HURCO bmc used machines

This 3-axis Hurco BMC 2416 vertical machining center was manufactured in 2000. It features a robust Ultimax control system, a spindle speed of up to 8000 rpm, and rapid traverse rates reaching 24003 mm/min. With a tool magazine of 24 positions and generous travels in X, Y, and Z dimensions (610, 406, 540 mm respectively), consider the opportunity to buy this Hurco BMC 2416 vertical machining center. Contact us for more information about this machine.

Description Machining Center Hurco BMC 30 Details Serial No. B3HM-92206089EB with control Ultimax approx. 45 tool holders Replacement spindle 4382 Hours

Inv. Num. : 5552 Type: BMC 24 SSM Producer: HURCO Created: 2004 Parameters: Control system: ULTIMAX Work table length: 760 mm Work table width: 400 mm Spindle drive power: 7.5 kW Tool magazine: 24 pieces Speed: 80-8000 1/min Travel X-axis: 610 mm Travel Y-axis: 405 mm Travel Z-axis: 505 mm Cone: SK40 Machine height: 2650 mm Machine length: 2140 mm Machine width: 2100 mm Machine weight: 4200 kg

x-travel: 610 mm y-travel: 405 mm z-travel: 510 mm table surface area: 760 x 400 mm spindle taper: SK 40 spindle turning speed - stepless: 80 - 8000 U/min spindle drive: 7,5 kW max. torque on the spindle: max. 142 Nm feeds: 3,0 - 7600 mm/min rapid motion -longitudinal/cross/vertical: 24 / 24 / 15 m/min distance table / vertical spindle: max. 600 mm table load: 350 kg no. of tools in magazin: 24 workpiece diameter at full load: 80 mm tool length - max.: 300 mm weight of tools max.: 6,8 kg control: ULTIMAX SSM total power requirement: 18 kVA weight of the machine ca.: 4,1 t Accessories: 2 tool fixtures SK 40, 3-jaw chuck RÖHM, chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 1020 mm, 510 mm, 610 mm

Inv. Num. : 6222 Type: BMC 4020 Producer: HURCO Created: 2000 Parameters: Control system: UNIMAX Operating hours: 59,600 h Work table length: 1220 mm Work table width: 510 mm Minimum vertical spindle speed: 80 1/min Maximum vertical spindle speed: 8000 1/min X-axis travel: 1020 mm Y-axis travel: 510 mm Z-axis travel: 610 mm Spindle power: 15 kW Maximum tool weight: 682 kg Max. tool weight: 7 kg Machine height: 2670 mm Machine length: 3350 mm Machine width: 2320 mm Machine weight: 5600 kg Equipment: Tool clamping 2015: Spindle change

Sell our old vertical milling machining center as a spare parts dispenser, unfortunately I can not say what the machine has exactly, I only know that the control unit is defective

Control Ultimax 3-4 2 color screens (text + graphics) Travel X/Y/Z 1020/510/610 mm Speed 8000 1/min Tool magazine for 24 Wkz. SK 40 DCF Software

Control Ultimax 3-4 2 color screens (text + graphics) Travel X/Y/Z 1020/510/610 mm Speed 8000 1/min Tool magazine for 24 Wkz. SK 40 DCF Software

Machine Details Stock No. 1105-03273 Type of machine Machining Center - Vertical Make HURCO Type VMX 42 M 2008 Year of Manufacture Type of control CNC Storage location FRANCE Country of origin taiwan Delivery time immediately Freight basis ex work Technical details x-travel 1060 mm y-travel 610 mm z-travel 610 mm work surface 1200 X 610 mm engine output (30 min. ED) 15 kW Distance between table and spindle 150 - 760 mm Torque 600 Nm rpm 30 min ED 22 Control Ultimax 4 weight of the machine about 6 t Additional information ultimax 4 8000 rpm

HURCO VM10 Vertical Machining Centre. Hurco WINMax Control Year of construction: 2010 Manufacturer: Hurco Model: VM10 Control: Hurco WINMAX Spindle Speed: 10000rpm Table size: 762 x 356 mm Tool change capacity: 20 Tool size: DIN40 Traverses XYZ: 560 x 356 x 457mm

Machine Details Stock number 1105-037895 Machine type machining center - vertical Brand HURCO Type VMX 40 Year of construction 2000 Control type CNC Storage location FRANCE Country of origin taiwan Delivery time immediately Freight base from site Technical details x-travel 1060 mm y-travel 508 mm z-travel 650 mm Working surface 1200 X 610 mm Motor power (30 min. ED) 15 kW Distance between table and spindle 150 - 760 mm Torque 600 Nm rpm 30 min ED 22 Tool changer 30 times Ultimax 4 Control Machine weight ca. 6 t Information HURCO VMX 40 BORN 2004 CNC ULTIMAX 4 Synchronous.Thread 8000 rpm SPAENEFOERDEREr

Inv. Num. : 6594 Type: VMX 42 SR Producer: Hurco Generated: 2008 Parameters: Control system: Winmax Work table length: 1270 mm Work table width: 610 mm Maximum table load (even): 500 kg Speed: 12000 1/min Travel X-axis: 1066 mm Travel Y-axis: 610 mm Travel Z-axis: 610 mm Cone: SK40 Machine weight: 7550 kg Equipment: C-axis: CNC rotary table B-axis 2016: new spindle

Inv. Num. : 4427 Type: WMX 60i Producer: HURCO Created: 2017 Parameters: Control system: WINMAX Switch-on hours: 5648 h Operating hours: 1554 h Working table length: 1 680 mm Working table width: 660 mm Maximum table load (uniform): 1 360 kg Spindle drive power: 18 kW Maximum vertical spindle speed: 12 000 1/min X-axis travel: 1560 mm Y-axis travel: 660 mm Cone: SK40 Number of all tools: 30 pieces Maximum tool length: 300 mm Maximum tool weight: 15 kg Machine weight: 9 000 kg

Key data: 1625 mm, 860 mm, 760 mm

Control Ultimax 4 Travel X/Y/Z: 1625/860/760 mm Speed 8000 min-1 Tool magazine for 40 Wkz., SK 40 IKZ Conveyor

Control Ultimax 4 Travel X/Y/Z 760 x 510 x 610 mm Table size 1020 x 510 mm Speed 12,500 min-1 Tool magazine for 24 Wkz., SK 40

We have a HURCO CNC milling machine from 2008 to offer: HURCO VMX 64T Travel: X1625 Y860 Z760 Speed max. 8000 rpm (limited by the new bearings after spindle replacement) Sporadic clamping of the interchangeable arm

Control Winmax Travel X/Y/Z 2135 x 865 x 762 mm Spindle speed 12,000 min-1 Tool magazine for 40 Wkz., SK 40 Handwheel Ultimotion IKZ 40bar Probes Renishaw Conveyor

2001 Hurco VMX40 Technical data: - Ultimax 4 control - network card - DXF software - Tool changer 24 places - SK40 holder - Spindle speed 10-10,000 rpm - Chip conveyor - Operating hours 5279 Travels: - X-axis 1,020mm - Y-axis 510mm - Z-axis 610mm Find more here - / Contact us at -

Travel (X / Y / Z) 1,524 mm / 660 mm / 610 mm Table size 1,676 × 660 mm Table load Up to 2,000 kg Spindle holder SK50 DIN 69871 Speed range up to 8,000 rpm Spindle power 22 kW continuous power (30 min. to 26 kW) Coolant by spindle Number of seats standard: 30 Iiebtfbewt N Nhj Tpmsc Tool weight max. 15 kg Tool length max. 300 mm Tool diameter max. 125 mm (if the adjacent space is empty), otherwise 75 mm Rapid traverses (X/Y/Z) 30 / 30 / 24 m/min Machine weight approx. 10,000 Control Hurco WinMax / Ultimax Installation area (L×W×H) approx. 5,600 × 3,900 × 3,300 mm

Winmax V10 X-axis: 1,067 mm Y-axis: 610 mm Iebtfb Tswt N Tgepmsic Z-axis: 610 mm Table size: 1,270 × 610 mm Tool holder: SK40 (DIN 69871) Max. speed: 12,000 rpm⁻¹ Drive power (S1/S6): approx. 15 / 22 kW IKZ (internal cooling) 20 bar Separate coolant tank with paper belt filter Rapid traverse X/Y/Z: 35 m/min (X/Y), 30 m/min (Z) Capacity: 30 tools (optionally 40) Changeover time: Tool-to-tool approx. 2 s Max. tool diameter: 80 mm (next to free space: up to 125 mm) Max. tool length: 300 mm Max. tool weight: 7 kg Machine weight: approx. 6,900 kg Space requirement (W × D × H): approx. 4,600 × 3,900 × 2,800 mm Spindle nose to table: 150 – 760 mm Table surface to floor: approx. 900 mm

Travel (X / Y / Z) 762 mm / 508 mm / 610 mm Table size 1,020 mm × 510 mm Table load max. 1,000 kg Spindle holder SK 40 (DIN 69871) Spindle speed max. 10,000 min⁻¹ Spindle power 11 kW Tool Stations 24 Stations, Automatic Tool Changer (ATC) Iobjwt Rfwstfb Tpmjic Max. tool weight 7 kg Max. tool length 300 mm Max. tool diameter 80 mm Rapid traverse (X / Y / Z) 24 m/min / 24 m/min / 20 m/min Feeds programmable up to approx. 7,600 mm/min Control HURCO Ultimax 4 Machine weight approx. 4,700 kg Machine dimensions (L × W × H) approx. 3.9 m × 2.4 m × 2.7 m

Year of manufacture 2007 Travel X 1270 mm Travel Y 660 mm Travel Z 610 mm Table size 1500 mm × 660 mm Table load 1300 kg Spindle speed up to 12,000 min⁻¹ Spindle drive approx. 18 kW Tool holder SK 40 Tool Stations 24-Fold Tool Changer Rapid traverse (X/Y) 30 m/min Rapid traverse (Z) 20 m/min Machine weight approx. 9000 kg to 9500 kg Machine dimensions (L×D×H) approx. 3.25 m × 2.35 m × 2.95 m

Name: CNC control unit / control unit Name: HURCO CNC Control Unit Manufacturer: HURCO Companies, Inc. (USA) Serial Number: U4M01003112D Type: Control Unit / Control Kit Dimensions (estimated): approx. 440 × 360 × 160 mm Weight: approx. 15 kg Country: USA Short Description: HURCO control unit with several plug-in cards, including RAM and interface boards as well as connections for COM, I/O and other interfaces. The device is designed for industrial use in CNC milling machines or machining centers. The rugged aluminum chassis features two active fans for internal cooling, as well as numerous I/O ports (Sub-D and Centronics). There are several signal connectors on the front and back, as well as internal expansion slots for additional modules.

A CNC 3-axis milling machine Hurco is available. Travel X/Y/Z: 760mm/510mm/610mm, table dimensions X/Y: 1020mm/510mm, max. table load: 1360kg, speed: 10000rpm, tool stations: 18, tool holder: SK40, rapid traverse: 30m/min. Machine dimensions X/Y/Z: approx. 2700mm/2200mm/2400mm, weight: approx. 4000kg, control: Hurco Ultimax, spindle hours: approx. 10500h. Documentation available. An on-site inspection is possible.

Travel path X/Y/Z: 1630mm/860mm/760mm, speed: 8000rpm, torque: 142Nm, power: 15kW, tool positions: 40, max. tool diameter: 75mm/127mm, max. tool length: 300mm, max. tool weight: 10kg, table dimensions X/Y: 1680mm/890mm, max. table load: 2700kg. Machine dimensions X/Y/Z: approx. 6400mm/4400mm/3300mm, weight: approx. 14500kg, control: Hurco Ultimax 4, operating hours: approx. 621h. Documentation available. An on-site inspection is possible. Expected to be available from mid-2026.
