precision used for sale

Description: Material: 20CrMnTi, Use: machining, Hardness: HRC 58-62 (150x175 mm, h 50 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 450 x 180 x 150 mm, weight approx.: 26 kg

Description: Material: 20CrMnTi, Use: machining, Hardness: HRC 58-62 (100x260 mm, h 45 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 360 x 140 x 140 mm, weight approx.: 20 kg

Description: Control: Siemens Sinumerik 840 D Travel paths: Z-axis: 220 mm X-axis: 300 mm Rapid traverse speed: 15 m/min Main spindle: Spindle hole: 26 mm C-axis (spindle, resolution): 0.01° Spindle speed: 100 - 8000 rpm Spindle power: 7 kW Rear spindle: Max. speed: 6000 rpm Power: 6 kW Voltage: 50 Hz 3x 400 Volt Total power required: 10 kW Incl. documentation weight approx.: 2,600 kg, Approx. Onsite Dimension. (l x w x h): 2,700 x 1,900 x 2,100 mm

Description: 1 x KERN CB 6 K 0.1 N, max. 6000 g 1 x ,SARTORIUS QC 64 IDE-S, max. 62 kg Approx. Onsite Dimension. (l x w x h): 800 x 600 x 700 mm, weight approx.: 25 kg

Description: Sturdy base with ground support surface, hardened and ground shaft. Stainless, anti-reflective chromed reading elements. Black reading scale for easy reading. Micrometric adjustment. The slightly raised edges of the sliding rod prevent the movement of the slide from damaging the graduation. The zero value and the scribing tip are aligned with the footprint of the socket (measuring range from '0'). Tracking measurements can thus be directly detected without calculation errors. Scoring point with hard metal coating. The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 1,320 x 400 x 190 mm, weight approx.: 23 kg

Description: Sturdy base with ground support surface, hardened and ground shaft. Stainless, anti-reflective chromed reading elements. Black reading scale for easy reading. Micrometric adjustment. The slightly raised edges of the sliding rod prevent the movement of the slide from damaging the graduation. The zero value and the scribing tip are aligned with the footprint of the socket (measuring range from '0'). Tracking measurements can thus be directly detected without calculation errors. Scoring point with hard metal coating. The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 1,320 x 400 x 190 mm, weight approx.: 23 kg

Description: Sturdy base with ground support surface, hardened and ground shaft. Stainless, anti-reflective chromed reading elements. Black reading scale for easy reading. Micrometric adjustment. The slightly raised edges of the sliding rod prevent the movement of the slide from damaging the graduation. The zero value and the scribing tip are aligned with the footprint of the socket (measuring range from '0'). Tracking measurements can thus be directly detected without calculation errors. Scoring point with hard metal coating. The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 745 x 350 x 145 mm, weight approx.: 7 kg

Description: Sturdy base with ground support surface, hardened and ground shaft. Stainless, anti-reflective chromed reading elements. Black reading scale for easy reading. Micrometric adjustment. The slightly raised edges of the sliding rod prevent the movement of the slide from damaging the graduation. The zero value and the scribing tip are aligned with the footprint of the socket (measuring range from '0'). Tracking measurements can thus be directly detected without calculation errors. Scoring point with hard metal coating. The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 1,320 x 400 x 190 mm, weight approx.: 23 kg

Description: Sturdy base with ground support surface, hardened and ground shaft. Stainless, anti-reflective chromed reading elements. Black reading scale for easy reading. Micrometric adjustment. The slightly raised edges of the sliding rod prevent the movement of the slide from damaging the graduation. The zero value and the scribing tip are aligned with the footprint of the socket (measuring range from '0'). Tracking measurements can thus be directly detected without calculation errors. Scoring point with hard metal coating. The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 745 x 350 x 145 mm, weight approx.: 7 kg

Description: Material: 20CrMnTi, Usage: machining, Hardness: HRC 58-62 (50x65mm, h 25 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 250 x 90 x 90 mm, weight approx.: 3 kg

Description: Material: 20CrMnTi, Usage: machining, Hardness: HRC 58-62 (50x65mm, h 25 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 250 x 90 x 90 mm, weight approx.: 3 kg

Description: Material: 20CrMnTi, Use: machining, Hardness: HRC 58-62 (80x100 mm, h 40 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 320 x 120 x 120 mm, weight approx.: 12 kg

Description: Material: 20CrMnTi, Use: machining, Hardness: HRC 58-62 (80x100 mm, h 40 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 320 x 120 x 120 mm, weight approx.: 12 kg

Description: Material: 20CrMnTi, Use: machining, Hardness: HRC 58-62 (80x100 mm, h 40 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 320 x 120 x 120 mm, weight approx.: 12 kg

Description: Material: 20CrMnTi, Use: machining, Hardness: HRC 58-62 (100x260 mm, h 45 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 360 x 140 x 140 mm, weight approx.: 20 kg

Description: Material: 20CrMnTi, Use: machining, Hardness: HRC 58-62 (150x175 mm, h 50 mm) The item that is delivered is NOT the one shown in the pictures, but an equal one Approx. Onsite Dimension. (l x w x h): 450 x 180 x 150 mm, weight approx.: 26 kg

width of jaws: 150 mm, distance: 270 mm, Approx. Onsite Dimension. (l x w x h): 570 x 200 x 150 mm, weight approx.: 25 kg

turning diameter over bed:100 mm turning diameter over slide rest:70 mm turning length:80 mm total power requirement:1,0 kW weight of the machine ca.:0,5 t dimensions of the machine ca.:0,7 x 0,6 x 1,2 m facing lathe with manual feed, various accessories

KENYO VS80160 5-axis Machining center with CE Producer: Nanjing Kenyo Precision Machine Manufacture Co., Ltd YOM 2015 Simultaneously 5 axes Total Installed Capacity 22.4 kW 5-Axis vertical Milling machine for blanks up to 1000-1500kg Stroke X/Y/Z- 1600/800/800 mm Working table size 800x1800 mm Diameter of NC swivel table axle C 630 mm Rotating mass clamping force 4000 Nm Spindle clamping force: ≥ 2000 Nm Maximum mass load 2000 kg Spindle diameter 170 mm Spindle rotation angle- ± 110 Degree Tool Store Type BT40 ISO Tool magazine 24 pcs Maximum spindle rotation speed 10.000 rpm Spindle power 15 kW Ball-Screw pair HIWIN Spindle Hesheng Ball Bearings NSK Positioning accuracy ≤ X/Y/Z: 0.015 mm, C: 0.002 degree, B: 0.002 degree Repeat accuracy ≤ X/Y/Z- 0.01 mm, C:0.0015 Degree, B:0.0015 Degree Quick move: ≥ 10000 mm/min Milling speed: ≥ 1 to 8000 mm/min OC ...

automatic divider The divider RheoPan Precision is the basis of RheoPan line. It is very precise in weight thanks to a system of double weighing of the dough and the automatic adjustment of settings. Its stress-free division system allows it to handle both highly hydrated and fermented doughs, as well as hard doughs. It can thus produce a very wide variety of breads depending on the modules installed.

equipped with KNOLL fitter installation, type: KF 150/500 ( 2014)

X-travel: 189,2mm, y-travel: 101mm, z-travel: 638,3mm, max. rotational speed: 5000/min, swing over bed: 519mm, controls: FANUC Series 331i-MODEL A, connected load: 81.5kVA, length: 2991mm, width: 2289mm, height: 2089mm, weight: 6.57t, operational hours counter: 11.873h, including documentation and accessories.

General SKU401S1130 LocationBarneveld MakeEmerson network power TypeHPF12U302A3P10020 Mach.No.10940780001 Main Features Heating (medium)Gas Temp.18 °C Specified Features - Temperature control unit MaterialMild steel Temperating machinecheck With coolingcheck Temperature18-27°C. With temperature controllercheck With controlcheck Information Year of construction2012 With switchcheck With switchgearcheck( as is) CEcheck Floorspace0,9x0,75 m Total height2,05 m Weight300 kg Extra Specificationsthis machine is used to cool airTemperature control unitsLiebert HPFHeat exchangers > Temperature control unitsBrand > Liebert HPF What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. Please visit us in  ...

00790-2 R&D department for Lithium-ion battery manufacturing will be COMPLETELY dissolved The value of these fixed assets amounted to approximately 7.5 million euros at the time of new acquisition. Manufacturer: Werner Mathis AG Manufacturer: Eirich Gustav GmbH (see also List1 page 6 EL5 Profi-Plus Manufacturer: Robust Habicht Manufacturer: Digatron Manufacturer: Coherent Rofin B.V. Manufacturer: Keyence Inventory name Filling station: Glovebox Braun with scale, cooling unit, etc. Exhaust air scrubber FRIDURIT Neutralization plant FRIATEC Rena Technologies GmbH Lauda Dr. R. Wobser GmbH & Co. KG AFA Glass furnace Ball fall viscometer Solder fume hood Profilometer Battery test system BaSyTec CTS 32 channels CTS 1666 Battery test system BaSyTec CTS 32 channels CTS 1667 Battery test system BaSyTec CTS 32 channels CTS 1668 Vacuum pump Measuring  ...

german / English High-precision laser welding system fully automatic Laser 1 according to DIN EN 60825-1 Fully functional Well suited for medical technology, optics, precision precision engineering Granite bed Axes: X-920mm / Y-100mm /Z-100mm C-rotation axis - Föhrenbach precision rotary table B-Schenkachse IPG YLR-Series Laser 150Watt pulsed fiber laser 1070 nm Pilot laser red 633nm Camera Automatic door Drawer for vertical workpiece pick-up Control Fanuc 0i-MD Connection for extraction and shielding gas Dimensions: LxWxH 2400 x 1450 x 2200 mm Weight 2000 kg Connection 3 x 400 C / 32 A English: high precision laser welding machine fully automatic Laser 1 according to DIN EN 60825-1 Fully functional Well suited for medical technology, optics, precision engineering Granite bed Axes: X-920mm / Y-100mm /Z-100mm C-rotary  ...

Holzkraft Precision Wood Band Saw HBS 533 SET Product name: Precision wood band saw HBS 533 SET Manufacturer: Holzkraft Item number: 5155303 SET Year of construction: 01/2022 Condition: As good as new technical details: • Dimensions work table (L x W x H): 535 mm x 535 mm x 945 mm • Saw table inclination: -10° to +45° • 2 x suction nozzles • Diameter suction nozzle: 2 x 120 mm • Working table length max.: 685 mm • Work table widening length: 535 mm • Work table widening width: 150 mm • Cutting height max. 90°: 270 mm • Cutting width max. with stop: 474 mm • Cutting width max. without stop: 514 mm • Band saw blade speeds: 850/430 m/min • Band saw length: 3,865 mm • Band saw guide: precision guide at the top and bottom • Weight: approx. 163 kg • incl. band saw set, length 3865 mm, 3 pieces - 1x band saw blade wood 3865 x 10 x 0.5  ...

:FB-160 spindle diameter:160 mm x-travel:4000/6000/8000/10000/12000/14000/16000 mm y-travel:2000/2500/3000/3500/4000 mm z-axis:1200 mm w-axis:700 mm spindle cone:50 SK/BT spindle speed max.:3000 U/min spindle drive:37/51 kW feeds:X/Y/Z/W: 10 / 10 / 10 / 8 / 5 m/min rapid speed:X/Y/Z/W: 20 / 20 / 20 / 10 / 5 m/min max. torque on the spindle:3.300 Nm cross section of ram:460x520 mm table load:30 t table-size:2500x2500 mm table travel:1500 mm weight of the machine ca.:FBM-160 mit X=4m: 80 t positioning accuracy:0.032/1000 mm repeating accuracy:0.018/1000 mm CNC controller:Siemens/Fanuc/Heidenhain CNC controls from:Siemens/Fanuc/Heidenhain Factory-new CNC controlled panel drilling machine with CNC control from Siemens / Fanuc / Heidenhain. All essential components from well-known manufacturers such as Siemens, SKF, FAG, Heidenhain, Igus and many more. Newly developed FB series Convenient fo ...

TECHNICAL DATA SHEET CNC – Travelling column milling machine Make PARPAS Type SHARK One Control HEIDENHAIN iTNC 530 HSCI Year of construction 2016 Travel Longitudinal movement (X-axis) 3,500 mm Transverse movement (Y-axis) 1,083 mm Vertical movement (Z-axis) 1,074 mm Clamping table Clamping surface 4,000 x 1,000 mm Threaded holes with fitting seat Feeds X-, Y- and Z-axis, infinitely variable 2 - 30,000 mm/min. Rapid traverses in X / Y / Z 30 m/min feed force of the axes 10,000 N 2-axis milling head 2-axis milling head TUB-E92 with drive viaTorque motors for 5-axis simultaneous machining Power at 100 % ED 29 kW Speed range, infinitely variable 0-18,000 min-1 torque 92 Nm Rotational speed axis A/C 60 min-1 Tool holder HSK 63A – DIN 69893 Clamping force A-, C-axis 2,300/4,000 Nm Automatic tool changer ATC Tool stations 30 places  ...

x-travel: 3500 mm y-travel: 1083 mm z-travel: 1074 mm control: HEIDENHAIN iTNC 530 HSCI clamping table: - surface area: 4.000 x 1.000 mm Thread bore with fitting: - Feeds: - X-, Y- and Z-axis, stepless: 2 - 30.000 mm/min rapid travel x/y/z: 30 m/min Max. feed force of axis: 10.000 N 2-axis Milling Head: - 2-axis milling head TUB-E92 with power on: - Torque-Motors for 5-axis-simultaneos processing: - capacity at 100% load: 29 kW Speed stepless: 2- 30.000 max. torque: 92 Nm Max. torque: 60 min-1 tool taper: HSK 62A-DIN 69893 automatic tool changer ATC: - Tool places: 30 diameter of tools max.: 90 mm workpiece length: 320 mm weight of tools max.: 8 kg changing positions: vertikal electrical supply data: - capacity: 120 A voltage: 400 V operating frequency: 50 Hz total power requirement: 29 kW weight of the machine ca.: 28 t dimensions of the machine ca.: 8,3 x 6,7 x 3,6 m Guides, drive and  ...

Used Cimec America 6 1 1 DPS bottling line year 2018 Introduction of the Cimec America 9 1 1 Bottling Line The used bottling line Cimec America 6 1 1 DPS from the year 2018 stands out as an advanced solution for the beverage industry Cimec America DPS 6 6 1C Monoblock Precision and Reliability At the core of this line lies the Cimec America DPS 6 6 1C monoblock Crafted and engineered in 2018 this monoblock offers a bottling speed of 900 bottles per hour With a standard longneck format of 0 33 L it ensures a consistent and reliable production flow Equipped with safety features and manuals available it ensures smooth operation and easy maintenance Currently disassembled it awaits installation for immediate use Rinser Efficiency in Cleaning The rinser an integral part of the line boasts 6 grippers ensuring thorough cleaning of bottles before filling Consequently each bottle is primed for fi ...

Two identical Keyence measuring devices are available. Image sensor: 1inch 6.6 megapixel CMOS, lens: Double telecentric lens. Wide field diameter/length: 100mm/200mm, High precision diameter/length: 25mm/125mm. Repeatability: Without stage movement: +/-1µm(wide field), +/-0.5µm(high precision), with stage movement: +/-2µm(wide field), +/-1.5µm(high precision). Measuring accuracy (+/-2 sigma): Without binding: +/-5µm(wide field), +/-2µm(high precision), with binding: +/- (7+0.02L)µm(wide field), +/-(4 +0.02L)µm(high precision).

GeneralTurning-milling centre; Control: Fanuc 31iB5 CharacteristicsSwing- Ø, max.1070 mmDrive power milling spindle22 kWDrive power second spindle22 kWDrive power main spindle22 kWNumber of Toolmagazine positions50 Speed max.8000 rpmSlewability of B-Axis1 degreeMovements X / Z / Y1040/+-330/3150 mmMilling spindle upper side1 Input precision of C-axis on Counterspindle0,0001 degreeBar diametre164 mmSpindle speed 2nd Spindle max.1500 rpmInput precision of C-axis on Mainspindle0,0001 degreeBar diametre164 mmSpeed max.1500 rpmMax. Turning Length3076 mmMax machining diameter1070 mmWeight approx.46000 KgTool spindle full indexing specificationsErhöhung der mögl. Indexierung der B-Achse auf 0,0001º Einrichtung zur Positionierung der B-Achse mit einem minimalen Winkel von 0,0001º anstelle der Standardausführung mit 1º, einschließlich der Option Direktes Wegmesssystem in der B-Achse derSp ...

grinding length: 1.000 mm grinding width: 600 mm workpiece height: 400 mm Control: SINUMERK 840 D Grinding Area: : grinding range: max. 1.000 x 600 mm travel cross (z-axis): 540 mm distance table surface - grinding spindle centre: max. 600 mm Travel vertical (Y-axis): 500 mm Max. working height on new grinding wheel: 400 mm workpiece table: : Electro permanent magnetic plate: 800 x 500 mm pole pitch: 18 mm clamping force in 8 levels: - Table drive (X-axis): : Incremental encoder in the longitudinal axis X axi: - table speeds: 2-35.000 mm/min Electromechanical longitudinal movement: - by means of digital servo motor,: - toothed belt and ball screw: - Preloaded precision rolling guide size 35: - Central grease lubrication: - Automatic vertical feed (Y-axis): : min. feed size: 0,001 mm measuring system: Galsmaßstab Max. distance spindle centre - table: 700 Grinding head vertical: 550 mm El ...

FU 1600 SERVO 1600x500 Console Metal Milling Machine, Industrial Universal Multi-Purpose Cantilever Drilling Milling Machine FU 1600 SERVO 1600x500 Console Metal Milling Machine, Industrial Universal Multi-Purpose Cantilever Drilling Milling Machine Professional metal milling machine FU 1600 SERVO - available from stock! We present to you a professional, versatile, multi-purpose metal milling machine FU 1600 SERVO. The universal, industrial milling machine FU 1600 SERVO is a large, solid and stable machine, which, thanks to its precision and reliability, is designed for professional metalworking in both large and medium-sized enterprises, and thus satisfies even the most demanding customers. The professional FU 1600 Servo milling machine meets all safety and quality requirements. Brand: VIBER-SYSTEM Model: FU 1600 SERVO Table size: 1600x500mm Table load: up to 1800 kg Nu ...

Description/name of the machine: Console drilling and milling machine for metal Manufacturer: VIBER-SYSTEM Model: FU 1600 SERVO Year of production: 2023 Condition: New FU 1600 SERVO 1600x500 Console Metal Milling Machine, Industrial Universal Multi-Purpose Cantilever Drilling Milling Machine Professional metal milling machine FU 1600 SERVO - available from stock! We present to you a professional, versatile, multi-purpose metal milling machine FU 1600 SERVO. The universal, industrial milling machine FU 1600 SERVO is a large, solid and stable machine, which, thanks to its precision and reliability, is designed for professional metalworking in both large and medium-sized enterprises, and thus satisfies even the most demanding customers. The professional FU 1600 Servo milling machine meets all safety and quality requirements. Brand: VIBER-SYSTEM Model: FU 1600 SERVO Table  ...

Used rotary adhesive labeling machine PE Universal 16T up to 6000 bph In the bottling industry the efficiency and precision that the Used Adhesive Rotary Labeler PE Universal 16T brings to the production line are paramount Introduced by P E Labellers this rotary adhesive labeling machine known by its model number UNIVERSAL 16T 1120 4S 4E was launched in 2005 and has since established its reliability and performance consistency notably handling up to 6000 bottles per hour bph Sophisticated Design Capacity Constructed for glass containers particularly with formats supporting 1 0 L the robust design reflects its capacity to sustain high volume production workflows With its 16 plates functionality the rotary adhesive labeling machine ensures uniform application and distribution of work a technical detail that resonates well with experts seeking minimal downtime and maximum throughput The mac ...

In a highly competitive and ever evolving sector such as bottling and packaging having high quality equipment is crucial to ensuring efficiency and precision One of the bottling lines that has proven to offer these qualities is the complete Doypack pouches line with a capacity of 600 kg h In addition this machine could be described as approximately brand new as it has been used for only 1 000 hours to produce 5 million pouches With an operating speed of 600 Kg h this line is optimized for pouch containers and has a format capacity of 100g This makes it ideal for a wide range of products including dairy products juices ready to drink creams and sauces One of its distinctive features is the weight based filling type thus ensuring that each bag contains the exact amount of product The efficiency of the line is further enhanced by key components from renowned manufacturers Tetra Pak Contherm ...

Features: X = 2500 mm Y = 1000 mm Z = 1200 mm (vertical) Automatic platform indexed degree / degree C + - 180 ° and hydraulic locking. TBR automatic head Half body 45 ° A 120 indexed positions (3rd) Spindle ISO 50, Power 20 KW, RPM 10 - 4000g / . Automatic electric range change. 30000 g / electrospindle applicable to the head, for finishes. Axis feeds 15,000 mm / Transmission: X axis, precision ball screw. Transmission: Y axis, precision ball screw. Transmission: Z axis, vertical, precision ball recirculation .Vertical axis with cylinder and accumulator hydraulic balancing. X, Y, Z axis measuring systems Heidenhain precision lines CNC TNC 430 Heidenhain DIGITAL. Remote control panel SIEMENS Digital Brush-less Axis Feed Motors and Digital Drives Double Chip Conveyors. Machine base in cast iron. CE marking.

Control : Siemens SINUMERIK 840C • Spindle Taper: SK 40 • Magazine: 32 sets • Atc: UMBRELLA TYPE • Table Size: 400 mm x 400 mm • Pallet Changer: Available: Double Pallet • Travel X: 500 mm • Travel H: 500 mm • Travel Z: 500 mm • Table: B Axis: 0.001 Degree (Precision Rotating) • Power Shaft Motor: 35 KW • Spindle speed: 18000 rpm • Cooling through Shaft: Available • Chip conveyor: Available this extra information is standard for this model. Please always double-check the details during a visit The Deckel Maho 50 H is a precision machining center renowned for its exceptional performance and versatility. Manufactured in 2004, this horizontal machining center is equipped with advanced features and capabilities to meet the demanding requirements of modern machining operations. Controlled by the Siemens SINUMERIK 840C system, the Deckel Maho  ...

YEAR – 2001 CONTROL – FANUC 18i-M TABLE SIZE – 840 x 420 mm TRAVLERS – X: 600 mm Y: 410 mm Z: 520 mm SPINDLE – BT 40 SPINDLE SPEEDS – 0-8000 rpm SPINDLE MOTOR – 11.5 Kw RAPID FEED RATED – X/Y AXES 40m/min RAPID FEED RATE – Z AXES 20m/min MAXIMUM TABLE LOAD – 500 KG ATC – 22 STATIONS this extra information is standard for this model. Please always double-check the details during a visit The Bridgeport VMC 600 XP, introduced in 2001, stands as a pinnacle of vertical machining centers, engineered to deliver exceptional precision and performance in metalworking operations. Renowned for its reliability and versatility, this model is a testament to Bridgeports legacy of excellence in machining technology. Equipped with a powerful spindle and advanced CNC controls, the VMC 600 XP offers high-speed and high-precision machining capabili ...

grinding length: 1.000 mm grinding width: 600 mm workpiece height: 400 mm control: SINUMERK 840 D Grinding Area: : grinding range: max. 1.000 x 600 mm travel cross (z-axis): 540 mm distance table surface - grinding spindle centre: max. 600 mm Travel vertical (Y-axis): 500 mm Max. working height on new grinding wheel: 400 mm workpiece table: : Electro permanent magnetic plate: 800 x 500 mm pole pitch: 18 mm clamping force in 8 levels: - Table drive (X-axis): : Incremental encoder in the longitudinal axis X axi: - table speeds: 2-35.000 mm/min Electromechanical longitudinal movement: - by means of digital servo motor,: - toothed belt and ball screw: - Preloaded precision rolling guide size 35: - Central grease lubrication: - Automatic vertical feed (Y-axis): : min. feed size: 0,001 mm measuring system: Galsmaßstab Max. distance spindle centre - table: 700 Grinding head vertical: 550 mm El ...

internal diameter:250 mm swing diameter:455 mm workpiece length - max.:1200 mm table rotating:-4/+8 ° table speeds:0-4000 mm/min max. workpiece weight:80 kg workhead - center taper:5 MK Rotation speed of workhead :0 - 400 1/min workhead motor:4 kw 3-jaw chuck:250 (selbstschließend) mm grinding motor:4 kW coolant pump:2,2 kW Weight approx.:2,4 t machine dimensions:3200 x 2100 mm CNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mm clamping chuck:250 (selbstschließend), 1 Satz harte Backen, 1 Satz weiche Backen, 1 Satz Innen mm frequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:RPM 28.000, diam. 60 mm. Min. diam. cap. 25 mm. x Bohrung 50 mm, Max. diam. cap. 100 mm. x Bohrung 115 mm . internal grinding spindle: ...

internal diameter:300 mm swing diameter:300/350 mm workpiece length - max.:2300 mm table rotating:-2/+6 ° table speeds:0-4000 mm/min max. workpiece weight:400 (fliegend, 150mm von der Spindelnase) kg workhead - center taper:6 MK Rotation speed of workhead :0 - 400 1/min workhead motor:4 kw 3-jaw chuck:250 (selbstschließend) mm grinding motor:11 kW coolant pump:2,2 kW CNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mm clamping chuck:350 (selbst zentrierend) mm frequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:auf Anfrage internal grinding spindle:auf Anfrage fixed steady rests:10-100 mm, 100-170 mm PERFORMANCE AND PRECISION DEGREE Robbi grinding machines are according to the international precision normes ...

Specifications / Technical Data S-1400/T CNC-Router and CNC-Engraver / Engraving Machine (Attention: Pictures are showing the type with trapezium spindles, thats the only different to the t-series ) With the purchase of the T-variation of High-Z CNC-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T cnc-routers are conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T cnc-machines achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this 3D-cnc-machine you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on ...

Specifications / Technical Data S-1000/T CNC-Router / CNC-Engraver With the purchase of the T-variation of High-Z CNC-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T CNC-engraver achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machine you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This cnc-router series is usable in the industrial field as well as for works like engraving, milling, dr ...

Specifications / Technical Data S-720/T CNC-Engraving-Machine / Milling machine / CNC-Router With the purchase of the T-variation of High-Z CNC-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T 3D-cnc-engraver was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T cnc milling machines achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machines you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This cnc-machine series is usable in the industrial ...

Specifications / Technical Data S-400/T CNC-Portal-Router / CNC-Engraving machine with TÜV certification With the purchase of the T-variation of High-Z cnc-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T cnc-routers was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T 3D-cnc-engravers achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machines you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This 3D-milling-machine series is usable in the ...

Specifications / Technical Data S-400/T CNC-Portal-Router / CNC-Engraving machine Grabite marble soapstione slate engraving photo engraving, milling .. With the purchase of the T-variation of High-Z cnc-router you get a proven technology with a certain icing of the cake. High-Z/T cnc-routers was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T 3D-cnc-engravers achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machines you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This 3D-milling-machi ...

Specifications / Technical Data S-720/T CNC-Engraving-Machine / Milling machine / CNC-Router With the purchase of the T-variation of High-Z CNC-router you get a proven technology with a certain icing of the cake in german TÜV-certified quality. High-Z/T 3D-cnc-engraver was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T cnc milling machines achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machines you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This cnc-machine series is usable in the indus ...

M. No.: 3284 Equipment / Additional information: (min.) material thickness: 0.65 mm (max.) material thickness: 2 mm Technical Data: Width of film, max./min. 450/350 mm Forming area max. 430 x 160 mm Drawing depth max. negative/positive 6/20 mm (on request 22 mm negative) Top heater max. 10,15 kW Driving motors 3,0 kW Total connected load at 100 % duty cycle 12,7 kW Working air pressure 6 bar Air consumption (dependent on product) max. 1250 I/min Rate of water flow max. 1,0 m3/h COMPACT AND ROBUST - giving continuous high output. Easy and ergonomical operation (e.g. take- off height 1300 mm). QUICKLY CHANGEOVER - from 30° to 90° foil feed giving maximum material utilisation for both square and round lids. Heater changeover problem-free. PRECISION - The accuracy of the form table movement is guaranteed by linear guide bearings and hardened rods. The safe ...
