125465367 112

HOFLER PRIMA H 1000 E for sale
Gear Grinding Machines


Gear max. wheel diameter 1000 mm gear width 530 mm max. module 18 min. module 1,5 max. number of teeth 195 min. wheel diameter 300 mm
used machine

Gear max. wheel diameter 1000 mm
gear width 530 mm
max. module 18
min. module 1,5
max. number of teeth 195
min. wheel diameter 300 mm
1994
Price
  FR   request
125460772 210

SCM Method K for sale
Window production centre


Tenoning spindle: 1 St.Number of milling agregates: 5 St.Spindle diameter: 50 mm In order to sell still in useSCM METHOD K Machining center for windows and doorsTechnical specificationsMax. Working length: 2800 mm(using ...


Tenoning spindle: 1 St.
Number of milling agregates: 5 St.
Spindle diameter: 50 mm
In order to sell still in use

SCM METHOD K Machining center for windows and doors

Technical specifications
Max. Working length: 2800 mm
(using the stops)
minute Workpiece length: 200 mm
(clear pin dimension)
minute Workpiece height: 30 mm
Max. Workpiece height: 140 mm
Tenoning speed: 4/16 m / min
Feed rate: 3-15 m / min

Crosscut saw 4 kW with motor horizontal positioning over free
programmable axis control
Speed 3000 rpm
Saw blade diameter 400 mm, bore 80 mm
Extraction nozzle diameter 120 mm
automatic engine brake

Slotted spindle 7.5 kW with

Spindle diameter 50 mm
Spindle clamping length 620 mm
Spindle stroke under table 575 mm
Speed 3500 rpm
Max. Tool diameter 320 mm
upper bearings
Motorized vertical positioning via freely programmable axis control
automatic counter-timber beam
automatic engine brake
automatic star delta connection
Suction nozzle diameter 2 x 160 mm

1st profile spindle 5.5 kW clockwise and counterclockwise
(Synchronization) with
Spindle diameter 50 mm
Spindle clamping length 320 mm
Spindle stroke under table 265 mm
Horizontal adjustment 60 mm
Spindle speed 6500 rpm.
Tool diameter min./max. 100/220 mm
Motorized vertical positioning via freely programmable axis control
automatic engine brake
Extraction nozzle diameter 150 mm

2. Profile spindle 5.5 kW clockwise with
Spindle diameter 50 mm
Spindle clamping length 320 mm
Spindle stroke under table 265 mm
Horizontal adjustment 60 mm
Spindle speed 6500 rpm.
Tool diameter min./max. 100/220 mm
Motorized vertical positioning via freely programmable axis control
Extraction nozzle diameter 150 mm
automatic engine brake

Gear milling unit 5.5 kW with
Spindle diameter 50 mm
Spindle clamping length 160 mm
Spindle stroke 100 mm
Horizontal adjustment 60 mm
Speed 6500 rpm.
Tool diameter min./max. 100/200 mm
pneumatic single stroke programmable via control
Timed horizontal feed-in for insert milling for the execution of
non-continuous grooves via CNC control
Extraction nozzle diameter 150 mm
automatic engine brake

Glass saw 2,2 kW with
Saw shaft diameter 25 mm
Saw blade diameter max. 220 mm
Saw shaft clamping length max. 22 mm
Speed 5000 rpm.
Extraction nozzle diameter 50 mm
automatic engine brake

Motorized, height-adjustable roller feed with
closest roll spacing
Motor power 1.1 kW

complete with
-CE Compliance
- Crosscut saw, tenon cutting and slot part horizontally infinitely programmable
- Slot part 620 mm spindle length, anti-clockwise
- Programmable vertical movement via ball screws
- motor-driven tapping table movement
- automatically trailing splitter wood for all slot tool positions
- Workpiece clamping for single / double wood operation with
automatic pressure drop protection
- precise swiveling tap table +/- 0 - 60 °
- Extendable telescopic length stop with automatic
Differential control, working length 2800 mm
- Programmable vertical movement via ball screw
in position 2, 3 and 4
- Horizontal positioning on manually programmable
4-fold revolver to operate from the front of the machine
for positions 3, 4 and 5
- Continuous roller feed, swiveling for light
Tool change, with additional feed roller for
Milling and motorized height adjustment according to scale
- Glass bead saw with pneumatic vertical positioning on manual
adjustable 4-fold revolver,
Forced guidance of the glass retaining strip with non-return valve, use of the
Glass bead saw automatically controlled via cycle
- automatic synchronization - immersion function of the first
Profile spindle for tear-free milling of sash frames,
Horizontal positioning on manually programmable
4-speed turret to be operated from the front of the machine
- extendable support rail for large format sash frames
- Gear milling unit with pneumatic horizontal positioning,
Use of the glass bead cutting saw via automatic cycle of the
machine program
Vertical positioning on manually programmable 4-fold turret
- CNC machine control via programmable logic controllers
electronics (PLC) type CONTROL 20
- Motor protection switches for all motors
- Operating tools, operating instructions
- Weight 3600 Kg

special accessories

Motor amplification 11 kW in Pos. 2, 3, 4

(Technical information according to the manufacturer - without guarantee!)



This ad was created with MODUL MWS - the software solution of LogoTech.

3,000 €
    request
125465350 901

ZUGMASCHINE T1) Steyr Daimler Puch 760 a for sale


last off Code: BH-80088 First registration: 18.12.1979 elapsed. Hours of operation: 4.208 h Output: 44 kW Displacement: 1,140 cc Test badge: no inspection sticker must be acquired by the buyer pursuant to Â&se ...


last off Code: BH-80088
First registration: 18.12.1979
elapsed. Hours of operation: 4.208 h
Output: 44 kW
Displacement: 1,140 cc
Test badge: no inspection sticker must be acquired by the buyer pursuant to § 57a, authorities
Drive type: Diesel
FIN: 295.05-3685
Equity / total weight: 2,517/4,500 kg
Color: grey
Facilities: with headlamps above installed, safety signal lamp
Tyres: Max. Axle load front 1,750 kg, allowed axle load rear 2.300 kg, documentation: licence of types of available key: 1
Comments to the State: motor does not start, gearbox is leaking, axes are leaking, corrosion game on the steering linkage and steering column, have strong bearing clearance at rear axle, brake lines and hoses partly rusted and cracked, Total failure cable fire, batteries, frame has some significant corrosion damage, hydraulic system results in oil loss, paint largely bleached out, div. Rust all around vehicle, abrasions, and dents all around vehicle, rust spots on wheels,
Expressly stated, that no complete inventory and check the functionality of the auction object performed. There is still the possibility that there are significant defects. To learn about the condition and the efficiency of the auction object, the possibility of the visit and this is highly recommended. The auctioneer assumes no responsibility for the quality, condition, completeness, accessories, special properties, open or hidden defects and other damages. Please note also the general terms and conditions of auction.
System number: 2420-0-350-0014 and 2420-0-550-0005

Price
    request
125460774 210

WEINIG Unicontrol 6 CNC Spindeln for sale
Window production centre


Tenoning spindle: 1 St.Number of milling agregates: 5 St.Spindle diameter: 50 mmweight: 4300 kgWeinig Unicontrol 6 with CNC-spindle with full options/features!Cut-off saw-----------------motor: 3 KWspindle diameter 40 mm ...


Tenoning spindle: 1 St.
Number of milling agregates: 5 St.
Spindle diameter: 50 mm
weight: 4300 kg
Weinig Unicontrol 6 with CNC-spindle with full options/features!

Cut-off saw
-----------------
motor: 3 KW
spindle diameter 40 mm
spindle turnings: 2.800 Upm
tool diameter max.: 400 mm
horizontal adjsutment variable by control

length stop CNC controlled 3500 mm
------------------------------------------------------------

Tenoning spindle
---------------------------------
motor: 11 KW
spindle diameter 50 mm
spindle turnings: 3.500 Upm
tool diameter max.: 320 mm
Usable length of spindle 320 mm
Adjjustment by CNC-axis axial variable max. 240 mm for IV 68-92
adjustment speed approx. 50 mm/sek.
Number of tool postion variable because of CNC axis

1. profiling spindle (turning direction in both directions)
--------------------
Clockwise running for rip-off free stormproofing
Switsch for turning in normal direction for normal milling
motor: 11 KW
spindle diameter 50 mm
spindle turnings: 6.000 Upm
tool diameter max.: 232 mm
tool zero cycle 112 to 140 mm
Usable length of spindle 120 mm
Number of tool positions

2. Profilspindel
--------------------
motor: 11 KW
spindle diameter 50 mm
spindle turnings: 6.000 Upm
Max. tool diameter with zero cycle 112 mm: 210 mm
Max. tool diameter with zero cycle 140 mm: 232 mm
usable spindle length: 320 mm
Adjjustment by CNC-axis axial variable max. 240 mm for IV 68-92
adjustment speed approx. 50 mm/sek.
Number of tool postion variable because of CNC axis

3. spindle: grooving aggregate from top, horizonal and vertical clocked
------------------------------------------------------------------
motor: 3 KW
spindle diameter 40 mm
spindle turnings: 5850 Upm
adjustment way axial: 30 mm
adjustment way radial: 125 mm

Radial clocked on 8 positions by pneumatc revolver
Axial clocked on 8 positions by pneumatc revolver

4. profiling spindle
--------------------
profiling spindle vertical right
motor: 3 KW
spindle diameter 40 mm
spindle turnings: 5850 Upm
tool diameter : 210 mm
usable length 160 mm, 3 tools
adjustment way radial: 100 mm
adjustment way axial: 115 mm

Radial clocked on 8 positions by pneumatc revolver
Axial clocked on 8 positions by pneumatc revolver

5. spindle: groowing aggregate from bottom side
--------------------

Radial clocked on 8 positions by pneumatc revolver
Axial clocked on 8 positions by pneumatc revolver

More features:

- equipment for stormproofing of presses sashes
- Automatic turnng of the work pieces with lammella conveyour
- PC-control / NEXUS:
- laser lighter for cut-off saw
- studio window equipment (not straight windows)
- double piece package
- bars support in profiling unit
- carriage for profiling small sashes smaller 500 mm

Option:
LEITZ IV 78/90 Holz und Holz-Alu

(techncial details according to manufacturer - without guarantee!)



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125465346 1200

DMN WESTINGHOUSE AL 200 for sale
Rotary valve


DMN Westinghouse AL 200 rotary valve Discharge and dosing valve, type AL 200 stainless steel 1.4408 (ASIS 316) Volume 5.5 ltr. / U, SEW direct drive 24 RPM / 0.55 kW / 380 V


DMN Westinghouse AL 200 rotary valve

Discharge and dosing valve, type AL 200 stainless steel 1.4408 (ASIS 316)
Volume 5.5 ltr. / U, SEW direct drive 24 RPM / 0.55 kW / 380 V

Price
    request
125460776 210

WEINIG Unicontrol 12 CNC - Video - for sale
Window production centre


Tenoning spindle: 2 St.Number of milling agregates: 10 St.Spindle diameter: 50 mm! MACHINE CAN BE INSPECTED DURING PRODUCTION Machine for sale in customer orders !# 6192 Weinig Unicontrol 12 CNC, with 2 tenoning spindle ...


Tenoning spindle: 2 St.
Number of milling agregates: 10 St.
Spindle diameter: 50 mm
! MACHINE CAN BE INSPECTED DURING PRODUCTION !

! Machine for sale in customer orders !

# 6192 Weinig Unicontrol 12 CNC, with 2 tenoning spindles and Vario table
..

Specifications Summary
(Possibly more included equpment please inquire)
..


Cut-off saw
..
cut-off saw electronically, horizontally adjustable: NC axis
Number of tools: 1 pcs.
Spindle speed: 3000-6000 r / min
Spindle diameter: 40 mm
Tool clamping length: 13 mm
Tool diameter max .: 400 mm
Motor power: 3 kW
Alignment laser for detecting the cut
Displacement axial: NC-axis integrated into control
Displacement axial: 150 mm

Aggregate for edge rounding of the bottom
..
Axial adjustment along with Ablängsäge
Spindle speed: 9000 U / min
Spindle diameter: 20 mm
Tool clamping length: 25 mm
Tool diameter max .: 130 mm
Motor power: 3 kW

Length stop CNC controlled
..
Length 3500 mm
Incl. Positioned cut-off saw integrated into control

1st tenoning spindle
..
Number of tools: variable, CNC-axis
Spindle length: 640 mm
Spindle stroke vertical: variable, CNC-axis
Spindle speed: 2800 U / min
Spindle diameter: 50 mm
Tool diameter max .: 380 mm
Engine power: 15 kW
With hydraulic tensioned outboard bearing
Complete counterprofile: Complete spindle length is countered


2. tenoning spindle
..
Number of tools: variable, CNC-axis
Spindle length: 640 mm
Spindle stroke vertical: variable, CNC-axis
Spindle speed: 2800 U / min
Spindle diameter: 50 mm
Tool diameter max .: 380 mm
Engine power: 15 kW
With hydraulic tensioned outboard bearing
Complete counterprofile: Complete spindle length is countered


Vario table with horizontal NC-axis


1. profiling spindle
..
Position: Right
Number of tools: variable, CNC-axis
Spindle length: 400 mm with counter bearing
Spindle stroke vertical: variable, CNC-axis
Spindle horizontal: variable, CNC-axis
Spindle speed: 7000 U / min
Spindle diameter: 50 mm
Tooling circle max .: 232 mm
Engine power: 11 kW
Radial adjustment: CNC axis
Axial adjustment: CNC axis

2. profiling spindle
..
Position: Right
Number of tools: variable, CNC-axis
Spindle length: 400 mm with counter bearing
Spindle stroke vertical: variable, CNC-axis
Spindle horizontal: variable, CNC-axis
Spindle speed: 7000 U / min
Spindle diameter: 50 mm
Tooling circle max .: 232 mm
Engine power: 11 kW
Radial adjustment: CNC axis
Axial adjustment: CNC axis

Grooving aggregate from above - before the final profile spindle
..
Position: horizontal top
Spindle speed: 9000 U / min
Spindle diameter: 40 mm
Spindle length: 40 mm
Engine power: 3.7 kW
Displacement axial: 30mm
Displacement radial: 125 mm
Radial clock to 8 positions by pneumatic gun
Axial adjustment with NC-axis


3. profiling spindle
..
Position: Right
Number of tools: variable, CNC-axis
Spindle length: 400 mm with counter bearing
Spindle stroke vertical: variable, CNC-axis
Spindle horizontal: variable, CNC-axis
Spindle speed: 6000 U / min
Spindle diameter: 50 mm
Tooling circle max .: 232 mm
Engine power: 11 kW
Radial adjustment: CNC axis
Axial adjustment: CNC axis


Profiling spindle - fitting spindle - at the machine end
..
Position: vertical right up
Spindle length: 160 mm
Spindle speed: 5850 U / min
Spindle diameter: 40 mm
Tooling circle max .: 210 mm
Engine power: 3.7 kW
Displacement axial: 115 mm
Displacement radial: 100 mm
Radial adjustment: CNC axis
Axial adjustment: CNC axis

grooving aggregate from top - in addition stand
..
Position: vertical right
Spindle length: 40 mm
Spindle speed: 5850 U / min
Spindle diameter: 40 mm
Tooling circle max .: 180 mm
Motor power: 3 kW
Displacement axial: 100 mm
Displacement radial: 80 mm
Radial clocked to 8 positions by pneumatic gun
Axial clocked to 8 positions by pneumatic gun

Grooving aggregate from bottom side - in addition stand
..
Position: horizontal bottom
Spindle length: 125 mm
Spindle speed: 5850 U / min
Spindle diameter: 40 mm
Tooling circle max .: 200 mm
Motor power: 3 kW
Displacement axial: 100 mm
Displacement radial: 100 mm
Radial adjustment infinitely variable NC axis
Axial clocked to 8 positions by pneumatic gun


Other features
..

Online-capable
equipment for stormproofing of already pressed sashes.
That means on the machine you can do the outside profiles on single pieces or
in pressed condition
Double piece package
Return conveyor for 1-man operation: turning system with collet
Studio window equipment
Electronic angle display for angular windows
Control: PC-Nexus
NC-axis for feed height adjustment
2 axially clocked feed rollers opposite profile spindle for manufacturing
narrow and short parts
Rung leadership and shoot Supports bar
pressure lineal from side is divided in sections
Automatic central lubrication
Vario table with horizontal NC-axis


Option:
used Oertli tools in different systems for single part production (that means
customer did the outide profile of the sahes on the single piece)


techn. details according to manufacturer - without guarantee!



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125465335 2422

LKW ÖAF Gräf & Stift 20320G2 for sale


last off Code: BH-79040 Year of construction: 1976, vehicle was never approved, authorities must be assumed by the buyer elapsed. Mileage: 132.490 km : KW 235 Displacement: 12.763 cc Test badge: no inspection sticke ...


last off Code: BH-79040
Year of construction: 1976, vehicle was never approved, authorities must be assumed by the buyer
elapsed. Mileage: 132.490 km
: KW 235
Displacement: 12.763 cc
Test badge: no inspection sticker must be acquired by the buyer pursuant to § 57a, authorities
Drive type: Diesel
FIN: 6970040
Equity / total weight: 12,900/22,000 kg
Number of seats: 2 in driver's cab
Equipment: material facilities, with rear mounted plane
Documentation: types of licence available
Key: 1
Comments on the condition: engine oil loss, loss of fuel, exhaust system strongly div. rubber bearings for axles and Wishbone rusted, porous, Doppelrollgelenke VA game Achsschenkel have right and left vertical game, compressed air brake system heavily leaking, div. Compressed air hoses porous, brake master cylinder leaking, different steering knuckle heads have Heckzellonen have game, faulty, battery jump, frame, springs and shock absorbers are rusted, missing parts of front, div. parts probably spare parts dispensers, vehicle not ready to go, rust all-round vehicle div. paint damage, paint differences, is pointed out expressly that no complete inventory and check the functionality of the auction object was performed. There is still the possibility that there are significant defects. To learn about the condition and the efficiency of the auction object, the possibility of the visit and this is highly recommended. The auctioneer assumes no responsibility for the quality, condition, completeness, accessories, special properties, open or hidden defects and other damages. Please note also the general terms and conditions of auction.
System number: 2320-0-410-0037

Price
    request
125460780 206

S+S Super for sale
Frame press


Working width: 4500 mmWorking height: 2500 mmNumber of cylinders: 6 St.Dimensions (L/W/H): 6.400 x 1.850 x 3.650 mmWeight: 3.500 kgElectrohydraulic frame presser S + S Superwith automatic adjustmentCE versionFrame press  ...


Working width: 4500 mm
Working height: 2500 mm
Number of cylinders: 6 St.
Dimensions (L/W/H): 6.400 x 1.850 x 3.650 mm
Weight: 3.500 kg
Electrohydraulic frame presser S + S Super
with automatic adjustment

CE version

Frame press machine with 2 pieces movable presses, complete with 8 pieces
Holding cylinder for fixing frame parts, as well as with motor protection and
Control circuit breaker.

Size adjustment by optical length detection for height and width.

Working length x width: 4500 x 2500 mm

Rotating beam light curtain OTD 3

Medium pressure bar with automatic adjustment in height
up to 2500 mm high

Single pressure control for medium pressure bars

Cross-pressure device for pressing cross-bar window

Single pressure control for cross-pressure device

A triangle studio window crimping apparatus comprising:

Locking device of the vertical pressure beam
-3 push-on side-mounted pendulum pressure plates and regulators,
Central drive with single, pneumatic decoupling of the
Vertical pressure cylinder
(thereby independent of each other is the setting in any
Working height)


electrical hand control

Double pendulum plate

2 pendulum printing plates with extension (for triangular window triangle)


(Techn. Description according to manufacturer - without guarantee!)



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125465328 2479

PKW M1) Ford Bus Vario FT330 85 for sale


last off Code: BH-66701 Matriculation year: 24.01.2007 elapsed. Mileage: 135.903 km Power: 85 kW Displacement: 2.402 cc Test badge: no inspection sticker must be acquired by the buyer pursuant to § 57a,  ...


last off Code: BH-66701
Matriculation year: 24.01.2007
elapsed. Mileage: 135.903 km
Power: 85 kW
Displacement: 2.402 cc
Test badge: no inspection sticker must be acquired by the buyer pursuant to § 57a, authorities
Drive type: Diesel
Type, variant, version: FDC6TRANSIT/TURNEO/JXFA2B/D9CCA
FIN: WF0SXXTTFS6G34663
Equity / total weight: 2,044/3,330 kg
Color: Blue
Body: Sedan
Number of seats: 9
Equipment: 6-speed manual transmission, radio, Electr. Window regulator front
Documentation: types of licence available
Key: 1
Comments to the State: oil leak at crank shaft sealing ring, injector leaking, div. Anrostungen on all axle parts, brake discs and pads are 1 cylinder renewed, is steering leak, various rusty Anrostungen on main and auxiliary frame, springs and shock absorbers,. Passenger seat cover, expanded storage space, manufacturer emblems bleached out, gall at hood, rust spots on steel rims,.
Expressly stated, that no complete inventory and check the functionality of the auction object performed. There is still the possibility that there are significant defects. To learn about the condition and the efficiency of the auction object, the possibility of the visit and this is highly recommended. The auctioneer assumes no responsibility for the quality, condition, completeness, accessories, special properties, open or hidden defects and other damages. Please note also the general terms and conditions of auction.
Asset number: 2310-41-000-3765 und2310-0-550-0283

Price
    request
125460504 109

ROTOX EPA 376 for sale
Machine Tool


Weight approx.: 300 kgDimensions (l x w x h) approx.: 1600 x 1500 x 1500 mmDescription: - profile width: min. 40 mm up to max. 120 mm - profile height:max. 100 mm - operating pressure: 7 bar - mains connection:400 V, 4.  ...
used machine

Weight approx.: 300 kg
Dimensions (l x w x h) approx.: 1600 x 1500 x 1500 mm
Description: - profile width: min. 40 mm up to max. 120 mm
- profile height:max. 100 mm
- operating pressure: 7 bar
- mains connection:400 V, 4. 2 A, 50 Hz (three-phase current)
- Control: PLC with bus coupling to I/O modules, KLÖCKNER-MÖLLER
- attention:technical data without guarantee!
- for further information see pictures as well as PDF
1991
used machinery auction RESALE 100 €
  DE   request
125465326 1200

RÜTSCHI FLUID AG CNN 125-100-315 for sale
Centrifugal pumps


4 piece standard chemical pump CNN 125-100-315 / ISO 2858-EN 22858 ISO 5199, in stainless steel 1.4408 / process design, 119 m3, FH 25 m, 15 KW, unused with documents and spare Mechanical seal


4 piece standard chemical pump CNN 125-100-315 / ISO 2858-EN 22858 ISO 5199, in stainless steel 1.4408 / process design, 119 m3, FH 25 m, 15 KW, unused with documents and spare
Mechanical seal

Price
    request
125460547 1900

Workbench with Contents


Weight approx.: 380 kgDimensions (l x w x h) approx.: 2800 x 1100 x 1100 mmDescription: Worktop consisting of steel, dimensions 2800 x 680 mm, contents: length gauges, brackets, max. bracket: 2000 x 1000 mm, spirit level ...


Weight approx.: 380 kg
Dimensions (l x w x h) approx.: 2800 x 1100 x 1100 mm
Description: Worktop consisting of steel, dimensions 2800 x 680 mm, contents: length gauges, brackets, max. bracket: 2000 x 1000 mm, spirit levels, hammers, see photos for details

used machinery auction RESALE 105 €
  DE   request
125465311 206

ITALPRESSE UT6L for sale
Hydraulic veneering presses


HOT PRESS Type ITALPRESSE UT/6L Solid Steel Plates heathed by water with wood fired boiler useful size plates mm. 2500 x 1300 n.06 cylinders diam.mm. 70 max. open mm. 650 hydraulic pump motor power Hp 2 Thrust Ton ...


HOT PRESS Type ITALPRESSE UT/6L
Solid Steel Plates
heathed by water with wood fired boiler
useful size plates mm. 2500 x 1300
n.06 cylinders diam.mm. 70
max. open mm. 650
hydraulic pump motor power Hp 2
Thrust Ton.120
max. pressure 4 kg/cm2

complete with security systems. perimeter rope
closing by bimanual buttons
opening by electric button
exclusion of 2 cylinders from the control panel
Volt. 380/50
net weigth kgs.4500
working conditions : Excellent

Price
  IT   request
125460551 1900

Steel Winches


Weight approx.: 150 kgDimensions (l x w x h) approx.: 1200 x 800 x 500 mmDescription: 4 pcs., one is declared as defective, details and technical data see photos


Weight approx.: 150 kg
Dimensions (l x w x h) approx.: 1200 x 800 x 500 mm
Description: 4 pcs., one is declared as defective, details and technical data see photos

used machinery auction RESALE 65 €
  DE   request
125465310 901

ZUGMASCHINE T1) Steyr Daimler Puch 760 a for sale


last off Code: BH-80088 First registration: 18.12.1979 elapsed. Hours of operation: 4.208 h Output: 44 kW Displacement: 1,140 cc Test badge: no inspection sticker must be acquired by the buyer pursuant to Â&se ...


last off Code: BH-80088
First registration: 18.12.1979
elapsed. Hours of operation: 4.208 h
Output: 44 kW
Displacement: 1,140 cc
Test badge: no inspection sticker must be acquired by the buyer pursuant to § 57a, authorities
Drive type: Diesel
FIN: 295.05-3685
Equity / total weight: 2,517/4,500 kg
Color: grey
Facilities: with headlamps above installed, safety signal lamp
Tyres: Max. Axle load front 1,750 kg, allowed axle load rear 2.300 kg, documentation: licence of types of available key: 1
Comments to the State: motor does not start, gearbox is leaking, axes are leaking, corrosion game on the steering linkage and steering column, have strong bearing clearance at rear axle, brake lines and hoses partly rusted and cracked, Total failure cable fire, batteries, frame has some significant corrosion damage, hydraulic system results in oil loss, paint largely bleached out, div. Rust all around vehicle, abrasions, and dents all around vehicle, rust spots on wheels,
Expressly stated, that no complete inventory and check the functionality of the auction object performed. There is still the possibility that there are significant defects. To learn about the condition and the efficiency of the auction object, the possibility of the visit and this is highly recommended. The auctioneer assumes no responsibility for the quality, condition, completeness, accessories, special properties, open or hidden defects and other damages. Please note also the general terms and conditions of auction.
System number: 2420-0-350-0014 and 2420-0-550-0005

Price
    request
125460595 1900

Workshop Cabinet with Contents


Weight approx.: 400 kgDimensions (l x w x h) approx.: 1500 x 800 x 2150 mmDescription: Steel cabinet, contents: various turning tools, thread cutting spindle GB 2 A for M 5 to M 16, hand reamers, dies, drill chuck, see p ...


Weight approx.: 400 kg
Dimensions (l x w x h) approx.: 1500 x 800 x 2150 mm
Description: Steel cabinet, contents: various turning tools, thread cutting spindle GB 2 A for M 5 to M 16, hand reamers, dies, drill chuck, see photos for details

used machinery auction RESALE 65 €
  DE   request
125465306 2419

SPEZIALKRAFTWAGEN N1) VW Hochraum-Kasten Allrad for sale


last off Code: BH-70539 Matriculation year: 26.09.1989 elapsed. Mileage: 82.060 km Output: 51 kW Displacement: 1,588 cc Test badge: no inspection sticker must be acquired by the buyer pursuant to § 57a,  ...


last off Code: BH-70539
Matriculation year: 26.09.1989
elapsed. Mileage: 82.060 km
Output: 51 kW
Displacement: 1,588 cc
Test badge: no inspection sticker must be acquired by the buyer pursuant to § 57a, authorities
Drive type: Diesel
Type, variant, version: 251/4WD bra
FIN: WV2ZZZ25ZLG114504
Equity / total weight: 2,060/2,600 kg
Color: Green
Construction: closed
Number of seats: 3
Equipment: material equipment, cassette player, 4-speed manual transmission, all-wheel drive
Documentation: types of licence available
Key: 1
Comments on the condition: engine oil loss, exhaust manifold and gasket defective, gearbox leaking, clutch on the wear limit, intermediate gear leaking axle parts div. porous suspension rubbers, rear wheel bearing play, brake rusted, front discs and pads damaged, partially rusted brake line, steering gear easily leak, starter broken, heating and fresh air controller Anrostungen in frame, fenders and shock absorbers, rust spots at windscreen dawned, front left, differences in colour varnish, div. prov. Repainting, sticker residue, is pointed out explicitly that no complete inventory and check the functionality of the auction object performed. There is still the possibility that there are significant defects. To learn about the condition and the efficiency of the auction object, the possibility of the visit and this is highly recommended. The auctioneer assumes no responsibility for the quality, condition, completeness, accessories, special properties, open or hidden defects and other damages. Please note also the general terms and conditions of auction.
System number: 2320-0-300-0132 and 2320-0-550-0083

Price
    request
125460609 1900

Hand Lever Shears


Weight approx.: 250 kgDimensions (l x w x h) approx.: 1200 x 2400 x 2000 mmDescription: 3 pcs., 1 x NOSSENER MASCHINENBAU SCDH 10, cutter length 180 mm, with profile cutting unit, square up to 22 mm, 1 x cutter length 18 ...


Weight approx.: 250 kg
Dimensions (l x w x h) approx.: 1200 x 2400 x 2000 mm
Description: 3 pcs., 1 x NOSSENER MASCHINENBAU SCDH 10, cutter length 180 mm, with profile cutting unit, square up to 22 mm, 1 x cutter length 180 mm, with profile steel cutting unit, 1 x cutter length 360 mm, see photos for details

used machinery auction RESALE 105 €
  DE   request
125465300 109

Hagen & Goebel HG-8E for sale
Thread Drills


Automatic tapping machine with leadscrew Cap M3 to M8 in steel M12 in messing and aluminium With several leadscrews Dubble tapping head All on a table


Automatic tapping machine with leadscrew
Cap M3 to M8 in steel
M12 in messing and aluminium
With several leadscrews
Dubble tapping head
All on a table

Price
    request
125460441 1900

Hanging File Cabinet


Weight approx.: 60 kgDimensions (l x w x h) approx.: 770 x 500 x 1760 mmDescription: With 2 double doors, steel shelves, height adjustable, 2 suspension files, for further details see photos


Weight approx.: 60 kg
Dimensions (l x w x h) approx.: 770 x 500 x 1760 mm
Description: With 2 double doors, steel shelves, height adjustable, 2 suspension files, for further details see photos

used machinery auction RESALE 65 €
  DE   request
 page 1  >
You didn't find your wanted machine?   to all dealers(no registration necessary)
More models (2 or more machines):
(17)
sell machinery
Sell your machinery
to the price starting with only € 0.09 monthly per machine!
machinery sold

Sold machinery

Self-Cleaning Disc Separators Alfa-Laval BRPX 417


BRPX 417: high speed vertical disc centrifuge Made from stainless steel for the food and beverage industry. Approximate capacity: 10000 liter/hour The bowl is mounted on a vertical spindle driven by a vertically mounted motor, via a belt drive ELECTRICAL CABINET AVAILABLE 2 UNITS AVAILABLE

horizontal boxer press Euromac Digibend 360


EUROMAC punching Digibend 360 capacity 36 tonnes lengh of stroke 250 mm working speed 10/24-6 mm/sec hight bending 200 mm extra high bending 415 mm oil tank capacity 60 lt aprox 3-phases motor 5.5-4 (hp-kw) table 580 x 1170 mm size 680 x 1170 x 1130 mm weight 900 kg year 2000 CE The data are mechanically translated in the english language. Translation errors are possible. No guarantee for printed date and pricing. • Save up to 100 bend in machine memory. • Bend the guaranteed accurate to +/-0.05mm. • Automated for fast, precise production. • Reduce your set up time. • Adjusting the machine bending pressure or working speed. • Monoblock construction. • Maximum flexibility for bending application (up to 10 tooling) Benefits: • With Euromac punching bending machine, you can change over from one type of tooling to another quickly and easily. • Our bending table is machined from one piece tapered roller steel casting that's guaranteed for 5 year. • Our horizontal acting bending machines give you unlimited bending capabilities, without the risk of damaging your expensive press brake tooling. • Euromac punching bending machine are easy to program, easy to operate, and the cost of production is surprisingly low Well in good conditions of use, which ' can be seen connected and running, by appointment. Specification The RAM force-tonnage (KN) 36 (160) Length of stroke 250 mm Table dimension 1200x580mm Overall dimensions (W x D x H) 1250 x 650 x mm-1140 mm Weight 900 kg

Guillotine Shears STROJARNE PIESOK NTC 2000/4


Guillotine STROJARNE PIESOK NTC 2000/4 were produced in 1987. Shears allow cutting of materials with different strength such as steel, aluminium, copper, etc. The materials with a tensile strength of more than 450 MPa cut material thickness must be correspondingly reduced. In the case of less strength than the 450 MPa can cut materials with a greater thickness, which the breakdown does not exceed 8 mm. The thickness of the material to be cut, depending on the strength of: aluminum 200 MPa: 6 mm copper 250 MPa: 5.3 mm nickel 400 MPa: 4.2 mm steel 450 MPa: 4 mm steel 500 MPa: 3.8 mm brass 600 MPa: 3.4 mm steel 700 MPa: 3.2 mm steel 800 MPa: 3 mm Technical parameters of the guillotine NTC 2000/4: -maximum thickness sheet with pt = 450 MPa: 4 mm -maximum cutting length: 2050 mm -cutting angle: 1.33 degree -outreach in the stands: 200 mm -number of jumps continuous operation at idling speed: 60 RPM -the minimum thickness of the metal: 0.4 mm -the minimum width of the webs: 10s mm (s-thickness) -the maximum radius of curvature of the knife: 0, 05s mm (s-thickness) -cut on the rear bumper, the maximum width without brackets: 300s mm (s-thickness) -position the rear bumper: 4-750 mm -installed power: 5 kVA -the power of main motor: 4 kW -engine power bumper: 0.25 kW -overall dimensions of the device (l x w x h): 2600 x 1600 x 1500 mm -Cutter weight: 3400 kg -foot pedal -DTR, a technical-functional

Heavy Lathes POREBA TCA 160


Heavy lathe POREBA TCA 160 was produced in 1959 by the famous Polish FUM POREBA. Technical data of lathe POREBA TCA 160: Scope of work:-height of tusks: 800 mm -maximum turning diameter over bed: 1600 mm -maximum turning diameter over support: 1300 mm -eyepiece: fi 800 mm -maximum turning diameter in the pó?okularze: 250 mm -maximum turning length: 6000 mm -maximum weight of workpiece between centers in: 16000 kG -permissible cross section of the chip (turning steel Rr = 60 kG/mm2) on a single support: 30 mm2 -permissible cross section of the chip (turning steel Rr = 60 kG/mm2) on a single support: 50 mm2 -permissible force on the knife: 6000 kG -the maximum torque at the spindle: 630000 kg.cm -the maximum cross section 70 x 70 mm knife: Cap Headstock: -number of spindle speeds: 24 n -the exponent of the speed: 1.25 -spindle speed range: 1,12-224 RPM., 1,12-224 r/min, 0.85-170 RPM. -front spindle neck diameter: 260 mm -slot in the spindle of the cone metric: # 120 -reducing Bush metric cone Tip: # 120/80 -spindle bore diameter: 105 mm -diameter of the blade Cap: 1600 mm Suport, feeds the normal: -20 longitudinal feed range: 0,19-5,0 mm/Rev. -20 transverse feed range: 0,095-2.5 mm/Rev. -20 feed on the upper tray of the range: 0,095-2.5 mm/Rev. Suport, feeds 8-20 longitudinal feed range: 1.5-40 mm/Rev. -20 transverse feed range: 0.75-20.0 mm/Rev. -20 feed on the upper tray of the range: 0.75-20.0 mm/Rev. Suport, feeds minute:-20 longitudinal feed range: 12-320 mm/Rev. -20 transverse feed range: 6-160 mm/Rev. -20 feed on the upper tray with a range: 6-160 mm/Rev. Suport, feeds to thread (the main screws. train.):-35 thread jumping metrycz. about t. : 1-50 mm -jumping 35 inch threads range: 24-1/2 scroll/inch Suport, feeds for threading on the top tray:-25 thread jumping metrycz. about t. 0.25-7 mm -jumping 35 inch threads/inch scroll: the scroll 28-3/inch Feed rates associated to the rolling cones of gradients creating: 1:1.5 (d) 1:1000 -rapid traverse: 4000 mm/min. Konik: -barrel diameter: 200 mm -stroke sleeve: 600 mm -slot in the spindle sto?. meter.: # 80 -radial offset: +-30 mm Glasses: -diameter adjustment range normal: 200-600, 200-500 equipment, okular, 300-800 mm -adjustment range of diameters okular special equipment: 30-300, 50-400, 200-500 mm Pó?okular: -adjustment range pó?okulara diameter: 50-250 mm Drive:-main motor power: 40 kW -the engine speed: 750 RPM. -rapid feed motor power: 2.2 kW -the engine speed rapid feed rate: 3000 rpm. -oil pump motor power: 0.37 kW -engine oil pump: 1500 rpm. -performance oil pump: 25 l/min. Sizes and weights: -distance between centres: 3000-15000 mm -weight for length 6000 mm and 1 support: ok. 30000 kg -extra weight Prov difference length 1000 mm: 1200 kg -the weight of the additional bracket: 1500 kg

BYSTRONIC bystar


Bystronic Bystar 4025 12 meter 6kw Manufacture: Bystronic Type: Bystronic Bystar 4025 12 meter 6kw YOM 2007 Laser on Hours 30,540 Laser working hours 15,809 Sheet Size XYZ 4000mm x 2500 x 150 mm Thickness of Cutting Material Mild Steel - 25MM Stainless Steel -25MM Aluminium - 15MM Power Output 6000 Watts Cutting Heads 7.5” & 5” Comes with Auto change tables, extractor and chiller. Price: Machine Price Ex Works 200.000 euros EX WORKS GERMANY

Radial Drilling Machines WRS 25/08


Radial drilling machine WRS 25 produced in 1992. WRS drills specific data 25/08: -the size of the work surface: 660 x 360 mm -the size of the work surface: 860 x 560 mm -dimensions: 1400 x 700 mm -drilling capacity in steel: 25 mm -drilling in cast iron: 30 mm -spindle speed: 65-2880 RPM -the largest travel: 160 mm -the number of feed motor spindle: 6 -distance between the spindle from the table: 10-500 mm -distance between the spindle from the Base: 780-940 mm -radial drilling range: 315-815 mm -motor power: 3 KW -Cone Morsea: MK3 -dimensions (l x w x h): 1460 x 700 x 2300 mm -weight: 1100 kg

Hob milling machines BARBER COLMAN AEDA 27-7


Hobbes BARBER COLMAN AEDA 27-7 produced in 1989. Milling machine to machine the wheel teeth straight and slanted. Technical data routing, BARBER COLMAN AEDA 27-7: -module: 1 mm-max. module: 10 mm -the maximum diameter of the wheel: 360 mm -distance from the catch of centres: 1000 mm -overall dimensions of the machine (w x l x h): 900 x 2600 x 2200 mm -weight: ok. 4.5 tons

CNC Bending Machines Göteneds FUTURA 20 3X2100


CNC bending machine Göteneds FUTURA 20 3X2100 the Swedish production, was produced in 2007. The machine has a full CNC control, which, along with digitally controlled bumper allows you to perform advanced near-perfect for example. such shapes as the gutter. Upper beam is rotating and can be fitted with two types of tools. Bending machine is equipped with a touch-screen LCD for easy programming and control of the machine. Today the company Göteneds is connected with the Du?s? company CIDAN and belongs to the Petersen Machinery Group. Characteristics: -bending length: 2100 mm The maximum thickness of bending: -steel standard: 3 mm -stainless steel: 2 mm -aluminum: 4.5 mm -motor power beam pressure: 2.2 kW -motor power beam solenoids: 2.2 kW -weight (with beam Combi): 3450 kg Standard equipment of the CNC machine Göteneds CIDAN FUTURA 20 3X2100: -rotating beam type COMBI with auto-lock, trim 300 and quick change tool system shared with a height of 125 mm -driven rear bumper type AMF-1550 -CNC control with graphics and touch screen type CS-301 -CNC controlled slot between the beam and the lower gn?c? -trim the lower beams -adjust the bending speed by inverter -Manual beam deflection compensation solenoids

TEKNA TK419/4


3-axis CNC vertical machining center featured with a clamping system made up of vacuum tables that allow panels and plates to be held by vacuum; this solution is useful to obtain an extremely efficient machining of thin components that could hardly be fixed by means of a traditional clamping system. The machining center is equipped with a series of valves that turn on/off different areas of the machining table, thus concentrating the suction on one area and optimizing the clamping of components with limited dimensions. It is designed for drilling and interpolated milling operations on composite panels, panels and plates in aluminum and steel. To create programs that control the machines, Tekna provides user-friendly software tools that can be used both by professional CNC programmers, who can implement the most complex solutions, and by completely inexperienced users; after a few training hours the customer will be able to operate the machining center using a graphical programming. Software solutions offered by Tekna result from an accurate design and from the actual customer needs analysis. The simplicity of usage of these solutions reduces the management time and costs.

Elumatec DG104, E555


Double mitre saw DG 104 Description The optimal double mitre saw for series production as well as for special applications The universal pivoting and tilting of both saw units allows cutting of high and wide profiles as well as every type of compound mitre. Consequently, many profiles can be cut without support blocks External-dimension cuts possible for all cutting variants. Consequently, no complicated length calculations are necessary. This is a big advantage when cutting special angles Pivoting range with digital angle display Safety hoods Equipped with saw blades as standard Equipped with digital display E 111 as standard Pulsed coolant system Technical specifications Minimum cutting length at 90° 350 mm Minimum cutting length tilted at 45° 350 mm Pivoting range inwards 90° - 45° (up to 22.5° manual with digital display) Tilting range inwards pneumatically 90° - 45° For cutting range, see cutting diagram Saw blade diameter 420 mm Saw blade speed 2,800 rpm Power supply 230/400 V, 3~, 50 Hz Power output per motor 4 kW Compressed air supply 7 bar Air consumption per working cycle 40 l without spraying, 64 l with spraying Cutting length 6,000 mm Options DG 104 M machine bed made of steel sheet (cutting length 4,500 mm, 6,000 mm) Software for E 555: Software module for chop and oversize length cuts MACHINE IS WELL MAINTAINED AND WORKING WITHOUT ANY PROBLEM. PERFECT CONDITION. MACHINE HAS INCLUDED E555 INDUSTRIAL PC.

Hob milling machines LAMBERT 751


Hobbes gear Lambert 751. Technical parameters of the milling Lambert 751: -module: 1,5/2 mm -the minimum cutting diameter: 2 mm -maximum cutting diameter: 88 mm -speed of the cutter worm: 270-1440 Rpm feed range: 0.075-0.8 mm/min -length of milling (teeth, straight-screw): 25-50 mm -number of teeth: 4-390 -total power: 1.5 kW -machine weight: 400 kg -dimensions (l x w x h): 1.7 x 1.2 x 0.8 m

CNC Milling Machines Elumatec 2009


Profile machining centre SBZ 130 eluCam Description 3-axis profile machining centre Designed for economical and efficient machining of aluminium, steel and stainless steel profiles All operations, such as routing, drilling and tapping are performed while the profile bar is stationary to protect the profile surfaces The on-board turret head ensures that tool changing times are kept very short, thereby optimising machining cycles The turret head can be equipped with eight tools or angle routing heads Automatic clamping adjustment enables the machine to position the material clamps 3-axis controller The tool spindle is designed as an additional axis Network connection Technical specifications Traverse path X-axis, 4,200 mm, 7,200 mm, 8,500 mm, 10,200 mm, 11,500 mm (additional lengths on request) Vmax. 60 m/min. Traverse path Y-axis, 485 mm, Vmax. 30 m/min. Traverse path Z-axis, 340 mm, Vmax. 30 m/min. Max. spindle speed 6,000 rpm, 18,000 rpm with high-speed spindle Spindle power output 5.5 kW Tool changer for eight tools on a turret head Compressed air supply 7 bar Power supply 400 V, 3~, 50 Hz, 35 A Air consumption per minute 100 l with spraying Machining length SBZ 130 – 7.2 m Max. machining length with profile end machining, 7,080 mm Max. machining length without profile end machining, 7,200 mm

Double Miter Saws Abcd Machinery 2015


SELECTA 3 - Double head cutting off machine Home / ABCD Machinery – Machines for processing Aluminum Steel and PVC / SELECTA 3 – Double head cutting off machine SELECTA 3 High quality double head cutting off machine with a fixed sawing head on the left and automatic right head movable by numeric control with upstroke blades. Rotation and tilting of both blades for compound cuts. Brushless motor for the positioning of the movable head. Automatic pivoting inwards/outwards heads by brushless motor 22,5°90°-140°. Automatic tilting range inwards of the saw blades 90°-45°, with 2 TCT Saw blades Ø600mm. Motor power 3Kw each, lubrication by micro drop with pure oil, full protections, cutting areas with automatic raising/closing safety head, kit vertical pneumatic clamps, software of the machine completely graphical-colour display Touch screen video. 17’’Wide extension thanks to the gates RJ45-USB it allows the possibility to manage different typologies of windows with image memory for direct use. Ethernet connection to the main office or with other programs or connections with other CNC machines. Possibility of tele-assistance via . CUTTING LENGTH 6 MT. STANDARD EQUIPMENT Unlimited memorizing of cutting lists via keyboard, USB key Management expanding capacity of cut on length Management reducing capacity of cut on length Auto-feed and cut off saw (point to point) Movable roller table support with vertical stop 4x vertical pneumatic clamps Electric device for connecting motorized belt conveyor Electric device for connecting industrial vacuum Lubrication by micro drop with pure oil Full protections cutting area 2x TCT Saw Blades Ø600mm MACHINE JUST USED 3 MONTHS. PERFECT CONDITION. 5*AXIS CONTROLLED.

Elumatec 2011


Profile machining centre SBZ 140 Description 4-axis profile machining centre Designed for economical and efficient machining of aluminium and thin-walled steel profiles All operations, such as routing, drilling and tapping are performed while the profile bar is stationary to protect the profile surfaces Machining with all tools at angles continuously adjustable from 0° - 180° The on-board tool magazine ensures that tool changing times are kept short, thereby optimising machining cycles The magazine can be equipped with eight tools A rotating angle head with two different tools is available for double-bar and end machining (0°?-?90°?-?180°?-?270°) (option) Two separate working zones enable machining in shuttle operation (option) 4-axis controller 15" colour display, USB ports and network connection Windows operating system Technical specifications Traverse path X-axis, 4,200 mm, 6,400 mm, 7,600 mm, 9,700 mm (additional lengths on request) Vmax. 65 m/min. Traverse path Y-axis, 850 mm, Vmax. 60 m/min. Traverse path Z-axis, 650 mm, Vmax. 60 m/min. Pivoting angle A-axis, 0° - 180°; freely programmable in 1/10° steps Max. spindle speed 24,000 rpm Spindle power output 11 kW, S1 Tool changer for eight tools, additional tool positions on request Compressed air supply 7 bar Power supply 400 V, 3~, 50 Hz, 63 A Air consumption per minute 180 l with spraying Machining length SBZ 140 - 9.7 m Max. machining length with profile end machining, 9,580 mm Max. machining length without profile end machining, 9,700 mm MACHINE IS PERFECT CONDITION. SET UP TIME IS END OF 2012. NOT USED SO MUCH AND FULL FUNTIONALITY.

Hob milling machines POREBA ZFA 75


POREBA enveloping machine ZFA 75 was produced in 1967 by Mechanical Factory "MUNICH". The machine is designed for the production of gears with straight, oblique teeth and worm gears. During operation without a steady handle, it allows for machining wheels with a maximum diameter of 800 mm, and when working with a steady support, the maximum diameter of the wheel is 450 mm. Technical date: The largest cut-out module: -normally: 6 mm -with reduced accuracy: 8 mm The largest diameter of the gear being machined: -with the support fixed: 450 mm -without a steady: 800 mm The largest diameter of a toothed wheel work with helical teeth: -at a helix angle of 30 °: 500 mm -at a helix angle of 60 °: 190 mm The largest milling length for straight teeth: 275 mm Range of distances between the workpiece the axes and the milling cutter: -the smallest 30 mm -the largest 500 mm Vertical milling cutter: 310 mm The smallest distance from the table surface to the milling cutter axis: 200 mm The largest diameter of the milling cutter: 120 mm Diameter of mandrels for setting the cutters: 22, 27, 32 mm Diameter of the hole on the table: 80 mm The number of spindles of the milling spindle: 7 Range of rotation of the milling spindle: 47.5-192 Vertical cutter range for 1 turn of the workpiece: 0.5-3 mm The range of radial feeds of the milling cutter for 1 turn of the workpiece: 0.1-1 mm The range of axial feeds of the milling cutter for 1 turn of the workpiece: 0.25-1 mm Main engine power: 2.8 kW Machine dimensions: 2395 x 1210 x 1975 mm Milling weight: 3800 kg Equipment: -a set of shift wheels for the guitar -change tires/wheels for the second guitar: 7 pcs. -spindles: 5 items -conical wheels: 2 pcs -claw coupling -tests: 5 items -hook key -DTR-technical and operational documentation It is possible to buy additional equipment of the machine, i.e.: -modular cutters with various modules, from 1-8:100 pieces (additional fee, price: $9990 net, visible in the last two photos)

Monarch-Scalvos Protti good models excellent conditio


MAJOR TEXTILE Knitting PLANT LIQUIDATION (Please your intrest with confirmed target price immedaitely) KNITTING 12 Monarch FIL 8AEQ, 30", 4-18 cut, 8-24 cut, 84 feed 2 Monarch FIL 8AEQ, 30", 18 cut, 84 feed, 50 % lycra 10 Monarch FIM 108A, 30", 24 cut, 108 feed 1 Monarch FDR Rib, 26", 14 cut, 52 feed 3 Monarch Rib, 26", 14 cut, 52 feed, Lycra 1 Monarch Rib, 20", 14 cut, 40 feed 1 Monarch SEC Electronic Striper, 30", 16 cut, 36 feed 6 Monarch FXC4S, 30', 20 cut, 122 feed 4 Monarch RACE, 30", 28 cut, 122 cut 1 Monarch STEP JACK, 30", 20 cut, 72 feed 14 Monarch RXDF, 30", 122 feed, 3-24 cut, 6-22 cut, 5-18 cut, 24 Monarch RX4S, 26", 104 fd, 2-28 cut, 4-24 cut, 9-18 cut, 9-22 cut, 7 Monarch FXC 4S, 26", 20 cut, 104 fd. 6 Monarch RX4S, 26", 20 cut, 104 fd. 8 Monarch RX WSY Striper, 30", 48 feed, 5-16 cut, 1-18 cut, 1-28 cut FLAT KNITTING 2 Protti PV94 Doublelock, 240 cm, 12 gauge 6 Protti PT222, 213 cm, 12 cut 9 Protti PT242 Jacquard, 218 cm, 12 cut 35 Stoll JBOMB, 150 cm, 160 cm & 180 cm, 12 gauge DYEING 1 Gaston Jet Dye, 80 lb., 1996, M6000 Controller 4 Sclavos Jet Dye, Venus HT3, 3 port, 1000 lbs., 50 PSI, 1999, updated Recore controls, 2014-15 3 Gaston Futura, 2 port, 1000 lbs., 53 psi, Barco controls, 1987 1 Gaston Futura Jet Dye, single tube, 160 lbs,, 1992, M3000 controller 4 Recore Dye Machine Controllers, 2012-14 6 Then Airflow, 1200 lbs., 3 strand/3 ports, 1988 1 Then Airflow, 400 lbs., 1 port, 1987 3 Arganthan Jet Dye, 80 lbs. each, 60 PSI, 1982-80 1 Arganthan Jet Dye, 400 lbs., 60 PSI, 1982 11 Arganthan Jet Dye, 4 ports, 1000 lbs., 60 PSI, 1980 7 Gaston 824 Jet Dye, 5-3 port, 2-2 port 200 Stainless Mixing Tanks with mixers, 50 to 250 gal. 200 Dyehouse Trucks, 72" x 42" wide x 35" dp. FINISHING 1 Santex Santastrech Plus 120, 48" wide, 120 cm, balloon extractor, 5 to 60 YPM, 1994 1 Santex SANTASHRINK Dryer, 220 cm wide, with pin tenter entry, 1994, 6K/220 Gas IR SRS + SPR+FOUL+CUT, gas fired, 6 chambers, 2400 lbs./hour evaporation capacity, 6.1 mil BTU/HR 1 TubeTex Dryer #6 gas fired drum, entry with 3- Fabcon Padders 1 Bianco Slitter, 86" wide, Bianco slitter head (updated 2015), rope squeeze, detwister, folder, stainless steel 1 Bianco Slitter, 86" wide, opener and detwister, 2 scrolled rolls, flat folder 1 Stentex Tenter Stentotherm 3300, 1995, 2400 mm max. working width, unwind, J box, Dogal uncurler, 2 Santex Padders, 102" wide, Bianco Weft Straightner, E & L guiders, low profile gas fired 12 zones, 1 Krantz Syncro Shrink Conveyor Dryer, 100" wide belt 2 Famatex Tenter #1 & #2 3 Tube Tex Drum Dryers, 48" wide & 72" wide 1 Fabcon Drum Dryer, 8 zone 5 Tubular Inspection machines 6 6 Fabcon Tubular Gullwing Tubular Compactors, 52" wide Fabcon & Tubetex Tubular Calendars, 50" & 60" wide 1 Argathen Bleach Range, 10 section, 2200 lbs. hour. 1 Jemco Bleach Range, Model III 2000 CBR, 2,000 lbs. hour, 1995 1 Curtis & Marble, plastic roll wrapping 1 Bespoke Dye Mixing System, Year 2000, 16 pumps, 2 Model SRD Exact Weigh liquid chemical collecting, mixing, batch weighing, 2 IR dual head centrifugal pump, Mettler intergrated scale 1 Tube Tex, drum dryer 1999, with 3 Tube Tex tubular padders 1 1 Monforts Knitgoods Toptex 92" wide, open width rubber belt compactor, Kombi Batcher, steam heated main cylinder, 1990 Fabcon Open Pin Tenter, 90" wide x 20' long, steaming section, batcher 1 LABORATORY: Raitech Quickwash, DataColor 500, Milnor Washer, Huebsch Dryer 50 lb., PLUS MANY MORE ITEMS 25 Merrow Sewing Machines, with table and motor 2 Gardner Denver Air Compressor, 60 HP 1 Gardner Denver Air Compressor, 200 HP 3 Ingersoll-Rand Screw Compressor, 2- 250 HP, 1-150 HP 3 Propane Storage Tanks, 30,000 gallon, with mixer 4 Stainless Steel Outside Tanks, 6000 gal to 10,000 gal. 3 Waste Balers, vertical style 2 Cleaver Brooks Package Boilers, 800 HP, 1988 + 1989, dearator system PLEASE CONTACT US FOR FURTHER INFORMATION .

STAINLESS STEEL WIRE DRAWING MACHINE SUMITOMO 5.5 - 1.2 MM DIA.


Qty. 1 Second-hand stainless steel wire drawing machine Mfc.: Sumitomo(Japan) Built: 1996 Wire dia.: 5.5 mm ~1.2 mm Stainless Steel wire drawing machine Material: SUS304, SUS440, SUS303Cu Inlet: Stainless steel dia. 5.5 mm (In case tension strength: 70 kg/mm2 below) Outlet diameter: Minimum 1.2 mm (In case tension strength: 230 kg/mm2 below) Inlet speed: Max.100 m/min Outlet speed: Max. 1200 m/min Finishing Precision: plus/ minus 0.02 mm Product capacity: Max. 1120 kg/hr Stands: dia.130 mm x13 stands+dia.80 mm x19 stands=32 stands

CNC Milling Machines INFOTEC 3121 PRO


CNC milling-milling plotter INFOTEC 3121 PRO was built in the year 2016. Plotter is designed for 2D and 3D milling materials that lend themselves to machining. These could be e.g.: composites, pleksa, dibond, tubond, PVC, ABS, teflon, nylon, resin, PRO LAB, korian, aluminum, brass, bronze, steel construction (engraving), mdf, hdf, plywood, particle board, solid wood and other materials like wood. Technical data for CNC milling machines INFOTEC 3121 PRO: -dimensions of the working field of machinery gave the X and Y axis: 2100 x 3100 mm jump in the Z axis: 500 mm -the speed of the machine is X, Y, Z: 60, 60, 12 m/min. -overall dimensions: 4280 x 2900 x 3500 mm -weight: 3300 kg Milling Centre InfoTEC 3121 Professional-sample application: -cieci? of furniture panels -production of furniture fronts -production of furniture -production of façade -aluminium profiles

CNC Hydraulic Plate Shear LVD HST-E 31/6


CNC guillotine shears LVD HST-E 31/6 produced in 2003 year. Technical parameters of CNC cutter LVD HST-E 31/6: -maximum cutting length: 3000 mm -position the rear bumper: 5-1000 mm + Manual 3.5 – 1000 mm -cut on the rear bumper: 800 x 3000 mm -the thickness of cut material: Steel-6 mm, aluminium-6 mm, St37-6 mm -power: 9.5 kW -the cutter dimensions (l x h x w): 4000 x 1760 x 2730 mm + handles 1120 mm

Gear Milling Machines WMW ZFTK MODUL 250 X 5


Conical gears milling machine WMW MODUL ZFTK 250 X 5. WMW MODUL ZFTK milling machine-specific data 250 X 5: -the maximum module: 7 mm -maximum width wreath: 40 mm -number of teeth: 6-100 -dimensions: 3000 x 2000 x 2100 mm -milling machine weight: 6700 kg

CNC Laser Cutting Machines Trumpf TruMatic 3000 fiber (K04)


OVERVIEW: Brand: Trumpf Model: TruMatic 3000 fiber (K04) Application type: Laser Cutting Machine type: Laser Punch Combination Machine Availability: September Construction year: 2011 Production hours: 34000 Laser hours: 33000 Location: Spain MAIN DRIVE: Laser power: 3000 kW Punching force: 165 kN CONTROL UNIT: Brand: Siemens MOVEMENT: X-AXIS: Movement: 2500 mm Y-AXIS: Movement: 1250 mm WORKPIECE: Workpiece weight: 120 kg MAX MATERIAL THICKNESS: Steel: 4 mm ADDITIONAL EQUIPMENT: 1 - MultiTool function 2 - MultiBend function 3 - Thread shaped function 4 - Fast marking / grooving function 5 - Function roller technology and deburring 6 - Additional clamping claw 7 - Repositioning cylinder with moving parts in height 8 - Small parts sensor for ramp evacuation 9 - Mounting on mattress 10 - Chip conveyor with folding tank 11 - Deformed sheet metal detection 12 - Teleservice via and modem 13 - SheetMaster (2500 x 1250) 14 - Off / Load parallel to the main time 15 - Sheet separation system incl. Positioning help for medium format (2500 x 1250) 16 - Suction cup frame 17 - Disp. Load control 18 - GripMaster (2500 x 1250) 19 - SortMaster Pallet (6 transversal Pallets x = 1200 mm, y = 800 mm) 20 - Double trolley load incl. connection with warehouse 21 - 18 RTC cassettes incl. Matrix plate 22 - QuickSet 23 - Conveyor belt parts 24 - TruTops Punch License 25 - Includes € 40,000 in tooling

Laser Cutting Machines Trumpf TruMatic 3000 fiber (K04)


OVERVIEW: Brand: Trumpf Model: TruMatic 3000 fiber (K04) Application type: Laser Cutting Machine type: Laser Punch Combination Machine Availability: September Construction year: 2011 Production hours: 34000 Laser hours: 33000 Location: Spain MAIN DRIVE: Laser power: 3000 kW Punching force: 165 kN CONTROL UNIT: Brand: Siemens MOVEMENT: X-AXIS: Movement: 2500 mm Y-AXIS: Movement: 1250 mm WORKPIECE: Workpiece weight: 120 kg MAX MATERIAL THICKNESS: Steel: 4 mm ADDITIONAL EQUIPMENT: 1 - MultiTool function 2 - MultiBend function 3 - Thread shaped function 4 - Fast marking / grooving function 5 - Function roller technology and deburring 6 - Additional clamping claw 7 - Repositioning cylinder with moving parts in height 8 - Small parts sensor for ramp evacuation 9 - Mounting on mattress 10 - Chip conveyor with folding tank 11 - Deformed sheet metal detection 12 - Teleservice via and modem 13 - SheetMaster (2500 x 1250) 14 - Off / Load parallel to the main time 15 - Sheet separation system incl. Positioning help for medium format (2500 x 1250) 16 - Suction cup frame 17 - Disp. Load control 18 - GripMaster (2500 x 1250) 19 - SortMaster Pallet (6 transversal Pallets x = 1200 mm, y = 800 mm) 20 - Double trolley load incl. connection with warehouse 21 - 18 RTC cassettes incl. Matrix plate 22 - QuickSet 23 - Conveyor belt parts 24 - TruTops Punch License 25 - Includes € 40,000 in tooling

Self-Cleaning Disc Separators Alfa-Laval BRPS 617


Stainless steel construction. Max bowl speed 4900RPM, . Clarifier design, centripetal pump liquid discharge. It is used for removing suspended solids with particle sizes from approximately 0.5 to 500 ?m from a liquid having a lower specific gravity than the solids. The solids content in the feed is normally in the range of 0.1-10 % by volume, but can vary between different duties 37KW DRIVE MOTOR , BELT DRIVE ELECTRICAL CABINET AVAILABLE

Self-Cleaning Disc Separators ALFA-LAVAL BRPX 417


Alfa-Laval Self-Cleaning Disc Separators for the food and beverage industry , high speed vertical disc centrifuge Made from stainless steel for the food and beverage industry. Approximate capacity: 10000 liter/hour The bowl is mounted on a vertical spindle driven by a vertically mounted motor, via a belt drive

CNC Bending Presses LVD PPBL 200/30


Press brake LVD PPBL 200/30 manufactured in 2000. The machine allows you to fold items on length 3100 mm with the force 200 tons. Control and control cabinet have been completely upgraded in November 2017 (on work carried a guarantee). Early upgrades carried out the company HARTMANN from Germany. Technical data of the press LVD PPBL 200/30: -pressure capacity: 200 tons -bending length: 3100 mm -distance: 160 mm -maximum pressure: 300 bar -power: 11 kW -machine weight: 11200 kg -menu machine and manual work: in Polish language -a complete wiring diagram

Bread and biscuit cutting machines REGO-HERLITZIUS ROTO-SHOP


Bread slicing machine-mounted ROTO-SHOP manufacturer REGO-HERLITZIUS. The device the smooth technically, after review, housing stainless steel, on wheels, shelf for sliced bread. EU VAT invoices (%). Possible shipping forwarding company at a price of around 150-200 Euro.

CNC Punching Machines AMADA PEGA 357


OVERVIEW: Brand: AMADA Model: PEGA 357 Application type: Punching Machine type: Turret Punching Machine Availability: Immediately Construction year: 1993 Production hours: 48600 Location: India Origin country: Japan GENERAL DATA: Measurements width: 3770 mm Measurements depth: 4931 mm Measurements height: 2315 mm Machine weight: 11600 kg MAIN DRIVE: Punching force: 300 kN Maximum sheet thickness: 4 mm CONTROL UNIT: Brand: AMADAN Model: 04PC Interface: RS232 MOVEMENT: X-AXIS: Movement: 1830 mm Y-AXIS: Movement: 1270 mm MAX MATERIAL THICKNESS: Steel: 4 mm Stainless steel: 2 mm Aluminium: 5 mm TOOLS: No. of stations: 45 Max. tool diameter: 114,3 mm No. of index: 4 MEDIA: Main electronic connection: 400 V / 50 Hz Power consumption: 18 kVA Air pressure: 6 bar Lubrication tank: 1 L Oil tank: 80 L ADDITIONAL EQUIPMENT: 1 - 30x tools 2 - Stabilizer

Heidelberg GTOZ 52 S


-Two colours STRAIGHT machine max size 36x52 cms. -Year 1993, 10 mil. impressions -ALCOLOR dampening with Technotrans refrigeration system -Suction Stream feeder, Air suction steel table -CPtronic, Preset of the paper size -NP group, in production, very nice conditions

CNC Punching Machines Trumpf Trumatic 2000 R


OVERVIEW: Brand: Trumpf Model: Trumatic 2000 R Application type: Punching Machine type: Turret Punching Machine Availability: Immediately Construction year: 2001 Production hours: 48600 Location: India Origin country: Germany GENERAL DATA: Measurements width: 2800 mm Measurements depth: 5500 mm Measurements height: 2200 mm Machine weight: 9200 kg MAIN DRIVE: Punching force: 180 kN Maximum sheet thickness: 4 mm CONTROL UNIT: Brand: Bosch Interface: RS232 MOVEMENT: X-AXIS: Movement: 1250 mm Y-AXIS: Movement: 1250 mm MAX MATERIAL THICKNESS: Steel: 4 mm Stainless steel: 2 mm Aluminium: 5 mm TOOLS: No. of stations: 10 Max. tool diameter: 76 mm No. of index: 10 MEDIA: Main electronic connection: 400V/50 Hz Power consumption: 17 kVA Air pressure: 7 bar ADDITIONAL EQUIPMENT: 1 - 10x tools

Laser Cutting Machines BYSTRONIC BYSTAR 4020


Laser BYSTRONIC BYSTAR 4020, built in 2006 year. The machine regularly serviced. In December 2014, he was carried out overhaul of machinery and these have been the most important part (audio of the resonator, the exchange of ceramics, turbine). One of the working tables are equipped with design for loading a sheet with a length of 6 meters, area cutting 2 x 4 m Laser is ready to further its long-standing work without financial contribution. BYSTRONIC BYSTAR 4020 laser-specific parameters: -power: 4.4 kW -number of working hours of the machine: 46243 h -number of working hours: 27766 h -number of working hours of the turbine: 13456 (h) -the nominal dimension: x = 4000 mm, y = 2000 mm -the maximum positioning speed parallel to the axis of x, y: 60 m/min -maximum thickness sheet metal, structural steel: 25 mm -maximum thickness sheet stainless steel: 20 mm -maximum thickness sheet, aluminium: 12 mm -Heads: 5 "; 7.5 "

Bottle Capper 45000 bph for aluminum caps AROL, Italy EURO VA IES EVO Light


Bottle Capper AROL EURO VA for Aluminum Caps, 45000 bph This bottle capper was installed in 2017 and has very limited operating hours. It has been capping glass bottles with aluminum threaded caps. Capper is made of stainless steel and can be washed. The machine is still working and in excellent condition. Manufacturer: AROL, Italy Type: EURO VA IES EVO LIGHT Year: 2017 Operating hours approx. 1500 h Capacity: up to 45000 bph Capping heads: 4 pieces Pitch: 288 mm Certificate: CE

Beer Brewery 250 hl/Brew, 400 000-700 000 hl/year Steinecker Complete brewery


Beer Brewery 250 hl / brew 400 000 – 700 000 hl / year The brewery was originally built by Anton Steinecker in year 1984. Operation was stopped in January 2018 and it is almost untouched with all production equipment and water treatment (Only some tanks, EBI of the RGB line and filtration line were relocated to another brewery) This brewery is designed to produce high quality lager beers and pack them either in returnable glass bottles or 30 and 50-liter stainless steel KEGs. Annual technical beer production capacity is around 700 000 hl (with diluting high gravity beer) to actual 428 000 hl with 2 shift x 5 days packaging operation. Beer is packed in 0.5-liter returnable glass bottles and 30-50 liter stainless steel KEGs This brewery has Künzel made malt transport system from year 1984 with steel malt silos (3x 360 m3 malt, 2x42 m3 maiz). Malt handling capacity is 20 tons/hour and it has also 5 t/h malt dosing line with a hammer mill. Malt department is controlled with Siemens S7 200 PLC which has InTouch system. Malt house is complete and no missing equipment. Malt mill is wet type 2-roll Künzel. The complete line equipment is made by Steinecker in year 1984 and having substantial upgrade in 1994 and 2002 and it still powered and in good condition. This brew line can brew 8.5 brews / day, brew size 250 hl / brew, grist throw 5500 kg / brew and worth gravity up to 17 ° Plato. This brewery produced tree different type of high quality lager beers only. Last brew was made in December 2017 so everything is in good working order. This equipment forms a complete brewery (brew line) from malt mill to wort cooler with water island, CIP unit, buffer tank and Steinecker made Botec control system with Siemens Simatic S7-400 PLC up to the wort boiling. Yeast department is complete with sterilizer tank, two propagators and four yeast storage tanks. System is controlled with Siemens S7 PLC InTouch system. Filtration department has two good condition Alfa-Laval DAW units, 2 x 400 hl buffer tanks for DAW water and 4 x 400 hl BBT’s left. For fermentation this brewery has total cross capacity of 55600 hl tank volume. All fermenting tanks are outdoor model vertical tanks. Direct ammonia cooled CCTs Inox 10 x 2400 hl, glycol cooled CCTs Inox 14 x 1100 hl and direct ammonia cooled, coated (Fe) CCTs 4 x 2400 hl glycol cooled Packaging of beer is made with Krones year 1998 delivered returnable glass bottle line, capacity 45 000 – 55000 bph. The line has complete crate handing system and both flash and tunnel pasteurizer. Complete line (excluded EBI, which will go another brewery) is well maintained, powered and in full operational condition. The brewery has also KHS Till KEG line with 3 filling lines having capacity of 180 KEG / hour in 30 liter in stainless steel KEGs

CNC Laser Cutting Machines Trumpf TruLaser 1030 (L22)


OVERVIEW: Brand: Trumpf Model: TruLaser 1030 (L22) Application type: Laser Cutting Machine type: Laser Cutting Machine Availability: 31/10/2018 Construction year: 2010 Production hours: estimated 20000 Location: Germany Origin country: Germany GENERAL DATA: Measurements width: 7369 mm Measurements depth: 2723 mm Measurements height: 2291 mm Machine weight: 8900 kg MAIN DRIVE: Laser brand: Trumpf Laser power: 2 kW Laser type: CO2 CONTROL UNIT: Brand: B&R Model: Automation PC620 MOVEMENT: X-AXIS movement: 3048 mm Y-AXIS movement: 1524 mm Z-AXIS movement: 76 mm WORKPIECE: Workpiece weight: 575 kg MAX MATERIAL THICKNESS: Steel: 15 mm Stainless steel: 6 mm Aluminium: 5 mm MEDIA: Main electronic connection: 400 V Power consumption: 65 kVA

Fermenting Tanks Vertical CCT 4 x 2650 hl Hinke kft, Hungary 2650 hl / 2500 hl - insulated


Fermenting Tanks Vertical CCT Hinke 4 x 2650 hl Tanks are made by Hungarian Hinke kft in. They are made on normal steel and special coated for this purpose, self-standing PU foam insulated and cooled with glycol-water solution cooling and they have 4 + 1 (cone) cooling zones. Operation control with Siemens S7 200 PLC with InTouch based on System Platform. We have 4 identical tanks, all equipment with CIP bowl, legs, service platform, vacuum and overpressure safety valves. Technical data: Volume Gross 2650 hl, net 2500 hl Made by Hinke kft, Number of tanks 4 Pressure 1.0 bar Insulation PUR foam 150 mm Cooling media Direct NH3 Number of cooling zones 4 + 1 (cooled cone) Diameter 4500 mm (4800 with insulation) Height 22480 (without legs) Weight 24400 kg

Fermenting Tanks Vertical CCT 20 x 1150 hl Hinke kft / Alfa Laval 1150 hl / 1000 hl


Fermenting Tanks Vertical CCT Hinke 20 x 1150 hl Glycol Tanks are made by Hungarian Hinke kft in year 1984. They are made of stainless steel, skirt supported, PU foam insulated and cooled with glycol-water solution and they have 4 cooling zones. Operation control with Siemens S7 200 PLC with InTouch based on System Platform. We have 20 identical tanks, all equipment with CIP bowl, service platform, vacuum and overpressure safety valves. Tanks have recently installed valve panels made by Alfa Laval. Technical data: Volume Gross 1150 hl, net 1000 hl Made by Hinke kft, / Alfa Laval Manufacturing year 1984 Number of tanks 20 Pressure 1.0 bar Insulation PU foam 150 mm Cooling media Glycol-Water Solution Number of cooling zones 4 Diameter 3500 mm (3800 with insulation) Height 14750 Weight 13250 kg

Fermenting Tanks Vertical CCT 10 x 2650 hl Hinke kft, Hungary 2650 hl / 2500 hl - NH3


Fermenting Tanks Vertical CCT Hinke 10 x 2650 hl - NH3 Tanks are made by Hungarian Hinke kft in year 1995-2000. They are made of stainless steel, self-standing (with legs) PU foam insulated and cooled with direct ammonia evaporation and they have 4 + 1 (cone) cooling zones. Operation control with Siemens S7 200 PLC with InTouch based on System Platform. We have 10 identical tanks, all equipment with CIP bowl, legs, service platform, vacuum and overpressure safety valves. Tanks are in good condition. Technical data: Volume Gross 2650 hl, net 2500 hl Made by Hinke kft, Manufacturing year 1995 Number of tanks 10 Pressure 1.0 bar Insulation PUR foam 150 mm Cooling media Direct NH3 Number of cooling zones 4 + 1 (cooled cone) Diameter 4500 mm (4800 with insulation) Height 22480 (without legs) Weight 24400 kg

Liquid CO2 Storage Tank 47 m3 E&P Hinke, Hungary with two compressors


Liquid CO2 storage tank 47 m3 with cooling compressors Horizontal storage tank for liquid CO2 with two Bitzer made cooling compressors, valves and pipes. Tank is made of steel and insulated in year 2001 and compressors were changed in year 2013 to Bitzer piston compressor operating with freon R-404A. Technical data Tank manufacturer Hungarian E&P Hinke Manufacturing year 2001 Tank volume 47 m3 Tank empty weight 12800 kg Compressors 2 x Bitzer 4NES-14Y-40 P Refrigerant R-404-A, 10 kg/compressor Compressor year both made in 2013 Ref. flow rate 56.3 m3/h in 50 Hz and 67.9 m3/h in 60 Hz system

Air Bottle 5 m3, 11 bar Otto Klen Gmbh,m Germany Steel tank for compressed air


Air Bottle 5 m3, 11 bar This vertical air bottle is designed to work in max 11 bar airline as an air accumulator. Bottle is made of normal steel and it is galvanized and in good condition Manufacturer German Otto Klen GmbH Manufacturing year 2007 Bottle volume 5000 liters Max. working pressure 11 bar Testing pressure 16 bar

Laser Cutting Machines MAZAK SUPER TURBO-X 48 HI-PRO


MAZAK laser SUPER TURBO-X 48 Hi-PRO was produced in 1999 year by the renowned Japanese brand YAMAZAKI MAZAK CORPORATION. Technical data: -CNC: MAZAK L32 -power: 2 kW -table size: 2500 x 1250 mm -maximum cutting thickness, black steel: 16 mm -maximum cutting thickness, stainless steel: 5 mm -maximum cutting thickness, aluminium: 4 mm -stroke X axis: 2630 (103.5) mm (in.) -stroke Y axis: 1270 (50.0) mm (in.) -stroke Z axis: 100 (3.9) mm (in.) -3-phase voltage: 230 ~ 460 V -current protection: 3x100 A, 47 kW -weight: 10.4 T -external dimensions: laser L 5800 mm x (H) 2100 mm x S2730 mm-3 Cabinet dimensions: H 2000 mm x 1400 x 800 mm, H 2000 mm x 600 x 70 mm, 1300 mm x 700 x 700 mm Additional information about machine MAZAK SUPER TURBO-X 48 Hi-PRO: -the number of man hours on/cutting: 37180 h incorporation, 27000 h-external program to the laser beam: SICAM -consumption and type of gases: oxygen to steel, nitrogen-stainless steel, aluminum, bronze, copper, gas laser -condition: good, after services, these mirrors, oils

Cutters and vacuum cutters Marel Portion cutter I-cut


Marel portion cutter, type I-Cut 55 from 2012 in a superb condition. This single lane boneless meat portion cutting machine with 3D 360 grades laser scanning for product measurement to facilitate cut to fixed length and/or weight, rotating knife, hold down stabilisation belt and 10" Omron colour touch screen. Maximum product size 950 x 300 x 180mm, maximum product weight 10kg, with , manuals and spare blade. Stainless steel 304 construction

Veneering presses ITALPRESSE XL-8


Code: 0361 Brand: ITALPRESSE Model: XL-8 - CE Standard Hot press with diathermic oil , with soli steel platens and oil boiler - CE Standard - Year 2008 Technical data: Solid steel platens dimensions mm 3200 x 1600 Thrust tonn 160 Opening mm 400 N° 8 pistons Pistons diameter mm 85 Oil Boiler 120 degrees Digital press timer for automatic opening Digital temperature setting and reading . working pressure Daily /weekly timer Exclusion of left cylinders Boiler power more than 18 Kw with selector for partialisation of 50% power Platens covered with Mylar Overall dimensions : mm 4000 x 2100 x 2320 h

Injector Belam MI-402-9/93


Condition: Used Technical data: • overall dimensions 1663x1560x2130 mm; • power supply 8.5 kW; • power supply 400 V; • all stainless steel; • 93 needles in 6 rows 3x15 and 3x16; • conveyor width 400 mm; • working height 250 mm; • weight 1060 kg.

Laser Cutting Machines Trumpf Trumatic L3030


OVERVIEW: Brand: Trumpf Model: Trumatic L3030 Application type: Laser Cutting Machine type: Laser Cutting Machine Availability: 01/08/2018 Construction year: 2001 Laser hours: 40000 Location: Germany Origin country: Switzerland GENERAL DATA: Measurements width: 4700 mm Measurements depth: 9300 mm Measurements height: 2200 mm MAIN DRIVE: Laser brand: TruFlow Laserpower: 4 kW Laser type: Co2 CONTROL UNIT: Brand: Siemens Model: SINUMERIK 840D MOVEMENT: X-AXIS: Movement: 3000 mm Y-AXIS: Movement: 1500 mm MACHINE SPECIFIC DATA: Size of cutting head 1: 5" Size of cutting head 2: 7.5" MAX MATERIAL THICKNESS: Steel: 20 mm Stainless steel: 16 mm Aluminium: 10 mm MEDIA: Main electronic connection: 400 V / 50 HZ Power consumption: 66 kVA Air pressure: 6 bar ADDITIONAL EQUIPMENT: 1 - Lift Master

Hob Grinding Machines ZFWZ 3150


The maximum diameter of the workpiece without steady ø3150 mm Maximum diameter of the workpiece steady Ø1600 mm The minimum diameter workpiece ø175 mm The largest width of the tooth milling cutters Ø350 mm at engagement angles of 1000 mm Max module incised teeth 30 mm The greatest distance from the center of the table fixing inside the milling spindle 1800 mm The largest width (B) cutting teeth Mills - spindle milling Max milling diameter ø 350 mm Max cutter length 400 mm The wheelbase between the milling spindle and the spindle mounting 300-1800 mm - Without steady max 1800 mm - Without steady min 300 mm - The steady min 300 mm The ability to manipulate the spindle milling (manual or automatic) 500 mm Cone for pin milling metric 80 Sleigh milling tilting up to 1950 The diameters of burrs ø50; ø60; ø80 table bracket diameter ø2400mm Ext hole in the table ø500mm Hole depth of 1000 mm The biggest load of 30 tons Number of T-slot in the table 12

Glass Cylinder Stirring Apparatus with Lifting Dev


Glass cylinder mixing vessel 50l - mobile VA tubular frame. Mixing motor speed: 0-600/min, power: 0.55kW, operational temperature: -10°C to 180°C, operational pressure: -1 to 0.5bar, impeller agitator enamel, VA baffle with temperature sensor, display, spray ball, glass bottom valve: DN 25 with VA quick coupling, stainless steel tripod with swivel castors, lifting device, CE switch 16A, motor protective switch.

Glass Vessel Reactor Stirring Apparatus


Glass spherical mixing vessel 50l - mobile VA tubular frame (demonstration model). Mixing motor speed: 0-700/min, power: 0.55kW, mechanical seal: Al2O3/PTFE , PTFE angled blade agitator: 4 winged/ pressing, PTFE handhole cover DN: 100L with quick lock, bottom angle valve: DN 25/ 22 Olive, operational temperature: -10° to 140°C, operational pressure: -1 to 0.5bar, stainless steel pipe construction with VA/Gi swivel castors, with CE plug 16A and motor protective switch.

Yeast Department Holvrieka - Alfa-Laval two lines Complete yeast department


Yeast Department Holvrieka – Alfa-Laval 1997 - 2000 Equipment for sterilization of the wort, the dilution of pure culture of yeast, storage of diluted yeast before pumping to CCT. Yeast department was established by Holvrieka in 1998. Currently stopped, not dismantled. All tanks, including cooling jackets, product pipelines and distribution panels are made of food grade stainless steel. Each tank has a distribution panel. The product is heated by steam, glycol cooling. In the yeast Department, you can work simultaneously with two cultures of yeast – there are two separate lines of sterilization/propagation and storage of yeast. The equipment is in good condition, ready for dismantling and shipment. Inspection on request. In the presence of the original documentation.

Stainless steel tables


Stainless steel cutting table with polyethylene top Description Brand Stainless ID SH27316-7 Status Active Price 200 € + VAT Location Oradea (RO) Stainless steel cutting table with polyethylene top. Dimensions (L x l x h): 1500 x 900 x 850 mm.  ...

Automatic pounder Pound.O.Matic 2500


Condition: Checked/Working Technical data: • overall dimensions 2086x802x1463 mm; • power 2.5 kW; • capacity up to 7500 steaks/hour; • pounding force 2000 kg; • pressing stroke 50 mm; • thickness adjustment 1-20 mm; • stainless steel constructio ...

Carton closing machines SIAT SM8


Siat SM8 Case Sealer Semiautomatic taping machine with side straps and manual adjustment on the different box sizes. The simple and robust steel design, place it at the forefront in its field. Sealing with adhesive tape of boxes through the simultaneou ...
Get the latest machine offers by email: order newsletter
