trough used for sale

Conveyor belt, trough conveyor, trough conveyor GASUS type DG 300-5/2.75 Belt conveyor, conveyor belt, belt conveyor Fabrig No: D-7321915 Year of construction 1996 Usable length: 2.75 meters Belt width: 230/300 mm Deflection roller diameter: 210 / 230 mm (rubberized drive roller )Pulley width: 400 mm Belt speed: approx. 15 meters /min. Motor power: 0.75 kW Mains connection: 400 volts, 50 Hz - Drive via SEW Geared motor inlet hopper 550 x 430 mm- Metal rollers with maintenance-free ball bearings - Belt tension adjustable via threaded spindles- Rubber conveyor belt with corrugated edge - Conveyor belt has grooves - stable frame made of sheet steel- for horizontal or slightly rising transport of bulk materials Overall dimensions L x W x H: 3000 x 950 x 700 mm Weight: 400 kg good condition; used

Conveyor belt, trough conveyor, trough conveyor probably GASUS type FB 400 x 5500 Belt conveyor, conveyor belt, belt conveyor Fabrig No: F-02071168 Year of construction 1996 Usable length: 5.5 meters Belt width: 400 mm Deflection roller diameter: 225 mm Pulley width: 450 mm Belt speed: approx. 30 meters /min. Motor power: 1.5 kW Mains connection: 400 volts, 50 Hz - Drive via tubular motor - inlet hopper 600 x 400 mm - The support stations are recessed in 2 parts- Metal rollers with maintenance-free ball bearings - Band tension adjustable via threaded spindles- Rubber conveyor belt smooth - stable tubular frame made of steel - cover plate can be dismantled via conveyor belt- for horizontal or slightly rising transport of bulk materials Overall dimensions L x W x H: 6400 x 850 x 950 mm Weight: approx. 700 kg good condition; used

Trough chain conveyor TKF Redler up to 120 to/Hused Trough width inside approx.: 300 mm Trough depth inside approx.: 320 m Trough length approx.: 6800 mm Inlet opening approx.: 300 x 400 mm Exhaust opening approx.: 300 x 600 mm Taker distance approx.: 130 mm Drive motor NORD 220/380 V, 1.5 kW, 1410/18 rpm by replacing the engine, power can be increased Total length approx.: 6900 mm Other names: TKF, Reedler, Chain Conveyor

Cooling principle: water cooling (for drying pasty solids), capacity: 4,0 cbm/h, trough length: between 6,7 and 7.9 m, screw diameter: 400 mm, cooling jacket diameter: 560 mm, double-walled, wall thickness trough: 5 mm, helical geared motor 4 kW, conveyor trough coat, cooling shroud, front plates, Auger and Auger blades made of V2A steel

Trough length approx. 7300 mm Trough width approx. 280 mm Trough depth approx. 400 mm Inlet approx. 640 x 280 mm Spout approx. 320 x 280 mm Taker distance approx. 160 mm Taker width approx. 180 mm Chain gears Drive gear motor SEW-Eurodrive R67-DVE100M4 230/400 V; 8.0/4.6 A; 50 Hz; IP54 Power: 2.2 kW; 1455/62 rpm Total approx. 7400 x 750 x 1000 mm

Stainless steel trough screws for all types of bulk materials Length: 4 m Width: 70 cm Width of the drive: 85 cm Height: 50 cm Length: 4 m Trough screw has two augers with a drive. In very good condition!

Bühler trough chain conveyor new, still packed in wooden boxes. 18 pieces trough chain conveyor, different lengths and outputs 10 to 60 t/h immediately available Mob. +491715213204

Bühler trough chain conveyor new, still packed in wooden boxes. 18 pieces trough chain conveyor, different lengths and outputs 10 to 60 t/h immediately available Mob. +491715213204

Trough auger used overhauled and functional Conveying line 1.6m with 2 outlets Trough width inside 17cm Lid for auger not included

70 Meter Trough Chain Conveyor Galvanized, T20, Plastic Floor, 14 Electric Gate Valves, Geared Motor 22 KW, 28 RPM 28 meter trough chain conveyor galvanized T20/30, left - clockwise rotation, 5 mechanical slides, 5 hinged boxes D250 mm Tel. 01715213204

System includes (1) Round Trough Vibrator Spaleck VA1451, working container volume: 140l, stretched container length: 2320mm, speed: 1460/min, container cross-section: 235mm, motor power: 1.3kW, space requirement: 2m², empty weight: 440kg, max. operating weight: 890kg, with two directions of rotation, operating hours: 149h. Operating weight: 890kg, with two directions of rotation, operating hours: 149h (2) Rotary Trough Dryer Spaleck VAT33, working container volume: 230l, heating power: 3.6/7.2kW, motor power: 1.6kW, empty weight: 700kg, max. operating weight: 1.2t, designed for automatic drying/separation process, optional pendulum flap for multiple workpiece circulation, with documentation, maintenance overdue, on-site inspection is possible.

New Water trough for Heidelberg KORD 64

Trough screw, washing screw, screw conveyor used Conveying length: approx. 6500 mm Diameter: approx. 700 mm Slope: approx. 400 mm Wing height: approx. 210 mm Wing thickness approx. 4 mm Stainless steel Geared motor SEW 3 kW 22 rpm 220/400 V Dimensions approx. 7800 x 1800 x 1800 mm The screw can be converted according to your wishes by our own special machine construction. All articles are checked for function before delivery, if technically possible! Changes and errors in the technical data, information and prices as well as prior sale reserved.

Trough chain conveyor used VECOTR Aandrijvingstechniek B.V. Rotterdam Refurbished and functional Total length approx. 13.5m x width 0.46m An outlet on the drive side (but can be replaced) Can be shortened in approx. 2.5m pieces (the conveyor chain can also be easily adjusted) Drive motor SEW 4KW 8,8A

Mixing pan, mixing bowl, mixing tub, mixing trough -Tub depth: 470 mm -Contents: approx. 220 l -Corners: rounded -Dimensions: 840/860/H640 mm -Weight: 32 kg

Description: Trough width approx. 700 mm Approx. Onsite Dimension. (l x w x h): 1,700 x 1,700 x 1,100 mm, weight approx.: 250 kg

Description: Trough width approx. 700 mm Approx. Onsite Dimension. (l x w x h): 1,700 x 1,700 x 1,100 mm, weight approx.: 250 kg

Description: Trough width approx. 1150 mm Approx. Onsite Dimension. (l x w x h): 2,600 x 1,900 x 1,400 mm, weight approx.: 400 kg

Description: Trough width approx. 1150 mm Approx. Onsite Dimension. (l x w x h): 2,600 x 1,900 x 1,400 mm, weight approx.: 400 kg

Description: Trough width approx. 700 mm Approx. Onsite Dimension. (l x w x h): 1,700 x 1,700 x 1,100 mm, weight approx.: 250 kg

Description: Trough width approx. 1150 mm Approx. Onsite Dimension. (l x w x h): 2,600 x 1,900 x 1,400 mm, weight approx.: 400 kg

Description: Trough width approx. 1150 mm Approx. Onsite Dimension. (l x w x h): 2,600 x 1,900 x 1,400 mm, weight approx.: 400 kg

Description: Trough width approx. 700 mm Approx. Onsite Dimension. (l x w x h): 1,700 x 1,700 x 1,100 mm, weight approx.: 250 kg

Description: Trough width approx. 1150 mm Approx. Onsite Dimension. (l x w x h): 2,600 x 1,900 x 1,400 mm, weight approx.: 400 kg

Description: Trough width approx. 700 mm Approx. Onsite Dimension. (l x w x h): 1,700 x 1,700 x 1,100 mm, weight approx.: 250 kg

Description: Trough width approx. 700 mm Approx. Onsite Dimension. (l x w x h): 1,700 x 1,700 x 1,100 mm, weight approx.: 250 kg

Description: Trough width approx. 700 mm Approx. Onsite Dimension. (l x w x h): 1,700 x 1,700 x 1,100 mm, weight approx.: 250 kg

Normal steel, length. 9.00 m, Diameter: 420 mm, outlet: round D = 300 mm Drive: Gear motor 4.0 kW with max. 100 UPM

Mild steel, length. 10.20 m Diameter: 420 mm, spout: 300 X 300 mm,. Drive: gear motor 7,5 kW Max. 135 RPM

; NEW

Width: 800 mm Length: 7,000 mm SEW gear motor

Triple flour-collecting screw conveyor in steel design Total length 6.2 m, outlet at 5.2 m Screw diameter 150 mm 1 m counter-rotating thread, slope 105 cleaning flaps, Wooden lid with folding boxes, 2 intermediate bearings each, motor 1.5 kw

Linear feeder, Consisting of 2 chutes of the same type, Air pressure controlled valve at the end, Each chute 220 V - 50 hz - 0.55 A,

Max. bulk material density: 875kg/m³, grain size: 2-3mm, conveying width/ height: 400/ 6340mm, with documentation, was maintained regularly.

TECHNICAL SPECIFICATIONS Manufacturer: GIPO Designation: Feed chute / vibrating chute Type: FA 1235 Width: 1,200 mm Length: 3,500 mm Propulsion: Vibration motor Drive power: 2 x 5.6 kW SPECIFIC COMMENT - Incl. rubber buffer

Description: 1 x ROTHERM KK 50, year 2016, load capacity 125 kg, approx. 1500 x 800 x 1000 mm, 1 x RR INDUSTRIETECHNIK RUK-150, year 2020, serial number 37182, load capacity 2000 kg, approx. 1700 x 1350 x 1200 mm Approx. Onsite Dimension. (l x w x h): 2,200 x 1,500 x 1,200 mm, weight approx.: 250 kg

Description: serial number 801325 center distance between each spindle 32 mm minimum and maximum distance between the vertical heads 96-2000 mm minimum lenght of the piece 240 mm max. working width 2500 mm min.working width between the vertical units 96 mm boring capacity maximum 27 cycles/min the drilling depth is adjustable 0-70 mm conveying speed 57 m/min spindle rotations per minute 2800 g/min engine capacity 2,5 (horizontal) 1,5 plus 1,5 (vertical) HP pressure 5-8 atm air consumption with 6 boring units 50 liter / cyle air consumption per head 7 liter / cyle feeding nominal tension 400 V, 50 Hz nominal current 30,8 A maximum overload current 0,104 kA Approx. Onsite Dimension. (l x w x h): 3,710 x 1,800 x 1,500 mm, weight approx.: 1,540 kg, Serial Number of Manufacturer: 801,325

Cooling screw trough screw double-walled heated or coolable used Manufacturer: BARL Maschinenbau GmbH Type: KT0803F17T50 Built: 2015 Total dimensions of the trough screw approx. 9.5 x 1.3 x 1.6 m Trough length approx. 8000 mm Trough width outside approx. 450 mm Trough depth approx. 600 mm Conveyor length approx. 7000 mm partly double-walled and can be heated or cooled with water Steel screw with cooled shaft Spiral thickness approx. 8 mm Diameter approx. 400 mm Spiral height approx. 100 mm Slope approx. 160 mm Shaft approx. 200 mm geared motor 1.5 kW 6.8 rpm 220/380 V substructure Steel construction approx. 11 x 2.5 x 0.2 m Total dimensions: approx. 11 x 2.5 x 2 m Subject to changes and errors in the technical data, dates and prices as well as intermediate sale.

Trough screw wash screw, sieve basket screw stainless steel used Trough length: approx. 3500 mm Trough width inside: approx. 55 mm Screw diameter: approx. 490 mm Slope approx. 250 mm Thickness approx. 4 mm Wing height approx. 155 mm Stainless steel trough and screw variable gear motor 2.5 kW Total dimensions: approx. 4400 x 700 x 1450 mm All articles are checked for function before delivery, if technically possible!

Offer 23186 Specifications: - Capacity approx. 15 l - Trough - inner diameter approx. 320 mm - Trough - inner height approx. 180 mm - Trough dimensioning outside approx. W 550 x H 220 mm - 2 trough inserts - Space requirement approx. W 600 x H 600 x D 600 mm - Drive 400 V / 0.7 / 1.0 hp - Weight approx. 100 kg

MATEC easily from our own development and production running lightly and quietly and transport bulk material and individual loads up to 250 kg with minimal energy over long distances up to 12 m at a time with a hand drill 300 w power consumption. The combined forced - and promotion of resonance stores the kinetic energy in the spring and must compensate for only the frictional resistance of the material. Sawdust, shavings, gravel, Earth, grain, hay and grass, etc. are exactly same speed transported with approximately 17 m / min. by means of Frequenzumforner the speed can be adjusted. The transport and screening in a single operation with a built-in sieve base perforation on request MATEC Vibrorinne standard Trough width inner 500 mm Trough height inner 260 mm current trough length 2500 mm (can front and rear to 1.5 m be extended without additional support) In addition current ...

System: Used trough screw conveyors Coil height: 280 mm Spiral distance: 290 mm Trough height: 325 mm Trough length: 5500 mm Width: 440 mm Overall length: 6700 mm Engine: Greifenberger 5,5 kW Other: Center bearing

Solid pump sewage sludge pump Saxlund with double hydraulic aggregate 90Kw + 18.5 Kw used Solid pumping system consisting of 2 x solid piston pumps (duplex pump) oil-hydraulic drive/hydraulic unit. For reliable conveying of sludge of all kinds. Manufacturer: Saxlund 2 cylinder solid piston pump / double pump: Type: 119083 Komm.Nr. 2925-30/59410/2 Operating pressure: max. 280 bar 100/63/1000 Outer diameter: 140 mm Inner diameter: 13 mm Dimensions: 1x approx. 3,700 x 700 x 1,300 mm Dimensions: 1x approx. 3,750 x 850 x 1,800 mm Drive hydraulic unit: Square Bosch Hydraulics Saxlund 9710026 HA1-0 4069 No. SAX.2925-30 Built: 1998 V = 1200 P = 90 kW P = 18.5 kW Dimensions: approx. 2,400 x 1,700 x 1,900 mm ---------------------------------------------------------------------- ---------------------------------------------------------------------- ----------------  ...

Apple pomace drying as a precursor for pectin production at albi Berghülen Capacity: up to 1.5 tons of pomace per hour, built in 1977 and 1992 Manufacturer: Kunz AG, Dintikon CH Function The apple coming from the winery became damp pomace with a transport screw into a pomace transport system open at the top transported diagonally upwards, and then via a further transport screw, D= 600 mm in the all-round running round drying chamber, D = 360 mm, L = 11,400 mm. With an internally welded bucket in the drying chamber, the still damp pomace moves intensively with the hot air. At the same time, a gas burner flame and the furnace blow the hot gases into the drying chamber. Length burner and oven together: 6,500 mm The pomace waste, which is dried and crushed at the same time, is processed by an ejection chamber located directly at the end of the drying chamber with a t ...

Trough trowal vibrator manufactured by WALTHER TROWAL type V 65Technical specifications:Inside trough size: 500 x 400 x 350 mmTrough opening: 500 x 220 mmExternal dimensions approx: 2000 x 1000 x 1230 mmWith- adjustable water supply (pump)- Trough opening tap for removalused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

System: Used screw conveyor Type: W-DA100LR-D Performance: 1415 r/min Shaft diameter: 90 mm Shaft size: 280 mm Coil height: 300 mm Spiral distance: 180 mm Trough height: 320 mm Trough length: 4200 mm Width: 450 mm Total width of the drive: 910 mm Motor: 3.0 kW Other: product-contacting parts stainless steel

Fresh concrete recycling plant BIBKO RAM 20/ used manufactory: Bibko type: RAM 20 YOM: 2001 Capacity: ca. 12 m³/h system washing trough, trough length 2500 mm separating layer 0,25 mm with discharge conveyor screw (new) overhauled/reconditioned and exactly aligned - gear reconditioned (overhauled) and sealed - all bearings are new - buckets and scraper exactly aligned - 1 pcs feed hopper / used - 1 pcs agitator (wastewater) with console / used - 1 pcs control unit / used -for the full automatic control of the complete plant - 1 pcs gallows-shaped pipe/ used Facility is fully equipped, clean and primed. The final painting according to customer's request. location: South Germany available: march 2024 offer and all price are net and ex stock without guarantee and/or guarantee, mistakes and/or false representations reserve, purchasing like ...
