tos whn 13 used for sale

Clamping surface of the table: 1000x7000 mm Longitudinal movement of the table - x-axis: 5000 mm Transverse movement of the table - z axis: 2000 mm Vertical table movement - y axis: 1250 mm Spindle taper: ISO 50 Spindle diameter in front bearing: : 100 mm Number of table T-slots / spacing: : 7/140 -/mm Maximum torque: : 1200Nm

Table dimensions X 2000mm Y 1000mm Z 1000mm, Heidenhain 426 control system, machining head type K (smooth machining in five axes), year of manufacture 1998. The machine is in operation and can be tested.

Max. grinding diameter mm 160 Max. grinding length mm 250 Max. workpiece weight kg 10 Internal grinding device true Dimensions LxWxH mm 1900x1100x1500 Machine weight kg 1400. The grinder has been completely overhauled (beds, guides, bearings, complete electrical installation, …….)

Circulating diameter 160 mm. Distance between spikes 250 mm Max. workpiece weight 10 kg. Dimensions LxWxH 1900x1100 mm. Machine weight 1350 kg. The machine is in good technical condition, testing possible upon agreement.

Machine dimensions: 3500x2300x2100 mm Max. grinding length: 1000mm Max. grinding width: 400mm Standing weight: 4000 kg. The machine can be tested after prior agreement. Hydraulic repair required.

The machine is in good technical condition. Circulating diameter: 295mm Center distance: 1000mm Accessories: grinding wheels, flange, balancing stand, bezel, dresser Weight: 2550 kg Upon prior arrangement, inspection in operation possible

The machine is in good technical condition, it is possible to inspect it in operation by agreement. Circulating diameter: 320 mm Distance between spikes: 1000 mm Max. workpiece weight: 300 kg Power of the main electric motor: 9.5 kW Dimensions L x W x H: 4890 x 2320 x 1720 mm Machine weight: 5100 kg.

Description of the machine: Circulating diameter . 320 mm Distance between spikes . 1500 mm Max. workpiece weight . 350 kg Power consumption . 16 kVA Machine dimensions l x w x h . 4600 x 1990 x 1760 mm Machine weight . 5300 kg

The machine is in good technical condition. Revolving diameter: 295mm Distance between the tips: 630mm Upon prior agreement, the possibility of inspection while in operation.

grinding diameter 630 mm grinding length 4000 mm max. dia. of grinding wheel 630 mm spindle speed 8 - 315 mm voltage 380V workpiece weight 3000 kg Technical details: grinding diameter 630 mm grinding length 4000 mm max. dia. of grinding wheel 630 mm spindle speeds 8 - 315 mm voltage 380 V workpiece weight 3000 kg

The machine is in good technical condition, after the complete GO in 2012, since then it has been used minimally. Max. grinding diameter: 280 mm Max. grinding length: 630 mm Max. workpiece weight: 65 kg Longitudinal feed: 760 mm Power of the main electric motor: 4 kW Dimensions lxw: 2800x1600 mm Machine weight: 2250 kg. Accessories: digital measuring, diamond wheel.

BPH 20 NA machine for sale, year 1966. GO performed in 2004 by Procházka-Moravec. Also installed Heidenhain measuring. Table clamping surface 200 x 630 mm. max. revolutions 2440/min.

Location: Poland Description: The machine is in good technical condition, inspection possible upon agreement. Circulating diameter . 295 mm Distance between spikes . 1000 mm.

This machine is a numerically controlled and cross rail elevating double column type vertical boring and turning mill. Is a machine with two rail heads. One, on the right side is turning head and the other, on the left side is a milling head. The right head is utilized exclusively for turning work and can withstand heavy duty operation, and left performs boring and milling work. After the turning is completed, both heads can be performed without changing the machine set-up. These features, coupled with table indexing and milling feed, assure versatility machining capabilities. The cross rail is guided by the slideways of the two columns. Electro-hydraulic clamping clamping devices assure clamping of the cross rail at the desired position. Highly accurate horizontal straightness is guaranteed by the simple and stabilized method of utilizing the compensation beam inside the cross beam. ...

MCFHD 80 CNC - TOS KUŘIM Machining center Medium correction made: 2021 System: TNC 407 Warranty: 6 months Availability: 1 month from order IN GEOMETRIC ACCURACY BY MANUFACTURER MCFHD 80 CNC - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 4,490 mm Overall width: 5,700 mm Overall height: 3,885 mm Gross weight: 20,500 kg Total power consumption: 75 kVA Working range: X-axis longitudinal stroke 1,000 mm Transverse stroke of the Y axis 750 mm Vertical stroke Z axis 750 mm Positioning the pallet clamping base ° 360 x 1 Working spindle: Cone of the cavity in the spindle ISO 50 Number of steps / speed range continuously / 9 - 2,000 n. min-1 Ex. engine spindle. at 60/100% ED 23.5 / 27.5 (AC) kW Max. twisting mom. on the spindle. 1,000 Nm X - Y / Z feed range: Number of degrees / range continuously / 1 - 3,000  ...

FSQ 80 (100) O / A3 CNC - TOS KUŘIM Table milling machine, table length 3m System: Heidenhain / optional Availability: according to the selected repair Warranty: according to the selected repair FSQ 80 (100) O / A3 CNC - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 7,760 mm Overall width: 4,360 mm Overall height: 3,400 mm Total weight: 18,000 kg Total power consumption: 40 kVA Working range: X-axis longitudinal stroke 3,000 mm Transverse stroke of the Y axis 1,000 mm Vertical stroke Z axis 900 mm Spindle head (head O): Max. performance 22 kW Speed range 11 - 2,500 rpm Number of speed steps smoothly H-V machining, 2.5o rotation X - Y / Z feed range: Number of degrees / range continuously / 1 - 5,000 mm.min-1 Y - Z / X rapid traverse 10,000 / 15,000mm.min-1 Table : Table area 800 x 3,000 mm Max.  ...

FCQV 63 B CNC - TOS KUŘIM Table milling machine System: TNC 407 Warranty: 6 months Availability: 2 weeks from order We have the machine in stock FCQV 63 CNC B - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 5,900 mm Overall width: 3,600 mm Overall height: 3,400 mm Gross weight: 15,500 kg Number of places in the tool magazine: 40 pcs Total power consumption: 65 kVA Working range: X-axis longitudinal stroke 1,500 mm Transverse stroke of the Y axis 630 mm Vertical stroke Z axis 630 mm Working spindle: Cone of the cavity in the spindle ISO 50 Number of steps / speed range continuously / 20 - 3,500 n / min Ex. spindle motor 27.4 kW Max. twisting mom. on the spindle. 1,000 Nm X - Y / Z feed range: Number of degrees / range continuously / 1 - 2,000 mm / min Rapid traverse 15,000 -15,000 / 10,000 mm / min  ...

Year of production: 1986 Serial number: 50 166 N and the machine was overhauled in 2003 with modernization of electrical control. The machine was equipped with a new SIEMENS automatic controller and new SIEMENS drives. GENERAL CHARACTERISTICS OF THE MACHINE The basic feature of the machine is a fixed portal, a sliding table. The portal has a height-adjustable crossbar, which is equipped with one or two vertical headstocks in the VFS 160 design. Furthermore, the portal is equipped with one or two side (horizontal) VFS 160 headstocks. These types of headstocks can be fitted with additional spindle heads, up to 4 pieces available. The clamping surface of the machine consists of two connected clamping tables, which after disconnection can be used individually (only one is always functional). Clamping table Dimensions of 1 table 2 2,000 x 4,000 mm Total length of connect ...

Year of production / SO / GO: 1987 / - / 1997 Technical parameters of the machine: Maximum torque on the spindle - 1000 NMMaximum feed force in the X, Y, Z axes - 25,000 NMMaximum workpiece weight - 2,000 kgTotal table area (with grooves) - 630 x 2200 mmNumber of table T-slots - 5Width and T-pitch Table grooves - 22 x 100 mmTable height from base - 900 mmLongitudinal table stroke X - 1,500 mmTransverse table stroke Y - 630 mmVertical headstock stroke Z - 630 mmSpindle taper - ISO 50Spindle diameter in front bearing 110 mmSpindle face distance from table clamping surface - 150 -780 mmSpindle motor - regulatingMotor power S119.3 kW, S327.4 kWSpindle speed range - 20-3 500 n.min-1Reed range 1-5 000 mm.min-1Speed ​​feed in X, Y axes - 15 m.min-1Speed ​​feed in Z axes - 10 m.min-1Total length - 5 900 mmTotal width - 3 400 + 3 600 mmTotal height - 3 400 mm.

FGS 50/63 - TOS KUŘIM Cantilever milling machine Horizontal / vertical axis milling New electrical switchboard + Print. panel Digital measuring of axes Overhaul 2021 Warranty: 12 months Availability: 3 weeks from order STATE OF THE MACHINE IN GEOMETRIC ACCURACY BY MANUFACTURER FGS 50/63 - Technical data: Basic machine data: Manufacturer: TOS Kuřim Overall length: 3,060 mm Overall width: 3,350 mm Overall height: 2,500 mm Total weight: 6,500kg Total power consumption: 23 kVA Working range: X-axis longitudinal stroke 1,400 mm Transverse stroke of the Y axis 630 mm Vertical stroke Z axis 500 mm Working spindle: Cone of the cavity in the spindle ISO 50 Number of steps / speed range 18 / 35.5 - 1,800 n / min Ex. spindle motor 15 kW Max. twisting mom. on the spindle. 2,500 Nm X - Y / Z feed range: Number of degrees / range 16/10 - 1 800 / 2.5  ...

Tailstock, counter bearing for dividing head, dividing attachment -Tip height: 135 mm -Recording: MK2 -Drawing with the photos -Price: per piece -Number: 2 pieces -Dimensions: 200/75/H145 mm -Weight: 5 kg

The machine is in good technical condition, it is possible to test it by agreement. Work table 1800 x 1800mm. Machine dimensions: 7150 x 6280mm, height 5164mm. Main engine 80kW.

spindle diameter: 130 mm x-travel: 3500 mm y-travel: 2500 mm z-travel: 1250 mm w-axis: 800 mm b-axis: 360 ° spindle turning speed range: 1000 U/min transmission ratio: 4 Control: Heidenhain type: 355 table surface area: 1800x2200 mm Table load: 12000 kg spindle taper ISO: 50 width of T-slots: 22 mm T-slot - distance: 160 mm Feed: 1-6000 mm/min table rotating: 1,5 U.min-1 total power requirement: 80 KVA weight of the machine ca.: 36 t dimensions of the machine ca.: 7,7x7,2x4,9 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Type: WHN 13A Parameters: 130 mm, 2000 mm Manufacturer: Tos Čelákovice Year of production / SO / GO: 1979 / - / - Description: Heidenhain control system Cross arrangement of beds Four axes + rotary table Retractable working spindle Machine designed for universal engineering production Heidenhain control system Axis strengthening hydraulically Machine parameters: X-axis 3510 Y axis 2040 Z axis 1200 W 800 axis incl. reinforcement, 600 without reinforcement Clamping surface of the table 1800 x 1800. The machine is connected, with the possibility to test. Bearings and damaged wheels must be replaced in the headstock.

TOS WHN 130 MC used machine Specifications System Heidenhain TNC 426 Working range Spindle diameter 140 [mm] Taper in the spindle ISO 50 Table transverse adjustment (X) 3000 [mm] Vertical headstock adjustment (Y) 2000 [mm] Vertical travel (Z) 1250 [mm] Spindle stroke (W) 560 [mm] 2X Clamping surface 1800 x 1600 [mm] Speed range 10 - 2500 [rpm] Main motor output 37,0 [kW] Max. workpiece weightƒ 8000 [kg] Accessories Tool changer for 60pcs Tool cooling Chip conveyor

This TOS WHN 13.4A from Czech Republic was manufactured in 1985, is operated through a Heidenhain 355 control unit. It is equiped with 4 axis.

CNC table drill TOS WHN 13 with quill Built in 1991 Control FAGOR 8055 Travel xyzw 3500/1850/1330/600 mm Table size 1800 x1800 mm. Machine immediately available and available. Dismantling and loading onto suitable trucks is cost-effective. Installation and commissioning on request.

Control system Heidenhain TNC 415 Spindle diameter 130 mm Tapered hollow spindle ISO 50 Spindle speed range 10 to 1500 rpm Table transverse (X): 3500 mm Rolling headstock stand for (Y): 2000 mm Longitudinal displacement rack (W): 1250 mm Eject working spindle (Z): 800 mm Table load 12 000 kg Machine weight: 36 000 kg

The machine is in good technical condition. Working spindle diameter: 90mm Transverse table adjustment: 1120mm. After agreement, the possibility of testing. Accessories: digital measuring, angles.

The machine is in good technical condition. Working spindle diameter: 90mm Transverse table adjustment: 1120mm accessories for the machine include a column crane A tour is possible by prior arrangement.

X=3500mm Y=2000mm Z=1250mm W=800mm H=360° spindle 130 mm, ISO 50, max. 1600 rpm table 1600 x 1800 mm with a load of 12000 kg with Siemens electric and CNC Heidenhain TNC 415B Oil cooled: Schimpke. Dismantled. The machine has been used very little = in very good technical condition.

equipped with ATC = automatic toolchanger with 60 positions equipped with AVO = device for automatic pallet/table changer Transversal movement of table (X): 2000 mm Vertical movement of headstock (Y): 1250 mm / 1150 with pallet Horizontal movement of the stand (Z): 1000 mm Movement of spindle (W): 500 mm with Heidenhain measuring probe Longitudinal travel X-axe: 2000 mm Cross travel Y-axe: 1250 mm Travel Z-axe: 1000 mm Dimensions clamping space- table: 1400 x 1250 mm Power on spindle: 37 kW Admission in millinghead (ISO): ISO 50 (dia 125 mm) Max speedrange: 10 > 2800 rpm Control: Heidenhain TNC 426 Power needed (KVA): 78 kVa / 82 kW

Catalog No. : 6346 Type: WHN 13 A Producer: TOS Made in: 1980 Characteristic: Control system: MEFI CNC 859 Length of the working table: 1600 mm Width of the working table: 1800 mm Maximum rotary speed of the spindle: 2800 1/min X-Axis travels: 2000 mm Y-Axis travels: 1600 mm Z-Axis travels: 1200 mm Power of the spindle: 38 kW Machine weight: 34.600 kg Replaced ball screws. Measuring each IRC axis separately. Drives separately each XYZ axis.

spindle diameter: 130 mm x-travel: 3500 mm y-travel: 2000 mm z-axis: 1300 mm Table dimensions: 1800x1800 mm Control: ECS 2101 number of spindle speeds: 12,5 - 800 (63x) voltage: 380 V Control: total power requirement: 25 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC control HEIDENHAIN TNC 355 Spindle diameter 100 mm x-travel 1130 mm y-travel 1250mm z-travel 950 mm Flange diameter of the hollow spindle 221.44 mm Table clamping area 1120 x 1000 mm Spindle mount ISO 50 size Mass of the workpiece 3000 kg Quill stroke 650 mm Spindle speeds 0 - 1500 rpm Feed speeds 4 - 2500 mm / min Rapid traverse 4.5 m / min Total power requirement 32kVA Weight of the machine approx. 14 t Dimensions L x W x H 4.75 x 2.45 x 3.03 m

Inv. Num. : 6345 Type: WHN 13.4.C Producer: TOS Produced: 1988 Parameters: Control system: MEFI CNC 836 Work table length: 2200 mm Work table width: 1800 mm Spindle drive power: 37 kW Maximum spindle speed: 2800 1/min Travel X-axis: 2000 mm Travel Y-axis: 1600 mm Travel Z-axis: 1200 mm Machine weight: 32.000 kg Replaced ball screw. Measurement of each ESSA axis separately. Drive for each XYZ axis.

spindle diameter: 130 mm x-travel: 2000 mm y-travel: 2000 mm z-travel: 1250 mm w-axis: 800 mm Control: Heidenhain type: TNC 135 table surface area: 1800x1800 mm Table load: 12000 kg power capacity: 30 kW 09-08 machine number The techn. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About usMore than 400 of our own machines in the warehouseMore than 12,000 m² of storage space, crane capacity 70 tMore than 1000 items Accessories for your workshopYou want to sell machines, production lines or your company,then contact us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 6702 Type: WHN 9B Producer: TOS Created: 1975 Parameters: X-axis travel: 1250 mm Y-axis travel: 900 mm Z-axis travel: 1000 mm Equipment: DRO

Inv. Num. : 6737 Type: WHN 11 Producer: TOS Created: 1970 Parameters: Working table length: 1250 mm Working table width: 1250 mm Maximum table load (uniform): 8000 kg Maximum spindle speed: 900 1/min X-axis travel: 1600 mm Y-axis travel: 1250 mm Z-axis travel: 1000 mm Spindle power: 34 kW Spindle diameter: 110 mm

Inv. Num. : 6762 Type: WHN 9 B Producer: TOS Created: 1975 Parameters: Repair history: 30.8.2021: Repair of the rotary table 31.5.2021: Repair of the lubrication system for guide surfaces 18.02.2021: Adjustment of the rotary table coupling 22.10.2020: Replacement of the sealing elements of the hydraulic cylinder of the tool clamping Replacement of the tool support bearings Replacement of hydraulic hoses for tool clamping 21.10.2019: Replacement of the electromagnetic clutch 09.10.2019: Brush holder - carbon 31.1.2017: adapted quick-shift clutches with replaced spark plugs and shift knobs on the "Y" axle 11.03.2017: Lockshift clutch

CNC Heidenhain TNC 426 with handwheel HR 410 X = 3500 mm Y = 2500 mm Z = 1250 mm W = 800 mm Table dimensions 1800 x 2200 mm Spindle diameter 130 mm Max. spindle speeds 2500 RPM External coolant 2-axis manual milling head TOS HUR 50 year 2004 almost unused.

Key data: 130 mm, 3000 mm, 2000 mm

Inv. Num. : 6957 Type: WHN 13 Produzent: TOS Erzeugt: 1976 Parametern: Arbeitstischlänge: 1800 mm Arbeitstischbreite: 1800 mm Maximale Tischbelastung (gleichmäßig): 120.000 kg Verfahrwege X-Achse: 3000 mm Verfahrwege Y-Achse: 2000 mm Verfahrwege Z-Achse: 800 mm Spindeldurchmesser: 130 mm DRO

spindle diameter: 130 mm x-travel: 3500 mm y-travel: 2000 mm z-axis: 1250 mm w-axis: 800 mm b-axis: 360 ° output: 85 KVA table-size: 1800x1800 mm table load: 12 t spindle taper ISO: 50 table rotation: 360x0,0001 ° spindle motor: 37 kW spindle turning speed range: 1500 U/min feed range: 4-8000 mm/min electrics - voltage/frequency: 400 / 50 V/Hz weight of the machine ca.: 35 t dimensions of the machine ca.: 7x7x6 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control Heidenhain TNC 407 Year 1996 Workpiece weight 2200 kg X=1250mm Y=1125mm Z=950mm Machine can be checked under power

Inv. Num. : 7260 Type: WHN 13.4 A Producer: TOS Created: 1986, GO 2003 Parameters: Control system: MEFI CNC 859 Work table length: 1800 mm Work table width: 1600 mm Maximum table load (uniform): 12 t Maximum spindle speed: 1098 1/min X-axis travel: 3000 mm Y-axis travel: 2000 mm Z-axis travel: 800 mm W-axis travel: 1250 mm Spindle diameter: 130 mm Cone: ISO 50 Machine height: 3900 mm Machine length: 6200 mm Machine width: 5930 mm Machine weight: 32 t

Description: The machine is in good technical condition. Working spindle diameter: 110mm Table clamping surface: 1250 x 1250mm Machine dimensions lxwxh, 5290x4063 mm. Machine weight, 27000 kg By prior arrangement, the possibility of a tour in progress.

Machine weight: 38000 kg Working spindle diameter: 130 mm Spindle taper: ISO 50 Spindle speed: 1800 rpm Table clamping surface: 1800 x 1600 mm Transverse table movement - x axis: 3500 mm Longitudinal table movement - z axis: 2000 mm Vertical table movement - y axis: 2500 mm

Weight of the machine: 32000 kg Total power of the machine:: 37 kW Working spindle diameter: 130 mm Cross table movement - x axis: 2000 mm Vertical table movement - y axis: 2500 mm Machine dimensions LxWxH: 7480x6300x4800 mm

The WHN 13.8B CNC boring machine is in good technical condition, HEIDENHAIN control system. The year of GO 2001 Total machine input:: 37 kW Working spindle diameter: 130 mm Spindle taper: ISO 50 Spindle speed: 2500 rpm Clamping surface of the table: 1800x2200 mm Transverse movement of the table - x-axis: 3500 mm Longitudinal movement of the table - z axis: 1200 mm Vertical table movement - y axis: 2500 mm

Year of Manufacture/SO/GO: 1987/-/2001 Description: The machine is in very good technical condition, dismantled, stored in storage. 5 persons X (table lift) 5000 mm Y (vertical lift of headstock) 2000 mm Z (longitudinal displacement of the column) 1250 mm W (spindle travel) 800 mm Engine power: 37 kW Spindle speed range: 1.25-900 rpm Rapid feed: 4000 mm/min Spindle diameter: 130 mm Table: 1800 x 1800 mm Machine weight: 12000 kg Spindle taper: ISO 50. control system HEIDENHAIN
