Composed of: - heat pump ( OMNIA UE 3.2.3)  - hybrid boiler (OMNIA S HYBRID 28C 3.2) - Coaxial hoses + bends + hybrid hydraulic kit Loading dimensions : 1200x900x1300 mm Auction-ID: A7-51441-1024

Composed of: - Model Compress 7000i AW 13s - B - Model GC7000i W 24 24 kW in heating - Flexible outdoor unit connection kit to piping - HW50 - Hydraulic compensator with threaded connections 1¬Ω'Äù - Vertical adapter 80/125 to 60/100 mm - Split adapter C53x 80/125 at 80-80 mm - VW1 - 3-way diverter valve (mod LK525) for external DHW tank load - Puffer PS 100 model with 103 liter capacity - 2FTV/ST/BWPS300 kit with 2 FT226-2 vertical manifolds - FKA 26 mounting kit - Twin-Tube 15-10 Cu Load measurements: Pallet 1: 950x1200x2000 mm Pallet 2: 1200x800x2350mm Pallet 3: 1200x1000x1500 mm Pallet 3: 600x600x1800 mm Auction-ID: A7-51441-5

POS POSmill H 800 U CNC 5-Axis Machining Center Technical Data: Distance Spindle/Table: 120–720 mm Swivel Range A-Axis: ±120° Rotation C-Axis: 360° continuous Rapid Traverse Max.: 60 m/min Speed A-Axis Max.: 50 rpm Tool Holder: HSK A63 Tool Changer: 64 slots (standard) Tool Length Max.: 300 mm Tool Diameter Max.: 125 mm Tool Change Time Min.: 8.5 s Connected Load: 90 kVA Voltage: 400 V / 50 Hz Pneumatic Connection: 6 bar Machine Weight: approx. 20,000 kg (nameplate)

Intos Zebrak S 32 - Universal lathe - ACU-RITE DRO 200S position indicator - 2x 3-jaw chuck Ø 160 mm - 1x 4-jaw chuck Ø 140 mm - Collet chuck - Fixed Lynette - Quick-change tool holder - Coolant device - Feed protection - Swarf back wall - Workplace lighting - Various accessories such as tool holders, collets, tools and spare gears Technical data - Center width / turning length: 1000 mm - Turning Ø over bed: 320 mm - Turning Ø over support / cross slide: 190 mm - Spindle bore: 36 mm - Spindle mount: M40 (1:2) - Tailstock quill: MK3 - Bed width: 250 mm - Spindle speeds: 20 - 3200 rpm (54 steps) - Longitudinal feeds: 0.03 – 3.52 mm/rev (36 steps) - Transverse feeds: 0.015 – 1.76 mm/rev (36 steps) - Metric threads: 0.375 - 44 mm (36 steps) - Inch Thread (Whitworth): 3/128" - 23/4" (36 Steps) - Module thread: 0.375 – 11 (36 steps) - Diametrically Pit ...

Weiler DA 180 / 1000 - Universal lathes - ACU-RITE position indicator - 3-jaw chuck Ø 200 mm - Quick-change tool holder - Coolant device - Workplace lighting - Feed protection - Swarf back wall - various tool holders and tools - Instruction manual - Year of construction 2000 Technical data Main spindle: - Spindle head according to DIN 55027: Gr. 6 - Spindle bore: 52 mm - Ø in the front bearing: 83 mm - Inner cone: metr. 57 - Number of speeds: 12 - Speed range: 33–1500 rpm Tailstock: - Tailstock quill diameter: 65 mm - Morse taper: Mk 4 - Pitch of the lead screw: 6 mm - Lathe bit cross-section: 20 × 20 mm Areas of work: - Circumferential Ø over bed: 380 mm - Rotary Ø over face slide: 185 mm - Displacement of the face slide: 330 mm - Displacement of the upper slide: 120 mm - Tailstock quill displacement: 120 mm Feeds: - Longitudinal feeds: 0. ...

Description Item # 9418 - UNIVERSAL REFINER CONCHE Manufactured by LOW & DUFF MACINTYRE Model 5CR-MK7 Original Year 1989 3000Kgs Refiner/Conche Overhauled in 2026 Has been stripped down, had new bearings throughout with all new packing and seals New bearings and seals in both motors and gearbox It has been repainted and cleaned out and has new heating elements and clean cocoa butter added and ran for 4 hours with no issues

Equipped with: Wire thickness: AWG 24, suitable for connection between mains power supply and electronic SSC/SWS-compatible SCHELL luminaires, unused in original packaging. Auction-ID: A1-47451-1756

Manufacturer: NIDO Type: UNIVERSAL Equipment: Electro-hydraulic snow plough blade Working width: approx. 2,800 mm Features: Heavy-duty curved steel snow blade Electro-hydraulic operation Hydraulic blade angling via two hydraulic cylinders Hydraulic hoses and connections Mounting frame Replaceable lower cutting / wear edge Side marker poles Application: Professional snow clearing and winter road maintenance Designed for mounting on compatible municipal vehicles / trucks Condition: Used, with visible signs of use, paint wear and surface corrosion Condition and configuration as shown in the photographs Auction-ID: A1-50932-82

This 3-axis KUNZMANN WF 410 MC universal machining centre was manufactured in 2023. It features an electronically controlled infinitely variable main drive with a spindle speed of up to 5,000 rpm and a robust spindle power of 13.0 kW. The machine is equipped with hardened and ground flat guideways and automatic mechanical tool clamping. If you are looking to get high-quality machining capabilities, consider the KUNZMANN WF 410 MC machine we have for sale. Contact us for further details.

Lathe STANKO 1M65/5000

Lathe STANKO 1M63/2800

ZMM Lathe C11MT/1500

Cegonheira conventional centre lathe with chuck, toolpost, tailstock and screwcutting gearbox. Used industrial lathe; centre distance, spindle bore and operation to be confirmed. Auction-ID: A1-51153-7

Deckel FP2LB Universal Milling Machine Type: Universal milling machine Manufacturer: Deckel Model: FP2LB Year of manufacture: 1977 X-axis travel: 800 mm Y-axis travel: 300 mm Z-axis travel: 400 mm Approx. dimensions (L x W x H): 1750 x 1700 x 1750 mm Includes various accessories and documentation Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51153-21

Novar KBA-1400 Machining Center Manufacturer: Novar Model: KBA-1400 Equipment type: Machining Center Serial number: 369 Control: NCT Heavy-duty machining center designed for precision milling, drilling, boring and general machining of medium-to-large metal workpieces. Technical specifications: X-axis travel: 1,200 mm Y-axis travel: 700 mm Z-axis travel: 800 mm Spindle / tool interface: SK40 Equipment / features: NCT control unit CNC-controlled axes SK40 spindle Heavy-duty machine structure Worktable Operator control panel Approx. dimensions (L × W × H): 3,500 × 2,800 × 2,800 mm Approx. weight: 6,000 kg Condition: Used. Main machine structure, worktable and NCT control appear present. Spindle, axis movements, feeds, lubrication/coolant systems, control functions and machining accuracy should be verified before operation. Auction-ID: A7-51510-8

BIO-RAD Universal Hood II ChemiDOC XRS+ Molecular Imager The ChemiDoc XRS+ Gel Imaging System is a rapid detection system for chemiluminescence, fluorescence and colorimetry imaging Auction-ID: A1-51527-56

Deckel FP3LB Universal Milling Machine Type: Universal milling machine Manufacturer: Deckel Model: FP3LB Serial number: 0554 X-axis travel: 500 mm Y-axis travel: 300 mm Z-axis travel: 400 mm T-slot table size: 300 x 1000 mm Taper: SK40 Speed range: up to 2000 rpm Engine power: 4 kW Machine weight: approx. 1100 kg Dimensions (L x W x H): 2000 x 1200 x 1800 mm Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51153-65

SARTORIUS STEDIM Biotech - BIOSTAT B + FRIGOMIX 1000 + DZ VHC Designed to meet your specific needs, Biostat ® B covers a wide range of applications, from a flexible base unit for preclinical research to a fully qualified system that meets the requirements of a validated GMP environment Please inspect. The sale includes only what appears in the photos. The buyer, by purchasing the equipment, agrees that the device must be used according to the standards and legislation in force in his country. The seller will not be held responsible in any way for misuse that does not comply with the safety conditions and the standards and legislation in force. Lots may be added to the list later. A prior exhibition is set up, please inspect. The equipment is made available on pallet or pallet box or cardboard with all the appropriate protections, the price of the packing is integrated into the sale pr ...

Deckel FP33 Universal Milling Machine Type: Universal milling machine Manufacturer: Deckel Model: FP33 T-slot table size: 430 x 1000 mm Approx. dimensions (L x W x H): 2150 x 1800 x 2200 mm 5 horizontal T-slots 2 vertical T-slots Tension clamp: 90 x 90 mm x 4 T-slot width: 20 mm Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51153-25

Ref. -No.: 10530 Manufacturer: DöRRIES - SCHARMANN Year of construction: 2010 Type of control: CNC-Steuerung Control: Siemens SINUMERIK 840 D Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 2000 mm Z-Travel: 2000 mm A-Axis: 0 - 90 x 0,001 ° B-Axis: 360 x 0,001 ° Number of T-slots: 1 + 8 Max. Workpiece Weight: 5000 kg T - groove width: 22 mm T - slot spacing: 100 mm T-Slots: DIN 650 mm Tool Taper: HSK - A 100 Tool Piece Magazine With: 207 + 10 Pcs./pcs. Max. Torque: 1250 Nm Feed Speeds X/Y/Z Axis: 1 - 30000 mm / min Rapid Travel X/Y/Z: 30,00 mm / min Drive Capacity - Spindle Motor: 45 kW Total Power Requirement: 100 kW Dimensions Of The Machine Ca.: 13 x 8 x 4,5 m Size Of Pallet: 2 x 1000 x 1000 mm Spindle speed gear stage 1: 1 - 1096 1 / min Spindle speed gear stage 2: 1096 - 6000 1 / min Further information: - Measuring probe - Chip conveyor - ...

Ref. -No.: 10553 Manufacturer: HANDTMANN / BAVIUS Year of construction: 2014 Type of control: CNC-Steuerung Control: Heidenhain TNC 640 Storage location: Halberstadt Country of origin: Germany Machine-No.: 200XXXXX X-Travel: 1270 mm Y-Travel: 1100 mm Z-Travel: 900 mm Table Height: Ø 1200 mm Table Load: 2000 kg Max. Tool Weight: 20 kg Max. Tool Length: 90 x 200 / 24 x 400 mm Max. Tool Diameter: Ø 130 mm Tool Taper: HSK 100 Numbers Of Tools In Magazin: 40 Tool Piece Magazine With: 140 Pcs./pcs. Spindle Turning Speed - Stepless: 14.000 RPM Max. Torque: 15000 Nm Rapid Traverse X-Axis: max. 60 m / min Rapid Travel Y-Axis: max. 60 m / min Rapid Traverse Z-Axis: max. 60 m / min Machine length: 7500 mm Machine width: 5500 mm Machine Height: 3500 mm Weight Of The Machine Ca.: 26 t Rapid traverse C-axis: max. 25 RPM Rapid traverse A-axis: max. 20 RPM A-axis (swivel axis): - 30 / + 120 ° C-axis  ...

Ref. -No.: 10548 Manufacturer: MONFORTS Year of construction: 1998 Type of control: CNC-Steuerung Control: Monforts Storage location: Halberstadt Country of origin: Germany Machine-No.: 303XXXX Chuck diameter: 250 mm Centre Distance: 1080 mm Spindle Diameter In Front Bearing: 100 mm Spindle head according to DIN 55027 (size): Gr. 8 Circumferential diameter over radial slide: 290 mm Max swing diameter: 500 mm travel of the cross slide: 265 mm Tailstock outside diameter of the quill: 80 mm Tailstock maximum quill stroke: 160 mm Tailstock inner cone: MK 5 Type Material flow max.: 70 mm Turning Speed Range: 2 - 2800 rpm Further information: The machine can be viewed under power by arrangement.

Ref. -No.: 10544 Manufacturer: DECKEL Year of construction: 1990 Type of control: N/A Control: N/A Storage location: Halberstadt Country of origin: Germany Power Capacity: 1,6 / 2,0 kW Tool Taper: 20 mm Ø Space requirements: 1600 x 1350 LxWxH (mm) Feed rate: 0-350 mm / min Vertical portal passage, clamping table - lower beam cross member: 300 mm Distance table - spindle nose with vertical milling spindle: 50 mm Distance table - spindle nose with horizontal milling spindle: 450 mm Machine Height: 1950 mm Weight: 2,1 t Pre-milling spindle: 80...1000 min-1 Collets: 20 O taper bushing: Morse 1 Touch lift: 12 O Speed of the milling motor: 1400 RPM Further information: - Optical testing device - Pre-milling spindle - Model milling device - Rotary table - Inclined spindle - Mirror image milling device - Reduction and enlargement device - Roller engraving devices - Machine vice hydraulic clamps ...

Ref. -No.: 10159 Manufacturer: KELLENBERGER Year of construction: 1974 Type of control: N/A Control: N/A Storage location: Halberstadt Country of origin: Schweiz Grinding Length: 1000 mm Grinding Diameter: 250 mm

Ref. -No.: 10716 Manufacturer: DMG MORI Year of construction: 2015 Type of control: CNC Control: Siemens 840D Storage location: Halberstadt Country of origin: Germany Machine-No.: 004xxxxxxx Tool holder type: VDI 30 X stroke: 260 mm Z - stroke: 550 mm Bar passage: 65 mm Turning Diameter: 500 mm Turning Length: 520 mm Spindle Speeds: 5.000 RPM Spindle Bore: 76 mm Tool changer: 12 Pcs Operating hours: 38.500 Hours Weight Of The Machine Ca.: 4.8 t Further information: Including chip conveyor, transport securing equipment, documentation and accessories. The machine has been cleaned and can be inspected under power.

Anetic Aid QA4 – Universal Hydraulic Mobile Surgery Table Manufacturer: Anetic Aid Model: QA4 The perfect combination of transport trolley and operating table All manual functions: Motorized functions - variable height (up/down), backsplash lift, crossing platform, lateral tilt, Trendelenburg Optimized surgery access Extremely light and easy to maneuver Removable side safety barriers 75% access for shine amp Supports a 160kg patient Auction-ID: A1-51618-524

Key data: 1600 mm, 880 mm

CNC cylindrical grinding machine, (carousel) for internal, external and surface grinding. A lot of accessories, such as grinding wheels of different types and sizes. Retrofitted 2007 . Magnetic clamping plate dia 1500mm, Circumferential diameter 1800mm, Largest grinding diameter 1600mm Maximum grinding height 880mm Max. workpiece weight 5to Swivel angle of the grinding spindle: 90° left, 60° right

Key data: 600 mm, 855 mm, 750 mm

Manufacturer: GROB Model: G350 Year: 2010 Condition: Used Stock number: 9652 Control System: FANUC Series 31i-MODEL A5 Table diameter: 720 mm Maximum table load (uniform): 400 kg X-axis travel: 600 mm Y-axis travel: 855 mm Z-axis travel: 750 mm Machine weight: 15300 kg

POREBA TR 135-B1 x 5000 Universal heavy lathe Turning diameter over bed slide: 1,350 mm Turning diameter over top slide: 1,000 mm Turning diameter in gap 1650 mm Turning length: 5,000 mm Spindle bore: 120 mm Tailstock quill diameter: 190 mm Spindle mount: MK 6 Workpiece weight (max.): 11,000 kg Rotational speed (max.): 630 rpm Rotational speed (min.): 5 rpm Dimensions 7,500 x 2,130 mm Total Machine Weight: ~13,200 kg Steadies

Description: - Excellent condition from training workshop - Digital display - Stepless speed control - Stepless feed drives - Hydraulic tool clamping - Mechanical handwheels - Electronic handwheel - Drill quill - Horizontal milling spindle - Coolant device x-travel 620 mm y-travel 420 mm z-travel 400 mm Speed 50- 4000 rpm Total power requirement 17.5 kW Machine weight approx. 1.9 t Space requirements approx. 2.0 x 2.7 x 2 m Auction-ID: A7-51438-546

Universal bed milling machine MAHO MH 1600 S Spindle SK-50, Speed range up to 4000 rpm Max. workpiece weight 3000kg 35,000 switch-on hours, Dimensions 5 x 3.70 x 3 m, Weight 16 tons. Automatic swivel milling head, Fixed table 1800 x 980 mm, 36-fold universal tool changer, Internal coolant supply with paper belt filter, Chip conveyor, manual control bar. Auction-ID: A7-51643-1

Deckel FP2LB Universal Milling Machine Type: Universal milling machine Manufacturer: Deckel Model: FP2LB Year of manufacture: 1977 X-axis travel: 800 mm Y-axis travel: 300 mm Z-axis travel: 400 mm Approx. dimensions (L x W x H): 1750 x 1700 x 1750 mm Includes various accessories and documentation Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51509-21

Micro shredder / universal shredder IKA MF 10 basic + MF 10.1; ; With MF 10.1 blade grinding head; With 1 sieve; ; Equipment in working order; Visible wear of joints and blades.; Sensitivity of the variable speed drive functional but altered; ; Type of operation: inline; Working system: cutting/impact; Motor power consumption: 1000 W; Motor power output: 500 W; Speed Range: 3000 - 6500 rpm; Run time WALK: 120 min; Operating time OFF: 30 min; Dimensions (W x H x D): 320 x 380 x 300 mm; Weight: 14 kg; Permissible medium temperature range: 5 - 40 °C; Permissible relative humidity: 80%; Protection according to DIN EN 60529: IP 22; Voltage: 230V; Frequency: 50/60 Hz; ; Average general condition; ; Internal reference: FA-2628; Auction-ID: A1-50994-1011

Deckel FP3LB Universal Milling Machine Type: Universal milling machine Manufacturer: Deckel Model: FP3LB Serial number: 0554 X-axis travel: 500 mm Y-axis travel: 300 mm Z-axis travel: 400 mm T-slot table size: 300 x 1000 mm Taper: SK40 Speed range: up to 2000 rpm Engine power: 4 kW Machine weight: approx. 1100 kg Dimensions (L x W x H): 2000 x 1200 x 1800 mm Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51509-65

Deckel FP33 Universal Milling Machine Type: Universal milling machine Manufacturer: Deckel Model: FP33 T-slot table size: 430 x 1000 mm Approx. dimensions (L x W x H): 2150 x 1800 x 2200 mm 5 horizontal T-slots 2 vertical T-slots Tension clamp: 90 x 90 mm x 4 T-slot width: 20 mm Functionality not tested This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A1-51509-25

NC Swivel Milling Head (B-Axis) -120/+30° 60-position tool magazine with taper cleaning NC rotary axis (A-axis) with collet chuck Spanntop 65; Tailstock, hydraulically lowerable, NC bar loader 1100 mm Workpiece pick-up device with discharge conveyor Production package with coolant tank 600 litres, INTERLIT SKA 200-760 - IKZ 40 bar through spindle centre- Chip conveyor, Rotating inspection window Tool measurement BLUM Oil mist extraction Operating mode 4 Auction-ID: A7-51643-10

Cegonheira conventional centre lathe with chuck, toolpost, tailstock and screwcutting gearbox. Used industrial lathe; centre distance, spindle bore and operation to be confirmed. Auction-ID: A1-51509-7

x-travel:2000 mm y-travel:800 mm z-travel:800 mm table-size:2.000 x 700 mm workpiece weight:3500 kg drive capacity - spindle motor:17 kW spindle cone:50 ISO spindle turning speed range:3000 U/min dimensions of the machine ca.:5265 x 3250 x 2730 m weight of the machine ca.:9 t CNC controller:HEIDENHAIN TNC-426 :manuell used universal bed type milling machine with chip conveyor, automatic 2 position (vertical/horizontal) head 3000Rpm The retrofitting jobs done in this machine, are the same than those done to all of our machines. - Completely repair of the head, replacing bearings, shafts and engaging gears. - Completely replacement of all the bearings of the machine. - Replacing the joining screws of the bodies. - Completely repair of spindles. - Adjustment and repair of axis. - Grinding and adjusting all guides, because of deterioration. - Grinding and adjusting of the guide ways of the ...

x-travel:600 mm y-travel:580 mm z-travel:530 mm distance spindle center to column:630 mm distance spindle center to table:100-600 mm milling feed range:1-10.000 mm/min max. table load:200/100 kg max. tool weight:8 kg positioning accuracy:+/- 0,01 mm :8000/15000 1/min spindle drive:7,5/11,5 /5,5 kW repeating accuracy:+/- 0,008 mm weight of the machine ca.:7,4 / 7,65 t Brand-new CNC vertical machining center with CNC control FANUC or HEIDENHAIN Warranty: 12 months More information can be found in the Appendix.

x-travel:1000 mm y-travel:1150 mm z-travel:700 mm table-size:900 mm table load:1500 kg spindle speeds:10.000 1/min spindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nm spindle taper:A100 HSK T-slots:18mm/7/100 mm milling feed range:20.000 mm/min rapid traverse feeds:X/Y/Z: 24 m/min diameter of tools max.:150 mm workpiece length:300 mm weight of tools max.:20 kg weight of the machine ca.:15 t dimensions of the machine ca.:s. Katalog m CNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fach Scales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20

x-travel:630 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:6,5 t Number of axles:5 St. spindle turning speed range:18.000 U/min numbers of tools in magazin:24 tool taper:SK 40 Round Table B-Axis

grinding diameter:280/320 mm grinding length:750 mm centre height:170 mm weight of the machine ca.:22,5 t dimensions of the machine ca.:4,7 x 3,65 x 3,0 m Junker Jumat 6S 18-20S-18 has 2 internal and 1 external spindle.

x-travel:600 mm y-travel:770 mm z-travel:675 mm A-Axis travel:-180 ... +45 ° b-axis:360,000 ° spindle drive:40 / 52 (100% / 40% ED) kW spindle turning speed range:10000 U/min Tool bore:HSK-A63 numbers of tools in magazin:40 total power requirement:47 kW weight of the machine ca.:13 t including additional tool magazine ZM 182 1 spindle , 5 axes

x-travel:800 mm y-travel:950 mm z-travel:1020 mm weight of the machine ca.:17 t dimensions of the machine ca.:6 x 3 x 3,2 m Diameter of the table:770 mm max. table load:800 kg tool taper:HSK-A63 max. tool length:465 mm no. of tools in magazin:60 spindle turning speed range:12.000 U/min feed power:8 kN kp power capacity:25/35 kW 5 axis G550-1024 HSK A-63 Grob (Bezeichnung G550-1024) 1 spindle

x-travel:780 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:10 t Number of axles:5 St. spindle turning speed range:20-12.000 U/min numbers of tools in magazin:30 tool taper:SK 40 surface area:500 x 630 mm Round Table B-Axis Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2026, Josef Weber. All rights reserved.

x-travel:700 mm y-travel:630 mm z-travel:700 mm weight of the machine ca.:15 t dimensions of the machine ca.:4,20 x 2,90 x 2,90 m pallet size::500 x 500 mm tool taper:SK 40 Tool taper:HSK-A 63 turning speed range:10.000 U/min

grinding length:1500 mm centre height:325 mm weight of the machine ca.:12 t Karstens EMAG H310 Universal Grinding Machine Year of manufacture: 2004 Center distance: 1500 mm Center height: 325 mm Reinforced workpiece spindle, load capacity up to 250 kg Driven C-axis for polygon, thread, and eccentric grinding. 3 individually mounted grinding spindles. Siemens 840D control system

x-travel:3600 mm y-travel:1250 mm z-travel:1600 mm table load capacity:8000 kp table clamping surface::4100 x 1050 feed range:10 - 5000 mm/min rapid traverse feeds:10000 mm/min spindle motor:29 kW spindle taper::ISO 50 spindle turning speed range:5 - 4000 U/min total power requirement:70 kW weight of the machine ca.:28 t dimensions of the machine ca.:8,5 x 5,4 x 3,2 m Machine with Heidenhain TNC 430 Steuerung - tool changer 30-fold - milling head indexable 2,5° - 4. axis turn table

x-travel:800/945 mm y-travel:800 mm z-travel:600 mm spindle motor:27 kW spindle turning speed range:10 - 8000 U/min spindle taper ISO:40 c-axis:360.000 x 0,001 table load capacity:600 kg table clamping surface::800 630 mm total power requirement:55 kW weight of the machine ca.:16 t Machine with Heidenhain iTNC 530 CNC control for 5 axis - pendulum operation with turn- swivil table left and fixed table right - tool changer for 30 tools - coolant device, chip conveyor - complete splash housing

x-travel:1.250 mm y-travel:880 mm z-travel:800 mm spindle turning speed range:1 - 10.000 U/min high speed spindle taper ISO:50 table-size:1.250 x 1.000 mm max. workpiece weight: 2.000 kg feed speeds infinitely variable:1 - 30.000 mm/min rapid traverse speed:40 m/min weight of the machine ca.:16 t dimensions of the machine ca.:7,2 x 4,4 x 2,9 m
