120173011
FRIGOSCANDIA GYRoCOMPACT M76-10-28-NS-CR
Spiral freezers

Product number: 1050 Type: GYRoCOMPACT M76-10-28-NS-CR Serial number: O-1200125 Year of construction: 2002 Model: North - South, Clockwise Belt width: 760 mm Tiers: 28 pcs Product gap: 75 mm Capacity: 1600 kg/hr  ...
used machine

Product number: 1050
Type: GYRoCOMPACT M76-10-28-NS-CR
Serial number: O-1200125
Year of construction: 2002
Model: North - South, Clockwise
Belt width: 760 mm
Tiers: 28 pcs
Product gap: 75 mm
Capacity: 1600 kg/hr (Nuggets of +70°C)
Belt length: 366.8 meters
Belt surface: 215.6 m²
Outfeed height: 2670 mm
Refrigerant: R717/Ammonia
Cooling capacity: 220 kW / 65 tons
Power: 3 x 400V, 50Hz, 49 kW
Dimensions: 8600 x 4800 x 4110 mm
Including CIP system
Siemens S7 PLC with touch screen
2002
Price
  NL   request
119940882
GEA GRASSO GMBH VP 1300
Ammonia Liquid Chiller GEA Grasso VP 1300

Ammonia Liquid Chiller GEA Grasso VP 1300 CAPACITY CONTROL All screw compressors used in the package series are fitted with a continuous capacity control with a range of 10 - 100%. The capacity is adjusted by shor ...
used machine

Ammonia Liquid Chiller GEA Grasso VP 1300

CAPACITY CONTROL
All screw compressors used in the package series are
fitted with a continuous capacity control with a range
of 10 - 100%.
The capacity is adjusted by shortening the compressor
stroke. The defining factor for the compression
process is the effective rotor length; this is altered by
a hydraulically operated control slide (mounted below
the rotors).
As a standard, each Grasso liquid chiller FX PP, LP, VP comprises a low-voltage switchgear installation (IP54) with
integral freely programmable logic controller (PLC) GSC. The software functions and the assignment of
inputs/outputs of the GSC control are described separately.
THE STANDARD SCOPE OF DELIVERY FOR THE LOW-VOLTAGE SWITCHGEAR INSTALLATION FOR LIQUID
CHILLERS FX COMPRISES:
• Main switch (load break cut-out)
• star/delta combination for drive motor
• motor fuse
• motor current transformer
• motor winding protector
• PLC hardware
• oil pump contactor
• control transformer with double control fuse on primary and
secondary side
• 24 V DC current supply
• emergency Off button
• signal lamp - compressor running
• signal lamp — fault
• signal lamp - warning

Price
  FI   request
119940702
YORK SABROE, DENMARK DuoPack SAB 128 HF - 750 kW
Refrigeration Screw Compressor SAB 128 HF

Refrigeration Screw Compressor DuoPack SAB 128 HF - 750 kW This is a chiller package made by Sabroe Denmark in 2002, cooling capacity 750 kW, adjustable for 10-100% load. The package consist of two separate liquid coo ...
used machine

Refrigeration Screw Compressor DuoPack SAB 128 HF - 750 kW

This is a chiller package made by Sabroe Denmark in 2002, cooling capacity 750 kW, adjustable for 10-100% load. The package consist of two separate liquid cooling screw compressors type SAB 128 HF (DuoPack) with their own electric motor, both operating with R22 refrigerant. Units are built on a common base frame with an integrated horizontally mounted common oil separator, oil circulation pump, oil filter, suction- discharge- and safety valves. Unit has local control unit Unisab III system. Unit was dismantled in year 2014 and is ready for immediate shipment

Lubrication oil of the refrigeration compressor is fed to the compressors during the compression process for lubrication, sealing, noise reduction and to remove some of the heat of compression. After the compression process, the oil is separated from the refrigerant in the oil separator. The refrigerant-oil mixture is led into the lower part of the vertical oil separator. There, the first step of oil separation is performed by a combined agglomerator/ demister. The lower part of the oil separator is also used as an oil receiver. The fine separation of the aerosol-type oil portion from the refrigerant is carried out in the upper part of the oil separator by means of coalescing cartridges. The oil separated in the fine section of the oil separator is returned to the compressors suction side via an additional injection orifice.

Technical data
Manufacturer: York Sabroe Denmark
Manufacturing year 2002
Compressor type SAB 128 HF (DuoPack)
Refrigerant R 22
Cooling capacity 2 x 379 kW ( 0 /+40C)
Swept volume 2 x 454 m3/h
Electric drives (compressor) 2 x 110 kW - 400/690 V 50Hz (also suitable for 60Hz)
Control system UNISAB III
2002
Price
  FI   request
119837518
CENTURY 600 USRT Type AR-W-600 G2
Absorption Chiller, Two Stage

Two Stage Steam Absorption Chiller Century 3 x 600 US Refrigeration Tons This in one chiller plant with 3 identical two stage steam absorption chillers made by Finetec Century in year 2005. Total cooling capacity of t ...
used machine

Two Stage Steam Absorption Chiller Century 3 x 600 US Refrigeration Tons

This in one chiller plant with 3 identical two stage steam absorption chillers made by Finetec Century in year 2005. Total cooling capacity of this plant is 1800 USRT or 6.33 MW and the plant needs approx 7.9 t/h steam min pressure 8.0 bar. These are high efficiency absorption chillers utilizing low pressure steam for generating refrigerant (water) vapor and lithium bromide solution as an absorbent. The equipment is NEVER installed and some parts of control system - with Siemens Simatic S 7 PLC - are missing today.

The plant has the following main technical data:
Made by: Finetec Century India
Year of manufacturing: 2005
Number of chillers 3 pcs
Type of chillers AR-W-600G2
Cooling capacity USRT 600 / unit (2.11 MW)
Chiller water temp in-out 12 Deg C in, 7 Deg C out
Flow rate of chilled water 3 x 362.9 m3/hour
Cooling water temp in-out 32 Deg C in, 37.4 Deg C out
Cooling water flow rate 3 x 624 m3/h
Steam flow required 3 x 2.64 t/h at min 8 bars
Main dimensions / machine 6.61 x 2.25 x 2.66 m (L x W x H)
Machine weight dry 3 x 17 tons

Each chiller has the following components and system functions
1. Evaporator. The refrigerant (water) is evaporated in tube bank with energy from steam
2. Absorber. Aqueous lithium bromide solution is absorbing evaporated water (refrigerant) and heat from this absorption process is transferred through tube bank in to cooling water circuit
3. Low temperature heat exchanger. A shell-and-tube horizontal type, will increase the cycle efficiency of heat exchange between diluted solution and concentrated solution
4. Second stage / low temperature generator. Thermal energy from water vapor produces in the first stage generator is used to concentrate the diluted solution
5. Condenser. Water vapor from second state generator is condensed with cooling water
6. High temperature heat exchanger. A shell-and-tube horizontal type, will increase the cycle efficiency of heat exchange between diluted solution and concentrated solution
7. First stage/ high temperature generator. Thermal energy from steam is used to generate high temperature water vapor from diluted lithium bromide solution
8. Drain cooler. The steam condensed in 1st stage is cooled below 90 C
9. Purge unit. Discharging system for chilled water
2005
Price
  FI   request
119592517
DAIKIN EWAQ 130DAYN NFD
Ice water installations

DAIKIN EWAQ 130DAYN NFD Product number:M17-6064 Cooling capacity:95 kW Number of fans:4 Refrigerant:R410A Refrigerant Content:19 + 19 kg Voltage:400 Volt Power consumption:46,6 kW Dimensions:2350 x 2000 x 2650  ...
used machine

DAIKIN EWAQ 130DAYN NFD

Product number:M17-6064
Cooling capacity:95 kW
Number of fans:4
Refrigerant:R410A
Refrigerant Content:19 + 19 kg
Voltage:400 Volt
Power consumption:46,6 kW
Dimensions:2350 x 2000 x 2650 mm
Weight:1500 kg
Year:2012
Number in stock:1 piece(s)
Price:Quotation request


Complete ice water (+1 ° C) system consisting of a DAIKIN water chiller with two refrigerant circuits (4 x scroll compressor), two stainless steel tanks (5000 l per tank) fitted with circulation pumps for the ice water. There are glycol spirals in the stainless steel tanks. The glycol circuit consists of a stainless steel glycol tank (1300 l), expansion tank and a circulation pump.

Please visit also our website: used-refrigeration
2012
Price
  NL   request
119586434
AIRWELL VLS
Chillers

Cooling capacity: 235 kW Year of manufacture: 2007 Refrigerant circuit: 2 pieces Freon: R410A Compressors: 4 pcs. Copeland (scroll) Number of fans: 4 pcs. Complete hydraulic module (water pump, buffer tank and a ex ...
used machine

Cooling capacity: 235 kW
Year of manufacture: 2007
Refrigerant circuit: 2 pieces
Freon: R410A
Compressors: 4 pcs. Copeland (scroll)
Number of fans: 4 pcs.
Complete hydraulic module (water pump, buffer tank and a expansion vessel)
Dimensions: 5,3 ? 1,4 ? 2,4 m
Weight: 2165kg

This chiller is in a verygood condition.
2007
Price
  PL   request
119585634
GEOCLIMA VHA
Chillers

Cooling capacity: 170 kW Year of manufacture: 2005 Refrigerant circuit: 2 pieces Freon: R407c Compressors: 4 pcs. Copeland (scroll) Number of fans: 6 pcs. Hydraulic module (water pumps and an expansion vessel) Dim ...
used machine

Cooling capacity: 170 kW
Year of manufacture: 2005
Refrigerant circuit: 2 pieces
Freon: R407c
Compressors: 4 pcs. Copeland (scroll)
Number of fans: 6 pcs.
Hydraulic module (water pumps and an expansion vessel)
Dimensions: 3,5 x 2 x 2,3 m
Weight: 3000 kg

This chiller is in a verygood condition.
2005
Price
  PL   request
118580474
MTA ITALIEN TAE evo 20
Water coolers

gebr. Water coolers/chillers make MTA Model TAE evo 20.-No.: 2200141592 year of construction 2009 Rated power 4,7 kW Current consumption 8.6 A Refrigerant R407C Filling quantity: 1.94 kg Operating pressure w ...
used machine

gebr. Water coolers/chillers make MTA
Model TAE evo 20.-No.: 2200141592 year of construction 2009

Rated power 4,7 kW
Current consumption 8.6 A
Refrigerant R407C
Filling quantity: 1.94 kg
Operating pressure water circuit 6 bar
maximum temperature of 35 ° c.
maximum operating pressure of cooler 28 bar
maximum temperature 65 ° C
Fuel tank capacity 60 l
Water flow rate 0.5-4.8 m ³/h
External dimensions:
Width 560 mm
1260 mm deep
Height 810 mm
Weight approx. 137 kg
with electronic control

2009
Price
  DE   request
118374912
GEA GRASSO GMBH Grasso FX VP 2800 / S - R717
Liquid Chiller GEA Grasso FX 2800 / S - 2.800 kW

Liquid Chiller GEA Grasso FX 2800 / s - 2 x 2800 kW Two GEA Grasso FX PV 2800 S - screw type liquid chiller compressors were installed in 2003 (made in 2002) and they still installed and in very good working condition ...
used machine

Liquid Chiller GEA Grasso FX 2800 / s - 2 x 2800 kW

Two GEA Grasso FX PV 2800 S - screw type liquid chiller compressors were installed in 2003 (made in 2002) and they still installed and in very good working condition. The compressors have flooded evaporation, plate type evaporator and evaporative condenser cooler. type They have been operated only 15 000 hours, their cooling capacity is 2800 kW/unit. Refrigerant is R717 (NH3)

The delivery includes complete system with compressor package, evaporators, pumps, intermediate NH3 tanks, evaporative condenser and control cabinets.

The screw compressor sucks NH3 gas out of the liquid separator and compresses it up to condensation pressure. The refrigerant turns to liquid as it is cooled in the condenser. The liquid NH3 is injected back to the liquid separator via a high pressure float valve as expansion device. Inside the liquid separator liquid form and gas for are separated. The liquid NH3 passes in a gravity driven circuit to the evaporator. During the evaporation into gaseous form (with heat energy delivered by the secondary refrigerant) it evaporates and a mixture of gas and liquid is coming back to the liquid separator. Oil is injected into the working chamber of the screw compressor during operation and it is then separated again from the refrigerant in the discharge side oil separator. The oil which has heated up in the compressor is cooled in an oil cooler to reach the entry temperature and passes a fine filter.

This liquid chillers is equipped with a freely programmable standard logic controller PLC SIMATIC C7-633. All operating and fault signals as well as the process variables can be read from a LCD display with background lighting. The display is operated via a robust foil keyboard having 6 functions and 24 system keys.

Technical data:

Manufacturer: GEA Grasso GmbH
Manufacturing year: 2002
Number of units: 2 complete units
Type: Grasso FX VP 2008 / S
Cooling capacity: 2800 kW / unit
Electric motor: Schorch 560 kW / 2988 rpm / 50 Hz
Refrigerant: R 717 (Ammonia)
Evaporator: Alfa-Laval M20-MWFRC
Evaporative condenser: BAC XX
Compressor package EW: 13250 kg
2002
Price
  FI   request
118374688
BAC FRANCE BAC VXC 1240 - R717

Evaporative Condenser BAC VXC 1240 - 4984 kW This evaporative refrigerant (NH3) condenser was delivered by BAC France in 2009 but it was never installed. This unit has four separate forced draught, curved plate and be ...
used machine

Evaporative Condenser BAC VXC 1240 - 4984 kW

This evaporative refrigerant (NH3) condenser was delivered by BAC France in 2009 but it was never installed. This unit has four separate forced draught, curved plate and belt driven centrifugal fans which are very quiet and energy saving. Equipment is suitable for various chiller applications with cooling capacity up to 4984 kW. The equipment is in excellent, new like condition.


General data:
Condensing capacity 4984 kW
Refrigerant NH3 - R717
Dew point 35.0 ° C
Wet -bulb temperature 21.0 ° C - working wet


Technical characteristics
Overall length 12233 mm
Overall width 3000 mm
Total height 4310 mm
Shipping / operating weight / 20380/ 25240 kg
Weight of the heaviest section 7010 kg
Number of fan motors and power 4 x 5.5 k / 1500 rpm
Circulation pumps 2 x 4.0 kW
The maximum evaporation 1,797 l / s@ 4984.0 kW
Noise level at full load 61 dB(A) at 15 meters
2009
Price
  FI   request
118282476
THERMOFIN TDH.3-080-26-A-N-D5-CC-2
Dry cooler

THERMOFIN TDH.3-080-26-A-N-D5-CC-2 Product number:M17-3161 Cooling capacity:676 kW Number of fans:12 Refrigerant:water/glycol Refrigerant Content:421,2 kg Voltage:400 Volt Power consumption:22 kW Dimensions:10. ...
used machine

THERMOFIN TDH.3-080-26-A-N-D5-CC-2

Product number:M17-3161
Cooling capacity:676 kW
Number of fans:12
Refrigerant:water/glycol
Refrigerant Content:421,2 kg
Voltage:400 Volt
Power consumption:22 kW
Dimensions:10.030 x 2290 x 1495 mm
Weight:2198 kg
Year:2012 / Unused
Number in stock:1 piece(s)
Price:Quotation request


Very nice unused Thermofin dry-cooler with 12 fans. Mentioned capacity at +40/+35 °C (in/out) and an air temperature of 25 °C and 34% glycol.

Please visit also our website: used-refrigeration
2012
Price
  NL   request
118282454
THERMOFIN TDH.3-091-25-A-M-D5-BC-2
Dry cooler

THERMOFIN TDH. 3-091-25-A-M-D5-BC-2 Product number: M17-3160 Cooling capacity: 628 kW Number of fans: 10 Refrigerant: water/glycol Refrigerant content: 199.5 kg Rated voltage: 400 Volt Power consumption: 25 kW  ...
used machine

THERMOFIN TDH. 3-091-25-A-M-D5-BC-2

Product number: M17-3160
Cooling capacity: 628 kW
Number of fans: 10
Refrigerant: water/glycol
Refrigerant content: 199.5 kg
Rated voltage: 400 Volt
Power consumption: 25 kW
Engine power: 10 x 2.48 kW
Size: 8430 x 2290 x 1510 mm
Empty weight: 1714 kg
Year of construction: Unused/2012
Units in stock: 1 piece (s)
Price: request a quote

Very nice unused Thermofin dry-cooler with 10 fans. Listed capacity at + 40/+ 35 ° c (in/out) and an air temperature of 25 ° c and 34% glycol.

Visit our website: used-refrigeration
2012
Price
  NL   request
118116518
STULZ CFO
Chillers

Chiller with Free Cooling capability Cooling capacity: 250 kW Year of manufacture: 2009 Power: 250 kW. Refrigerant circuit: 2 pieces Freon: R410A Compressors: 4 pcs. Copeland (scroll) Pumps: 3 pcs Dimensions: 3,8 ...
used machine

Chiller with Free Cooling capability
Cooling capacity: 250 kW
Year of manufacture: 2009
Power: 250 kW.
Refrigerant circuit: 2 pieces
Freon: R410A
Compressors: 4 pcs. Copeland (scroll)
Pumps: 3 pcs
Dimensions: 3,8?1,15?2,25 m
Weight: 1800 kg
Country: Germany
This chiller is in perfect condition
2009
Price
  PL   request
118116511
YORK YLCA
Chillers

Cooling capacity: 156 kW Year of manufacture: 2011 Refrigerant circuit: 2 pieces Freon: R410A Compressors: 4 pcs. Copeland (scroll) Number of fans: 4 pcs. Complete hydraulic module (water pumps, buffer tank and a e ...
used machine
Quantity: 2

Cooling capacity: 156 kW
Year of manufacture: 2011
Refrigerant circuit: 2 pieces
Freon: R410A
Compressors: 4 pcs. Copeland (scroll)
Number of fans: 4 pcs.
Complete hydraulic module (water pumps, buffer tank and a expansion vessel)
Dimensions: 4,2 x 1,3 x 2,3 m
Weight: 1650 kg

These chillers are in excellent condition and has few operating hours
2011
Price
  PL   request
116883637
NORDCAP GETO 120 Roll-In Evo
Freezing Chamber

Used Lagerfroster NORDCAP, type: GETO 120 roll in Evo - 23 trays for plates 60 x 80 cm -El. Connection: 230 V, 50 Hz, 1,0 kW -Maximum temperature: 23 ° C -Refrigerant: R404A A tour is like possible by arrangement. ...
used machine

Used Lagerfroster NORDCAP, type: GETO 120 roll in Evo - 23 trays for plates 60 x 80 cm
-El. Connection: 230 V, 50 Hz, 1,0 kW
-Maximum temperature: 23 ° C
-Refrigerant: R404A

A tour is like possible by arrangement.
2014
2,999 €
  DE   request
116574893
CARRIER 30RA090 30RA090
Chiller

Chiller, Carrier 30RA090, 90KW7 25ton cooling capacity incl. pump, year 2009,


Chiller, Carrier 30RA090, 90KW7 25ton cooling capacity incl. pump, year 2009,

Price
  DE   request
116573748
MCQUAY MNG 179.2 A XN
Chiller

Screw chiller, aircooled , McQuay MNG179.2 year 2007, 640KW/200ton cooling capacity, R134a, incl. two cold water pumps. 4985Kg.
used machine

Screw chiller, aircooled , McQuay MNG179.2 year 2007, 640KW/200ton cooling capacity,
R134a, incl. two cold water pumps. 4985Kg.
2007
Price
  DE   request
116566980
KTK TWA 562 S/Z/P
Chiller

Chiller KTK TWA 562 S / Z / P about 500KW, incl. two chilled water pumps, R407c,. Two refrigeration circuit with each 6pcs. scroll compressors.


Chiller KTK TWA 562 S / Z / P about 500KW, incl. two chilled water pumps, R407c,.
Two refrigeration circuit with each 6pcs. scroll compressors.

Price
  DE   request
116566868
KTK TWA 562 S/Z/P
Chiller

Chiller KTK TWA 562 S / Z / P about 500KW, incl. two cold water pumps, R407c,. Double refrigeration circuit with each 6Stück scroll compressors. Machine can be very well Leistungsgeregelt and very to the conditions of  ...


Chiller KTK TWA 562 S / Z / P about 500KW, incl. two cold water pumps, R407c,.
Double refrigeration circuit with each 6Stück scroll compressors. Machine can be very well Leistungsgeregelt and very to the conditions of the electric supply lines, be customized water volumes and load.

Price
  DE   request
116249610
LINDE Condensing Cooling Unit Bitzer 4J-13.2Y
Compound systems

Cooling set unit Linde/BITZER - 2 x compressor of BITZER 4J-13.2Y - capacity: 70 kw at -10 - Condenser Guntner - year of production: 2006 In very good condition
used machine

Cooling set unit Linde/BITZER

- 2 x compressor of BITZER 4J-13.2Y
- capacity: 70 kw at -10
- Condenser Guntner
- year of production: 2006

In very good condition

Price
  PL   request
page 1 >
You didn't find your wanted machine? to all dealers(no registration necessary)
sell machinery
Sell your machinery
to the price starting with only € 0.09 monthly per machine!
machinery sold
Get the latest machine offers by email: order newsletter
