quil used for sale

turning diameter: 420 mm turning length: 1500 mm swing diameter over bed slide: 250 mm Swingdiameter in the bed bridge: 590 mm centre height: 210 mm Turning length in the bed bridge: 260 mm reus: 16 (45-1800) U/min tail stock: MK 4 quill stroke: 120 mm diameter of quill: 50 mm spindle taper: DIN ISO 702-2 Nr. 6 spindle bore: 52 mm spindle cone: MK 6 feed: längs 17 / 0,05 - 1,7 m/min feed: plan 17 / 0,025 - 0,85 m/min total power requirement: 4,6 kW weight of the machine ca.: 1340 kg dimensions of the machine ca.: 2440 x 915 x 1375 mm Fully equipped leading and tension spindle lathes. TH 4215 with digital position indicator DPA 21 - Hardened and ground Z-axis guideway - Spindle mount Camlock DIN ISO 702-2 No. 6 - Precisely crafted slide - Handwheels with adjustable fine scale 0.04 / 0.02 mm - Quadruple steel holder - All guides can be adjusted using V-ledges - Upper slide adjustment rang ...

Power: 0.85, 1.5kW; Speed range: 300 - 4000 rpm; Speed levels: infinitely variable; Spindle mount: MK-3; Drilling stroke: approx. 105 mm; Spindle projection: 200 mm; Weight: 152 kg; Smooth-running and powerful electric motor Two speed settings clockwise/anticlockwise rotation V-belt cover with safety switch Digital speed display integrated in the housing concentricity guaranteed less than 0.015 mm measured in the drill quill Height-adjustable chuck guard with microswitch for the greatest possible protection of the user Machine light integrated in the drill head Drilling spindle with precision ball bearing High-quality quick-release drill chuck as standard Precisely machined drill table with diagonally running T-slots, 360Â rotatable with circumferential cooling water chute Thick-walled cast iron column for high force absorption and stability Solid base plate, large dimensions st ...

turning diameter: 330 mm turning length: 830 mm swing diameter over bed slide: 196 mm Swingdiameter in the bed bridge: 170 centre height: 165 mm centre distance: 830 mm Turning length in the bed bridge: 430 reus: 16 (70-2000) U/min tail stock: MK 3 quill stroke: 110 mm diameter of quill: 32 mm spindle taper: DIN ISO 702-2 Nr. 4 spindle bore: 38 mm spindle cone: MK 5 feed: längs 32 / 0,052 1,392 m/min feed: plan 3,2 / 0,014 0,38 m/min total power requirement: kW weight of the machine ca.: 0,52 t dimensions of the machine ca.: 1,7 x 0,75 x 1,6 m Fully equipped leading and tension spindle lathes. TH 3309D with digital position indicator DPA 21/3402040 - Hardened and ground Z-axis guideway - Spindle mount Camlock DIN ISO 702-2 No. 4 - Precisely crafted slide - Handwheels with adjustable fine scale 0.04 / 0.02 mm - Quadruple steel holder - All guides can be adjusted using V-ledges - Main spi ...

turning diameter: max. 650 mm turning length: max. 790 mm control: MORIC T5F turning diameter over bed: 890 mm turning diameter over cross slideways: 560 mm centre distance: 900 mm Main spindle:: turning speed range - main spindle: 4 - 1.010 min/-1 power capacity - main spindel: 37 / 30 kW max. Torque: 3.870 Nm Number of speed ranges: 2 spindle bearing diameter: 240 mm spindle bore: 168 mm max. bar capacity: 144 mm usable bar diameter: 120 mm spindle head: JIS A2 -11 chucking diameter: 610 mm turret:: number of toolpositions: 12 pos. Shank height for square tool: 32 mm Drill shank diameter: max. 65 mm axis stroke:: x-axis: 350 (25 + 325) mm z-axis: 860 mm Tailstock:: tailstock: 680 mm diameter of quill: 110 mm quill stroke: 100 mm taper of center: MK 4 feeds:: rapid traverse: X: 5 / Z: 8 m/min Tipp feed: 0 - 1.260 mm/min total power requirement: 69 kVA weight of the machine ca.: 9,2 ...

Table drill, table drilling machine ALZMETALL type AX 3 T Fabr. No. 3826 Year of construction 1983 Drilling capacity 30 mm Spindle holder MK 3 - long quill Spindle speed 250 - 1600 rpm 5 steps projection 250 / 290 mm Pinol stroke 120 mm Table size 400 x 300 mm Distance spindle-table top max. 700 mm Column diameter 115 mm Motor power 0.75 kW Mains connection 380 Volt, 50 Hz - Spindle speed via 5 V-belt stages - Drill head height adjustment via hand crank approx. 450 mm (column extends downwards through the table top) - Emergency stop button quick-change drill chuck ALBRECHT 1-13 mm Space requirement L x W x H 900 x 600 x 1400 mm Weight 185 kg good condition; used

Drilling capacity steel/GG: 40/55 mm Spindle holder: 4 MK Projection: 345 mm Table size: 450 x 600 mm Quill stroke: 180 mm Spindle speeds: 30 - 760 rpm Feeds: 0.15; 0,2; 0.3 & 0.36 mm Drive motor: 380 V, 2.3/3.4 kW Space requirement: 1150 x 730 x 2000 mm Weight: 600 kg

Stanko X: 1000 - Y: 320 - Z: 410 mm Max longitudinal travel X-axe: 1000 mm Max cross-travel Y-axe: 320 mm Max travel Z-axe: 410 mm Max height workpiece: 500 mm Power on spindle: 7,5 kW Max quill travel Z´: 80 mm Admission in boring head (ISO): ISO 50 Spindlespeeds: 1450 rpm Table size: 1700 x 400 mm Length: 2560 mm Depth : 2260 mm Height: 2120 mm Weight: 4,2 ton

Drilling capacity steel/GG: 35/40 mm Spindle mount: 4 MK Projection: 350 mm Table size: 560 x 560 mm Quill stroke: 180 mm Spindle speeds: 30 - 1450 rpm Feeds: 0.1/0.2 mm Drive motor: 400 V, 0.75/1.5 kW Space requirements: 900 x 550 x 2300 mm Weight: approx. 500 kg

Machine Details Stock-No. 1105-03853 Type of machine CNC Lathe Make MORI SEIKI Type NLX 2500/700 Year of manufacture 2016 Type of control CNC Storage location HAGUENAU Country of origin Japan Delivery time to be agreed Freight basis ex site Price Technical details turning diameter 356 mm turning length 705 mm control MORI SLIM LIN X-AXIS 260 mm Z-AXIS 795 mm power capacity - main spindle 18,5/15 kW Speed Mainspindle 3300 min/-1 Spindle Bore 91 mm spindle nose JIS A2-8 chuck Kitagawa B-212A8 mm max. chuck pressure 3.1 MPa number of toolpositions 12 pos. Shank diameter 50 mm Shank height for square tool 25 mm Turret change time 0.25 sec. tailstock 734 mm slide. of quill 80 mm rapid power traverse in X-and Z direction 30 m/min rapid travel tail stock 7 m/min total power requirement 27,6 kW Weight of the machine approx. 5.8 t dimensions of the machine app ...

x-travel: 720 mm y-travel: 255 mm Z-Travel: 400 mm clamping surface area: 1000 x 250 mm range of revolution per miute: 40...3150 / 8 step U/min tool taper: ISO 40 (SK40) milling head swivable : +/- 90 ° Quill Stroke: 127 mm feed:Z: 8,5...136 / with 9 step rapid traverse:: X/Y/Z: 2500 mm/min feed:: X/Y: 28...450 / with 9 step mm/min. total power requirement: 3.2 (4 kVA) kW dimension machine approx. LxWxH: 1.8 x 1.6 x 2.4 m Weight of the machine approx.: 1,5 t

x-travel: 400 mm y-travel: 210 mm z-travel: 300 mm Table size: 600x390 mm Spindle mount ISO: 40 Spindle speeds: 40-2000 rpm 3 axes feed rate 10-500 mm/min Rapid traverse 1.25m/min Quill stroke 60mm Universal table 600'390mm T grooves 16mm H7 5pcs Transverse adjustment manual165mm Swivel around the horizontal longitudinal axis +/-30° Swivel around the horizontal transverse axis +/-30° Can be rotated around the vertical axis 360° Various tool holders and collets Documentation Weight of machine approx.: 1.5 t Dimensions approx.: 1.3x2x1.7 m high Digital display Fagor 3 axes Forklift for on-site loading

Machine Details Stock-No. 1105-03860 Type of machine CNC Lathe Make MORI SEIKI Type SL 150 Year of manufacture 1996 Type of control CNC Storage location Warehouse Country of origin Japan Delivery time immediately Freight basis ex Warehouse, free on truck Price Technical details turning diameter 420 mm centre distance 580 mm Turning length max. 500 mm Travel X / Y 230 / 520 mm spindle turning speed range 50 - 5000 rpm spindle nose JIS A2-5 bar diameter round max 42 mm spindle bearing diameter 90 mm tool turret - number of stations 12 (12) Tool Taper 20 x 20 tailstock adjustment 515 mm tailstock quill diameter 85 mm tailstock quill taper MT 4 tailstock travel 120 mm Rapid Travel - Longitudinal/Face 24 / 18 m/min Coolant Tank 160 L connected load 21 kVA Weight of the machine approx. 4.1 t dimensions of the machine approx. 7.5 x 2.5 x 1.8 m Additional infor ...

x-travel: 700 mm y-travel: 400 mm z-travel: 450 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m 3-axis digital read out horizontal and vertical milling spindle quill Technische Daten / technical details: Längsweg X / X-travel longitudinal 700 mm Querweg Y / Y-travel cross 400 mm Senkrechtweg Z / Z-travel vertical 450 mm Tischgröße / table size 1000x470 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 31,5-1600 UpM /rpm Vorschubbereich X und Y-Achse / feed range X and Y axis 10-500 mm/min. Vorschubbereich Z-Achse / infeed Z-axis 5-250 mm/min Antriebsleistung/ power capacity 5 kW Gewicht der Maschine / weight 2400 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was cre ...

grinding diameter: max. 320 mm grinding length: 1.500 mm centre height: 160 mm Control: Touch Jones & Shipman between centers: max. 100 kg table:: Traverse Z-Axis: 1.645 mm traversing speed: 0,0001 - 12 m/min swivable: +5 / -5 ° x-axis:: Traverse X-Axis: 260 mm traversing speed: 0,0001 - 6 m/min grinding head:: grinding wheel motor: 7,5 kW cutting speed: 45 m/s Grinding wheel Ø x width x bore: 450 x 50 x 203,2 mm Tailstock:: Swivel range: -15 / +90 ° turning speed range: 0 - 660 U/min Torque: 27 Nm tool adaptor: MK 3 total power requirement: kW weight of the machine ca.: 8,5 t dimensions of the machine ca.: 5,5 x 2,5 x 2,0 m paper band filter: magnetic separator for cooling water: Coolantsystem: Cylindrical Grinding Machine JONES & SHIPMAN - Suprema Easy 1500 E - Replacement grinding wheel flange - Multi-grain diamond (for circumferential and lateral dressing, 10mm, 1 carat) -  ...

Bench drill Manafacture: IXION Type BST - 25438/61 Projection approx. 180 mm Quill stroke approx. 65 mm Year of manufacture: unknown Power: 0.25 kW Chuck 0-10 mm total height approx. 80 cm Weight approx. 55 kg Item location: 58730 Fröndenberg/Ruhr The machine can be viewed and tried out under power. We will be happy to send you more photos by e-mail. A forklift/crane for loading is available. We reserve the right to make an intermediate sale. It is possible to expertly examine the items for sale on site. Specific questions should be clarified in advance. The information, such as technical data, dimensions, year of construction, condition are non-binding and have been shown to the best of our knowledge and belief. Errors are therefore reserved. The warranty / guarantee is excluded. The goods are sold ex location / warehouse, with the transfer of risk to the b ...

turning diameter: 500 mm turning length: 1000 mm control: MONFORTS CONTROL control: SYSTEM MTC-K turning diameter over bed slide: 290 mm spindle bore: 70 mm spindle turning speed range: 3 - 2800 U/min spindle power: 15 kW max. torque on the spindle: 1530 Nm spindle head: DIN 55027 Gr. 8 feed power X/Z axis: 11300 N rapid travel - longitudinal/face: 10 / 5 m/min bed width: 360 mm travel of cross-slide: 265 mm upper slide travel: 140 mm turning tool - shaft cross cut: 32 x 25 mm tailstock quill diameter: 80 mm tailstock quill stroke: 160 mm tailstock taper MT: 5 total power requirement: kW weight of the machine ca.: 3,1 t dimensions of machine L x W x H: 2,88 x 1,68 x 2,18 m Accessories: 3-jaw chuck ROTA-S plus 250 mmø, 4 pos. toolholder PARAT, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer | Manufacturer: Chemnitzer Maschinenbau GmbH Chemnitz Type | Type: CMB 16 Pinole Lift | Quill stroke: 120 mm Speed (infinitely variable) | speed (stepless): 460 - 1840 rpm ; 140 - 560 rpm Dimensions table | Table dimensions: 280 x 360 mm Adjustment range table | Adjustment travel table: 540 mm Recording | Holder: MK 2 Connected load | Connection Value: 0.8 kW Total weight | Total Weight: 350 kg

Radial drilling machine, used Manufacturer: KOVOSVIT Type: VO 50 Year built:1999 Projection: 1600 mm Drilling capacity: 60 mm Quill stroke 310 mm Table / footprint 1470 x 986 mm Weight: approx. 5 t

turning diameter: 500 mm turning length: 1500 mm control: MONFORTS CONTROL control: SYSTEM EURO TURN turning diameter over bed slide: 290 mm spindle bore: 70 mm spindle turning speed range: 3 - 2800 U/min spindle power: 15 kW max. torque on the spindle: 1530 Nm spindle head: DIN 55027 Gr. 8 feed power X/Z axis: 11300 N rapid travel - longitudinal/face: 10 / 5 m/min bed width: 360 mm travel of cross-slide: 265 mm upper slide travel: 140 mm turning tool - shaft cross cut: 32 x 25 mm tailstock quill diameter: 80 mm tailstock quill stroke: 160 mm tailstock taper MT: 5 total power requirement: kW weight of the machine ca.: 3,3 t dimensions of machine L x W x H: 3,45 x 1,65 x 1,93 m Accessories: 3-jaw chuck ROTA-S plus 250 mmø, 4 pos. toolholder PARAT, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

greates pass round over bed: 175 mm swing diameter over slide rest: 350 mm centre distance: 800 mm bed width: 220 mm spindle bore: 46 mm internal taper -metric: 50 (1:20) mm chucking diameter: 160 (max. 200) mm face slide travel: 225 mm upper slide: 100 mm swival range +/-: 45 Grad lead of leadscrew: 6,0 mm quill stroke: 130 mm dia. of quill: 50 mm taper: 3 MK number of spindle speeds: 3,5-2500 min number of spindles: 18 power capacity: 4,7 kW longitudinal feeds:: 0,051-1,034 mm/U face feeds: 0,025-0,517 mm/U metric threading: 0,4-7,0 mm Dimensions (L/W/H): 1920x990x1360 mm weight of the machine ca.: 900 kg voltage: 400 V The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Bosch Turbo Scara SR6 Swivel Arm Robot Manafacture: Bosch Order No. 3842999835 Serial No. 3610 773 Tripod length: Console HubQuill 40025 PN. pressure max. 8 bar Load max 8 kg Weight 48.5 kg Swivel range see picture Mounted on aluminium profile base frame. Condition: Used The robots were all in the warehouse of a large automotive supplier as a breakdown replacement machine, so they are they are in very good condition. In addition to about 50 paternosters, there are countless other machines such as presses, robots, ovens, industrial vacuum cleaners, etc. Available. Workshop equipment, workbenches, workshop trolleys, tools, stackers and shelves plentiful A total of 24,000 m² of production space will be dismantled and sold Please also take a look at our other offers.' After purchase, the amount is due within 7 working days. More items - new and used ...

max. turning diameter: 580 mm turning length: 1500 mm control: OSP 7000 L greates pass round over bed: 610 mm swing diameter over slide rest: 580 mm Main spindle:: turning speed range - main spindle: 12 - 2.800 min/-1 spindle bearing diameter: 150 mm spindle bore: 110 mm spindle nose: JIS A2-11 power capacity - main spindel: 37 (30) kW C-Axis: 0,001 ° axis stroke:: x-axis: 598 mm y-axis: 230 (+110 / -120) mm z-axis: 1.660 mm feeds:: rapid traverse: X / Y: 12.000 mm/min rapid traverse: Z: 20.000 mm/min rapid traverse: C: 100 min/-1 cutting feed speed: X / Z / Y: 0,001 - 1.000 mm/U turret:: type: H2 ATC number of toolpositions: 2 (1x L-Tool / 1x M-Tool) pos. driven statition: stufenlos / stepless Spindle speed - driven tool stations: 40 - 3.000 min -1 tool shank height: 25 mm Boring bar shank diameter: 50 mm Tailstock:: diameter of quill: 120 mm quill stroke: 170 mm taper of center:  ...

Univ. NC tool milling machine KUNZMANN type WF 3/4 machine no. 341020 Year of construction 1998 Travel X: 400 mm Y: 320 mm Z: 400 mm Table size 650 x 350 mm Spindle mount SK 40 Spindle speed 40 - 2500 rpm. Feeds X, Y and Z- axis 0 - 1000 mm/min. infinitely variable rapid traverse X, Y- axis 4000 mm/min. Rapid traverse Z-axis 3000 mm/min. Vertical quill adjustment 60 mm Drive power spindle motor 3 KW Mains connection 400 volts, 50 Hz - CNC line control Heidenhain TNC 124 - Spindle speed over 2 gear stages and infinitely variable via frequency converter - Vertical milling head +/- 90 swivelling - hydr. Tool clamping - fixed angle table - control cabinet fixed to the machine - coolant tank with pump opposite - central lubrication - lighting space requirement L x W x H 1800 x 1800 x 1900 mm weight 1300 kg good condition; used

Universal – Milling Machine Make: Deckel Type: FP 4 A Year of construction: 1985 Controls: Contour 1 Travel: x-485 mm y-385 mm z-380 mm Quill stroke: 80 mm Main drive: 3.7 / 4.4 kW Speeds: 18 steps 50 -2500 rpm Mounting: SK 40 Feed rate: 10 – 1000 mm/min Rapid traverse: 2000 mm/min Table size: 800 x 460 mm Weight: approx. 1800 kg

Machine Details Stock-No. 1105-03874 Type of machine CNC Lathe - Inclined Bed Type Make MORI SEIKI Type SL 15 Year of manufacture 1991 Type of control CNC Storage location FRANCE Country of origin Japan Delivery time by arrangement Freight basis ex stock HAGUENAU FRANCE Technical details Travel -X AXIS 230 mm turning diameter 450 mm turning length 525 mm control FANUC 15TF Spindle Bore: Ø 42 mm Number of Turrets: 1 piece no. of tools in turret 1 12 Stück power capacity 7,5 kW spindle nose A2-5 tailstock quill taper MT 4 feed range 1 - 15000 mm/min Rapid Traverse 15 m/min Additional information Machine in good condition CONTROL FANUC 15 TF CHIP CONVOYER TAILSTOCK NICE MACHINE

Universal milling machine Ecomil 100 Heidenhain Control TNC 124 SK 50 56 shots with tools Spindle head swivel Quill extendable 700 x 2000 clamping area Control retrofitted. Feed continuously variable all axes Rapid traverses Length 3.20 m Width 2 m Height 3.50 m Weight 14 tons Spindle 20 - 1000 rpm T slots 22/42 min distance 140 mm

bore capacity in steel (diameter): 50,0 mm throat: 360 mm bore stroke: 220 mm morse taper: 4 MK table:: 570 x 480 mm threading: M 42 Stahl turning speeds: 50 - 2.200 U/min feed: 0,08 - 0,50 mm/U column diameter: 180 mm total power requirement: 3,0 kW weight: 575 kg range L-W-H: 750 x 950 x 2380 mm The gear column drilling machine GB 50 NC Vario is standard with a infinitely variable speed control, reducing the cutting speed can be optimally adapted to the workpiece. Because of the heavy, massive It is designed primarily for use by professional users or ideally suited in mechanical engineering or workshops. - Equipped with motorized table height adjustment as standard - 6 automatic drilling feeds switchable via electromagnetic clutch - Hand-scraped drilling table made of solid gray cast iron, swiveling from -45° to + 45 ° - Ground base plate with T-slots - for clamping particularly tal ...

turning length: 1500 mm turning diameter: 560 mm turning diameter over slide: 350 mm turning speeds: 25-220/220-1500 U/min swing diameter over bed slide: 350 mm turning dia. in gap: 785 mm quill travel: 185 mm spindle bore: 105,0 mm engine output: 7,5 kW spindle taper: DIN 55029 D 1-8 quill:: 5 MK weight of the machine ca.: 2420 kg. range L-W-H: 2840 x 1150 x 1610 mm Furnishing : - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck PS3-315 mm / D8 - Fixed bezel - Passage diam. 180mm max - Revolving bezel - passage diam. 120mm max - Foot pedal with brake function according to CE - Protective device for quick-change tool holder - LED machine light - First fill with Shell Tellus 46 - Clamping disc 450 mm - 2 center points - Frequency converter - Digital speed display - slip clutch - Rapid traverse longitudinal and face - Cooling device - Quick change steel holder with 4 inserts - ...

turning diameter: 324 mm turning length: 600 mm control: SINUMERIK 840D ShopTurn bar diameter: 65 mm swing diameter: 680 mm travel -x axis: 260 mm travel -z axis: 635 mm spindle speed:: 5000 1/min spindle bore: 79 mm C-Axis: 0,025 ° turret head: 12 Pos. / VDI 40 Driven Tools: 12 Pos. 4.500 U/min rapid traverse X-axis: 60 m/min rapid traverse Z-axis: 45 m/min taper in tailstock-quill: MK 5 tailstock travel: 580 mm drive capacity - spindle motor: 25 kW voltage: 400 V total power requirement: 50 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 3,50 x 2,46 x 2,10 m chip conveyor: 4,00 x 1,25 x 1,50 m - Serial-No.: 02260001561 - Machine ON: 64.692 h - Programm ON: 18.296 h - control: SIEMENS 840D ShopTurn - electrical hand wheel - C-Axis / driven tools - Spindle bearings NEW - Ball screw Z-Axis incl. bearings NEW - chip conveyor - coolant equipment - machine lamp The dat ...

Tapping capacity: 45 mm Drilling capacity: 45 mm Throat: 322 mm Tapping depth: 4 mm Pillar drillALZMETALL - AC 32 MACH-ID 7651 Make: ALZMETALL Type: AC 32 Year: 2007  Max. drill Ø steel:          45mm Max. tap Ø:                  30M Stroke pinole:               180mm Throat:                      322mm Column sleeve:               145mm Quill Ø:                     46mm Spindle Taper:               4ISO/Bt/Mk Speeds / ranges:             5000Rpm Table Length:                500mm Table Width:&nb ...

turning diameter: 324 mm turning length: 600 mm control: Data Pilot 4290 HEIDENHAIN swing diameter: 680 mm bar diameter: 65 mm travel -x axis: 260 mm travel -z axis: 635 mm spindle speed:: 5000 1/min spindle bore: 79 mm C-Axis: 0,025 ° turret head: 12 Pos. / VDI 40 Driven Tools: 12 Pos. 4.500 U/min rapid traverse X-axis: 60 m/min rapid traverse Z-axis: 45 m/min taper in tailstock-quill: MK 5 tailstock travel: 580 mm drive capacity - spindle motor: 25 kW voltage: 400 V total power requirement: 50 kVA weight of the machine ca.: 6,0 t dimensions of the machine ca.: 3,50 x 2,46 x 2,10 m chip conveyor: 4,00 x 1,25 x 1,50 m - Serial-No.: 02260003251 - Machine ON: 19.039 h - Programm ON: 2.676 h - control: HEIDENHAIN Data Pilot 4290 - New main spindle bearings - Z-Axis ball screw reconditioned incl. new bearings - electrical hand wheel - C-Axis / driven tools - chip conveyor - coolant equipmen ...

Travel: X, Y, Z 595mm x 400 mm x 450 mm Speed range from 30 - 1,800 rpm for horizontal and vertical Milling head to turn to the right and left with quill 75 mm Tool holder SK 40 Machine number 80003 Accessories: 3-axis digital display Heidenhain

Turning diameter: 1600 mm Center distance: 10000 mm Spindle bore: 110 mm Numbers of bed guide ways: 2 Weight between centres maximum: 30000 kg CNC Brand: Siemens CNC latheGurutzpe - GLX 16.15.7  4 bed way construction Bed width 1350 mm Chip conveyor 4 chuck 1250 mm Filtration / Coolant system 2 x C-Type steady rest Motorized tailstock Max. turning Ø:1600mm Spindle bore:  110mm Speedrange:    800Rpm Spindle power: 71kW ATC / revolver:4 Chip conveyor: Yes Pinole taper:  6Mk Quill Ø:       220mm Length:        12000mm Width:         4000mm Height:        3200mm Weight:        35000kg

turning diameter over bed: 330 mm turning diameter over slide rest: 170 mm turning length: 800 mm centre height: 155 mm centre distance: 800 mm spindle bore: 38 mm spindle turning speed range: 24 - 2800 U/min spindle head: DIN 55022 Gr. 5 feeds - longitudinal: 0,026 - 1,253 mm/U feeds - cross: 0,013 - 0,628 mm/U dia. of leadscrew: 24 mm lead of leadscrew: 6 mm tailstock taper MT: 3 tailstock quill stroke: 110 mm total power requirement: 3 kW weight of the machine ca.: 800 kg dimensions of machine L x W x H: 1,80 x 0,70 x 1,23 m Accessories: 3-jaw chuck RÖHM 160 mmø, changing tool post PARAT, solid steady, running center, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 390/400 mm y-travel: 210/220 mm z-travel: 390/400 mm turning speeds: 25-2500 U/min feed: 8-400 mm/min rapid traverse: 1500 mm/min quill stroke: 100 mm tool taper: Sk 40 x S 20 x 2 drive motor: 2,0/3,0 kW total power requirement: kW weight of the machine ca.: 1,2 t dimensions of the machine ca.: m Optical condition: good: Mechanic: good: The machine can be viewed under current.: 2202 11050 380 V, 50 Hz, with CEE plug and cable Color green Equipment: 3 Axis Active Digital Display (HH) TNC 113 Vertical head Sk 40 Coolant device Centralized lubrication pump Free-running safety wheels Stepless feed Emergency stop switch Engine brake New scrapers New bellows Great maintenance done Lockable main switch 10 tool holders fixed angle table (planed) Chip tray 4 machine shoes Cold light lamp Instruction manual, spare parts list, circuit diagram Control key u. driver ri ...

Center height: 420 mm Center distance: 2176 mm Spindle bore: 78 mm Steady rest hydraulic 50 130 mm Axial force tailstock pinole 15 kN Rebuild in 2017 at EUR 80k Large tooling package Max. turning Ø:420mm X-Axis:        2176mm Z-Axis:        370mm Spindle bore:  78mm Speedrange:    2800Rpm ATC / revolver:12 Pinole taper:  Sk30Mk Stroke pinole: 100mm Quill Ø:       100mm Length:        7300mm Width:         3070mm Height:        2250mm Weight:        13700kg

turning diameter over bed: 360 mm turning diameter over slide rest: 220 mm turning length: 1000 mm turning diameter in the gap: 380 mm turning speeds: 70 - 2000 U/min centre height: 180 mm spindle bore: 50 mm tailstock quill taper MT: 3 MK connected load frequency: 230 V total power requirement: 1,8 kW weight of the machine ca.: 0.65 t dimensions of the machine ca.: 2,0 x 0,8 x 1,56 m 3-axis digital display 3-jaw chuck 200 mm. 4-jaw chuck 200 mm. Faceplate 320mm bezel fixed running bezel 4-fold steel holder. Halogen machine light machine light foot brake removable chip tray, chip protection wall Hardened and ground bed tracks Complete coolant system lining protection machine tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 1000 mm turning diameter over slide rest: 710 mm turning length: 7000 mm max. workpiece weight between centres: 10000 kg spindle turning speed range: 1,8-400 U/min tailstock quill taper metric: 80/1:10 tailstock - quill dia: 170 mm tailstock - travel of quill: 200 mm Tailstock quill travel speed: 2150 mm/min main drive motor: 37 kW longitudinal feeds:: 0,125-48 mm/U face feeds: 0,4 der Längsvorschübe weight of the machine ca.: 17 t dimensions of the machine ca.: 11x1,9x2 m machine was mechanically and electrically overhauled in the last years. - taper turning function - 3 lynettes - misc. center points for tailstock - set of change gears The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 45 mm arm length: 325 / 1000 mm workpiece height max.: ca. 1000 mm spindle taper MT: 4 spindle turning speed range: 40 - 1700 U/min feeds: 0,125 - 1,25 mm/U distance spindle/base plate: 385 / 1400 mm quill stroke: 325 mm crossrail adjustment vertical: 700 mm : 360 ° boring head horiz. adjustable: 675 mm base plate surface area: 1300 x 800 mm total power requirement: 6,2 kW weight of the machine ca.: 3,8 t - autom. feed - right-/left spindle run Accessories: box table 1000 x 750 x 500 mm, hydr. vice, width of jaws 200 mm, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning length: 750 mm turning diameter: 310 mm turning diameter over slide rest: 175 mm spindle bore: 32,0 mm tailstock quill taper MT: 3 MK turning speeds: 85 - 2200 U/min bed width: 200 mm spindle taper: DIN 55027 GR 5 total power requirement: 2,2 kW weight of the machine ca.: 710 kg range L-W-H: 1884 x 717 x 1262 mm New price ~ 20.000 euros from a technical college () Furnishing: - Robust conventional center lathe - 3-jaw lathe chuck Ø 160 mm, with replacement jaws - NEWALL digital display, front left - MULTIFIX steel holder with 4x inserts - fixed bezel - moving bezel - Movable tailstock - Foot/spindle brake - Machine swing feet - User manual (PDF/NL) all technical data: - Turning diameter over bed 310 mm - Distance between centers 750 mm - Turning diameter over support 175 mm - Spindle bore 32 mm - bed width 200 mm - Spindle mount / DIN 55027 GR 5 - Spindle taper 4.5 M - Spindl ...

turning length: 750 mm turning diameter: 310 mm centre height: 175 mm spindle bore: 32,0 mm tailstock quill taper MT: 3 MK turning speeds: 85 - 2200 U/min bed width: 200 mm spindle taper: DIN 55027 GR 5 total power requirement: 2,2 kW weight of the machine ca.: 710 kg range L-W-H: 1884 x 717 x 1262 mm New price ~ 20.000 euros from a technical college () Furnishing: - Robust conventional center lathe - 3-jaw lathe chuck Ø 160 mm, with replacement jaws - NEWALL digital display, front left - MULTIFIX steel holder with 3x inserts - fixed bezel - moving bezel - Movable tailstock - Foot/spindle brake - Machine swing feet - User manual (PDF/NL) all technical data: - Turning diameter over bed 310 mm - Distance between centers 750 mm - Turning diameter over support 175 mm - Spindle bore 32 mm - bed width 200 mm - Spindle mount / DIN 55027 GR 5 - Spindle taper 4.5 M - Spindle speed 85 - 2000 r ...

centre height: 102 mm Distance between centres: 450 mm turning dia. over face-slide: 120 mm turning diameter over bed: 200 mm spindle taper:: W20 spindle bore: 22 mm number of spindle speeds: 18 from/to: 45-2500 U/min tailstock quill taper MT: 2 diameter of quill: 30 mm quill stroke: 110 mm dimensions of the machine ca.: 1500x800x1400 mmxmmxmm weight: 380 kg accessories and equipment:: 3-jaw-chuck diameter: 100 mm quick change tool holder:: make: MULTIFIX boring chuck: 1 misc. accessories: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Turning diameter: 550 mm Turning length: 550 mm Turret positions: 12 CNC Brand: Fanuc Tool holders included Around 4000 Hours Tool eye 3 chuck Samchully Max. turning Ø: 550mm X-Axis:         220mm Z-Axis:         550mm Spindle bore:   65mm Speedrange:     4000Rpm Spindle power:  15kW ATC / revolver: 12 Speed live tools:4000Rpm B-Axis power:   3.7kW Chip conveyor:  Yes Tool eye:       Yes Pinole taper:   4Mk Stroke pinole:  720mm Quill Ø:        56mm Length:         2900mm Width:          1650mm Height:         1870mm Weight:         4400kg

x-travel: 500 mm y-travel: 350 mm z-travel: 380 mm table-size: 790x360 mm spindle turning speed range: 63-4000 U/min spindle taper ISO: 40 quill stroke: 50 mm range L-W-H: 1600x2000x1850 mm digital readout: PHILIPS weight of the machine ca.: 1.4 t Active Digital read out Misc.accessories www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m 3-axis digital read out horizontal and vertical milling spindle quill Technische Daten / technical details: Längsweg X / X-travel longitudinal 500 mm Querweg Y / Y-travel cross 400 mm Senkrechtweg Z / Z-travel vertical 400 mm Tischgröße / table size 800x460 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 50-2500 UpM /rpm Vorschubbereich / feed range 8-630 mm/min. Antriebsleistung Frässpindel / power capacity milling spindle 4,4 kW Gewicht der Maschine / weight 1500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTec ...

turning diameter: 380 mm turning length: 700 mm control: SIEMENS spindle turning speed - stepless: 2500 U/min tailstock quill taper MT: 4 weight: 1.5 t dimensions of the machine ca.: 2000x1400x1820 mmxmmxmm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m 3-axes digital read out horizontal and vertical milling spindle quill Technische Daten / technical details: Längsweg X / X-travel longitudinal 500 mm Querweg Y / Y-travel cross 400 mm Senkrechtweg Z / Z-travel vertical 400 mm Tischgröße / table size 800x460 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 50-2500 UpM /rpm Vorschubbereich / feed range 8-630 mm/min. Antriebsleistung Frässpindel / power capacity milling spindle 4,4 kW Gewicht der Maschine / weight 1500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTec ...

I am selling a stacking system HOMAG BARGSTEDT TBH22/D/25/12, built in 2001. Destacking system One-sided guide Spout also suitable for pallets. Postural head vacuum shoe system. Vacuum system (with pump) Automatic loading. Entry table motorized roller system Exit table on the floor with lifting mechanism motorized roller system Exit table front roller system Enters feed roller stazion for quilted material. Security fences fully complete ! Working capacity Approx. 8 cycles / min Available right away. Ready for use, possible to test. With CE certificate and full documentation.

turning length: 1000 mm turning diameter over bed: 356 mm turning diameter over slide rest: 220 mm turning dia. in gap: 506 mm length: 0 mm number of spindle speeds: 30 - 3000 U/min. spindle bore: 38,0 mm tailstock quill taper MT: MK 3 quill stroke: 115 mm bed width: 206 mm adjustment: Plan 180 mm spindle taper: DIN 55029, D1-4 total power requirement: 4,0 kW weight of the machine ca.: 1500 kg range L-W-H: 1850 x 1000 x 1300 mm New price ~ 13,500 euros Special price on request Lathe with precision ground and induction hardened bed. Very suitable for use in workshops and training centres. Furnishing: - Robust main lathe and spindle lathe with VARIO gear - NEWALL B60 digital display, front left - 3-jaw chuck Ø 160 mm, with spare jaws & chuck key - foldable lathe chuck protection - MULTIFIX steel holder with 3x inserts - folding steel holder protection - Infinitely variable speed adjustm ...

turning diameter over bed: 330 mm turning diameter over slide rest: 170 mm turning length: 800 mm centre height: 155 mm centre distance: 800 mm spindle bore: 38 mm spindle turning speed range: 24 - 2800 U/min spindle head: DIN 55022 Gr. 5 feeds - longitudinal: 0,026 - 1,253 mm/U feeds - cross: 0,013 - 0,628 mm/U dia. of leadscrew: 24 mm lead of leadscrew: 6 mm tailstock taper MT: 3 tailstock quill stroke: 110 mm total power requirement: 3 kW weight of the machine ca.: 800 kg dimensions of machine L x W x H: 1,88 x 0,87 x 1,32 m Accessories: 3-jaw chuck RÖHM 160 mmø, changing tool post TRIPAN with various inserts, collet fixture with various collets, solid steady, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
