0 MIKRON universal tool milling machines used machines

WE OFFER VERY NICE CONDITION - MIKRON WF3 S technical details: X-travel longitudinal 500 mm Y-travel cross 500 mm Z-travel vertical 380 mm spindle speed 12-steps 50-2240 UpM /rpm feed 1-750 mm/min spindle taper SK40 table size 800x445 mm drive capacity 7 kW weight 1650 kg

Key data: 420 mm, 250 mm, 350 mm

with Heidenhain TNC 114 digital display Tool holder ISO 40/M16 Travel X/Y/Z 420 x 250 x 350 m 12 spindle speeds from 50 - 2240 Weight approx. 900 kg Central lubrication Bellows NEW! Accuracy in: X-axis 0.005/300 mm Y-axis 0.006/250 mm Z-axis 0.01/300 mm Spindle concentricity 0.003 mm Angular accuracy 0.01/250 Spindle clearance X 0.12, Y 0.04, Spindle noise: very good Very good overall condition!

Key data: 630 mm, 500 mm, 460 mm

Speed range: 31.5 - 3150 rpm Control Heidenhain TNC 155 Feed speed: 1 - 3000 mm/min. in rapid traverse X -Y: 6000 mm/min. in rapid traverse Z: 4000 mm/min.

Mikron WF 32 CH universal milling machine Machine with chips and splash guard cabin Equipped with a Heidenhain TNC355 controller Specifications Manufacturer: Mikron Type: WF 32 CH Control: Heidenhain TNC355 Travel: X 560 mm Y 500 mm Z 400 mm Clamping area: 530 x 900 mm Rapid traverses : X, Y 6,000 mm/min, Z 5,000 mm/min Spindle speed: 20 – 6,300 rpm Dimensions: 2,700 x 2,000 x 2,400 mm Weight: 2,400 kg More items - new and used - can be found in our shop! International shipping costs on request!

x-travel: 400 mm y-travel: 400 mm z-travel: 380 mm total power requirement: 2,6 kW weight of the machine ca.: 1,5t t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 530 mm, 450 mm, 450 mm

5-Axis CNC Machining Center Mikron UCP 600 Year of Make: 2004 Control: Heidenhain iTNC 530 x-travel: 530 mm y-travel: 450 mm z-travel: 450 mm Spindle: SK 40 Speed: 12,000 rpm Swivel table STP: Ø 400 mm Tool changer: 30 x Weight: approx. 6.5 t Switch-on hours: approx. 49,000 h Spindle hours: approx. 2,500 h

MIKRON WF 3 DCM Universal Milling Machine Heidenhain TNC 151 control Table 800x380 mm x-travel 500 mm y-travel 500 mm z-travel 400 mm speed range 3150 rpm drive power 4 kW SK 40 Weight 1700 kg Many Accessories and tools

x-travel: 500 mm y-travel: 500 mm z-travel: 400 mm table-size: 900 x 530 mm control: Heidenhain TNC 355 tool adaptor: ISO 40 | | turning speed range: 40- 4000 U/min rapid speed: 5 / 6 m/min feed speeds: 2 - 3000 | mm/min | power requirement: 6 kW table load: 350 kg dimensions: 2,6 x 1,8 x 2,2 m weight: 2,6 t Univers. milling machine 3 axis - external electric handweel - housing - universal head The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Mikron UM 710/900 Universal Milling Machine High-precision universal tool milling machine from the Swiss quality manufacturer MIKRON, model UM 710/900. The machine comes from a well-groomed operation and impresses with the proverbial micron precision as well as the generous working range (up to 900 mm travel in X). It is ideal for toolmaking, prototyping, training or demanding repair shops. Technical data at a glance (manufacturer's specifications): Working range & axes: Longitudinal travel (X-axis): 710 / 900 mm Transverse travel (Y-axis): 630 mm Vertical travel (Z-axis): 500 mm Working spindle: Tool holder: SK 40 / DIN 69871 Gear stages: 4 Speed range: adjustable (vertical & horizontal) Main Drive & Feed: Drive power spindle: 11 kW (at 44% ED) / 7.5 kW (at 100% ED) Feed speed (X, Y): 0 – 10,000 mm/min (programmable) Feed speed (Z): 0 – 8,000 mm/min  ...

Mikron WF 41C CNC Universal Milling and Drilling Machine Professional, extremely robust CNC universal milling and drilling machine MIKRON WF 41C Due to its stable design, the machine is ideal for workshops, prototype construction, maintenance or demanding toolmaking. The machine is equipped with the proven HEIDENHAIN TNC 155 web control system Thanks to plain text dialog guidance, it is extremely easy to program directly on the machine, masters graphical simulations and allows easy loading of external CNC programs via the serial interface (ideal for CAD/CAM use). Technical data at a glance CNC control Model: HEIDENHAIN TNC 155 Operating modes: manual operation (such as digital display), positioning with manual input, single set, sentence sequence, program test (graphic simulation) Interface: V.24/RS-232-C for data transmission Feed Drives & Travel Paths Travel  ...

x-travel: 560 mm y-travel: 500 mm z-travel: 400 mm Control: TNC 360 spindle speed:: 40-4.000 U / min total power requirement: 7,5 kW weight of the machine ca.: 2,6 t dimensions of the machine ca.: 2,6 x 1,8 x 2,2 m X-axis travel: 560 mm Y-axis travel: 500 mm Z-axis travel: 400 mm Control system: Heidenhain TNC 360 Spindle speed range: 40 – 4,000 rpm Total power requirement: 7.5 kW Machine weight: approx. 2.6 t Space requirement (L × W × H): approx. 2.6 × 1.8 × 2.2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 560 mm y-travel: 500 mm z-travel: 400 mm total power requirement: 7,5 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,2*2,2*2,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Specifications: Travels X/Y/Z 400 x 400 x 375 mm Max. clamping area 350 x 800 mm Speed range (12) 50 - 2240 min-1 Feed, infinitely variable 1 - 630 mm/min Rapid traverse, max. 1.4 m/min Total connected load 4.7 kW Dimensions (LxWxH), approx. 1300 x 1215 x 1700 mm Weight with pallet, approx. 1700 kg Equipment: Digital Rigid angle table Coolant Setup

- Travel X/Y/Z: 500/500/380 mm - Speed range: 50 - 2240 rpm -Power. 1.8 / 2.6 KW - Spindle brake - Feed: X-Y-Z infinitely variable 1-750 mm/min - Rapid traverse X-Y-Z 1400 mm/min - Rigid angle table 450 x 800 mm - Spindle holder SK 40 M16 (ISO 7388-1) - Weight approx. 1650 kg - Space requirements: L x W x H: approx. 1700 x 1800 x 1800 mm

x-travel: 560 mm y-travel: 500 mm z-travel: 400 mm total power requirement: 7,5 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,2*2,2*2,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 560 mm y-travel: 500 mm z-travel: 400 mm total power requirement: 7,5 kW weight of the machine ca.: 2,5 t dimensions of the machine ca.: 2,5 x 2,5 x 2,2 m No. 4614 Mikron WF 31 SA Universal tool milling machine Working area: 560 x 500 x 400 Control: Heidenhain TNC 114 - active digital display Rigid angular table Spindle holder SK 40 Coolant device Speed range 40 - 4000 rpm Weight approx. 2450 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 560 mm y-travel: 500 mm z-travel: 400 mm control: Heidenhain TNC 114 Aktiv turning speed range: 40 - 4000 U/min spindle drive, 2-steps: 3,3 / 4 kW total power requirement: 9 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,3 x 2,3 x 2,1 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Table clamping surface: 500 x 1000 mm stroke x: 630 mm traverse path y: 500 mm traverse path z: 460 mm Quill stroke: hand 45 mm spindle retainer: ISA 40 spindle speeds: 31.5-3150 rpm stufenl feeds. adjustable: 1-3000 mm / min rapid traverse: x/y 6 / z 4 m/min. Supply: 380 V, 6/8 kW space: 1800 x 2120/2600 x 2020 mm weight: 3100 kg

x-travel: 800 mm y-travel: 500 mm z-travel: 460 mm table surface area: 1000 x 500 mm spindle taper: SK 40 control: HEIDENHAIN TNC 150 spindle turning speed range: 31,5 - 3150 U/min feeds longditudinal/cross/vertical: 1 - 3000 mm/min rapid traverse longitudinal and cross: 6 m/min rapid traverse vertical: 4 m/min quill stroke: 110 mm distance spindle nose and table: max. 559 mm table load capacity: max. 500 kg total power requirement: 14 kW weight of the machine ca.: 3,1 t dimensions of machine L x W x H: 2,15 x 1,8 x 2,15 m Accessories: vertical head with hydr. tool clamping and quill retraction, solid table, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 500 mm z-travel: mm Control: Heidenhain tool taper: SK 40 : 13,5 kw turning speeds: 3150 U/min total power requirement: kW weight of the machine ca.: 3 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Mikron C Axis Machine Table - with Heidenhain control 430 - Siemens server motor - Table: 60 x 110 cm - 4th axis, diameter: 50 cm - Weight: 650 kg Good condition fully functional can be visited and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article, in order to avoid misunderstandings, can be viewed before the purchase and tested under electricity. Please ask questions before buying to avoid ambiguity. For general questions or an appointment for a viewing, I can be reached at any time at the telephone number below or above. Errors in the description and prior sale excepted. VAT will be shown separately on my invoices. Shipping with freight forwarder.

Gear milling machine Micron 106 16 A 380 V

WE OFFER AN BRAND NEW MACHINE, MACHINE WAS NEWR USED FOR WORK ATTACHED PHOTOS MACHINE IS AWAILIBLE IMEDIATELY

Type: Milling Machine/Machining Center Ident Number: 22367 Category: Milling Machines Manufacturer: Mikron Model: HSM 500 Year of construction: 2006 Travel: 500 x 450 x 360 mm [ X x Y x Z ] HSC Machine Number of axles: 3 Control: Heidenhain iTNC 530 Spindle mount: HSK 32 E Spindle speed: 54000 rpm Table size X: 550 mm Table size Y: 450 mm max. workpiece weight: 200 kg Tool changer: 40 speed Conveyor Laser probes for tools Probe PS 32 Infrared / HSK 32 E Minimal lubrication Oil Mist Extraction Device APS Advanced Process System ITC Intelligent Heat Control Mobile handwheel

MIKRON Cutter Mod. VCP 1000 Machinable dimensions: square = 125x125 round 152 Machine visible in operation, in excellent condition.
