profile projector used for sale

Qty. 1 Second-hand Electrostatic Multi Colour Powder Coating Production Line Mfc.: Gema Type: OptiFlex A2-14 Guns Built: 2013 OptiFlex A2 adjusts the air settings electronically by means of patented DVC System and monitors the production parameters continuously, resulting in a high quality coating Result. Work piece data – Aluminium Profiles Dimensions: 1800 x 400 x 6000 mm – H x W x L Conveyor speed: 2.0 m/min. One new Booth No. 2 (Mobile on rails) Magic Plus Booth” with cyclone recovery installed 2013, consisting of: Gema Electrostatic Powder Coating Equipment type OptiFlex A2 – 14 Guns With OptiFlex AS05 and OptiStar CG06 Gema Reciprocator System type ZA05-23 with carriage type XT10 for remote width positioning and outside cleaning Gema Control System type CM-30 Magic control including height recognition system Gema Quick Color change system Magic Plus with mu ...

see pdf attached

pdf attached

Technical data of the CS Sigma profile: Manufacturer: SSI Schäfer Type designation: CS 300-3,0 Included in delivery: 01x CS Sigma Profile, II Choice Material color: sendzimir galvanized Total length: approx. 2,550 mm CS-Sigma profile: approx. 300x75x15 mm Material thickness: approx. 3.00 mm

FOM INDUSTRIE profile machining center was built in 2009 by F.O.M. INDUSTRIE s.r.l. This machine, designed for precision machining of PVC profiles, is an excellent choice for businesses specialising in the manufacture of windows. It enables, among others, milling, cutting or making ventilation and holes for the handle. Window profiles are machined by means of various types of aggregates. The standard machine in this series has 14 aggregates, however, the machine in our offer has been equipped with additional milling and drilling aggregates and has a total of 18 of them. This solution significantly increases the machining capacity of the machine as well as the overall machining efficiency. The FOM INDUSTRIE PVC profile machining center is also extremely easy to operate. All machining parameters are programmed in the intuitive CNC control with graphic software. Technical specifications  ...

Technical data of the CS Sigma profile: Manufacturer: Stow Type: MSNSBG 350/2.0 S 350 GD Included in delivery: 01x CS Sigma profile, used Material colour: sendz. galvanized Total length: approx. 4,450 mm CS-Sigma profile: approx. 350 x 85 x 25 x 12 mm Material thickness: approx. 2.00 mm

Scissors for reinforcing steel or bars max 32mm

Profile steel shears

Finishing unit, modular unit, format processing unit, double-end tenoner, edge processing machine, scraper for edge processing machine -Manufacturer: Homag, profile scraper from edge banding machine BRANDT KM 36 / KM35 -Quantity: 1 piece available -Dimensions: 510/430/H570 mm -Weight: 62 kg

Rubber sealing profile, sealing plate, curing tool, seal, edge protection, solid rubber rectangular profile -Rubber sealing profile: with 2 grooves, 3 pieces -Length: 3 x 8450 mm / total 25.35 m -Cross-section: 50 x 55 mm -Groove width: 5 mm -Weight: 120 kg

Technical data of the CS Sigma profile: Manufacturer: Stow Type: MSNSBG 350/2.0 S 350 GD Included in delivery: 01x CS Sigma profile, used Material colour: sendz. galvanized Total length: approx. 5,500 mm CS-Sigma profile: approx. 350 x 85 x 25 x 12 mm Material thickness: approx. 2.00 mm

I - beam section - flat steel: 50 x 10 mm I-beam section - upend: 80 x 15 mm I-beam section - upend: 80 x 15 mm L-beam: 50 mm round material: 30,0 mm bar material dia. max.: 1 1/2 mm bar material - diameter: 30,0 mm weight: 185 kg range L-W-H: 670 x 530 x 1350 mm square material: 40 x 40 x 3 mm pipes: 60 x 2,0 mm total power requirement: 0,75 kW Equipment: • Base frame of the machine • Foot switch • Standard-rolls (divided) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control cabinet, distribution cabinet, control cabinet TS modular cabinet, profile door -Profile door KTS for: refrigerator -TS8 1200 x 2200 -Price: per piece -Number: 2 pieces -Dimensions: 2240/680/H280 mm -Weight: 66 kg

Ring bending machine, profile bending machine, three-roll bending machine, bending machine -Outer diameter: 200 mm -for: 35 mm pipe -Bearing seat: Ø 55 mm -Bore: Ø 49 mm -Quantity: 2 rolls available Price: complete -Dimensions: Ø 200 x 81 mm -Weight: 11 kg

Profile steel shear, profile shear, punch, punching machine, hole punch -Pressure force: 40 tons -Punching -scissors -cut -disengage -mechanical release -Foot switch: 1 -various stamps and dies -Dimensions: 800/1250/H1800 mm -Weight: 1112 kg

Technical data of the CS Sigma profile: Manufacturer: Stow Type: MSNSBG 350/2.0 S 350 GD Included in delivery: 01x CS Sigma profile, used Material colour: sendz. galvanized Total length: approx. 5,600 mm CS-Sigma profile: approx. 350 x 85 x 25 x 12 mm Material thickness: approx. 2.00 mm

Offer 22646 Hydraulic profile and bar steel shears with notching device and hole punch Specifications: - Flat steel scissors - Flat steel - 400 x 16 mm - or: 300 x 18 mm - Profile steel shears - L- and T-irons at 90° 130 x 12 mm - Square steel / round steel 40 / 40 mm - Notcheter - with square clinker for sheet metal up to approx. 13 mm - Latch depth approx. 70 mm - Latch width approx. 52 mm - Hole punch - Punching force approx. 60 t - Projection 400 mm - Stroke approx. 10 to 50 mm - perforated in steel up to Ø 31 in 15 mm - Material stop - div. 10 pcs punches + matrices - Drive 400 V / 5.5 kW - Dimensions W 1100 x H 2000 x D 1700 mm - Weight approx. 2100 kg

Hydr . Flat profile and bar steel shears with notching device and hole punching Specifications: - Flat steel shears cut up to 375 x 10 mm - 220 x 20 mm - Profile steel shears - cuts L-steel at 90° to 130 x 13 mm - Steel bar shears - cuts round steel up to 45 mm - Square steel up to 45 mm - Notching device - with square notching device 100 x 42 x 10 mm - Hole punch - punching force 600 KN - with stop table - Projection 300 mm - perforated in steel up to 28 mm Ø in 15 mm - or 34 mm Ø in 12 mm - manual length stop - Drive 400 V / 4 kW - Space requirement approx. W 600 x H 1550 x D 1500 mm - Weight approx. 1300 kg

Line for PVC profiles : 1.Extuder Single Theysohn AS 63mm PVC 2. Calibration table Greiner Genius Cal 2P/3.6 3. Theysohn REA32/1HJ-TECH belt lashing 4. saw Theysohn REA32/1HJ-TECH) price for all Line 23.000 Euro

MECAL MC302 GEOS-5 aluminium profile machining centre was built in 2014 in Italy. The machine, characterised by high structural rigidity, quality components and a longitudinal working area with a sliding workstation, is used for milling, drilling, threading and cutting profiles made of aluminium alloys, plastics and steel. Thanks to the sliding workstation, the MECAL machining centre can perform machining on a single work area as well as inside 2 separate work areas, resulting in a significant increase in speed and productivity of the manufacturing process. All 5 axes (X,Y,Z,A,C), driven by motors with digital systems, move on automatically lubricated precision guideways. The clamps holding the workpiece during machining are equipped with an independent power supply system which allows positioning and automatic repositioning of all of the clamps in a very short time. The MECAL GEOS-5  ...

Hinge, door hinge, folding hinge, angle profile -Angle profile: Material: Aluminum, 45 pieces -Dimensions/recess: see photos / technical drawing -Price/Fee: complete Dimensions: 70/60/H35 mm -Weight: 0.05 kg/pc.

Max. punching capacity: 600 kN Max. shear power: 800 kN Punches 27 mm holes in 16 mm steel Shears on the flat steel shears to 400 mm up to material thickness of 16 mm steel Hydraulic hold-down device on flat steel shears Further technical data on request With an assortment of punches and dies as desired Weight: approx. 2,000 kg

MEPAL ATLANTIS C3SR profile machining center was built in 2018 in Italy by MEPAL Italia s.r.l (RobTech). The machine is new, stocked after purchase and has never been in operation. MEPAL ATLANTIS C3SR is an advanced CNC machining center designed for precision machining of aluminium and PVC profiles from three sides. It is designed to perform such operations, i.e. drilling and milling of workpieces with a maximum wall thickness of 2.5 mm and lengths in excess of 3 metres. All these processes are performed fully automatically in three numerically controlled axes (X,Y,Z). Inside the large work area there is a rotary work table, which is pneumatically rotatable within the range of -90°, 0° and +90°. This solution allows workpieces to be machined from different sides without having to refit the workpiece. The spindle, driven by a powerful 4.5 kW motor, reaches a speed of as much as 1800 ...

Pressing tool, clamping pad, square profile, support profile, alignment pad -Square profile: clamping base, support profile, alignment base -Length: 503 mm -Number: 2x profile available -Price: per piece -Dimensions: 503/97/80 mm -Weight: 27.5 kg/pc.

Pressing tool, clamping pad, square profile, support profile, alignment pad -Square profile: clamping base, support profile, alignment base -Length: 515 mm -Number: 3x profile available -Price: per piece -Dimensions: 515/97/80 mm -Weight: 28.3 kg/pc.

Pressing tool, clamping pad, square profile, support profile, alignment pad -Square profile: clamping base, support profile, alignment base -Length: 492 mm -Number: 7x profile available -Price: per piece -Dimensions: 492/97/80 mm -Weight: 27 kg/pc.

Compressive force max.: 55 kN Projection: 175 mm Punching stroke adjustable: 0 - 28 mm Number of strokes at 15 mm stroke: 30 Adjustable notch stroke: 0 - 60 mm Hydraulic drive: 380 V, 3 kW Required space: 1170 x 620 x 1470 mm Weight: 930 kg

Mazak machining center mod. FH 480 Year 1995 X = 560 Y = 560 Z = 510 Cutting speed 32,000 mm./min 12,000 rpm CNC Mazatrol M Plus

ELUMATEC SBZ 140 profile machining center was manufactured in 2010 in Germany by elumatec AG. The machine is designed for the economical machining of aluminium profiles and thin-walled steel profiles with a maximum length of 7600 mm. It enables precise milling, drilling and threading of workpieces with high repeatability. With its capabilities, the ELUMATEC SBZ 140 is ideal for use in plants involved in, amongst others, the production of aluminium joinery and steel structures. The SBZ 140 profile machining centre is distinguished by its 4-axis machining unit, equipped with a high-performance, air-cooled milling spindle. It enables all machining operations to be performed at various angles within a range of -90° to +90°. The machining unit cooperates with an 8-position tool magazine, which automatically exchanges tools in accordance with the programmed sequence. The workpiece is held ...

ZENITH MACHINES HRBM 65 3-roll bending machine was built in 2020 in China. The machine is designed for the precision bending of steel tubes and profiles into arcs, circles and spirals with a constant radius. The bending process is performed using three driven rollers rotating at a maximum speed of 9,3 rpm. The hydraulic pressure enables precise positioning of the upper roller. Side positioning shafts stabilise the workpiece during operation, increasing process stability, bending precision and the range of operations that can be performed. Thanks to its robust design and reliable components, the ZENITH MACHINES HRBM 65 is an excellent addition to professional production plants and workshops. The total weight of the bending machine is 720 kg. It is possible to purchase 4 ROLOTOK roller conveyors, each 3 m long with a roller width of 600 mm, at an additional cost. The price of one convey ...

The scope of delivery includes: 01x Rectangular tube, used Profile dimensions: approx. 50 x 30 mm Material color: orange Total length: approx. 3,660 mm Center-center hole: approx. 3,630 mm Material thickness: approx. 1.50 mm Number of boreholes: 2 pcs. Drill holeØ: approx. 10 mm Weight / pcs.: 6,150 kg Your contacts in our company: Mr. Andre Evering Mr.: Mario Klöver Lord: Falk German General information about the item: This item is offered for pickup only. In addition, a desired transport or shipment of this article is with additional costs, which are charged separately depending on the place of delivery. or scope of delivery can be queried from us.

Specifications Type: KBLH 700 Dimensions (LxWxH): 1850 x 680 x 2050 mm Working height: 700 mm Cutting length: 510 mm Knife length: 520 mm Max. shear cross-section: 3500 mm Stroke of the scissors, infinitely variable: 0 – 45 Max. stroke number of scissors: 11 PMG knife for: L-steel 90°+45°/ T-steel 90° Required power : 8.5 kW Weight approx.: 2950kg

table diameter: 200 mm workpiece height: 100 mm number of wheels: 1 Control: Robot CNC total power requirement: 6 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 1,83 x 2,04 x 2,1 m Technical data - Grinding capacity : Ø 0.025 –12.7 [mm] - Bar diameter : Ø 1.0 –12.7 [mm] - Grinding length : W15 (option W20) - Z-axis : 35[mm] Resolution : 0.5 [µm] – X- axis : 25 [ mm] Resolution : 0.1µm – Y-axis : 286[mm] Resolution : 0.5µm – U- axis : 15 [mm] Resolution : 0.1µm Head Motor: 0.70 [kW] Rotation: 300 – 3000 [rpm] Grinding - Raw grinding : 1.5 [kW] Spindle : Ø 60 [mm] Grinding wheel diameter : Ø 200 [mm] Cutting speed : 30 m/sec. - Completion: 0.75 [kW] Spindle: Ø100 [mm] Grinding wheel diameter: Ø150 [mm] Cutting speed: adjustable - Dimensions (L x W x H): 1830 x 2040 x 2100 mm - Weight: approx. 1800 [kg] Accessories - Loading and unloading robots - F ...

Find more here - .ucymachines/ Contact us at - sales@ucymachines 1998ca. 7 t10.3 x 2.6 x 3.35 m

Bosch Rexroth aluminium profile workstation Bosch Rexroth aluminium profile Complete plastic glazing 4 cm worktop with a light grey melamine resin direct coating 190 x 90 cm Dimensions of the workplace WxDxH 195x93x220 cm Magnifier Magnifying Lamp 8062D2 More items new and used - you can find them in our shop! International shipping costs on request!

Imcar CPH80 Dia rolls: 245 mm Dia of die mandrel: 70 mm Motorpower: 4,9 kW Length : 1380 mm Depth: 1050 mm Height: 1330 mm Weight: 1,5 ton

Qty. 1 Second-hand aluminium profile lamination line Mfc.: S.I.M. PACK Srl Model: SIRIO PROFILI TA/200/2S Built: 2011 Stopped: 2026 Voltage: 400 V, 3 ph., 50 Hz The machine applies the protective film simultaneously on 2 flat surfaces of profiles with a max. width 200 mm and height 200 mm and the cut of the film between the profiles is automatic. The machine in made up of a strong electric welded iron tubular frame on which there are: One unit for the dragging of the film on the upper and lower surface composed by a vertical column bearing no. 2 opposed rubbered rollers. No.1 Pulling unit composed by no. 2 rollers position at the exit of the machine. No. 1 Automatic cutting activated by pneumatic cylinder with vertical movement. No. 2 Idle roller table 2.5 m long, with PVC covered rolls and alignmentlocator to get a correct Alignment of the material to be coat with the prot ...

Max. punching capacity: 600 kN Max. shear capacity: 1000 kN Punches 20 mm holes in 19 mm steel Shears on flat steel shears to 500 mm up to material thickness of 12 mm steel Further technical data on request With an assortment of stamps and dies as desired

Offer 23294 Specifications: - Flat steel shears - knife length 470 mm - for flat material 450 x 15 mm - or 300 x 20 mm - Sectional steel shears - L- steel at 90° 140 x 13 mm - at 45° 70 x 7 mm - T-steel at 90° 70 mm - Bar steel shears - round steel 50 mm - Square steel 42 mm - Notching device - rectangular notching 52 x 90 x 12 mm - Punch punch - punching force approx. 750 KN - - Infinitely variable stroke 0 - 70 mm - Perforates in steel up to 30 mm Ø in 20 mm - Projection 310 mm - Hydraulic drive 400 V / 7.5 kW - Space requirement approx. W 1600 x H 1850 x D 1400 mm - Weight approx. 2400 kg - With: - 2 E. foot switches for two separate workstations - Slewing ring

Max. punching force: 700 kN Projection: 510 mm Cuts on flat steel shears 500 x 18 mm Punches e.g. 30 mm diameter in 20 mm flat bars Quick-change device Assortment of tools is included in the price Weight: 3,000 kg

CNC – controlled profile and tube bending machine for demanding and precise bending work with hollow sections and tubes. With our machines, aluminium – steel / stainless steel – various plastics such as PVC window profiles (depending on the application) can be bent with repeatable accuracy, regardless of the material. Depending on the equipment, our machines can also be used for three-dimensional bending work. Our REPANDUS models can work both horizontally and vertically. The models of the REPANDUS series work with a fixed upper roller and two movable lower rollers – this means that the straight end piece is relatively short compared to machine concepts with fixed lower rollers. The machine body is made of vibration-absorbing cast steel Shaft diameter of upper and lower rollers Ø 70 mm Shafts made of special steel – hardened and ground Bending force 190 kN Maximu ...

ELB Perfect BD 15 PLC surface grinding machine, grinding area 1500 x 550 mm, grinding wheel 400 x 100 mm, electric perm magnetic clamping plate 1500 x 550 mm, automatic dresser with compensation, paper belt filter, the machine is overhauled, grinding spindle rebeared, guideways are scraped, meets the tolerance of a new machine. We are happy to take over the installation / training on site, as well as the subsequent service

SECOND-HAND PROFILE SHAPER AND SANDER BALESTRINI CP8/HSC - CE RULES - positions 1-2 milling units - positions 3-4 milling units - positions 5-6 sanding units - positions 7-8 sanding units - positions 9-10 trasversal sanding units - working length mm. 2500 - working height mm. 180 - n. 10 pneumatic locking cylinders - SN 0 133 H2 - CE rules (year 2001)

without pallet box; Auction-ID: A1-50476-209

Auction-ID: A1-50476-284

Auction-ID: A1-50476-290

Qty. 1 Second-hand profile forming production line – already in storage Mfc.: Incheon Industry Machine Co Model No.: 1250-RC Built: 2019 This line that continuously produces products weighing 30 kg or less using the roller forming Method - Forming line for deck plate use for building construction. State condition: Dismantled, Stock in warehouse Raw material: Cold rolled steel strip Strip width: 1250 mm Thickness: 0.5 – 1.2 mm Coil ID: 508 mm OD: 2000 mm Weight Max.: 15,000 kg Forming stands: 40 stands / 100 mm x 1250 mm space Mill reducer Worm reducer Mill Drive: 90 kW with reducer Line speed Max.: 12.5 m/min Deep for form Max.: 100 mm Electric voltage source: 220 V, 3 ph., 60 Hz

Punching force: 750 kN (punches e.g. 30 mm in 22 mm material), with search device via foot switch for punching Projection: 320 mm Cuts 450 x 15 mm or 300 x 20 mm on flat steel shears Support table on the punching side Two separate foot switches for the punching and shearing side, so that independent punching and shearing can be carried out Assortment of tools is included in the price

Max. workpiece height 100mm Max. workpiece width 1000mm Min. workpiece width 500mm Top unit 6 brushes Top/bottom adjustable unit Helicopter rotating system 2 types of brush rotation speeds Smooth adjustment of belt feed speed Belt feed 1.5kW 4kW motor Diameter of the exhaust port 180mm, 200mm

General Description CNC profile cutting and machining center manufactured by Schirmer Maschinen GmbH , model BAZ VU 90° . Designed for fully automated cutting and machining of PVC and aluminium window and door profiles. The machine forms part of an automated production line and is equipped with a Beckhoff PC-based CNC control system. Technical Details Manufacturer: Schirmer Maschinen GmbH Model: BAZ VU 90° Machine type: CNC profile cutting and machining center Year: 2020 Machine No.: 2344 900 Power supply: 400 V, 3-phase, 50 Hz Pneumatic supply: Max. 8 bar Beckhoff PC-based CNC control Touchscreen HMI Automatic profile infeed and outfeed roller conveyors Integrated cutting, drilling, milling and routing units CE marked Approximate machine weight: 4,000 kg Condition Very good used industrial condition. The machine appears complete and remains installed in a clean p ...
