used MONFORTS dnc

CNC lathe make MONFORTS type DNC 5Year 1995 with C-axis and driven tool stationsCircumference diameter: 560 mmNumber of revolvers: 2Travel distance Z1 / Z 600/600 mmTravel X1 / X 260/260 mmMax. Spindle distance: 1460 mmSpindle passage: 85 mmSpindle flange: A8 / A8feed drivesRapid traverse Z1 / Z 15/15 m / minRapid traverse X1 / X 12/12 m / minFeed force Z1 / Z 11900/11900 NFeed force X1 / X 6600/6600 NNumber of revolvers: 2Number of tools per turret: 12Straight shank: 40 mmTurning tool shank: 25 x 25 mmSpeed range: 5 - 4000 rpm.Drive power: 18/24 kWWith:- CNC control SIEMENS 840 C- C axis- 2 tool turrets with driven tool stations- without driven tools- 2 opposite spindles- 1 set of tool holders- Chip conveyorSingle-layered run!usedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors except ...

Key data: 560 mm

Monforts DNC 5, Built in 1998, Control Fanuc Series 16 T, max. swivel Ø 560 mm, 2 x C axis, 2 x Y axis +/- 50 mm, max. spindle spacing 1460 mm, Main / counter spindle chuck Ø 250 mm, max. bar passage max 82 mm, 2 turrets 12-fold driven all stations, Conveyor Machine weight 13,000 kg,

swing diameter: 530 mm turning diameter: 150 mm spindle passage: 65 mm control: SIEMENS 840 C travel x1: 175 mm travel y1: +/- 70 mm travel z1: 433 mm travel x2: 175 mm travel y2: +/- 70 mm travel z2: 433 mm spindle turning speed range: 38 - 4000 U/min C-axis: 2 x tool turret: 2 x 12 Pos. number of driven tool stations: 2 x 12 total power requirement: 33 kW dimensions of machine L x W x H: 3,95 x 2,49 x 2,6 m Accessories: collet fixtures on main spindle and sub spindle, one collet for main spindle and one for sub spindle, various tool holders (for driven tools as well), various spindle reductions, chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 600 mm, 1000 mm, 4000 1/min

CNC lathe Monforts Type: RNC 5 High-quality high-performance lathe with a wide range of performance in universal 2- to 3-axis machining, with a turning length of 1,000 mm and a circulation diameter above bed of 600 mm. The RNC series meets all requirements; Various spindle assemblies and drive variants, Y-axis, hard turning package, automatic loading and unloading equipment, tool and workpiece measurement, tailstock and steady rest are all options available. Available with Fanuc or Siemens control. Turning diameter 600 mm Turning length 1000 mm Control MCS 800 (Siemens 840 C) Spindle speed 1 4000 1/min Spindle speed 2 4000 1/min Drive power L / R 18/24 kW Torque at the spindle 630 nM C-axis 0.001° Revolver No. 1 stations / of which driven 12/12 VDI 40 Turret No. 2 stations / of which driven 12/12 VDI 40 Speed range - milling 3000 1/min Drive power - milling spindle 8. ...

BRAND: MONFORTS YEAR: 1999 MODEL: KNC 5 APPLICATION TYPE: TURNING LOCATION: GERMANY MACHINE TYPE: LATHE AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MEASUREMENTS WIDTH: 1550 MM MEASUREMENTS DEPTH: 2830 MM MEASUREMENTS HEIGHT: 1790 MM MACHINE WEIGHT: 3300 KG MAIN DRIVE SPINDLE SPEED RANGE: 2-2800 1/MIN SPINDLE MOTOR POWER: 11-15 KW Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - PEAK WIDTH: 1080/1580 MM - SWING DIAMETER OVER BED: 500 MM - SWING DIAMETER OVER CROSS SLIDE: 290 MM - TRAVEL OF THE CROSS SLIDE: 265 MM - DISPLACEMENT OF THE UPPER SUPPORT: 140 MM - BED WIDTH: 360 MM - WIDTH OF CROSS SLIDE: 220 MM - BED SLIDE GUIDE LENGTH: 615 MM - TURNING TOOL CROSS-SECTION: 32X25 MM

Control: SIEMENS / MTC K Max.turning length: 1000 mm Max swing diametr over bed: 500 mm Quick Change Toolposts:1 Coolant tank:100l Made in Germany

turning diameter: 630 mm turning length: 200 mm control: MTC K turning diameter over slide rest: 360 mm turning speeds: 1800 U/min 3-jaw chuck: 315 mm Holder Multifix: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 302 mm turning length: 600 mm control: Siemens type: 810 T tail stock: Tool changer: 12 Pos. tool taper: VDI 30 chip conveyor: 3-jaw-chuck diameter: 200 mm swing diameter: 400 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- LNS Quick Load Servo 80 S2 short bar loading magazine (for mounting on the lathe) - Tools + tool trolley - Collets - Control 840D

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: MONFORTS CONTROL SYSTEM MTC Technical data Centre height: 250 mm Distance between centres: 1500 mm Swing over cross-slide: 290 mm Swing over bed: 500 mm Taper in spindle: DIN 55027 Carriage: Transversal strocke (X axis): 265 mm Spindle speeds: number (steps): 3 from: 3 rpm up to: 2800 rpm Taper in tailstock: Morse taper: 5 MT Spindle stroke: 160 mm Spindle diameter: 80 mm Rapid traverse X: 5 m/min Rapid traverse Z: 10 m/min Spindle motor: 16.5 kW Voltage 50 Hz 3x: 400 Volt Total power required: 16 kVA Machine´s weight about: 3000 kg Various accessories: 3-jaw chuck diameter: ROTA-S 250 mm 4-jaw chuck diameter: 250 mm Set of jaws Set of jaws hard Travelling steady Lamp Tailstock Coolant system Interface serial port RS 232 Chip conveyor  ...

Monforts RNC7 Type of machine: CNC lathe Manufacturer: Monforts Model: RNC 7 Year of manufacture: 1991 Control: Fanuc Technical data: Travel X/Z 415/1100mm, tool measurement, tailstock, Röhm lathe chuck, spindle speed 4000 min-1, disc turret with VDI60 interface, number of tool places: 12, turning length (max.) 1000mm, revolving Ø over bed (max.) 720mm, revolving Ø over radial slide (max.) 550mm, dimensions: 4930x2790x2200mm without chip conveyor, weight: approx. 12000kg

This MONFORTS KNC6 x 2000 Lathe was manufactured in the year 1994 in Germany. It is equipped with a MONFORT CTK control unit.

This Monforts Knc 5 Lathe was manufactured in the year 1999. The machine has a spindle speed of 2-2800 rpm.

Center distance: 1500mm, rotational speed: 3-2800/min, max. swing over bed/ slide: 500/ 290mm, controls: Monforts Control-System K, weight: 3.3t, with accessories, without tools.

Center width: 1500mm, max. turning diameter: over bed: 500mm, over cross slide: 290mm, max. spindle speed: 2800rpm, control: Monforts Control-System K, weight: 3300kg. Including Coromant Capto with inserts, workbench without tools, grating.

Max. turning diameter: 200mm Max. turning length: 650mm Spindle opening: 65mm Control: SIEMENS 810D Dimensions(L x W x H): 6500mm x 3500mm x 2500mm Weight: 10t.

Material thickness: 0..4-1mm, speed: 0-60m/min, working width: 2200mm, with calibrated length measurement Elovis and spare parts.

Turning length (max.) 1000 mm Circulation diameter (max.) 400 mm Turning diameter over bed 410 mm Turning diameter over slide 280 mm Center width 1000 mm X-axis 250 mm Z-axis 620 mm Number of tools 12 Driven tool stations 12 Spindle speeds 4000 rpm Spindle motor power 26.5 kW Tailstock Yes Bar loader No ------------------- Weight 7500 kg

turning diameter: 420 mm turning length: 1000 mm control: Fanuc 10 T Monforts Control F spindle passage: 65 mm turning speeds: 4000 U/min chip conveyor: Tool turret 12 positions: total power requirement: 22 kW weight of the machine ca.: 4 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Type: RNC 5 Plus Mayfran chipconveyor Swing over bed: 600 mm Swing over cross-slide: 425 mm Distance centre tot centre: 1000 mm Spindle cone: A8 Dia of spindle bore: 96 mm Power on the spindle: 18,5 kW Number of speeds: 1 > 4000 rpm Command: GE Fanuc16-T ACCESORIES: yes Toolchanger: yes Number of tools: 12 VDI toolpositions

turning diameter: 555 mm turning length: 1500 mm turning diameter over slide: 290 mm 3-jaw-chuck diameter: 315 mm make: Röhn control: Monforts MTCK quick change tool holder: Multifix C steady: turning speeds: 2-2800 U/min transmission ratio: 3 face slide travel: 235 mm spindle passage: 70 mm tailstock quill taper MT: 5 total power requirement: kW weight of the machine ca.: 3 t dimensions of the machine ca.: 2,9x1,6x1,8 m About usmore than 400 machines in the warehouse over 12000 m² storage area, crane capacity 70 tmore than 1000 items accessories for your workshopYou want to sell machines production lines or your company, then talk to us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine Details Stock number 1105-03806 Machine type CNC lathe - inclined bed machine Make MONFORTS Type RNC 400 AC Year of construction 2001 Control type CNC Control SIEMENS 810 D Storage location FRANCE Country of origin Germany Delivery time by arrangement Freight base from HAGUENAU FRANCE Technical details Turning diameter 420 mm Turning length 600 mm Control SIEMENS 810 D Speed range 70 - 4000 rpm Information With C axis and driven tool holders Tool carrier disc turret VDI 40 (12pcs), bore 40 mm; Power clamping futte DIA 315 MM, chip conveyor coolant device, TAILSTOCK CNC SIEMENS 810 D 24 KW 4000 RPM good condition WITH ACCESSORIES

turning diameter: 800 mm turning length: 2000 mm control: Monfort R&D turning diameter over slide: 520 mm spindle hollow: 88 mm total power requirement: 53 kW weight of the machine ca.: t dimensions of the machine ca.: 4,2x2,2x1,9 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 290 mm turning length: 3000 mm swing dia.: 650 mm swing diameter over face slide: 350 mm spindle bore diameter: 71 mm number of controlled axis: 2 control: Monforts EuroTurn turning speed range: 2- 1800 U/min rapid speed: 10/5 m/min tail stock: MK 6 number of tapers in turret head: Multifix C bed width: 550 mm power requirement: 21/15 kW max. torque on the spindle: 3320 Nm dimensions: m weight of the machine ca.: 6,5 t Used Teach in lathe in good condition Zubehör: - 3 jaw chuck - Multifix C with Capto quick change tool - coolant system - steady - chip conveyor - 4 mech. gear steps (2- 225/ 4- 450/ 8- 900/ 16- 1800 rpm) - electric break main motor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 500 mm turning length: 1000 mm control: MONFORTS CONTROL control: SYSTEM MTC-K turning diameter over bed slide: 290 mm spindle bore: 70 mm spindle turning speed range: 3 - 2800 U/min spindle power: 15 kW max. torque on the spindle: 1530 Nm spindle head: DIN 55027 Gr. 8 feed power X/Z axis: 11300 N rapid travel - longitudinal/face: 10 / 5 m/min bed width: 360 mm travel of cross-slide: 265 mm upper slide travel: 140 mm turning tool - shaft cross cut: 32 x 25 mm tailstock quill diameter: 80 mm tailstock quill stroke: 160 mm tailstock taper MT: 5 total power requirement: kW weight of the machine ca.: 3,1 t dimensions of machine L x W x H: 2,88 x 1,68 x 2,18 m Accessories: 3-jaw chuck ROTA-S plus 250 mmø, 4 pos. toolholder PARAT, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
