GERA arcade used machines

Bottle washing machine GERA type: Arcade year of manufacturing: 2010 working hours: 32767 capacity: approx. 33.000 bph by 1,0 ltr. bottles control range: 13.200 - 36.300 bph cell pitch: 110 mm bottle cells per row: 30 bottle cells complete: 7.860 with pre-soaking The machine is still in production in Germany and will be available in February 2025

GERA Bottle Washing Machine – Arcade GEL 6 RV1-VL 362/110-30 (Year 2010) High-capacity industrial bottle washing machine designed for efficient cleaning of returnable PET and glass bottles in beverage production lines. The GERA Arcade GEL 6 RV1-VL 362/110-30 provides reliable multi-zone washing performance and high throughput, making it ideal for breweries, soft drink producers, and mineral water bottlers. General Information - Manufacturer: GERA - Model: Arcade GEL 6 RV1-VL 362/110-30 - Article Number: 1334 - Year of Manufacture: 2010 - Operating Hours: approx. 35,000 h - Condition: Excellent used condition, regularly serviced Technical Specifications - Production Capacity: approx. 30,000 bottles per hour (1.0 L format) - Control Range: 13,200 – 36,300 bottles per hour - Cell Pitch: 110 mm - Bottle Cells per Row: 30 - Total Bottle Cells: 7,860 Washing System  ...

Cleaning machine, Fabr. GM Gera, Type: Arcade, for 24,000 bph, control range 7,600 - 26,400 bph, 25 bph, cage pitch 95mm, chain pitch 140mm, with Siemens S7 control

Cleaning machine, Fabr. GM Gera, type: Arcade GEK2.1RV1, for 4,000 bph, 9 b/row, with 0.5 lt NRW bottle, cell pitch 95mm, with pre-soak, caustic bath 1+2, hot water bath 1+2, cold water and fresh water spraying, year 2007

Overview The GM Gera NAGEMA Arcade DS bottle washer was previously used in a brewery. There it was operated in single-shift operation. Since the sales volume has decreased, the beer of the brewery is now bottled at another location and this bottling line has become available. Due to the low number of operating hours and regular maintenance, the machine is in a very good condition. All basins and the machine body are made of stainless steel. Spare parts, such as bottle cells, are also still available. Furthermore, the main drive shaft, as well as the motor and gearbox were overhauled by SEW in 2018 and the carrier chain was replaced in 2015. The machine is still mounted and can also be demonstrated. Tech Specs: Capacity: 23,000 bph Cell pitch: 85 Bottles per row: 16 Dimensions + weights with attachments: 8640 x 4470 x 1920 mm / 17,900 kg Details: Standard drives Heating with steam Operati ...

Bottles-cleansing machine 12000 bottles / h completely V2A

Overview The bottle washer was previously used in a brewery. Due to the low number of operating hours, the machine is in very good condition, like new. It was replaced, as the previous owner wanted to run bottle formats, which did not fit this machine. All basins and the machine body are made of stainless steel. The machine is already disassembled and dry stored, so that it can be easily loaded and transported. The machine comes with 12months warrantee. Tech Specs: Capacity: 9,500 bph Cell Pitch: 95 mm Bottles per row: 25 Dimensions + Weights: Housing: 7,162 x 2,740 x 2,500 mm / 18,806 kg Ready for operation with attachments: 7,162 x 3,540 x 2,730 mm / 31,563 kg YOM 2024 Formats: 0,25l 0,33l 0,5l 0,75l The Machine in Detail / Equipment Features: Heated by steam Pre Cleaning and removal of residual liquids by pulsed rinsing prior to washing CE certified Chemical Dosing Pumps Machin ...

Overview   This ARCADE GEL 6 bottle washer was built in 2010 by the German manufacturer GM Gera. The machine is still in operation and can be inspected in person at any time. The ARCADE GEL 6 is fully functional and must be replaced due to an increase in performance.   Technical details   Nominal output: 33,000 bph   Control range: 13,200 - 36,300 bph   Chain pitch: 169 mm   Cell pitch: 110 mm   Bottle cells per row: 30 pieces   Total bottle cells: 7,860 pieces   Bottle cells, loaded: 7,680 pieces   Consumption  Compressed air: 1m³   Steam (operation): 489 kg/ h   Steam (heating): 4,430 kg/ h   Electrical power: 48.4 kW   Water: 7.35 m³/ h   Bath volume   Pre-soak: 2,263 l   Pre-caustic: 7,240 l   Caustic 1: 31,755 l   Caustic 2: 350 l   Hot water 1: 350 l  Hot water 2: 350 l   Cold water: 350 l

Overview The bottle washer was previously used in a brewery. Due to the complete reconditioning in 2005 and continuously maintentance, the machine is in very good condition. All basins and the machine body are made of stainless steel. The machine is already disassembled and dry stored, so that it can be easily loaded and transported.  Tech Specs: Capacity: 6,700 bph Cell Pitch: 102 mm Bottles per row: 10 Dimensions + Weights: Housing: 7,200 x 1,300 x 2,850 mm / 13,500 kg Ready for operation with attachments: 7,790 x 3,450 x 2,950 mm / 20,000 kg YOM 1999 Formats: 0,33l 0,5l The Machine in Detail / Equipment Features: Heated by steam Pre Cleaning and removal of residual liquids by pulsed rinsing prior to washing CE certified Chemical Dosing Pumps Machine data sheet included High pressure pre rinsing Rotating Spray nozzles Single End Machine Label discharge rear right Finger discharge + ...

Overview The bottle washer was previously used in a mineral water factory. Due to the good maintenance, the machine is in good condition. All basins and the machine body are made of stainless steel. The machine is still working and will be free in early 2027, when the complete line is replaced. Tech Specs Capacity: 15,500 bph Cell Pitch: 95mm Bottles per row: 16 Dimensions + Weights: Housing: 8350 x 1,860 x 2,990 mm / 21,750kg Ready for operation with attachments: 8,700 x 3,560 x 3,330mm / 37,639kg YOM 2005 Formats: 0,5l 0,75l The Machine in Detail / Equipment Features Heated by steam Pre Cleaning and removal of residual liquids by pulsed rinsing prior to washing CE certified Chemical Dosing Pumps Machine data sheet included Rotating Spray nozzles Single End Machine Label discharge rear right Label press mounted to the machine Finger discharge + finger feed Bottle cells made of plastic C ...

Filling system for COOLANT manufacturer: Müller Geräetebau GmbH All information without guarantee

x-280 ,y- 200 , Z 315 , Table dimensions 380x380/250x500 A lot of writings,much more than pictured

A GM Gera bottle cleaning system is available. Throughput capacity with 1l PET bottles: 13000 bottles/h, bottle cells: 3240 pieces, cells per basket row: 18, cell pitch: 110mm, chain pitch: 169mm, total treatment time: approx. 15min, total immersion time: approx. 7.5min, housing material: stainless steel (SST). System dimensions X/Y/Z: approx. 8900mm/4200mm/3350mm, weight: approx. 23650kg, operating hours (09.2025): approx. 14300h. Documentation available. An on-site inspection is possible. Expected to be available from mid-March 2026.

Modular vise, jaw width 125mm Gerardi Modular 125 Stable Machine Vise, Drill Vise Total length approx. 345mm Clamping range approx. 150mm Jaw width 125mm with pull-down jaws Additional prism jaw Mechanical clamping actuation with 19mm wrench or ratchet The machine can be demonstrated on site by appointment. We offer only machines that are ready for demonstration in our warehouse, see "other offers of this year". provider".

Tool holder, milling holder, chuck, milling tool, adapter, clamping unit, tool holder, collet sleeves -Milling holders: MK4 holder -Type: Ø27 x 60 mm Z 03 1-02 -Dimensions: 245/43/43 mm -Weight: 1.3 kg

* General * SKU267N238 * LocationBarneveld * MakeGerhard+Rauh GmbH * TypeRZE counterflow column, DN900/700 * No.6321 * Pressure * Working pressure1 Bar * Vacuum possiblecheck * Main Features * MaterialStainless steel * Volume4000 Ltr. * Motor5.5 KW * Specified Features - Extraction * Capacity4000 Ltr * Diameterdia. 700 mm * Length10 m * Max. temperature95 °C * With rotorcheck * Motor5.5 kW (230/400 V) * With variable speed drivecheck * Rotor speed88 rpm * MaterialStainless steel 1.4539 (904L) * With jacketcheck * General * Year of construction1996 * Floorspace1,2 x 1,2 m * Total height12 m * Weight3000 kg * ATEX designedcheck * Technical specs * Extra information-1/1 bar working pressureExtractionGerard + RauColumns > ExtractionBrand > Gerard + Rau What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destin ...

Machine vise, stable vise, milling machine vise, modular vise -Manufacturer: Gerardi, Modular Vise - Jaw width: 195 mm - Jaw height: 60 mm -Clamping range: 345 mm -Total dimensions: 595/195/H130 mm -Quantity: 1 piece available -Weight: 63kg

Machine vice, stable vice, milling machine vice, modular vice -Manufacturer: Gerardi, Modular Vice -Jaw width: 195 mm -Back height: 60 mm -Clamping range: 450 mm -Dimensions: 695/195/H130 mm -Weight: 70 kg

Tool holder, milling tool holder -Number: 21x SK50 recording -Receptacles: Ø 22-50 mm -Drill chucks: Surface clamping chucks, reducing sleeves, cutter heads, end mills -Sale: only complete set -Weight: 88 kg

Single-end bottle washer. Factory overhauled in 2005., Additional title: one end machine, Nominal capacity: 6700 bo/h, Control range: 7370 bo/h, Number of bottle cells: 1620 pcs., Number of bottle cells per row: 10 pcs., Length: 7790 mm, Width: 3450 mm, Height: 2950 mm, Weight: 20000 kg, Machine partitioning: Chain division 150 mm, cell division 110 mm, Operation / Control: Siemens S 5, Material: Stainless steel, Position: Free-standing on spherical feet, Base construction: Housing in one-piece block design, Features: Bottle insertion and removal finger system, chemical dosing stations with dosing pumps, format parts for inlet and outlet

Nominal output: 9500 bottles/h (based on 0.5 litre NRW bottle, 68x260mm, 370g), mechanical control range: 3800-10,450 bottles/h, cycle time: 9.47s, total bottle cells: 3375, filled: 3175, per row: 135 basket rows, cell pitch: 95mm, chain pitch: 140mm, drive lanes: 3 lanes, discharge lanes: 3 lanes. Total throughput time: 21.32min, total immersion time: 7.24min, caustic immersion time: 5.34min, caustic filling time: 7.05 min, caustic contact time: 9.91min, total rinse time: 123s, total spray time: 47s, water consumption: 2.61m³/h, 275 ml/bottle, heat consumption (operation): 721. 715 kJ/h = 172,247 kcal/h, 75.97 kJ/bottle = 18.1 kcal/bottle, heat consumption (heating): 2,880 MJ = 687,467 kcal, total installed power: 27.2kW, pump power: 20.4kW, drives: 5.7kW, compressed air consumption (at 6bar): 0.2m³/h, dimensions housing: 7162x2740x2500mm. Overall dimensions: 7162x3540x2730mm, minimum ...

Overview This returnable glass bottling line consists of equipment from KRONES, KETTNER, GM GERA, RINK, SYSCONA, MATEC, FALTERBAUM, Bohrer and further supporting manufacturers. The line is designed for the processing of returnable glass bottles in crates, mainly in 0.33 L and 0.75 L formats. It includes the key process steps from crate depalletizing, crate sorting, bottle decapping, unpacking, bottle washing, empty bottle inspection, filling and screw capping to labelling, full bottle inspection, crate packing, crate inspection and palletizing. The existing crate depalletizer and palletizer are available on site; however, due to their age and outdated technology, it is recommended not to include this unit in the line acquisition. Instead, suitable modern depalletizing equipment can be offered and integrated into the line concept according to the buyer’s requirements. The line has a nom ...

6-colour format: 720 mm<br>TYP: 500, 6 INTAGLIO + 1 FLEXO, PAPIER & FOLIEN 50-150 GSM, ROLLS of 800 MM WIDTH: 750 MM;<br><br>Still in operation: Yes<br>Verf Gbar: immediately

6-colour format: 900 MM<br>ROTOPAK 1/S, 50-200 G, WEB WIDE: 820 MM, ROLLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

<br>DECOIL DURCHMESSER: 1000 MM, AUFWICKLER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
