tapping center used for sale

WILLEMIN MACODEL 508S2 ist ein Vertikalbearbeitungszentrum hoher Präzision, ausgelegt für Genauigkeit und Zuverlässigkeit. Kapazitäten: 6 Achsen; Rundtisch Ø180 mm, max. Werkstückgewicht 15 kg; Verfahrwege X400 Y200 Z385 mm; B -100/+30°; Auflösung 0,0001. Daten: Spindel HSK E40 50–42000 rpm; Leistung 10/15 kW; Drehmoment 8/12 Nm; Eilgang 60 m/min; Beschleunigung 10 m/s²; Anschluss 3×400V 50Hz; Gesamtleistung 35 kVA; Gewicht ~5000 kg. Zubehör: Werkzeugtaster BLUM 3D Z-MT, Werkstücktaster Renishaw OMP400, Ölnebelabscheider Donaldson, Turbo Separator Filter, zentrale Schmierung. Für enge Toleranzen in Automotive, Uhren, Luftfahrt, Medizintechnik und Maschinenbau. Technische Daten ohne Gewähr

number of spindles: 25 -1500 U/min Stufenlos bore capacity in steel (diameter): 23 mm bore stroke: 120 mm table clamping surface:: 1250 x 340 mm taper MK: MK3 total power requirement: 2 kW weight of the machine ca.: 0,4 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mm y-travel: 580 mm z-travel: 580 mm control: SEICOS 16M B-axis (table): 360 x 1° mm feed X/Y/Z/-axis: 1 - 50.000 mm/min rapid traverse X/Y/Z: 50,00 m/min turning speed range - stepless: 35 - 12.000 Nm spindle drive: 22,00 kW max. torque on the spindle: 236 tool taper: BT40 toolpiece magazine: chain magazine: 61 Stück size of pallet: 2x 400x400 mm max. workpiece diameter: 630 mm workpiece height max.: 680 mm workpiece weight max.: 400 kg total power requirement: 30,00 kW weight of the machine ca.: 12,00 t dimensions of the machine ca.: 4,00 x 3,50 x H3,00 m With SEICOS S16M control unit, coolant system, chip conveyor, electron. handwheel, dust exhauster. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 2134 mm, 1016 mm, 762 mm

Manufacturer: HAAS Model: VF 9 Year: 2008 Condition: Used Stock number: 9399 Control system: HAAS Work table length: 2134 mm Work table width: 914 mm Maximum table load (uniform): 1814 kg Maximum vertical spindle speed: 8100 1/min X-axis travel: 2134 mm Y-axis travel: 1016 mm Travel Z axis: 762 mm Machine weight: 12837 kg 2025: Spindle replacement

Version: T1-T1C-T5C-T6CN2, tool magazine: RACK T95, number of tool positions: 95, workpiece dimensions for parts longer than 3500mm: width: 50-140mm, thickness: 50-92mm, tool identification: chip, Balluff, extraction hoods: automatic movement for machining long parts, control: Siemens 840 D SL. Equipment: transport system, 1x motorized roller conveyor, 6000mm with pusher device. Loading system: motorized roller conveyor, length: 3880mm, with single pusher device, 2x motorized central structure, with driven belts, 3000x2000mm, speed: 15m/min, power: 0,37kW, 1x small motorized central structure, with driven belts, 1500x2000mm, speed: 15m/min, power: 0,37kW, 1x liftable roller conveyor, length: 3800mm, power: 0,37kW, 1x liftable roller conveyor, length: 2290mm, power: 0,37kW. Parking system: 1x motorized roller conveyor, length: 3070mm, with single pusher device, speed: 60m/min, power: 0,37 ...

HAAS VF-2SS ist ein Vertikal Bearbeitungszenter, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit im Fertigungsbetrieb. Tisch 914×356 mm mit 3 T-Nuten à 16 mm, Verfahrwege X762 × Y406 × Z508 mm, max. Werkstückgewicht 680 kg; Magazin 24 Plätze, Werkzeug-Ø max. 64 mm (127 mm bei freien Nachbarplätzen), Werkzeuglänge 279 mm, Werkzeuggewicht max. 5,4 kg. Spindelaufnahme BT40, bis 12.000 U/min; Spindelmotor 22,4 kW; Arbeitsvorschub 21,2 m/min, Eilgang 35,6 m/min; Werkzeugwechsel 1,8 s, Span-zu-Span 2,4 s. Anschluss 3x 400 V 50 Hz, Druckluft 5,5 bar; Maschinengewicht ~3800 kg, Abmessungen 3150×2600×2700 mm. Zubehör: Tisch 4. Achse (B), Satz Werkzeughalter, Satz Spannzangen, Kühlmitteleinrichtung 208 l, 3D Messtaster REGO-FIX. Ermöglicht enge Toleranzen für Automotive, Luftfahrt, Medizintechnik, Uhrenbau und Werkzeugmaschinenbau. Technische Daten ohne Gewähr

X-axis: 640mm, Y-axis: 600mm, Z-axis: 500mm, feed force (40% duty cycle) X-, Y-, Z-axis: 7000N, max. feed speed X-, Y-, Z-axis: 40m/min, rapid traverse speed Y-, Z-axis: 40m/min, rapid traverse speed X-axis: 70m/min, ball screw diameter/pitch Y-, Z-axis: 40/15mm, number of magazine pockets: 30, position coding: fixed-position coding, max. tool loading weight: 90kg, max. diameter of standard tools: 100mm, max. diameter of special tools with adjacent positions free: 140mm, max. tool length: 300mm, max. tool weight: 6kg, table clamping surface: 850x600mm, T-slots: DIN 650-14, loading height (top edge of table): 850mm, max. load: 600kg, connected load: 39kVA, control: Heidenhain iTNC 530, length: 2500mm, width: 4100mm, height: 3000mm, weight: 7,74t, operating hours: 60.366h. With documentation.

A KERN 5-axis CNC machining center with EROWA Robot Compact is offered. Travel X/Y/Z: 500mm/500mm/400mm, simultaneous 5-axis machining, hydrostatic guideways in the X and Y axes, swivel range: -10° to +110°, feed rate X/Y/Z: 30m/min, max. acceleration: 10m/s², max. spindle speed: 40000rpm, spindle power: 37kW, max. torque: 12000rpm, tool taper: HSK-E40, tool magazine: 50, tool change time: approx. 3s, control: Heidenhain iTNC 530 smart.TNC, laser tool measurement, workpiece touch probe, EROWA PowerChuck P, EROWA Robot Compact year of manufacture 2013 with 70 magazine positions, including 55 positions ITS 72 and 15 positions ITS 148, max. transfer weight pallet incl. workpiece: 30kg, automatic loading and unloading of the magazine also possible during machining, machining medium: oil, belt filter system and max. high-pressure supply 80bar, oil mist extraction system and fire extinguish ...

Key data: 762 mm, 406 mm, 508 mm

Manufacturer: HAAS Model: VF 2SS HE Year: 2007 Condition: Used Stock number: 9426 Work table length: 914 mm Work table width: 356 mm Maximum table load (uniform): 1361 kg Tool magazine: 24 pieces Maximum vertical spindle speed: 8000 1/min X-axis travel: 762 mm Y-axis travel: 406 mm Travel Z-axis: 508 mm Cone: ISO 40 Equipment: Pallet system

turning diameter: 400 mm turning length: - mm control: DMG Mori SLIMline z-axis: ca. 750–755 mm x-axis: 276 mm y-axis: +/-60 mm greates pass round over bed: 700 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The machine is in very good condition and has recently been inspected and measured by a service technician. The lathe was primarily used to manufacture turned plastic parts. CNC lathe with driven tools, C-axis, Y-axis, and counter-spindle CNC control: DMG Mori SLIMline multi-touch control (19/Operate 4.7 on Siemens) Screen language: German/English Main spindle: A2-8 with AC motor Drive power 25.5/17 kW (40/100% duty cycle) Spindle speed 4000 rpm Hollow clamping system, max. bar capacity 80 mm Counter-spindle: A2-6 designed as a built-in motor spindle ISM 52 with hydraulic clamping device Drive power 14/13 kW (100/40% duty cycle) Spindl ...

The machine is in good technical condition; it can be tested by prior arrangement.

x-travel: 400 mm y-travel: 400 mm z-travel: 375 mm control: Siemens 840D sl Linear total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: - mm y-travel: - mm z-travel: - mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 500 mm z-travel: 550 mm Control: Mazatrol Smooth G spindle turning speed - stepless: 15000 U/min spindle motor: 11 kW distance table - lower edge spindle: 150 - 700 mm rapid traverse: 42 m/min table surface area: 1050 x 500 mm workpiece weight max.: 750 kg tool taper: CAT 40 total power requirement: kW weight of the machine ca.: 5,7 t dimensions of the machine ca.: m dimensions of the machine ca.: 3,34 x 2,33 x 2,9 m - CNC control Mazatrol Smooth G - 30-fold tool changer (CAT 40) - NIKKEN 4th Axis -ROBOJOB MA-PAL Robot with Controller & Accessories - Loading & Unloading Pallets - Swarf Conveyor & Swarf Bin. EXOMIST Mist Extractor - Renishaw Tool Setter - Renishaw Probe - Renishaw Receiving Unit - Peripheral Safety Guarding - Selection of Spindle Tooling - Set of Manuals. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

BROTHER TC-32 B is a 3-Achsen Bearbeitungszentrum, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Tisch 800×400 mm, max. Werkstückgewicht 600 kg; Verfahrwege X 550 mm, Y 400 mm, Z 415 mm; Werkzeugmagazin 26 Plätze, Ø Werkzeug max 30 mm, Länge 200 mm, Gewicht max 3,5 kg, Wechselzeit 0,9 s. Spindel BT30 bis 12000 t/min; Spindelmotor 7,3 kW; Vorschübe 0,001–20 m/min pro Achse; Eilgang 70 m/min; Anschluss 3x380 V 50 Hz; Gesamtleistung 18 kVA; Maschinengewicht ca. 4300 kg; Abmessungen L1890×B3700×H2400 mm. Zubehör: Kühlmitteleinrichtung, Werkzeugbruchkontrolle, 3D-Messtaster RENISHAW, Fernbedienung mit Handrad und Beleuchtung. Erreicht enge Toleranzen; ideal für Automotive, Uhrmacherei, Werkzeugbau, Luftfahrt und Medizintechnik. Technische Daten ohne Gewähr

Manufacturer: DOOSAN Model: DNM 400 A Year: 2011 Condition: Used Stock number: 9438 Control system: FANUC Work table length: 920 mm Work table width: 435 mm Maximum table load (uniform): 600 kg Maximum vertical spindle speed: 12000 1/min X-axis travel: 762 mm Y-axis travel: 435 mm Travel Z-axis: 510 mm Machine height: 2509 mm Machine length: 2093 mm Machine width: 1962 mm Machine weight: 5000 kg

Key data: 762 mm, 406 mm, 508 mm

Manufacturer: HAAS Model: VF 2SS Year: 2012 Condition: Used Stock number: 9440 Control system: HAAS Work table length: 914 mm Work table width: 356 mm Maximum table load (uniform): 680 kg Maximum vertical spindle speed: 12000 1/min X-axis travel: 762 mm Y-axis travel: 406 mm Travel Z-axis: 508 mm Machine weight: 3539 kg Equipment: 4. Axis

Key data: 762 mm, 406 mm, 508 mm

Manufacturer: HAAS Model: VF 2SS Year: 2013 Condition: Used Stock number: 9441 Control system: HAAS Work table length: 914 mm Work table width: 356 mm Maximum table load (uniform): 680 kg Maximum vertical spindle speed: 12000 1/min X-axis travel: 762 mm Y-axis travel: 406 mm Travel Z-axis: 508 mm Machine weight: 3539 kg Equipment: 2x double 4th axle

Manufacturer: HAAS Model: VF 2SS Year: 2014 Condition: Used Stock number: 9442 Control system: HAAS Work table length: 914 mm Work table width: 356 mm Maximum table load (uniform): 680 kg Maximum vertical spindle speed: 12000 1/min X-axis travel: 762 mm Y-axis travel: 406 mm Travel Z-axis: 508 mm Machine weight: 3539 kg Equipment: 4. Axis

Key data: 460 mm, 510 mm, 560 mm

Manufacturer: Kitamura Model: MYCENTER HX 300 iG Year: 2018 Condition: Used Stock number: 9444 Work table length: 305 mm Work table width: 305 mm Maximum spindle speed: 15000 1/min Number of axes: 4 pieces X-axis travel: 460 mm Y-axis travel: 510 mm Travel Z-axis: 560 mm Max. tool diameter: 95 mm Max. tool weight: 10 kg

Key data: 1040 mm, 600 mm, 500 mm

Manufacturer: DMG Model: DMC 104V linear Year: 2006 Condition: Used Stock number: 9445 Control system: HEIDENHAIN iTNC 530 Switch-on hours: 60797 h Hours: 23735 h Work table length: 1250 mm Work table width: 600 mm Maximum table load (uniform): 800 kg Maximum spindle speed: 12000 1/min X-axis travel: 1040 mm Y-axis travel: 600 mm Travel Z axis: 500 mm Cone: SK 40 Tool magazine capacity: 30 Machine height: 2800 mm Machine length: 4060 mm Machine width: 2450 mm Machine weight: 8800 kg Equipment: Air conditioning in the electric cabinet Spindle temperature Oil mist extraction Workpiece Probe

CNC vertical machining center Type: DNM 500 Manufacturer: Doosan Year: 2018 Spindle overhauled in 2023 Control: Siemens Sinumerik 828 D X: 1020 mm Y: 540 mm Z: 510 mm Spindle speed: 10000 rpm Spindle taper: BT 40 Table: 1200 x 540 mm Max table load: 800 kg Tool magazine 32 positions Machine dimensions: 3000 x 2550 x 2740 mm Machine weight: 6500 kg Tool probe Work probe Chip conveyor Tool holders Machine in good condition, under power. Find more here - .ucymachines/ Contact us at - sales@ucymachines

Manufacturer: Samag Model: MFZ 2-2 Units Available: 3 Years of Manufacture: 2006, 2007, and 2003 Technical Specifications: - Total weight: 24,000 kg (per nameplate); general weight 22,000 kg, comprising base machine 20,000 kg, empty clean water tank 930 kg, and empty chip conveyor 450 kg - Dimensions with coolant tank and chip conveyor: 5.50 x 6.00 x 3 m - Dimensions during maintenance: 6.00 x 6.50 x 3 m - Connection power: 72 kVA / 72 kW - Mains voltage: 3 x 400 V AC, plus or minus 10 percent - Frequency: 50 Hz - Control voltage: 230 V AC / 24 V DC - Fuse protection ahead of main switch: 3 x 160 A - Numerical control: manufacturer Indromat type MTC200 - Operating panel: main control panel consisting of flat control panel BTV 20.3, machine control panel BTM 16.2, and CNC full keyboard VAK 40.1, with workpiece loading station at the right operating panel - Pneumatic operating pressur ...

Key data: 660 mm, 1500 mm

X-axis 580 mm Y-axis 150 mm Z-axis 1,545 mm B-axis -30 to 210° W-axis 1,490 mm Main spindle Drive power 22 kW Max. spindle speed 4,600 rpm Max. bar passage 52 mm Sub-spindle Drive power 18.5 kW Max. spindle speed 5,000 rpm Milling spindle Drive power 18.5 kW Max. spindle speed 12,000 rpm B-axis 0.0001° Interface for bar feeder Parts catcher Chip conveyor 50 bar high pressure pump 5-axis simultaneous machining Full C-axis bending spindle Gear Hobbing, Abwalfräsem Milling spindle synchronized threading Cylinder interpolation Preparation for multiple and flash tool holders 1 pcs LNS Quick Load Servo 3 Short Bar Loader

Key data: 1740 mm, 760 mm, 660 mm

Mazatrol PC Fusion CNC 640 M Control 30-fold tool changer SK-40 Tool holder according to DIN 69871 Automatic tool length measurement Cooling by the spindle Chip Conveyor, Right Discharge Detachable handwheel Rapid traverses X/Y/Z: 36 m/min CE mark

CONTROLS   CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 5   X-axis travel: 600 mm   Y-axis travel: 450 mm   Z-axis travel: 450 mm   rotating range B-axis from: -115 °   rotating range B-axis up to: 30 °   rotating range C-axis from: 0 °   rotating range C-axis up to: 360 ° TABLE   clamping surface diameter: 450 mm   workpiece load (max): 200 kg SPINDLE / HEAD   spindle revolutions (max): 20000 /min AXIS DRIVES   rapid traverse X: 22000 mm/min TOOL MAGAZINE   number of positions: 220 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 4400 mm   space requirements -front/back-: 3400 mm   total height: 2700 mm   total weight approx.: 8000 kg ATTACHMENTS   digital display: yes   chip conveyor: yes   coola ...

Manufacturer: Hedelius Model: Forte 7 Condition: Used Stock number: 9457 Control system: Siemens Sinumerik Switch-on hours: 2682 h Operating hours: 640 h Work table length: 3080 mm Work table width: 700 mm Maximum table load (uniform): 2000 kg Maximum vertical spindle speed: 18000 1/min X-axis travel: 2600 mm Y-axis travel: 700 mm Z-axis travel: 800 mm Number of all tools: 45 pieces

turning diameter: 275 mm turning length: 900 mm control: TRAUB TX8i-s spindle passage: 65 mm spindle turning speed - stepless: 1 - 5.000 U/min spindle diameter in front bearing: 110 mm C-axis: 1 - 500 U/min x-axis: 175 mm z-axis: 650/975 mm y-axis: +/- 40 mm rapid traverse X/Y/Z: 20 / 40 / 20 m/min feed capacity X/Y/Z: 5,5 / 5,5 / 10 kN tool turret - number of stations: 10 number of driven tools: 10 mm toolpiece turning speed range: 1 - 6.000 U/min power capacity at 25 % load: 5,50 kW max. torque at 25% load: 17,50 Nm tool taper DIN 69880: Ø30x55 spindle diameter in front bearing: 110 mm total power requirement: 95,00 kW weight of the machine ca.: 16,00 t dimensions of the machine ca.: 10,00 x 3,50 x H3,00 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1040 mm y-travel: 600 mm z-travel: 500 mm Control: Heidenhain iTNC 530 table surface area: 1250 x 600 mm table load: 600 kg tool taper: SK 40 spindle turning speed range: 1 - 8000 U/min max. torque on the spindle: (S1/S6) 140/200 Nm feed range: 40000 mm/min rapid power traverse in X-and Z direction: 70 m/min rapid motion - y-axis: 40 m/min spindle drive: (100/40 % ED) 13/19 kW total power requirement: 39 kVA weight of the machine ca.: 8,9 t dimensions of the machine ca.: m Operating hours 70294 Spindle hours 23335 Please note the enclosed geometry measurement report with the tool pull-in force measurement. Equipment: CNC control Heidenhain iTNC 530 Electronic handwheel Heidenhain HR 410 Motor spindle with increased torque Direct path measuring system in Y-Z axis Preparation for measuring probe 30-station tool changer, tool diameter 100/140 mm, length 300, weight 7 kg ROTOCLEAR ...

This 3-axis SCM Morbidelli N100 22-31 PROSPACE was manufactured in 2022. It features a powerful 9.5 kW electrospindle, a full nesting table, and a 13-position linear automatic tool changer. The machine is equipped with two vacuum pumps and an automatic tool length measurement system, making it suitable for various applications such as nesting, drilling, and milling. If you are looking to get high-quality CNC processing capabilities, consider the SCM Morbidelli N100 22-31 PROSPACE machine we have for sale. Contact us for further details.

Manufacturer: AXA Model No.: DBZ Year: 2007 Condition: Used Stock number: 9465 Work table length: 1350 mm Work table width: 600 mm Number of axes: 4 pieces X-axis travel: 2x 750 mm Y-axis travel: 550 mm Z-axis travel: 600 mm In 2022, GO was carried out. Equipment: Technical documentation Chip conveyor Round Table Workpiece feeding Workpiece Remover Handwheel 2x hydraulic power unit for vices

x-travel: 1660 mm y-travel: 510 mm z-travel: 510 mm Control: M+ Mazatrol Table dimensions: 2000x510 mm table load: max. 1.000 kg number of spindle speeds: 7.000 UpM tool taper: SK 40 tool piece magazine with: 48 Stück weight of the machine ca.: 7.500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: Manufacture: FANUC 21-M x-travel: 1020 mm y-travel: 510 mm z-travel: 575 mm table-size: 1200 x 500 mm spindle turning speed range: 60-8000 U/min tool magazin:: 24 weight of the machine ca.: 7.5 t HEIDENHAIN TNC-426 Prepared for the 4th axis www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Mori Seiki NL2500Y/700 CNC Drehmaschine (02/2008) Hersteller: Mori Seiki Typ: NL2500Y/700 Baujahr: 02/2008 Zustand: gebraucht, sehr gut, in Produktion Drehdurchmesser 275 mm Drehlänge 705 mm Steuerung MAPPS II MSX 850 Umlaufdurchmesser über Bett 923,8 mm Umlaufdurchmesser über Planschlitten 755 mm max. Drehdurchmesser 356 mm max. Stangendurchmesser 80 mm Hauptspindel Drehzahlbereich ? Hauptspindel 4.000 U/min Antriebsleistung ? Hauptspindel 26 / 22 kW Spindelnase JIS A2-8 Spindelbohrung 91 mm Spindellagerdurchmesser 140 mm C-Achse 0,001 ° Verfahrweg x-Achse 260 mm z-Achse 795 mm y-Achse 100 (+/- 50) mm Revolver Werkzeugplätze 12 Pos. Schafthöhe für Vierkantwerkzeug 25 mm Schaftdurchmesser für Bohrstange max. 50 mm Revolverschaltzeit 0,25 sec. Drehzahlbereich der angetr. Werkzeuge 6.000 min -1 Antriebsleistung ? angetr. Werkzeuge 5,5 / 3,7 kW Vorschub ...

Key data: 700 mm, 400 mm, 330 mm

Technical data: Manufacturer: Stama Type: MC 021 Fanuc Robodrill Year of Make: 2006 Control: Fanuc Series 31i Model A5 Travel: X 700 mm Y 400 mm Z 330 mm Rapid traverse X/Y/Z: 54 m/min. Working spindle Speed: 10,000 rpm Tool/movement Tool holder: DIN 30 Tool changer: 21-speed Dimensions and weight Weight: 2,200 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Chip conveyor closed roof

CONTROLS   CNC controls SIEMENS 840 D WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 4   .. among of them simultaneous CNC axes: 3   X-axis travel: 1000 mm   Y-axis travel: 800 mm   Z-axis travel: 1100 mm SPINDLE / HEAD   tool fixture: HSK E100 AUTOMATIC WORKLOAD EQUIPMENT   number of store positions: 4 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 6800 mm   space requirements -front/back-: 3000 mm   total height: 3200 mm   total weight approx.: 20000 kg

x-travel: 650 mm y-travel: 650 mm z-travel: 680 mm rotary table tiltable: 360 Grad Number of working hours: 55.000 h tool taper: HSK 63 spindle turning speed range: 20.000 U/min max. torque on the spindle: 85 table-size: 400 x 500 mm table load: 0,5 t 4-axis machine Chain-type tool magazine: 60 positions Chip conveyor Pallet changer Coolant filtration system High-pressure coolant through the spindle The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: HELLER Model: MCH 250 Machine Type: Horizontal Machining Center Application Type: Milling Year: 2007 Control Unit: • Control Brand: SIEMENS • Control Model: 840D Movement: • Number of Axes: 4 • X-Axis Travel: 800 mm • Y-Axis Travel: 800 mm • Z-Axis Travel: 800 mm Technical Specifications: • Spindle Speed: 6,000 RPM • Tool Holder: BT50 • Number of Tool Positions: 100 Additional Information: • 4th-axis rotary table with 1 degree indexing • Workpiece/tool probing system (touch probe) Find more here - .ucymachines/ Contact us at - sales@ucymachines

vertical machining center, year 2019, 3500 operating hours, CNC CNC-C00. Used machine. More info & price on IndustrialBuyer.

Control OSP 100U Travel X/Y/Z: 560 x 610 x 560 mm Spindle speed 15,000 min-1 2-fold pallet changer 400 x 400 mm Tool magazine for 60 Wkz., SK 40 Chip conveyor d

- Control: SIEMENS SINUMERIK 840-C - Max. rod Ø: 65 mm - C-axis - Turntable main spindle: 31 - 6,300 rpm - Turret 1: 8 stations, 4 of which are powered - Revolver 2: 8 stations, 4 of which are powered - Speed applied Operating time: 4,000 1/min - Both turrets with internal cooling - High-pressure system - Chip conveyors - Bar feeder IRCO SiMag 65 - Max. rod length: 3200 mm Dimensions LxWxH: - Machine 3400 x 1700 x 1800 mm - Bar feeder 4000 x 1000 x 1400 mm - Chip conveyor 3000 x 1100 x 1600 mm Total weight: approx. 6,000 kg

SMEC Q 4200 ist ein Bearbeitungszenter mit hoher Präzision, hoher Genauigkeit und Zuverlässigkeit. Tisch 650×420 mm, max. Werkstückgewicht 250 kg; Verfahrwege X 530 mm, Y 420 mm, Z 350 mm. Spindel BT30 bis 12.000 t/min, Drehmoment 35 Nm; Magazin 28 Plätze, Werkzeug-Ø 80 mm (150 mm bei freien Nachbarplätzen), Werkzeuglänge 250 mm, Werkzeuggewicht 3 kg, Wechselzeit 1,6 s; Vorschübe 1–30 m/min je Achse, Eilgang 48 m/min; Abstand Spindelnase–Tisch 150–500 mm; Leistung 35 kVA; Maschinengewicht ~3900 kg. Ermöglicht enge Toleranzen; typische Branchen: Automotive, Luftfahrt, Medizintechnik, Uhrenbau, Werkzeugbau Technische Daten ohne Gewähr

x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

DMG DMU 40 eVo ist ein vertikales Bearbeitungszentrum mit hoher Präzision, Genauigkeit und Zuverlässigkeit. Arbeitsfähigkeiten: Tisch 480x400 mm, 5 T-Nuten (63 mm Abstand, 14H7), Zentrierbohrung 30H6, max. Tischlast 250 kg; Wege X400 Y400 Z375 mm, B -5/+110°, C 360°, Tischdrehzahl 60 t/min. Technische Hauptdaten: Leistung 50 kW, Spindel HSK-A63 bis 24000 min-¹ (stufenlos), Drehmoment 130/86 Nm, Spindelleistung 35/25 kW, Vorschub 0-80000 mm/min, Druckluft 6 bar, 3x400V 50Hz, Abmessungen L2960xB2620xH2530 mm, Gewicht ~7150 kg. Zubehör: FANUC Lade-Roboter, Kühlmittel/IKZ 40/80 bar, TRS2 Werkzeugbruchkontrolle, Laser-Werkzeugvermessung, Späneförderer, Nebelabsaugung, Spülpistole, rotierendes Sichtfenster, Schaltschrank-Klimagerät. Erreicht enge Toleranzen; typische Branchen: Automotive, Luftfahrt, Medizintechnik, Uhrmacherei, Werkzeugbau. Technische Daten ohne Gewähr

Machine number: 9611-1806 Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Control: SIEMENS SINUMERIK Center height: 1240 mm Max. turning length: 2000 mm Spindle bore: 130 mm Max. chuck diameter: 130 mm Max. torque: 460 Nm Tool holder: VDI 40 Plan stroke: 200 mm Tailstock Quill cone: MK 5 Quill diameter: 90 mm Max. quill stroke automatic: 150 mm Incl. workshop cabinet and large batch VDI 40 tool holders also coolant system and loading system Attention: the machine can be transported on a standard truck ! Auction-ID: A7-49089-190

Machine number: 34101101 Operating voltage: 400 V Rated current: 128 A Frequency: 50 Hz Power: 89 kVA Operating hours read: 2782 Turning length: 3000 mm Center height above floor: 1270 mm Circulation diameter over slide top: 520 mm Circulation diameter over telescopic left: 520 mm Circulation diameter over steady rest slide: 520 mm Main spindle left, spindle diameter in front bearing: 160 mm Spindle bore: 77 mm Spindle speed: 4000 rpm Torque: max. 630 Nm tailstock moving built-in centering tip: MK 5 tailstock Quill diameter: 135 mm Starting force: 200 to 1200 daN Max. workpiece weight: 1000 kg Turning-drilling-milling unit Drive power: 15 kW Torque: max. 190 Nm Tool holder: HSK 63 The machine is equipped with a tailstock, a moving steady rest SMW Autoblock and a three-jaw chuck RÖHM, diameter: 310 mm incl. matching workshop cabinet and workbench with large items Documentation max. tool  ...

turning diameter: . mm turning length: 2000 mm control: Siemens 840 D sl mainspindle: turning speed max.: 3800 1/min mainspindle: torque max.: 1200 Nm tailstock:: diameter of quill: 140 mm center point: MK6 quill power: 5 - 30 kN feed rate Z-axis: 0,1 - 30000 mm/min rapid traverse Z-axis: 40 m/min feed rate X-axis: 0,1 - 18000 mm/min rapid traverse X-axis: 25 m/min total power requirement: 125 kW weight of the machine ca.: 20 t The machine can still be inspected under power at the production plant. The condition of the machine is good, the accuracy during turning operation is very good. The milling drive is not functional. A quotation from Niles for the repair of the milling drive is available on request. Including hydraulic steady rest. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 735 mm y-travel: 650 mm z-travel: 560 mm control: 840D sl FD operate Siemens Main spindle:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 35 / 24 kW max. Torque: 119 Nm tool taper: HSK-A63 DIN 69893 swiveling-rotary-table:: table diameter: 680 mm max. table load: 600 kg max. workpiece sizes: 650 x 650 x 500 mm swivellable: +/- 120 ° rotatable: 360 ° tool magazin:: number of toolpositions: 30 pos. tool taper: HSK-A63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool length: 315 mm max. tool weight: 8,0 kg change-time chip to chip: ca. 4,9 sec feeds:: feed speeds: max. 40.000 mm/min rapid traverse: 40 m/min total power requirement: 65 kVA weight of the machine ca.: 11,6 t dimensions of the machine ca.: 4,0 x 3,0 x 2,95 m Documents: Chip conveyor: Coolantsystem: 600 L through spindle coolant: 40 bar paper ba ...

Number of tool positions: 30 Spindle power: 14 kW Spindle speed: 14,000 [rpm] A-axis travel: 360 [°] (+/-) Indexing accuracy: 0.001 [°] Stroke: -10 / +95 [°] Indexing accuracy: 0.001 [°] Tool Changer Type : Loader Arm Table load capacity : 350 [kg] Auction-ID: A7-32339-12

Machine number: 96101805 Operating voltage: 400 V Frequency: 50 Hz Control voltage: 220 V Connection: 105 kW Rated current: 200 A Control: SIEMENS SINUMERIK Max. rotation diameter over bed: 185 mm Max. rotation diameter over face slide: 185 mm Spindle bore: 205 mm Number of bed slides: 2 Number of facing slides: 2 Longitudinal stroke: 800/2000 mm Face stroke: 320 mm Tailstock Quill cone: MK 5 Quill diameter: 110 mm max. tailstock displacement by hand: 300 mm incl. chip conveyor, coolant system and loading system also large batch VDI tool holders, partly equipped with cutting tools incl. documentation Attention: the machine can be transported on a standard truck ! Auction-ID: A7-49089-191
