unimat used for sale

ORDER NO. 6575 TECHNICAL DATA - max width of the workpiece 230mm - max height of the workpiece 170mm - 7 spindles: 1) horizontal bottom 230mm, 11kW 2) vertical right 170mm 3) vertical left 170mm (2 and 3 spindle), 11kW 4) horizontal right 170mm, 5.5kW 5) horizontal upper 230mm, 11kW 6) horizontal bottom 230mm, 7.5kW 7) universal 230mm, adjustable at 360°, 7.5kW - all spindles adjustable up/down, right/left - spindle 3 and 5 electrically adjustable - ATS - spindle diameter 40mm - electric brakes - from above 4 pulling introductory shafts, toothed including 1 double - from above the introductory roller pulling rubber double - from above the shaft leading out, pulling, rubber, double - from below 2 metal rollers, pulling, smooth - pulling roller, rubber, double - feed on cardan rollers - pneumatically pressed shafts - smooth adjustment of the feed spe ...

WEINIG planer and moulder model Unimat 22 A Equipment: - Package - Lifting table (no pit required) - automatic stacking strip removal - Rubberized inclined conveyor - Rubberized separation - Longitudinal conveyor for planing.- Moulder - Unimat 22 A with soundproof cabin - 2nd operating unit - Manual acceptance Weinig Planer.- Automatic throat machine, technical data: Spindle arrangement: U - R - L - O - U Saw Working width: 220 mm Working height: 120 mm Motor power feed: 4 kW Motor power of the working spindles: 4 kW Speed of the working spindles: 6000 rpm. Diameter of the working spindles 40 mm Feed infinitely variable 6 - 32 m/min Diameter of feed rollers (hardened) 140 mm Space requirement line: 12.7 x 5.0 m Spelling mistakes and errors excepted

Four-way planer Weinig Unimat U 23 (Ref. No. 231-2615) with 7 waves Planer width 130 mm Planing height 140 mm Masch. Item no. 023-161 Year of construction 1991 The machine is in good condition, ready for operation. Subject to change, error, prior sale ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system+technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Phone 0041 62 966 18 32 fax 0041 62 966 21 12

WEINIG planer/moulder Unimat 22A with 9 heads Year of construction: 1987 Serial number 222-896. The planer is in good working condition and has been partially overhauled, cleaned and subjected to careful technical controls. • The machine has been thoroughly cleaned and technically checked. • Some wear parts have been replaced. • A test run was carried out to ensure functionality. • The machine is bolted to a wooden structure and is ready for shipment. • The planer and moulder is equipped with all the tools and is sold as such. Further technical data of the machine: Maximum planing width: 220 mm Maximum planing height: 140 mm Diameter of the spindles: 40 mm Spindle speed: 6000 rpm Length of the inlet table: 2 m The machine has a total of 9 spindles with the following configuration: 1. Lower spindle / dressing spindle : 5.5 kW 2. Right spindle /  ...

Crimping jaws, crimping tools for cable end sleeves, wire end sleeves, cable lugs -for: cable end sleeves -Sizes: approx. Up to 28 mm² -in the suitcase -Dimensions: 490/300/H70 mm -Weight: 22.4 kg

Four-sided planer Weinig Unimat 23 EL Working width 230mm Working height 160mm Head Arrangement: Bottom 5.5kw 4kw rights Left 5.5kw 4kw rights Mountain 11kw Bottom 5.5kw Mount 7.5kw Bottom 7.5kw Feed speed adjustable on variator 6-36m/min Feed driven by cardan shaft Driven rollers in the table Pneumatic clamps CE Certified Year of Build 2003 Net price

Pressing pliers, pressing machine, pressing jaws, pressing tool -Manufacturer: Roller, press machine type 5788001 with accessories -Pressing pliers: size M15, M18, M22, M28 -Accessories: see photos -Dimensions case: 510/300/H120 mm -Weight: 11.7 kg

CATALOG NO. 7221 TECHNICAL DATA - min / max width of the workpiece 45 / 150mm - min / max height of the workpiece 15 / 50mm 3 spindles: 1) horizontal lower 11kW 2) horizontal upper 22kW (7000 rpm) 3) horizontal lower 5.5kW spindle diameter 40mm - spindle 1 and 3 manually adjustable up/down, right/left - 2 spindle, manually adjustable right/left - 2 spindle, electrically adjustable up/down - spindle 2 and 3 are equipped with brakes in advance: - 3 introducing, pulling, metal toothed rollers - 1 double output, pulling, rubber roller from down: - pressure on insertion - grooved top - pulling roller, metal, smooth - electric setting of planing thickness - smooth adjustment of feed speed 6-24m/min - 3kW feed motor - feed on cardan shafts - length of the introductory tabletop 1970mm - automatic tabletop lubrication system - diameter of the exhaust port 1x150mm, 2x ...

Key data: 5 , 230 mm, 130 mm

I sell the Weinig Unimat 300 four-sided planer, built in 2004 Feed speed 5-30 m/min. Working width 230mm Working height 130mm 5 Spindle Configuration: bottom - right - left - up - down Combined power 28kW 3-zone pneumatic pressure Good condition. Fully operational! Available soon. Includes full documentation and CE certification.

SPECIFICATIONS Pilot plane on the entrance side: 2000 mm Grooved table Machinable width: max. 180 mm Machinable height: max. 150 mm Spindle diameter: 40 mm Shaft drive Drive shaft power: 4.0 Kw Soundproof booth Spindle Configuration: I Shaft: Bottom 4.0 kW II Shaft: Right 4.0 kW III Shaft: Left 5.5 kW IV Shaft: Right 5.5 kW V Shaft: Top 11.0 kW VI Shaft: Bottom 4.0 kW VII Shaft: Top 11.0 kW VIII Shaft: Universal 4.0 kW

Weinig Unimat 23 four-sided planer Working width 230mm Working height 160mm Number of spindles 5 Spindle arrangement Bottom 5.5kw Rights Left 7.5kw Top 11kw Bottom 5.5kw Pneumatic material clamps divided into 4 sections Feed speed adjustable by variator 4-24m/min Input table length 1980mm Drive on cardan shafts Thick soundproof cab Machine dimensions 380x226x178cmH CE Certified

Weinig Unimat 1000 Star four-sided planer Working width 20-230mm Working height 8-160mm Number of spindles 6 Spindle system: Bottom 5.5kw 6000r.p.m Right 4kw 7000r.p.m Left 5.5kw 7000r.p.m Mountain 7.5kw 7000r.p.m Bottom 7.5kw 7000r.p.m Universal 7.5kw 7000r.p.m Automatic height and width setting Automatic Countertop Lubrication Pump Countertop driven rollers (1 corrugated roller for wet wood) Pusuw speed adjustable by variator 5-24m/min Weinig EM10 automatic material feeder

Weinig Unimat 500 four-sided planer Working width 230mm Working height 130mm Number of spindles 5 Spindle system: 1. Bottom 7.5kw 2.Rights 3.Left 11kw 4.Top 7.5kw 5.Bottom 5.5kw Powercom system Pneumatic clamps divided into 4 sections Feed speed adjustable via inverter Feed drive on gimbals Input table length 1970mm CE Certified

Manufacturer: Weinig, Type: Unimat 17, Planing widht mm: 170, Planing hight mm: 120, Spindle diameter in mm: 35, Rotations of spindles max. rpm: 6.000, Spindle arrangement: U / R / L / R / O / U, Feeding - kW: 4, 1.Bottom spindle kW: 4, 3.Left spindle kW: 3, 4th spindle on right kW: 3, 5.Top spindle kW: 4, 6th spindle at bottom kW: 4,

Drilling cell with milling robot Staubli Unimation RX160 (Under Storm)  Year of production: 2006 Reach: 1710 mm Control: CS8C66 Mounting bracket details

Manufacturer: Weinig, Type: Unimat 17, Planing widht mm: 180, Planing hight mm: 120, Number of spindles: 7, Elektronische Achsverstellung: no, Work piece width min-max mm: 180, Min.-max. workpiece length in mm: 350, Wellendrehzahl: 6000, Spindles: 6, Spindle diameter in mm: ca 40, Spindle arrangement: U / R / L /R / O / U / Uni, 1.Bottom spindle kW: 4, 2nd spindle on right kW: 4, 3.Left spindle kW: 4, 4th spindle on right kW: 4, 5.Top spindle kW: 4, 6th spindle at bottom kW: 4, 7th universal on left kW: 4,

Manufacturer: Weinig , Type: Unimat 17 A, Year: 1979, Control: hand, Planing widht mm: 10-170, Planing hight mm: 10-120, Min.-max. workpiece length in mm: 300, Number of spindles: 6, Diameter of the spindle mm: 30, Fast exchange device: no, Rotations of spindles max. rpm: 6000, Separate engine per spindle: yes, Fully suspended drive feeding: no, Year :1979

WEINIG moulder, type Unimat 1000 Star, Manufacture year 2003, Machine specifications:, - Planing width 230 mm, - Planing height 120 mm, - Cardan feeding, motor 7.5 kW, - Feed speed 6 – 36 m/min, Spindle layout:, 1. Horizontal bottom spindle, 11 kW, 2. Vertical spindle right, 7.5 kW, 3. Vertical spindle left 11 kW, 4. Vertical spindle right, 7.5 kW, 5. Vertical spindle left 7.5 kW, 6. Horizontal top spindle, 15 kW, 7. Horizontal bottom spindle, 7.5 kW, 8. Horizontal top spindle, 7.5 kW, - Surface table 1050 mm, - Spindles 8000 rpm, - Motor brakes, - Feeded table rollers, - Waxalite pump, - Spindle diameter 40 mm, - Incl. accessories

Working width: 230mm, working height: 160mm, number of spindles: 6, spindle diameter: 50mm, spindle power: 4x 5.5kW/2x 11kW, feed rate: 24m/min, input table length: 3000mm, vertical spindle axial stroke: 80mm, horizontal spindle axial stroke: 45mm. Connected load: 126kW, air requirement: 8400m³-9600m³/h, machine dimensions X/Y/Z: approx. 3500mm/2000mm/1800mm, weight: approx. 3500kg. Including Weinig EM-11 slide-in unit and suitable distributor for the extraction system. Documentation available. On-site inspection is possible.

WEINIG moulder, type Unimat 23E, Manufacture year 2005, Machine specifications:, - Planing width 230 mm, - Planing height 120 mm, - Cardan feeding, motor 3 kW, - Feed speed 6 – 36 m/min, Spindle layout:, 1. Horizontal bottom spindle, 5.5 kW, 2. Vertical spindle right, 11 kW, 3. Vertical spindle left (with no. 2), 4. Vertical spindle right, 5.5 kW, 5. Horizontal top spindle, 11 kW, 6. Horizontal bottom spindle, 5.5 kW, - Surface table 2500 mm, - Motor brakes, - Feeded table rollers, - Waxalite pump, - Spindle diameter 40 mm, - Incl. accessories

Weinig Unimat 17 four-sided planer Working width 170mm Working height 140mm Number of spindles 6 Spindle arrangement Bottom 5.5kw Right 5.5kw Left 5.5kw Top 7.5kw Bottom 5.5kw Universal 5.5kw Adjustable heads Feed speed adjustable via variator 6-36m/min Drive on cardan shafts Feed motor 5.5kw Pneumatic material clamps Total power 41kw

SPECIFICATIONS: Feed length: 1970 mm Working width: 230 mm Working height: 120 mm Spindle: Ø 40 mm Number of Spindles: 5 Direct drive / cardan (0.25 kW x 3 motors) Speed: 6000 rpm Installed power: 22.9 kW Voltage: 380 V Spindle configuration: I Bottom (4 kW) II Right - Left (7.5 kW), Left equipped with electronic control III Top (5.5 kW) equipped with electronic control IV Bottom (4 kW) EQUIPMENT: Complete with tools

Weinig Unimat 500 four-sided planer Working width 230mm Working height 140mm Number of spindles 5 Spindle system: Bottom 5.5kw Rights Left 7.5kw Top 11kw Bottom 5.5kw Feed speed adjustable by inverter up to 30m/min Feed motor 4kw Drive on cardan shafts Pneumatic clamps 3 axes controlled from the panel (width, height, pressure position) Worktop air cushions Input table length 2470mm CE Certified DTR documentation

Weinig Unimat 500 four-sided planer Working width 230mm Working height 140mm Number of spindles 5 Spindle system: Bottom 5.5kw Rights Left 7.5kw Top 11kw Bottom 5.5kw Feed speed adjustable by inverter up to 30m/min Feed motor 4kw Drive on cardan shafts Pneumatic clamps 3 axes controlled from the panel (width, height, pressure position) Worktop air cushions Input table length 2470mm CE Certified DTR documentation

Height=1.6 m, Overall length= 1.5 m, Overall width= 2.6 m, Net weight= 1275 kg,

SPECIFICATIONS: Machine inlet: 1970 mm Working width: 230 mm Working height: 120 mm Spindles: Ø 40 mm Number of Spindles: 6 Shaft drive Installed power: 38 kW Voltage: 380 V SPINDLE CONFIGURATION: 1: bottom (4 kW) 2-3: right-left (11 kW) 4: top (7.5 kW) 5: bottom (5.5 kW) 6: universal (5.5 kW) EQUIPMENT: Miscellaneous Accessories

Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2000 mm Feed motor: 4 kW Feed speed: 5-24 m/min. 1 WEINIG Unimat 23 E Planer and moulder ------------------------------------------ 6 spindles (with 2 rigth spindles, reinforced motors, 8,000 rpm, ATS control Machine will be cleaned and functionally checked before delivery Working width 20 - 230 mm Working height 8 - 120 mm 1st spindle (bottom) 5.5 kW (motor replaced) ------------------------- Diameter 40 mm Speed 6,000 rpm Tool swing diameter 125 - 180 mm Rebating unit including tool Hardened table insert in front of 1st (bottom) spindle 2nd spindle (right) 12.1 kW (motor replaced) ------------------------- Shared motor with left vertical spindle Diameter 40 mm Speed 8,000 rpm Tool swing diameter 112-250 mm Max. Tool diameter behind stop plane 203 mm Max. groove depth 35 mm Axially travel ...

This WEINIG Unimat 23 E was manufactured in 1999, designed for efficient wood planing. Ideal for woodworking professionals looking to enhance their production capabilities. Contact us for more information.

WEINIG moulder Unimat 23EL, Manufacture year 2002, Machine specifications:, - Planing width 20 - 180 mm, - Planing height 8 - 120 mm, - Electric feeding system, motor 15 kW, - Feed speed frequency drive 6 - 40 m/min, Spindle lay-out:, 1. Horizontal spindle bottom, motor 11 kW, 2. Vertical spindle right, motor 11 kW, 3. Vertical spindle left, motor 15 kW, 4. Vertical spindle right, motor 7.5 kW, 5. Vertical spindle left, motor 15 kW, 6. Horizontal spindle top, motor 22 kW, 7. Horizontal spindle bottom, motor 7.5 kW, 8. Horizontal spindle top, motor 22 kW, 9. Horizontal spindle bottom, motor 18.5 kW, - Spindle diameter 50 mm, - Spindle 2 - 5 + 8 are 8000 rpm, - Spindle 9 adjustable 4000 – 8000 rpm, - LogoCom controller, - Short infeed table, - Automatic lubrication system, - Driven feeding rollers in table, - Heavy duty cardan feeding, - Separate electricity trunk with separate control p ...

Manufacturer: Weinig , Type: Unimat 3000 Brilliant, Year: 2002, Control: Weinig LogoCom, Planing widht mm: 20-230, Planing hight mm: 10-160, Number of spindles: 9, Elektronische Achsverstellung: yes, Wellendrehzahl: 4000-12000 regelbar, Fast exchange device: HSK 63, Setting up program shafts: yes, Saw unit kW: no, Table rollers: yes, Tool exchange places: no, Elektronische Anzeige : yes, Rotations of spindles max. rpm: 12000, Spindle arrangement: unten/rechts/links/rechts/oben/unten/oben/unten, Separate engine per spindle: yes, Fully suspended drive feeding: yes, Feeding - kW: 7,5, Feeding speed min-max m/min: 10-36, Feeding speed continous adjustable: yes, Table length: kurz, Pneumatical top pressure: yes, Adjustment - electonically: yes, Jointer Stück: yes, 1.Bottom spindle kW: 7,5 KW/12000 U/min, 2nd spindle on right kW: 7,5/12000 U/min, 3.Left spindle kW: 11/<CRLF>4000-12000mi ...

This WEINIG Unimat 500 was manufactured in 2005. A robust woodworking machine featuring a working range of 230 x 120 mm and five spindles, it ensures efficient processing with variable feed speeds from 4 to 30 m/min. Spindle power outputs include 4 kW for infeed and outfeed, and 7.5 kW for right/left and top spindles. Consider the opportunity to buy this WEINIG Unimat 500 woodworking machine. Contact us for more information about this machine.

Manufacturer: Weinig , Type: Unimat 30 EL, Year: 1999, Control: Siemens, Planing widht mm: 300, Planing hight mm: 120, Number of spindles: 6, Elektronische Achsverstellung: no, Work piece width min-max mm: 300, Min.-max. workpiece length in mm: 300, Min.-max. workpiece height in mm: 120, Saw unit kW: no, Table rollers: no, Rotations of spindles max. rpm: 6000, Spindle arrangement: U/R/L/R/O/U, Separate engine per spindle: yes, Fully suspended drive feeding: yes, Feeding - kW: 5,5, Feeding speed min-max m/min: 5-36, Feeding speed continous adjustable: yes, Pneumatical top pressure: yes, Jointer Stück: no, 1.Bottom spindle kW: 7,5, 2nd spindle on right kW: 5,5, 3.Left spindle kW: 5,5, 4th spindle on right kW: 5,5, 5.Top spindle kW: 7,5, 5th spindle at bottom kW: 7,5, Noise enclosure: Kabine, FREE TEXT: inkl.3 Hebebühnen und und eine Apstapelanlage/, Year :1999

WEINIG moulder, type Unimat 23E (blue line), Manufacture year 1998, Machine specifications:, - Planing width 230 mm, - Planing height 120 mm, - Cardan feeding, motor 4 kW, - Feed speed 6 – 36 m/min, Spindle layout:, 1. Horizontal bottom spindle, 7.5 kW, 2. Vertical spindle right, 11 kW, 3. Vertical spindle left (with no. 2), 4. Horizontal top spindle, 11 kW, 5. Horizontal top spindle, 11 kW, 6. Horizontal bottom spindle, 11 kW, - Surface table 2500 mm, - Motor brakes, - Grooved table, - Feeded table rollers, - Waxalite pump, - Spindle diameter 40 mm, - Complete with tooling and accessories

Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 + 500 mm Feed motor: 3 kW Feed speed: 6-36 m/min. 1 WEINIG Unimat 23 E 4-side Planer and Moulder ------------------------- 6 spindles (2 on the right), powerful motors, EM 11 feed magazine available Working width 20 - 230 mm Working height 8 - 120 mm 1st spindle, bottom 7.5 kW ------------------------ Diameter 40 mm Speed 6000 rpm Tool travel radius 125 - 180 mm Folding device Hardened table insert in front of 1st lower spindle 2nd spindle, right 11.0 kW ------------------------- Shared motor with left vertical spindle Diameter 40 mm Speed 6000 rpm Tool travel radius 112-250 mm Max. tool diameter behind stop plane 203 mm Max. groove depth 35 mm Axis adjustment range 80 mm 3rd spindle, left ------------------------- Shared motor with 2nd spindle Diameter 40 mm Speed 6000 rpm Tool cutti ...

Capacity: 230 x 130 mm. Number of shafts: 9 Bottom 7.5 kW, right 7.5 kW, left 7.5 kW, right 7.5 kW, left 7.5 kW , top 7.5 kW, bottom 7.5 kW, top 7.5 kW, bottom 7.5 kW Kardan drive Pneumatic pushers Front surface table Feed rollers for short workpieces Manually operated pump for bed lubrication Shaft diameter: 50 mm. Powered rollers in the table Feed: 6 - 36 m/min Motorized height adjustment

Capacity: 230 x 130 mm. Spindles: 7 Bottom 7,5 kW, right 7,5 kW, left 11 kW, right 7,5 kW, top 11 kW, bottom 11 kW, universal 11kW spindles 2, 3, 4 and 5 are 8000 tr/min straight jointer on 2nd bottom spindle Cardan shaft drive Pneumatic pressures Intermediate driven feedroller for short pieces 0,8 m infeed straightening table manual bed lubrication Spindle diameter: 50 mm. 5 driven rollers in table Feed: 6 - 36 m/min, motor 7,5 kW motor height adjustment

- Total installed power 51 KW. - Working width from 20 mm to 230 mm. - Working height from 9 mm to 140 mm. - 8 headers: down 5.50 KW - right 5.50 KW - left 5.50 KW - right 5.50 KW - left 5.50 KW - up 5.50 KW - up 5.50 KW - down 5.50 KW. - Axle diameter 40 mm. - Rotation speed of the shafts 6000 rpm. - Some accessories are included. - Operating conditions of this machine: unchecked. - This item is delivered loaded by truck. The costs of dismantling and loading are those that are specified as additional costs. Auction-ID: A7-44896-1

- Total installed power 53 KW. - Working width up to 170 mm. - Working height up to 120 mm. - 8 heads: down - right - left - right - up - up - down - universal . - Axle diameter 40 mm. - Rotation speed of the shafts 6000 rpm. - Variable feed rate. - Operating conditions of this machine: unchecked. - This item is delivered loaded by truck. The costs of dismantling and loading are those that are specified as additional costs. Auction-ID: A7-44896-14
