used MONFORTS dnc 5

Key data: 560 mm

Monforts DNC 5, Built in 1998, Control Fanuc Series 16 T, max. swivel Ø 560 mm, 2 x C axis, 2 x Y axis +/- 50 mm, max. spindle spacing 1460 mm, Main / counter spindle chuck Ø 250 mm, max. bar passage max 82 mm, 2 turrets 12-fold driven all stations, Conveyor Machine weight 13,000 kg,

Key data: 600 mm, 1000 mm, 4000 1/min

CNC lathe Monforts Type: RNC 5 High-quality high-performance lathe with a wide range of performance in universal 2- to 3-axis machining, with a turning length of 1,000 mm and a circulation diameter above bed of 600 mm. The RNC series meets all requirements; Various spindle assemblies and drive variants, Y-axis, hard turning package, automatic loading and unloading equipment, tool and workpiece measurement, tailstock and steady rest are all options available. Available with Fanuc or Siemens control. Turning diameter 600 mm Turning length 1000 mm Control MCS 800 (Siemens 840 C) Spindle speed 1 4000 1/min Spindle speed 2 4000 1/min Drive power L / R 18/24 kW Torque at the spindle 630 nM C-axis 0.001° Revolver No. 1 stations / of which driven 12/12 VDI 40 Turret No. 2 stations / of which driven 12/12 VDI 40 Speed range - milling 3000 1/min Drive power - milling spindle 8. ...

CNC lathe make MONFORTS type DNC 5Year 1995 with C-axis and driven tool stationsCircumference diameter: 560 mmNumber of revolvers: 2Travel distance Z1 / Z 600/600 mmTravel X1 / X 260/260 mmMax. Spindle distance: 1460 mmSpindle passage: 85 mmSpindle flange: A8 / A8feed drivesRapid traverse Z1 / Z 15/15 m / minRapid traverse X1 / X 12/12 m / minFeed force Z1 / Z 11900/11900 NFeed force X1 / X 6600/6600 NNumber of revolvers: 2Number of tools per turret: 12Straight shank: 40 mmTurning tool shank: 25 x 25 mmSpeed range: 5 - 4000 rpm.Drive power: 18/24 kWWith:- CNC control SIEMENS 840 C- C axis- 2 tool turrets with driven tool stations- without driven tools- 2 opposite spindles- 1 set of tool holders- Chip conveyorSingle-layered run!usedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors except ...
