turning lathe used for sale

Mobile s/s turning table, dimensions: 1200 mm x 1200 mm x 820 mm.

Element welding Turntable werkstueck drehvorrichtung

-Digital display Fagor. -Accessories available. Tip height 200 mm Top width 800 mm Turning diameter over slide/bed 240/425 mm Length of the bend of the Planscheibem with 4 JAWS 180 mm Spindle bore 51 mm Inner cone 60 metric Recording camlock D6 " Speed 45-2240 Rev/min The lead screw pitch 6 mm Tailstock spindle mount MT 4 Diameter of tailstock Quill 70 mm Quill: 200 mm stroke Feeds: Along 0.05 2.8 mm / Rev Plan 0.05 2.8 mm / Rev Rapid traverse: LW Thread pitches: Metric 0.5 14 mm English 2-56 U/1 " Module 0.125 3.5 Motor 380 Volt, 12.5 HP Machine dimensions: B x T x H 2400 x 1200 x 1800 mm Weight 2100 kg

SMT Lathe 80001350 The machine was designed and manufactured to produce rotor shafts for power tools. The machine is designed and manufactured to perform the following operations automatically. - Load/unload parts automatically from/to tool carrier line with a pick-up & placement unit between the shaft ends. - Rotate ring seat + flat rotate commutator + rotate commutator. - Ring mounting - Commutator side - Ring mounting - Drive wheel side The machine has several production programs to produce different parts. Each program uniquely corresponds to a wave type Specifications Anchor wavelength from up to 92.5 - 163.1 mm Bearing pin diameter commutator side 8; 10; 12.5 mm Drive side 12; 8 mm Min. Available length bearing position 3.6 mm Package diameter 52; 55; 59 mm Ring dimensions Outer diameter 40 - 57.4 mm Inner diameter 37.4 - 56 mm Ring width 4 - 8 mm R ...

Emco Emcomat 17S Year of construction: 1999 Center height 140/280 mm Weight 725 kg Dimensions: 1650x 1060 x 1290 Speed 15- 3550 rpm

Thickness: 16 x 16 mm number: 4 Stähle weight: 3 kg dimensions: 300m x 200 x 50 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Robust, high-quality welding rotator with a load capacity of 5 tons. Diameter range: 100-3500 mm. A sustainable turning device that is ideal for welding pipes and steel tanks. Easy adjustment of the roller spacing. Includes wired remote control and foot pedal. With the built-in master-slave function, you can control several driven units synchronously. CE conformity, 1 year warranty. The price does not include VAT and transport. Depending on your wishes, we can organize the transport.

L&Z Lathe Lathe Turning (Used) Manufacturer: VDF Heidenreich & Harbeck Model 21 R0 Turning diameter over bed 420 mm Turning diameter over support 270 mm Turning length 1100 mm Center height 210 mm Spindle bore 58 mm Speed range 19 - 2000 rpm Main motor 7.5 kW Bed width 330 mm Cone Quill MK 4 Quill stroke 160 mm Quill diameter 65 mm Machine weight approx. 2000 kg Length 3200 mm, width 1100 mm, height 1600 mm 3-jaw chuck 250 mm incl. jaws 4-jaw chuck 250 mm incl. jaws Steel bracket System Multifix incl. insert size B Chip pan Grain tip MK 4 Condition of the machine very good. The machine has a very smooth running behaviour Forklifts available, freely loaded trucks Shipping by freight forwarder possible Location of the machine D-48324 Sendenhorst for enquiries 0157-35496006

Haas SL-10T CNC Lathe New turning tools are also included(paid approx. €3440), chuck (packs) for individual production and chuck (cartridges) for working from bar. The machine is in operation and the condition and accuracy can be tested. The lathe has an arm with a probe for quick tool presetting. Maintained regularly.

For sale REM Vertical Turning Lathe SC 43/44 with DRO. Technical Details: Faceplate Diameter: 4.000 mm Max. Turning Diameter: 4.400 mm Bqyuqbw8uq Machining Height: 2.050 mm Max. Work Piece Weight: 18 tons DRO Control

Vertical Turning Lathe with Double Columns UMARO SC 53 Technical Data: Table diameter: 4500mm Max. turning diameter: 5000mm Max. height of workpiece: 3000mm Conventional Control Max. workpiece weight: 30 tons Working table range of rotation speed: 0.85-25.4 r/min Working table step of rotation speed: stepless Horizontal travel of tool post: 2650mm Crossbeam travel: 2150mm Power of main motor: 75 kW Weight of machine (approx.): 80tons

Code: 0126 Brand: MINIMAX SCM Model: T 124 Wood-turning lathe with base for producing columns, furniture parts, etc., for wood, plastics, plaster, marble, etc. Technical data: Max distance between centres mm 1180 Centre height mm 210 Three-phase motor (V. 380) Hp 1,5 Spindle speed rpm 570/1000/1850/2500 Max working diameter mm 420 Rapid tailstock Easy speed change Holder table Suction hood diameter mm 100 Box with n° 5 gouges Overall dimensions mm 1800 x 600 x 1280 h Weight kg 125

RAFAMET Wheel Turning Lathe XAD 112

Technical data: Capacities: Height of centres over the flat way: 625 mm Height of centres over the flat floor: 1225 mm Swing over bed: 1250 mm Swing over carriage: 940 mm Diameter of four-jaw chuck: 1250 mm Only range of the chuck min/max: 230/1050 mm Distance between centres: 5000 mm Headstock: Spindle bore: 105 mm Spindle seat: cyl. 105 Diameter of the spindle in the front bearing: 320 mm Number of spindle speeds: 24 Overall range of spindle speeds: 1.6-315 rpm Spindle drive motor rating: 75 kW Maximum torque of the spindle: 63000 NM Carriage: Of the bed width: 1100 mm Length of the saddle: 1320 mm Of the cross slide width: 550 mm Travel of cross slide: 800 mm Travel of tool slide: 600 mm Number of feed Council for each range: 20 Overall range of longitudinal feed Council: 0.18-160 mm / rev Range of longitudinal feed Council at: -high range of spindle speeds:  ...

Machine according to DIN 8605: lathe with increased accuracy. Top width: 700 mm Tip height: 170 mm Swing over bed: Ã? 340 mm Swing over cross slide: Ã? 190 mm Bed width: 260 mm Longitudinal slide displacement: 600 mm Cross slide displacement: 220 mm Upper carriage displacement: 110 mm Plan carriage length: 410 mm Plan slide width: 150 mm Bed slide length: 380 mm Turning tool cross section: 20 x 20 mm Distance turning Center - upper carriage: 34 mm Range of the upper carriage (support): 60 / 120 ° Main spindle: Spindle connection DIN 55029 (camlock): S 5 spindle bore: Ã? 50 mm Internal cone according to DIN 7178: 1:22 spindle diameter in front bearing: Ã? 70 mm Maximum Chuck diameter: Ã? 200 mm Faceplate diameter: Ã? 200 mm Spindle speeds: 40-3000 rpm Speed: Stepless mechanical speeds: 4 Main drive: Power at 40% ED: 5,3 kW Maximum nominal torq ...

Tip height 300 mm Top width 2000 mm Spindle speeds 16-1120 U/min Dimensions L/W/H 3750/1100/1400 mm Weight approx. 2500 kg

LZ lathe. Tip height 200 mm. Top width 1000 mm. 16 spindle speeds 40-2000 RPM. Coolant system. Quick change Toolpost. Geometric, machine has been revised. Digital display.

Accessories: -Three jaw Chuck ø 630 mm -Multi fix steel holder Tip height 400 mm Top width 2000 mm Recording camlock Turning diameter in the offset 900 mm

Tip height over bed top distance of 200 mm 1000-1500 mm Permissible diameter on bed 400 mm Permissible diameter on sled 230 mm bed Bed width 280 mm head Spindle passage 52 mm 6ʺ camlock spindle nose Speed Spindle speed 16 n. Values 36-2000 RPM. Feeding and tapping 72 longitudinal feed 0.05-4.45 mm / rev 72 cross feed 0.025-2.25 mm / rev 54 Whitwort Division 1-56 TPI 54 metric pitch 0.5-28 mm 54 English Division 1-32-1ʺ inch 54 Division of modular 0.25-14 mm 54 pitch Division 2-112 D.P.. Cross slide 470 mm Width 180 mm Maximum stroke 235 mm Cross slide Length 260 mm Width 120 mm Maximum stroke 150 mm Slewing range 360 degrees Counter tailstock Hollow shaft diameter 58 mm Hollow shaft length 265 mm Maximum stroke hollow shaft 120 mm Cone of the hollow shaft 4 C.M.. - MK Motor Power 4 kW

Accessories available Tip height 120 mm Top width 450 mm Spindle passage 23 mm Spindle inner taper MK 4 Plan travel 150 mm Tailstock MK 2 Quill way 80 mm Manual 9 levels Speed range 2 travel of bolt turn 30 3000 rpm

Control SIEMENS 805 TECHNICAL DATA: WORK AREA / DIMENSIONS Swing over bed [mm] 820 Swing over facing slide [mm] 515 Displacement of the plan slide [mm] 520 Displacement of the upper support [mm] 250 Turning length [mm] 2000 Tip height on flat railway [mm] 400 Bed width [mm] 560 Bed sleigh length [mm] 800 Facing slide width [mm] 320 Plan valve length [mm] 1005 Upper support width [mm] 200 Turning tool cross section according to DIN 770 hxb [mm] 40 x 25 MAIN SPINDLE Spindle nose according to DIN 55 027 [Gr.] 11 Spindle diameter in front bearing [mm] 170 Spindle bore [mm] 128 Inner taper of main spindle [metr.] 136 MAIN drive infinitely adjustable three-phase motor (AC motor) Power 60% / 100% ED [kW] 46/37 Torque max 60% / 100% ED [NM] 5,300/4.260 Torque max 60% / 100% ED [NM] 5,300/4.260 Total speed range [min-1] 6.3 1,600 Transmission levels 2 Speed rang ...

Accessories available Tip height 300 mm Top width 2000 mm Spindle speeds 16-1120 RPM Dimensions L/W/H 3750/1100/1400 mm Weight approx. 2500 kg

Accessories: -Fixed and revolving bezel -Rapid steel holder type B Turning diameter: 225 mm top width 1000 mm Spindle bore 42 mm Spindle speeds 35 1500 rpm.

Lace high 400 mm Drehlange 700 mm, hydraul. Tailstock more info on request

Accessories: Steel holder Multifix B Tip height 200 mm Top width 1000 mm Spindle speed 5 2520 U/min Turning diameter over bed 405 mm over slide 245 mm Offset bore Ø 500 mm Recording camlock Spindle bore 38 mm Longitudinal feeds 0.029 1.6 mm / Rev Plan feeds 0.022 1.25 mm / Rev Machine weight approx. 1500 kg

Digital display of HEIDENHAIN Hydr. Copy Setup various accessories faceplate diameter 2000 mm Rotary height 1500 mm

Tip height: 102 mm Top width: 450 mm Spindle bore: 32 mm Reduction gear Links.-right rotation 2-stage drive Vario speed: 270-3000 rpm Knee circuit Turning diameter over bed: 200 mm Spindle nose: W 20 Tailstock Quill: MK 2 Dimension (Lxwxh): approx. 140 x 56 x 123 cm Weight: approx. 550 kg Accessories available Manual available The machine is located in a clean good condition!

Qty. 1 Second-hand roll lathe Mfc.: Herkules Type: WD-700 Built: 1952 General overhauled by Hoesch-MFD in 1990 Centre height: 600 mm Turning length: 2750 mm 2-axis digital display – Mfc.: Micro Wizard Longitudinal drive Standstill torque: 14 Nm Rated revolution: 2500 RPM Feeding range: 5 – 100 mm/min. Rapid speed: 2500 mm/min. Plain drive Standstill torque: 14 Nm Rated revolution: 3000 RPM Feeding range: 5 – 100 mm/min. Rapid speed: 2500 mm/min.

Accessories available. Peak height 125 mm Tip width 500 mm Circulation diameter over bed 250 mm Circulation diameter via flat slide 140 mm Spindle head size 4 Inner cone similarly shortened MK 5 Spindle bore 38 mm Speed 3000 rpm. Bed slide path 450 mm Plan slide path 120 mm Upper slide path 82 mm Inner cone Reitstockpinole DIN 228 MK 3 Pinole stroke 80 mm Feed diameter 125 mm Collet passage max. 28 mm Flat slide diameter max. 200 mm Guide diameter fixed set stick 10 - 60 mm guide diameter. Seedstick 10 - 50 mm Workpiece weight incl. clamping equipment max 40 kg Space requirement L x W x H approx. 1300 x 700 x 1400 mm Weight approx. 650 kg

Tip height: 130 mm Top width: 450 mm Rotational speed: approx. 55-3000 rpm Pneumatic clamping system Spindle nose: W 25 Div. W25 collets available Div. holder available BERGER LAHR axis motors Combitec EIP E-500 control Manual control available Coolant system available Machine lamp available Machine feet available Dimension (Lxwxh): approx. 1400 x 560 x 1230 mm Weight: approx. 550 kg The machine is located in a clean good condition!

Tip height 102 mm Top width 450 mm Leit.-/ spindle Collets W20 available Rotational speed: approx. 210 3000 rpm Reduction gear Links.-right rotation 2-stage drive L x W x H: CA. 1760 x 595 x 1230 mm Weight: approx. 650 kg

-Three jaw Chuck ø 200 mm -Multi fix steel holder -Fixed bezel -Revolving bezel Centre height 175 mm Top width 1000 mm Speed 40-1800 rpm Spindle bore ø 52 mm Recording camlock 6° machine dimensions 2300 x 1100 x 1400 mm Weight approx. 1400 kg

Vertical turret lathe FKD 40 CNC with Y-axis and CNC Rotary milling head (A-axis) Faceplate diameter 4000 mm Turning diameter: 8000 mm Turning height: 3000 mm Slide cross section: 300 mm x 300 mm Stroke: 3000mm X-axis: travel 5000 mm Z axis: travel 2000 mm Y-axis: travel 6000 mm W-axis: stroke 1500 mm C-axis in face plate table A-axis milling head Control: Siemens 840 DSL Tool changers: 60 seats PickUp station: 5 places

Lathe brand KERN

CNC carousel lathe FKD 30, Siemens 840 dsl, machining range-diameter 3500, working height 3000mm, workpiece weight max. 25 tons, driven tools speed 0-3000 rpm, faceplatespeed 0 - 150 rpm, pickup station 5 places. Manufactured in the EU Remarks: 2columns carousel lathe with traversing cross beams, 1 piece ram for rotating and milling (ram 300mm x 300mm) with driven tools, ISO 50 C axis with master-slave bracing Filter system 3000 liters incl. high pressure pump 25 bar 3 chip conveyors

Round table with C-axis and Y-axis FKD 40: Faceplate diameter 4000mm Y-axis traverse path: 6000mm Load capacity 50 to Max. Speed 120rpm with shifting-gearbox Stoeber Master-Slave-embracing on C-axis and on Y-axis, 2 Siemens motors each 60 KW (C-axis), 2 Siemensmotoren (Y-axis) Speed 1st stage 0-20rpm, 180000 Nm Speed 2nd stage 0-120rpm, 45000 Nm Oil lubrication, Hydrostatic bearing Dimensions: Length: 11000 mm, width: 4000 mm, height: 1200 mm Mass 35 t. Maintenance free, Manufactured in Germany

Round table with C-axis and Y-axis FKD 40: Faceplate diameter 4000mm Y-axis traverse path: 6000mm Load capacity 50 to Max. Speed 120rpm with shifting-gearbox Stoeber Master-Slave-embracing on C-axis and on Y-axis, 2 Siemens motors each 60 KW (C-axis), 2 Siemensmotoren (Y-axis) Speed 1st stage 0-20rpm, 180000 Nm Speed 2nd stage 0-120rpm, 45000 Nm Oil lubrication, Hydrostatic bearing Dimensions: Length: 11000 mm, width: 4000 mm, height: 1200 mm Mass 35 t. Maintenance free, Manufactured in Germany

Voest DA210 - 210/48/1500 universal lathe Centre distance: 1500 mm Tip height: 210 mm Turning diameter over bed: 430 mm Swing over carriage: 280 mm Quill recording: MK4 Spindle bore: 48 mm Bed width: 330 mm Speeds: 12 Speed range: 21-1500 rpm Feed speed: 0,072-4.04 mm Metric threads: 0.5-28 mm Inch thread: 1-56 tpi Motor power: 3 kW Voltage: 400V Dimensions WxHxD: approx. 2700 x 1400 x 800 mm Weight: 1500 kg Facilities: 4 - jaw Chuck, tracking grains u.m..

Accessories: Coolant system Digital display HEIDENHAIN Tip height 200 mm Top width 1000 mm Speed 36-1600 rpm Umlauf-Ã? on cross slide 230 mm Spindle hole 52 mm Spindle support 6 "camlock Reitstock Quill Ã? 58 mm Tailstock spindle mount MT 4

Vertical turret lathe FKD 40 CNC with Y-axis and CNC Rotary milling head (A-axis) Faceplate diameter 4000 mm Turning diameter: 8000 mm Turning height: 3000 mm Slide cross section: 300 mm x 300 mm Stroke: 3000mm X-axis: travel 5000 mm Z axis: travel 2000 mm Y-axis: travel 6000 mm W-axis: stroke 1500 mm C-axis in face plate table A-axis milling head Control: Siemens 840 DSL Tool changers: 60 seats PickUp station: 5 places

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

CNC carousel lathe FKD 30 CNC control: Siemens 840D sl Machining-range: diameter 3500mm Working height: 3000mm Workpiece weight: max. 25 tons Driven tools: speed 0-3000 rpm Tool holder: ISO 50 for milling and drilling, Capto C8 for turning Faceplatespeed: 0 - 150 rpm Pickup station: 5 places. Filter system: 3000 liters incl. high-pressure pump 25 bar Chip conveyors: 3 items Remark: 2column carousel vertical lathe with traversing cross beam (W-axis adjustable) Support (X-axis) with one ram (Z-axis, ram 300mm x 300mm) for turning and milling with driven tools C-axis (faceplate) with master-slave bracing – zero backlash Manufactured in the EU

CNC carousel lathe FKD 30 CNC control: Siemens 840D sl Machining-range: diameter 3500mm Working height: 3000mm Workpiece weight: max. 25 tons Driven tools: speed 0-3000 rpm Tool holder: ISO 50 for milling and drilling, Capto C8 for turning Faceplatespeed: 0 - 150 rpm Pickup station: 5 places. Filter system: 3000 liters incl. high-pressure pump 25 bar Chip conveyors: 3 items Remark: 2column carousel vertical lathe with traversing cross beam (W-axis adjustable) Support (X-axis) with one ram (Z-axis, ram 300mm x 300mm) for turning and milling with driven tools C-axis (faceplate) with master-slave bracing – zero backlash Manufactured in the EU

CNC carousel lathe FKD 30 CNC control: Siemens 840D sl Machining-range: diameter 3500mm Working height: 3000mm Workpiece weight: max. 25 tons Driven tools: speed 0-3000 rpm Tool holder: ISO 50 for milling and drilling, Capto C8 for turning Faceplatespeed: 0 - 150 rpm Pickup station: 5 places. Filter system: 3000 liters incl. high-pressure pump 25 bar Chip conveyors: 3 items Remark: 2column carousel vertical lathe with traversing cross beam (W-axis adjustable) Support (X-axis) with one ram (Z-axis, ram 300mm x 300mm) for turning and milling with driven tools C-axis (faceplate) with master-slave bracing – zero backlash Manufactured in the EU

CNC carousel lathe FKD 30 CNC control: Siemens 840D sl Machining-range: diameter 3500mm Working height: 3000mm Workpiece weight: max. 25 tons Driven tools: speed 0-3000 rpm Tool holder: ISO 50 for milling and drilling, Capto C8 for turning Faceplatespeed: 0 - 150 rpm Pickup station: 5 places. Filter system: 3000 liters incl. high-pressure pump 25 bar Chip conveyors: 3 items Remark: 2column carousel vertical lathe with traversing cross beam (W-axis adjustable) Support (X-axis) with one ram (Z-axis, ram 300mm x 300mm) for turning and milling with driven tools C-axis (faceplate) with master-slave bracing – zero backlash Manufactured in the EU

CNC carousel lathe FKD 30 CNC control: Siemens 840D sl Machining-range: diameter 3500mm Working height: 3000mm Workpiece weight: max. 25 tons Driven tools: speed 0-3000 rpm Tool holder: ISO 50 for milling and drilling, Capto C8 for turning Faceplatespeed: 0 - 150 rpm Pickup station: 5 places. Filter system: 3000 liters incl. high-pressure pump 25 bar Chip conveyors: 3 items Remark: 2column carousel vertical lathe with traversing cross beam (W-axis adjustable) Support (X-axis) with one ram (Z-axis, ram 300mm x 300mm) for turning and milling with driven tools C-axis (faceplate) with master-slave bracing – zero backlash Manufactured in the EU

CNC carousel lathe FKD 30 CNC control: Siemens 840D sl Machining-range: diameter 3500mm Working height: 3000mm Workpiece weight: max. 25 tons Driven tools: speed 0-3000 rpm Tool holder: ISO 50 for milling and drilling, Capto C8 for turning Faceplatespeed: 0 - 150 rpm Pickup station: 5 places. Filter system: 3000 liters incl. high-pressure pump 25 bar Chip conveyors: 3 items Remark: 2column carousel vertical lathe with traversing cross beam (W-axis adjustable) Support (X-axis) with one ram (Z-axis, ram 300mm x 300mm) for turning and milling with driven tools C-axis (faceplate) with master-slave bracing – zero backlash Manufactured in the EU

Horizontal Lathe POREBA TCA 160 x 12 m Condition: very good, complete Technical details: Max. swing over bed 1600 mm Max. swing over carriage 1280 mm Max. swing over gap 1600 mm Turning length (between centers) 12000 mm spindle turning speed (min) 0.85 rpm spindle turning speed (max) 170 rpm The width of guide way 1100 mm Dia. of spindle bore 105 mm Taper of center sleeve 120/80 Feeds: bed slide/longitudinal 0,19-5, 0 mm/1 spindle rotation Feeds cross slide 0,095-2, 5 mm/1 spindle rotation Rapid travel-longitudinal/face 4000 mm/min Max work piece weight centre this centre 30000kg Max work piece weight with 2 steady rest 40000kg Faceplate diameter 1600 mm Metric thread 35 strokes-1-50 mm Whitworth thread 35 strokes-24-1/2 " Module thread Diametrical pitch thread Section of tool shank 70x70mm Travel of the top slide 0,095-2, 5 mm/1 spindle rotation Max.travel o ...
