rotary transfer used for sale

F20 BOILER : ORGANIC HEAT TRANSFER MATERIAL HEATER ORIGIN : CHINA RATE CALORIFIC POWER : 3500KW MAWP : 1.0MPa MAX. WORKING TEMP. : 320°C ALL UP WEIGHT : 19.5t HYDARULIC TEST PRESSURE : 1.5MPa

F24 BOILER : ORGANIC HEAT TRANSFER MATERIAL HEATER ORIGIN : CHINA RATE CALORIFIC POWER : 3500KW MAWP : 1.0MPa MAX. WORKING TEMP. : 320°C ALL UP WEIGHT : 19.5t HYDARULIC TEST PRESSURE : 1.5MPa

Lippert belt conveyor belt transfer GF 1000-550-400 RA2508 Technical data: Conveying length (NL): 1000 mm Framework width (NB): 550 mm belt width (GuB): 400 mm height (BH): 105 mm support feet: optionally available Conveying speed (v m/s): Drive: SEW gear motor S37 DT71D4/MM03/BW1 Electrical data: 50Hz V380-500, kW 0.075 / 0.37 / S1 Deflection roller (UR): Ø = 34 mm Drive drum (AT): Ø = 64 mm Belt: Type SNB 5 E Year of construction: 2001 Optionally available: Supports Side guides frequency converter for stepless speedcontrol Prices net plus VAT from central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: Construction year: 2001 condition: good (used) Conveying length in mm: 1090 Nominal / outside width in mm: 550 Belt width in mm: 400 Driven: YES Engine type: SEW Eurodrive KW: 0,37/S1 Ampere: 1,30 scope of delivery: without supports and side guides For individual, prof ...

A horizontal CNC rotary transfer machine Sinico for tube and bar processing is available. Throughput capacity: approx. 2500pieces/h, max. cutting capacity: 110mm, max. workpiece length: 350mm, max. tube diameter: 81mm, max. bar diameter: 40mm, tool holder: HSK-63, machine weight: approx. 16000kg. Documentation available. An on-site inspection is possible.

A horizontal CNC rotary transfer machine Sinico for tube and bar processing is available. Throughput capacity: approx. 2500pieces/h, max. cutting capacity: 81mm, max. workpiece length: 340mm, max. tube diameter: 81mm, max. bar diameter: 40mm, tool holder: HSK-63, machine weight: approx. 16000kg. Documentation available. An on-site inspection is possible.

Riggs 1000 Transfer pump 2012, stainless, filling range from 125ml to 1200ml, they pump directly from cooking kettles, tote bins, mixing vessels or IBC, provide damage free transfer of hot or cold liquid, semi liquid and suspended solid products

Manufacturer: SINICO Model: Sin-O-Matic Top 2000 Year of Manufacture: 2011 Type of Machine : Transfer Machine Maximum Cutting Capacity: 110 mm diameter Maximum Workpiece Length: up to 6,000 mm Cutting Capacity (mm): 350 mm Maximum Workpiece Length Setting: 65 mm (max) Installed Power: 24 kW Voltage / Frequency: 400 V / 50 Hz Control Voltage: 230 V Hydraulic Oil Tank Capacity: 45 L Machine Weight: 7,200 kg Find more here - .ucymachines/ Contact us at - sales@ucymachines

Manufacturer: SINICO Model: Sin-O-Matic Top 2000 Year of Manufacture: 2005 Type of Machine : Transfer Machine Maximum Cutting Capacity: 81 mm diameter Maximum Workpiece Length: up to 4,000 mm Maximum Workpiece Length Setting: 340 mm Installed Power: 33.3 kW Mains Voltage / Frequency: 380 V / 50 Hz Control Voltage: 24 V Hydraulic Oil Tank Capacity: 260 L Hydraulic Circuit Pressure: 45 bar Machine Weight: 6,200 kg Find more here - .ucymachines/ Contact us at - sales@ucymachines

bushing cut-off diameter range 8-18 mm number of dies 5 number of stations (incl. cut off) 6 shaft length under head 120 mm cutting length 140 mm output - pieces/min 60-170 press power 100 to

bushing cut-off , PKO , IFO , Slug feeding possible diameter range 16-34 mm number of dies 5 number of stations 6 cutting length 210 mm shaft length under head 180 mm output - pieces/min 55-80 press power 450 t

bushing cut-off , PKO diameter range 16-30 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 235 mm shaft length under head 180 mm output - pieces/min 90 press power 380 to

Four identical Nagel + Hermann transfer and placement machines for transfer motifs (rhinestone, hotfix or similar) are available. Colors: 6, shapes: 2, production capacity: 5000elements/h, machine dimensions X/Y/Z: approx. 2000mm/1050mm/1750mm, weight: approx. 320kg. Including PC, CAD software, 12x conveyor plates as well as various spare parts and tools. Documentation available. An on-site inspection is possible.

bushing cut-off diameter range 16 - 30mm number of dies 4 number of stations (incl. cut off) 5 cutting length 260 mm shaft length under head 225 mm output - pieces/min 60-80 press power 450 t

Two identical Nagel + Hermann transfer and setting machines for transfer motifs (rhinestone, hotfix, or similar) are available. Colors: 6, shapes: 2, production output (2-color): 8000elements/h, feed bowl diameter: 200mm. Machine dimensions X/Y/Z: approx. 2450mm/1100mm/1800mm, weight: approx. 400kg. Including PC, CAD program, 8x feed plates, 22 feed bowls, 4 rotary tables, as well as various spare parts and tools. Documentation available. An on-site inspection is possible.

Three identical Nagel + Hermann transfer and placement machines for transfer motifs (rhinestone, hotfix or similar) are available. Production capacity: 7000elements/h, round element diameter: 2mm/3mm/4mm/5mm/6mm/8mm. Including laptop, CAD software, feed plate, various tools and spare parts. Documentation available. An on-site inspection is possible.

bushing cut-off diameter range 23 mm number of dies 5 number of stations (incl. cut off) 6 cutting length 190 mm shaft length under head 175 mm output - pieces/min 120 press power 220 to

A Nagel + Hermann transfer and placement machine for transfer motifs (rhinestone, hotfix or similar) is available. Colors: unlimited, shapes: unlimited, production capacity: 5000elements/h, max. motif dimensions X/Y: 300mm/300mm, machine dimensions X/Y/Z: approx. 820mm/650mm/650mm, weight: approx. 120kg. Including PC notebook, CAD software, 4x conveyor plates, 2x mounting plates as well as various spare parts and tools. Documentation available. An on-site inspection is possible.

bushing cut-off , PKO , IFO diameter range 10-26 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 220 mm shaft length under head 165 mm output - pieces/min 35-70 press power 380 to

bushing cut-off diameter range 23 mm number of dies 5 number of stations (incl. cut off) 6 cutting length 175 mm shaft length under head 130 mm output - pieces/min 86 - 130 press power 220 to

bushing cut-off diameter range 8-22 mm number of dies 5 number of stations (incl. cut off) 6 cutting length 175 mm shaft length under head 6-140 mm output - pieces/min 125 press power 250 to

bushing cut-off , PKO diameter range 8-22 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 175 mm shaft length under head 155 mm output - pieces/min 105 press power 250 to

bushing cut-off diameter range 8 - 20 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 175 mm shaft length under head 142 mm output 40-80 press power 250 to

diameter range 8-20mm number of dies 4 number of stations (incl. cut off) 5 output - pieces/min 50 shaft length under head 200 mm cutting length 225 mm

bushing cut-off , PKO , IFO diameter range 17 mm number of dies 4 number of stations 5 cutting length 30-230 mm shaft length under head 40-190 mm output - pieces/min 70-110 press power 160 t

diameter range 10- 18 mm number of dies 4 number of stations 5 cutting length 155 mm shaft length under head 125 mm output - pieces/min 90 press power 200 to max diameter of the head 35 mm

bushing cut-off diameter range 8-16 mm number of dies 2 number of stations (incl. cut off) 4 cutting length 160 mm shaft length under head 130 mm output - pieces/min 100

bushing cut-off , PKO diameter range 7-15 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 10-160 mm shaft length under head 15-130 mm output - pieces/min 130 press power 150 to

bushing cut-off , PKO , IFO diameter range 6-14 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 280 mm shaft length under head 220(260) mm output - pieces/min 40-75 press power 100 t

bushing cut-off , PKO diameter range 14 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 127 mm shaft length under head 90 mm output - pieces/min 200

bushing cut-off , PKO in 2nd and 3rd diameter range 14 mm number of dies 2 number of stations (incl. cut off) 4 cutting length 100 mm shaft length under head 90 mm output - pieces/min 100 press power 120 to

bushing cut-off , PKO , Forma packs diameter range 11,8 mm number of dies 5 number of stations 6 cutting length 3 - 45 mm shaft length under head 50 mm output - pieces/min 85 - 255 press power 50 to

diameter range 12 mm number of dies 4 number of stations 5 cutting length 100 mm shaft length under head 80 mm output - pieces/min 125 press power 65 to

diameter range 10 mm number of dies 2 number of stations (incl. cut off) 4 cutting length 100 mm shaft length under head 80 mm output - pieces/min 150 press power 60 t

bushing cut-off , PKO diameter range 8,5 mm number of dies 2 number of stations 4 cutting length 55 mm shaft length under head 55 mm output - pieces/min 200 press power 30 to

diameter range 10 mm number of dies 2 number of stations (incl. cut off) 3 cutting length 110 mm shaft length under head 100 mm output - pieces/min 170

PKO diameter range 3-8,5mm number of dies 2 number of stations (incl. cut off) 4 cutting length 60 mm shaft length under head 55 mm output - pieces/min 250

bushing cut-off , PKO diameter range 8,5 mm number of dies 2 number of stations (incl. cut off) 3 cutting length 100 mm shaft length under head 80 mm output - pieces/min 300 press power 30 t

bushing cut-off , PKO diameter range 8 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 65 mm shaft length under head 45 mm output - pieces/min 350 press power 48 to

PKO , Stripper , Variable speed diameter range 8 (9,5) mm number of dies 2 number of stations (incl. cut off) 4 max. cut-off length 80 mm shaft length under head 60 mm output - pieces/min 50-120 press power 70 to

bushing cut-off , PKO diameter range 3-8,5 mm number of dies 2 number of stations 4 cutting length 55 mm shaft length under head 55 mm output - pieces/min 200 press power 30 to

with PKO diameter range 3-8 mm number of dies 3 number of stations (incl. cut off) 4 cutting length 70 mm shaft length under head 12-60 mm output - pieces/min 300 press power 28 t

bushing cut-off diameter range 6,5 mm number of dies 8 number of stations (incl. cut off) 9 cutting length 6-10 mm plane of stroke 123 mm output - pieces/min 150

PKO diameter range 3,8 - 6,5 number of dies 4 number of stations 4 cutting length 52 mm shaft length under head 6-35 mm output - pieces/min 250 press power 55 to

bushing cut-off , PKO diameter range 2-6 mm number of dies 4 number of stations (incl. cut off) 5 cutting length 95 mm shaft length under head 75 mm output - pieces/min 80-200

bushing cut-off diameter range 5 mm number of dies 6 number of stations (incl. cut off) 7 cutting length 35 mm shaft length under head 25 mm output - pieces/min 400 press power 15 to

Icon 6-250Year of manuf. : 2011 Control : Fanuc 30i ____________Description:In General:Year of manufacture:2011Control system:Fanuc 30iMaximum table load:100 kgTravel range X/Y/Z:300/300/370 mmInstallation weight:approx. 33,000 kgMachining station I (X/Y/Z/B):Technology:1 x vertical spindleSpeed:8,000 rpmTool holder:HSK-A 63Power:31 kWTorque:197 NmTool changer:12 stationsB-axis:0.001°, pneumatic indexing, clamping forceTool diameter/length:125/250 mmMachining station II (X/Y/Z/B):Technology:1 x vertical spindle + 1 x horizontal spindleSpeed:8,000 rpmTool holder:HSK-A 63Power:31 kWTorque:197 NmTool changer:12 stationsB-axis:0.001°, pneumatic indexing, clamping forceTool diameter/length:125/250 mmMachining station III (X/Y/Z/B):Technology:1 x vertical spindleSpeed:8,000 rpmTool holder:HSK-A 63Power:31 kWTorque:197 NmTool changer:12 stationsB-axis:0.001°, pneumatic indexing, clampi ...

Witzig & Frank TriFlex 5XYear of manuf. : 2018 Control : Fanuc 30i-B ____________Description:In General:Year of construction:2018Control system:FanucProcessing stations:5 piecesLoading station:1 pieceTravelling range:X-axis:450 mmY-axis:500 mmZ-axis:450 mmRapid traverse X/Y/Z:50 m/minTurret:Number of stations:8Speed:13,300 rpmTorque:58 NmTool holder:HSK 63 CWorkpiece/device:Dimensions max.:350 x 350 x 350 mmMax. permissible mass:250 kgMedia supply line:6 piecesNC swivelling rotary table:A-axis:+/- 150°B-axis:360°Max. load:250 kgTable diameter:320 mmEquipment:Loading/unloading:Fanuc Robot M20i-AChip removal:2x chip conveyorsCoolant supply:IKZ system, 20 barPosition measuring systems:Direct in all axes

A complete 8-stage transfer press line with a Weingarten double-column transfer press is available. 1) Mechanical double-column transfer press Weingarten S.3100.08.70.1, year of manufacture: 1969, tool stations: 9, forming stages: 8, total press force: 3100t, press force blanking slide/drawing slide: 300t/2800t, strokes: 28/min, blanking slide stroke: 200mm, drawing slide stroke: 500mm, max. drawing depth: 120mm, drawing slide ejector stroke: 100mm, blank holder stroke: 50mm, drawing cushion force: 25t, transfer pitch: 700mm, max. blank dimensions X/Y: 450mm/450mm, max. blank diameter: 540mm, table dimensions X/Y: 1200mm/5600mm, main motor power: 300kW, machine dimensions X/Y/Z: approx. 10500mm/7500mm/9700mm, weight (according to documentation): approx. 524t, stroke counter reading (September 2024): approx. 25 million. 2) Blanking and cutting press Georg Maschinentechnik PKD 630, year of ...

A transfer press line is offered, consisting of a Gräbener double-column transfer press including a feed unit and a Fecker decoiler-straightener combination with strip feed. 1) Gräbener GSET 2-250-280-315 double-column transfer press, year of manufacture: 1997, condition: operational, nominal force: 2500kN, nominal force stroke: 5mm, nominal energy capacity: 45kJ, slide stroke: 315mm, max. stroke rate: 50strokes/min, slide adjustment: 125mm, number of connecting rods: 2, shut height between bolster and slide: 800mm, bolster dimensions X/Y/Z: 2800mm/1150mm/200mm, slide area X/Y: 2800mm/900mm, max. die cushion stroke: 160mm, die cushion force: 88kN, machine dimensions X/Y/Z: approx. 5200mm/2700mm/5450mm, dimensions including sound enclosure X/Y/Z: approx. 7200mm/4700mm/5610mm, weight: approx. 55000kg. 2) Feed unit, condition: partially operational. 3) Fecker decoiler-straightener combina ...

pressure: 2500 t table length: 5200 mm table width: 2300 mm PRESS FORCES: • CAPACITY : 2500ton • Point pressure capacity: • - Upper 1600t • - Down 900ton • Slide stroke: 650mm • Slide adjustment: 225mm • Slide stroke number: continue 9~25spm • Die-height: 1250mm • Slid size(LxR ,FxB): 5400x2400mm • Bolster size(LxR, FxB, T): 5200x2300x200mm • Balance capacity: 30ton • Main motor: DC 355kw • Feed back(bolster upper side): 700,780mm • Feed back stroke : 550,700,1000mm • Cramp stroke : 0-250mm • Lift stroke: 0~150mm • Transfer inner size(cramp): 650~2200mm • Die cushion capacity • No.1 station 120ton • No.2 station 80ton • No.3 station 60ton • No.5,6,7 station: 5ton • Stroke: 200mm • Bed size: 480x1780mm • Stop time: 430ms The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
