125465357 103

DECKEL FP 1 for sale
Tool room milling machine


No. R 56716-08, with digital display for lateral axis. Clamping surface of the solid table 195 x 605 mm Table movement along autom. and hand 290/300 mm Table motion vertical machine. and hand 330/340 mm Spindle stock ...
used machine

No. R 56716-08, with digital display for lateral axis.
Clamping surface of the solid table 195 x 605 mm
Table movement along autom. and hand 290/300 mm
Table motion vertical machine. and hand 330/340 mm
Spindle stock Cross movement by hand 150 mm
Spindle carrier ISA 40
Spindle speeds from 40 to 2000 RPM.
Spindle drive 1/1.4 kW
Weight approx. 660 kg

Accessories: separate control cabinet.

Price
    request
125460803 102

HARRISON M 450 for sale
Center Lathe


turning diameter over bed: 450 mmturning diameter over slide rest: 280 mmturning length: 1000 mmturning speeds: 40 - 2000 U/mincentre height: 225 mmspindle bore: 67 mmtailstock quill taper MT: 4 MKtotal power requirement ...


turning diameter over bed: 450 mm
turning diameter over slide rest: 280 mm
turning length: 1000 mm
turning speeds: 40 - 2000 U/min
centre height: 225 mm
spindle bore: 67 mm
tailstock quill taper MT: 4 MK
total power requirement: 7,5 kW
weight of the machine ca.: 1,7 t
Dimensions (LxWxH): 2,3 x 1,2 x 1,7 m
Center lathe with
- 3-jaw chuck F 315
- Fixed tailstock top
- Multifix holder
- 2-axis digital display
- Fixed Lynette 180 mm
- Coolant system
- rapid traverse



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125465301 203

WEINIG U17A for sale
Four-sided planing machines


MULTISPINDLE MACHINE Type WEINIG U17A indipendent motors for each planing spindle composed by 6 Spindles : 1) Surface planer 2) Moulder ( right ) 3) Moulder ( left ) 4) Moulder ( right ) 5) Thickness Planer 6) Un ...


MULTISPINDLE MACHINE Type WEINIG U17A
indipendent motors for each planing spindle
composed by 6 Spindles :
1) Surface planer
2) Moulder ( right )
3) Moulder ( left )
4) Moulder ( right )
5) Thickness Planer
6) Universal shaft 360°
- max. working width mm. 170
- max. working heigth mm. 120
- length of entry table mm. 1800
- Lift of infeed unit motor Hp 0,5
- Feed speed from 6 to 22 mt./min
- Spindle rotations of working heads rpm. 6000
- Spindle diameter of working heads mm. 40
- Infeed unit with pneumatic pressure
- Table lubrification
- Volt. 380/50

Price
  IT   request
125460805 102

GEMA LZ 185 for sale
Center Lathe


turning diameter over bed: 370 mmturning diameter over slide rest: 230 mmturning length: 700 mmturning speeds: 25 - 2000 U/mincentre height: 185 mmspindle bore: 40 mmtailstock quill taper MT: 3 MKtotal power requirement: ...


turning diameter over bed: 370 mm
turning diameter over slide rest: 230 mm
turning length: 700 mm
turning speeds: 25 - 2000 U/min
centre height: 185 mm
spindle bore: 40 mm
tailstock quill taper MT: 3 MK
total power requirement: 3,2 kW
weight of the machine ca.: 1,2 t
Dimensions (LxWxH): 1,85 x 0,8 x 1,5 m
Center lathe with
- 3-jaw chuck F 315
- Fixed tailstock top
- Multifix holder
- 2-axis digital display
- Fixed Lynette 180 mm
- Coolant system
- rapid traverse



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125465279 202

PADE 1000 N for sale
CUTTING BORING MOULDING machine


AUTOMATIC CUTTING , BORING and MOULDING machine type PADE 1000 N Machine suitable for assembling part of chairs, tables, frames, small furniture, wheelchair frames, etc. The PADE 1000 N performs the operations of Cut ...
used machine

AUTOMATIC CUTTING , BORING and MOULDING machine type PADE 1000 N
Machine suitable for assembling part of chairs, tables, frames, small furniture, wheelchair frames, etc.
The PADE 1000 N performs the operations of Cutting , milling and drilling at the end of the piece, either singularly or differently combined. All movements of the machine are controlled by pneumatic devices.

composed by 3 working units :
1- Cutting unit
circular saw diam. mm.350
motor power hp 3

2- Boring unit
boring head with 5 / 7 mandrins
motor power Hp 3
max. working stroke of boring unit mm. 130

3- Moulding unit
vertical spindle for moulder
motor power Hp 5,5
spindle diam. mm.30
pneumatic sliding carriage

volt. 380/50
2007
Price
  IT   request
125460807 103

FORMAT UF 250 for sale
Tool Room Milling Machine - Universal


x-travel: 900 mmy-travel: 250 mmz-travel: 450 mmturning speed range - horizontal: 50 - 1700 U/minturning speed range - vertical: 50 - 1700 U/minmilling-head swivable +/-: 90° spindle taper ISO: 40 table surface area:  ...
used machine

x-travel: 900 mm
y-travel: 250 mm
z-travel: 450 mm
turning speed range - horizontal: 50 - 1700 U/min
turning speed range - vertical: 50 - 1700 U/min
milling-head swivable +/-: 90°
spindle taper ISO: 40
table surface area: 1250 x 250 mm
total power requirement: 4,2 kW
weight of the machine ca.: 1,5 t
dimensions of the machine ca.: 1,2 x 1,5 x 1,8 m
? hydr. vise
? horizontal milling equipment (without steady) with 3 milling spindles


This ad was created with MODUL MWS - the software solution of LogoTech.
2001
Price
    request
125456378 1200

ALFA-LAVAL BRPX 417 for sale
Self-Cleaning Disc Separators


BRPX 417: high speed vertical disc centrifuge Made from stainless steel for the food and beverage industry. Approximate capacity: 10000 liter/hour The bowl is mounted on a vertical spindle driven by a vertically mounted  ...
used machine

BRPX 417: high speed vertical disc centrifuge Made from stainless steel for the food and beverage industry. Approximate capacity: 10000 liter/hour The bowl is mounted on a vertical spindle driven by a vertically mounted motor, via a belt drive
ELECTRICAL CABINET AVAILABLE
2 UNITS AVAILABLE

25,000
  RO   request
125460809 103

KUNZMANN UF6N for sale
Tool Room Milling Machine - Universal


x-travel: 450 mmy-travel: 500 mmz-travel: 200 mmturning speed range - horizontal: 30 - 1280 U/minturning speed range - vertical: 50 - 2150 U/minmilling-head swivable +/-: 90° spindle taper ISO: 30 table surface area:  ...
used machine

x-travel: 450 mm
y-travel: 500 mm
z-travel: 200 mm
turning speed range - horizontal: 30 - 1280 U/min
turning speed range - vertical: 50 - 2150 U/min
milling-head swivable +/-: 90°
spindle taper ISO: 30
table surface area: 865 x 265 mm
total power requirement: 3 kW
weight of the machine ca.: 1,44 t
dimensions of the machine ca.: 1,2 x 1,5 x 1,8 m
? hydr. vise
? horizontal milling equipment (without steady) with 3 milling spindles


This ad was created with MODUL MWS - the software solution of LogoTech.
1979
Price
    request
125452415 101

DMG DECKEL MAHO DMU 50 EVO for sale
Numerically Controlled Machining Centres


Machining center - universal DMG DECKEL-MAHO DMU 50 EVO / 5-axis bearing no 1105-00930 category machining center - universal make DMG DECKEL-MAHO type DMU 50 EVO / 5 axes built in 2001 State second-hand machine control C ...
used machine

Machining center - universal DMG DECKEL-MAHO DMU 50 EVO / 5-axis bearing no 1105-00930 category machining center - universal make DMG DECKEL-MAHO type DMU 50 EVO / 5 axes built in 2001 State second-hand machine control CNC HEIDENHAIN TNC 430 Vidia RT France country of origin Germany delivery immediately cargo base EX WORK technical details x way 500 mm y way 420 mm z-way 380 mm control HEIDENHAIN TNC 430 spindle taper SK 40 speed 18,000 rpm spindle motor 15 kW rapid 50 m / min table on clamping area 500 diameter. x 380 mm feed range up to 20 000 mm / min tool changer 32 x total power consumption 38 kVA machine weight approx. 5.9 t description - CNC - screen control HEIDENHAIN TNC 430 - 5-axis machine with B + C - axis
-Spindle: 19 500 h - a power: 88 000 h - machine documents
2001
59,000 €
    request
125460811 102

GEMA LZ 185 for sale
Center Lathe


turning diameter over bed: 370 mmturning diameter over slide rest: 230 mmturning length: 700 mmturning speeds: 25 - 2000 U/mincentre height: 185 mmspindle bore: 40 mmtailstock quill taper MT: 3 MKtotal power requirement: ...


turning diameter over bed: 370 mm
turning diameter over slide rest: 230 mm
turning length: 700 mm
turning speeds: 25 - 2000 U/min
centre height: 185 mm
spindle bore: 40 mm
tailstock quill taper MT: 3 MK
total power requirement: 3,2 kW
weight of the machine ca.: 1,2 t
Dimensions (LxWxH): 1,85 x 0,8 x 1,5 m
Center lathe with
- 3-jaw chuck F 315
- Fixed tailstock top
- Multifix holder
- 2-axis digital display
- Fixed Lynette 180 mm
- Coolant system
- rapid traverse



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125452392 103

DECKEL FP4A for sale
Vertical Milling Machines


OVERVIEW: Brand: DECKEL Model: FP4A Application type: Milling Machine type: Milling Machine Availability: Immediately Construction year: 1991 Production hours: 32000 Location: Netherlands Origin country: Germany ...
used machine

OVERVIEW:
Brand: DECKEL
Model: FP4A
Application type: Milling
Machine type: Milling Machine
Availability: Immediately
Construction year: 1991
Production hours: 32000
Location: Netherlands
Origin country: Germany

GENERAL DATA:
Measurements width: 3000 mm
Measurements depth: 2700 mm
Measurements height: 1630 mm
Machine weight: 1950 kg

MAIN DRIVE:
Number of spindle: 1
Spindle speed range: 4000 1/min

CONTROL UNIT:
Brand: Grundig
Model: Dialog 11

MOVEMENT:
X-AXIS movement: 560 mm
Y-AXIS movement: 500 mm
Z-AXIS movement: 390 mm

WORKPIECE:
Workpiece drm: 80 mm
Workpiece x: 485 mm
Workpiece y: 385 mm
Workpiece z: 380 mm
Workpiece weight: 800 kg

TABLE:
Outer length: 900 mm
Outer width: 530 mm

TOOLS:
Max weight: 450 kg
Max tool diameter: 40 mm
Max tool length: 150 mm

MEDIA:
Main electronic connection: 380 V
Power consumption: 16.5 kVA
Internal cooling: yes

ADDITIONAL EQUIPMENT:
1 - 1x Tool holder
1991
Price
  NL   request
125460795 102

DMG MORI CTX beta 1250 TC 4A for sale
CNC Turning- and Milling Center


turning diameter: max. 500 mmturning length: 1.250 mmcontrol: Sinumerik 840 D sl Siemensswing diameter: 500 mmdistance between spindles: 1.450 mmMain spindle:: turning speed range - main spindle: max. 5.000 min/-1power ...
used machine

turning diameter: max. 500 mm
turning length: 1.250 mm
control: Sinumerik 840 D sl Siemens
swing diameter: 500 mm
distance between spindles: 1.450 mm
Main spindle::
turning speed range - main spindle: max. 5.000 min/-1
power capacity - main spindel: 25 / 32 kW
max. Torque: 360 / 280 Nm
spindle head: 170h5
spindle bearing diameter: 130 mm
spindle bore: 77 mm
bar material dia.: 67 mm
usable bar diameter: 65 mm
C-Axis: 360 °
chucking diameter: max. 250 mm
tool magazin::
number of toolpositions: 24 pos.
max. tool diameter: 80 mm
max. tool-dia with free toolbox: 120 mm
max. tool weight: 5 kg
max. tool length: 300 mm
Milling Spindle::
Speed Milling Spindle: max. 18.000 min/-1
power capacity - milling spindle: 22 kW
max. Torque: 100 Nm
tool taper: HSK 63 A
B-Axis: +/- 110 °
axis stroke::
x-axis: 1: 450 (-10) mm
z-axis: 1: 1.300 mm
y-axis: 1: +/- 100 mm
Subspindel::
Spindle speed range subspindle: max. 5.000 min/-1
power capacity - Sub spindle: 25 / 32 kW
bar material dia.: max. 65 mm
chucking diameter: max. 250 mm
C-Axis: 360 °
turret::
number of toolpositions: 12 pos.
tool taper: VDI 40 TriFix
Number of driven toolspositions: 12 pos.
Spindle speed - driven tool stations: max. 4.000 min -1
power capacity driven tool-stations: 11,3 / 28 kW
max. Torque: 7 Nm
switching time: 30°: 0,4 sec
axis stroke::
x-axis: 2: 195 mm
z-axis: 2: 1.200 mm
total power requirement: 70 kVA
weight of the machine ca.: 8,0 t
dimensions of the machine ca.: 4,0 x 2,5 x 2,5 m
Documents:
Chip conveyor:
Milling spindle:
Coolantsystem:
high pressure coolant: 20 bar
hydraulic system:
Automatic Tool Changer: 24 pos.
work light:
C-axis: 2x
B-axis:
Y-axis:
hollow chuck unit:
Subspindle:
direkt probing: X1 / Y1 / Z1 / X2
Parts removal:
Signal lamp - 4 colour:
bar feeder interface:
bar feeder: LNS SuperHyd. 6.50-6.68 4,4m
Tailstock function counter spindle:
steady-rest on turret: SMW - SLU2X / 8-101mm
5-Axis CNC - Turning- and Millingcenter
DMG MORI - CTX beta 1250 TC 4A

- Main- Sub- and Millingspindle
- lower turret
- Conrol: Siemens Sinumerik 840 D sl Ergoline / Shopturn 3G
- 5-Axis-Simultaneous-Machining
- Betriebsstunden: Strom-Ein: ca. 7.500h / Spindellauf: ca. 2.000h



This ad was created with MODUL MWS - the software solution of LogoTech.
2013
Price
    request
125452338 103

TOS FMA-U for sale
Universal Milling Machines


Table clamping surface: 1400 x 800 mm Number of table grooves 8 Spindle axis distance from the column guide: 1000 mm Manual and machine spindle setting: 250 mm Spindle pitch 90 ° - 0 ° - 45 ° Spindle speed:  ...
used machine

Table clamping surface: 1400 x 800 mm
Number of table grooves 8
Spindle axis distance from the column guide: 1000 mm
Manual and machine spindle setting: 250 mm
Spindle pitch 90 ° - 0 ° - 45 °
Spindle speed: -1400 rpm
Spindle end distance from the table - min. 40 mm - maximum 1160 mm
Electric motor for spindle drive - power 2.2 / 3 kW
Machine weight: 4200 kg
An additional table (on which can be cut to a diameter of 5m)
1980
Price
    request
125460797 101

EMCO MC 1200 for sale
Machining Center - Vertical


x-travel: 1.200 mmy-travel: 600 mmz-travel: 600 mmControl: TNC 620 HeidenhainMain spindle:: turning speed range - main spindle: 50 - 10.000 min/-1power capacity - main spindel: 25 kWmax. Torque: 70 Nmtool taper: SK 40 d ...
used machine

x-travel: 1.200 mm
y-travel: 600 mm
z-travel: 600 mm
Control: TNC 620 Heidenhain
Main spindle::
turning speed range - main spindle: 50 - 10.000 min/-1
power capacity - main spindel: 25 kW
max. Torque: 70 Nm
tool taper: SK 40
distance spindle nose and table: 120 - 720 mm
work table::
table surface area: 1.400 x 650 mm
number of T-slots: 5
T-slot - width: 18 H8 mm
tool magazin::
number of toolpositions: 30 pos.
tool taper: SK 40
max. tool diameter: 80 mm
max. tool-dia with free toolbox: 125 mm
max. tool length: 280 mm
max. tool weight: 8,0 kg
max. total weight: 100 kg
tool changing time: 1,6 sec
feeds::
rapid traverse: 40 m/min
feed speeds: 20.000 mm/min
Accelaration: 5 m/s²
feed power: 5,8 kN
total power requirement: 35 kVA
weight of the machine ca.: 7,7 t
dimensions of the machine ca.: 5,0 x 4,0 x 3,2 m
Documents:
Chip conveyor:
Coolantsystem:
high pressure coolant: 30 bar
through spindle coolant:
paper band filter:
interface 4. axis:
4. axis: defekt / defect
Automatic Tool Changer:
elektr. hand wheel:
CNC - Machiningcenter Vertical
EMCO - MC 1200

- only ca. 4.900h Spindle-Runtime



This ad was created with MODUL MWS - the software solution of LogoTech.
2011
Price
    request
125452336 102

EXCEL SL-320 / 600 for sale
CNC Sloping Beds


CNC lathe EXCEL SL-320 / 600 04-02-102 delivery time: immediate number: 04-02-102 manufacturer: EXCEL type: SL - 320 / 600 MACHINE data year: approx. 1996 L x W x H: CA. 4000 x 2000 x 2000 mm weight: approx. 3500 kg  ...
used machine

CNC lathe EXCEL SL-320 / 600 04-02-102 delivery time: immediate number: 04-02-102 manufacturer: EXCEL type: SL - 320 / 600

MACHINE data year: approx. 1996 L x W x H: CA. 4000 x 2000 x 2000 mm weight: approx. 3500 kg

Good general condition specifications control: Fanuc 0 - T dimensions: Max turning diameter over bed: approx. Ã? 450 mm maximum swing over carriage: approx. Ã? 270 mm maximum turning length: approx. 600 mm bar passage: approx. Ã? 70 mm turret: number of who kzeugstationen: 12 PCs tool holder: VDI 40 spindle: speed range: approx. 40-4000 RPM spindle nose: A 2 - 8 drive power: approx. 22.0 kW automatic feeds & express ducts: feed range: approx. 1-10000 mm / min rapid traverse: X 10 / 15 m / min Reitst ock: MK 4 Accessories â?¢ 3 - bake - SMW chuck Ã? 250 mm â?¢ central lubrication â?¢ machine light â?¢ coolant system â?¢ machine documentation â?¢ emergency - off â?¢ electrical hand wheel â?¢ RS 232 data interface â?¢ conveyors â?¢ foot switch

Accessories on request price and other specifications on request
1996
Price
    request
125460791 102

GILDEMEISTER CTX 400S2 for sale
CNC Lathe - Inclined Bed Type


turning diameter: 440 mmturning length: 635 mmcontrol: Heidenhain 4290 total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mHeidenhain 4290 control inclusive TurnPlus3-jaw chuckc-axis ...
used machine

turning diameter: 440 mm
turning length: 635 mm
control: Heidenhain 4290
total power requirement: kW
weight of the machine ca.: t
dimensions of the machine ca.: m
Heidenhain 4290 control inclusive TurnPlus
3-jaw chuck
c-axis
driven tools
12 fold turret head
tailstock
chip conveyor

Technische Daten / technical details:
max. Umlauf-? über Bettbahnabdeckung / max. swing ? over bed 570 mm
max. Umlauf-? über Planführungsabdeckung / max. swing-? over sledge 420 mm
Planweg (x) / cross way (x) 220 Mm
Längsweg (z) / longitudinal way (z) 635 mm
Spindelbohrung / spindle hole 79 mm
Drehzahlbereich / spindle speed 25-5000 UpM /rpm
Werkzeugrevolver / turret head 12 fach /holes
Reitstockaufnahme / tail stock taper MK4
Eilgang X / rapid feed X 20 m/min
Eilgang Z / rapid feed Z 24 m/min.
Antriebsleistung Spindel 100%ED / drive capacity spindle 100%ED 21 kW
Gewicht der Maschine ca. / weight 5700 kg
Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -
Technical data, accessories and description of the machine are not binding.





This ad was created with MODUL MWS - the software solution of LogoTech.
2001
Price
    request
125452328 102

COLCHESTER TORNADO T8MS for sale
Automatics (Lathes) For Bars


OVERVIEW: Brand: Colchester Model: TORNADO T8MS Application type: Turning Machine type: Lathe Availability: Immediately Construction year: 2007 Production hours: 1112 Location: Latvia Origin country: United King ...
used machine

OVERVIEW:
Brand: Colchester
Model: TORNADO T8MS
Application type: Turning
Machine type: Lathe
Availability: Immediately
Construction year: 2007
Production hours: 1112
Location: Latvia
Origin country: United Kingdom

GENERAL DATA:
Measurements width: 1650 mm
Measurements depth: 4000 + 1800 mm
Measurements height: 1950 mm
Machine weight: 5000 kg

MAIN DRIVE:
Number of spindles: 2
Spindle speed range: 5000 1/min

CONTROL UNIT:
Brand: GE Fanuc
Model: Series 18i-TB

MOVEMENT:
X-AXIS movement: 240 mm
Z-AXIS movement: 540 mm
A-AXIS movement: 625 mm

TURRET:
Number of turrets: 12

MEDIA:
Main electronic connection: 415 V / 53 A / 50 Hz / 3 P
Chip conveyer: yes

ADDITIONAL EQUIPMENT:
1 - Chip conveyer
2 - Bar loader
3 - Tools (upon request)
2007
Price
  LV   request
125460786 104

WMW - BWF SI 8 S for sale
Internal Grinding Machine


internal diameter: 630 mmgrinding depth: 500 mmswing diameter: 800 mmworkpiece turning speeds: 16 - 250 U/mintotal power requirement: 21 kWweight of the machine ca.: 10,7 tdimensions of the machine ca.: 5380 x 2800 x 330 ...


internal diameter: 630 mm
grinding depth: 500 mm
swing diameter: 800 mm
workpiece turning speeds: 16 - 250 U/min
total power requirement: 21 kW
weight of the machine ca.: 10,7 t
dimensions of the machine ca.: 5380 x 2800 x 3300 mm
Equipment:
Four-jaw chuck, diameter 630 mm
Dresser
Coolant system with magnetic filter
Separate hydraulic system
Various internal grinding spindles.
Operating manual



This ad was created with MODUL MWS - the software solution of LogoTech.

Price
    request
125452325 102

OKUMA - HOWA ACT - 4 for sale
CNC Turning Machines


CNC lathe OKUMA - HOWA ACT - 4 - 04-02-099 delivery time: immediate number: 04-02-099 manufacturer: Okuma - Howa type: ACT - 4 MACHINE data year: approx. 1990 L x W x H: CA. 3000 x 2000 x 2000 mm weight: approx. 5000  ...
used machine

CNC lathe OKUMA - HOWA ACT - 4 - 04-02-099 delivery time: immediate number: 04-02-099 manufacturer: Okuma - Howa type: ACT - 4

MACHINE data year: approx. 1990 L x W x H: CA. 3000 x 2000 x 2000 mm weight: approx. 5000 kg

Good general condition specifications control: Fanuc 0 - T dimensions: Max turning diameter over bed: approx. Ã? 350 mm maximum swing over carriage: approx. Ã? 280 mm maximum turning length: approx. 730 mm bar passage: approx. Ã? 77 mm turret: number of who kzeugstationen: 12 PCs tool holder: right spindle: speed range: approx. 35-3500 RPM spindle nose: A 2 - 6 power: approx. 22.0 kW automatic feeds & express ducts: feed range: approx. 1-8000 mm / min rapid traverse: X 12 / Z 16 m / min tailstock: MK 5 accessories â?¢ 3 - bake - chuck Ã? 255 mm (Kitagawa B-10) â?¢ central lubrication â?¢ machine light â?¢ coolant system â?¢ complete machine documentation â?¢ emergency - off â?¢ electrical hand wheel â?¢ RS 232 data interface â?¢ various tool holder (Inn enbearbeitung) - 3 units â?¢ foot switch

Accessories on request price and other specifications on request
1990
Price
    request
125460772 210

SCM Method K for sale
Window production centre


Tenoning spindle: 1 St.Number of milling agregates: 5 St.Spindle diameter: 50 mm In order to sell still in useSCM METHOD K Machining center for windows and doorsTechnical specificationsMax. Working length: 2800 mm(using ...


Tenoning spindle: 1 St.
Number of milling agregates: 5 St.
Spindle diameter: 50 mm
In order to sell still in use

SCM METHOD K Machining center for windows and doors

Technical specifications
Max. Working length: 2800 mm
(using the stops)
minute Workpiece length: 200 mm
(clear pin dimension)
minute Workpiece height: 30 mm
Max. Workpiece height: 140 mm
Tenoning speed: 4/16 m / min
Feed rate: 3-15 m / min

Crosscut saw 4 kW with motor horizontal positioning over free
programmable axis control
Speed 3000 rpm
Saw blade diameter 400 mm, bore 80 mm
Extraction nozzle diameter 120 mm
automatic engine brake

Slotted spindle 7.5 kW with

Spindle diameter 50 mm
Spindle clamping length 620 mm
Spindle stroke under table 575 mm
Speed 3500 rpm
Max. Tool diameter 320 mm
upper bearings
Motorized vertical positioning via freely programmable axis control
automatic counter-timber beam
automatic engine brake
automatic star delta connection
Suction nozzle diameter 2 x 160 mm

1st profile spindle 5.5 kW clockwise and counterclockwise
(Synchronization) with
Spindle diameter 50 mm
Spindle clamping length 320 mm
Spindle stroke under table 265 mm
Horizontal adjustment 60 mm
Spindle speed 6500 rpm.
Tool diameter min./max. 100/220 mm
Motorized vertical positioning via freely programmable axis control
automatic engine brake
Extraction nozzle diameter 150 mm

2. Profile spindle 5.5 kW clockwise with
Spindle diameter 50 mm
Spindle clamping length 320 mm
Spindle stroke under table 265 mm
Horizontal adjustment 60 mm
Spindle speed 6500 rpm.
Tool diameter min./max. 100/220 mm
Motorized vertical positioning via freely programmable axis control
Extraction nozzle diameter 150 mm
automatic engine brake

Gear milling unit 5.5 kW with
Spindle diameter 50 mm
Spindle clamping length 160 mm
Spindle stroke 100 mm
Horizontal adjustment 60 mm
Speed 6500 rpm.
Tool diameter min./max. 100/200 mm
pneumatic single stroke programmable via control
Timed horizontal feed-in for insert milling for the execution of
non-continuous grooves via CNC control
Extraction nozzle diameter 150 mm
automatic engine brake

Glass saw 2,2 kW with
Saw shaft diameter 25 mm
Saw blade diameter max. 220 mm
Saw shaft clamping length max. 22 mm
Speed 5000 rpm.
Extraction nozzle diameter 50 mm
automatic engine brake

Motorized, height-adjustable roller feed with
closest roll spacing
Motor power 1.1 kW

complete with
-CE Compliance
- Crosscut saw, tenon cutting and slot part horizontally infinitely programmable
- Slot part 620 mm spindle length, anti-clockwise
- Programmable vertical movement via ball screws
- motor-driven tapping table movement
- automatically trailing splitter wood for all slot tool positions
- Workpiece clamping for single / double wood operation with
automatic pressure drop protection
- precise swiveling tap table +/- 0 - 60 °
- Extendable telescopic length stop with automatic
Differential control, working length 2800 mm
- Programmable vertical movement via ball screw
in position 2, 3 and 4
- Horizontal positioning on manually programmable
4-fold revolver to operate from the front of the machine
for positions 3, 4 and 5
- Continuous roller feed, swiveling for light
Tool change, with additional feed roller for
Milling and motorized height adjustment according to scale
- Glass bead saw with pneumatic vertical positioning on manual
adjustable 4-fold revolver,
Forced guidance of the glass retaining strip with non-return valve, use of the
Glass bead saw automatically controlled via cycle
- automatic synchronization - immersion function of the first
Profile spindle for tear-free milling of sash frames,
Horizontal positioning on manually programmable
4-speed turret to be operated from the front of the machine
- extendable support rail for large format sash frames
- Gear milling unit with pneumatic horizontal positioning,
Use of the glass bead cutting saw via automatic cycle of the
machine program
Vertical positioning on manually programmable 4-fold turret
- CNC machine control via programmable logic controllers
electronics (PLC) type CONTROL 20
- Motor protection switches for all motors
- Operating tools, operating instructions
- Weight 3600 Kg

special accessories

Motor amplification 11 kW in Pos. 2, 3, 4

(Technical information according to the manufacturer - without guarantee!)



This ad was created with MODUL MWS - the software solution of LogoTech.

3,000 €
    request
 page 1  >
You didn't find your wanted machine?   to all dealers(no registration necessary)
More models (2 or more machines):
(17)
sell machinery
Sell your machinery
to the price starting with only € 0.09 monthly per machine!
machinery sold

Sold machinery

Vertical Milling Machines DECKEL FP4A


OVERVIEW: Brand: DECKEL Model: FP4A Application type: Milling Machine type: Milling Machine Availability: Immediately Construction year: 1991 Production hours: 32000 Location: Netherlands Origin country: Germany GENERAL DATA: Measurements width: 3000 mm Measurements depth: 2700 mm Measurements height: 1630 mm Machine weight: 1950 kg MAIN DRIVE: Number of spindle: 1 Spindle speed range: 4000 1/min CONTROL UNIT: Brand: Grundig Model: Dialog 11 MOVEMENT: X-AXIS movement: 560 mm Y-AXIS movement: 500 mm Z-AXIS movement: 390 mm WORKPIECE: Workpiece drm: 80 mm Workpiece x: 485 mm Workpiece y: 385 mm Workpiece z: 380 mm Workpiece weight: 800 kg TABLE: Outer length: 900 mm Outer width: 530 mm TOOLS: Max weight: 450 kg Max tool diameter: 40 mm Max tool length: 150 mm MEDIA: Main electronic connection: 380 V Power consumption: 16.5 kVA Internal cooling: yes ADDITIONAL EQUIPMENT: 1 - 1x Tool holder

Automatics (Lathes) For Bars Colchester TORNADO T8MS


OVERVIEW: Brand: Colchester Model: TORNADO T8MS Application type: Turning Machine type: Lathe Availability: Immediately Construction year: 2007 Production hours: 1112 Location: Latvia Origin country: United Kingdom GENERAL DATA: Measurements width: 1650 mm Measurements depth: 4000 + 1800 mm Measurements height: 1950 mm Machine weight: 5000 kg MAIN DRIVE: Number of spindles: 2 Spindle speed range: 5000 1/min CONTROL UNIT: Brand: GE Fanuc Model: Series 18i-TB MOVEMENT: X-AXIS movement: 240 mm Z-AXIS movement: 540 mm A-AXIS movement: 625 mm TURRET: Number of turrets: 12 MEDIA: Main electronic connection: 415 V / 53 A / 50 Hz / 3 P Chip conveyer: yes ADDITIONAL EQUIPMENT: 1 - Chip conveyer 2 - Bar loader 3 - Tools (upon request)

Jig Boring Machine SIP HAUSER MP-54


X-travel: 650mm, y-travel: 450mm, z-travel: 500mm, clamping surface: 770x630mm, max. table load: 500kg, drilling spindle stroke: 160mm, drive power: 5kW.

CNC Long Turning Automatics POLYGIM DIAMOND 32 CSB SWISS TYPE


Automatic longitudinal turning Swiss POLYGIM DIAMOND CSB 32 SWISS TYPE was built in 2008. Technical data for CNC lathes POLYGIM DIAMOND CSB 32 SWISS TYPE: CNC Control: MITSUBISHI Working range: -maximum turning diameter: fi 33 mm -maximum turning length: 250 mm -the maximum diameter of drilling: fi 15 mm -the maximum diameter of the thread: M10 Processing of external diameters: -quantity: 5 PCs. -dimension of the CAP: 16 x 16 x 120 mm Treatment of internal diameter: -quantity: 4 PCs. -Sleeve dimension: 13 mm (ER20) Transverse driven tool:-number of tools: 3 PCs. -Sleeve dimension: 13 mm (ER20) -speed: 200-6000 RPM. Tools from the back to the internal diameter: -quantity: 4 PCs. -Sleeve dimension: 13 mm (ER20) Tool driven to face: -number of tools: 3 front, 3 rear -Sleeve dimension: 10 mm (ER16) -speed: 3000 rpm. Main spindle:-spindle bore diameter: fi 36 mm -spindle speed: 200-8000 RPM. -Spindle bore diameter: subspindle steals: fi 36 mm -spindle speed steals: 6000 RPM. -the maximum spindle stroke: 220 mm rapid feeds X, Y, Z: 18 m/min. Engines: -spindle motor: 5.5 kW -spindle motor steals: 1.5 kW -drive motors. X/Y/Z axis: 0.5 kW -Coolant pump motor: 0.55 kW -lubrication: 4 -power supply: 8.67 kW -the spindle axis height: 960 mm Machine dimensions:-overall dimensions: 2550 x 1140 x 1568 mm -weight: 2788 kg Compressed air supply: -Outlook: 10 l/min. -pressure: 5 kg/cm Equipment: -subspindle -lighting of the workspace -cooling system -orientation of przeciwwrzeciona every 5 degrees -sensor cut off part-receiver detail -Guide ring Rod fixed and Rotary -5 pieces of the outer surface of the turning handles -4 desktop holders for turning the inner surface of the -4-position for desktop tools for turning the inner surface of the rear -6-powered tool for working the transverse -3 to-powered tool to work from the front -3 to-powered tool to work from behind -automatic bar feeder: Fedek SUNNY 542 (3.2 m) -chip conveyor

Vertical Processing Centers DMG DMU 80 monoblock


Producer ..... DMG Year manufacture/Year overhaul ..... 2006 Control system Heidenhain ..... TNC 530 Clamping area of table ..... 1270x700 mm Travel X-axis ..... 980 mm Travel Y-axis ..... 630 mm Travel Z-axis ..... 630 mm Spindle speed ..... 20 - 12000 /min. Number of driven axes ..... 5 Cooling through spindle Pressure of cooling ..... 40 bar Spindle taper ..... SK 40 . Tool magazine Number of positions in magazine ..... 32 Max. load of table ..... 650 kg Control panel with handwheel, 3D probe, paper filtration. possible to test under power.

Milling Machine AJAX CLEVELAND MODEL 4


Table dimensions: 1600x342mm, spindle mount: SK 50.

Cylindrical Grinding Machine TSCHUDIN HTG 430


Center distance: 480mm, center height: 100mm, grinding wheel diameter: 500mm, max. grinding wheel width: 80mm, grinding wheel bore: 203.2mm, motor power: 5.5kW, spindle cone: MK 4, spindle nose: 3x M48, swivelling range: 360°, rotational speed: 65-500/min, quill cone: MK 3, quill stroke: 20mm, length: 2200mm, width: 1700mm, weight: 2.6t.

Grinding Machine DELAPENA SPEEDHONE EM


Working diameter: 1.143-79.375mm, spindle speed: 200-2500/min, motor power: 1.5kW, stroke length: 0-150mm, stroke speed: 60-350double strokes/min, stroke motor power: 0.37kW, length: 1210mm, width: 1210mm, height: 1680mm, weight: 225kg.

Horizontal boring machine TOS H100 A


X - the table is transversal, 1250 mm Y - spindle turret upright, 1000 mm Z - table longitudinally, 1250 mm W - spindle extension, 900 mm Spindle diameter, 100 mm Morse spindle cone execution 6 Power of the drive of the main motion, 7,5 kW Working surface of the table, 1250x1250 mm Capacity of the table, 3000 kg The speed of rotation of the flatbed, 0.8 ... 800 rpm Overall dimensions of the machine (LxBxH), 6000 x 3700 x 3000 mm Total machine weight 13500 kg

Boring Mills TOS Varnsdorf W9


Horizontal boring machine W9 TOS Varnsdorf K.102259 Diameter of working spindle mm 90 Depth of working spindle mm 710 Vertical spindle adjustment mm 900 (1120) Spindle speed: number of degrees 21 range min-1 14-400 Spindle speed with removable faceplate number of degrees 18 range min-1 28-1400 Speed of the face plate number of degrees 12 range min-1 14-180 Working feeds: 18 degrees in the mm / rev range 0.016-0.8 18 degrees in the range of mm min-1 12.5-600 Micro-axis mm min-1 5 Rapid traverse mm min-1 2400 Threads: 18 metric with pitch mm 0.25-12 24 Whitworth threads / 1 "120-2 Electric motor kW 7.5 Machine dimensions: length mm 3900 (4750, 5120) width mm 2500 (2600) Height mm 2650 (2875)

Turning Machines (Lathes) NAKAMURA-TOME TW-20 MMY


OVERVIEW: Brand: NAKAMURA-TOME Model: TW-20 MMY Application type: Turning Machine type: Lathe Availability: 01/08/2018 Construction year: 1997 Production hours: 35200 Location: Turkey Origin country: Japan GENERAL DATA: Measurements width: 3645 mm Measurements depth: 2179 mm Measurements height: 2200 mm Machine weight: 6500 kg MAIN DRIVE: Number of spindles: 2 Spindle speed range: 50-5000 1/min CONTROL UNIT: Brand: FANUC Model: Series 18-T MAIN DRIVE: X-AXIS movement: 195 mm Y-AXIS movement: 40 mm Z-AXIS movement: 265 mm WORKPIECE: Workpiece drm: 51 mm TURRET: Number of turrets: 2 TOOLS: Max tool diameter: 25 mm MEDIA: Main electronic connection: 50 Hz / 3 P Power consumption: 77 kVA Chip conveyer: yes Internal cooling: yes ADDITIONAL EQUIPMENT: 1 - Kamsan Bar Loader 2 - 1x 0° Live Tool 3 - 1x 90° Live Tool

Turning Machines (Lathes) NAKAMURA-TOME W-20 MMY


OVERVIEW: Brand: NAKAMURA-TOME Model: TW-20 MMY Application type: Turning Machine type: Lathe Availability: 01/08/2018 Construction year: 1995 Production hours: 1637 Location: Turkey Origin country: Japan GENERAL DATA: Measurements width: 3645 mm Measurements depth: 2179 mm Measurements height: 2200 mm Machine weight: 6500 kg MAIN DRIVE: Number of spindles: 2 Spindle speed range: 50-5000 1/min CONTROL UNIT: Brand: NAKAMURA-TOME Model: LUCK-BEI MAIN DRIVE: X-AXIS movement: 195 mm Y-AXIS movement: 40 mm Z-AXIS movement: 265 mm WORKPIECE: Workpiece drm: 51 mm TURRET: Number of turrets: 2 TOOLS: Max tool diameter: 25 mm MEDIA: Main electronic connection: 50 Hz / 3 P Power consumption: 77 kVA Chip conveyer: yes Internal cooling: yes ADDITIONAL EQUIPMENT: 1 - IEMCA Bar Loader 2 - 1x 0° Live Tool 3 - 1x 90° Live Tool 4 - Loading Robot

Turning Machines (Lathes) DMG MORI NLX 2500/500


OVERVIEW: Brand: DMG MORI Model: NLX 2500/500 Application type: Turning Machine type: Lathe Availability: Immediately Construction year: 2014 Production hours: 3171 Location: Hungary Origin country: Japan GENERAL DATA: Measurements width: 2200 mm Measurements depth: 1900 mm Measurements height: 1826 mm Machine weight: 4200 kg MAIN DRIVE: Number of spindles: 1 Spindle speed range: 4000 1/min CONTROL UNIT: Brand: DMG MORI ERGOLINE Model: CELOS MAIN DRIVE: X-AXIS movement: 260 mm Z-AXIS movement: 500 mm TURRET: Number of turrets: 1 ADDITIONAL EQUIPMENT: 1 - Power transformer 2 - Tool setter

Radial Drilling Machines Z 3050 X 16


Radial drilling machine with 3050 X 16 was built in 1989. This versatile general-purpose machine. It is suitable for drilling, countersinking, reaming, chamfering and thread cutting medium and large items. With the right equipment it is also possible to boring. Technical data drilling machine Z3050 X 16: -the maximum drilling diameter: 50 mm maximum range: 1600 mm -the maximum distance between the axis of the spindle and the column: 1600 mm -the minimum distance between the spindle axis and column: 350 mm -horizontal spindle head on your shoulder: 1250 mm -maximum distance from spindle face to the working surface of the base plate: 1220 mm (1250 mm) -minimum distance from spindle to base plate working surface: 320 mm (350 mm) -vertical stroke in column: 580 mm -arm lifting speed: 0.02 m/sec. -angle of rotation of the arm: 360 degrees -taper in the spindle: Morsea Nr. 5 -spindle speed range: 25-2000 RPM. -number of spindle speeds: 16 PCs. -feed range: 0.04-3.2 mm/Rev. -the amount of feeds: 16 PCs. -extension: 315 mm -depth of feed per rotation of graduated: 122.5 mm -maximum permitted torque on the spindle: 490 Nm -maximum permitted weight spindle: 15680 N -the power of main motor: 4 kW -engine power lifting arm: 1.5 kW -engine power the hydraulic lock: 0.75 kW -Coolant pump motor power: 0.09 kW -overall dimensions (l x w x h): 2500 x 1060 x 2655 mm -weight of the machine: ok. 3500 kg (3900 kg with a column guide)

Turning Machines (Lathes) SPINNER TC80077 SMCY


OVERVIEW: Brand: SPINNER Model: TC80077 SMCY Application type: Turning Machine type: Lathe Availability: Immediately Construction year: 2008 Production hours: 19461 Location: Hungary Origin country: Germany GENERAL DATA: Measurements width: 4923 mm Measurements depth: 1980 mm Measurements height: 2090 mm Machine weight: 7500 kg MAIN DRIVE: Number of spindles: 1 Spindle speed range: 4000 1/min CONTROL UNIT: Brand: SIEMENS Model: SINUMERIK 840D MAIN DRIVE: X-AXIS movement: 360 mm Z-AXIS movement: 980 mm ADDITIONAL EQUIPMENT: 1 - High pressure external cooler 2 - VDI 40 tool holder 3 - Electrostatic external air filter

Bottom-spindle copy moulders GRIGGIO T200


Spindle moulder GRIGGIO model T200 with: -side tenoning carriage -extended plane in entrance -adjustable casing, with Aigner fences -feeder at 4 wheels -top suspended electric box

CNC Turning Machines MATRA FUL 510x1000


CNC lathe MATRA FUL 510x1000 was produced in 2000. CNC lathe-specific data MATRA FUL 510x1000: -CNC control in Polish and German: Fagor 8055TC (the machine you can program the g code or supplement the ready field in marker overlays) machine reads dxf drawings -Turning length: 1000 mm -turning diameter: 510 mm -spindle speed: 5-2000 RPM -Chuck: fi 250 hydraulic head: 8 items VDi30 -extracted Bridge: increases the diameter of component manufacturing -taper tailstock: Morsea 5 -installed power: 13 KVA -size Lathes (l x w x h): 2500 x 1800 x 1900 mm -machine weight: 2.5 tons of equipment: a variety of high-quality knives for turning the company ISCAR

Heavy Lathes POREBA TCA 160


Heavy lathe POREBA TCA 160 was produced in 1959 by the famous Polish FUM POREBA. Technical data of lathe POREBA TCA 160: Scope of work:-height of tusks: 800 mm -maximum turning diameter over bed: 1600 mm -maximum turning diameter over support: 1300 mm -eyepiece: fi 800 mm -maximum turning diameter in the pó?okularze: 250 mm -maximum turning length: 6000 mm -maximum weight of workpiece between centers in: 16000 kG -permissible cross section of the chip (turning steel Rr = 60 kG/mm2) on a single support: 30 mm2 -permissible cross section of the chip (turning steel Rr = 60 kG/mm2) on a single support: 50 mm2 -permissible force on the knife: 6000 kG -the maximum torque at the spindle: 630000 kg.cm -the maximum cross section 70 x 70 mm knife: Cap Headstock: -number of spindle speeds: 24 n -the exponent of the speed: 1.25 -spindle speed range: 1,12-224 RPM., 1,12-224 r/min, 0.85-170 RPM. -front spindle neck diameter: 260 mm -slot in the spindle of the cone metric: # 120 -reducing Bush metric cone Tip: # 120/80 -spindle bore diameter: 105 mm -diameter of the blade Cap: 1600 mm Suport, feeds the normal: -20 longitudinal feed range: 0,19-5,0 mm/Rev. -20 transverse feed range: 0,095-2.5 mm/Rev. -20 feed on the upper tray of the range: 0,095-2.5 mm/Rev. Suport, feeds 8-20 longitudinal feed range: 1.5-40 mm/Rev. -20 transverse feed range: 0.75-20.0 mm/Rev. -20 feed on the upper tray of the range: 0.75-20.0 mm/Rev. Suport, feeds minute:-20 longitudinal feed range: 12-320 mm/Rev. -20 transverse feed range: 6-160 mm/Rev. -20 feed on the upper tray with a range: 6-160 mm/Rev. Suport, feeds to thread (the main screws. train.):-35 thread jumping metrycz. about t. : 1-50 mm -jumping 35 inch threads range: 24-1/2 scroll/inch Suport, feeds for threading on the top tray:-25 thread jumping metrycz. about t. 0.25-7 mm -jumping 35 inch threads/inch scroll: the scroll 28-3/inch Feed rates associated to the rolling cones of gradients creating: 1:1.5 (d) 1:1000 -rapid traverse: 4000 mm/min. Konik: -barrel diameter: 200 mm -stroke sleeve: 600 mm -slot in the spindle sto?. meter.: # 80 -radial offset: +-30 mm Glasses: -diameter adjustment range normal: 200-600, 200-500 equipment, okular, 300-800 mm -adjustment range of diameters okular special equipment: 30-300, 50-400, 200-500 mm Pó?okular: -adjustment range pó?okulara diameter: 50-250 mm Drive:-main motor power: 40 kW -the engine speed: 750 RPM. -rapid feed motor power: 2.2 kW -the engine speed rapid feed rate: 3000 rpm. -oil pump motor power: 0.37 kW -engine oil pump: 1500 rpm. -performance oil pump: 25 l/min. Sizes and weights: -distance between centres: 3000-15000 mm -weight for length 6000 mm and 1 support: ok. 30000 kg -extra weight Prov difference length 1000 mm: 1200 kg -the weight of the additional bracket: 1500 kg

Milling machine MICROCUT HBM 4


CNC FANUC 32i MB 2008 power 17.9 Kw table 1200 x 1500 mm Table rotation 360 capacity 5000 kg stroke x 2200 mm stroke y 1600 mm stroke z 1600 mm stroke w 550 mm spindle taper ISO 50 diam. Spindle 110 mm spindle speed 35/3000 rpm Warehouse 60 tools

Universal Lathes Up To 800 Mm Diameter PONAR REMO KEPNO TUX 63 B


Lathe PONAR REMO K?PNO TUX 63 B was built in the machine tool Factory PONAR REMO K?PNO in 2006 year. Technical data of lathe TUX 63B: -maximum turning diameter over bed: 630 mm -maximum turning diameter over cross slide: 380 mm -maximum turning length in between centers: 1500 mm -slot in the spindle, the cone metric: 80 mm -spindle: 71.5 mm -the width of the bed: 433 mm -slot in the tailstock sleeve Morse: 5 tailstock sleeve travel mm 180:- tailstock sleeve diameter: 90 mm -spindle speed range: 18-1800 rpm. -the number of spindle speeds: 21 -the number of feeds in the entire range of spindle speeds: 42 -feed range longitudinal: 0.08-3,26 mm/Rev. -the scope of the transverse feed rate: 0.04-1.63 mm/Rev. -the number of metric: 42 -range of metric: 1-88 mm -number of modular threads: 42 -range of modular thread: 1-88 II mm -number of inch threads: 42 -range of inch threads: 1-88 zw/1 " -the number of threads DP: 42 -range of DP threads: 1-88 DP -fast movement of bottom bracket: 4.2 m/min -life on the spindle torque: 980 Nm -maximum torque on the spindle (5 minutes): 1960 Nm jump lead screw: 6 mm -screw the cross slide stroke: 5 mm -the maximum cross section of the CAP the knife: 32 x 20 mm -speed synchronous motor: 750/1500 rpm. -main drive motor power: 3,9/7.2 kW -overall dimensions: 3130 x 1140 x 1285 mm -weight of the machine: 3200 kg

TORNIO HAWK TC 150 M Cincinnati Machine


LATHE HAWK TC 150 M Cincinnati Machine BRAND MODEL TC 150 150 200 YEAR Lathe Hawk HAWK-M complete with: Basic machine with CNC Fanuc 21i-TA Government Supply voltage 400V 50 Hz drip shavings, 12 positions VDI 30 turret to 5-7.5 KW-5500g "ASA spindle/1 ' Autocentrale to 3 jaw Chuck ø 52 mm. radial tool Kit Tools including: form B1, reduction sleeve. For more information contact us at + 39 030 725026 machinery and vision from Monday to Friday from 8:30 to 13:00 and from 14:00 to 19:00

CNC GRINDER FOR ROLLERS TSCHUDIN GRENCHEN HTG 342


CNC cylindrical grinder TSCHUDIN GRENCHEN HTG 22 E14 342 type was produced in 1987. In 2008 he underwent a modernisation, which lists: -numerical control system -servo axis -adjustable spindle drive -all electrical equipment: contactors, overload switches, buttons, etc. Technical data: -grinding length: 230 mm -the maximum diameter of grinding: fi 170 -the maximum diameter of the dial: fi 500 mm CNC grinder for shafts TSCHUDIN GRENCHEN HTG 22 E14 type 342 has used Siemens ET200S and servo drives STOEBER.

MILLING MACHINE FIL FIL FSM 300


MILLING MACHINE FIL FSM 300 Category: Milling Machine Type: mobile upright Brand: FIL Model: FSM 300 Capacity: 3500x1000x1250 mm Year built: 2008 FIELD WORK: Longitudinal (x): 3000 mm, vertical (y): 1250 mm Transverse ram (z): 1000 mm CNC CNC: Heidenhain TNC430 SPINDLE Spindle power: 30 kW Rotation speed: 10-3000 Rpm Taper: ISO50 FEEDS: Rapid x: 25 m / min, Rapid y: 25 m / min, Rapid z: 25 m / min ATC Locations: 24 Position: on mast PLAN OF ANCHORAGE Size (lxwxh): 3500x1000 mm Capacity: 15,000 Kg / m HEAD 1 Type: OVER Spindle taper: ISO50 Axle: 180 ° Max speed: 3000 rpm Machine weight: 24700 kg Fridge: yes

Boring Mills STANKOIMPORT 2L614


Boring machine STANKOIMPORT 2L614 produced in 1978. The machine is equipped with measuring, and has upgraded partly electronic. Technical data of boring STANKOIMPORT 2 l 614: -spindle diameter: 80 mm -table dimensions: 800 x 1000 mm -the maximum workpiece weight: 1000 kg -spindle speed: 20-1600 min -engine power: 4.5/6.7 kW -dimensions of the machine: ok. 4300 x 2200 x 2800 mm -weight: 7000 kg

Fresalesatrice FPT LEM M60


Technical data Running Long. 6000 mm. 1200 Trasv.mm race. Corsa 2000 Vert.mm. Working feeds 6000 mm/min. Rapid feeds 15000 mm/min. Motor power mand. 22 kW. Spindle speed 3000 rpm. Total installed power KW. 57 Data not binding to obtain/verify Date must be Standard equipment CNC HEIDENHAIN TNC 426 C. Auto Tools 40 pos. Auto dual-rotating head 2.5° x 2 .5° Anchor plans mm. diameter 1500x6000

Bed milling machine floor type FPT LEM M60


Technical data Running Long. 6000 mm. 1200 Trasv.mm race. Corsa 2000 Vert.mm. Working feeds 6000 mm/min. Rapid feeds 15000 mm/min. Motor power mand. 22 kW. Spindle speed 3000 rpm. Total installed power KW. 57 Data not binding to obtain/verify Date must be Standard equipment CNC HEIDENHAIN TNC 426 C. Auto Tools 40 pos. Auto dual-rotating head 2.5° x 2 .5° Anchor plans mm. diameter 1500x6000

Tube Bending Machines TELHOO CNC DW63NC


Pipe Bender TELHOO CNC DW63NC was produced in 2010 year. Complete tooling for bending 15 mm diameter and with different bending radii. The machine is suitable for the spindle (actuator to the introduction and pulling). Characteristic parameters of CNC bending machine TELHOO DW63NC: -diameters of bent tubes: up to 63 mm -the thickness of the wall of bent tubes: up to 4 mm -the maximum bending angle: 190 degrees -bending radius: up to 350 mm -power: 5.5 kW -overall dimensions: 3500 x 750 x 1100 mm -weight: 1500 kg

Radial Drilling Machines WRS 25/08


Radial drilling machine WRS 25 produced in 1992. WRS drills specific data 25/08: -the size of the work surface: 660 x 360 mm -the size of the work surface: 860 x 560 mm -dimensions: 1400 x 700 mm -drilling capacity in steel: 25 mm -drilling in cast iron: 30 mm -spindle speed: 65-2880 RPM -the largest travel: 160 mm -the number of feed motor spindle: 6 -distance between the spindle from the table: 10-500 mm -distance between the spindle from the Base: 780-940 mm -radial drilling range: 315-815 mm -motor power: 3 KW -Cone Morsea: MK3 -dimensions (l x w x h): 1460 x 700 x 2300 mm -weight: 1100 kg

CNC Milling Machines Elumatec 2009


Profile machining centre SBZ 130 eluCam Description 3-axis profile machining centre Designed for economical and efficient machining of aluminium, steel and stainless steel profiles All operations, such as routing, drilling and tapping are performed while the profile bar is stationary to protect the profile surfaces The on-board turret head ensures that tool changing times are kept very short, thereby optimising machining cycles The turret head can be equipped with eight tools or angle routing heads Automatic clamping adjustment enables the machine to position the material clamps 3-axis controller The tool spindle is designed as an additional axis Network connection Technical specifications Traverse path X-axis, 4,200 mm, 7,200 mm, 8,500 mm, 10,200 mm, 11,500 mm (additional lengths on request) Vmax. 60 m/min. Traverse path Y-axis, 485 mm, Vmax. 30 m/min. Traverse path Z-axis, 340 mm, Vmax. 30 m/min. Max. spindle speed 6,000 rpm, 18,000 rpm with high-speed spindle Spindle power output 5.5 kW Tool changer for eight tools on a turret head Compressed air supply 7 bar Power supply 400 V, 3~, 50 Hz, 35 A Air consumption per minute 100 l with spraying Machining length SBZ 130 – 7.2 m Max. machining length with profile end machining, 7,080 mm Max. machining length without profile end machining, 7,200 mm

Elumatec 2011


Profile machining centre SBZ 140 Description 4-axis profile machining centre Designed for economical and efficient machining of aluminium and thin-walled steel profiles All operations, such as routing, drilling and tapping are performed while the profile bar is stationary to protect the profile surfaces Machining with all tools at angles continuously adjustable from 0° - 180° The on-board tool magazine ensures that tool changing times are kept short, thereby optimising machining cycles The magazine can be equipped with eight tools A rotating angle head with two different tools is available for double-bar and end machining (0°?-?90°?-?180°?-?270°) (option) Two separate working zones enable machining in shuttle operation (option) 4-axis controller 15" colour display, USB ports and network connection Windows operating system Technical specifications Traverse path X-axis, 4,200 mm, 6,400 mm, 7,600 mm, 9,700 mm (additional lengths on request) Vmax. 65 m/min. Traverse path Y-axis, 850 mm, Vmax. 60 m/min. Traverse path Z-axis, 650 mm, Vmax. 60 m/min. Pivoting angle A-axis, 0° - 180°; freely programmable in 1/10° steps Max. spindle speed 24,000 rpm Spindle power output 11 kW, S1 Tool changer for eight tools, additional tool positions on request Compressed air supply 7 bar Power supply 400 V, 3~, 50 Hz, 63 A Air consumption per minute 180 l with spraying Machining length SBZ 140 - 9.7 m Max. machining length with profile end machining, 9,580 mm Max. machining length without profile end machining, 9,700 mm MACHINE IS PERFECT CONDITION. SET UP TIME IS END OF 2012. NOT USED SO MUCH AND FULL FUNTIONALITY.

Hob milling machines POREBA ZFA 75


POREBA enveloping machine ZFA 75 was produced in 1967 by Mechanical Factory "MUNICH". The machine is designed for the production of gears with straight, oblique teeth and worm gears. During operation without a steady handle, it allows for machining wheels with a maximum diameter of 800 mm, and when working with a steady support, the maximum diameter of the wheel is 450 mm. Technical date: The largest cut-out module: -normally: 6 mm -with reduced accuracy: 8 mm The largest diameter of the gear being machined: -with the support fixed: 450 mm -without a steady: 800 mm The largest diameter of a toothed wheel work with helical teeth: -at a helix angle of 30 °: 500 mm -at a helix angle of 60 °: 190 mm The largest milling length for straight teeth: 275 mm Range of distances between the workpiece the axes and the milling cutter: -the smallest 30 mm -the largest 500 mm Vertical milling cutter: 310 mm The smallest distance from the table surface to the milling cutter axis: 200 mm The largest diameter of the milling cutter: 120 mm Diameter of mandrels for setting the cutters: 22, 27, 32 mm Diameter of the hole on the table: 80 mm The number of spindles of the milling spindle: 7 Range of rotation of the milling spindle: 47.5-192 Vertical cutter range for 1 turn of the workpiece: 0.5-3 mm The range of radial feeds of the milling cutter for 1 turn of the workpiece: 0.1-1 mm The range of axial feeds of the milling cutter for 1 turn of the workpiece: 0.25-1 mm Main engine power: 2.8 kW Machine dimensions: 2395 x 1210 x 1975 mm Milling weight: 3800 kg Equipment: -a set of shift wheels for the guitar -change tires/wheels for the second guitar: 7 pcs. -spindles: 5 items -conical wheels: 2 pcs -claw coupling -tests: 5 items -hook key -DTR-technical and operational documentation It is possible to buy additional equipment of the machine, i.e.: -modular cutters with various modules, from 1-8:100 pieces (additional fee, price: $9990 net, visible in the last two photos)

HP Papierspindel fuer DesignJet 430,450,/DIN A-1 HP C4717-60005


HP - Papierspindel fuer DesignJet 430,450, / DIN A-1 HP - Nr. C4717-60005 / Neu abc.designjet-parts

HP Spindel Hub Latex L - 25500 HP CH955-67037


HP - Spindel HUb fuer Designjet L-25500 HP - Nr. CH955-67037 abc.designjet-parts

HP - Papierspindel 42 Zoll DesignJet 500/800 HP C7769-60243


HP - Papierspindel fuer DesignJet 500/510/800, 42 Zoll HP - Nr. C7769-60243

CNC Turning Machines MORI SEIKI MT-253/1000


OVERVIEW: Brand: MORI SEIKI Model: MT-253/1000 Application type: Turning Machine type: Lathe Availability: Immediately Construction year: 2000 Production hours: 64000 Location: Germany Origin country: Japan GENERAL DATA: Measurements width: 5000 mm Measurements depth: 3200 mm Measurements height: 2700 mm Machine weight: 12500 kg MAIN DRIVE: Spindle speed range: 3500 1/min CONTROL UNIT: Brand: MORI SEIKI Model: MSG-501 MAIN DRIVE: X-AXIS movement: 635 mm Y-AXIS movement: 110 mm Z-AXIS movement: 1000 mm WORKPIECE: Workpiece drm: 570 mm MEDIA: Power consumption: 58 kVA Chip conveyer: yes Internal cooling: yes

Horizontal Milling Machines Kitamura Mycenter H500


OVERVIEW: Brand: Kitamura Model: Mycenter H500 Application type: Milling Machine type: Machining Center Availability: Immediately Construction year: 1989 Production hours: 23200 Location: Germany Origin country: Japan GENERAL DATA: Measurements width: 7500 mm Measurements depth: 3800 mm Measurements height: 2910 mm Machine weight: 15000 kg MAIN DRIVE: Number of spindle: 1 Spindle speed range: 35-8000 1/min CONTROL UNIT: Brand: FANUC Model: 15M MOVEMENT: X-AXIS movement: 710 mm Y-AXIS movement: 610 mm Z-AXIS movement: 610 mm MEDIA: Chip conveyer: yes ADDITIONAL EQUIPMENT: 1 - Tools 1 - Tool holder

CNC Milling Machines MATCHMAKER VMC 1100 CNC


CNC milling center MATCHMAKER VMC 1100 was built in England in 2006. Technical data of the CNC machine MATCHMAKER VMC 1100: -CNC control: FANUC 0i-MC -Working feeds X, Y, Z: 1100 x 550 x 600 mm -table size: 1300 x 630 mm -spindle speed: 8000 RPM -handle tools: BT 40 -tool Magazine: 20 PCs. -machine weight: 6000 kg

CNC Turning Machines OERLIKON BOEHRINGER VDF400C-F


OVERVIEW: Brand: OERLIKON BOEHRINGER Model: VDF400C-F Application type: Turning Machine type: Lathe Availability: Immediately Construction year: 1985 Production hours: 120000 Location: Germany Origin country: Germany GENERAL DATA: Measurements width: 4365 mm Measurements depth: 2685 mm Measurements height: 2795 mm Machine weight: 16000 kg MAIN DRIVE: Number of spindle: 1 Spindle speed range: 3550 1/min MOVEMENT: X-AXIS movement: 1000 mm WORKPIECE: Workpiece drm: 400 mm MEDIA: Main electronic connection: 163 A Chip conveyer: yes Internal cooling: yes

CNC Turning Machines DOOSAN PUMA 240 MB CNC


CNC lathe DOOSAN PUMA 240 MB produced in 2007 year in Korea. The machine is equipped with a FANUC Series 21i-TB. Cnc lathe allows for effective machining, which allows you to save time and gain accuracy. CNC lathe-specific data DOOSAN PUMA 240 MB: -number of tools: 12 PCs. -the number of driven tools: 2 PCs. -spindle: 65 mm -stroke x axis: 205 mm -stroke y axis: 580 mm -diameter of the handle: 225 mm -rated power: 28.95 kVA -weight: 4140 kg -hydraulic Chuck -horse -four-bed

Vertical Numerically Controlled Machining Centres Dahlih DL-MCV 1020 BA


Make: Dahlih Model: DL-MCV 1020 BA Vertical Machining Centre Year: 2006 Condition: Used Machine type: Other Location of machine: UK Machine Details MAKE DAHLIH MODEL DL-MCV 1020 BA YEAR 2006 CONTROL FANUC 0i MC TABLE SIZE 1250 mm x 660 mm TRAVERSES X: 1020 mm Y: 550mm Z: 560 mm RANGE OF SPINDLE SPEEDS Upto 8000 RPM ATC 24 STATIONS SPINDLE TAPER BT 40 PLUS TWIN SCREW CONVEYORS COOLANT TRAY MACHINE MANUALS PRICE INCLUDES LOADING!

Self-Cleaning Disc Separators ALFA-LAVAL BRPX 417


Alfa-Laval Self-Cleaning Disc Separators for the food and beverage industry , high speed vertical disc centrifuge Made from stainless steel for the food and beverage industry. Approximate capacity: 10000 liter/hour The bowl is mounted on a vertical spindle driven by a vertically mounted motor, via a belt drive

Universal grinding machines KOMMUNAR 3Y131 (3U131)


Universal grinder for shafts and bores KOMMUNAR 3Y131 (3U131) produced in 1977 year in the Soviet Union. The machine is designed for external and internal grinding of cylindrical surface, and the surface of the flat flange, conical shaped. Grinder allows external grinding machines with automatic grinding wheel, on the headland of the table or a hand-fed and sanding with manual feed. Universal 3Y131 Sanders-specific data: -the maximum diameter of workpiece: 280 mm -maximum length of workpiece: 710 mm -the maximum diameter of workpiece in podtrzymce: 60 mm -height of tusks: 185 mm -maximum weight of workpiece: 55 kg -the largest grinding wheel diameter: 600 mm -rotation speed spindle grinding wheel diameter: 600 Prov 1111 Rev/min -the maximum angle of rotation of the spindle head: 30 degrees -the maximum diameter of the cut: 100 mm -maximum length of cut: 125 mm -spindle speed: 16900 RPM. -the size of the sanding spindle head stroke after bolt: 290 mm -time supply fast grinding wheel: 2 s -the size of the feeding speed, spindle head szlifirskiego from hydraulic drive: 50 mm -feed for one turn of the wheel: 0.5 mm -the value of the plot of limbusa feed precision: 0.001 mm -the value of the parcel for the diameter transverse feed limbusa: 0.005 mm -periodic feed grinding spindle head (headland of the table): 0,0025 – 0,025 mm -fast speed adjusting sanding spindle head: 240 mm/min -the amount of speed of rotation of the product: smooth, bezskokowa speed control -speed range: 40-327 RPM -angle of rotation: 0-90 degrees -dimensions of centres: SM4 -the weight of the grinder with accessories: 6200 kg -size grinding machines (at the extreme position of the moving parts): 5620 x 2585 x 1982 mm

Table Drilling Machine PBR


X-travel: 1500-2000mm, y-travel: 1200-1500mm, z-travel: 500mm, w-travel: 1500mm, drilling spindle diameter: 110mm, taper: ISO 50, milling spindle diameter: 160mm, milling cutter housing diameter: 44-221mm, table surface: 1000x1250mm, rapid traverse: 8000mm/min, tabel load: 4t, tool slots: 50-60, max. workpiece weigth: 45kg, max. tool length: 500mm, tool changer defective.

Lathe VDF BOEHRINGER V 800NC-II


Max. spindle torque: 10000Nm, rotational speed: 5.6-1120/min, feed rate: 0.001-8000mm/min, rapid traverse: 8000mm/min, boring force: 20kN, quill diameter: 125mm, quill stroke: 280mm, chuck diameter: 630mm, control: B32T, including accessories.

Manzoni 1222


LATHE HAWK TC 150 M Cincinnati Machine BRAND MODEL HAWK-150 YEAR 2002 About 150 M Lathe Hawk full TC: Basic machine with Fanuc 21i-TA Supply voltage 400V 50 Hz drip shavings, 12 positions VDI 30 turret to 5-7.5 KW-5500g "ASA spindle/1 ' Autocentrale to 3 jaw Chuck ø 52 mm. radial tool Kit Tools including: form B1, reduction sleeve. See images for specific datasheet. For more information contact us at + 39 030 725026 machinery and vision from Monday to Friday from 8:30 to 13:00 and from 14:00 to 19:00

Famar Pronto 6 Vertical Lathe Famar Pronto 6


2008 powered Standard Chuck diameter [mm] 260 Maximum Chuck diameter [mm] 260 Rated turning diameter [mm] 180 Maximum working diameter [mm] 250 maximum turning diameter [mm] 350 maximum working length [mm] 200 Spindle Nose [ASA] 6 Front bearing Ø [mm] 110 Power [kW] 23.6 Rated torque [Nm] 146 Max. [Nm] 196 Max. [Rpm] 5300 type of tool [VDI] 40 Tools [No.] 12 Max. [KW] 12.5 Max. [Nm] 88 Max. [Rpm] 8000/10000 Maximum tool length [mm] 250 Tool change time [sec] 0.25 in excellent condition Machine available from July 2018

Work Clock 600 MCM 14 pallets FMS Centers MCM Clock 600 14 pallet in FMS


Year 2001 2 Horizontal machining centers in the FMS FMS consists of 2 MCM CLOCK 600 MP14 pallet changer 14 positions Features of each machine: 500x500 pallet 600x600x700 races rapid 75 m / min Axis continuous B (4th axis) 360,000 pos. HSK63A chuck 15000 rpm Spindle motor 22 Kw torque 214 Nm electro OMLAT CNC Fanuc 16IM 200 tools each machine High adjustable pressure Renishaw tool setting Optical lines pressurized Supervisor jFMX (Windows) manual loading station for robot load point (robot not supplied)

CNC Milling Centers SW BA 25


The Centre of the vertical-spindle machining drilling mill SW BA 25 built in 1997. Technical data SW Center BA 25: -CNC control: SINUMERIK 840 SW3 -tool Magazine: 2 x 36 frames SK 40

lathe CNC EMCOTURN E65


CNC Fanuc Oi / TC Year 2005 Racing in X / Y / Z: 210 / +/- 40/610 mm from bar diameter: 65 mm Swing diameter max .: 500 mm Vaulting on the bench: 610 mm Distance between centers: 682 mm Rapid traverse in X / Y / Z 30/15/30 m / min CHUCK HOME Top speed .: 5000 rev / min Spindle nose: A2-6 Maximum drive power: 22

Four-sided planing machines SCM COMPACT 23K


Moulding machine 4 spindle + neutral Scm Compact 23K composition: Bottom spindle kW 7,5 Right and left spindles one motor kW 7,5 Upper spindle kW 5,5 Neutral spindle kW 5,5 Max width of work (finished section) 230 mm Max height of work (finished section) 125 mm Diameter of spindle tools-holcer 40 mm Useful length vertical spindles 140 mm Useful length horizontal spindles 253 mm Length neutral spindle 230 mm
Get the latest machine offers by email: order newsletter
