trough used for sale

Stainless steel trough screws for all types of bulk materials Length: 4 m Width: 70 cm Width of the drive: 85 cm Height: 50 cm Length: 4 m Trough screw has two augers with a drive. In very good condition!

New Water trough for Heidelberg KORD 64

; NEW

Bühler trough chain conveyor new, still packed in wooden boxes. 18 pieces trough chain conveyor, different lengths and outputs 10 to 60 t/h immediately available Mob. +491715213204

Trough length approx. 7300 mm Trough width approx. 280 mm Trough depth approx. 400 mm Inlet approx. 640 x 280 mm Spout approx. 320 x 280 mm Taker distance approx. 160 mm Taker width approx. 180 mm Chain gears Drive gear motor SEW-Eurodrive R67-DVE100M4 230/400 V; 8.0/4.6 A; 50 Hz; IP54 Power: 2.2 kW; 1455/62 rpm Total approx. 7400 x 750 x 1000 mm

Bühler trough chain conveyor new, still packed in wooden boxes. 18 pieces trough chain conveyor, different lengths and outputs 10 to 60 t/h immediately available Mob. +491715213204

Trough chain conveyor TKF Redler up to 120 to/Hused Trough width inside approx.: 300 mm Trough depth inside approx.: 320 m Trough length approx.: 6800 mm Inlet opening approx.: 300 x 400 mm Exhaust opening approx.: 300 x 600 mm Taker distance approx.: 130 mm Drive motor NORD 220/380 V, 1.5 kW, 1410/18 rpm by replacing the engine, power can be increased Total length approx.: 6900 mm Other names: TKF, Reedler, Chain Conveyor

400 V / 50 Hz

Auger

Meng troughs

Triple flour-collecting screw conveyor in steel design Total length 6.2 m, outlet at 5.2 m Screw diameter 150 mm 1 m counter-rotating thread, slope 105 cleaning flaps, Wooden lid with folding boxes, 2 intermediate bearings each, motor 1.5 kw

completely stainless steel Track width 800 mm 2 engines "JVM GmbH & Co.KG", type JV 156-250 Opening grille: dia. 14-22 mm Power: 2 x 0.95 kW Dimensions : ± 2,700 x 1,600 x 1,000 mm

Mixing tub, mixing bowl, mixing trough -Bathtub depth: 470 mm -Contents: approx. 220 l -Corners: rounded -Internal dimensions: 800 x 610 x D 470 mm -External dimensions: 840/860/H640 mm -Weight: 32 kg

Volvo quick switch connection, Content 2.2m3 Auction-ID: A1-40132-345

Trough screw, washing screw, screw conveyor used Conveying length: approx. 6500 mm Diameter: approx. 700 mm Slope: approx. 400 mm Wing height: approx. 210 mm Wing thickness approx. 4 mm Stainless steel Geared motor SEW 3 kW 22 rpm 220/400 V Dimensions approx. 7800 x 1800 x 1800 mm The screw can be converted according to your wishes by our own special machine construction. All articles are checked for function before delivery, if technically possible! Changes and errors in the technical data, information and prices as well as prior sale reserved.

Grain conveyor belts capacity 150 t/h, belt width 650 mm, MZN 650, galvanized, also for hall filling 2 pieces 60 meters, stationary 1 drum motor each 2 pieces 60 meters revisable LEFT 7 RIGHT, 2 drum motors each, 2 displacement drives, IPE 200 mm rails, trailing cable 1 piece 30 meters, with drum motor 2 pieces 20 meters, with drum motor 1 piece 26.6 meters with regulating gear motor 15 KW, was receiving conveyor with many rollers 2 pcs 5 meter drum motor 2 pieces 7.5 meter drum motor Pictures are welcome to be sent. Dismantled, immediately available. Tel. 01715213204

Redler 25 meters length Trough chain conveyor Horstkötter TTF 25 Engine 1,5 kw 84 rpm Good condition

Dosing screw conveyor BOSCHE 150 mm diameter Length 1.30 m Engine 1,5 kw 32 rpm right-hand thread, slope 110, at the outlet slope 150, Sliding Inlet 270 x 680 mm, outlet 170 x 170 mm Review and test run in our qualified workshop done Good condition

Stainless steel screw conveyer length: 15 meters. Diameter: 500mm. With drive electric motors, APV valves, protective covers and accessoiries. Dismantled into 3 lengths.

Vibratory trough, type FRU 10/2-0-ER, built in 2011 Magnetic vibrator, type ER 42, built in 2011 - Swing width: 1.5 mm - Connected load: 230 V, 50 Hz, 2.5 A Condition: well-maintained, fully functional Availability: immediately

Two identical Drytee drying machines are available. Useful chamber dimensions X/Y/Z: 700mm/1400mm/1150mm, external dimensions X/Y/Z: approx. 1350mm/1600mm/1800mm, heating capacity: 36kW, operating temperature: 90°C, heating medium: thermal oil, heating medium temperature: 140°C, air circulation rate: 3x5200m³/h. Documentation available. On-site inspection is possible.

Mixing troughs plastic white 3 pcs. plastic shelf approx. 80x160 cm, turquoise, small parts lying in this room

350 litre, Stock number: T1354, Litre: 350, Material: Stainless steel AISI 304, In stock: Yes, Amount in stock: 1 pc., Item: Trough, Lying: On legs, Dimensions: L 4080 x W 400 x H 450 mm., Other: With wall mountings

Conveyor belt, trough conveyor belt, trough conveyor GASUS type DG 300-5/2,75Belt conveyor, conveyor belt, belt conveyorFabrig Nr: D-7321915 Year of construction 1996Effective length: 2.75 metersBelt width: 230/300 mmDeflection pulley diameter: 210 / 230 mm (rubberized drive roller)Deflection pulley width: 400 mmBelt speed: approx. 15 meters/min. Motor power: 0.75 kWNerg connection: 400 volts, 50 Hz - Drive via SEW geared motor- Inlet hopper 550 x 430 mm- Metal idler rollers with maintenance-free ball bearings- Strip tension via threaded spindles

Conveyor belt, trough conveyor belt, trough conveyor presumably GASUS type FB 400 x 5500Belt conveyor, conveyor belt, belt conveyor Fabrig Nr: F-02071168 Year of construction 1996Working length: 5.5 metersBelt width: 400 mmDeflection pulley diameter: 225 mmDeflection pulley width: 450 mmBelt speed: approx. 30 meters/min. Motor power: 1.5 kWNerg connection: 400 volts, 50 Hz - Drive via tubular motor- Inlet hopper 600 x 400 mm- The support stations are 2-part troughed- Metal support rollers with maintenance-free ball bearings-

Condition: tested, fully functional Availability: immediately Width approx.: 350 mm Length approx.: 1570 mm

A vibratory finishing trough Trowal for the aging of parquet strips is available. Maximum product length: 2400mm. An on-site inspection is possible.
