulation diameter (max.) 400 mm Turning diameter over bed 410 mm Turning diameter over slide 280 mm Center width 1000 mm X-axis 250 mm Z-axis 620 mm Number of tools 12 Driven tool stations 12 Spindle speeds 4000 rpm Spindle motor power 26.5 kW Tailstock Yes Bar loader No ------------------- Weight 7500 kg

- LNS Quick Load Servo 80 S2 short bar loading magazine (for mounting on the lathe) - Tools + tool trolley - Collets - Control 840D

turning diameter: 420 mm turning length: 1000 mm control: Fanuc 10 T Monforts Control F spindle passage: 65 mm turning speeds: 4000 U/min chip conveyor: Tool turret 12 positions: total power requirement: 22 kW weight of the machine ca.: 4 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Type: RNC 5 Plus Mayfran chipconveyor Swing over bed: 600 mm Swing over cross-slide: 425 mm Distance centre tot centre: 1000 mm Spindle cone: A8 Dia of spindle bore: 96 mm Power on the spindle: 18,5 kW Number of speeds: 1 > 4000 rpm Command: GE Fanuc16-T ACCESORIES: yes Toolchanger: yes Number of tools: 12 VDI toolpositions

Description: Including chuck, as well as chip conveyor, foot switch and existing documentation control: GE FANUC SERIES 15 - T, toolchanger positions: 10, weight approx.: 7,000 kg, Approx. Onsite Dimension. (l x w x h): 5,800 x 2,800 x 2,300 mm

Key data: 600 mm, 1000 mm, 4000 1/min

CNC lathe Monforts Type: RNC 5 High-quality high-performance lathe with a wide range of performance in universal 2- to 3-axis machining, with a turning length of 1,000 mm and a circulation diameter above bed of 600 mm. The RNC series meets all requirements; Various spindle assemblies and drive variants, Y-axis, hard turning package, automatic loading and unloading equipment, tool and workpiece measurement, tailstock and steady rest are all options available. Available with Fanuc or Siemens control. Turning diameter 600 mm Turning length 1000 mm Control MCS 800 (Siemens 840 C) Spindle speed 1 4000 1/min Spindle speed 2 4000 1/min Drive power L / R 18/24 kW Torque at the spindle 630 nM C-axis 0.001° Revolver No. 1 stations / of which driven 12/12 VDI 40 Turret No. 2 stations / of which driven 12/12 VDI 40 Speed range - milling 3000 1/min Drive power - milling spindle 8. ...

turning diameter: 630 mm turning length: 200 mm control: MTC K turning diameter over slide rest: 360 mm turning speeds: 1800 U/min 3-jaw chuck: 315 mm Holder Multifix: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 302 mm turning length: 600 mm control: Siemens type: 810 T tail stock: Tool changer: 12 Pos. tool taper: VDI 30 chip conveyor: 3-jaw-chuck diameter: 200 mm swing diameter: 400 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

swing diameter: 530 mm turning diameter: 150 mm spindle passage: 65 mm control: SIEMENS 840 C travel x1: 175 mm travel y1: +/- 70 mm travel z1: 433 mm travel x2: 175 mm travel y2: +/- 70 mm travel z2: 433 mm spindle turning speed range: 38 - 4000 U/min C-axis: 2 x tool turret: 2 x 12 Pos. number of driven tool stations: 2 x 12 total power requirement: 33 kW dimensions of machine L x W x H: 3,95 x 2,49 x 2,6 m Accessories: collet fixtures on main spindle and sub spindle, one collet for main spindle and one for sub spindle, various tool holders (for driven tools as well), various spindle reductions, chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: MONFORTS CONTROL SYSTEM MTC Technical data Centre height: 250 mm Distance between centres: 1500 mm Swing over cross-slide: 290 mm Swing over bed: 500 mm Taper in spindle: DIN 55027 Carriage: Transversal strocke (X axis): 265 mm Spindle speeds: number (steps): 3 from: 3 rpm up to: 2800 rpm Taper in tailstock: Morse taper: 5 MT Spindle stroke: 160 mm Spindle diameter: 80 mm Rapid traverse X: 5 m/min Rapid traverse Z: 10 m/min Spindle motor: 16.5 kW Voltage 50 Hz 3x: 400 Volt Total power required: 16 kVA Machine´s weight about: 3000 kg Various accessories: 3-jaw chuck diameter: ROTA-S 250 mm 4-jaw chuck diameter: 250 mm Set of jaws Set of jaws hard Travelling steady Lamp Tailstock Coolant system Interface serial port RS 232 Chip conveyor  ...

BRAND: MONFORTS YEAR: 1999 MODEL: KNC 5 APPLICATION TYPE: TURNING LOCATION: GERMANY MACHINE TYPE: LATHE AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MEASUREMENTS WIDTH: 1550 MM MEASUREMENTS DEPTH: 2830 MM MEASUREMENTS HEIGHT: 1790 MM MACHINE WEIGHT: 3300 KG MAIN DRIVE SPINDLE SPEED RANGE: 2-2800 1/MIN SPINDLE MOTOR POWER: 11-15 KW Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - PEAK WIDTH: 1080/1580 MM - SWING DIAMETER OVER BED: 500 MM - SWING DIAMETER OVER CROSS SLIDE: 290 MM - TRAVEL OF THE CROSS SLIDE: 265 MM - DISPLACEMENT OF THE UPPER SUPPORT: 140 MM - BED WIDTH: 360 MM - WIDTH OF CROSS SLIDE: 220 MM - BED SLIDE GUIDE LENGTH: 615 MM - TURNING TOOL CROSS-SECTION: 32X25 MM

Control: SIEMENS / MTC K Max.turning length: 1000 mm Max swing diametr over bed: 500 mm Quick Change Toolposts:1 Coolant tank:100l Made in Germany

CNC lathe make MONFORTS type DNC 5Year 1995 with C-axis and driven tool stationsCircumference diameter: 560 mmNumber of revolvers: 2Travel distance Z1 / Z 600/600 mmTravel X1 / X 260/260 mmMax. Spindle distance: 1460 mmSpindle passage: 85 mmSpindle flange: A8 / A8feed drivesRapid traverse Z1 / Z 15/15 m / minRapid traverse X1 / X 12/12 m / minFeed force Z1 / Z 11900/11900 NFeed force X1 / X 6600/6600 NNumber of revolvers: 2Number of tools per turret: 12Straight shank: 40 mmTurning tool shank: 25 x 25 mmSpeed range: 5 - 4000 rpm.Drive power: 18/24 kWWith:- CNC control SIEMENS 840 C- C axis- 2 tool turrets with driven tool stations- without driven tools- 2 opposite spindles- 1 set of tool holders- Chip conveyorSingle-layered run!usedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors except ...

This MONFORTS KNC6 x 2000 Lathe was manufactured in the year 1994 in Germany. It is equipped with a MONFORT CTK control unit.

This Monforts Knc 5 Lathe was manufactured in the year 1999. The machine has a spindle speed of 2-2800 rpm.

Center distance: 1500mm, rotational speed: 3-2800/min, max. swing over bed/ slide: 500/ 290mm, controls: Monforts Control-System K, weight: 3.3t, with accessories, without tools.

Center width: 1500mm, max. turning diameter: over bed: 500mm, over cross slide: 290mm, max. spindle speed: 2800rpm, control: Monforts Control-System K, weight: 3300kg. Including Coromant Capto with inserts, workbench without tools, grating.

Material thickness: 0..4-1mm, speed: 0-60m/min, working width: 2200mm, with calibrated length measurement Elovis and spare parts.
