120,746 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
Pressure:080 t throat:345 mm stroke:20 - 160 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:495 mm table surface area:920 x 610 mm table height over floor:800 mm Hole in the table:280 mm passage to the back:670 mm ram surface:650 x 400 mm ram adjustment:50 mm power capacity:10,0 kW weight:7,7 t Dimensions (WxDxH):1,5 x 2,2 x 3,15 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric
used
Length: 0 mm Module: 0 mm Width: 0 mm CNC Brand: 0 CNC Model: 0 Operating hours: 49903 Technical data Working range: Module from up to: 8 Toothed racks: Max. length to be shaped: 1850 mm Max. width to be shaped: 160 mm Table surface: Length: 2200 mm Width: 360 mm Max. ram stroke: 180 mm Distance ram to table: from: 55 mm up to: 280 mm Taper in ram: 50 ISO Ram stroke speeds: number (steps): 12 from: 26 s/min up to: 237 s/min Voltage 50 Hz 3x: 380 Volt Drive: 8.76 kW Machine´s weight about: 7100 kg Overall dimensions machine: Length: 5200 mm Width: 2300 mm Height: 2340 mm Description: gears are missing
used
QTY 1 x Pomini VIC1.8-PX1.6 Tandem Lab mixer, Machine number 9912, date 1990, Modern frame design with unitized fabricated steel base, Anti friction roller bearings with floor lubrication, 22kW DC variable speed motor. Rotor speeds 0-230rpm Torque montioring sensors. Siemens PLC control system with S7-300 CPU (combined with original S5). Desktop computer interface. Left hand mixer: Pomini PX1.6 tangential rotor type, Volume 1.6Litre, 2 wing rotors, FY type bronze dust seals, Jacketed chamber for heating or cooling, Hard Chrome plated chamber and rotors, Chamber sides can manually swing open for cleaning/maintenance (by removing 4 bolts on each side), Pneumatic oil injector, Pneumatically operated discharge drop door with linear actuator, Pneumatically operated hopper load door, Pneumatic ram with transducers fitted to monitor floating weight position. Proporti ...
used
Table diameter: 2000 mm Turning diameter: 1800 mm Turning height: 1250 mm Motor power: 35 HP/kW Positions ATC: 0 Positions APC: 0 MACH-id 4306 MAKE WMW TYPE DKZ 2000 x 1250 B YEAR 1976 SPECIFICATIONS Max. turning diamter Ø 2000 mm Table / chuck size Ø 1800 mm Workpiece height 1250 mm Work piece weight 6000 Kg Horizontal movement support / ram 1150 mm Stroke support left ram 700 mm Stroke support right ram 700 mm Angle adjustment / ram swivable 30 Spindle speeds / ranges 50 Rpm Power 35 Kw DIMENSIONS Length 4100 mm Width 5300 mm Heig ...
used
Turning diameter: 10000 mm Turning height: 6500 mm Chuck diameter: 8000 mm Number of chucks: 1 CNC Brand: NUM MAKE Schiess Froriep TYPE 5K800 - 1000 YEAR Complete rebuild in 2014 - 2014 SPECIFICATIONS Controll NUM Max. turning diamter Ø 10.000 mm Table / chuck size Ø 8000 mm Workpiece height 6500 mm Work piece weight 350.000 Kg Horizontal movement support / ram 6000 mm Stroke support left ram 3500 mm Stroke support right ram 3500 mm Angle adjustment / ram swivable - 30 / + 45 Singel column or double column Double Column Spindle speeds / ranges Vario 18 Rpm Power 125 Kw DIMENSIONS Length 11.000 mm Width 15.000 mm Height 14.000 mm
used
Table diameter: 7100 mm Turning diameter: 8000 mm Turning height: 3240 mm Motor power: 0 HP/kW Positions ATC: 0 Positions APC: 0 MAKE STANKO 3KTC TYPE 1580 L YEAR Overhauled 2006 SPECIFICATIONS Controll Conventionel Max. turning diamter Ø 8000 mm Table / chuck size Ø 7100 mm Workpiece height 3240 mm Work piece weight 125000 Kg Horizontal movement support / ram 4400 mm Stroke support left ram 2000 mm Stroke support right ram 2000 mm Angle adjustment / ram swivable - 15 / - 30 Gr Live tooling Milling spindlel 650 Rpm Singel column or double column Double column Spindle speeds / ranges 19.6 Rpm DIMENSIONS Length 9000 mm Width 14000 mm Height ...
used
pressure: 10 t throat: 0 mm stroke: 400 mm total power requirement: 7,5 kW weight of the machine ca.: 6500 t dimensions of the machine ca.: m D U N K E S (Germany) CNC Controlled Hydraulic Double Column Press Model HD 10 Year 1993 ________________________________________________________ Pressure 10 tons Ram stroke 400 mm Mounting height 600 mm Table size 400 x 300 mm Table height above floor 820 mm Ram area 400 x 300 mm Ram bore 40 mm Quickspeed, downwards, max. 70 mm/s Working speed, downwards, using max. pressure 40 mm/s Working speed, min. 5 mm/s Working speed adjustable from 5 - 70 mm/s Return stroke speed, min./max. 20 / 175 mm/s Drive 7.5 kW Total electrical load, approx. 12 kW - 380 V - 50 Hz Weigh ...
used
pressure: 160 t no. of strokes: 40 - 120 Hub/min sheet width: mm total power requirement: 40 kW Pressing capacity 160 ton Table clamping area 1,100 x 1,280 mm Ram clamping area 850 x 890 mm Distance between guides 1,120 mm Distance between columns (below guide ways) 1,350 mm Distance between Table and ram in upper position approx. 400 mm No. of strokes 40 - 120 /min Adjustment of stoke 67 / 115 / 160 mm Ram adjustment, motor driven 125 mm Ejector travel 50 mm Total electrical load, approx. 40 kW - 500 V - 50 Hz Weight, approx. 24,000 kg Accessories / Special Features WEINGARTEN Sheet Metal Uncoiler with overhead loop control (space saving because it does not need a loop-pit). Strip width 375 mm. The loop control guides the strip-material from the uncoiler to the machine thru a straightening device with automatic supervision. 8-track slide bearing guide. Automatic oil-circulation lubr ...
used
pressure: 80 t throat: 250 mm stroke: 5/95 mm table surface area: 805 x 510 mm distance table/ram: Hub unten - 400 mm tool hole in ram: 45 mm ram adjustment: 100 mm ram surface: 360 x 300 mm no. of strokes: 55 Hub/min total power requirement: 5,5 kW weight of the machine ca.: 4 t dimensions of the machine ca.: 0,83 x 1,7 x 2,6 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 100 t throat: 355 mm stroke: 8 - 130 mm table surface area: 710 x 1200 mm T-slots at tabel: 3 clamping plate thickness: 75 mm no. of strokes: 50/80 Hub/min ram adjustment: 80 mm ram surface: 450 x 560 mm T-slots at ram: 2 tool shank hole (depth x diameter): 100 x 50 mm max. distance table - ram: 540 mm distance between columns: 400 mm connected load: 11,5 kW weight of the machine ca.: 9,0 t Overall size: 1,65 x 2,25 x 3,05 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 100 t throat: 300 mm stroke: 20 - 124 mm strokes per minute: 60/90 ram adjustment: 85 mm table surface area: 920 x 600 mm ram surface: 540 x 290 mm daylight, max. stroke above - ram adjustment above: max. 440 mm hole in the table: 290 x 170 mm tool hole in ram: Dm. 50 mm total power requirement: 6,5 - 8,5 kW weight of the machine ca.: 5,7 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 63 t throat: 235 mm stroke: 6 - 100 mm no. of strokes: 60 Hub/min dayligth: 270 mm distance table - lower edge of ram: 370 mm ram adjustment: 80 mm table-size: 650 x 600 mm ram head dimension: 180 x 230 mm work height max.: 700 mm table hole: 110 mm total power requirement: 4,0 kW weight of the machine ca.: 3,5 t dimensions of the machine ca.: m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. This high performance Profi Press feature ...
used
Capacity (x): 0 Process Application: 0 Other Info: 0 Technical data Working range: Module from up to: 1.25 / 1.50 Helix angle: +30 / -30 ° Max. gear cutting width: 28 mm Toothed racks: Max. length to be shaped: 440 mm Max. width to be shaped: 28 mm Number of ram stroke lengths:: 3 Min. ram stroke: 10 , 20 mm Max. ram stroke: 28 mm Ram stroke speeds: number (steps): 7 from: 165 s/min up to: 750 s/min Table leading spindle speeds: number (steps): 5 from: 0.02 mm up to: 0.10 mm Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 225 kg Overall dimensions machine: Length: 900 mm Width: 750 mm Height: 1300 mm Various accessories: Spindle head int.gear cutting Device for toothed racks
used
Diameter: 0 mm CNC Brand: 0 CNC Model: 0 Control: SYNTEC 200TB (NEW 2019) Technical data Working range: Module from: 1 up to: 5 Max. wheel diameter: 250 mm Max. gear cutting width: 70 mm Table diameter: 320 mm Drill diameter of the table: 125 mm Max. ram stroke: 100 mm Distance ram to table: from: 190 mm up to: 290 mm Taper in ram: 40 ISO Ram stroke speeds: from: 100 s/min up to: 1200 s/min Voltage 50 Hz 3x: 380 Volt Drive: 36 kW Machine´s weight about: 10000 kg Overall dimensions machine: Length: 4500 mm Width: 3200 mm Height: 2900 mm Equipment: Retrofited control: 2019 Helical gearing Mise en conformité CE
used
Nominal Turning Envelope Faceplate Diameter 4,000 mm Machining Diameter 4,250 mm Machining Heights 2,000 mm Work Piece Weight 20,000 kg X-Axis Ram Carriage From -300 mm To 2,850 mm W-Axis Elevating CrossRail 1.800 mm Z-Axis Ram 1,350 mm WorkTable Diameter 4,000 mm WorkTable Speed 1 - 50 rpm Power Continuous S1 100 kW Torque Continuous S1 125,000 Nm WorkTable Milling Speed 0.02 to 1.5 rpm Milling Torque Continuous S1 55,000 Nm Locking Table Torque 80,000 Nm 2XRam Size Turning Milling 250X250 mm RAM cross section Tool shank size: ISO 50 Ram Spindle Speed 0 to 3,000 rpm Power Continuous S1 37 kW Torque Continuous S1 2.000 Nm Tool Storage And Interchange Number Of Tool Magazines one ATC for 12 turning and/or milling toolholder Tool Storage 12 X2 Maximum Singular Tool Weight 50 kg Maximum tool long 600 mm X and Z axes thrust Continuous S1 50,000 N X And Z-Axes ...
used
Nominal Turning Envelope Faceplate Diameter 4,000 mm Machining Diameter 4,250 mm Machining Heights 2,000 mm Work Piece Weight 20,000 kg X-Axis Ram Carriage From -300 mm To 2,850 mm W-Axis Elevating CrossRail 1.800 mm Z-Axis Ram 1,350 mm WorkTable Diameter 4,000 mm WorkTable Speed 1 - 50 rpm Power Continuous S1 100 kW Torque Continuous S1 125,000 Nm WorkTable Milling Speed 0.02 to 1.5 rpm Milling Torque Continuous S1 55,000 Nm Locking Table Torque 80,000 Nm 2XRam Size Turning Milling 250X250 mm RAM cross section Tool shank size: ISO 50 I09rgztr Ram Spindle Speed 0 to 3,000 rpm Power Continuous S1 37 kW Torque Continuous S1 2.000 Nm Tool Storage And Interchange Number Of Tool Magazines one ATC for 12 turning and/or milling toolholder Tool Storage 12 X2 Maximum Singular Tool Weight 50 kg Maximum tool long 600 mm X and Z axes thrust Continuous S1 50,000 N X ...
new
Technical Details: Maximum turning diameter: 10000 mm Maximum turning height over table: - Standard: 3150 mm - Option: 3500; 4000; 4500 mm TABLE: Table diameter: 4770 mm Maximum table loading capacity: 100 tons Table speed range – turning mode: 0,4÷40 RPM Table speed range –milling mode: 0,001÷2 RPM Power of main drive motor: 100 (option: 130) kW CROSS RAIL: Cross rail vertical travel: 2500 (option: 3000; 3800) mm Cross rail speed: 360 mm/min. WORKING HEAD and RAM: Working HEAD: - travel on X axis: 3375 mm Rapid feed X axis: 6000 mm/min Feed range: 0,01÷6000 mm/min RAM – section: 360 x 360 mm Travel on Z axis: 1600 (option: 1800; 2000; 2300) Rapid feed on Z axis: 6000 mm / min Working feed range on Z axis: 0,01÷6000 mm/min Speed range of RAM tool spindle: 10÷2000 RPM Power of RAM tool spindle drive motor: 37 (option: 41; 51)kW Machine tool tape: ...
new
Maximum turning diameter: 8000 mm Maximum turning height over table: - Standard: 3150 mm - Option: 3500; 4000; 4500 mm TABLE dimensions: Table diameter: 4770 mm Maximum table loading capacity: 100 tons Table speed range – turning mode: 0,6÷45 RPM Table speed range –milling mode: 0,05÷2 RPM Power of main drive motor: 100 (option: 130) kW CROSS RAIL: Cross rail vertical travel: 2500 (option: 3000; 3800) mm Cross rail speed: 360 mm/min. WORKING HEAD and RAM: Working HEAD: - travel on X axis: 3375 mm Rapid feed X axis: 6000 mm/min Feed range: 0,01÷6000 mm/min RAM – section: 360 x 360 mm Travel on Z axis: 1600 (option: 1800; 2000; 2300) Rapid feed on Z axis: 6000 mm / min Working feed range on Z axis: 0,01÷6000 mm/min Speed range of RAM tool spindle: 10÷2000 RPM Power of RAM tool spindle drive motor: 37 (option: 41)kW Machine tool tape: ISO 50 WEIGHT ...
used
Vertical shaping machine manufactured by RAVENSBURG type S 200Technical specifications:Large stroke of the ram: 200 mmRam adjustment: 200 mmRound table diameter: 440 mmThroat: 410 mmGroove width max: 32 mmHeight between table and ram guide: 370/470 mmLongitudinal table displacement: 375 mmCross table displacement: 350 mm4 lifting speeds: 33/49/75/110 H / min6 feeds, lengthways per slide stroke: 0.03 - 0.3 mmacross per ram stroke: 0.07 - 0.7 mmround per ram stroke at 100 mm diameter: 0.05 - 0.5 mmDrive power: 3.0 kWDimensions approx: 1000 x 1600 x 2200 mmWeight: 2000 kgWith- Round dividing tableused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Ma ...
used
O-M LTD. CNC Vertical Boring Mill FANUC 16T-A CNC CONTROLS, RETROFIT 1994 CAPACITY: TABLE DIAMETER 4000mm MAXIMUM TURNING DIAMETER 7000mm MAXIMUM TURNING HEIGHT 2900mm MAXIMUN HEIGHT UNDER RAIL 3000mm TABLE WEIGHT CAPACITY 45400kg VERTICAL RAM TRAVEL, Z-AXIS 1500mm HORIZONTAL TRAVEL OF RAM, X-AXIS 2550mm TABLE SPEEDS RANGE .55-40 RPM TABLE SPEEDS 16 STEPS FEED RANGE VERTICAL RAM HEAD 0.003-.6 IPR RAPID TRAVERSE, HORIZONTAL HEAD 49 IPM RAPID TRAVERSE, CROSS RAIL 12 IPM RAPID TRAVERSE, COLUMN 21 IPM MAXIMUM TORQUE 58,000 LB/FT EQUIPPED WITH: FANUC 16T-A CNC CONTROLS (RETROFIT 1994) 4000mm T-SLOTTED TABLE WITH 4-TOP JAWS OPENSIDE ADJUSTABLE COLUMN VERTICAL OCTAGONAL RAM ON CROSS RAIL COOLANT CHIP GUARDS MAYFRAN CHIP CONVEYOR 50 HP MAIN MOTOR NOTE: MACHINE IS UNDER POWER FOR INSPECTION. WELL MAINTAINED MACHINE IN EXCELLENT CONDITION! RETROFIT WITH FANUC 16T-A CNC ...
used
Single stand - eccentric press KRUPP type PEKRD 125 h Masch. No. 2861 Year of construction 1977 Compressive force 125 ton. Projection 400 mm Table size 950 x 750 mm Ram surface 800 x 540 mm Table opening 100 x 250 mm Stroke adjustment 8 to 160 mm Ram adjustment 100 mm Installation height largest stroke top max. 550 mm Number of strokes 60 strokes/min. Table height above corridor 800 mm Motor power 10 kW Mains connection 380 Volt, 50 Hz - Hydraulic overload in the tappet - Compressed air Clutch-brake combination ORTLINGHAUS - Ram weight compensation cylinder - Motorized ram position - Table top with ball rollers - Two-hand operation - Grease central lubrication HELIOS- Stroke counter - UVV 7n 5.1 §4a, paragraph 2 No. 3b for manual insertion work Space requirement L x W x H 2300 x 1800 x 3200 mm Weight approx. 10 tons. good condition (very little used); used
used
Capacity 250 ton Kinetic energy of moving parts at the end of max. ram stroke 13,5 kj Max. ram stroke 400 mm Number of ram stokes (SPM) 34 Slide clearance 560 mm Ram size (front-back 560 mm Table size 670 x 750 mm Lower ejector capacity 16 ton Lower ejector movement 105 mm Main drive motor powe 15 kW Press dimensions 3710 x 1925 x 4415 mm Press weight 18000 kg
used
Capacity 250 ton Kinetic energy of moving parts at the end of max. ram stroke 13,5 kj Max. ram stroke 400 mm Number of ram stokes (SPM) 34 Slide clearance 560 mm Ram size (front-back 560 mm Table size 670 x 750 mm Lower ejector capacity 16 ton Lower ejector movement 105 mm Main drive motor powe 15 kW Press dimensions 3710 x 1925 x 4415 mm Press weight 18000 kg
used
Type / type: N 25 Year of make: 1977 Manufacturer / make: Weingarten Rated pressure: 25 t Number of strokes: 140 / min Radius slide center to frame: 200 mm Window in frame: 240 mm distance table slide: 250 mm Stroke adjustment / adjustment of stroke: 8 ... 80 mm Ram adjustability/adjustment of ram: 50 mm Ram size / surface of ram: 355 x 220 mm Table size / surface of bed: 560x 400 mm Hole in table: 160 mm Power of main motor:3 kW Weight / weight: 2,23 t
new
Mario Carnaghi CNC Vertical Boring Mill FEATURES: Siemens 840DE SL CNC Control 12-Position Automatic Tool & Attachment Changer 40-Station Automatic Tool Magazine Hydrostatic Table Vertical Ram with Milling Spindle Vertical Milling & Drilling Attachment Right Angle Milling Attachment Universal Milling Attachment Through Spindle Coolant & Flood Coolant Dual Dive 108 HP (81 KW) Table Motors High Resolution Heidenhain Scales & Encoder Renishaw RMP 60 Probe Renishaw NC-4 Milling Tool Probe Full Machine & Operator Enclosure Chip Conveyor CAPACITY: Table Diameter 196.85" (5000mm) Turning Diameter .. 236.22" (6000mm) Maximum Turning Height 98.42" (2500mm) Maximum Stroke of Vertical Rams ... 59.05" (1500mm) Ram Cross Section . 13.77" x 13.77" (350x350mm) Cross Rail Travel . 47.24" (1200mm) Ram Saddle Travel, X-Axis . 175" (4445mm) Turning Tool .. Capto C8 ...
used
pressure: 100 t throat: 350 mm stroke: 8 - 100 mm no. of strokes: 60 Hub/min daylight (stroke down, ram adjustment above): 300 mm ram adjustment: manuell 80 mm table surface area: 850 x 700 mm hole in the table: Dm. 180 mm mm ram surface: 560 x 400 mm ram drills x depth: 40 x 95 mm table height over floor: 850 mm total power requirement: 7,5 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 1,4 x 2,2 x 2,85 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 110 t throat: 290 mm stroke: 20-124 mm no. of strokes: 60 / 90 Hub/min ram adjustment: 85 mm table surface area: ca. 920 x 590 mm ram surface: ca. 530 x 280 mm distance table to upper part of the press: ca. 450 mm hole in the table: ca. 180 x 300 mm mm table height: ca. 750 mm tool hole in ram: Ø 50 mm Number of working hours: 8214 h distance table to upper part of the press: mm weight of the machine ca.: 5,5 t dimensions: ca. 2000 x 2000 x 2600 mm overhauled by the manufacturer Helmerding in 2014 including conversion to new ones press safety control. Operating hours read since overhaul in 2014: 8214 Documentation of press safety control available electrical grease central lubrication Hydraulic clutch-brake combination Mechanical break plate in the ram two-hand operation foot control The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Daniels 500ton Upstroking Press Platen 1050mm wide x 1100mm deep Capacity in Tons: 500 Working pressure Lbs: 2950 Daylight between tables: 24"/30" Daylight between platens: 18"/24" Stroke (main ram): 24" Main ram dia. : 22" Side ram dia. : 3 1/2" / 2" 4 columns Return Ram Steam heated platens New light guarding Fast / slow close Complete with pump unit and brand new control panel
used
pressure: 100 t throat: 300 mm stroke: 20 - 128 mm ram - range of adjustment: 80 mm strokes per minute: 60 - 90 table surface area: 920 x 600 mm ram surface: 540 x 290 mm hole in the table: 315 x 180 mm daylight, max. stroke above - ram adjustment above: 520 mm tool hole in ram: Dm. 50 mm total power requirement: kW weight of the machine ca.: 5,8 t dimensions of the machine ca.: 1,8 x 1,7 x 2,2 m Furnishing: - Gear transmission - fixed table - Triple bearing shaft - semi-automatic stroke adjustment - hydraulic clutch-brake combination - hydraulic overload (modern unit mounted on the stand on the left) - Hydraulic unit with oil cooler for clutch mounted on the left side of the stand - Ball spindle adjustment using a ratchet - automatic central lubrication VOGEL - Operating instructions / CE declaration available Machine is partially overhauled in our company as follows: - dismantled, clea ...
new
pressure: 125 t throat: 360 mm stroke: 20 - 130 mm table surface area: 920 x 690 mm ram surface: 580 x 400 mm no. of strokes: 60 Hub/min ram adjustment: 80 mm hole in the table: 200 mm tool hole in ram: 50 mm daylight (stroke down, ram adjustment above): 500 mm total power requirement: 11 kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: B 1,32 x T 1,8 x H 2,82 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
pressure: 100 t throat: 370 mm stroke: 10 - 140 mm no. of strokes: 58 Hub/min ram adjustment: 80 mm table surface area: 900 x 670 mm ram surface: 410 x 430 mm table height: 760 mm tool hole in ram: 65 mm toolpiece height max.: 450 mm weight of the machine ca.: 6 t pneumatic clutch-brake combination Mechanical fracture plate in the ram Two-hand operation Foot control UVV until 03/2023 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
press ram:: ram head width: 2.100 mm depth: 840 mm stroke: 350 mm Control: EXNER Guide way length: 750 mm nominal pressure: 2x 400 kN return capacity: 2x 150 kN ram stroke speed - under load: 100%: ca. 0 - 10 mm/s ram stroke speed: ca. 0 - 20 mm/s T-slot - width: 18 mm T-slot - distance: 150 mm Installation Space:: dayligth: 550 mm table surface area: 1.600 x 840 mm T-slot - width: 18 mm T-slot - distance: 90 mm dist. between pillars (left to right): 1.700 mm dist. between pillars (front to rear): 600 mm table height over floor: 1.300 mm total power requirement: 11 kW weight of the machine ca.: 12 t dimensions of the machine ca.: 2,5 x 2,0 x 3,7 m Hydraulic tool testing press EXNER - PG 80 - very good condition - approx. 300 operating hours - Electronic roller feed device EV 22 AK incl. Bandwidth: max. 220 mm Band cross section: max. 200 mm² Feed length: 0.1 x 19,999 mm Speed: ...
used
swing diameter: 2800 mm turning height: 1195 mm Control: Siemens 840 D turning speeds: 224 U/min x-travel: +-1600 mm z-travel: 1100 mm machine table: diameter: 2500 mm workpiece weight: 25000 kg power capacity: 80 kW Torque: 35900 Nm total power requirement: kW weight of the machine ca.: 66,5 t dimensions of the machine ca.: m faceplate diameter: mm Dörries 6, Machine no. V-800293 - Fixed crossbeam, no tool drive Ram -Cross section of ram: 250 x 250 mm -Travel ram: 1100 mm Equipment/accessories: -Tool changer revolver 4-times in the ram -Own filter system -BRANKAMP monitoring -REXROTH hydraulic unit -Chip conveyor -Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Description: Delivery date: 28.9.62 Pressing force: 40 t Largest sheet thickness: 4 mm Stroke number: 130/min Ram stroke: 8 - 88 mm Ram adjustment: 63 mm Largest distance between table and ram with max. stroke at bottom, adjustment at top, table at the bottom: 400 mm Smallest distance between table and ram with max. stroke at bottom, adjustment at top, table at top: 160 mm Lower worktop dimensions: approx. 550 x 440 mm Upper worktop dimensions: approx. 350 x 230 mm With safety screen weight approx.: 3,000 kg, Approx. Onsite Dimension. (l x w x h): 1,100 x 1,600 x 2,400 mm
used
Mini Tower PC Assembled- Intel i7 8core 3.6 GHZ, 64gb Ram, 256Gb disk, Nvidia GeForce RTX 2080 Mini Tower PC Assembled- Intel iS 4core 3.1Ghz, 8gb Ram, 128gB, Intel HD Graphics 4600 Mini Tower PC Assembled- Intel i7 4core 3.6 GHZ, 64gb Ram, 256Gb disk, Nvidia GeForce RTX 2080 Dell XPS 13.3" Laptop - S/N 7RRRYM2 - 64bit - 8mb cache -16gb Ram - SSD 512gb Lenovo Ultrabook Thinkpad 14" X1 Carbon- s/n PF-122LSC Wacom intuos pro medium PTH-651 Graphics Tablet Wacom intuos pro large PTH-851 Graphics Tablet
new
faceplate diameter:10000 mm swing diameter:10000 mm turning height:5000 mm ram head dimension:280x280 mm workpiece weight:200 t table turning speeds:0.23 ? 14 U/min transmission ratio:2 Stück Travel of Ram (vertical):2500 mm Travel of ram (horiz.):5150 mm Machine size (LxWxH):ca. 19500x11500×11600 mm main drive:132 kW weight of the machine ca.:290 t CNC controller:Siemens 828D/Fanuc 0i TF hydr. components:Kompass (Taiwan) Rams:2 (konv. + CNC) Stk. servo spindle motor:Siemens/Fanuc CE-design:optional Stock machine with short delivery time of only approx. 3-4 months. Main components available! Brand new vertical lathes double stand, type KRAFT, type VTL - 100 CNC incl. Siemens 828D or Fanuc 0i TF with two tappets (one piece of conventional and one piece CNC controlled ram) Substantially parts of the hydraulics of Taiwanese manufacturer compass Illustration similar. Also leasing and hire ...
new
:YS-VL-1000 | YS-VL-1200 | YS-VL-1600 | YS-VL-2000 faceplate diameter:1000|1250|1600|2000 mm swing diameter:1350|1600|2000|2500 mm turning height:1070|1350|1350|1700 mm max. turning diameter:1150|1350|1800|2300 mm table load:4|5|8|10 t table rotation speed:2 - 600 | 2 - 300 | 2 - 250 | 2 - 200 U/min max. torque on the faceplate:10000|12500|18500|54000 Nm Travel of Ram (vertical):800 | 900 | 900 | 1000 mm Travel of ram (horiz.):1350 | 1475 | 1650 | 2275 mm ram head dimension:230 x 230|250 x 250|250 x 250|280 x 280 mm rapid power traverse in X-and Z direction:10/12|10/12|10/12|10/10 m/min feeds:0,1 - 50 mm/U feed speeds:0 - 1260 mm/min Tool changer:12 (C-Achse mit 16) drive capacity - spindle motor:37/45| 37/45 (60/75 opt.)| 37/45 (60/75 opt.)| 37/45 (60/75 opt.) kW Machine height: 5330 |5500 |5500|6600 mm machine length:4600 |4700 |5050| 4950 mm machine width:5500 |5800 |6300|7320 mm weig ...
new
:YS-VL-3000 faceplate diameter:3000 mm swing diameter:3500 mm turning height:1650 mm max. turning diameter:3400 mm table load:40 t table rotation speed:2-40/41-120 U/min max. torque on the faceplate:64500 Nm Travel of Ram (vertical):1000 (1400 opt.) mm Travel of ram (horiz.):2775 mm ram head dimension:280x280 mm rapid power traverse in X-and Z direction:10/10 m/min feeds:0,1 - 50 mm/U feed speeds:0 - 1260 mm/min Tool changer:12 (C-Achse mit 16) tool taper:SK50/BT50 drive capacity - spindle motor:60/75 (75/100) kW Machine height:6700 mm machine length:6100 mm machine width:8700 mm weight of the machine ca.:69000 kg repeating accuracy:0,005 mm hydraulic motor:3,75 kW servo motor X-axis:7 kw servo motor Z-axis:7 kw coolant pump drive:2,2+1,1 kW :150 kva CNC controller:Siemens/Fanuc/Fagor coolant system:700 Liter automatic tool changer:16-fach 4-jaw faceplate Ø:s. oben CNC controls from:Sie ...
new
faceplate diameter:4000 mm swing diameter:5000 mm turning height:2500 mm max. turning diameter:5000 mm table load:40 t table rotation speed:0,1-80 (2-stufig) U/min max. torque on the faceplate:108000 Nm Travel of Ram (vertical):1800 mm Travel of ram (horiz.):-2500~+2900 (aus Tischmitte) mm ram head dimension:300x300 mm spindle speed:10-2500 (2-stufig) 1/min spindle taper:50 SK rapid power traverse in X-and Z direction:10/10 m/min feed speeds:1-3000 mm/min Cross rail travel :1680 mm Tool changer:12-fach für rechten Stößel (für Drehwerkzeuge) Tool changer:60-fach für linken Stößel (für Fräswerkzeuge) tool taper:SK50/BT50 Machine height:s. Anlage mm machine length:s. Anlage mm machine width:s. Anlage mm drive capacity - spindle motor:18,5/22 kW coolant pump drive:3 kW servo motor X-axis:9 kw servo motor Z-axis:9 kw table drive:100 kW :300 kva positioning accuracy:0,01/500 mm repeat ...
used
sheet width:2000 mm plate thickness:1.8 mm Controls:SIEMENS S7 PRESS DESIGN:. - frame design : H-frame :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - height above floor level:375 mm RAM:. - ram force:800 to - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):3100 mm - Free passage between side columns (width):2560 mm - Free passage between side columns (height):1500 mm DECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. diamet ...
used
pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:56 / 84 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:710 x 500 mm hole in the table:320 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,1 t dimensions (W x D x H):1,35 x 2,0 x 2,6 m overload protection in ram:mechanical
used
Pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:700 x 500 mm hole in the table:250 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,5 t Dimensions (WxDxH):1,6 x 2,0 x 2,8 m overload protection in ram:mechanical
used
Pressure:063 t throat:250 mm stroke:10 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:380 mm table surface area:700 x 500 mm hole in the table:180 x 140 mm table height over floor:700 mm ram surface:360 x 275 mm ram adjustment:60 mm power requirement:5,5 kW weight:3,8 t Dimensions (WxDxH):1,9 x 1,7 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical
used
pressure:150 t throat:400 mm stroke:30 - 150 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1000 x 750 mm hole in the table:320 x 200 mm table height over floor:800 mm ram surface:800 x 600 mm ram adjustment:85 mm weight:10,0 t Dimensions (WxDxH):1,4 x 2,2 x 3,1 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram counterbalance:pneumatic
used
nominal force:2500 t stroke:600 mm cycle time:13 - 18 s distance between columns:1720 mm Distance table/ram, max. stroke up, adjustment up:2600 mm table surface area:1720 x 1800 mm allowed max. force:4000 t blow die to die:5000 t ram surface:2100 x 1320 mm capacity of ejector in table:40 t ejector stroke in table:250 mm ejector surface area in table:900 x 820 mm capacity of ejector in ram:6 t ejector stroke in ram:40 mm spindle diameter:425 mm power requirement:900,0 kW weight:335,0 t Dimensions (WxDxH):3,4 x 4,6 x 9,7 m height over floor:8,3 m fully-automated forging line:to produce axle shaft
used
pressure:015 t throat:200 mm stroke:4 - 70 mm no. of strokes:140 /min distance table/ram, max. stroke up, adjustment up:310 mm table surface area:430 x 395 mm hole in the table:165 x 160 mm table height over floor:560 - 735 mm table adjustable:175 mm ram surface:160 x 130 mm ram adjustment:80 mm power requirement:1,2 kW weight:0,9 t Dimensions (WxDxH):1,0 x 1,25 x 1,8 m clutch:Drehkeil overload protection in ram:mechanical
used
pressure:100 t throat:350 mm stroke:6 - 100 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:850 x 700 mm hole in the table:470 x 150 mm table height over floor:855 mm ram surface:450 x 300 mm ram adjustment:80 mm power requirement:7,5 kW weight:5,0 t dimensions (WxDxH):1,5 x 2,3 x 2,6 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical
used
pressure:040 t stroke:8 - 50 mm no. of strokes:50 - 300 /min distance between columns:600 mm distance table/ram, max. stroke up, adjustment up:285 mm table surface area:590 x 500 mm hole in the table:590 x 40 - 100 mm table height over floor:860 mm column travel -side:280 mm ram surface:590 x 380 mm ram adjustment:80 mm material width of feeder:150 mm power requirement:7,5 kW clutch:pneumatic ram adjustment:motoric pincer feed:mechanical
used
pressure:035 t throat:225 mm stroke:8 - 100 mm no. of strokes:110 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:580 x 460 mm hole in the table:250 x 150 mm table height over floor:700 mm table adjustable:230 mm ram surface:355 x 120 mm ram adjustment:70 mm power requirement:2,2 kW weight:1,5 t dimensions (WxDxH):1,0 x 1,5 x 2,05 m clutch:rolling key overload protection in ram:mechanical
used
pressure:080 t throat:360 mm stroke:8 - 112 mm no. of strokes:78 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:900 x 650 mm hole in the table:250 mm table height over floor:800 mm passage to the back:330 mm ram surface:650 x 400 mm ram adjustment:80 mm power requirement:11,0 kW dimensions (WxDxH):1,2 x 2,2 x 2,9 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanisch
