MAAG SH-45 Gear shaping machine Min - max diameter 20 - 450 mm Min - max module 1 - 6 Min - max teeth diameter 6 - 250 Min - max tool stroke 0 - 145 mm Table diameter 360 mm Machine dimensions (LxWxH) 2100x1500x2000 mm Machine weight 3600 Kg Change gears The MAAG SH-45 Gear Cutting Machine is suitable for machining of: -External & internal cylindrical gears -Pinions -Spur & helical gears -Gear teeth with longitudinal and profile corrections -Cluster gears -Double helical gear Pictures attached. The machine was in operation for approximately 25 years in a custom manufacturing workshop producing one-off parts according to customer drawings, including gears, shafts, and components for machine tools and transport vehicles. It is in very good condition. Fully functional until it was last used. It hasn't been cleaned, so it doesn't have a "showroom" appearance.
Inv. Num. : 9278 Type: HSS-10 Producer: MAAG Generated: Parameters: Maximum grinding wheel diameter: 220 mm Max. workpiece weight: 6 kg
Hydraulic power unit with pressure accumulator
Planing comb to Maag gear planing machine
SH75 max. wheel diameter 750 mm gear width 200 mm max. module 10 min. module 1 min. wheel diameter 30 mm max. number of teeth 300 min. number of teeth 6 tooth helical angle min/max 0 / 60 ° min. ram stroke 0 mm max. ram stroke 225 mm table diameter 500 mm table load 0,8 t no. of strokes 23,5 - 150 Hub/min table hole 90 mm total power requirement 7 kW weight of the machine ca. 3,8 t dimensions of the machine ca. 2,1 x 1,7 x 2,1 m
Various MAAG pump E.g. Extrex 90, 70, 56, and 36 Reconditioned available from stock in Wuppertal. more details on request
max. wheel diameter: NA mm gear width: NA mm max. module: min. module: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Manually operated 2-Flank Gear Tester The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
max. wheel diameter: 600 mm gear width: 150 mm max. module: 15 min. module: 1 clamping length min.: 45 mm clamping length max.: 750 mm workpiece weight: 150 kg total power requirement: kW weight of the machine ca.: 0,55 t dimensions of the machine ca.: 1,2x0,8x1,95 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Ref. -No.: 10103 Manufacturer: MAAG Year of construction: 1976 Type of control: Konventionell Control: N/A Storage location: Halberstadt Country of origin: Schweiz Minimum number of teeth: 6 Max. Number of teeth: 300 Serial no.: 4216 Gear width: 200 mm Max. Pile driving: 225 mm Max. Wheel Diameter: 750 mm Min. Wheel Diameter: 30 mm Table Diameter: 500 mm Max. Module: 10 mm Min. Module: 1 mm Spiral Angle: 0/60 °
