turning center used for sale

Turning Diameter 830 mm Turning lenght 750 mm Spindle speed 2000 rpm Controller FANUC-i Chuck size 24"

Key data: 356 mm, 406 mm, 4000 1/min

Machine Details Stock number 1105-04050 Machine Type: CNC Lathe - Inclined Bed Machine Make HAAS Type SL 15 Year of construction 2019 Condition Control type: CNC Control Haas Storage location HAGUENAU Country of origin Delivery time immediately Freight base from location Price Technical details Turning diameter 356 mm Turning length 406 mm Control Haas Chuck diameter 210 mm Passage 51 mm Circumferential diameter 480 mm Speed 4000 rpm Power 407 Nm Power 15 KW Tool Changer 10 VDI Gear stages 0 Total power requirement 25 kW Machine weight approx. 5 t Space requirements approx. 3.3 X 2 X 1.9 H m Information CNC HASS LINING DIA 210 MM SPAENEFOEDERER TAIlSTOCK

Details Turning diameter 165 mm Turning length 1000 mm Total power requirement 2 kW Turning diameter over bed 335 mm Rotary diameter via tool carriage 310 mm large turning diameter via cross slide 168 mm Bed width 250 mm Main spindle diameter 42 mm Main spindle nose CAMLOCK n-5 - DIN 55027 Morse taper 4 Spindle speeds 9 Speed range: 60-2000 rpm max. working feed 0-5000 mm/sec Rapid traverse 5 m/min Shaft diameter 48 mm Tailstock-Spindle Travel 140 mm Machine weight approx. 1100 kg Control CNC Control Name FANUC 21i/210i

Universal lathe of the Weiler brand suitable for tooling, fixture construction, training and mould making Tip Height : 280mm Speed :48-2500 rpm Tip height : 280 mm Circumferential diameter over bed : 570 mm Circulation diameter over face slide : 340 mm Center width : 1,000 mm Rhqel FULCRUM SHAFT Spindle head DIN 55027/DIN ISO 702-3 : Gr. 8 Spindle bore : 83 mm Spindle diameter in front bearing : 120 mm MAIN DRIVE Drive power 60 %/100 % ED : 15/12 kW Speed range : 1 – 2,500 rpm Number of speeds : infinitely variable FEED RANGE Number : infinitely variable Longitudinal : 0.001 – 10 mm/rev Plan : 0.001 – 10 mm/rev Longitudinal feed force : 10,000 N Feed force plan : 7.000 N Max. longitudinal rapid traverse speed : 6/3 m/min THREADING AREA Metric threads : 0.1 – 400 mm Inch thread : 56 – 1/4 TAILSTOCK Quill ...

Machine type: Lathe - cycle-controlled Manufacturer: WEILER Type E30 Year of manufacture 1991 Weiler control Country of origin Germany Additional information Cycle-controlled lathe HAMLET - E30 Technical details Turning diameter max. 330 mm Turning length 750 mm Weiler control Center height 165 mm Circumferential diameter over bed 330 mm Circulation diameter max. via face slide 160 mm Slide travel 180 mm Bed slide longitudinal travel 395 mm Main spindle: Speed range - main spindle 1 - 4,500 rpm/-1 Drive power - main spindle 9 / 11 kW Max. torque 165 Nm Spindle head DIN 55027 / 5 Spindle diameter in the vord. Bearing 70 mm Spindle bore 40 mm Usable rod diameter ( - ) mm Tool carrier: Type MultiFix Turning chisel shank cross-section 20 x 20 mm Tailstock: Quill stroke 110 mm Quill diameter 50 mm Tailstock mount MK 3 Feeds: Rapid traverse max. 10 m/min Fee ...

Kanteneinschlagmaschine / Turning-In Machine Hunkeler BE 110 Arbeitsbreite max. / Working width max. 1100mm Pneumatische Ausführung / PneumaticOperation Online-Video-Inspection by Skype-Video We would be very pleased with your visit - more machines on Stock Available Immediately - Can be inspect On Stock Emskirchen / Nürnberg - Can be test

Inv. Num. : 7997 Type: SC 3200 Producer: TITAN Created: GO 2020 Parameters: Control system: Sinumerik 840D SL Table diameter: 3000 mm Max. turning diameter: 3300 mm Motor power: 55 kW Max. workpiece height: 2260 mm Max. workpiece weight: 18000 kg Maximum table speed: 92 1/min Weight: 48000 kg

Key data: 3600 mm, 4200 mm, 4800 mm

Specifications Control Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,600 mm Circumferential diameter (max.) 4,200 mm Workpiece height (max.) 4,800 mm Total height of the machine 8,700 mm Maximum workpiece weight 80,000 kg. Table base Y Horizontal table displacement 2,000 mm Crossbar Vertical adjustment of the crossbeam in 100 mm increments 2,800 mm Crossbeam Support (Right) Horizontal adjustment support - 1,800 to + 2,200 mm Vertical displacement of the chisel slide valve 1,500 mm Cross-section of the chisel slide 240x240 mm Tool stations 20 pcs. Side Support (Right) Vertical adjustment support 2,800 mm Horizontal displacement of the chisel slide valve 1,000 mm Cross-section of the chisel slide 240x240 mm Turning diameter max./min. 4500/2500 mm Tool Changer Main Drive: Main motor power 105 kW Face plate speed  ...

General Manufacturer: Spinner Type: SB 32-V4 Year of Make: 2016 Control: Fanuc Series 32i Model B Travels: X 250 mm Z 285 mm Switch-on hours: 46,318 h Spindle Spindle speed: 8,000 rpm Spindle Passage: 32 mmin Dimensions and weight Dimensions: 2,100 mm x 800 mm x 1,600 mm Weight: approx. 1,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: C-axis Preparation Interface Bar Feeder Linear Tool Carriers Collet chuck

Workspace: - Travel in X/Y/Z: 220 / - / 710 mm - Center width: 700 mm - Tip height: 170 mm Main spindle: - Max. speed: 3000 rpm - Spindle connection: size 5 (DIN 55029) - Max. drive power: 5.3 kW Tailstock: - Inner cone: MK3 - Quill stroke: 120 mm - Inner cone of the quill: 50 mm

2 machines one 2003 and 2006 Pakert price 39,900 Circumferential diameter 320 mm Chuck diameter 203 mm Machining diameter 260 - 320 mm Machining length 180 - 530 mm Rod diameter 51 mm Spindle bore 61 mm Spindle speed 35 - 5,000 rpm Number of shots in the turret head 12 x 2 Control MATRIX 2 Travel - x 240 mm Travel - y 100 [+/-50] mm Travel - z1 440 mm Travel - z2 495 mm CNC Turning and Milling Center | MAZAK - MULTIPLEX 6200 IIY equipped with gantry loader

Universal CNC cycle separation machine of the brand Pinacho suitable for tooling, fixture construction, training and mold making Circumferential diameter 360mm Center width 1000mm Control Fagor 8055 Tailstock MK 3 Tool station Barufaldi 6-fold Speed 1-4000rpm Connection 380V - 5.5 KW

WE SELL AN STUNNING NICE CONDITION CNC BIGLIA WITH TOOLS AND ACCESSORIESS CONDITION IS AS ALMOST NEW. VERY LITLLE USED. FANUC SERIES 18-T Maximum turning diameter: 520 mm Maximum turning length: 500 mm Bar turning diameter: 80mm X axis travel: 210 + 5 Z axis travel: 500 + 10 Spindle speed: 4000 rpm Spindle motor: 11-15 Kw (50%) Spindle connection: ASA 6 Spindle hole: 80 mm Self-centering diameter: 250 mm Turret: number 12 stations Tailstock: CM 4 Dimensions: 3500 x 1670 x 1650 mm Weight: 4600 Kg HOLE TROUGH SPINDLE: 82 mm YEAR:1997

Universal CNC cycle separation machine of the brand Pinacho suitable for tooling, fixture construction, training and mold making Circumferential diameter 360mm Center width 1000mm Control Fagor 8055 Tailstock MK 3 Tool station Barufaldi 6-fold Speed 1-4000rpm Connection 380V - 5.5 KW

Inv. Num. : 8070 Type: Multiturn 3000 Producer: Colchester Created: 2005 Parameters: Control system: FANUC Maximum turning diameter over bed: 460 mm Maximum turning diameter over support: 270 mm Spindle diameter: 78 mm Motor power: 11 kW Maximum spindle speed: 2250 1/min Travel X: 296 mm Travel Z: 1530 mm Equipment: Owner Vacuum

Manufacturer: DMG Type: Sprint 42/10 Linear Year of Make: 2014 Technical data working space Max. travel X-axis: 50 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 120 mm Workpiece Max. workpiece diameter: 42 mm Max. workpiece length: 320 mm Max. bar passage: 42 mm Control: Fanuc Basic functions Sub-spindle Y-axis Accessories Bar Feeder Säneförderer Tool Holder Condition Perfect Availability Immediately after payment Terms and conditions of purchase: no guarantee, no warranty, no return Terms of delivery: Ex-works Terms of payment: 100% prepayment

HORIZONTAL LATHE DAEWOO PUMA TT1800SY :::TECHNICAL SPECIFICATIONS::: CNC Model: Fanuc - CNC Version: 18iTB - Main Spindle Nose: ASA 6 - Main Spindle Power: 22.4Kw Main spindle bar passage: 65mm - Turning diameter: 230mm - Turning length: 980mm - Main spindle speed: 5000 Number of tool turrets: 2 Number of tool positions for the first turret: 12 Number of Motorized First Turret: 12 First turret X-axis travel: 165mm Y-axis travel first turret: +- 50mm Z-axis travel first turret: 700mm Second turret X-axis travel: 190mm Second turret Z-axis travel: 720mm Sub-spindle: yes Spindle nose: ASA 6 Number of counter-spindle speeds: 5000 Counter spindle power: 22Kw Bar loader model and brand: Iemca Master 880 Chip conveyor: belt Machine equipment: device for unloading long pieces Set of fixed and motorized tool holders :::D DIMENSIONS AND WEIG ...

OKUMA HOWA Type ACT 4 CNC control Fanuc 10 TF Turning diameter 380 mm Circulation over bed 520 mm Turning length 750 mm Revolver 12 speed Spindle speeds 20 - 3500 rpm Fodder Tailstock Spindle bore 75 mm Feed adjustment by foot switch CAM connector

Key data: 400 mm, 1000 mm

Pinacho Mustang 200 - CNC lathe - Fagor 8055 CNC control - Operating modes: manual/cycle-controlled - 8-cavity tool turret - Year of construction 2001 Specifications Capacity: - Center height: 200 mm - Center width: 1000 mm - Permissible Ø over guide bed: 400 mm - Permissible Ø over longitudinal slide: 370 mm - Permissible Ø over cross slide: 210 mm - Bed width: 300 mm Headstock: - Bore main spindle: 65 mm - Main spindle nose: Camlock-n°6 / DIN 55027-n°6 - Morse taper of the main spindle: MK5 - Spindle speeds: 2 - Constant cutting speed: 0-750 / 750-3000 rpm Feeds: - Working thrust Z/X: 0 - 7000 mm/min - Rapid traverses Z/X: 10 m/min Tailstock: - Tailstock Ø: 58 mm - Tailstock shaft travel: 155 mm - Morse taper tailstock: 4 Engines: - Power main motor: 7.5 kW - Power DC motor Z-axis: 6.8 Nm - Power DC motor X-axis: 3.4 Nm - Motor pump power: 0.57 ...

Key data: 300 mm, 570 mm, 5000 1/min

Machine Details Stock-No. 1105-04044 Type of machine CNC Lathe Make MAZAK Type QT NEXUS 200 Year of manufacture 2009 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time immediately Freight basis ex work Technical details turning diameter 350 mm turning length 575 mm Diameter bar 76 mm swing dia. 475 mm control Mazatrol Fusion 640 T X-Axis 190 mm Z-AXIS 570 mm total power requirement 26/22 kW weight of the machine approx. 5 t dimensions of the machine approx. 3.4 x 1.8 x 1.9 m Additional information mazatrol fusion 640 t 2 AXIS tool eyes chip convoyer tailstock

max. turning diameter 500 mm max. turning length 1400 mm 12-station turret not driven

MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindl ...

5 axis machininng center (milling/turning from bar), Under power in our warehouse, MAKE CHIRON, MODEL MILL 800 5 axis, CNC Fanuc 18iMBS (5 simoultaneous axis 1), X, Y, Z (mm) 800 – 500 - 550, Rapids (Highspeed) 60 m/min, Swivelling head CNC controlled (B axis) +/- 100°, Turning spindle Peiseler, Milling spindle 12.000 giri / 140 Nm (v nota 2), Tools 65, Tool type HSK-A 63 DIN 69893, Tool-change time 1,5 sec (v nota 3), Table 1400x500, Max table load 1200 kgs, Coolant through spindle 70 bar (see note 4), CNC controlled clamping/rotating unit for 6th face machining (v. nota 5), Pressurised linear encoders, Swarf conveyor, Renishaw-ready, Y.O.M. 2006, Weight 7500 kgs, Turning package, Max dia 65mm, RPM: 15 / 4500, Max 42,5 KW / 90 Nm., Hydraulic clamping 800 Nm., Bar loader ILS-RBK- 10012 65, Diameters min/max 5/65 mm L= 600-1200 mm, Highspeed (2), 60m/min., Spindle 20-12.000 min.â ...

CNC lathe Daewoo Lynx 200 B CNC Fanuc 21t, 10 tool turret tailstock, bar feeder The machine can be seen under power in our warehouse (M i m u)

Surfaces of reference plates, roughness measures MASSI turning TGL 4763 Rz 0.4 μm - Rz 1.6 μm in wooden box Dimensions: 240 x 125 x 40 mm

Surfaces of reference plates, roughness measures MASSI turning TGL 4763 Rz 2.5 μm - Rz 10 μm in wooden box Dimensions: 240 x 125 x 40 mm

Surface reference plates, roughness measures MASSI turning TGL 4763 Rz 3.2 μm - Rz 80 μm in wooden box Dimensions: 345 x 125 x 40 mm

Surfaces reference plates, roughness measures MASSI turning TGL 4763 Rz 6.3 μm - Rz 80 μm in wooden box Dimensions: 240 x 125 x 30 mm

Pallet Turning Device FLOWER 2 x 1000 kg for Euro pallets 360° rotatable with locking to 0° and 180° Dimensions: 2200 x 1900 x 800 mm

Lathe chisel PAGUS 315 x 40 x 40 mm ( 315x40x40mm) length hardened area: 70 mm tip length: 55 mm depth tip: 15 mm New ! Dimensions: 315 x 40 x 40 mm

Key data: 330 mm, 730 mm, 3500 1/min

Stock number: 3953 CNC LATHE Manufacturer: DOOSAN, Type: S390 LM Aircraft NO.: LNV-1019, Year of manufacture: 2001 Specifications: Max. circumferential diameter 330 mm dia. Turning length 730 mm Turning over planing slide 580 mm dia. Main motor power 22 kw Main spindle speed range 3500 rpm Hole through drawing tube 77 mm dia. X axis movement 245 mm Z ash movement 750 mm Tool turret with 12 stations Powered stations revolver 1 12 pieces. Total power consumption 40 kva Control Fanuc 18I Fabr. Spindle operating hours 9482 hours Accessories: Hydr. Chuck main spindle 300 mm dia Chip conveyance. Tailstock Length: 6550 mm, Height: 2200 mm, Width: 2200 mm, Weight: 5000 kg

Inv. Num. : 8139 Type: QTN-200M Producer: MAZAK Created: 2005 Parameters: Control system: Mazatrol Fusion 640 T Nexus Maximum turning length: 538 mm Maximum turning diameter: 210 mm Maximum Spindle Speed: 35-5000 1/min Tool magazine: 12 pieces Maximum length of travel in the X-axis: 230 mm Maximum feed in the Z-axis: 575 mm Number of axes: 3 pieces Chuck Size: 8 (Kitagawa BB208) Power consumption: 37 kW Length: 2485 mm Width: 1780 mm Height: 1840 mm Weight: 4380 kg

Key data: 350 mm, 1250 mm, 2500 1/min

Stock number: 3954 CNC LATHE Manufacturer: Dainichi, Type: F35 - 1250 Machines NO.: 24350 , Year of manufacture: 1990 Specifications: Max. circumferential diameter 350 mm dia. Max. turn. About Bed 550 mm Dia. Turning length 1250 mm Turning over planing slides 400 mm dia. Main motor power 22 kw Main spindle speed range 25-2500 rpm Spindle bore 90 mm dia. Tool turret with 12 stations Accessories: Hydr. Chuck main spindle mm dia Various tool holders. Chip conveyance. Length: 3750 mm, Height: 1800 mm, Width: 1700 mm, Weight: 6500 kg

Key data: 420 mm, 1538 mm, 3300 1/min

Stock number: 3962 CNC LATHE Manufacturer: MAZAK, Type: QTN 350 MY NEXUS Machines NO.: 202640, Year of manufacture: 2008 Specifications: Max. circumferential diameter 420 mm dia. Max. turn. About bed 700 mm DIA. Turning length 1538 mm Main motor power 30 kw Main spindle speed range 3300 rpm Spindle bore 102 mm dia. C axis - head spindle movement 0.001 degrees Z Ash Movement 1607 mm Y axis 150 mm Tool turret with 12 stations Powered stations revolver 1 12 pieces. Motor Power Driving Tools 7.5 Kw Powered tools. 4500 rpm Controlled in X-Z-C-Y axes Accessories: Hydr. Chuck main spindle 300 mm dia Driving angle tools 2 pieces Driving Tools Straight 2 pcs. Various tool holders. Tool setter Chip conveyance. Delivery time: Feb. 2025 Length: 4300 mm, Height: 2400 mm, Width: 2600 mm, Weight: 8 ...

CNC controller: Mitsubishi M-720BM (MAPPS 2) Capacity X-axis travel mm: 260 Z-axis travel mm: 590 Turning length mm: 510 Max. turning diameter mm: ø: Ø356 Upper turret Tool holder: 12 Main spindle Speed spindle rpm: 5000 Drive power spindle kW: 15/11 Spindle bore mm: 73 Manufacturer: KITAGAWA Equipment Chip conveyor Signal lamp Tool measuring arm High pressure pump Workarea light 4th axis Interface for Bar feeder Rated power kVA Working time hours Under power: 7456 Spnidle: 5423 Basic machine dimensions / weight Length mm: 3495 Width mm: 2050 Height mm: 2230 Weight kg: 5800

2001 & 2002 HYUNDAI HIT 15 2X HYUNDAI HIT 15 turning machines equipped with QUICK LOAD portal and two stockers (loading and unloading) Both machines are currently working. Ordinary maintenance can be proved by invoices. Turning machine G1 Hyundai HIT-15 (single spindle with tailstock, no axis C) Year of manufacture: 2001 Turning machine G2 Hyundai HIT-15 (single spindle with tailstock, no axis C) Year of manufacture: 2002 Quick Load portal Year: 2003 Find more here - / Contact us at -

- Manufacturer: DMG MORI - Model: CLX 450 - Type of machine: Horizontal Turning Machine - Year: 2020 - Max Spindle Speed: 4000 RPM - Weight: 6400 kg - Power Requirements: - Power: 39 kVA - Max Current: 56 A - Max Voltage: 440 V ±10% - Frequency: 50/60 Hz - AC Voltage: 400 V - DC Voltage: 24 V Including the following equipment: - 13 rotary tool holders (coolant through, 5 radial and 8 face) by ALGRA/MT Marchetti - more than 20 steady tool holders for turning and boring tools by ALGRA - 4 bolted tool holders by SAUTER/ALGRA - a mechanically operated bar puller toolholder by KINTEK - a live center - balanced pressure clamping (able to grip thin walled parts) - sets plastic drawtubes for bar working in different diametrers - more than 50 sets of soft machined jaws - 5 sets of hard jaws for different range of diameters and inside/outside clamping by SMW - SMW special ring for soft jaw turn ...

Key data: 420 mm, 1524 mm, 3300 1/min

Stock number: 3963 CNC LATHE Manufacturer: MAZAK, Type: INTEGREX 400 III-S Machine NO.: 173882, Year of manufacture: 2005 Specifications: Max. circumferential diameter 420 mm dia. Max. turn. About Bed 850 mm Dia. Turning length 1524 mm Main motor power 30 kw Main spindle speed range 3300 rpm Drilling through drawing tube 102 mm dia. C axis - head spindle movement 0.001 degrees Y axis +/- 115 mm B Axis Movement -30/+195 degrees B axis spindle speed 12000 rpm B axis spindle effect 18.5 B axis tool system Capto C6 Sub-spindle C axis - counter pindle movement 0.001 degrees Engine power sub-spindle 26/22 Kw Total Power Consumption 99.9 kva Control Mazatrol 640 Fabr. Spindle Hours 7167 Hours Controlled in 6 Axes Accessories: ATC Tool magazine with 40 stations Hydr. Chuck main spindle 300 mm dia Hydr. Chuck Subspindle 300 mm dia  ...

CNC turning-milling center Emco Hyperturn 65 Powermill SMYB Commissioning 7/2019 At call! Siemens 840D-SL Shopturn Main spindle BigBore spindle passage 76mm KK8 - 4,000 1/min Sub-spindle KK6 - 5,000 1/min 40-speed chain magazine HSK-T63 Turret bottom VDI30 / Sauter Electronic handwheel Emco Tool Breakage and Wear Gear milling Shopturn Expansion Pack 5-axis simultaneous machining Energy management for Sinumerik OPC UA / Siemens interface 3D machine model Emco Standard Bar Feeder Interface Machine Status Lamp LED Multiflow Cleaning Gun Oil Mist Separator Belt filter system with IKZ Main Spindle Clamping Hook Hainbuch Clamping Top Mini Combi Ax Hoist Sub-spindle Schunk 185mm THW-plus with hard jaws The options list is complete! No interest in dealer enquiries! No separate dealer price! WB mechanics GmbH is a precision mechanics workshop that markets its ...

Key data: 1350 mm, 11000 mm

CNC Lathe Make Swift CNC Fanuc 21i-MB Inspection Under Power Year 1978 Between centers .. 11,000 mm Swing over Bed .. 1,350 mm Swing over Carriage .. 1,000 mm Chuck dia .. 1 ,200 mm Max. Workpiece weight …….. 20 ton Motor power ………………………… 40 kW RPM …………………………………………….150 c/w 2 steadies

CNC turning-milling center Emco Hyperturn 65 Powermill SMYB Commissioning 10/2017 At call! Siemens 840D-SL Shopturn Main Spindle SuperBigBore Spindle Passage 95mm KK8 - 3,500 1/min Sub-spindle KK6 - 5,000 1/min Milling spindle HSK-T63 12,000 1/min / new milling spindle 2024 40-speed chain magazine HSK-T63 Turret bottom VDI30 / Sauter Electronic handwheel Emco Tool Breakage and Wear Gear milling Shopturn Expansion Pack 5-axis simultaneous machining Energy management for Sinumerik OPC UA / Siemens interface 3D machine model Emco Standard Bar Feeder Interface Machine Status Lamp LED Multiflow Cleaning Gun Oil Mist Separator Belt filter system with IKZ Main Spindle Clamping Hook Hainbuch Clamping Top Mini Combi Ax Hoist Sub-spindle Schunk 185mm THW-plus with hard jaws The options list is complete! No interest in dealer enquiries! No separate dealer price!  ...

equipped with Iemca Boss 332E-r/32 new in 2007 - Fanuc 18i-TB control - chip conveyor - machinery still in production will arrive in our stock at the end of January.

Description HERSTEL Vertical Lathe VDM 120 Details Year of construction 1998 Control Siemens Sinumerik 840C Flexos Max. turning diameter 1,300 mm max. circulating diameter 1,400 mm (option 1,500 mm) Axis stroke Z/X axis 1,000/1,000 mm (option 1,000/1,500 mm) Dimensions to top edge of spindle 940 mm Main Spindle Bearing Circulation Lubrication 2-speed manual transmission autom. Range switching Main spindle motor 76/115 kW Clamping device diameter 1,600 mm Chuck pick-up centering diameter 790 mm Max. feed force Z-/X-axis 25,000 N Axis speed Z-/X-axis 0.01 - 14,000 mm/min. Disc turret with B-axis Tool holder modular system UTS 50 Main dimensions approx. 6,250 x 3,300 x 4,500 mm incl. documentation

:::TECHNICAL SPECIFICATIONS::: CNC Model: Fanuc - CNC Version: 18-T - Spindle Nose: ASA 6 - Spindle Power: 18.5Kw - Turning Diameter: 310mm Turning length: 200mm - Main spindle speed: 3500 - Sub spindle speed: 3500 Number of tool positions for the first turret: 12 Number of fixed tool positions for the first turret: 12 Number of second turret tool positions: 12 Number of fixed tool positions for the second turret: 12 :::D DIMENSIONS AND WEIGHT::: Length: 2800mm Width: 2240mm Weight: 7000Kg

:::TECHNICAL SPECIFICATIONS::: CNC model: Fanuc - CNC version: 21 TB - Spindle nose: ASA 6 - Spindle power: 11Kw - Turning diameter: 240mm Self-centering diameter: 160mm - Turning length: 130mm - Main spindle speed: 4000 - Sub spindle speed: 4000 Number of tool positions for the first turret: 10 Number of second turret tool positions: 10 Fast feeds for linear axes X Y Z: 24m/min Gantry loader: yes Chip conveyor: belt

gebr. CNC Long Short Turning/Milling Center with B-Axis Hours: 7200 Control: Fanuc 31i-A Processing length: max. 250 mm Number of controlled axes: 7 axes and max. 5 axes simultaneously B-axis: 0°-130° freely programmable Bar passage: Ø 3 mm to max. Ø 20 mm Drive power main spindle: 3.7 kW Drive power sub-spindle: 2.2 kW Main spindle speed: 10,000 rpm Sub-spindle speed: 10,000 rpm C-axis: main and counter spindle Number of linear beams: 2 pieces Total number of tools: 35 pieces Dimensions (LxWxH) in mm: 2,110x1,200x1,885 Weight: 3,300 kg Conversion from longitudinal to short turning Deep Hole Drilling Stations NAKANISHI high-speed spindle Rear carriage with Y-axis Cross Drilling Rear Conveyor Fire extinguishing system FMB Bar Feeder Minimag 20, YOC 2012 The machine can be viewed under power by arrangement. Changes and errors in the technical data and informa ...

Specifications: first-class condition, only approx. 9000 operating hours Fanuc, High Performance CNC Control Series 31i-B5, 3-channel control, 3 turrets, 12 CNC axes, (X1/Z1/Y1/C1/X2/Z2/Y2/YA2/C2/X3/Z3/Y3), Rapid traverse speed 30 mm/min, Rod diameter max. 38 mm, Turning length max. 350 mm, Main spindle, speed max. 7,000 rpm, C-axis 0.001 degrees, Main spindle drive power 11 kW Sub-spindle speed max. 7,000 rpm, C-axis 0.001 degrees, Sub-spindle drive power 7.5 kW Turret speed max. 5,700 rpm, (with appropriate tool holder also higher) Turret drive power 4 kW Tool holder stations for a total of 30 (10 per turret) (prepared for internally cooled tools) Tool holder set, (non-driven) Guide bush unit (pull system, JBS) Oil cooler unit High-pressure conveyor (with integrated high-pressure unit) type Müller combistream CS 3 Coolant use: Oil Weight: 6.25 tons Dimensions: ( ...

Year of Build 2003 (0450) FANUC 16i-T control with 9 axes, 9 axes (X/C1/Y/E/B/A/X/c2), Rod Ø max. 13 mm Turning length max. 205 mm, Main spindle, speed max. 12,000 rpm, C-axis, Sub-spindle with collet, speed max. 12,000 rpm, C-axis, 4-fold tool holder 3 cross drilling rigs 8-station turret various additional tool holders, quills, Fire extinguishing system Kraft und Bauer Parts Conveyor Belt Manuals Operation/Programming/Electrics/Spare Parts Operating Tool Machine Up to 29 turning tools and up to 19 operated tools Tools possible 9.0KVA Fuel tank capacity 170L Charging magazine FMB Turbo 2-16 /3200/A / from Ø2- Ø20 mm / Coolant Insert of Machine: Oil Machine dimensions: approx. 2700 x 1400 x 1700 [mm] Machine weight: approx. 1700 [kg] Dimensions loading magazine: approx. 4300 x 600 x 1800 [mm] Weight loading magazine: approx. 700 [kg] Dimensions of the perip ...

gebr. CNC Swiss lathe STAR SR20R, built in 2001 Control, Fabr. Fanuc, 18i-T Series, 7 axes (X/Z/Y/C1/X1/Z1(C2), Rod Ø max. 20 mm, Turning length max. 205 mm, Main spindle, speed max. 10,000 rpm, C-axis 0.001 degrees, Sub-spindle with collet, speed max. 8,000 rpm, C-axis, Tool holder for a total of 19 tools (linear tool holder, front apparatus, reverse side machining), Parts Conveyor Belt, Standard Guide Bushing Unit Charging magazine FMB turbo 3-26/3200 / A /, year 2001 Coolant use of the machine: oil. Kraft & Bauer extinguishing system The machine can be viewed under power by appointment. Changes and errors in the technical data and specifications as well as Subject to prior sale! used CNC sliding headstock lathe STAR SR20R, year 2001 control, make Fanuc, series 18i-T, 7 axes (X/Z/Y/C1/X1/Z1(C2), bar-Ø max. 20 mm, turning length max. 205 mm, main sp ...

Control, Fabr. CINCOM MITSUBISHI Meldas 6 axes (X1/Z1/Y1/C1/X2/Z2), Rod Ø max. 16 mm, Turning length max. 200 mm, Main spindle, speed max. 10,000 rpm, C-axis 0.001 degrees, Sub-spindle Ø max. 16 mm, Counter spindle speed max. 10,000 rpm, incl. spindle indexing Tool holder for a total of 17 tools (linear tool holder, front apparatus, reverse side machining), Parts Conveyor Belt Conveyor Fire extinguishing system Charging magazine IEMCA Genius 118/3200 Year of construction 2005 The machine can be viewed by appointment. Changes and errors in the technical data and specifications as well as prior sale reserved! control, make CINCOM MITSUBISHI Meldas 6 axes (X1/Z1/Y1/C1/X2/Z2), bar-Ø max. 16 mm, turning length max. 200 mm, main spindle, speed max. 10,000 rpm, C-axis 0,001 degree, counter spindle Ø max. 16 mm, Counter Spindle Speed max. 10,000 RPM, incl.  ...
