vertikal used for sale

Machine Model Sulak BIS 02 MAXI Machine Type Vertical Glass Edging Machine Glass Thickness 3 – 20 mm Minimum Glass Size 200 × 200 mm Maximum Glass Size Approx. 2600 × 2600 mm Conveyor Speed Approx. 0.5 – 6 m/min (variable) Spindle Speed 2800 rpm Installed Power 3.3 kW Electrical Supply 3 × 400 V, 50/60 Hz Machine Weight Approx. 620 kg Dimensions (L × W × H) 4580 × 850 × 2500 mm Minimum Internal Radius Ø 300 mm Processing Type Grinding and Polishing of Flat Glass Edges

Maximum turning diameter: 3800 mm Maximum swing diameter: 3800 mm diameter of spindle flange: 1900 mm control: Siemens 840 D sl Table rpm: 100 1/min Maximum speed of driven tools: 6000 1/min x-travel: 2800/3200 mm z-travel: 1000 mm Feed - X: 20 m/min feed capacity - x: 22 kN tool taper: CAPTO C8 total power requirement: 280 kVA dimensions of the machine ca.: 10,4 x 6.3 x 5,7 m weight of the machine ca.: 155 t Equipment/Accessories: - 2 tool changers, each with 60 positions - 2 x chip conveyors - Coolant system, 6 bar - High-pressure cooling, 70 bar - Knoll paper belt filter - 12-jaw balancing chuck, RÖHM - internal coolant supply - Hydraulic unit - Automatic door - Electric handwheel - Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Single column vertical turning lathe BERTHIEZ TM500 SP, as follows: Manufacturer: Berthiez: (France) Model: TM500 SP Year of manufacture: 1979 Main technical data: Table diameter: 6300 mm Maximum turning diameter: 15000 mm Maximum usable height: 4000 mm Arm travel: 3600 mm Main motor power 100KW Maximum allowable load on faceplate: 80 t Ram size: 360x360mm Machine weight ab. 250ton The machine can perform turning and milling operations. The machine is equipped with 2 milling attachements. One head is for high speed milling 3000rpm and one is with 1500rpm

Main Technical Specifications: Machine Type: Heavy-Duty CNC Vertical Turning Lathe Chuck / Table Diameter: 4,500 mm Maximum Machining Height: 3,150 mm Maximum Workpiece Load Capacity: 80 metric tons CNC Control System: Siemens The machine is suitable for heavy machining applications in the power generation, metallurgy, heavy engineering, and other industrial sectors. Price, technical documentation, photographs, and further details regarding the machine’s condition and configuration are available upon request.

Model : VTS-1620 CNC Vertical Lathe Year : 2013 Table : 1600mm manual chuck/10,000 kg load Table speed : 250 rpm Max swing : 2000mm Max cutting height : 1556mm X/Z : -127~1600mm/960mm Ram size : 308x250mm 37.5/45 kW motor 18 position ATC 8 tool holders Tool presetter Manual guide i Chip conveyor Fanuc control

Model : V550 CNC Vertical Lathe Year : 2012 Max cutting dia : 730mm Max cutting height : 730mm Table speed : 2000rpm 21" hyd. Chuck 10 Position Turret Gearbox Chip conveyor Fanuc control

EMAG VL 5 i Vertical Pick-up Lathe GENERAL Project No.: 906056 Quantity: 1 pcs. Manufacturer: EMAG Type: VL 5 i Control: Fanuc 32i MA Year of Make: 2012 Condition: Used machine Program run approx. (hrs.): 37064 DESCRIPTION TURNING Max. turning diameter 220 mm Max. workpiece length 175 mm Max. circumferential diameter over bed cover 270 mm Max. chuck diameter 250 mm Max. speed main spindle 4500 1/min Max. power main spindle at ED 10-40/100% 27/18 kW Max. torque main spindle at ED 10-40/100% 300/200 Nm Spindle diameter in the front bearing main spindle 110 mm Spindle flange size main spindle size size 6 Travel in X/Y/Z Main spindle unit 660/-/300 mm Max. rapid traverse speed in X/Y/Z Main spindle unit 60/-/30 m/min Feed force in X/Y/Z Main spindle unit 10/-/10 kN Direct displacement measurement system main spindle unit X/Z Full-clamping cylinder on the ...

EMAG VL 6 Vertical Pick-up Lathe GENERAL Project No.: 906057 Quantity: 1 pcs. Manufacturer: EMAG Type: VL 6 Control: Fanuc 32i B Year of Make: 2021 Condition: Used machine Program run approx. (hrs.): 21797 DESCRIPTION TURNING Max. turning diameter 300 mm Max. turning length 250 mm Max. workpiece length 250 mm Max. circumferential diameter over bed cover 270 mm Max. chuck diameter 400 mm Max. speed main spindle 3100 1/min Max. power main spindle at ED 10-40/100% 39/28 kW Max. torque main spindle at ED 10-40/100% 460/340 Nm Travel in X/Y/Z Main spindle unit 880/-/480 mm Max. rapid traverse speed in X/Y/Z Main spindle unit 60/-/30 m/min Direct displacement measurement system main spindle unit X/Z Full-clamping cylinder on the main spindle Revolver Bottom Number of stations/powered by 12/12 Tool holder in the BMT 65 turret Speed tool drive 6000 1/mi ...
