turning diameter:640 / 400 mm turning length:1500 mm control:Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z:550 / 180 (±90) / 1585 mm Swivle angle milling spindle (B-axis):±120° interpol. ° Rapid traverse feeds turret 1 (milling head) x/y/z:40/24/60 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:12 / 23 kW Torque of milling spindle:100 Nm Tool magazine for milling spindle (turret 1):120 HSK-A 63 Tool change time tool/tool, milling spindle:1,6 s Spindle 1 RPM:4000 1/min Spindle 1 power:36/ 45 kW Spindle 1 Torque:730 Nm Spindle 1 max. bar diameter:90 Spindle 2 RPM:4000 1/min Spindle 2 power:36 / 45 kW Spindle 2 torque:730 Nm Spindle 2 max. bar diameter:90 c-axis:0,001 ° Travel turret 2 x:225 mm Travel Turret 2 z:1595 mm RPM of rotary tools turret 2:4000 1/min no. of tools in turret 2:12 VDI 40 high-pressure pump:20 bar total power requiremen ...
turning diameter:500 mm turning length:1000 mm control:Siemens 840 D spindle:42 / 28 kW spindle turning speed - stepless:31 - 4000 1/min max. torque on the spindle:345 Nm c-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/min rapid traverse:10000 mm/min turret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/min diameter of quill:90 mm quill stroke:80 mm tailstock quill taper ISO:SK 30 Tailstock Travel:600 mm Power rotary tools:3,5 kW :22,5 Nm Rotary tool holders:4 ax./ 4 rad. spindle passage:66 mm total power requirement:30 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:8x 3 x 4 m
standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS III greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm ...
turning diameter:160 mm turning length:300 mm control:Siemens 840D Spindle 1 Power:22 kW Spindle 1 RPM:5000 1/min Spindle 1 max. bar diameter:65 Spindle 1 Torque:150 Nm Spindle 2 power:16,8 kW Spindle 2 RPM:5000 1/min Spindle 2 torque:100 Nm Travel for pick up of 2nd Spindle:W2=690 mm dimensions of the machine ca.:´4,5x2,0x2,3 m weight of the machine ca.:9 t CNC turning center with 3 turrets with rotary tool drives and 2 spindles. There is an internal coolant system for the turrets with individual pumps
turning diameter:190 mm turning length:503 mm control: Fanuc 31i - TA Travel x/z turret 1:135 / 503 mm Travel Y1:62 (± 31) mm Travel x/z turret 2:135 /503 mm c-axis:Sp. 1 / 2 Spindle 1 RPM:6000 1/min Spindle 1 Power:11/7,5 kW Spindle 1 max. bar diameter:42 mm Spindle 2 RPM:6000 1/min Spindle 2 power:11/7,5 kW Turret No.1 stations / rotary tools:12/12 Turret 1 tool RPM:6000 1/min Turret 1 power rotary tools:7,1 / 2,2 kW Turret No.2 stations / rotary tools:12/12 Turret 2 tool RPM:6000 1/min Turret 2 power rotary tools:7,1 / 2,2 kW total power requirement:53 kVA weight of the machine ca.:5700 t dimensions of the machine ca.:2,3 x 1,6 x 1,94 m High precision cnc turning center, rotary tools and y-axis on upper turret, Robot loader for shafts.
turning diameter:410 mm turning length:500 mm control:Fanuc 21i TB standard turning diameter:275 mm travel -x axis:277 mm travel -y axis:82 (±41) mm travel -z axis:500 mm Spindle 1 RPM:4500 1/min Spindle 1 Power:18,5/18,5/15 kW Spindle 1 max. bar diameter:65 mm turret stations / rotary tool stations:12/12 Power rotary tools:5,5 kW RPM of rotary tools:6000 1/min total power requirement:39,2 kVA weight of the machine ca.:6,2 t dimensions of the machine ca.:3,1 x 2,0 x 2,2 m collet chuck:Hainbuch High precision Turning and Milling Centre with Y-axis and robot loading. Stäubli Robot for shaft loading.
standard turning dia.:42 / 140 turning length:170 mm control:Mitsubishi max. turning diameter:140 mm bar material dia.:42 mm turning speed range - spindle:80-8000 1/min spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:60-6000 1/min spindle nose:JIS A2-6 bar material dia. max:42 mm collet chuck:173E C-Axis:0,001 ° Number of Turrets:2 . Number of tool stations:12 x 2=24 pos power capacity - driven tools:7,5 / 5,5 kW total power requirement:92,7 kVA weight of the machine ca.:3,3 t dimensions of the machine ca.:2,4 x 1,6 x 2,2 m The Boley BE 42 2 has 2 spindles und 2 turrets with 12 toolstations VDI 20 each. It can work simultaneus with 7 Achsen. The machine has ca. 22.000 run hrs. The coolant system has a cooling unit 15 collets 173E come with the machine. A bar feeder interface is installed.
max. turning diameter:350 mm turning length:1040 mm control:OSP E 100 L Fanuc greates pass round over bed:550 mm Max. distance between centres:1200 mm max. workpiecediameter:550 mm Traverse X-Axis 1:270 Traverse X-Axis 2:230 mm Traverse Y-Axis 1:120 (±60) mm Traverse Z-Axis 1:930 mm Traverse Z-Axis 2:920 mm Spindle 1 Power:22 / 15 kW Spindle 1 RPM:5000 1/min spindle nose:JIS A2-8 bar material dia.:65 mm C-Axis:0,001° Number of Turrets:2 Turret No.1 stations / rotary tools:12/12 VDI 40 Turret 1 tool RPM:4500 1/min Turret 1 power rotary tools:7.0 / 3,3 kW Turret No.2 stations / rotary tools:12/12 VDI 40 Turret 2 tool RPM:4500 1/min Turret 2 power rotary tools:7.0 / 3,3 kW rapid traverse X-axis:30 m/min rapid traverse Y-axis:26 m/min rapid traverse Z-axis:40 m/min total power requirement:33 kVA weight of the machine ca.:10 t dimensions of the machine ca.:7,0 x 2,3 x 2,3 m spindle load m ...
turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.
turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with live tools:VDI40 Live tooling VDI40 with automatic loading and unloading system G300 with "spindle bore clamping capacity 90mm" in tailstock version Chip conveyor, belt filter press, hydraulic unit, as well as infeed and outfeed chain conveyor EWAP, with 33 pallets. The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.
turning diameter:270 mm turning length:710 mm weight of the machine ca.:6,5 t max. swing diameter:590 mm with automatic loading and unloading system, chip conveyor G300 with "spindle bore clamping capacity 90mm" in tailstock version The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools.
turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.
turning diameter:120 mm turning length:650 mm weight of the machine ca.:11 t dimensions of the machine ca.:5,032 x 3,048 x 2,445 m max. swing diameter:250 mm Gildemeister MF Twin 65-II lathe with loading automation. This machine is suitable as a counter spindle machine for 4-axis machining on the main and counter spindles, complete machining (turning, drilling, milling, Y-axis, B-axis) of bar and shaft parts.
turning diameter:33 mm turning length:330 mm control: 840 total power requirement:20 kW weight of the machine ca.:6 t dimensions of the machine ca.:3850,2000,2100 m 17 axes 3 revolvers with the powered tools 1 gantry with the driven tools Main and counter spindle with C axes Barfeeder Machine On-time 58,133 hours
turning diameter:220 mm turning length:- mm control:- distance between milling spindels:800 mm spindle speed max.:12.000 U/min daylight:66 mm machine weight ab.:11 t total power requirement:90 kVA Fanuc control Two turrets Two spindles Spindle bore 66 mm on both spindles Two Y-axes Parts gripper Hainbuch chuck on both spindles Tailstock function Chip conveyor Tool eye Short bar loader Tool holder package
turning diameter:275 mm turning length:900 mm spindle passage:65 mm power capacity at 100 % load:25/20 kW spindle turning speed range:1 - 5000 U/min spindle diameter in front bearing:110 mm c-axis:1 - 500 U/min. number of workpiece supports:4 tool turret:1 x-axis:290 mm y-axis:165 mm z-axis:360 mm b-axis:360 ° rapid speed:18/30 m/min number of tools:2x2 + 2x2 number of driven tools:2x2 + 2x2 mm toolpiece turning speed range:8000 / 2000 U/min power capacity:25% ED 5,8 kW tool taper:TRAUB 60 tool turret:2/3/4 x-axis:170 mm z-axis:600/950 mm y-axis:+/- 60 mm rapid speed:18/15/30 m/min number of driven tools:10 mm toolpiece turning speed range:1 - 6000 U/min power capacity:25% ED 5,8 kW tool taper:DIN 69880 40 x 63 total power requirement:95 kW weight of the machine ca.:16 t dimensions of the machine ca.:10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and ...
Technical data: 1-drive unit / 1-loose unit 2012 overtaken max. load: 10 to Container diameter: 1000-5000 mm Roll diameter: 540 mm Roll width: 600 mm
Technical data: working surface: 2500 x 3000 mm Table load: 30 to. The mounting pad height: 240 mm Number of T-slots: 10 Rotation speed: 0.008 ? 0.45/rpm Power: 7,5 kW
Machine according to DIN 8605: lathe with increased accuracy. Top width: 700 mm Tip height: 170 mm Swing over bed: Ã? 340 mm Swing over cross slide: Ã? 190 mm Bed width: 260 mm Longitudinal slide displacement: 600 mm Cross slide displacement: 220 mm Upper carriage displacement: 110 mm Plan carriage length: 410 mm Plan slide width: 150 mm Bed slide length: 380 mm Turning tool cross section: 20 x 20 mm Distance turning Center - upper carriage: 34 mm Range of the upper carriage (support): 60 / 120 ° Main spindle: Spindle connection DIN 55029 (camlock): S 5 spindle bore: Ã? 50 mm Internal cone according to DIN 7178: 1:22 spindle diameter in front bearing: Ã? 70 mm Maximum Chuck diameter: Ã? 200 mm Faceplate diameter: Ã? 200 mm Spindle speeds: 40-3000 rpm Speed: Stepless mechanical speeds: 4 Main drive: Power at 40% ED: 5,3 kW Maximum nominal torq ...
Many thanks for your interest on our second hand machines, please find follow our offer: manufacturer : roundtable / turntable diameter : 800mm / 1000mm/1200mm/1400mm/2000mm electrical : 230 VAC / on request 400V/3ph - Legs adjustable - Stainless steel construction - Speed control with frequency converter - CE confirmation - Manual and electr. draw - driven with geared motor - edge high 30mm The base frame has a support for the lift truck transport I offer this machine in NEW condition Round table in Stainless steel Ø mm Round table 800 Round table 1000 Round table 1200 Round table 1400 Round table 2000 Example fotos, with additional parts
Woodturning machine DB 1100 new 230 V 0.75 kW 50 Hz Top distance of 1100 mm Tip height 179 mm Machine bed, base, tailstock made of cast iron Speed control of 500-2000 RPM MK2/M33 Spindle stock 90 ° swiveling ideal for large diameter! Weight 92 kg G & pieces 5921100
2006 completely rebuilt Clamping surface: 1,800 x 1,800 mm Table height: 800 mm Maximum table load: 20 tons. Table displacement: 850 mm Electrics: 400 V / 50 Hz
Control SIEMENS 805 TECHNICAL DATA: WORK AREA / DIMENSIONS Swing over bed [mm] 820 Swing over facing slide [mm] 515 Displacement of the plan slide [mm] 520 Displacement of the upper support [mm] 250 Turning length [mm] 2000 Tip height on flat railway [mm] 400 Bed width [mm] 560 Bed sleigh length [mm] 800 Facing slide width [mm] 320 Plan valve length [mm] 1005 Upper support width [mm] 200 Turning tool cross section according to DIN 770 hxb [mm] 40 x 25 MAIN SPINDLE Spindle nose according to DIN 55 027 [Gr.] 11 Spindle diameter in front bearing [mm] 170 Spindle bore [mm] 128 Inner taper of main spindle [metr.] 136 MAIN drive infinitely adjustable three-phase motor (AC motor) Power 60% / 100% ED [kW] 46/37 Torque max 60% / 100% ED [NM] 5,300/4.260 Torque max 60% / 100% ED [NM] 5,300/4.260 Total speed range [min-1] 6.3 1,600 Transmission levels 2 Speed rang ...
Table dimensions: 2000 x 2000 mm Table height: 890 mm Table displacement: 1,200 mm Maximum table load: 20 tons. Electrics: 400 V / 50 Hz
Turning- and Distibution Built in: 2000; working condition
Curve lathe SCHWERDTFEGER UA20 - see picture
Inv. Num. : 6238 Type: HIT-250 MS Producer: HYUNDAI Created: 2004 Parameters: Control system: Siemens Sinumerik 840D turning length: 650 mm turning diameter: 390 mm Maximum turning diameter over bed: 590 mm Maximum spindle speed: 3600 1/min Maximum main spindle power: 15 kW Spindle passage: 80 mm Number of all tools: 12 pieces Number of driven tools in the turret head: 12 pieces Chuck diameter: 250 mm Axis X: 265 mm Axis Z: 660 mm Clamping diameter (counter spindle): 160 mm Spindle passage (counter spindle): 50 mm speed (counter spindle): 4500 1/min Length: 3692 mm Width: 1850 mm Height: 1850 mm Weight: 6450 kg Equipment: C-axis Technical documentation Conveyor Driven tools 2x 3-jaw chuck Cooling Complete coverage of the work area Oil mist separators Housing for clamping rotary knives and cases (8 pcs.)
Curve lathe INDEX B60 - not complete - as spare part dispenser - see pictures
Note: We have 6 pieces of this machine in stock! Manufacturer: Gildemeister Type: GS 36 – 6 A/C Machine no.: 7.0176 Year of construction: 1987 Weight: 11t General / technical data: Portal-6spindle automatic lathe with measuring device and automatic feeding Spindle dividing circuit: 300mm Number of longitudinal slides: 6 Number of cross slides: 2 gr. cross slide stroke: 60mm gr. longitudinal slide stroke: 125mm Spindle speeds: Infinitely variable 562 – 3373 rpm Main time range: Stepless 1.95 – 78 sec. Low time range: 0.79 – 2.13 sec. Drive power: DC motor spindles 20kW; Feed rates 8kW Installation area: approx. 1720 x 4700mm Remark: The machine cannot be converted for bar work. Equipment: – 1 creep gear drive for set-up operation – 1 automatic central lubrication device – 1 coolant device with lines and pu ...
Curve lathe INDEX ER60 - see pictures More: turnover machine MANURHIN Traminer TR22B
Universal CNC lathe BOEHRINGER NG 200 Manufacturer: BOEHRINGER Type [ type]: NG200 CNC double Control unit: Siemens 840D Year of construction[construction year]: 10/2001 Rotating diameter: 290 mm Turning length: 850 mm Control: SIEMENS 840 D Orbital diameter over bed: 600 mm Revolver 1 Revolver 2 Counter spindle Counter headstock Tailstock C-axis Powered tools Automatic machine doors – newly retrofitted Z-axis resolution: 40nm (2nm interpolated) Travel in Z: 740mm Rapid traverse speed in Z: 25 m/min Centering tip SK 30 X-axis resolution: 125nm (8nm interpolated) Travel in Z: 220mm Rapid traverse speed in Z: 25 m/min Distance between main and counter spindle: 1034mm Drive power: 30-72 kW Torque: 662 Nm Speed range max.: 4500 rpm Spindle head: Size 6/8 DIN 55026 Spindle diameter in the front. Bearing [spindle]: 120 mm Chuck diameter: 200-315mm Spindl ...
Brake drum turning and grinding machine - see pictures More: Brake jaw grinding machine SCLEDUM SC 600 see picture below
Inv. Num. : 6521 Type: Compact A35 Producer: Kovosvit Generated: 2005 Parameters: bar diameter: 35 mm Maximum main spindle power: 7.5 kW Maximum spindle speed: 7000 1/min Number of CNC controlled axes: 8pcs Length: 2250 mm Width: 1480 mm Height: 1890 mm Weight: 3450 kg Equipment: Bar feeder (3 meters) LNS Sprint 555 Part of the sale: Collets Auxiliary head Polished holders VDI25/ER32 Axis tool holder VDI25 Straight and angled power tool holders Equipping the machine with tools (square 16x16 mm) The feeder is equipped with guide channels, pushers and reducing bushes
CATALOG NO. 6901 TECHNICAL DATA - max turning length 1200mm - max turning diameter 210mm - max turning diameter with a standard 90mm steady rest - max dimension of square material for turning with automatic feeding 100mm - 3 hydraulic copiers - additional 3 knives on hydraulic pistons (2 pcs) - 4 types of spindle rotation - automatic or manual operation of the machine - headstock spindle motor 9kW - 3kW hydraulic pump motor - diameter of the exhaust connection 90mm - dimensions for transport length/width/height 3700x2100x2000mm - weight about 3000 kg ADVANTAGES – Italian production – automatic hydraulic copier – original DTR documentation – unpainted – used lathe, very good condition Net price: PLN 69900 Net price: 15032EUR Net price calculated according to the exchange rate of 4.65 PLN/EUR (with larger exchange rate fluctuations, the price may cha ...
Turning Diameter 400 mm Turning Lenght 650 mm With C ,Y axes and subspindle Control Unit Fanuc 31i Can be inspected under power
34"/44" x 60" Mazak gap bed lathe Model: Rex, Specifications: Swing over bed ways . 34" Swing in removable gap .. 44" Swing over cross slide .. 24-1/2" Distance between centers 60" Hole thru spindle ... 4-1/16" Spindle nose D1-11" camlock Width of bed 22" Spindle speed range (16) 12 - 1200 rpm Longitudinal feed range . .00217" - .0331" ipr Cross feed range half of longitudinal setting Inch threading range (40) ... 4 - 56 tpi Metric threading range (23) . .5 - 7 mm Tailstock spindle travel 8" Tailstock spindle taper . #6mt Approximate floor space . 144"L x 60"W x 60"H Approximate weight .. 12,500 lbs
Ergomat TBC 60 - Multi-slide turning center - as good as new exhibition machine - Rod passage: 60 mm - Tool holder: VDI 25 Compact multi-carriage turning center with eight CNC axes, two-channel control and backside machining. Developed for the ready-to-use production of complex turned parts. - Fanuc 31i-TB dual-channel control - 8 CNC-controlled axes - 2 vertical shaped slides and piercing slides - CNC cross slide at the front - Rear CNC cross slide with servo-driven Sauter turret and driven tools - Tapping spindle integrated in the turret - Astonishingly short cycle times - Backside processing - Coolant device - Generously dimensioned working area for unhindered chip fall - Chip collector - Year of construction: 2021 Specifications: Rod passage: - Round material: 60 mm - Hexagonal material: 52 mm - Square material: 42 mm Main drive: - max. spindle speed: ...
Tip height: 102 mm Top width: 450 mm Spindle bore: 32 mm Reduction gear Links.-right rotation 2-stage drive Vario speed: 270-3000 rpm Knee circuit Turning diameter over bed: 200 mm Spindle nose: W 20 Tailstock Quill: MK 2 Dimension (Lxwxh): approx. 140 x 56 x 123 cm Weight: approx. 550 kg Accessories available Manual available The machine is located in a clean good condition!
CITIZEN CINCOM A20 VIPL CNC lathe built in 2006 ensures the highest precision and efficiency in the production process. During machining, the specially designed bed with its rigid structure and high thermal stability effectively reduces the heat impact, resulting in increased machine life and reliability. All of this, combined with a modular design with a reduced number of parts, makes the CINCOM A20 VIPL CNC lathe ideal for various types of production. Workpieces with a maximum diameter of 20 mm and a length of 135 mm are machined in 7 axes by a powerful main spindle which is synchronised with an AC motor, forming an electrospindle. A bushing driven by a separate AC motor is also synchronised with the machine’s main spindle. The operator’s panel consists of an intuitive FANUC 32i CNC controller, a memory card slot and an electronic wheel located next to the monitor designed to ch ...
