rotation used for sale

A rotational molding machine consisting of 2 rotational units and an oven in between. Rotation unit: Weight: 7500kg, weight with load: 11500kg, on 8 350mm x 350mm base plates. Rotation unit diameter: 3300mm. Compressed air nozzles: Pneumatic connection: 1inch, water connection: 0.5inch, 6bar, height: 1500mm. Oven: Dimensions X/Y/Z: approx. 5800mm/4200mm/6800mm, weight: approx. 27000kg, max. temperature: 400°C. Documentation available.

Rotation cutter Built in 2006; working condition

weight max.: 1000 kg table turning speeds: 180 - 1800 mm/min. roll diameter: 200 x 50 mm workpiece diameter: 50 - 1500 mm volt: 230 V / 50 Hz range L-W-H: 950 x 220 x 344 mm Mitlauf weight: 100 kg range L-W-H: 1270 x 310 x 344 mm Antrieb Furnishing: - Consists of a drive unit and a follower unit. - Clean, fluid turning movement even in the lower speed range. - PU rollers. - The container diameter can be adjusted quickly and easily using socket pins. - Hand remote control (3 meters) to set the speed and right / Counterclockwise rotation. - foot switch. - Compact, stable structure, easy to handle. Scope of delivery: - 1 control (integrated) - 1 foot switch - 1 wired remote control - Operating instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

weight max.: 3000 kg. table turning speeds: 120 - 1200 mm/min. roll diameter: 250 x 75 mm workpiece diameter: 150 - 2000 mm volt: 230 V / 50 Hz range L-W-H: 1210 x 300 x 480 mm Mitläufer weight: 154 kg range L-W-H: 1510 x 500 x 480 mm Antrieb Furnishing: - Consists of a drive unit and a follower unit. - Clean, fluid turning movement even in the lower speed range. - PU rollers. - The container diameter can be adjusted quickly and easily using socket pins. - Hand remote control for setting the speed and clockwise - counter clockwise rotation. - foot switch. - Compact, stable structure, easy to handle. Scope of delivery: - 1 control (integrated) - 1 foot switch - 1 wired remote control - Operating instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Positioning unit PAGUS stroke: 100 mm, rotation: 330° lifting motor: KEB 57/2.200.4,2 Rotary motor: PHYTRON ZSH 57-200-4,2 Rod diameter: Ø 30 mm Flange diameter: Ø 45 mm bolt circle diameter: Ø 55 mm hole diameter: Ø 4.5 mm with guide frame, 70 mm height adjustable used, tested ! Dimensions: 530 x 250 x 230 mm

Rotationsfilter,rustfrit stål,Fratelli Gianazza type 15020,5,6 m²

In working condition Punch force- 15 t Work area 1000х1000 Max thickness - 4.5 mm Plus:- 2 x Extra Original Side Tables Additional Programme Memory Storage Unit Full Set of Books Safety Optical Guards

weight max.: 2,2 t workpiece diameter: 101 - 1524 mm feed speeds infinitely variable: 0 - 3600 mm/min gear diameter: 254 mm gear width: 76 mm total power requirement: 0,5 kW weight of the machine ca.: 0,245 t dimensions of the machine ca.: 1,02 x 0,82 x 0,5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

weight max.: 5,0 t workpiece diameter: 303 x 2438 mm feed speeds infinitely variable: 0 - 1745 mm/min gear diameter: 305 mm gear width: 100 mm total power requirement: 0,5 kW weight of the machine ca.: 0,37 t dimensions of the machine ca.: 1,5 x 1,05 x 0,7 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Container turning device, roller block PAGUS load capacity: approx. 10 t per trestle 3 pieces wheel diameter Ø 320 mm without drive ! Weight: 3 x 950 kg Dimensions: 3 x 2020 x 870 x 1100 mm

weight max.: 5 t workpiece diameter: 300 - 2500 mm drum diameter: 250 x 100 mm feed: 100 - 1000 mm/min total power requirement: 0,75 kW weight: 0,6 t dimensions: 1,5 x 1,0 x 0,6 m characteristics • Self-aligning for multiple diameters • Infinitely variable speed of the drive unit • Polyurethane coating of the rollers • Optimum load distribution (4 rolls/unit), particularly gentle for workpieces with low wall thickness and sensitive surfaces • High stability due to the solid construction of the machine • CE certificate • Very good value for money • Remote control on the cable • Documentation in English The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

BOSCHERT COMPACT 1250 ROTATION-INDEX punching machine was manufactured in 2014 in Germany. The machine, used in precision nibbling, punching and stamping of workpieces, is characterised by excellent stability and rigidity even during demanding series machining. Workpieces with a maximum thickness of 10 mm are machined with a force of 28 tonnes on a large brush table, protecting sheet metal surfaces from scratches and scrapes. The punching tool head is equipped with a ROTATION tool station drive, which smoothly rotates each punching tool in a range of 360°, guaranteeing fast and trouble-free machining of even the most complex shapes. The punching machine is also equipped with a BOSCHERT einfach besser TFT control panel with an intuitive BOSCHERT CNC 32050 CNC controlle for programming machining modes and controlling the machine operation. The total weight of the machine is 8400 kg.  ...

The TRUMPF TRUMATIC 120 Rotation punching machine was built by the well-known German company TRUMPF in 1991. The compact sheet metal processing center enables profiling, punching and sheet forming. The CNC control of the machine uses a graphical interface to program the rotation of all tools. Technical data of the TRUMPF TRUMATIC 120 Rotation punching machine: Performance : - punching force: 15 t (150 kN) - maximum sheet thickness: 4 mm - maximum workpiece weight: 64 kg - maximum punching diameter: 38 mm Speeds: - maximum speed of a single axis: 40 m / min. - maximum speed of two axes simultaneously (XxY): 56 m / min. - rotary axis: 360 degrees / s, full rotation - maximum number of strokes: 320 l / min. Drive type: - X / Y / Z axis: AC motors, maintenance-free - punching: hydraulic drive Control system: TRUMAGRAPH CC 200 Accuracy: - the smallest programmable m ...

Durma RP6 Rotation CNC Punch Machine 6 stations Machine is in good working condition 1250 x 30 Ton Control unit : Siemens Multimatrix tooling Toolings are included(7x7mm, 9x9mm, 17x17mm, 20x4mm, Ø8mm, Ø10mm)

WE ARE SELLING AN NICE CONDITION TRUMPF ROTATION. MACHINE IS READY FOR USE. MACHINE INCLUDES ALSO TOOL GRINDER AND EXISTING TOOLS FOR CUSTOMER WE ORGANIZE TRANSPORT AND DISMANTLING AS WELL

Key data: 22 t, 2535 mm, 1280 mm

Manufacturer / Manufacturer: Trumpf Typ / Type: Trumatic 500 Rotation Stocknummer / stock number: 1008 Year of Manufacture: 1995 Punching force: 22 tons Max. sheet thickness: 8 mm Connected load: 19 kVA Machine weight: 13,8 tons

The machine is in good technical condition. Press force 30 tons (300 kN) Sheet format 1250×2500 (processing of flat bars up to 6000 mm) RS: Siemens By prior arrangement, the possibility of a tour in progress.

MACHINE IS GREAT WORKING CONDITION . INCLUDING TOOLINGS WEIGHT: 4300 KG YEAR: 1991

sheet width: mm plate length: mm plate thickness: mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: HSM , Type: Rotationsquerschneider, Year: 2012, Control: Siemens, Längenogabe: yes, Stückzähler: yes, Cross cutting guillotine: yes, Cutting lenght mm: 1.500 - 2.620, Schnittbreite min-max mm: 600 - 2.100, Abstapelung der Funierblätter: für Folien, Hebebühne: yes, machine ready for demonstration: yes, FREE TEXT: Anlage wurde um einen UV Strahler und ein Kühlaggregat erweitert/ Vorschub max.40 Meter, Year :2012

The machine has: -3 punching heads with quick-change tool system -fast tool change -2 sheet clamps - use of all types of punching and forming tools of the Trumpf standard - X-axis 0-3000 Y-axis 0-1250 - positioning speed of the axes 60 meters per minute, positioning accuracy 0.05 mm -automatic height adjustment of the tool stroke Specifications: punching force - 28 t adjustable height of striker stroke - for one stroke 105 mm maximum punching diameter - 90mm maximum thickness of the processed material - 6 mm

faceplate diameter: 3200 mm swing diameter: 3500 mm turning height: 2200 mm range L-W-H: 7730 x 6240 x 6700 mm control: Typ 840 D sl voltage: 3 x 400 V frequency: 50 Hz turning speeds: 0,8 - 40 U/min max. turning diameter: 3500 mm total power requirement: 51 kW weight of the machine ca.: 86 t Technical specifications Machine type: CNC vertical lathe Manufacturer: Rafamet Year of manufacture: 1973 conventional General overhaul with control retrofit 2010 Control upgrade 2016 Control: Siemens 840 D Sl Condition: very good faceplate Turning diameter of the faceplate 3,200 mm Number of rotation stages of the face plate 3 (infinitely variable) Speed ranges of the faceplate 0.8 - 40 rpm Level I 0.8 – 3 rpm Level II 0.8 - 11 rpm Level III 0.8 – 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above the faceplate 2,200 mm vertical supports S ...

Disc eroding machine for complete machining of rotationally symmetrical workpieces with ultra-hard cutting edges cutting materials. The workpieces are picked up flying (hanging vertically). Accesories Mechanical vapor separator N280, Disc changer for up to 6 eroding/grinding discs Adaptation to the A-axis on HSK 63-A-E Test mandrel HSK63A Glass scales on the linear axes X, Y & Z, Software package additional functions for metal working tools, Ex Level Pro Software, 3 grinding wheel changing elements Automatic shutter, Automatic central lubrication, Automatic fire extinguishing device, Coolant system with pump & coolant unit., Workpiece outside diameter: max 320 mm, Workpiece length: Max. 250 mm, workpiece length: max. 250 mm, Tool outside diameter: Max. 200 mm, Bore diameter: Max. 60 mm, bore diameter: Max. 60 mm, Travel X1: 520 mm, Travel path X1: 520 mm, Travel Y1: 970 mm, Travel path Y ...

Disc eroding machine for complete machining of rotationally symmetrical workpieces with ultra-hard cutting edges cutting materials. The workpieces are picked up flying (hanging vertically). Accesories: Mechanical vapor separator N280, Disc changer for up to 6 eroding/grinding discs, Adaptation to the A-axis on HSK 63-A-E Test mandrel HSK63A, Glass scales on the linear axes X, Y & Z, Software package additional functions for metal working tools, Ex Level Pro Software, 3 grinding wheel changing elements Automatic closure flap Automatic central lubrication Automatic fire extinguishing device Coolant system with pump & cooling unit, Workpiece outside diameter: max 320 mm, Workpiece length: Max. 250 mm, workpiece length: max. 250 mm, Tool outside diameter: Max. 200 mm, Bore diameter: Max. 60 mm, bore diameter: Max. 60 mm, Travel X1: 520 mm, Travel path X1: 520 mm, Travel Y1: 970 mm, Travel pa ...

DH Robotics RGI-14 Rotary Gripper Gripping force (per jaw): 10~35 N Stroke (both sides): 14 mm Rotation torque: 0.25 N.m Rotation range: Infinite Mechanical specifications Maximum speed of rotation: 1500 deg/s Repeatability of rotation: ± 0.02 deg Backlash of rotation: ± 1 deg Position repeatability (gripping): ± 0.02 mm Opening/closing time: 0.2 s/0.2 s Weight: 1.1kg  Electrical specifications Communication interface: Modbus RTU(RS 485), Digital I/O Nominal voltage: 24 V DC ± 10% Nominal current: 1.1 A Peak current: 2 A Ingress protection rating: IP 20 Recommended operating environment : 0~40°C,

DH Robotics RGI-30 Rotary Gripper Gripping force (per jaw): 10~35 N Stroke (both sides): 14 mm Rotation torque: 0.25 N.m Rotation range: Infinite Mechanical specifications Maximum speed of rotation: 1500 deg/s Repeatability of rotation: ± 0.02 deg Backlash of rotation: ± 1 deg Position repeatability (gripping): ± 0.02 mm Opening/closing time: 0.2 s/0.2 s Weight: 1.2 kg  Electrical specifications Communication interface: Modbus RTU(RS 485), Digital I/O Nominal voltage: 24 V DC ± 10% Nominal current: 1.1 A Peak current: 2 A Ingress protection rating: IP 20 Recommended operating environment : 0~40°C,

Fully hydraulic closing system, MC 4 control system with color monitor, integrated control panel and built-in disc drive. 1 complete plasticizing system for thermoplastics with a screw diameter of 45 mm - Levels for the foundation of the Nolato machine - Hydraulic blockade of reverse rotation of the auger - Hydraulic auger drive with standard speed - SVO open nozzle in 2-piece design (nozzle body with screw-in nozzle). - A device for sorting good and defective parts. Pneumatic pendulum. Pendulum speed approx. 3 sec. Free-standing device under the machines discharge shaft. Including electrical standard connector and software (Pos. 42.42). - Single pneumatic valve on the movable mold clamping plate for the blowing function (1 piece of 3/2 separating valve with 1 magnetic coil). Control to choose between road/time or time/time. Possibility to manually set the flow using 1 thrott ...

bore capacity in steel St 60: 25 mm Drilling capacity in St 60: 30 mm threading in St 60: M 16 : M 20 Short spindle: MK 3 spindle stroke: 140 mm throat: 293 mm column diameter: 115 mm Machine table - usable table surface: 514x360 mm T-Slots Amount - Width - Distance: 2x14x224 mm distance spindle - column min./max.: 132/724 mm feed: von Hand 0: stufenlos Spindle Speed: 225-4300 U/min. engine: 1,0/1,6 kW voltage: 400 V Standard equipment: - 7 TFT LCD display with touch function: Manual input of spindle speed set value Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status indicators and warnings on the display Service information Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Thread cutting device, for thread cutting with stop, max. 6 threads/min (thread cutting capacity depending on spi ...

The SCHIESS RF 30 gear hobbing machine is a specialist machine for machining large gear wheels. The machine is designed for machining of gears by processing individual pitches of a gear wheel. The milling machine processes a workpiece with diameter from 60 mm to 3500 mm and a weight of up to 25 t. The spindle of the milling machine rotates at a speed from 6 to 69 rpm. The SCHIESS RF 30 machine is designed for milling with: – cylindrical milling cutters in steel / cast iron up to module: 24/30 – disc milling cutters in steel / cast iron up to module: 33/42 – end mills in steel / cast iron up to module: 33/42 50/65 Technical data of the SCHIESS RF 30 milling machine - largest diameter of the milled workpiece: 3500 mm - llargest diameter of the milled workpiece in the circumferential method and with tooth pitch up to 45 3000 mm - lsmallest diameter of the milled part: 60 m ...

CNC Universal circular grinding machine SHU321C Brand new, never used. Control FANUC Series Oi-TC 2-axes machine. Diameter of grinding workpiece -external 8-320 mm -internal 30-250 mm Center height 165 mm Maximum grinding length -external grinding (center grinding) 710 mm -internal grinding (in chuck) 135 mm Maximum angle of table rotation -clockwise 3 degrees -counterclockwise 11 degrees Grinding wheel -dimensions for external grinding 450x50x203 mm -peripheral speed 35 m / sec Rotation angle of the grinding wheel ± 90 degrees Front saddle -30 degrees clockwise rotation angle -90 degrees rotation angle -speed range for external grinding 30-400 rpm Back saddle -size of the fixed center Morse N4 -Pinolite stroke 35 mm Cross feeding range 0.1- 4000 mm/min Range of longitudinal feeds 0.05-8 m / min Minimum cross feed 0.0005 mm Main motor power kW 5.5

GeneralTurning-milling centre; Control: Fanuc 31iB5 CharacteristicsSwing- Ø, max.1070 mmDrive power milling spindle22 kWDrive power second spindle22 kWDrive power main spindle22 kWNumber of Toolmagazine positions50 Speed max.8000 rpmSlewability of B-Axis1 degreeMovements X / Z / Y1040/+-330/3150 mmMilling spindle upper side1 Input precision of C-axis on Counterspindle0,0001 degreeBar diametre164 mmSpindle speed 2nd Spindle max.1500 rpmInput precision of C-axis on Mainspindle0,0001 degreeBar diametre164 mmSpeed max.1500 rpmMax. Turning Length3076 mmMax machining diameter1070 mmWeight approx.46000 KgTool spindle full indexing specificationsErhöhung der mögl. Indexierung der B-Achse auf 0,0001º Einrichtung zur Positionierung der B-Achse mit einem minimalen Winkel von 0,0001º anstelle der Standardausführung mit 1º, einschließlich der Option Direktes Wegmesssystem in der B-Achse derSp ...

max. wheel diameter: 330 mm gear width: - mm max. module: 7 min. module: 0,5 Control: Siemens 840 C total power requirement: 72 kVA weight of the machine ca.: 11,7 t dimensions of the machine ca.: m We offer a Pfauter model G 320 gear grinding machine for sale numerical control on 8 axes for the machining of gears with straight and helical toothing, with rolled profile for enveloping cuts, the one Worm profile disc used. Technical specifications: CNC control Siemens 840 C Controlled axes: X Radial axis Y Tangential Shift Z Vertical axis A Workhead rotation B Worm rotation during processing C Table rotation U Radial axis dresser V Tangential axis dresser Module 0.5 – 7.0 Minimum workpiece diameter 10 mm Maximum workpiece diameter 330 mm Number of teeth 10 - 600 Vertical carriage thrust Z 200 mm Horizontal grinding wheel - carriage stroke X 230 mm Tangential slide stroke Y 135 mm Angle o ...

CNC Plate Bending Roll Year 2021 Approx. 100 hours Number of Rolls 4 Rolls length 10’ 2” Top Roll diameter 18.2” – less deflecting thanks to Planetary Guide Technology Bottom Roll Diameter 16.6” Side Rolls diameter 14.2” Smallest possible diameter 21” thank to planetary guide technology Rolling Speed 20 ft/min (imperial) Installed power HP 72 (Energy Saving Technology) Power Supply V., 60 Hz Rolls material High resistance, heat treated, tested & certified Carbon Steel Rolls Hardening Induction surface up to 48 – 62 HR Rockwell C, according to Customer’s application and rolls materials Rolls Periph, Speed compensation Automatic (no torque loss, no operator setting needed) Rolls Crowning Top and lower (clamping) rolls are standard crowned to compensate Rolls deflection Rolls guiding Friction-free, mill-scale-proof, lubrication-less planetary guides R ...

Main axis diameter 90 mm Walrus Cone nº 5 (ISO 40) Longitudinal Column Travel 800 mm Vertical Movement 1.000 mm Automatic cross travel 1,000 mm Automatic longitudinal movement with lunette 1,000 mm 1.350 mm longitudinal automatic movement without lunette Bench width 900 mm Number of rotation speeds 18 Rotation speeds 10-1.000 rpm Table surface ` 1.000 x 1.200 mm Maximum weight allowed on the table is 4,000 kg Table rotation with 90º block function 360º Approximate weight 10 Tons Main engine power 15 HP Feather diameter 520 mm Plate travel 170 mm Speed Ranges 14 Maximum and minimum rotation speeds 10-335 rpm

Used complete spirits line up to 8000 bph 1 Used depalletizer ACMI Stratos 8000 bph The Stratos depalletizer of the used complete spirits line up to 8000 BPH produced by ACMI in 2003 is a technologically advanced device designed for the bottling industry With an operating capacity of 8000 BPH it operates in the used equipment for spirit with an automatic mode ensuring high efficiency in the bottle introduction process The machine despite having been dismantled in September 2021 is preserved in excellent condition It features crucial features such as a flap removal system and pallet storage capabilities An important feature of the Stratos depalletizer is its size of approximately 20 m2 By integrating a specific table for the alignment of round bottles safety barriers and pallet conveyor belts Human intervention in this used complete spirits line up to 8000 BPH is limited to the initial st ...

Maximum loadable weight (capacity between the tips) t 80 Machine weight t 160 Nominal turning diameter mm Ø 1,800 Maximum turning diameter mm Ø 1,900 Maximum diameter of passage on the bench mm Ø 2,600 Max turning length (distance between centers) mm 11,925 (12,025) Spindle axis height 1,300 mm Plateau diameter mm Ø 1,900 Plateau grip range mm Ø 300 ÷ Ø 1,350  Grip range 1 mm Ø 300 ÷ Ø 550  Grip range 2 mm Ø 500 ÷ Ø 950  Grip range 3 mm Ø 900 ÷ Ø 1,350 Clamping force (with max tightening torque 250 Nm) kN 200 Spindle motor power kW 160 Total installed power kW 310 Maximum spindle torque kNm 155 Spindle rotation speed range rpm 1 ÷ 150  Spindle rotation speed in 1st rpm range 1 ÷ 24  Spindle rotation speed in 2nd rpm range 20 ÷ 60  Spindle rotation speed in 3rd rpm range 50 ÷ 150 Carriage forward speed in transverse direction (X� ...

: 40 mm threading in St 60: M24 threading in GG 20: M30 : MK 3 spindle stroke: 120 mm : 160 - 2250 U/min. throat: 293 mm column diameter: 115 mm : 514 x 360 mm : 2 x 14 x 224 mm distance spindle /table: min. 117 / max. 701 mm feed: 0,1 + 0,2 mm/U height of the machine: ca. 1840 mm weight of the machine ca.: ca. 260 kg Standard equipment: - 7 TFT LCD display with touch function: Manual input of spindle speed set value Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status indicators and warnings on the display Service information Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Thread cutting device, for thread cutting with stop, max. 6thread/min (thread cutting capacity depending on spindle speed), thread depth adjustable via depth stop and on the TFT LCD display (4 tools) - Infinitely v ...

Number of spindles: 3 St. Number of tools: 2/3 St. Spindle diameter: 40/50 mm 1 OKOMA folding machine model UF 2 EG ------------------------------------- 1. Energy data: - Operating voltage: 3 phases, 380 V, 50 Hz. - Compressed air: Air requirement: 13 NL/min. Operating pressure: 8 bar up. Air: according to Pneurop 6611 2. Profile spindle 1: - Spindle arrangement: right - Power 11 kW - Speed 7000 rpm - Direction of rotation: synchronous and counter rotation - Spindle diameter 40 mm - Usable length 252 mm - Tool diameter max. 230 mm - U-movement of the profile spindle - Positioning vertically Drive: pneumatic cylinder 120 mm cycle for 2 tool positions Position sensor: limit switch - Positioning horizontally Drive: Pneumatic cylinder forward-back Position sensor: limit switch - Automatic immersion: immersion speed can be regulated for tear-free Fold over - Pro ...

Forest-Line MajorMill 5-Axis CNC Gantry Mill Year: 1992/2008 Number of Axes: 5 Type of CNC Control: Fidia C20 CNC Control Retrofit in 2008 Table Size: 83.27" x 236" (2115x6000mm) X: 236” (6000mm) Y: 110.23” (2800mm) Z: 49.21” (1250mm) Max. Cutting Height: 62.99"(1600mm) Effective Width Between Columns: 94.5"(2400mm) Spindle Speeds, 3-Range: 10-3200 RPM Main Milling Head on Ram: Hard Steel Cartridge - 3 Speed Ranges - Equipped with an accessory holder plate with auto clamping: Indexing 2.5 degrees Spindle Taper: #50 ISO A-Axis Spindle Head Tilt: +/-95 Degrees B-Axis Spindle Head Swivel: 360 Degrees A-Station AAC: yes Automatic Head Changer: yes Automatic Attachment Changer (ACC):: Yes - 3 Heads Right Angle Head: 10 - 3200 RPM, 2.5 degree indexing DRC12 Head Attachment (double stepless rotation): 10 - 5000 RPM, (Double stepless rotation) Multiplying spindle exten ...

Description: sanding machine with brushes Technical specifications: the machine was used for structuring veneered panels. sanding width approx. 1100 mm workpiece thickness from 3 mm up to 160 mm belt conveyor with variable feed speed aggregate 1: steel brush diameter 310mm, motor power 5,5 KW. rotation speed fixed. aggregate 2: tynex brush diameter 310mm, motor power 5,5 KW. rotation speed variable by inverter. aggregate 3: steel brush diameter 310mm, motor power 5,5 KW. rotation speed fixed. aggregate 4: tynex brush diameter 310mm, motor power 5,5 KW. rotation speed variable by inverter. CE norms serial number: 30, Approx. Onsite Dimension. (l x w x h): 2,500 x 1,500 x 2,100 mm, weight approx.: 2,000 kg

Description: 4-spindle copying lathe with aluminium template STANDARD EQUIPMENT 4 spindles for simultaneous copying of 4 workpieces Variable rotation with inverter Spindle drive with bronze gears and worm gear Centring devices for automatic workpiece positioning Pneumatic clamps Approach and moving away of cutter unit with pneumatic system Cutter carriage feed on rectified guides and recirculating ball pads Independent adjustment of cutter carriage feed and wood rotation Machine and electrical system complying with EC regulations TECHNICAL DATA Max. turning length mm 1100 Max. turning diameter mm 150 Cutter motor power V 380 / 50 - Kw 4 Spindle rotation motor power V 380 / 50 - Kw 0,75 Cutter carriage feed motor power V 380 / 50 - Kw 0,55 Tool holder diameter mm 145 Tool diameter mm 35 Variable carriage feed speed mm/min 0 ÷ 600 Variable spindle rotation speed r ...

:HBM-130XL spindle diameter:130 mm x-travel:2000 mm y-travel:1800 mm z-travel:(ohne Gegenhalter) 2000 mm U-axis:250 mm W-axis (spindle longitudinal):900 mm max. torque on the spindle:3136 Nm B-axis (table):360x1 ° rapid speed:X/Y/Z/W: 2500 mm/min table load:10 t table-size:1800 x 1600 mm T-slots:11 Stk. T-slot - width:28 mm transmission ratio:4 Stk. spindle speed:4-800 1/min spindle taper:50 ISO faceplate:Drehmoment: 4900 Nm faceplate:2.5-125 1/min faceplate:Umdrehung stufenlos einstellbar faceplate:Ø:750 mm weight of the machine ca.:29300 kg main drive:15 kW Machine size (LxWxH):7030x4665x3800 mm 2-Axis DRO :von NEWALL f. X- und Y-Achse Technical Offer of HBM-130 ? Powerful servo spindle motor and four spindle speed rang, stepless in each range. much lower maintenance and 80% failure rate reduced ? High rigidity spindle could insure the strong machining ? Worktable 4x90° position  ...

:HBM-130 | HBM-130L | HBM-130XL spindle diameter:130|130|130 mm x-travel:1600|2000|2000 mm y-travel:1400|1800|1800 mm z-travel:2000 mm U-axis:250 mm W-axis (spindle longitudinal):900 mm max. torque on the spindle:3200 Nm B-axis (table):360x1 ° rapid speed:X/Y/Z/W: 2500 mm/min table load:8|10|10 t table-size:1600 x 1400|1800 x 1600|2200 x 2000 mm T-slots:9/11/12 Stk. T-slot - width:28 mm transmission ratio:4 Stk. spindle speed:4-800 1/min spindle taper:50 ISO faceplate:Drehmoment: 4900 Nm faceplate:2.5-125 1/min faceplate:Umdrehung stufenlos einstellbar faceplate:Ø:750 mm weight of the machine ca.:22,5|24,5|25,5 t main drive:22 kW Machine size (LxWxH):6995/3647/342|7030/4665/3800|7030/4665/3800 mm PLC control:Siemens S7 servo motors:von Siemens/Fanuc/Fagor Technical Offer of HBM-130 ? Powerful servo spindle motor and four spindle speed rang, stepless in each range. much lower mainten ...

Used line for the production of the co-extrusion by PST Forming method. PTI - The twin screw extruder DS 92/28   2x screws with a diameter of 92 mm The length of screws 28 x L / D Snails closed system with internal temperature control, deep nitrided, with degassing on the cylinder, extruder equipped with a vacuum pump with filter, Siemens Servo Motor power: 60 KW Torque: Nm 15700 Screw rotation: 0 - 50 rev. / Min. Zones with ceramic heaters with an intense cooling: 5 x 5 KW Cooling Zones: 4 Performance with hard PVC, depending on the materials and tools: max.600kg / h Length: 4500 mm Width: 1600 mm Height: 2300 mm           Extruder equipped with a microprocessor control SIEMENS type Extrusion Pro Pak visualization 2. Co-Extruder PTI - The twin screw extruder DS 68/28 Snails with a diameter of 2 x 68 mm Length of the screws: 28 x L / D Snails cl ...

Manufacturer:ZM Zwickauer Maschinenfabrik Year: 1993 Power: 30 kW Allowable Operating Pressure: 8 bar Rotation speed: 5870 1/min Technical data of supply fan: Manufacturer: ILKA VEB Turbowerke Meißen Type: Lann 500 Year: 1991 Weight: 28 kg Flow: 1,43 - 1,94 m^3/s The total increase in pressure: 358 - 177 Pa Fan rotation speed: 1450 1/min Power: 0,7 kW Technical data of motor: Manufacturer: VEM Elektromotorenwerke Thurm Type: YP 1G4 Rotation speed: 1380 obr/min Power: 0,75 kW Voltage supply: 220/380 V 50 Hz The current consumption:3,45 / 2,0 A Weight: 11 kg Technical data of transformer: Manufacturer: TuR Transformatoren und Rontgenwerk Type: SVS 372 Year: 1991 Power: 37 kW Voltage supply: 380 V Control voltage: 220 V Nominal current: 72 A

CARVING machine type MARIANI PL 8 second hand machine working conditions : good with Frequency Converter HF rotary device for the simultaneous rotation of the model and the pieces manual chuck of mandrins unit also to work with flat pieces Technical Details : n.8 spindles distance betwen spindles mm. 420 n.02 rotation speed of spindles rpm 9.000 / 12.000 max. working length ( on rotation ) mm. 1900 volt. 380/50 net weigth kgs. 2500 overall dimension mm. 5000 x 2800 H=mm.1500 ( machine assembled ) Volt. 380/50

CARVING machine type ANDREONI STANDARD AL 12 second hand machine working conditions : good with Frequency Converter HF rotary device for the simultaneous rotation of the model and the pieces manual chuck of mandrins unit also to work with flat pieces Technical Details : n.12 spindles distance betwen spindles mm. 300 n.02 rotation speed of spindles rpm 12.000 / 18.000 max. working length ( on rotation ) mm. 1900 volt. 380/50 net weigth kgs. 2500 overall dimension mm. 5100 x 3100 H=mm.1500 ( machine assembled )

CARVING MACHINE type MARIANI PL 8 I Volt. 380/50 with Inverter rotary device for the simultaneous rotation of the model and the pieces (3D) manual chuck of mandrins unit also to work with flat pieces Technical Data : n. 8 spindles distance betwen spindles mm. 400 rotation speed by Inverter . rpm min. 9600 / max. 17400 max. working length ( on rotation ) mm. 2100 net weigth kgs. 2500 overall dimension mm. 5000 x 3000 H=mm.1500

Built-in screwdriver with control, BL57/50 MDW, 457010, Pico/mA, DSM, used Top Attention special price! (For your info - current new price for this screwdriver and control € 9.500 excl. VAT) We have set the lowest price on the market for a comparable used part. We still have several identical and other such units, but the quantity is ending. If you buy more than 1 piece you will get a great discount. If you have a UID number we will gladly issue an invoice without VAT. Used - Top condition The part was bought from a company in the course of a machine dismantling and is in very good condition. Technical data: Screwdriver BL57/50 MDW, DSM 457010, max. 50Nm, incl. all cable sets. This high quality DSM screwdriver is designed for direct measurement of torque and angle of rotation. The high-precision transducers required for this are installed directly on the output. The meas ...

Horizontal Lathe POREBA TCA 160 x 12 m Condition: very good, complete Technical details: Max. swing over bed 1600 mm Max. swing over carriage 1280 mm Max. swing over gap 1600 mm Turning length (between centers) 12000 mm spindle turning speed (min) 0.85 rpm spindle turning speed (max) 170 rpm The width of guide way 1100 mm Dia. of spindle bore 105 mm Taper of center sleeve 120/80 Feeds: bed slide/longitudinal 0,19-5, 0 mm/1 spindle rotation Feeds cross slide 0,095-2, 5 mm/1 spindle rotation Rapid travel-longitudinal/face 4000 mm/min Max work piece weight centre this centre 30000kg Max work piece weight with 2 steady rest 40000kg Faceplate diameter 1600 mm Metric thread 35 strokes-1-50 mm Whitworth thread 35 strokes-24-1/2 " Module thread Diametrical pitch thread Section of tool shank 70x70mm Travel of the top slide 0,095-2, 5 mm/1 spindle rotation Max.travel o ...
