tripan used for sale

1 x lathe Feinbau PM 1 FZ Facilities: - Hand lever cross support with Tripan quick-change system - additional steel holder single steel holder on support rear - Electric drill rig for thread cutting - collet tension with tension ingenuity Technical data: - Spindle passage: 23 mm - Spindle speeds: 700/1400/2800 rpm (left/right) - Peak height: 110 mm - Tip width: 160 mm - Groesster circulation over bed:220 mm Accessories: 20 x drawer tension erases partly new (1 - 20 mm round) 1 x Interchangeable Holder Tripan with 2 different casts 1 x collet + suit rod in tailstock Operating instructions (Copy) Machine can be inspected under electricity.

High precision tower SCHAUBLIN type 150 TECHNICAL SPECIFICATIONS: Year: 1998 Number of axes: 2 X-axis stroke: 180 [mm] Z-axis stroke: 600 [mm] Z-axis fast forward speed: 4000 [mm/min] Tip distance: 600 [mm] Peak height: 150 [mm] Diameter allowed above the bench: 340 [mm] Permissible diameter above trolley: 177 [mm] Spindle nose: CAMLOCK D 1-4'' Inner pin cone: CM5 Spindle for clamping pliers: B32 Spindle passage diameter: 40 [mm] Mini speed. Pin: 55 [rpm] Maximum speed. Pin: 3000 [rpm] Pin power: 4 [kW] Cone: CM5 Metric pitch range: 0.25 - 14 [mm] English pitch range: 112 - 1/2" [nets/inch] Modular pitches: 0.12 - 7.5 [modules] Watering tray capacity: 29 [l] Installed capacity: 6 [kVA] Supply voltage: 400 [V] Dimensions: 1730 x 970 x 1300 [mm] Weight: 1250 [kg] EQUIPMENT INCLUDED: x1 visualization HEIDENHAIN type ND780 (2 axes) x44 SCHAUBLIN B32 clamp ...

Parallel Lathe WEISSER HEILBRONN Between points: 1100 mm Maxi Ø on bench: 440 mm Maxi Ø over saddle: 230 mm Cone: CM4 Spindle diameter: Ø 45 mm Spindle speed: from 45 to 2000 RPM TRIPAN Turret 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Auto feeds longitudinal + transversal Lubricant pump Voltage: 380 V Dimensions (L x W x H): 2500 x 1300 x 1500 mm Weight: approx 2 T

Parallel Lathe GEMA LZ 160 Between points: 1000 mm Maxi Ø on bench: 310 mm Maxi Ø over saddle: 180 mm Maxi diameter in brocken bed: Ø 420 mm x Length 200 mm Spindle diameterØ 44 mm Spindle speed: from 48 to 1500 RPM TRIPAN Turret Supplied with 2 tool holders 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock: CM3 Auto feeds longitudinal + transversal Lubricant pump Voltage: 380 V Dimensions (L x W x H): 2100 x 800 x 1300 mm Weight: approx 1,3 T

1 x L+Z lathe Colchester Mascot 1600/600 Built: c.1975 Very stable lathe. Ideal machine for locksmiths or agricultural machine mechanics. Technical data: Turning diameter over crimson: 710 mm Turning diameter over bed:432 mm Turning diameter via support:267 mm Turning length: 1,000 mm Spindle speeds:20 - 1600 rpm Spindle bore:76 mm Drive motor:5.6 kW Feeds: 0.6 - 10 mm/u Metric threads: 40 (0.4 - 14 mm incline) Machine weight approx.:2000 kg Room requirements approx.:l:2.65 x w:1.1 x h:1.6 m Accessories: 3 - Jaw lining UVA 310 mm 4 Set of change jaws Bfraed8ae0 Tripan quick-change system 4 x Interchangeable holder running counter tip in tailstock (MK 5) Countertip in spindle Alternating wheels Manual Mudguard complete documentation The machine can be inspected at our warehouse in Reichenbach under electricity.

turning diameter over bed: 330 mm turning diameter over slide rest: 170 mm turning length: 800 mm centre height: 155 mm centre distance: 800 mm spindle bore: 38 mm spindle turning speed range: 24 - 2800 U/min spindle head: DIN 55022 Gr. 5 feeds - longitudinal: 0,026 - 1,253 mm/U feeds - cross: 0,013 - 0,628 mm/U dia. of leadscrew: 24 mm lead of leadscrew: 6 mm tailstock taper MT: 3 tailstock quill stroke: 110 mm total power requirement: 3 kW weight of the machine ca.: 800 kg dimensions of machine L x W x H: 1,88 x 0,87 x 1,32 m Accessories: 3-jaw chuck RÖHM 160 mmø, changing tool post TRIPAN with various inserts, collet fixture with various collets, solid steady, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Parallel Lathe MULLER & PESANT Between points: 2500 mm Maxi Ø on bench: 520 mm Maxi Ø over saddle: 280 mm Maxi diameter in brocken bed: 700 mm Spindle diameter: Ø 56 mm Spindle speed: from 12,5 to 1000 RPM TRIPAN Turret 3-jaws chuck Ø 250 mm Tailstock CM4 Auto feeds longitudinal + transversal Lubricant pump Voltage: 380 V Dimensions (L x W x H): 4000 x 1500 x 1600 mm Weight: approx 3,5 T

Key data: 178 mm, 485 mm, 100 mm

Turning length: 485 mm Rotation diameter: 178 mm above bed / 100 mm over cross slide Spindle Passage: 15.5 mm Spindle speeds: 25 - 2,150 rpm. Tool Container: Tripan Container Equipped with: - Rohm 3-jaw chuck with different jaws - Zahrade Set - Collet set -Operating instructions Country of origin: UK Machine LxWxH: 1180 x 700 x 1200 mm Machine weight: 170 kg
