used
n1-n2= 60-2000 rpm digital 220 V 50 Hz Dimensions LWH: 300 x 300 x 90 mm
used
* General * SKU430T1359 * LocationBarneveld * MakeIKA werke GmbH * TypeMHD 2000/5-ATEX * No.07-6301 * Year of construction2007 * Main Features * MaterialStainless steel * Motor5.5 KW * Rotor60 mm * Specified Features - Inline mixer * Continuous reactorcheck * Rotor sizesDia:60x15mm * InletDN50 * OutletDN32 * Number of stages:1 * Capacity700l/h * With jacketcheck * With mechanical sealcheck * Motor5,5kW, 400/690Volt, 2880rpm (EX) * Rotor speed6000rpm * With vesselcheck * Capacity100ltr * Vessel sizesDia: 500x450mm * MaterialStainless steel 1.4404 (316L) * Information * Mounted on framecheck * Total height2,5m * Weight550kg * CEcheck * Floorspace1,65x1,1m * ATEX compatiblecheck * Extra SpecificationsThis IKA Werke is equipped with additional items. A barrel of the brand AZO for mounting on top of the IKA Werke. Type: V150 Serial number: 15565-01-2007 Working pressure -1- 3.5 bar Test press ...
used
// New equipment - never been used // Technical details Manufacturer : IKA Werke GmbH Model : UTL 2000/05 Type : Inline disperser / Mill, dispersing machine high shear Rotor speed : 5800 rpm (possible variation) Max product temperature : 160?C Viscosity (max.) 5000 mPas Max permissible overpressure: 16 bar Max permissible temperature of the double jacket: 120?C Max. permissible overpressure in the jacket: 2.5 bar Max. flow rate (standard operation / product: water): approx.2500 l/h Motor power: 5.5 kW Material in contact with the product : Stainless steel 316 Barrier pressurisation system Design: https://www.osertech.eu/wp-content/uploads/2022/02/IMG_9885.jpeg Use and operation The IKA ULTRA-TURRAX UTL 2000 is a high performance single stage continuous dispersion machine (rotor/stator), used for the production of emulsions and suspensions. The UTL single-stage d ...
used
Dissolver Agitator IKA ULTRA-TURRAX T 65 Power 1,8 kW Speed 7200 1/min IKA dispersing tool S 65 Very good condition, straight from production!!!
used
IKA works DIS Pax reactor DR 3-13/4, 18.5 kW, 3.000 rpm, capacity up to 20.000 litres / hour, maximum pressure 2.5 bar.
used
No.: 0280 IKA works Cincinnati, Ohio Power: 7.5 kW Housing coolable, double jacket Switchgear 60 Hz movable Dimensions LWH: 1100 x 400 x 1000 mm Weight: approx. 150 kg
used
Laboratory mixer Manufacturer: IKA Type: RE 166 A N°: 489272 max. 6000 rpm, min. 50 rpm 190 volts speed-controlled, with control very good condition LWH: 450 x 410 x 760 mm
used
Ultra-Turrax Manufacturer: IKA N°: 0185 Power: max. 15 kW 380 volts max. 1476 rpm good condition LWH: 2750 x 500 x 550 mm
used
Jet-flow agitator Manufacturer: IKA Type: RT 220 KT N°: 0335 in EEx protection Power: 7.5 kW 380 V, 50 Hz 1450 rpm Built: 1995 (?) LWH: 1800 x 350 x 450 mm Weight: approx. 200 kg
used
Jet-stream agitator Manufacturer: IKA Type: RT 250 KT N°: 0345 Power: 15 kW 380 V, 50 Hz 1450 rpm in EEx protection LWH: 2200 x 380 x 500 mm Weight: approx. 350 kg
used
Stock number U2387-1 Used mixing station for liquids. Station consist of vertical stainless steel mixing tank with total volume 1300 l. Internal diameter 1170 mm x length of straight side of wall 1140 mm. Bottom elipsoidal, with central discharge outlet. Tank is mounted on three stainless steel legs, on tension cells. On side walls there are welded four baffles. Mixing is provided by homogenizing agitator by IKA (DE) model Turrax UTC TMP 150 / 2KT, driven directly by 11 kW, 2915 rpm, 380/660 V, 50 hz. Length of the shaft 900 mm x diameter of mixing die 150 mm. Agitator is mounted on stainless steel supporting frame. Discharge from tank is provided by sinusoidal stainless steel contact parts pump by Masosine Process Pumps model SP 25, working on pressure up to 15 bar. Working rotation up to 600 rpm. Pump is driven by 2.2 kW, 1400 rpm, 220-380 V, 50 hz. Working rotation of drive up to 2 ...
used
Explosion proof motor 3 KW (ADF / ATEX: EExdellCT4) 2870 rpm IP 55 Turbine D.125 Volume, max. with H2O): 5000 l Viscosity, max. 15000 mPas Process pressure (max.) 0 bar Vacuum, max. 100 mbar Process temperature, max. 120 ?C Mixing tools Propeller Motor power, standard 3 kW Shaft size D.40 X L.1000 Weight approx. 42 kg New sealing cartridge installed (seals, ...) The IKA ROTOTRON? RT is an all-purpose jet-flow agitator used for homogenizing, dispersing, suspending, emulsifying, aerating, dissolving and improvement of heat transfer. The RT is most effectively used for tasks ranging between that of a conventional stirring machine and a dispersing machine with a rotor-stator system.
used
Dispersion plant Manufacturer : IKA Maschinenbau Type: DISPAX-REACTOR DR 3-13/4 Year of manufacture: unknown Capacity: max. 20,000 litres/hour Technical specifications : Disperser for continuous operation. The maximum discharge pressure is 2.5 bar. Motor 18.5 kW, 3,000 rpm Mechanical seal is connected to the water. In the dispersion chamber there are three stators and rotors in the gradation coarse-medium-fine as standard. This combination can be varied both in order and in the degree of fineness. Documents: available
used
* General * SKU418U1310 * LocationBarneveld * MakeIKA * TypeSPP 10-ATEX * No.11-8178 * Year of construction2012 * Pressure * Working pressure3 Bar * Vacuum possiblecheck * Main Features * MaterialStainless steel * Volume21 Ltr. * Motor0.26 KW * Specified Features - Stirring vessel * MaterialStainless steel 1.4404 * Closed stirring vesselcheck * Capacity10 Ltr. (max. 21 Ltr.) * Vessel sizesdia. 320x265 mm * Conical bottomcheck * Dished top sidecheck * With covercheck * Top connectionsdia. 49 mm, dia. 59 mm, dia. 25 mm, dia. 13 mm (3x) * Outletdia. 24 mm * Max. temperature-10/80 °C * With propellor stirrercheck * Motor0,26 kW (Ex) * Speed mixing shaft918 rpm * Information * Total height1,45 m * Weight110 kg * CEcheck * Floorspace1x0,6 m * ATEX compatiblecheckStirring vesselsIKA WerkeStirring vessels > Stirring vesselsBrand > IKA Werke What you can expect from Foeth: -- Machine is in worki ...
used
* General * SKU286U528 * LocationBarneveld * MakeIka-labortechnik * TypeSuper dispax SD41 * Year of constructionUnknown * Main Features * MaterialStainless steel * Motor1.5 KW * Rotor30 mm * Specified Features - Inline mixer * Continuous reactorcheck * Rotor sizesDia. 30x15mm * InletDia. 15mm * OutletDia. 15mm * Number of stages:1 * With mechanical sealcheck * Motor1,5 kW, 220/380Volt, 2840rpm * With frequency controllercheck * Rotor speed4000-13000 rpm * With vesselcheck * Capacity±8Ltr. * Vessel sizesDia200x300mm * With jacketcheck * MaterialStainless steel 1.4301 (304) * Information * Mounted on framecheck * With switchcheck * With switchgearcheck(as is) * Weight80 kg * Floorspace0,49x0,40 m * Total height0,75 m * Extra SpecificationsWith Janke &: Kunkel speed control, type DS2SO, 1500 watt, 220-240 voltInline high shear mixersIKA WerkeMixers > Inline high shear mixersBrand > IKA Wer ...
used
* General * SKU242U270 * LocationBarneveld * Make(unknown: missing type plate) * Main Features * MaterialStainless steel * Motor1.2 KW * Length450 mm * Specified Features - Stirrer * Stirrercheck * Homogenising stirrercheck * Shaft length450 mm * Sizes stirring headdia. 50x20 mm * Number of stirrers on shaft1 * Motor1/1,2 kW 380 Volt * Mounted on supportcheck * MaterialStainless steel * Information * Mounted on framecheck * With switchcheck * Floorspace0,8x0,7 m * Total height1,3 m * Weight70 kgStirrersIKA WerkeMixers > StirrersBrand > IKA Werke What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. Please visit us in Barneveld for many more machines!
used
* General * SKU268M233 * LocationBarneveld * MakeJanke & Kunkel GmbH & Co. KG Staufen * TypeSuper Dispax SD-40 * No.257187 * Year of constructionunknown * Main Features * MaterialStainless steel * Motor1.5 KW * Rotor30 mm * Specified Features - Inline mixer * Continuous reactor(1x) * Rotor sizesdia. 30mm * Inletdia. 15mm * Outletdia. 15mm * Motor1,5 KW, 220/380 Volt * MaterialStainless steel * Information * With switchcheck * Floorspace0,6x0,3 M * Total height1,1 M * Weight60 KGInline high shear mixersIKA WerkeMixers > Inline high shear mixersBrand > IKA Werke What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. Please visit us in Barneveld for many more machines!
used
* General * SKUR0855 * LocationBarneveld * MakeIKA Werke GmbH & Co KG * TypeProcess Pilot 2000/4- ATEX * No.05-5463 * Year of construction2005 * Pressure * Working pressure5 Bar * Main Features * MaterialStainless steel * Motor2.2 KW * Rotor55 mm * Specified Features - Inline mixer * Continuous reactorcheck * Rotor sizesdia. 55mm * Inletdia 25mm * Outletdia. 15mm * Number of stages:1 * Max. temperature145 degr. C * With mechanical sealcheck * Motor2.2 kW 230/400 Volt (Ex) * Rotor speed7900 rpm * MaterialStainless steel 1.4571 (316Ti) * Information * Mounted on framecheck * Total height1,1 M * Weight220 Kg * CEcheck * Floorspace0,7x0,4 M * ATEX compatiblecheck * Extra Specificationswith barrel of approx. 15 liters (without lid) Inline high shear mixersIKA WerkeMixers > Inline high shear mixersBrand > IKA Werke What you can expect from Foeth: -- Machine is in working condition -- At a redu ...
used
* General * SKU232W251 * LocationBarneveld * MakeIKA Werke (D) * TypeProcess Pilot MK 2000/4- ATEX * No.11-7888 * Year of construction2011 * Main Features * MaterialStainless steel * Motor2.2 KW * Inlet diameter25 mm * Specified Features - Colloid mill * Colloid millcheck * Rotor sizesDia. 40x60 mm and Dia. 63x38 mm * Cross teethed rotorcheck * With jacketcheck * With hoppercheck 27 Ltr. * InletDN25 * OutletDN15 * Motor2,2 kW 200-240/380-420 Volt * Speed3 170 - 13 789 rpm (20-87 Hz): 7 923 rpm (50 Hz) * MaterialStainless steel 1.4571 (316Ti) * Information * Mounted on wheelscheck * With switchgearcheck * Total height1,45 m * Weight250 Kg * CEcheck * Floorspace0,8x0,55 m * ATEX compatiblecheck * Extra SpecificationsWith mechanical seal tankbrand: Aerni AR139SN: 10020/278,max. pressure: 25 barThis machine comes with 2 rotors.1 colloid rotor Dia. 40x60mm1 pump rotor Dia. 63x38 mmNew arrival ...
used
Manufacturer: IKA Type: T50 EIS-TURRAX Power: 11,000 watts Speed-controlled: up to 10,000 rpm Swivel in a circular manner LWH: 400 x 400 x 1300 mm
used
with Ultra Turrax T25 Vacuum pump with controler IKAVAC Heater Huber Control unit RE 1621 l P various spare parts Operating manuals Dimensions LWH: 1200 x 800 x 860 mm Weight: approx. 100 kg
used
Y.O.M.: 1997 No.: 96-1872 Dispax Reactor Motor Ex-Protection Dimensions LWH: 1000 x 400 x 800 mm Weight: approx. 80 kg
used
n1-n2= 60-2000 rpm 220 V 50 Hz Dimensions LWH: 300 x 300 x 90
used
Stroke: 800mm, max. rotational speed: 1200/min, without documentation or accessories, an inspection is possible.
used
n1-n2= 50-2000 rpm 220 V 50 Hz Dimensions LWH: 300 x 300 x 90 mm
