used
Manufacturer: Heesemann Druckbalken war noch eigebaut, Type: MFA 6 oder MFA 8 , FREETEXT1: Hubmagnet 6 mm, FREETEXT2: 24 Volt, FREETEXT3: Länge 1470 mm, FREETEXT4: Bauhöhe 200 mm,
used
- Producer Heesemann - Type MFA 8, Quer/Längs/Längs/Bürste - Year of construction 1998 - 1. Unit - Cross belt - Electronic sanding beam CSD - Fins belt - Belt speed 1. Stufe 0,6-12 m/s - 2. Stufe 24 m/s - Measure sanding belt 4800 x 150 mm - Motor power 11/17 kW - 2. Unit - Length belt - Electronic sanding beam CSD - Fins belt - Belt speed 3,5/10 m/s und 20 m/s - Measure sanding belt 2620 x 1350 mm - Motor power 4,5/12/17 kW - 3. Unit - Length belt - Electronic sanding beam CSD - Distance follower roller 32 mm - Dedusting brush 1 Stk. - Touchscreen with graphic design - Table length extension - Aggregate height adjustment - Electric height adjustment - Feed speed infinitely adjustable 3 - 15 m/min - Vacuum transport belt - Connecting piece 4x180 + 1x146 mm - Air speed main collector 20 m/s - Consumption of compressed air ~ 134,5 + 72,0 m³/h - Length 2.385 mm - Width 2 ...
used
Grinding machine Heesemann type MFA 6 Specifications: • Aggregate arrangement: roller/transverse/longitudinal/longitudinal/brush • Working height (mm): 920 • Working width (mm): 1350 • Workpiece thickness (mm): 3 - 150 • Longitudinal grinding unit: 22 kW, 18 m/s, steel roller: 200 mm grooved • Transverse grinding unit: 15 kW 2 - 20 m/s • Combination / longitudinal grinding unit: 15 kW 1.8 - 18 m/s with steel roller • Longitudinal grinding unit: 15 kW 1.8 - 18 m/s • Brush roller (mm): 120 • Sanding belt size (mm): broadband: 1400 x 2150 (1370 x 2150 possible); Longitudinal band: 150 x 4800 • Accessories: 1 lamellar belt for transverse band new; 1 sanding shoe cross band used; 2 sanding shoes longitudinal band unused revised; 2 sanding shoes longitudinal band used
used
Grinding machine Heesemann type MFA 8 Specifications: • Working width (mm): 1300 • CSD system • Transverse grinding unit • Longitudinal grinding unit - shoe • Brush unit • Ionization • Vacuum carpet
used
Manufacturer: Heesemann, Type: MFA 6, Year: 2011, Control: PC, Monting of the machine: Quer/Längs/Bürste, Sanding width mm: 1350, Sanding hight mm: 150, Number of sanding belts: 2, Sanding belt dimensions: 2150 X 1350, Steel roller: kombi, Belt 1Transverse sanding unit: yes, Elektronische Tastung mm: yes, Separation of sampling in mm: 16, Frequency control of belts: 2, Combi unit roller/shoe: yes, Continous adjustable feeding speed m/min: 5-15, Transportbandantrieb kW: 1,5, Intermediate sanding of lacquer: yes, Constant table hight: yes, Segment sanding shoe: yes, Brushing unit: yes, FREE TEXT: vakuumteppich/Zustand sehr gut, Year :2011
used
Manufacturer: Heesemann, Type: MFA 8/Rechtsmaschine, Year: 1996, Monting of the machine: Längs/Bürste, Sanding width mm: 1350, Sanding hight mm: 3 - 140, Number of sanding belts: 1, Sanding belt dimensions: 2620 X 1350, Band 1 Leistung kW : 11, Belt 1 shoe unit: yes, Band 1 Schleifbandgeschwindigkeit m/s : 0,5 - 12, Elektronische Tastung mm: yes, Separation of sampling in mm: 16, Frequency control of belts: 1, Continous adjustable feeding speed m/min: 5 - 25, Transportbandantrieb kW: ca.3, Intermediate sanding of lacquer: yes, Constant table hight: yes, Vacuum table: yes, Segment sanding shoe: yes, Brushing unit: yes, Diameter/ brush bristles: 150, Year :1996
used
Manufacturer: Heesemann, Type: MFA 6 Impression, Year: 2008, Control: Längs/Stahlwalze/ Bürste, Monting of the machine: 1300, Double sided sanding line: 3 - 140, Sanding width mm: 1, Sanding hight mm: 2620 x 1350, Number of sanding belts: 0,5 - 12, Konstantentisch: Konstatntentisch, Bürstenaggregate: CSD , Rubber roller: 16, Band 1 Leistung kW : 15, Konstantentisch: Konstatntentisch, Band 2 Leistung kW : 5 - 25, Belt 2 shoe unit: 3, Band 2 Queraggregat: yes, Band 2 Schleifbandgeschwindigkeit m/s : yes, Band 3 Kombiaggregat: yes, Band 3 Schleifbandgeschwindigkeit m/s : 1,5 kW, Year :2008
used
Second-hand wide belt sanding machine Make Heesemann Type MFA Impression not rebuilt - without guarantee Year of construction 2010 Technical specifications: Sanding width 1,350 mm - cross sanding unit with pressure lamellar belt system - combined longitudinal sanding unit with calibration roll - longitudinal sanding unit - structuring brushing unit - dust removal brushing unit - 3 pressure beams with computer-controlled selective pressure control system CSD Distance of the control rollers 21 mm Feed speed: 3 - 15 m/min. Working height constant 880 mm motorized adjustment to the workpiece thickness 3 - 150 mm 1 pressure roller Ø 50 mm swinging, in the infeed of the machine including workpiece oversize control Roller table in the infeed of the machine 1 industrial PC 10.4 with program memory for 100 programs 1 cross sanding unit Abrasive belt ...
used
- Producer Heesemann - Type MFA 6 - Year of construction 2009 - 1. Unit - Cross belt - Electronic sanding beam CSD - Fins belt - Belt speed 2 - 20 m/s - Measure sanding belt 4800 x 150 mm - Motor power 15 kW - 2. Unit - Length belt - Combi aggregate roller/beam - Electronic sanding beam CSD - Fins belt - Belt speed 1,8 - 18 m/s - Measure sanding belt 2620 x 1400 mm - Motor power 15 kW - Distance follower roller 32 mm - Dedusting brush 1 Stk. - Operating side, left - Touchscreen with graphic design - Table length extension - Aggregate height adjustment - Electric height adjustment - Feed speed infinitely adjustable 3 - 15 m/min - Vacuum transport belt - Connecting piece 4x180 + 1x146 mm - Air speed main collector 20 m/s - Consumption of compressed air ~ 134,5 + 72,0 m³/h - Length 2.385 mm - Width 2.300 mm - Height 2050 - 2250 mm - Weight 3500 kg - Location - Switch cabinet built ...
used
Equipped with 3 sanding units. The sizes include mobile roller conveyors. You are responsible for dismantling and transporting this lot. There are no tools available.
used
Description: Max. machining width 1350 mm Min. machining thickness 3 mm Tipologia Sanding and Finishing Working Table Fixed pass height Vacuum feed belt yes No. Operating units 3 Nr sectioned swab yes Max. machining width 1350 mm Min. machining thickness 3 mm Max. machining thickness 150 mm Work table yes height fixed for line operation Forward feed belt yes with speed adjustment by NC yes max. forward feed speed 15 m/min Fan for belt vacuum hold down yes no. fans 1 Operating units 3 OPERATING UNITS 1 Unit : pad Pad : vertical Segmented pad : yes Automatic timed intervention : yes with adjustable speed by NC : yes motor power : 15 KW sanding belt width : 1400 sanding belt extension : 2620 OPERATING UNITS 2 Unit : pad Pad : vertical Segmented pad : yes Automatic timed intervention : yes motor power : 15 KW sanding belt width : 1400 sanding belt extension : 2620 OPERATING UNITS 3 Unit : br ...
used
Description: • Power: 22 KW each Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 400 mm, weight approx.: 500 kg
used
Description: • Power: 22 KW each Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 400 mm, weight approx.: 500 kg
used
Description: well maintained and powerful wide-belt sander with technical specs as follows: sanding width 1350 mm workpiece thickness 3 - 160 mm feed speed 3 - 15 m/min (frequency controlled) vacuum feed-belt cross sanding unit 15 kW, belt speed 2,0 - 20 m/s (frequency controlled), dimensions of sanding belt 4800 x 150 mm length sanding unit 15 kW, belt speed 1,8 - 18 m/s (frequency controlled), ,dimensions of sanding belt 2620 x 1400 mm length sanding unit , with pressure lamella belt 15 kW, belt speed 1,8 - 18 m/s without pressure lamella belt and 1,8 - 9 m/s with pressure lamella belt, ,dimensions of sanding belt 2620 x 1400 mm pressure beam with computer controlled selctive pressure control system (CSD) with stepless pressure adjustment of the single pressing elements. Distance of the rolls 16 mm structure brush 11 kW, diameter 250 mm, oscillating cleaning brus ...
used
Description: • Lot of 2 electronic sectioned sanding pads with 56 sectors for wide belt sander • Dimensions of each unit: approx. 1600 x 150 x 260 mm • Sanding pad length , approx. 1500 mm • They include the control cards that appear in the photographs Approx. Onsite Dimension. (l x w x h): 1,600 x 800 x 300 mm, weight approx.: 150 kg
used
Description: • Lot of 3 motors for wide belt sander • It includes: • 1 x SIEMENS motor: power 2.20 KW-1420 rpm with gear motor and integrated frequency converter • 1 x UNIVERSAL MOTORS motor: power 1.50 KW-1425 rpm • 1 x SIEMENS motor: power 0.75 KW-1395 rpm with gear motor Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 450 mm, weight approx.: 200 kg
used
Description: • Lot of 3 motors for wide belt sander • It includes: • 1 x SIEMENS motor: power 3 KW-1420 rpm with gear motor and integrated frequency converter • 1 x ALREN motor: power 1.50 KW-1400 rpm • 1 x SIEMENS motor: power 0.75 KW-1395 rpm with gear motor Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 450 mm, weight approx.: 200 kg
used
Approx. Onsite Dimension. (l x w x h): 350 x 300 x 300 mm, weight approx.: 20 kg
used
Description: • Lot of spare parts for wide belt sander • It includes: • 2 x BLOCK HFD 202-400/90 EMI-filter • 2 x SIMCO A2A7S power units • 2 x KUHNKE 140.656.00 PLC Control Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 250 mm, weight approx.: 30 kg
used
Description: • Cleaning brush unit for wide belt sander • Brush length approx. 1400 mm • Roller diameter 240 mm • Motor power 4 KW-1440 rpm Approx. Onsite Dimension. (l x w x h): 1,900 x 420 x 950 mm, weight approx.: 200 kg
used
Description: • Lot of 4 transformers for wide belt sander • It includes: • 2 x BLOCK B9602175 transformers: primary 380-420 V, secondary 24 V • 2 x JACKE transformers: primary 400 V, secondary 230 V Approx. Onsite Dimension. (l x w x h): 800 x 600 x 450 mm, weight approx.: 100 kg
used
Description: • Electronic sectioned sanding pad with 56 sectors for wide belt sander • Dimensions of the unit: approx. 1600 x 150 x 260 mm • Sanding pad length approx. 1500 mm • It includes 2 control cards that appear in the photographs Approx. Onsite Dimension. (l x w x h): 1,600 x 800 x 300 mm, weight approx.: 100 kg
used
Description: • Electronic sectioned sanding pad with 56 sectors for wide belt sander • Dimensions of the unit: approx. 1600 x 150 x 260 mm • Sanding pad length approx. 1500 mm • It includes 2 control cards that appear in the photographs Approx. Onsite Dimension. (l x w x h): 1,600 x 800 x 300 mm, weight approx.: 100 kg
used
Fine sanding machine Working width: 1300 mm. Workpiece thickness: 3 - 140 mm N? of units: 2 * Crossbelt, CSD sanding pad, belt sizes 4900 x 150 mm, 13/17 kW motor, 12 and 24 m/s belt speed, belt cleaning * Wide belt, CSD sanding pad, belt sizes 2620 x 1350 mm, 13/17 kW motor, 10 and 20 m/s belt speed, belt cleaning, first belt guiding roller with excenter adjustment for light calibration * Fibre brush 150 mm diameter, 1,5 kW Vacuum-feedbelt suction, 7,5 kW fan Feedmotor 3 kW, feedbelt speed 4,5 - 22 m/min Motorised rise and fall of the table Panel tracers with 16 mm centers
used
Part Number 6291 TECHNICAL DATA - max width of the workpiece 1350mm - max height of the workpiece 100mm 3 aggregates: 1) transverse aggregate with pneumatically pressed shoe 13/17kW 2) combo unit (2 rolls) with pneumatically pressed shoe 13/17kW 3) combo unit (2 rolls) with pneumatically pressed shoe 13/17kW in advance: - rubber pressure roller - sequential shoe - aggregate - rubber pressure roller - aggregate - rubber pressure roller - aggregate - slip rubber roller, pressure roller - cleaning brush 1,5kW bottom: - slip roller - 5 segment feed tape with vacuum pump - pump motor 7,5kW - feed speed adjustable by 4kW geared motor - feed speed 5-26m/min - oscillation of pneumatic tapes on photocells - blowing of feeding belts - all units equipped with a sanding belt cleaning system - lifting the electric table - lifting motor about 0,55kW - de ...
