worm grinding used for sale

General Description Precision industrial gear grinding machine manufactured by NILES , model ZSTZ 315/630 C2 . Designed for precision grinding and finishing of spur and helical gears for industrial transmission, gearbox and mechanical engineering applications. Technical Details Manufacturer: NILES Model: ZSTZ 315/630 C2 Machine type: Gear grinding machine Year: 1981 Serial number: 35/23-20 Maximum gear diameter: 315 mm Module range: 1.5–10 Maximum gear width: 160 mm Maximum workpiece weight / table load: 200 kg Number of teeth: 12–140 Maximum helix angle: 45° Grinding wheel diameter: 270–350 mm Grinding wheel speed: 1,690 rpm Stroke length: 20–170 mm Stroke rate: 102–315 strokes/min, continuously variable Number of feed settings: 16 Feed speed: 80–800 Motor power: 8 kW Power supply: 380 V, 3-phase, 50 Hz Control voltage: 220 V Rated machine current: ...

We offer a complete set of original Kellenberger documents , for increasing the tip height by 50 mm. These are ground to a height. The overall picture shows the condition of the documents before post-processing

Various high-quality grinding wheels DM= 220mm, width 30 + 40mm, open-pored grain size 80 - 100- 120. Can be used for JUNG with bore dm 76.2mm, intermediate ring made of aluminium dm 76.2/50.8mm available.

Surface grinding machine manufactured in 2006. This STAEHLI DLM 450 features a lapping wheel diameter of 450 mm and a maximum lapping wheel speed of 110 rpm. It has a robust machine weight of 2100 kg and dimensions of 1200 × 1650 × 2050 mm. If you are looking to get high-quality lapping capabilities, consider the STAEHLI DLM 450 machine we have for sale. Contact us for further details regarding this machine.

Auction-ID: A1-40897-9

offer 23034 Specifications: - grinding length approx. 350 mm - grinding width 150 mm - installation height with / without magnet 150 / 210 mm - Grinding wheel stroke approx. 200 mm - Clamping surface 300 x 160 mm - Magnetic clamping plate 250 x 150 mm - Grinding wheel dimensions approx. 200 x 80 x 78 mm - Grinding wheel speed 2800 rpm - Swivel range of the grinding arm approx. 180 ° - manual swivel arm clamping via clamping lever - Wet grinding device - Drive 400 V / 1.85 kW - Space requirement approx. W 850 x H 1650 x D 800 mm - Weight approx. 350 kg

Manufacturer: ELB Type: SWN 6 VA2 Year of construction: 1982 Grinding length: 600 mm Grinding width: 320 mm Workpiece height: 525 mm Table clamping surface: 600x300 mm Magnetic plate: 600x300 mm Machine dimensions: 2600x1500x2000 mm Machine weight: ca. 2t

SAACKE UW I D CNC universal grinding machine was manufactured in Germany in 2020. The extremely powerful machine is designed for the fully automatic wet grinding of a wide range of tools, such as knives, cutters or drills. Machining is performed in a single work cycle, which significantly increases production efficiency, saves time and reduces costs. The SAACKE CNC tool grinding machine allows the use of a chain or pallet system for automatic tool feeding and machining of workpieces within it with a maximum diameter of 250 mm and a length of 480 mm. Precision tool grinding is performed in five numerically controlled axes (X,Y,Z,A,B) using grinding wheels housed in a 6-position magazine separated from the workspace with an automatic grinding wheel changing system. In order to guarantee high travel speeds and positioning accuracy, the X,Y and Z axes of the UWID CNC tool grinder are m ...

Auction-ID: A1-40897-212

Auction-ID: A1-40897-210

Auction-ID: A1-40897-205

We have about 50 different guide rails, different length/width and height for sale. The guide rails are HSS and HSS with HM. Partly new or used . Please contact us so that we can make you an offer.

- E L B - HIGH-PRECISION ROTARY TABLE SURFACE GRINDING MACHINE TYPE: ROTARY 80 SPS-NK / YEAR OF CONSTRUCTION 2002 = GRINDING DIAMETER : 800 mm GRINDING HEIGHT : 400 mm (from work table) TABLE LOAD : 300 kg Machine dimensions : 2800 X 2800 X 2660 mm ( WxDxH) Machine weight : 5,500 kg Motor version : DS flange motor Grinding spindle drive : 10 kW Grinding spindle speed : adjustable via frequency controller Grinding spindle cone : 60 mm Grinding wheel : 400x100x127 mm Control voltage : 24V DC Installed power : 20KW Fuse : 50A FULL ROOM COVERAGE

We clear our grinding wheels warehouse, there are new wheels unused, undamaged. They are exclusively ceramic-bonded discs. Diameter from 200 mm - 500 mm Width from 10 mm - 40 mm Different bonds and hardness. Please contact us so that we can make you an offer. The discs are sold at reasonable prices.

Sharpening machine for band saw blades Manafacture: Alber Sharpening machine for band saw blades Sharpening circuit Fabr. Alber Model: TB1 - AE2 Year of construction: 1978

Auction-ID: A1-40897-203

Surface Grinding HARIG Super 612 - No 2 Travel X: 300 mm Travel Y: 170 mm Travel Z: 250 mm Grinding wheel: Ø 200 mm Spindle motor: 3600 RPM Manual movement X - Y - Z Manual magnetic tray 345 mm x 145 mm Auto lubrication axes X and Y Delivered with 2 new grinding wheels 1 vacuum cleaner Voltage: 380 V Width: 1400 mm Depth: 1500 mm Total height: 1900 mm Weight: approx 1 T

Disc grinding machine Grinding machine for plates, bowls, rings, wheels, etc. Manufacturer: Hempel Model No.: PQ-4 Year of construction: 1982

EWAG RS 15 Conventional Grinding Machine TECHNICAL FEATURES: X-axis travel: 490 [mm] Y-axis travel: 130 [mm] Z-axis travel: 115 [mm] Spindle power : 2.2 [kW] B-axis angular travel: 260 [°] Workpiece Spindle Nose: HSK 63 Inverter speed drive: Yes Visualization: RSF-Elektronik Visualization number of axes: 3 Irrigation tray capacity: 100 [l] Centralized Lubrication: Yes Supply voltage: 400 [V] Dimensions: 1700 x 1750 x 1840 [mm] Weight 1850 [Kg] Machine visible under tension for testing at our premises, by appointment. Price excl. VAT on request, including truck loading. Possibility of shipping throughout France as well as internationally. More photos and details on request. Technical description for information purposes only, without obligation on our part. Machine for sharpening tools, milling cutter, tap and drill. Mach ...

Surface Grinding HARIG Super 612 - No 1 Travel X: 300 mm Travel Y: 170 mm Travel Z: 250 mm Grinding wheel: Ø 200 mm Spindle motor: 3600 RPM Manual movement X - Y - Z Manual magnetic tray 345 mm x 145 mm Auto lubrication axes X and Y Delivered with 2 new grinding wheels 1 vacuum cleaner Voltage: 380 V Width: 1400 mm Depth: 1500 mm Total height: 1900 mm Weight: approx 1 T

Specifications: - Sanding belt dimensions approx. 50 x 2500 mm - Contact wheel diameter approx. 250 mm - Drive 400 V / 5.5 kW - Space requirement approx. W 1350 x H 2050 x D 900 mm - Weight approx. 200 kg

Gear grinder REISHAUER OZA with change gears.

EWAG RS-15 Conventional Grinding Machine TECHNICAL FEATURES: X-axis travel: 490 [mm] Y-axis travel: 130 [mm] Z-axis travel: 115 [mm] Spindle power : 2.2 [kW] B-axis angular travel: 260 [°] Workpiece Spindle Nose: HSK 63 Inverter speed drive: Yes Visualization: RSF-Elektronik Visualization number of axes: 3 Irrigation tray capacity: 100 [l] Centralized Lubrication: Yes Supply voltage: 400 [V] Dimensions: 1700 x 1750 x 1840 [mm] Weight: 1850 [Kg] Machine visible under tension for testing at our premises, by appointment. Price excl. VAT on request, including truck loading. Possibility of shipping throughout France as well as internationally. More photos and details on request. Technical description for information purposes only, without obligation on our part. Machine for sharpening tools, milling cutter, tap and drill. Mac ...

This 3-axis KNUTH HFS 30638 C surface grinding machine was manufactured in 2015. It has a weight of 1,960 kg and has operated for approximately 9,200 hours. If you are looking to get high-quality grinding capabilities, consider the KNUTH HFS 30638 C machine we have for sale. Contact us for further details.

Specifications: - Polishing wheels - grinding wheel dimensions approx. 300 x 40 x 76 mm - Sanding belt dimensions approx. 3500 x 50 mm - Contact wheel dimensions 400 x 50 mm - Drive speed 1450 rpm - Drive 400 V / 1.8 kW - Space requirement approx. W 1100 x H 2450 x D 800 mm - Weight approx. 300 kg

max. grinding diameter: 238 - 620 mm grinding length: 190 mm workpiece length: 380 - 940 mm current capacity: 380 kVA power capacity - grinding motor: 1,1 kW speeds of grinding spindle: 2 - 10.000 U/min total power requirement: 2,2 kW Mechanic: very good: Optical condition: very good: Condition: general reconditioning: The machine can be viewed under current.: operating key and instruction: Machine and accessories completely overhauled with CE marking 400 V, 50 Hz, with CEE plug and cable BASICMACHINE! built of year 1988 / overhauled in 2023 Color: 2 K repainting Stand RAL 7005 mouse gray Structure and accessories RAL 7035 light gray motorized height adjustment, axial grinding spindle adjustment Complete electrical conversion includes: > Fi circuit breaker > new three-phase drive > new brake motor > new frequency regulation > new touch-safe built-in electronics > EMV screw ...

Inner diameter: 150 mm Grinding depth: 200 mm Table lift: 425 mm large oscillating circuit diameter: 250 / 420 mm Bore: 80 mm Table speed -infinitely-0.5 - 10 m/min Workpiece speeds: 125/176/246/350 rpm Spindle speed: 17000 rpm Total power requirement: 2.2 / 0.5 / 0.9 kW Machine weight ca. 2 t Space requirement approx. 2.40 x 1.20 x 1.45 m Control: conventional

Auction-ID: A1-49374-117

Auction-ID: A3-46162-17450

weight of the machine ca.:15 t

Shaft grinding machine with belt grinding attachment Specifications: - Flexible shaft 1500 mm - 5 speeds - Belt grinding attachment - Drive 380 V - mobile underframe - Space requirement approx. W 600 x H 1400 x D 600 mm - Weight approx. 80 kg

grinding length: 900 mm grinding width: 510 mm workpiece height: 400 mm table surface area: 800 x 400 mm longitudinal feed of the table: max. 980 mm table speed -stepless-: 1 - 35 m/min grinding wheel size: 355 x 51 x 127 mm cross feed of the table: 460 mm cross feed: 1 - 40 mm/Hub vertical feed autom.: 0,005 - 0,04 mm/Hub rapid traverse vertical: 0,5 m/min grinding spindle speed: 1450 U/min grinding spindle drive: 5,6 kW table load capacity: max. 1000 kg total power requirement: 10 kW weight of the machine ca.: 4,4 t Accessories: magnetic plate 800 x 400 mm, various grinding wheels with and without flanges, wet grinding attachment with paper band filter The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length:400 mm workpiece weight:250 kg weight of the machine ca.:4,1 t swing diameter:250 mm grinding spindle speed:2387, 2938 U/min

Specifications: - Flexible shaft 1500 mm - infinitely variable speeds 1000 to 12000 rpm - Drive 380 V - mobile underframe - Space requirement approx. W 750 x H 1400 x D 500 mm - Weight approx. 50 kg

• Grinding chamber with gradation for large individual parts • Dimensions: 3400 x 3750 x 2400 mm • Performance: Long sanding belts 5500 x 100 mm

grinding diameter:300 mm grinding length:540 mm centre height:175 mm total power requirement:20 kVA centre distance:1000 mm

grinding diameter:50 mm grinding length:100 mm centre height:100 mm centre distance:200 mm

dimensions of the machine ca.:3,5 x 2,0 x 2,5 m

Belt grinding station, support table with T-slot, Sanding belt width 100 mm, Sanding disc D 300 mm, with support table 350 x 140 mm, Suction connection available. Motor power: 0.9/ 1.3 kW 400 V/ 50 Hz 1450/ 2900 rpm Connection cable with CEE plug 16 A Machine dimensions: H 1450 x D 410 x W 900 mm Weight approx. 200 kg Transport vertical, bolted to EURO pallet.

max. wheel diameter:280 mm max. module:5 min. module:1 min. number of teeth:7 toolpiece turning speed range:4.000...10.000 U/min tool length:210 mm CBN

grinding diameter max.:400 mm max. width of grinding wheel:180 mm grinding range:2-100 mm total power requirement:24 kW weight of the machine ca.:3,2 t Out of valve production

max. wheel diameter:275 mm gear width:58 mm max. module:8 min. module:0,5 weight of the machine ca.:10 t max. number of teeth:200 min. number of teeth:5

Long belt sanding machine, veneer sanding machine, Specifications: Table width 2800 mm Grinding width 2500 mm Table depth approx. 2000 mm Sanding belt length 9500 mm Pressure lamellar belt length 10 mm x 7750 mm Sanding belt dimensions 150 mm x 9500 mm Belt speed 25 + 12.5 m/s Suitable for intermediate paint sanding Workpiece height 6 - 220 mm Grinding engine power 24 kW Total power 27 kW Machine dimensions approx. L 5000 x W 2300 x H 2400 mm Space requirement of the machine in width is 3500 mm Machine weight 2600 kg TOP condition, technical documentation, sanding belt.

Technical data of the used Equiptop ESG-1228ASD Tangential Rectification: Magnetic plane: 712 x 330 mm Automatic working stroke: 760 mm (manual 830 mm) Grinding wheel diameter: 355 mm Grinding wheel thickness: 50 mm Engine: 7 1/2 hP Automatic diamond maker Increased working height CE certified; Year: 2000 Machine in excellent condition, CE certified.

max. wheel diameter:275 mm gear width:58 mm max. module:8 min. module:0,5 weight of the machine ca.:10 t max. number of teeth:200 min. number of teeth:5

grinding length:900 mm grinding width:400 mm workpiece height:450/530 mm table clamping surface LxW:1.320 x 300 mm magnetic plate size:880 mm x 280 mm mm Finimatic Creep speed Add-on for Diaform Rectifier system Coolant device Infinitely variable grinding clamping drive

centre height:500 mm centre distance:2000 mm control:CNC Grundig Numerik total power requirement:400 V, 50 Hz, 22,5 kW weight of the machine ca.:3300 kg dimensions of the machine ca.:2500 x 4000 x 2400 mm
