UVV maintenance according to BG guideline BGR 500 Pradler Maschinen Service & Electrical Engineering Recognised maintenance technician On-site inspection , Test report Creation , Sealing Occupational safety (trailing measurement safety distance ) Operational safety according to DGUV regulation 3

pressure:300 t distance between columns:1800 mm stroke:1000 mm Distance table/ram, max. stroke up, adjustment up:1300 mm Table surface area:1600 x 1200 mm Table height above floor:1080 mm Ram surface:1600 x 1200 mm Weight:24,0 t Dimensions (WxDxH):2,8 x 2,1 x 6,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:400 t distance between columns:3250 mm distance table/ram, max. stroke up, adjustment up:1000 mm stroke:800 mm table surface area:3250 x 1400 mm table height over floor:1250 mm die cushion capacity:170 t die cushion stroke:200 mm die cushion area:1800 x 1000 mm distance between cutting impact cushioning:2610 mm side window:800 mm ram surface:3250 x 1400 mm return capacity:51 t speed down:300 mm/s speed up:300 mm/s working speed:16 - 33 mm/s quantity of oil:2900 l power requirement:100,0 kW weight:70,0 t Dimensions (WxDxH):4,9 x 3,1 x 7,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic

Pressure:080 t throat:380 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:472 mm table surface area:840 x 610 mm table height over floor:800 mm passage to the back:520 mm ram surface:650 x 400 mm ram adjustment:70 mm power capacity:7,5 kW weight:6,9 t Dimensions (WxDxH):1,1 x 2,15 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic

pressure:250 t distance between columns:930 mm stroke:200 mm Distance table/ram, stroke up:600 mm table surface area:900 x 860 mm die cushion capacity:100 t die cushion stroke:50 mm die cushion area:350 x 400 mm table height over floor:950 mm side window:380 x 380 mm ram surface:850 x 700 mm feed down:400 mm/s feed up:400 mm/s working feed:30 mm/s oil volume:350 l power capacity:45,0 kW weight:11,5 t Dimensions (WxDxH):2,0 x 1,2 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic depth stop:mechanical foundation pit:not necessary

pressure:1000 t distance between columns:3030 mm stroke:350 mm Distance table/ram, max. stroke up, adjustment up:1400 mm table surface area:3000 x 2000 mm table height over floor:430 mm side window:1450 x 1400 mm ram surface:3000 x 2000 mm speed down:300 mm/s speed up:340 mm/s working speed:18 - 44 mm/s return capacity:120 t oil volume:4400 l width with platform:4950 mm power capacity:2 x 90,0 + 10,0 kW weight:87,0 t Dimensions (WxDxH):4,35 x 3,65 x 7,55 m height over floor:6,05 m height beneath floor:1,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:200 t distance between columns:1650 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1250 mm die cushion capacity:80 t die cushion stroke:300 mm die cushion area:1300 x 900 mm table height over floor:800 mm ram surface:1600 x 1250 mm oil volume:ca. 2000 l power capacity:43,0 kW weight:25,0 t Dimensions (WxDxH):2,9 x 2,3 x 5,8 m height beneath floor:0,85 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20

pressure:350 t distance between columns:1350 mm stroke:900 mm distance table/ram, max. stroke up, adjustment up:1300 mm table surface area:1300 x 1000 mm pressure of drawing cushion in table:100 t stroke of drawing cushion in table:380 mm die cushion area:350 x 285 mm capacity of ejector in ram:25 t ejector stroke in ram:200 mm table height over floor:750 mm ram surface:1300 x 1000 mm speed down:500 mm/s speed up:160 - 470 mm/s working speed:16 - 44 mm/s drawing speed:57 - 160 mm/s return capacity:32 t oil volume:1700 l power requirement:91,0 kW Dimensions (WxDxH):3,75 x 2,8 x 7,2 m height over floor:5,28 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:in TDC foundation pit:necessary

Pressure:500 t distance between columns:1550 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1200 x 1300 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:150 mm die cushion area:950 x 950 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:780 mm/s working speed:105 mm/s oil volume:4000 l power requirement:263,0 kW weight:45,0 t Dimensions (WxDxH):3,3 x 3,3 x 6,1 m height over floor:6,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable

Pressure:315 t distance between columns:1350 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1200 x 1300 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:680 mm/s working speed:180 mm/s oil volume:2000 l power requirement:150,0 kW weight:35,0 t Dimensions (WxDxH):3,3 x 3,3 x 5,5 m height over floor:5,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:motorisch verstellbar ram interlocking:hydraulisch

pressure:160 t distance between columns:1340 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:930 mm side window:600 mm ram surface:1300 x 900 mm speed down:367 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:15,0 t Dimensions (WxDxH):2,5 x 2,2 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

Pressure:063 t throat:250 mm stroke:10 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:380 mm table surface area:700 x 500 mm hole in the table:180 x 140 mm table height over floor:700 mm ram surface:360 x 275 mm ram adjustment:60 mm power requirement:5,5 kW weight:3,8 t Dimensions (WxDxH):1,9 x 1,7 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical

pressure:150 t throat:400 mm stroke:30 - 150 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1000 x 750 mm hole in the table:320 x 200 mm table height over floor:800 mm ram surface:800 x 600 mm ram adjustment:85 mm weight:10,0 t Dimensions (WxDxH):1,4 x 2,2 x 3,1 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram counterbalance:pneumatic

pressure:100 t throat:380 mm stroke:650 mm distance table/ram, max. stroke up, adjustment up:950 mm table surface area:800 x 700 mm hole in the table:200 mm table height over floor:920 mm ram surface:630 x 600 mm speed down:65 mm/s speed up:375 mm/s working speed:17 mm/s oil volume:350 l power requirement:18,5 kW weight:9,0 t Dimensions (WxDxH):1,5 x 2,5 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 §20

pressure:250 t distance between columns:1125 mm stroke:250 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1100 x 900 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:100 mm die cushion area:700 x 400 mm table height over floor:960 mm side window:700 mm ram surface:1080 x 900 mm oil volume:1000 l power requirement:35,0 kW weight:23,0 t Dimensions (WxDxH):2,5 x 2,3 x 4,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick foundation pit:not necessary

pressure:160 t distance between columns:880 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:830 x 1000 mm hole in the table:265 x 365 mm table height over floor:850 mm side window:610 mm ram surface:860 x 1000 mm power requirement:55,0 kW weight:14,7 t Dimensions (WxDxH):2,2 x 2,0 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary

pressure:300 t distance between columns:2500 mm stroke:350 mm distance table/ram, max. stroke up, adjustment up:1280 mm table surface area:2500 x 1500 mm table height over floor:850 mm side window:900 mm ram surface:2500 x 1500 mm speed down:300 mm/s speed up:240 - 450 mm/s working speed:23 - 44 mm/s oil volume:3000 l power requirement:132,0 kW weight:54,0 t Dimensions (WxDxH):3,25 x 3,2 x 4,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA

pressure:200 t distance between columns:1800 mm stroke:710 mm Distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1600 x 1300 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:250 mm die cushion area:1400 x 1080 mm table height over floor:800 mm side window:1300 mm ram surface:1660 x 1300 mm speed down:400 mm/s speed up:410 mm/s working speed:14,3 - 49,7 mm/s power requirement:46,0 kW weight:25,0 t Dimensions (WxDxH):3,65 x 3,3 x 5,4 m height over floor:5,05 m height beneath floor:0,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical

pressure:50 t distance between columns:1750 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1700 x 750 mm table height over floor:800 mm side window:650 x 750 mm ram surface:1700 x 750 mm power requirement:11,0 kW weight:11,0 t Dimensions (WxDxH):2,1 x 1,15 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:100 t throat:350 mm stroke:6 - 100 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:850 x 700 mm hole in the table:470 x 150 mm table height over floor:855 mm ram surface:450 x 300 mm ram adjustment:80 mm power requirement:7,5 kW weight:5,0 t dimensions (WxDxH):1,5 x 2,3 x 2,6 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical

pressure:500 t distance between columns:2240 mm stroke:1180 mm distance table/ram, max. stroke up, adjustment up:1800 mm table surface area:2050 x 1800 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:380 mm drawing cushion surface in table:1800 x 1200 mm pressure of drawing cushion in ram:122 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:1800 x 1200 mm ram surface:2215 x 1800 mm table height over floor:500 mm speed down:400 mm/s speed up:10 - 400 mm/s working speed:10 - 100 mm/s depth of the foundation:3,0 m power requirement:122 + 75 + 64,5 kW weight:110,0 t Dimensions (WxDxH):3,6 x 2,2 x 8,5 m height over floor:6,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic

pressure:500 t distance between columns:3200 mm stroke:1250 mm distance table/ram, max. stroke up, adjustment up:1810 mm table surface area:3000 x 1900 mm pressure of drawing cushion in ram:150 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:2400 x 1200 mm ram surface:3160 x 1900 mm speed down:400 mm/s speed up:250 mm/s working speed:18 - 58 mm/s height over floor:6,5 m power requirement:90,0 + 36,5 kW weight:110 t German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic

pressure:100 t distance between columns:1060 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1250 mm table surface area:1000 x 700 mm pressure of drawing cushion in table:40 t stroke of drawing cushion in table:200 mm die cushion area:Ø 250 mm table height over floor:950 mm side window:580 x 750 mm ram surface:1000 x 700 mm oil volume:700 l power requirement:47,0 kW weight:13,0 t Dimensions (WxDxH):2,2 x 1,8 x 5,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA

pressure:6,3 t throat:300 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:450 x 400 mm hole in the table:80 mm table height over floor:700 mm ram surface:50 mm oil volume:90 l power requirement:5,5 kW weight:1,35 t dimensions (WxDxH):1,8 x 2,0 x 2,7 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical

pressure:160 t throat:370 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1000 x 700 mm hole in the table:100 mm table height over floor:820 mm ram surface:600 x 520 mm speed down:350 mm/s speed up:350 mm/s working speed:12 - 36 mm/s oil volume:1100 l power requirement:27,0 kW weight:16,5 t dimensions (WxDxH):1,8 x 2,7 x 3,95 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:motoric adjustable

pressure:080 t throat:360 mm stroke:8 - 112 mm no. of strokes:78 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:900 x 650 mm hole in the table:250 mm table height over floor:800 mm passage to the back:330 mm ram surface:650 x 400 mm ram adjustment:80 mm power requirement:11,0 kW dimensions (WxDxH):1,2 x 2,2 x 2,9 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanisch

pressure:315 t distance between columns:1620 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1100 mm pressure of drawing cushion in ram:20 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:300 x 300 mm side window:600 x 1100 mm table height over floor:750 mm ram surface:1600 x 1100 mm oil volume:1500 l power requirement:110,0 kW weight:35,0 t dimensions (WxDxH):4,65 x 2,61 x 5,5 m height over floor:5,05 m height beneath floor:0,45 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic ram interlocking:pneumatic cutting impact cushioning:hydraulic

pressure:60 t distance between columns:650 mm stroke:220 mm distance table/ram, max. stroke up, adjustment up:410 mm table surface area:600 x 525 mm pressure of drawing cushion in table:5 t stroke of drawing cushion in table:80 mm table height over floor:900 mm side window:200 mm ram surface:560 x 490 mm dimensions (WxDxH):1,9 x 1,3 x 2,7 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick FGS 600 drawing cushion in table:hydraulic foundation pit:not necessary

pressure:160 t throat:360 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:920 x 700 mm Hole in the table:150 mm table height over floor:960 mm passage to the back:590 mm ram surface:620 x 560 mm speed down:390 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:16,0 t dimensions (WxDxH):1,6 x 2,5 x 3,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanisch

pressure:100 t distance between columns:1000 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:650 mm table surface area:980 x 700 mm pressure of drawing cushion in table:4 x 10 / 1 x 20 t stroke of drawing cushion in table:180 mm table height over floor:800 mm side window:400 mm ram surface:1000 x 700 mm speed down:500 mm/s speed up:450 mm/s working speed:60 mm/s power requirement:40,0 kW dimensions (WxDxH):1,5 x 1,4 x 4,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:4 x 10 t + 1 x 20 t, getrennt einschaltbar foundation pit:nicht erforderlich

pressure:200 t distance between columns:970 mm stroke:360 mm Distance table/ram, max. stroke up, adjustment up:630 mm table surface area:1000 x 800 mm capacity of ejector:10 t ejector stroke in table:160 mm table height over floor:850 mm side window:400 mm ram surface:1000 x 800 mm speed down:420 mm/s speed up:410 mm/s working speed:50 mm/s oil volume:1240 l return capacity:24 t power requirement:45,0 + 15,0 kW weight:16,0 t dimensions (WxDxH):2,7 x 2,5 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:mechanisch foundation pit:nicht erforderlich

Pressure:063 t throat:400 mm stroke:16 - 90 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:350 mm table surface area:1000 x 750 mm hole in the table:260 x 140 mm table height over floor:710 mm ram surface:600 x 220 mm ram adjustment:50 mm weight:4,3 t dimensions (WxDxH):1,1 x 2,6 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch

pressure:100 t throat:540 mm stroke:560 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1000 x 1000 mm pressure of drawing cushion in table:50 t stroke of drawing cushion in table:200 mm die cushion area:710 x 650 mm table height over floor:910 mm ram surface:1000 x 1000 mm capacity of ejector in ram:2 t ejector stroke in ram:200 mm return capacity:19,5 t speed down:400 mm/s speed up:300 mm/s working speed:57,7 mm/s oil volume:650 l power requirement:37,5 kW weight:15,0 t dimensions (WxDxH):1,5 x 2,5 x 4,45 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion / ejector in table:hydraulisch ejector in ram:hydraulisch depth stop:mechanisch

pressure:150 t distance between columns:300 mm stroke:180 mm distance table/ram, max. stroke up, adjustment up:300 mm table surface area:570x180 / 300x410 mm table height over floor:875 mm side window:180 mm ram surface:180 mm speed down:250 mm/s speed up:160 mm/s working speed:6 - 12 mm/s oil volume:250 l power requirement:11,0 kW weight:2,4 t dimensions (WxDxH):1,3 x 1,3 x 2,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 foundation pit:nicht erforderlich

pressure:200 t distance between columns:1050 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:450 mm table surface area:1000 x 1200 mm table height over floor:850 mm side window:500 mm ram surface:1050 x 870 mm speed down:300 mm/s speed up:300 mm/s working speed:18 - 36 mm/s power requirement:37,0 kW weight:16,0 t dimensions (WxDxH):4,0 x 3,6 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulisch cutting impact cushioning:hydraulisch foundation pit:nicht erforderlich

pressure:100 t throat:315 mm stroke:30 - 160 mm no. of strokes:40 /min distance table/ram, max. stroke up, adjustment up:460 mm table surface area:910 x 680 mm Hole in the table:400 mm table height over floor:800 mm passage to the back:400 mm ram surface:630 x 400 mm ram adjustment:80 mm power requirement:7,5 kW weight:7,5 t dimensions (WxDxH):1,7 x 2,0 x 3,0 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical ram counterbalance:pneumatic

pressure:080 t throat:300 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:710 x 560 mm hole in the table:240 x 115 mm table height over floor:800 mm ram surface:400 x 315 mm ram adjustment:80 mm power requirement:7,5 kW weight:5,1 t dimensions (WxDxH):1,4 x 1,9 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical

pressure:060 t throat:220 mm stroke:6 - 94 mm no. of strokes:115 /min distance table/ram, max. stroke up, adjustment up:340 mm table surface area:680 x 400 mm hole in the table:120 x 70 mm table height over floor:750 mm passage to the back:290 mm ram surface:240 x 240 mm ram adjustment:57 mm power requirement:3,7 kW weight:2,8 t dimensions (WxDxH):1,5 x 1,5 x 2,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic

pressure:063 t throat:280 mm stroke:8 - 100 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:620 x 500 mm hole in the table:230 mm table height over floor:800 mm ram surface:310 x 255 mm ram adjustment:63 mm power requirement:5,5 kW weight:3,95 t dimensions (WxDxH):1,2 x 1,8 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical

Pressure:080 t throat:300 mm stroke:8 - 100 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:440 mm table surface area:720 x 600 mm hole in the table:300 x 175 mm table height over floor:860 mm ram surface:400 x 270 mm ram adjustment:60 mm power requirement:7,5 kW weight:6,0 t dimensions (WxDxH):1,3 x 2,2 x 3,05 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic, Ortlinghaus overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic

pressure:075 t throat:230 mm stroke:6 - 100 mm no. of strokes:105 /min distance table/ram, max. stroke up, adjustment up:354 mm table surface area:700 x 420 mm hole in the table:250 mm table height over floor:800 mm passage to the back:310 mm ram surface:264 x 270 mm ram adjustment:60 mm power requirement:5,5 kW weight:3,6 t dimensions (WxDxH):1,2 x 1,6 x 2,3 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1

Pressure:200 t distance between columns:1910 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1900 x 1150 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:300 mm die cushion area:1500 x 950 mm table height over floor:800 mm side window:1000 mm ram surface:1900 x 1100 mm return capacity:36 t speed down:400 mm/s speed up:170 mm/s working speed:30,5 mm/s oil volume:1500 l height over floor:4,85 m height beneath floor:2,6 m power requirement:45,0 kW weight:38,0 t dimensions (WxDxH):3,05 x 2,8 x 5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:300 t distance between columns:1220 mm stroke:1000 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1200 x 1000 mm pressure of drawing cushion in table:115 t stroke of drawing cushion in table:400 mm die cushion area:1100 x 860 mm table height over floor:900 mm side window:550 x 1000 mm ram surface:1200 x 1030 mm speed down:400 mm/s speed up:350 mm/s working speed:12 - 31 mm/s oil volume:1080 l power requirement:36,0 + 19,0 kW weight:22,0 t dimensions (WxDxH):2,5 x 2,5 x 6,3 m height over floor:5,4 m height beneath floor:0,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick hydraulic safety block and pump:Fabrikat Rexroth

pressure:100 t throat:375 mm stroke:20 - 125 mm no. of strokes:30 - 80 /min distance table/ram, max. stroke up, adjustment up:515 mm table surface area:900 x 635 mm hole in the table:280 mm table height over floor:800 mm passage to the back:570 mm ram surface:700 x 450 mm ram adjustment:80 mm power requirement:15,0 kW weight:8,0 t dimensions (WxDxH):1,5 x 2,4 x 3,5 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic

pressure:400 t throat:520 mm stroke:20 - 200 mm no. of strokes:30 /min distance table/ram, max. stroke up, adjustment up:680 mm table surface area:1600 x 1000 mm table height over floor:715 mm passage to the back:1000 mm ram surface:1300 x 800 mm ram adjustment:130 mm power requirement:38,0 kW weight:41,0 t dimensions (WxDxH):2,1 x 2,6 x 4,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Ortlinghaus overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic

pressure:25 t throat:400 mm stroke:1000 mm distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:620 x 620 mm Hole in the table:80 mm table height over floor:650 mm ram surface:110 mm speed down:300 mm/s speed up:500 mm/s working speed:14 - 85 mm/s oil volume:400 l power requirement:6,0 kW weight:3,8 t dimensions (WxDxH):1,5 x 2,1 x 3,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:40 t distance between columns:500 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:300 mm table surface area:480 x 400 mm hole in the table:50 mm table height over floor:950 mm side window:150 mm ram surface:150 mm speed down:480 mm/s speed up:480 mm/s working speed:20 mm/s oil volume:160 l power requirement:7,5 kW weight:2,6 t dimensions (WxDxH):1,1 x 1,4 x 2,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick depth stop:mechanical foundation pit:not necessary

pressure:125 t throat:340 mm stroke:20 - 160 mm no. of strokes:55 /min distance table/ram, max. stroke up, adjustment up:480 mm table surface area:1000 x 660 mm table height over floor:730 mm ram surface:600 x 300 mm ram adjustment:75 mm power requirement:8,5 kW weight:7,8 t dimensions (WxDxH):1,4 x 2,8 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical

pressure:160 t throat:500 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1140 x 980 mm hole in the table:180 mm table height over floor:860 mm ram surface:1000 x 800 mm oil volume:1000 l power requirement:50,0 kW weight:18,0 t dimensions (WxDxH):1,3 x 2,6 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical cutting impact cushioning:hydraulic

pressure:200 t distance between columns:1100 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1000 x 1000 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:250 mm die cushion area:800 x 750 mm table height over floor:800 mm ram surface:1000 x 1000 mm Speed down:400 mm/s speed up:250 mm/s working speed:22 - 56 mm/s power requirement:45,0 kW weight:24,0 t dimensions (WxDxH):2,4 x 1,5 x 5,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic
