portal used for sale

A Unisign CNC 5-axis large-format portal milling machine is available. Portal clearance height: 1200mm, tool stations: 35/53, tool interface: SK50, travel X/Y/Z: 10000mm/2000mm/800mm, table dimensions X/Y: 11750mm/1670mm, max. table load: 2500kp/m², max. table-to-spindle nose distance: 1200mm, main spindle power: 26kW, spindle speed: 6000rpm, feed rate: 24m/min, rapid traverse: 24m/min. Machine dimensions X/Y/Z: approx. 14000mm/5800mm/4000mm, weight: approx. 45t, control: Siemens Sinumerik 840C. Including automatic angular milling head coupling and decoupling, spindle orientation system, rigid tapping, through-spindle coolant, workpiece probing system and two-station pendulum operation. Documentation available. An on-site inspection is possible.

Offered for sale is a WaldrichSiegen CNC portal milling machine for horizontal and vertical milling as well as drilling of large workpieces. Table travel: 14000mm, crossrail saddle travel: 4500mm, crossrail travel: 4000mm, quill travel: 450mm, positioning accuracy of table/crossrail saddle/crossrail/quill: 0.05mm, distance between columns: 4545mm, distance from table to spindle: 4000mm, table size/clamping surface X/Y: 14000mm/4350mm, main spindle motor power: 125kW, main spindle tool interface: ISO SK60, max. table load: 200t, max. point load: 10000kg, control: Siemens 840D, measuring systems: Heidenhain, axis drives: Siemens/Dornhoff. Including an angle-adjustable universal milling head, angle milling heads with installation heights of 800mm/850mm/1400mm, a 1400mm work spindle extension, adapter plates for the work spindle with 400mm/220mm and chip conveyors on the left/right below flo ...

x-travel: 3000 mm y-travel: 4000 mm z-travel: 1500 mm Control: Heidenhain TNC 430 M total power requirement: 120 kVA weight of the machine ca.: 83,2 t dimensions of the machine ca.: m 3/5 axes CNC portal milling machine with integrated C-axis and changeable milling heads. The machine had a purchase price of € 1.4 million in 2002. An inspection in the sellers plant under power is possible after previous appointment. Condition: The machine was overhauled in 2018, costs of over € 100.000,-. - Drives of the X-axis renewed - New hydraulic power unit - Complete electrical wiring renewed - Spindle cooling unit new - 2 pieces longitudinal conveyors new - Coolant pump new - Cover complete X-axis new - Bellows Y-axis new - Exchange measuring ruler X-axis - Fork head spindle bearing new Belleville spring assembly new Drive motor A-axis new Spindle cone ground - Overhaul milling gear (2020) Work ...

x-travel: 2400 mm y-travel: 1500 mm z-travel: 810 mm Control: Heidenhain iTNC530 total power requirement: kW weight of the machine ca.: 7.8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-axis: 10.100 (2x 5.000) mm y-axis: 3.000 mm z-axis: 1.500 mm Control: Sinumerik 840 D Siemens distance between columns: max. 3.000 mm passage: max. 1.950 mm distance spindle center to table: max. 1.800 mm distance spindle nose and table: 1.350 / 1.500 mm Main spindle:: type: P 8005020/00-4 turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 20 kW max. Torque: 48 Nm tool taper: HSK-A63 DIN 69063 Spindle Extension: 450 mm swivellable: B: +110° / -10 ° rotatable: C: +/- 200 ° Main spindle:: type: P 8002320/00-4 turning speed range - main spindle: 20 - 5.000 min/-1 power capacity - main spindel: 40 kW max. Torque: 1.100 Nm tool taper: HSK-A100 DIN 69063 Spindle Extension: 300 mm swivellable: B: +110° / -10 ° rotatable: C: +/- 200 ° work table:: table surface area: 4.000 x 2.200 (2x) mm max. table load: 12 / 20 t height over floor: 700 mm number of ...

WALDRICH COBURG 20-10 FP 280 ist ein Portalfräswerk, ausgelegt für hochpräzise Bearbeitung, große Genauigkeit und Zuverlässigkeit. Tisch 8000×2800 mm, 11 T-Nuten 36H8 (250 mm Abstand); Verfahrwege X 9000 mm, Y 2950 mm, Z 1250 mm, W 2200 mm; Durchgang 3200 mm; max. Abstand Tisch-Spindel 2806 mm; Tischbelastung 64000 kg. Spindelaufnahme 60 ISO, 16 Stufen 20–600 t/min; Spindelmotor 100 kW, Drehmoment 13000 Nm; Vorschübe X/Y 5–3000 mm/min, Z 5–2000 mm/min, W 5–750 mm/min; Anschluss 3x 380 V 50 Hz; Abmessungen ca. 21000×7800×6622 mm. Optionale Ausstattung: 90° Aufnahme, schmale 90° Aufnahme, vertikale Verlängerung, kippbarer Aufsatz. Eignet sich für enge Toleranzen; typisch in Automotive, Luftfahrt, Werkzeugmaschinenbau und schwerer Industrie. Technische Daten ohne Gewähr

FPT DINO ist ein Portal Fräswerk, ausgelegt für hohe Präzision, exakte Bearbeitung und zuverlässigen Dauerbetrieb. Gesamt 5 Achsen, Verfahrwege X 2800 mm, Y 800 mm, Z 1600 mm. Spindelaufnahme HSK 63, stufenlos regelbar von 0 bis 18.000 t/min. Anschluss 50 Hz, 3x 380 V; installierte Leistung 68,7 kW. Abmessungen ca. L 10.500 mm × B 3.800 mm × H 4.600 mm. Ermöglicht enge Toleranzen; typische Einsatzbereiche: Automotive, Luftfahrt, Werkzeugbau, Medizintechnik, Feinuhrmacherei. Technische Daten ohne Gewähr

FOREST-LINE SERAMILL V3 270 2T ist ein Portal Fräswerk für hochpräzise Bearbeitungen, hohe Genauigkeit und Prozesszuverlässigkeit. Technische Kapazitäten: 2 Tische (Längen 3000 mm und 4000 mm, Breite 2000 mm), X-Achse 5000 mm (bei 1 Tisch), Y 3400 mm, Z 1250 mm, Achsen A ±135°/2.5° und C 360°/2.5°; Durchgang zwischen Ständern 2700 mm, max. Werkstückgewicht auf Tisch 10.000 kg. Hauptdaten: Spindelaufnahme SK50, Drehzahlen 10–6000 t/min, Spindelmotor 31 kW, Drehmoment 430 Nm, Gesamtleistungsbedarf 90 kVA; Vorschübe Achsen 1–30.000 mm/min; Eilgang X 30’000 m/min, Y 40’000 m/min, Z 30’000 m/min; Anschluss 3x 400 V 50 Hz. Ausstattung: Werkzeugmagazin 120 Plätze, Werkzeughalter 700 pce, automatische Werkzeugvermessung BLUM, Werkstücktaster M&H. Erreicht enge Toleranzen; geeignet für Automotive, Luft- und Raumfahrt, Werkzeugmaschinenbau, Medizintechnik und Uhrenindust ...

x-travel: 3500 mm y-travel: 2500 mm z-travel: 1000 mm Control: HEIDENHAIN iTNC-530 table-size: 4.500 x 1.500 mm distance between columns: 2300 mm rapid travel x/y/z: 15/12.000 mm/min feeds: 5.000 mm/min tool taper: ISO 50 number of spindle speeds: 5000 U/min/rpm Spindle power: 30 kW table weight: 10 t handwheel: HR- 410 weight of the machine ca.: 31 t dimensions of the machine ca.: 11 x 3,44 x 4,9 m - CNC control Heidenhain iTNC 530 - Tool changer 30-fold (ISO 50) - Milling head CH -45 - Coolant through spindle - Chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Vision Wide VF4000 portal milling machine for sale. 2-axis milling head (1 degree C-axis and 1 degree B-axis) with position determination Encoder SK50 VTEC VF4000 Dimensions X-axis 4200 Y-axis 2300 Z-Axis 1020 Tool magazine 40WZ Control Siemens 840D SL

HNK HPM Double Column 5-Face Machining Center Year: 2011 CNC: Fanuc 31i-MA Status: Under power Main specifications: X travel: 10,250 mm Y travel: 6,400 mm Z travel: 800 mm W travel: 2,000 mm Table: 4,000 × 10,300 mm Work area: 4,000 × 10,000 mm Maximum load: 50,000 kg Between columns: 5,300 mm Height clearance: 2,600 mm Spindle: 5–6,000 rpm Spindle power: 22/25 kW Maximum torque: 600 Nm Ram: 380 × 380 mm Tool shank: BT50 ATC: 60 tools Scales on X/Y/Z/W CTS Rigid tapping Right-angle head Extension head 2 chip conveyors + chip bucket This is a very large-capacity HNK machine designed for heavy and oversized workpieces, with 5-face machining capability and a maximum table load of 50 tons. The machine is currently under power and available for inspection.

KEKEISEN PFW-T 4000/12 portal milling machine in a heavy, rigid design for machining large and heavy workpieces. Travel paths of 4,000 x 2,700 x 1,200 mm and a large worktable of approximately 4,000 x 1,800 mm with a table load capacity of 10,000 kg enable the machining of large-volume components. The machine is equipped with a universal milling head with 2 swivel axes and 5 - 1 degree steps NC controlled - adjustable positions (manually or optionally NC-controlled). Hirth gearing ensures precise angle settings. Powerful main spindle drive with approximately 30 kW. Speed range 20 – 7,000 rpm, maximum torque of approximately 1050 Nm. Additional equipment includes a 60-tool changer (KWE60), Chip conveyor, KNOLL filtration system, Hydac cooling units, and central lubrication. Feed rate up to 4 m/min, rapid traverse up to 18 m/min, and feed forces of approximately 30,000 N per a ...

x-axis: 3000 mm y-axis: 2000 mm z-axis: 1100 mm distance between columns: 3800 mm spindle motor: 18 / 23 kW spindle turning speed range: 18000 U/min rapid traverse: - m/min table-size: 2800 x 2000 mm workpiece weight: 7,5 t/m² Control: Heidenain TNC 640 workpiece width - max.: 3650 mm A-Axis: +/- 115 / 0,001 ° c-axis: 360 / 0,001 ° total power requirement: - kW weight of the machine ca.: - t dimensions of the machine ca.: - m Machine equipped with: - 5-axis machining centre - Heidenhain 640 iTNC CNC control (15.1” LCD) with Kinematics Opt. function - 24-position tool changer (HSK A63) - (German) Cytec S8 A/C milling head (18,000 rpm, 56/72 Nm, integrated) - Linear guides with rollers for the X/YU/Z axes - Heidenhain linear scales for the X/YU/Z axes - Coolant supply through the spindle, 20 bar - Air blow-off device on the spindle - Blum TC-60 workpiece measuring system - Blum NT-A3  ...

Key data: 2200 mm, 1500 mm, 1000 mm

Description, subject to prior sale. CNC 5-axis gantry milling machine with high dynamics Manufacturer: Parpas Type: Diamond linear Year of manufacture: 2013, Acceptance: 2014 Control: Heidenhain iTNC530 X (longitudinal travel): 2200 mm (+330) Y (transverse travel): 1500 mm (+330) Z (vertical travel): 1000 mm Distance between uprights: 2700 mm Max. distance between table surface and spindle tip with mounted milling head 1220 mm Linear axis feed speed: X and Y axis 0-60 m/min Z-axis 0-40 m/min Table surface: 2300 x 1600 mm Max. weight with optimal distribution: 6000 Kg/m2 T-slots 22 mm, distance between T-slots 200 mm. 5-axis orthogonal milling head with electrospindle Max. spindle speed 20,000 min-1 Spindle cone HSK 63 A A-axis ±105° (torque 830 Nm), C-axis ± 370° (torque 1200 Nm) 42 Stations Tool Changer Tool holder HSK 63A-100 Max. tool∅ 80mm  ...

Key data: 2400 mm, 2850 mm, 1000 mm

with CNC control, Fabr. FIDIA, type: C20, travels: X-axis: 2400 mm, Y-axis: 2850 mm, Z-axis: 1000 mm, with automatic clamping plate. Tool changer with 20 tool positions, with T-slot clamping plate, size: approx. 2000 x 1800 mm, coolant device

FOOKE ENDURA 83.1 Portal milling machine The FOOKE ENDURA 83.1 is a 5-axis CNC portal milling machine with three linear axes X, Y, Z and two rotary axes A and C. The clamping surface consists of two machine tables of 3,200 mm x 1,000 mm each. An additional, brand-new spindle unit from the manufacturer SPL is included in the scope of delivery. Year of construction 2003 Control SIEMENS SINUMERIK 840D Travel X - 3,500 mm / Y - 2,500 mm / Z - 1,200 mm / A - ± 120° / C - 365° Rapid traverse X/Y/Z axis up to 20 m/min Rotation speed A/C axis up to 15 rpm Equipment: Spindle HSK 63A make SPL, type/DRF-FO-180M-W-16-34 with 34 kW up to 16,000 rpm. Tool changer for 20 tools / diameter up to 100 mm Internal cooling IKZ up to 30 bar Spindle cooling Paper belt filter system KNOLL Hinged belt chip conveyor KNOLL Automatic doors Full enclosure Electronic handwheel Machin ...
