slotting machine vertical used for sale

CNC vertical machining center for machining metal parts. Numerical control: Siemens 810D Strokes: X 630 mm / Y 500 mm / Z 500 mm Table: 800 × 500 mm Maximum table load: 500 kg Spindle cone: ISO 40 Spindle speed: 10,000 rpm

X / Y / Z axis strokes: 1020 × 510 × 550 mm Spindle power: 11 kW Max. spindle speed: 6,000 rpm Spindle taper: BT 40 Tool magazine: 22 positions Weight (kg): approx. 6000 Year & Manufacturer: 1993 – FONG LEE Lots sold as is, unchecked, without tools or tool holders.

Manufacturer: SIGMA Year: 2002 Type: CNC Vertical Machining Center Numerical Control: FANUC 18M Axes: 3-Axis (X, Y, Z) Strokes: X 750 mm / Y 400 mm / Z 450 mm Table: 900 x 400 mm – max. load 600 kg Spindle: SK40 (DIN 69871-A) – 6,000 rpm – 15 kW – max. torque 191 Nm Tool magazine: random carousel – 21 tools Guides: Linear guides Weight: 6,000 kg Remarks: Italian-made CNC vertical machining center, functional machine.

Equipped with 30-position tool magazine T-slots 7 18 mm Spindle cooling Coolant circulating system Renishaw probe fitted

machine ready for transport and assessment on viewing day

Machine already ready for transport, to be assessed on viewing day. Needed for transport 7.5 mtr

machine ready for transport and to be assessed on viewing day. Machine clamps not included

CNC Vertical Machining Center Order: Heidenhain TNC 426 Axes: 3 Table (mm): 1100 × 600 X/Y/Z strokes (mm): 1000 × 600 × 800 Spindle: ISO 40, max. 8,000 rpm Tool magazine: 40 positions Equipment: Chip conveyor Serial number: Notes: Used machine,

M. No.: 700571/99-280108 Working width max. (mm): 660

Speed 40/80 1/min, incl. inlet and outlet

Cutting width: 520 mm Cutting height: 310 mm Working height: 1000 mm Cutting speed level 1: 25 - 85 m/min Cutting speed level 2: 120 - 500 m/min Cord edge: 3880 mm Saw band width: 3 - 16 mm Table size: 600 x 500 mm Table swivel range (in 4 directions): 15° Motor power: 1.5 kW Blade welding device: 2.4 kVA Machine dimensions (L x D x H): 1300 x 760 x 2140 mm Weight approx.: 500 kg Equipment: - Band saw blade - Stepless cutting speed - Reduction gearbox - Belt welding device with annealing unit - Machine light -Scissors - Grinding station - Chip brush - Blow-out device - LED digital display (to indicate the cutting speed) - Table with stop groove - Angle stop - Parallel fence

- Including 15 bar cooling pump, cooling tank with chip conveyor and Mazak Die-Mold package (software) - Tools and fixtures are not included

VERTICAL MACHINING CENTER IBARMIA TYPE ZHV45 L1600 YEAR 2004 Brand: IBARMIA Year: 2004 Model: ZHV45 L1600 Features Type :Vertical NC Type :FIDIA Table Area(mm) :2000 x 850 mm X Stroke (mm) :1600 Y Stroke (mm) :800 Z Stroke (mm) :800 Spindle Speed (RPM) :15000 Spindle Motor Power(kw) :19 Tool Magazine Capacity :40 tools Tool Attachment Type :BT 40 Max Tool Length :365 Weight (g) :14.000 g Equipment B-axis on head +/-105 Maximum tool weight 20 kgs X,Y,Z Axis Ruler Chip conveyor

machine ready for transport and to be assessed on viewing day

Wooden band saw with extendable and swivel saw table Roller diameter 200 mm Cutting height 80 mm Cutting width 180 mm Motor power 350 W Table size mm Table tilt 45 degrees Saw blade length 1400 x 6.5 x 0.35 mm Condition: never used / new (5)

- Machine is equipped with a Haas TR 210 Combined Rotary and Tilt Table (4th/5th Axis) - incl. cooling tank - Tools and fixtures not included

CNC vertical machining center for machining metal parts. Numerical control: Fanuc O-M Strokes: X 1,270 mm / Y 762 mm / Z 820 mm Table: 1,370 × 760 mm Spindle taper: ISO 40 (DIN 69871) Spindle power: 11 kW Spindle speed: 60 – 8,000 rpm Tool magazine: 21-position chain Total power: 30 kVA Lots sold as is, unchecked, without tools or tool holders.

- Includes heidenhain handwheel and 1 color signal light - Excluding cooling tank and cooling installation/pump >/br> - Tools and fixtures not included

CNC Control: HAAS X/Y/Z Axis Travels: 750 × 410 × 500 mm Max. Spindle Speed: 10,000 rpm 4th Axis: HAAS Compatible (Presence Shown) Spindle Hours: Approx. 19,678 h (Meter Reading) User Documentation: Present Weight (kg): Approx. 5600 Year & Manufacturer: 2000 – HAAS

Manufacturer: OMEGA Year: 1990 Type: High-capacity CNC vertical machining center Numerical control: FANUC 15M Axes: 3-axis (X, Y, Z) Strokes: X 1650 mm / Y 850 mm / Z 790 mm Table: 1900 x 850 mm Spindle: BT50 – up to 6000 rpm – gearbox 2 ranges Tool magazine: 30 positions Weight: approx. 15000 kg Notes: Heavy duty CNC vertical machining center, suitable for intensive machining and large parts.

This 3-axis Roders RFM 760 vertical machining centre was manufactured in 2005. It features a spindle speed range of 3,000 to 42,000 rpm and travel paths of 760 mm in X, 550 mm in Y, and 300 mm in Z. Equipped with Röders RMS 6 V3.6 control, it offers precise machining capabilities. If you are looking to get high-quality milling capabilities, consider the Roders RFM 760 machine we have for sale. Contact us for further details regarding this machine.

This 3-axis RÖDERS RHP 500 vertical machining centre was manufactured in 2007. It features a machining range of 500 mm × 552 mm × 300 mm and a table size of 600 mm × 540 mm. The machine is equipped with a milling spindle that reaches up to 42,000 rpm and has a tool changer with 42 places. If you are looking to get high-quality machining capabilities, consider the RÖDERS RHP 500 machine we have for sale. Contact us for further details.

This 5-axis RÖDERS RXU 1001 DSH was manufactured in 2016. It features a machining range of 800 mm × 855 mm × 500 mm and a maximum workpiece weight of 800 kg. The machine is equipped with a milling spindle that operates at 24,000 rpm and includes a tool changer for 24 tools. If you are looking to get high-quality machining capabilities, consider the RÖDERS RXU 1001 DSH vertical machining centre we have for sale. Contact us for further details.

Inv. Num. : 4427 Type: WMX 60i Producer: HURCO Created: 2017 Parameters: Control system: WINMAX Switch-on hours: 5648 h Operating hours: 1554 h Working table length: 1 680 mm Working table width: 660 mm Maximum table load (uniform): 1 360 kg Spindle drive power: 18 kW Maximum vertical spindle speed: 12 000 1/min X-axis travel: 1560 mm Y-axis travel: 660 mm Cone: SK40 Number of all tools: 30 pieces Maximum tool length: 300 mm Maximum tool weight: 15 kg Machine weight: 9 000 kg

Vertical machining center Chiron FZ08W :::SPECIFICATIONS::: CNC Model: Fanuc CNC version: 21M Tool connection: HSK 32 Spindle power: 3,7Kw Number of spindle revolutions: 15000 Number of tools: 12 X Axis Stroke: 300mm Y Axis Stroke: 250mm Z Axis Stroke: 250mm Rapid feeds linear axes X Y Z: 40 40 60m/min Guides: roller Pallet change: yes Pallet size: 550 x 300mm Maximum load allowed: 200Kg Rotopallet: yes Chip evacuator: carpet :::D IMENSIONS AND WEIGHT::: Length: 2600mm Width: 1400mm Height: 2100mm Weight: 2200Kg

Ref. -No.: 10370 Manufacturer: FANUC Year of construction: 1997 Type of control: CNC Control: FANUC Series 16-M Storage location: Halberstadt Country of origin: Irland X-Travel: 500 mm Y-Travel: 380 mm Z-Travel: 300 mm Machine length: 1560 mm Machine width: 2060 mm Machine Height: 2218 mm Rotary Table (Lxw): 650 x 380 mm Table Load: 200 kg Max. Tool Weight: 2 kg Max. Tool Length: 120 - 200 mm Max. Tool Diameter: 65 mm Tool change time: 1 s Tool Taper: MAS BT30, MAS P30T-1 (45°) Numbers Of Tools In Magazin: 10 Tool changer: Revolvertyp (Spindel unabhängig vom Revolver) Turning Speed Range - Stepless: 1-15000 mm / min Rapid Traverse X-Axis: 48 m / min Rapid Travel Y-Axis: 48 m / min Rapid Traverse Z-Axis: 48 m / min Weight Of The Machine Ca.: 1,7 t Max spindle speed: 8000 min⁻¹ Positioning accuracy in one direction (1): 0,006 / 300 mm Positioning repeatability (2): +/- 0,002 mm ...

Ref. -No.: 10356 Manufacturer: AGIE CHARMILLES Year of construction: 2007 Type of control: CNC Control: iTNC530 Country of origin: Schweiz X-Travel: 800 mm Y-Travel: 500 mm Z-Travel: 540 mm Main spindle speed range: 16000 RPM Table Dimensions (Lengthxwidth): 910x500 mm Table Load: Vmax = 500kg, 5m/min = 1100kg kg Number of T-slots: 5 Tool change time (chip-to-chip): 8 s Max. Tool Weight: 6 kg Max. Tool Length: 305 mm Max. Tool Diameter: 77 mm Tool change time: 6 s T - slot spacing: 100 mm Numbers Of Tools In Magazin: 24 Tool changer: Doppelarm, seitlich montiert Rapid Traverse X-Axis: 24 m / min Rapid Travel Y-Axis: 24 m / min Rapid Traverse Z-Axis: 20 m / min Further information: Addition: probe

Ref. -No.: 10339 Manufacturer: AGIE CHARMILLES Year of construction: 2008 Type of control: CNC Control: Heidenhain iTNC 530 (2P) Storage location: Halberstadt Country of origin: Schweiz serial number: 107.20.00.040 X-Travel: 650 mm Y-Travel: 600 mm Z-Travel: 500 mm Main spindle drive power: 30/39 kW Main spindle speed range: 20.000 RPM Table Dimensions (Lengthxwidth): 800 x 600 mm Table Load: 500 kg Max. Workpiece Weight: 6,5 kg Tool change time (chip-to-chip): 7 s Max. Tool Length: 300 mm Max. Tool Diameter: 130 mm Tool change time: 1,5 s Workpiece Diameter At Full Load: 80 mm Workpiece Diameter With 2 Vacant Positions: 130 mm T - groove width: 14 mm T - slot spacing: 63 mm Tool Taper: HSK-A63 Numbers Of Tools In Magazin: 60 Tool changer: CT-60 Feed Speeds X/Y/Z Axis: 40/40/30 mm / min Feed Capacities X/Y/Z: 4/4/6 N Further information: Laser tool measuring system Type = BLUM laser syst ...

Ref. -No.: 10304 Manufacturer: SPINNER Year of construction: 2007 Type of control: CNC Control: Siemens 840 D with SHOP Mill Storage location: Halberstadt Country of origin: Germany X-Travel: 1100 mm Y-Travel: 610 mm Z-Travel: 610 mm B-Axis: 0.001 prepared for 4 th axis ° Main spindle drive power: 25 kW Main spindle speed range: 6000 RPM Table surface: 1200 x 600 mm Table Load: 1000 kg Tool Taper: SK 50 Numbers Of Tools In Magazin: 24 axes: 4 Rapid Traverse X-Axis: 18 m / min Rapid Travel Y-Axis: 18 m / min Rapid Traverse Z-Axis: 15 m / min Main Drive: 25 kW Weight Of The Machine Ca.: 8 t Further information: - additional 4 axis (Dividing head)

Ref. -No.: 10144 Manufacturer: DECKEL Year of construction: 2001 Type of control: CNC Control: Heidenhain Mill Plus Storage location: Halberstadt Country of origin: Deutschland Machine-No.: 11130000713 X-Travel: 880 mm Y-Travel: 630 mm Z-Travel: 630 mm Machine length: 3600 mm Machine width: 2700 mm Machine Height: 2500 mm Table Dimensions (Lengthxwidth): 1250 x 700 mm Table Load: 1000 kg Max. Workpiece Weight: 8 kg Tool Taper: SK 40 Tool Piece Magazine With: 32 Pcs./pcs. Spindle Speed: 18.000 RPM Rapid Traverse: 30 m / min Total connected load max.: 37 kVA Weight Of The Machine Ca.: 9 t Operating hours: 42.340 H Further information: Additional information: • Table: swivel milling head

Ref. -No.: 10362 Manufacturer: SCHIESS Year of construction: 2023 Type of control: CNC Control: Siemens - Heidenhain - Fanuc (configurable) Storage location: Halberstadt Country of origin: Germany financing: nach Anfrage Spindle Speed Max.: 3500 RPM Pallet diameter: 1600 mm Max. machining diameter: 2000 mm Number of claw boxes: 4 pc Clamping force per claw box: 55 kN Number of radial T-slots: 8 Max. speed for turning: 140 min-1 Max. speed for milling: 5 min-1 Max. torque for turning: 27000 Nm Max holding power: 36 kN positioning speed: 3000 mm Adjustment from center to right: 850 mm Shift from center to right (head and tool change): 2750 mm Adjustment from center to left: 850 mm Max feed rate: 2000 mm / min Max rapid traverse speed: 20000 mm / min Max. Feed force: 30 kN cross-section: 280 x 240 mm Max. cutting force when turning: 36 kN Max Spindle Torque: 1200 Nm Pressure: 6 bar Air requ ...

Ref. -No.: 10359 Manufacturer: BRINKMANN Year of construction: 2005 Type of control: CNC Storage location: Halberstadt Country of origin: Deutschland Tool holder type: Sauter Werkzeugrevolver Operating hours: 45000 Hours Further information: Hinged chip conveyor Coolant cleaning with 2 pumps Cooling system 1x jaw chuck without cooling mist exhaust system

Key data: 1000 mm, 500 mm, 500 mm

Inv. Num. : 5515 Type: VOC 1000 Produzent: INTOS Erzeugt: 2003 Parametern: Steuerungssystem: Siemens 810D Arbeitstischlänge: 1100 mm Arbeitstischbreite: 500 mm Anzahl der Stapelpositionen: 20 Drehzahl: 8000 1/min Verfahrwege X-Achse: 1000 mm Verfahrwege Y-Achse: 500 mm Verfahrwege Z-Achse: 500 cm Spindelleistung: 25 kVA Kegel: SK 40 Maschinengewicht: 4619 kg Ausstattung: Späneförderer Verfügbarkeit: April 2022 2022: GO Spindel

Key data: 1000 mm, 500 mm, 500 mm

Inv. Num. : 6776 Type: VOC 1000 Produzent: INTOS Erzeugt: 2003 Parametern: Steuerungssystem: SIEMENS Sinumerik Arbeitstischlänge: 1100 mm Arbeitstischbreite: 500 mm Maximale Drehzahl der Spindel: 8000 1/min Verfahrwege X-Achse: 1000 mm Verfahrwege Y-Achse: 500 mm Verfahrwege Z-Achse: 500 mm Spindelleistung: 25 kVA Kegel: SK 40 Anzahl der Stapelpositionen: 20 Stücke Maschinengewicht: 4619 kg

Key data: 1020 mm, 510 mm, 610 mm

Inv. Num. : 6222 Type: BMC 4020 Producer: HURCO Created: 2000 Parameters: Control system: UNIMAX Operating hours: 59,600 h Work table length: 1220 mm Work table width: 510 mm Minimum vertical spindle speed: 80 1/min Maximum vertical spindle speed: 8000 1/min X-axis travel: 1020 mm Y-axis travel: 510 mm Z-axis travel: 610 mm Spindle power: 15 kW Maximum tool weight: 682 kg Max. tool weight: 7 kg Machine height: 2670 mm Machine length: 3350 mm Machine width: 2320 mm Machine weight: 5600 kg Equipment: Tool clamping 2015: Spindle change

Key data: 1300 mm, 540 mm, 720 mm

Inv. Num. : 6148 Type: CFV 1300i Producer: Cincinnati Created: 2010 Parameters: Control system: Heidenhain iTNC 530 Hours: 59260 h Duty cycle: 26295 h Work table length: 1370 mm Work table width: 610 mm Tool magazine: 24 pieces Maximum vertical spindle speed: 9000 1/min X-axis travel: 1300 mm Y-axis travel: 540 mm Z-axis travel: 720 mm Cone: SK 40 Equipment: IKZ Conveyor New spindle 24x clamping tools 4x Hydro Vise

Key data: 1800 mm, 850 mm, 800 mm

Inv. Num. : 6502 Type: FTV 850 Producer: Cincinnati Created: 2002 Parameters: Control System: Acramatic Work table length: 2300 mm Work table width: 900 mm Tool magazine: 36 pieces X-axis travel: 1800 mm Y-axis travel: 850 mm Z-axis travel: 800 mm Spindle power: 42 kW Machine height: 3800 mm Machine length: 7200 mm Machine width: 3500 mm Machine weight: 17000 kg Equipment: Technical Documentation 40x Tool Holder 1x D100 cutter

Key data: 1050 mm, 510 mm, 560 mm

Inv. Num. : 5759 Type: SVM 105 Producer: LILIAN Created: 2013 Parameters: Control System: Fanuc Oi-MC Operating hours: 23000 h Spindle hours: 5081 h Work table length: 1200 mm Work table width: 500 mm Maximum table load (uniform): 650 kg Tool magazine: 32 pieces Speed: 60-8000 1/min X-axis travel: 1050 mm Y-axis travel: 510 mm Z-axis travel: 560 cm Cone: BT40 Max. tool weight: 6 kg Main motor power: 11/15 kW Machine height: 2558 mm Machine length: 3050 mm Machine width: 2319 mm Machine weight: 5200 kg Equipment: Conveyor IKZ

Key data: 760 mm, 430 mm, 450 mm

Inv. Num. : 6921 Type: VMCF-760 Producer: Microcut Created: 2007 Parameters: Control system: Fagor 8055 MC Work table length: 900 mm Work table width: 410 mm X-axis travel: 760 mm Y-axis travel: 430 mm Z-axis travel: 450 mm Cone: ISO 40 Machine weight: 3,300 kg

Control Fanuc ... 31i - B5 Clamping table surface ... 850x410mm Axis X ... 700mm Axis Y ... 400mm Axis Z ... 330mm Spindle speed ... 0-24000/min. controlled axes ... 5 cooling ... 35bar Spindle mounting... BBT30. Rapid traverse ... 54m/min Main engine power ... 4.7/14.2kW Max. table load ... 300kg L x W x H ... 2100x2165x2800mm Machine weight ... 2300kg Magazine slots ... 21 + Robot FANUC LR Mate 200iD The machine is in good condition, possible to test under electricity.

chuck diameter, mm 7100 (8000) Max. work piece diameter, mm 8000 Max. work piece height, mm 3200 Max. work piece weight, kg 125000 Chuck speed, rpm 0,22...20,1 Max. ram movement of vertical support, mm 2000 Max. movement of vertical, mm 4275 Support feed range, mm/min 0,0352...285 Support rapid feed, mm/min 2500 Supports possible work angle, deg. -15...+40 Jaws, units 4 Machine overall dimensions, mm 8615 x 17600 x 9800 Machine weight, kg app. 247300

Key data: 750 mm, 500 mm, 600 mm

Inv. Num. : 7098 Type: DBZ Producer: AXA Created: 2008 Parameters: Control system: Heidenhain iTNC53O Duty cycle: 57676 h Hours: 23680 h Work table length: 1000 mm Work table width: 500 mm Maximum table load (even): 800 kg Maximum vertical spindle speed: 6000 1/min X-axis travel: 2x 750 mm Y-axis travel: 500 mm Z-axis travel: 600 mm Maximum tool diameter: 85 mm Max. tool weight: 8 kg Max. tool length: 400 mm Number of stacking positions: 22 pieces Machine height: 3550 mm Machine length: 4460 mm Machine width: 2250 mm Machine weight: 12000 kg Equipment: Chip conveyor 300m Suction Showa CRD-1500RA-CE-0043 Preparation for the 4th axis

Dart VMC 650 XL/A twin speed vertical machining center ::SPECIFICATIONS::: CNC Model: Fanuc CNC Version: 18 - M Tool holder: ISO 40 Spindle power: 11Kw Spindle speed: 8000 Number of tools: 24 X-axis stroke: 800mm Y-axis stroke: 500mm Z-axis travel: 610mm Rapid feeds for linear axes X Y Z: 30m/min Table size: 1000 x 500mm Table capacity: 400Kg Guides: roller High refrigerant pressure: yes Chip conveyor: belt conveyor

Specifications: Cutting width 500 mm Table size 800 x 820 mm Travel approx. 350 mm Cutting height under guide approx. 400 mm Belt length 4000 mm Infinitely variable speeds approx. Gearbox stage 1 15 – 80 m/min Gearbox Stage 2 75 - 305 m/min Gearbox Stage 3 207 - 944 m/min

Paventa Speed 3100 moving column machining center ::SPECIFICATIONS::: CNC Model: Selca - CNC Version: 4040R - Tool Holder: ISO 40 - Spindle Power: 15Kw - Spindle Speed: 8000 Number of tools: 30 + 30 - X axis stroke: 3100mm - Y axis stroke: 600mm - Z axis stroke: 600mm - X Y Z linear axis rapid feeds: 15m/min Chip conveyor: belt conveyor

Key data: 1050 mm, 510 mm, 510 mm

Inv. Num. : 7111 Type: NEXUS 510 C Producer: MAZAK Created: 2008 Parameters: Control system: MAZATROL MATRIX NEXUS Duty cycle: 14206 h Hours: 4777 h Work table length: 1300 mm Work table width: 550 mm Spindle drive power: 11 kW Speed: 12,000 rpm X-axis travel: 1050 mm Y-axis travel: 510 mm Z-axis travel: 510 mm Cone: ISO 40 Number of stacking positions: 30 pieces Machine weight: 6886 kg Equipment: Tool Probe IKZ

Inv. Num. : 7105 Type: INNO 810 Producer: MACRO Created: 2011 Parameters: Control system: HEIDENHAIN 530 Work table length: 810 mm Work table width: 410 mm Maximum table load (uniform): 300 kg Maximum vertical spindle speed: 8000 1/min X-axis travel: 810 mm Y-axis travel: 410 mm Z-axis travel: 500 mm Maximum feed speed axis X: 3000 mm/min Maximum feed speed axis Y: 3000 mm/min Maximum feed speed axis Z: 3000 mm/min Machine height: 2500 mm Machine length: 3800 mm Machine width: 2000 mm Machine weight: 4000 kg Equipment: Workpiece probe Tool Probe

Key data: 3000 mm, 800 mm, 720 mm

Mazak VTC 800/30-SR CNC 5 (6) Axis Travelling Column Vertical Machining Center CNC control Mazatrol Matrix 2 Table size 3500 x 820 mm Table load 2500 kg Number of pallets 1 Travel X-Y-Z axis 3000 - 800 -720 mm C-axis (table rotation) 0.0001° B-axis travel ± 110° Spindle speed 35 - 18,000 rpm Spindle taper HSK-A63 Spindle motor 35-26 kW Magazine capacity 30 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail.
