surface used for sale

Magnetic chuck diameter: 0 mm Grinding height: 530 mm Grinding wheel diameter: 0 mm SPECIFICATIONS Controll   ConventioneL Vario Cylindical / Surface / Other    Surface grinder X - Travel   1000 mm Y - Travel   500 mm Z - Travel   530 mm Electro magnetic table   1000 x 500 mm Work piece weight    1500 Kg DIMENSIONS Length   4000 mm Width   2300 mm Height   2450 mm

Surface grinding machine make ABAYear of construction 1965Grinding area: 500 x 200 mmTable mounting surface: 500 x 200 mmGrinding wheel size: 200 x 30 x 51 mmWeight approx: 1500 kgDimensions approx: 1700 x 1050 x 1700 mmDrive power: 1.1 kWWith- Extraction system- Grinding dust collectorused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: by bank transfer net or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offerand are available for your queries every day.Best regardsM. WaldeckWAHO Machine Tools

Surface Grinding Machine Surface Grinder Grinding Machine Manufacturer: Somaco Type: C60 Travel: 500x200x300mm T-slot table: 720x220mm Incl. magnet

Grinding length: 530 mm Grinding width: 165 mm Grinding height: 390 mm Wheel diameter: 205 mm Spindle power: 1 kW X - Travel:              530mm Y - Travel:              165mm Z - Travel:              390mm Table Length:            450mm Table Width:             150mm Table load:              120 Feed rate X-Axis:        20000mm/min. Feed rate Z-Axis:        400mm/min. Grinding stone dimensions:205 x 19 x 31,75mm Speeds:                  3000Rpm Feed rate Y-Axis:        400mm/min. Length:                  2000mm Width:  & ...

The machine type B1-35/30 is a surface grinding machine that was manufactured in 1972. It is characterized by its ability to grind surfaces precisely. The dimensions of the machine are 1.25 meters in length, 1.1 meters in width and 2.4 meters in height. More details on the nameplate. ------------------------------------------------- The machine type B1-35/30 is a surface grinding machine that was manufactured in 1972. It is known for its ability to grind surfaces with precision. The dimensions of the machine are 1.25 meters in length, 1.1 meters in width, and 2.4 meters in height. Further details can be found on the type plate.

Machine Details Stock-No. 1105-03893 Type of machine Surface Grinding Machine - Horizontal Make CANTALUPPI Type 2100 x 450 Year of manufacture 1975 Type of control conventional Storage location FRANCE Country of origin Germany Delivery time immediately Freight basis EX WORK Technical details grinding length 2100 mm grinding width 450 mm workpiece height 650 mm table surface area 2200 x 750 mm distance table - spindle center max. 600 mm table speeds 1 - 25 m/min Cross Feed Autom. 1 - 60 mm/stroke grinding wheel size 400 x 100 x 76 mm grinding wheel speeds 1450 rpm total power requirement 15 kW Additional information Accessories: Magnetplate, 2100 x 400 mm, grinding wheel with flange, draw-off Device.

Surface reference plates, roughness dimensions MASSI surface grinding TGL 4763 Rz 0.063 μm - Rz 0.16 μm in wooden box Dimensions: 240 x 125 x 40 mm

Surface reference plates, roughness dimensions MASSI surface grinding TGL 4763 Rz 0.25 μm - Rz 2.5 μm in wooden box Dimensions: 345 x 125 x 40 mm

Surface reference plates, roughness dimensions MASSI surface grinding TGL 4763 Rz 1.6 μm and Rz 6.3 μm in wooden box Dimensions: 130 x 120 x 30 mm

Surface reference plates, roughness dimensions MASSI surface grinding TGL 4763 Rz 0.8 μm - Rz 20 μm in wooden box Dimensions: 345 x 125 x 40 mm

Surface reference plates, roughness measures MASSI surface grinding TGL 0-4763, DIN4763 Ra 0.25 μm - Ra 10 μm in wooden box used, tested ! Dimensions: 345 x 125 x 40 mm

Surface comparison plates, roughness dimensions MASSI surface grinding TGL 0-4763, DIN4763 Rz 0.4 μm - Rz 10 μm im Holzkasten used, tested ! Dimensions: 345 x 125 x 40 mm

Surface reference plates, roughness measures MASSI surface grinding TGL 0-4763, DIN4763 Ra 0.063 μm - Ra 0.16 μm in wooden box used, tested ! Dimensions: 240 x 125 x 40 mm

working width: 500 mm; cutter head: strip knive; number of blades: 4; surface table length: 2700 mm; adjustment surface table: Hebel; read out: table height; fence tilting: yes; motorpower: 4 kW; motorbrake: yes, automatic; machine length: 2800 mm; machine width: 1000mm; weight: 1050 kg;

working width: 630 mm; cutter head: strip knive; number of blades: 2; surface table length: 2200 mm; Hollow and pointed joint adjustment: no; surface fence adjustable: ja; maximum workpiece thickness: 220 mm; height adjustment thickness table: manual; read out for thickness table: Scala; feed speed: ca. 7 / 14 m/min; infeed roller: rubber; outfeed roller: rubber; pressure beam: durchgehend; table roller: ja; motor power: 5,5 kW; motor brake: Ja, manuell; suction connection: 160mm; machine length: 2000 mm; machine width: 1200 mm; weight: 1300;

Surface grinding machine, grinding machine -Surface grinding machine: Brown & Sharpe 612 Micromaster -Magnetic plate: 300 x 150 mm -Table: x 370 mm/y 180 mm -Max. Grinding height: 250 mm -Grinding wheels diameter: 180 mm -Transport dimensions: 1000/1400/H2280 mm -Weight: 772 kg

Surface grinding machine, grinding machine -hydraulic horizontal surface grinding machine -Magnetic plate: 300 x 150 mm -Motor grinding wheel: 1.1 kW 2800 rpm -Water cooling with: filter -Grinding wheels diameter: 200 mm -Transport dimensions: 1470/1170/H1920 mm -Weight: 1090 kg

Chrome Bath / Galvanic Surface Coating Chrome Bath / Galvanic surface Coating Galvanic chrome plating Complete system Manufacturer: Galvabau Year of construction: 2015 Power supply: 3x 400 V AC, 35 KVA Vertical chrome plant consists of : - Chrome bath 992mm x 3665mm - Diligence Rinse 1 Cascade - Diligence Sinks 2 Cascade - Chrome expansion tank ( includes heating cooling ) - Rectifier 15V / 8000A - Repolar - Refrigeration units ( MTA Aries 33 Kw) - Cooling water tank with heat exchanger 3000 liters - Control cabinet (Vipa 313, Siemens touch display...) Works flawlessly, carefully removed, cleaned, neutralized & packaged. All documents such as safety instructions, area of application and performance data, functional description, maintenance and repair, component parts list, drawings, electrical diagram, transmitter settings, certificates, component documenta ...

Surface probing system, roughness depth sensor MAHR perthometer NHT 6-100 Art.Nr. 6111501 Clamping shaft: Ø 8 mm, length: 25 mm Suitable surface measuring system - see ME893, ME894, ME895 ! as good as new ! Dimensions: 71 x 11 x 8 mm Dimensions (packaging): 85 x 25 x 25 mm

Surface probing system, roughness depth sensor MAHR perthometer NHT 3-100 Art.Nr. 6111502 clamping shaft: Ø 8 mm, length: 25 mm suitable surface measuring system - see ME893, ME894, ME895 ! as good as new ! Dimensions: 71 x 8 x 8 mm Dimensions (packaging): 85 x 25 x 25 mm

Surface probing system, roughness depth sensor MAHR perthometer NHT 11-100 Art.Nr. 6111505 clamping shank: Ø 8 mm, length: 25 mm Suitable surface measuring system - see ME893, ME894, ME895 ! as good as new ! Dimensions: 71 x 15 x 8 mm Dimensions ( packaging ): 85 x 25 x 25 mm

Surface Probe System, Roughness Depth Probe MAHR Perthometer NHT F0.5-100 Art.Nr. 6111503 clamping shaft: Ø 8 mm, length: 25 mm suitable surface measuring system - see ME893, ME894, ME895 ! as good as new ! Dimensions: 69 x 8 x 8 mm Dimensions (packaging): 85 x 25 x 25 mm

BERNARDO BSG 4080 TDC surface grinding machine was built in Austria in 2018. Designed for fully professional production applications, the machine machines workpieces placed on a magnetic plate or directly on the work table with the utmost precision and accuracy. The hydraulically driven work table with a large magnetic platen moves on hardened and ground guideways, which have been additionally coated with a special Turcite-B coating to increase abrasion resistance. The hydraulic drive, in the form of a separate hydraulic unit with heat exchanger, prevents vibration and overheating, and also ensures safe table feed even under heavy loads. Radial and axial forces are evenly distributed on special bearings without play in the grinding wheel spindle. The BERNARDO magnetic grinding machine weighs 3400 kg. Technical specifications of the magnetic surface grinding machine BERNARDO BSG 4080 T ...

Clamping surface of the magnet 600x350 mm Max grinding width 400 mm Max grinding length 700 mm Max distance of spindle axis from clamping surface Dimensions br. discs (ø x width x clamping hole) 300 x 20-50 x 76 Machine movement speed 2 -28 m/min Automatic transverse feed adjustable 1 – 60mm/Hub Automatic vertical movement 0.002 – 0.06 mm Machine weight approx. 2800kg Machine vagaries approx. 2800 x 1900 x 2400 mm Sander fully functional, can be tested.

Description: Surface Grinding Machine CHEVALIER FSG-3A20 no. 3A-0543 Manual magnetic table Fast vertical Manual increment Ideal machine for small molds or punches and dies. table surface area l x w : 450x200 mm, grinding wheel width x diameter: 200x25 mm, weight approx.: 1,000 kg, Approx. Onsite Dimension. (l x w x h): 1,700 x 1,200 x 1,790 mm

Description: Technical details: control type conventional, grinding length 600 mm, grinding width 200 mm, workpiece height 250 mm, vertically adjustable 290 mm, clamping surface 600 x 170 mm, speed 2800 rpm, additional information: incl. Add-on rotary table with 160 mm round magnetic surface weight approx.: 1,200 kg, Approx. Onsite Dimension. (l x w x h): 2,300 x 1,600 x 2,100 mm

Description: Magnetic clamping surface 1000 x 600 mm, Linea 80 control unit, with paper belt filter, belt width approx. 71 cm, additional tool cabinet - contents: manuals and training documents, machine without CE document , clamping surface of the table 1015 x 600 mm, table longitudinal movement 1170 mm, table transverse movement 665 mm, distance between table and grinding wheel axis 710 mm weight approx.: 7,000 kg, Approx. Onsite Dimension. (l x w x h): 4,000 x 3,500 x 1,900 mm

grinding length:500 mm grinding width:200 mm workpiece height:250 mm turning speed range - stepless:1000 - 2800 U/min surface area:600 x 200 mm total power requirement:2,6 kW weight of the machine ca.:1,6 t Fully functional Jung surface grinder

grinding length:1000 mm grinding width:550 mm workpiece height:400 mm surface area:1300x450 mm cross feed motor:0,55 kW grinding wheel speeds:1400 U/min total power requirement:18 kW weight of the machine ca.:4800 kg Used / overhauled surface grinding machine, Make ELB, type SWBE 010 NCK, machine no. 163811079 Machine with automatic notification in all 3 axes. Overhaul scope: Machine completely dismantled, cleaned all the components thoroughly and checked for complete functionality. All guideways new eingeschabt on Neumaschinengeometrie. Wear parts replaced defective components reparariert or replaced. Reassembly, compl. Functional testing and internal loss. Machine repainted. Machine in perfect, produktionsbereitem state. Accessories: - Vertical feed with pre-selectable active digital display, direct measuring system Heidenhain - Electric magnetic chuck with straight coarse / fine pole  ...

grinding length:7000 mm grinding width:1450 mm workpiece height:1000 mm distance between columns:1510 mm Clamping area:7.270 x 1.250 mm table load:35 t table speeds:1-50 m/min grinding wheel dia. x width:horizontaler Stößel: 630x180 mm spindle drive:horizontaler Stößel: 22 kW vertical movement:250 mm grinding wheel dia. x width:universal Stößel: 500x50 mm spindle drive:universal Stößel: 7 kW vertical movement:450 mm spindle motor:7,5 kW pivoting angle:universal Stößel: 45 Grad weight of the machine ca.:65 t Machine size (LxWxH):20.200 x 8.150 x 4.920 mm :PLC SIEMENS SIMATIC OP 27 grinding wheel with flange:diverse Used Surface grinding machine, ELB, type SWN 8 NPC-K. Machine cleaned and tested by qualified technician Functionality tested. Surface grinding machine in perfect condition, ready for production. Payment: 100% before loading the machine Warranty: none

grinding length:850/1000 mm grinding width:375 mm workpiece height:375 mm Clamping area:1550x370 mm total power requirement:9 kW space requirements approx. LxWxH:4,80 x 2,25 x 2,40 m Total weight, approx.:4300 kg max. workpiece weight:350 kg Used Surface grinding machine, manufactured EFA type AMBASSADOR 4/2 VA IZ, Baujar 1975 Machine with automatic feed in all 3 axes. Machine cleaned and tested by qualified technician Functionality tested. Surface grinding machine in perfect condition, ready for production. Accessories: - Electric - magnetic - table size 400x200mm, with a straight pole - demagnetising devise - wheel dresser mounted laterally on the grinding wheel, manually operated - wet grinding - 1 piece grinding wheel flange - 1 set of machine set up devises - Technical documentation in German - With diaform - device For more information, see the Appendix. Payment: 100% before loadin ...

grinding length:850 mm grinding width:610 mm table load:1000 kg grinding wheel speeds:1450 U/min loading area:800x400 mm dimensions of grinding wheel:400x60x127 mm weight of the machine ca.:5300 kg Used Surface grinding machine, ELB, type SWN 8 NPC-K. Machine cleaned and tested by qualified technician Functionality tested. Surface grinding machine in perfect condition, ready for production. Payment: 100% before loading the machine Warranty: none

grinding length:3150 mm grinding width:800 mm workpiece height:650 mm table surface area:3.150 x 600 mm magnetic clamping plate:3.000 x 600 mm dimensions of grinding wheel:450 x 100 x 127 mm total power requirement:22 kW dimensions of the machine ca.:11 x 3 x 2,4 m surface grinding machine, CNC Flachschleifmaschine, coolant device 2.500l, magnetical adhesive force control, semi automatic balancing system,

WORKING RANGE SURFACE GRINDING   grinding length: 400 mm   grinding width: 163 mm   vertical travel: 200 mm TABLE (SURFACE GRINDING)   magnetic table: optional MAGNETIC TABLE   length: 350 mm   width: 150 mm   height: 50 mm SPINDLESTOCK GRINDING SPINDLE   X-axis travel: 483 mm   Y-axis travel: 171 mm   Z-axis travel: 179 mm   spindle revolutions (max): 2800 /min GRINDING TOOL   type of grinding tool: wheel   diameter (max): 178 mm   borehole: diameter: 32 mm   width: 13 mm ELECTRICAL SPECIFICATIONS   total power consumption: 1.5 kW   mains voltage: 380 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 1650 mm   space requirements -front/back-: 825 mm  & ...

Schroeder-Combinator / scraped surface heat exchanger technical details: capacity/ flow rate: 20-100 ltr/h against 12 bar engine power: 3,5 KW dimensions: length x with x higth : 170 x 43 x 85 cm weight ca.: 150 kg with this device you can go with: hight viscosity and lumpy food for heating, cooling, mixing and pumping

Waldrich-Coburg leadership roads and surfaces sanding machine type: 0-15 SNC 2520 X/3 m Max.-Schleiflaenge: 3420 mms Max.-Schleifbreite: 1450 mms Max.-working height: 1005 mms Aufspannflaeche length: 3000 mms Aufspannflaeche width: 1250 mms accessories: -table fine adjustment -Papierbandfilter-Anlage -Schipmke-Haan DK150 V - back chill arrangement surface need: L=11,8m B=4,9m H=4,7m weight: 29.4 to . their prize image we await with pleasure. OTHER: the machine still stands live and can be visited any time.

Pressureless dust dilters für mounting on top of silos, material bunkers etc. in mild steel design. Equipped with 20 pcs. textile filter tubes (each 200 mm Ø x 2.000 mm long), incl. elektrical vibration device for cleaning. Filtering surface: Ca. 25 m². In very good condition, several filters available (identical).

Altronic surface coating for architectural glass Swiss manufacturer as good as new very precise conditioning CA 300 BH Year of construction 2009 New price of the plant 334.000,-€ net lt invoice / without commissioning The robots of rice with touch Los hook are also for sale designed for the solar industry, to get very thin coatings of sulfur on solar modules Here, it was important to achieve accurate distribution, had also worked. equipped with 9 x Linearruetteler type E-PLF 0.65 IP54 Overall dimensions of the coating plant: 180 w x 220 d x 210 h Editing dimension: ca. 130 w x 160 cm possibly even a belt conveyor is available incl control and adjustment table,

Type: UTK 18 200-2a-2e Power: 2 X 11 kW + 1 X 7.5 of kW, 380 V, 50 Hz Perslucht: max 20-25 bar Weight: 4,000 kg YOM 1985 Scraped surface heat exchanger for heating, temperature holding and cooling of liquid, vegetable, high viscous and crystalline products. Previous used for heating, holding (volume ± 85 ltr) and with steam cooling of food products (sauces) and ammonia (NH3, 125 ltr., 17 bar,-20 ° C / 45 ° C). 2 independent ammonia system. Constant quality of the product, continuous running and inline cleaning system (CIP).

THICKNESS PLANER type SCM S 52 SURFACE PLANER type SCM F 410 SPINDLE MOULDER type SCM T 130 NOT SEPARATE SALE second hand machines

SURFACE PLANER CASADEI DS 510 second hand machine volt. 380/50 working width mm. 510 length of table mm. 2800 cutterblock 4 knives motor power Hp 5,5 net weight kgs. 750

ADH 26C. Surface thickness Planer Dressing table (Lxw): 1120 x 275 mm Thicknessing table (Lxw): 545 x 258 mm Working height 830 mm Thickness: 5-225 mm Max depth of cut 3 mm Planer shaft diameter: 70 mm Planer blade 3 Speed 1/min 5200 Feed 5.5 m / min Engine: 1.7 kW 230V Dust nozzle diameter: 100 mm Weight 170 kg G & STÃ? 5904026 optionally with 400V

ADH 31C. Surface thickness Planer Dressing table (Lxw): 1295 x 325 mm Thicknessing table (Lxw): 545 x 308 mm Working height 850 mm Thickness: 5-225 mm Max depth of cut 3 mm Planer shaft diameter: 70 mm Planer blade 3 Speed 1/min 5200 Feed 7 m / min Motor: 2,2 kW 230 v Dust nozzle diameter: 100 mm Weight 210 kg G & STÃ? 5904031 optionally with 400V

Surface grinding machine. Magnetic chuck of 605x310mm. Longitudinal travel: 630mm. Cross travel: 350mm. Wheel diameter: 350mm.

Technical details TYP/Model: Formmaster 6/30 Table surface: 600 x 300 mm Table adjustment lengthwise: 700 mm Cross: 300 mm Grinding area: 600 x 300 mm Grinding height max: 300 mm Magnet: 600 x 320 mm Grinding slices: 220 x 25 x 52 mm Automatic vertical delivery: Yes Connection: 8 kW Accessories: Auto. Vertical delivery; Full enclosure, magnet, Wet grinding; Depulsion for grinding discs Condition: Good Addition: The machine can be visited in our warehouse, not currently under electricity! Weight: 2.6 t Dimension machine about: 2,700 x 2,200 x 2,500 mm Subject to change and error in the technical details and details.

working width: 410 mm; cutter head: strip knive; number of blades: 3; surface table length: 2400 mm; adjustment table: Hebel; read out table hight: Scala; fence tilting: yes; motor power: 4 kW; motor brake: no; machine length: 2400 mm; machine width: 800mm; waight: 750 kg;

Code 0736 Description hydraulic surface grinding machine Make ORION ( HAHN & KOLB ) Model 308 Serial No. 5128 Year 1978 Tablesize 1520 x 300 mm Table grinding size L x B x H 800 x 350 x 500 mm Magnetical plate size L x B 800 x 300 mm Speed table movement 2 - 30 m/min. Rapide vertical movement 0,4 m/min Max. distance table – centre grinding wheel 640 mm Max Grindingstone diameter x Wide x Taper 300 x 50 x Ø 76 mm Spindel power 5,5 and 7,5 kW Spindel speed 1440 and 2880 rpm Weight 3500 kgs Motor power 5,5 / 7,5 kW – 380 Volt Accessoiries Elec. Magneticplate 800 x 300 mm Coolant Condition Machine is in good condition

Code 0776 Description Surface grinding machine Make ELB Type SWBD 030 MCNC82 Machine No. 18.346.0383 Manufacturing date 1983 Control MCNC / 82-PC Tablesize 3520 x 600 mm Table grinding size L x B x H 3000 x 600 x 600 mm Magnetical plate size L x B 3000 x 400 mm Speed table movement 0,2 – 6 m/min. Max. distance table – centre grinding wheel 850 mm Speeds vertical 3 – 375 mm/min. Speeds cross 1,2 m/min. Speeds grindingwheel stepless 750 – 1400 omw/min Grindingstone: Ø 600 x Wide:100 x Bore: 200 mm Weight 18.000 kg Motor power 37 kW – 380 Volt Accessoiries Electro table 3000 x 400 mm Grinding unit with water cooling Filtering unit with paperfilter Profile grinding unit Condition Machine is in very good condition

Code 4925 Description Surface grinding machine Make ELB Model OPTIMAL 1 VA II Serial No. 180730982 Year 1982 Tablesize 900 x 250 mm Table grinding size L x B x H 600 x 300 x 250 mm Magnetical plate size L x B 500 x 250 mm Speed table movement 1 – 25 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 500 mm Grinding stone dim. Stone x Wide x Taper 300 x 50 x Ø 75 mm Spindel power 3,7 and 4,5 kW Spindel speed 1400 and 2800 rpm Weight 3500 kgs Motor power 3,7 and 4,5 kW – 380 Volt Accessoiries Elec. Magneticplate 500 x 250 mm Coolant with paperfilter 2 x DRO Grinding stones, etc. Condition Machine is in good condition

Code 61047 Description Hydr. Surface grinding machine Make ALPA Model RT 1000 Serial No. 53377 Year 1985 Tablesize 1200 x 300 mm Table grinding size L x B x H 1000 x 350 x 400 mm Base size L x B 1000 x 300 mm Speed table movement 3 – 40 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 600 mm Grinding stone diam. Stone x Wide x Taper Ø 400 x 50 x 127 mm Spindel power 8,8 kW Spindel speed 1460 rpm Weight 3000 kgs Motor power 8,8 kW – 380 Volt Accessoiries Magneticplate 1000 x 300 mm Coolant Grinding stones, etc. Condition Machine is in normal condition
