used Pillar-Type Drilling Machines for sale

Description: Column drill Table diameter: 300mm Spindle vertical travel: 170 mm approx. 4 working speeds: from 180 to 700 Rpm CH E-200 machine vice includedweight approx.: 150 kg, dimensions (l x w x h) approx.: 650 x 800 x 2,120 mm

: 40-1080 tool taper: MK 5 weight of the machine ca.: 2 tfeed: . The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Includes small vice, jaw width approx. ,100 mm . Machine number 4913turning speed range: 80 - 1400 rpm, table surface area l x w : 500x370 mm, weight approx.: 300 kg, dimensions (l x w x h) approx.: 1,100 x 700 x 1,800 mm

bore capacity in steel (diameter): 35 mmthroat: 330 mmbore stroke: 165 mmspindle taper: MK4 turning speed range - stepless: 130-480/480-1750 U/mintable width: 742 mmtable depth: 594 mmtotal power requirement: 2,2 kWweight of the machine ca.: 700 tFeed with electromagnetic feed clutch0.1/0,2/0,3right- and left rotationCooling unit not available Table and Drilling Head height adjustableheight adjustment of upper drilling unit: 200 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Alzmetall AB 35 S column drilling machine Column drilling machine Alzmetall AB 35 S - Tapping device - Drilling capacity 35 mm - Spindle holder MK 4 - automatic feed 0.1 – 0.2 – 0.3 mm/rev - Spindle speed 65 – 1750 rpm infinitely variable - Projection 300 mm - Pinol stroke 160 mm - Table height adjustable via rack with hand crank -Lighting - Table: 620 x 470 mm - Clamping surface: 500 x 370 mm - Column diameter 140 mm - Mains connection 380 volts, 50 Hz - Coolant equipment Space requirement L x W x H 1070 x 650 x 1880 mm Weight approx. 480 kg More column drilling machines - new and used - can be found in our shop! International shipping costs on request!

Bohrleistung in Stahl (-Ø: 36 mmthroat: 350 mmbore stroke: 180 mmBohrleistung in Guß (-Ø: 45 mmspindle taper: MT: 4 spindle head adjustment: Ý 500 mmtable surface area: 600 x 700 mmfloor plate:: 460 distance work spindle /surface of the table: 80 - 750 mmspindle turning speed range: 0,09 - 0,28 U/minfeeds: 380 mm/WUvoltage: 50 Vpower capacity: 2,5 kWweight of the machine ca.: 0,7 tdimensions of the machine ca.: 0,6 x 1,1 x 2,1 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: ja feed: 80 - 800 m/min: 1848 weight of the machine ca.: 2,2 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: - Serial number: PRJO46484 - Operating voltage: 3 x 400 V - Frequency: 50 Hz - Terminal fuse: 20 A - Total rated current: 13 A - Speed: 60 - 1530 rpm - Table dimensions: 600 x 450 mmweight approx.: 605 kg, dimensions (l x w x h) approx.: 1,200 x 800 x 1,900 mm

Description: throat: 290 mm drilling capacity in cast iron: diameter 32 mmboring stroke: 120 mm, boring diameter: 28 mm, tool taper: MK3, turning speed range: 80 - 1400 rpm, table surface area l x w : 375x325 mm, total power requirement: 1.6 kW, weight approx.: 380 kg, dimensions (l x w x h) approx.: 900 x 530 x 1,820 mm

- mounting table: 300 x 400 mm - quill ram: 120 mm - speed range: 5800 rpm - gearbox stages: 2 - feed: 0,001 - 3,5 m/min - rapid: 3,5 m/min - taper fixture: MK 3 - thread cutting device with foot switch - coolant system - total power: 1,5 kW - weight of machine: 380 kg - space requirement (W x D x H): 0,66 x 0,44 x 1,95 m - condition: very good Details High-performance drilling machine, machine number 511 accessories documentation, coolant equipment

Description: serial number 4214table surface area l x w : 300x300 mm, weight approx.: 200 kg, dimensions (l x w x h) approx.: 730 x 500 x 1,800 mm

Description: Number of speed stages: 16 Speed (max.): 4.300 rpm Quill: 100 mm Clamping surface: 250 x 250 mm including connecting cable Transport dimensions: 1.200 x 800 x 2.000 mm, ca. 200 kgturning speed range: 4,300 rpm, weight approx.: 180 kg, dimensions (l x w x h) approx.: 600 x 800 x 1,800 mm

Description: Includes cross table and small vice serial number 345744turning speed range: 105 - 2900 rpm, table surface area l x w : 420 x 270 mm, weight approx.: 150 kg, dimensions (l x w x h) approx.: 800 x 540 x 2,750 mm

Description: - machine no.: 349 - operating voltage: 400 V - frequency: 50 Hz - power: 0,15/0,90 kW - nominal current: 2,25/1,15 A - speed: 105 – 2900 rpm - table dimensions: 420 x 280 mm - with mounted vice - jaw width: 135 mmweight approx.: 190 kg, dimensions (l x w x h) approx.: 700 x 600 x 1,600 mm

Technical Data: Max. drilling capacity: 30 mm Complete with clamping

Drill with coordinate table, with digital display DRO , Year of construction: 1980, very good condition, can be visited under power Recording SK40, quick-change system, incl. recordings MK2, MK3, MK4, Spindle : 45 - 900 rpm , 3,4KW, right - left rotation, Stroke: 200mm, upper part adjustment electr. 500mm radius : 500, Coordinate table: clamping surface 600x400m, X-660, Y-450mm

Code 99901 Description Pillar drill Make CABER Modell 58 R Serial No. Year New Table ( turnable ) 400 x 600 mm Base 540 x 640 mm Drilling capacity ( Steel 60 ) 40 mm Spindle quill 200 mm Spindle taper 4 MC Gap 400 mm Max. distance spindle – table 800 mm Max. distance spindle – base 1180 mm Spindle speeds 9 steps 90 - 1550 rpm Spindle feeds 4 steps 0,06 – 0,30 mm/rev Weight 500 kg Motor 3 kW – 380 Volt Accessoiries automatic spindle feeds Coolant Condition Unused

Code 99902 Description Pillar drill Make CABER Modell 59 R Serial No. Year New Table ( turnable ) 400 x 600 mm Base 540 x 640 mm Drilling capacity ( Steel 60 ) 50 mm Spindle quill 200 mm Spindle taper 5 MC Gap 400 mm Max. distance spindle – table 800 mm Max. distance spindle – base 1180 mm Spindle speeds 9 steps 65 - 1150 rpm Spindle feeds 4 steps 0,06 – 0,30 mm/rev Weight 500 kg Motor 3 kW – 380 Volt Accessoiries automatic spindle feeds Coolant Condition Unused

Description: Machine number 627061, max. 1,450 rpm, drilling diam. max. 30 mm, countersinking stroke 120 mm, table clamping surface 420 x 370 mm, table height adjustableweight approx.: 1,200 kg, dimensions (l x w x h) approx.: 500 x 700 x 2,000 mm

Description: Machine number 626413, max. 1,450 rpm, drilling diam. max. 30 mm, countersinking stroke 120 mm, table clamping surface 420 x 370 mm, table height adjustableweight approx.: 1,200 kg, dimensions (l x w x h) approx.: 500 x 700 x 2,000 mm

Description: Drilling capacity in steel ST 60 30 mm, drilling spindle holder MK 3, drilling spindle stroke 160 mm, 9 drilling spindle speeds 90 - 1450 rpm, projection 300 mm, table with 2 T-slots + attached machine vice, table dimensions 400 x 450 mm, max. distance table - Drilling spindle 660 mm, height adjustable via rack with hand crank, Drive 400 V / 1.2 kWweight approx.: 400 kg, dimensions (l x w x h) approx.: 2,200 x 1,000 x 900 mm

Description: Serial number: 1491/998 Power: 380v, 50hz Installed power: 1.05kw Clamp includedweight approx.: 300 kg, dimensions (l x w x h) approx.: 600 x 800 x 1,000 mm

Description: Serial number: 15010 Drilling capacity: 40 mm Spindle speed: 2400 Rpm Number of speed ranges: 14 Stroke drilling pinole: 130 mm Movement X-axis: 450 mm Movement Y-axis: 150 mm Movement Z-axis: 400 mm Drilling feed: 0,05/0,1/0,2 Machine dimensions: Length x depth: 1300x1250 mm Height: 1900 mm Weight: 1150 kg boring stroke: 130 mm, boring diameter: 40 mm, turning speed range: 2,400 rpm, table surface area l x w : 800x255 mm, weight approx.: 1,150 kg, dimensions (l x w x h) approx.: 1,300 x 1,900 x 1,250 mm

Year: ca. 1970 tool taper: MK 2 : . feed:: Pleonastischer Vorschub The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Year: ca. 1988 Wario: . tool taper: MK 2 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: machine number 23100073, drill chuck RÖHM 3 to 16 mm, table approx. 220 x 220 mm, height adjustable, drilling stroke approx. 60 mm, speeds 480, 730, 1160, 1800 and 2800 rpmweight approx.: 50 kg, dimensions (l x w x h) approx.: 700 x 400 x 800 mm

Continuous/standard drilling capacity (mm) 20/23 (in E335/ST60) Thread cutting capacity (depending on pitch) M12 Spindle MK II Drilling depth (mm) 100 Projection (mm) 240 Column diameter (mm) 82 Usable work surface (W x L) (mm) 340 x 280 T-slot size (arm), distance (mm), dimension width (mm) Number 2, 125, 13/26 Speed display digital Digital drilling depth display Drilling depth stop quickly adjustable stop ring Feed (mm/revolution) by hand Table height adjustment with rack Motor three-phase current 400V with frequency converter (kW) 1.5 Spindle/work surface distance (mm) 160 – 880 Machine dimensions without packaging (mm) 355 x 705 x 1825 Machine dimensions with packaging (mm) 572 x 936 x 2142 Weight (kg) 195 Standard accessories: Thread cutting device Control panel with OLED display Robust, high-quality drill head hood with ergonomically inclined front LED li ...

- Infinitely variable speed control - Quickly adjustable drilling depth stop - Thread cutting device - Undervoltage triggers - Table height adjustment via rack - LED lighting in the head - Continuous/normal drilling capacity R1: 23/25 mm - Thread cutting performance (depending on slope) R1: max.M 16x1 - Spindle MK II - Drilling depth 100 mm - Projection 260 mm - Column diameter 110 mm - Usable table surface (W x L) 420 x 340 mm - T-slot size (arm): number 2, distance 125 mm - Speed display digital - Drilling depth display digital - Drill depth stop quickly adjustable - Feed by hand - Motor three-phase current 400 V - Spindle speeds infinitely variable R1 with 20-2,000 1/min Option: Coolant device: € 525,- FACTORY WARRANTY: 3 years DELIVERY: free domicile incl. packaging NOT THE RIGHT MACHINE? WE ALSO CARRY OTHER FLOTT PRODUCTS - ASK FOR A QUOTE! FAS ...

taper MK: MK2 weight of the machine ca.: 200 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Duration / ALB ear power 25/30 mm Thread cutting capacity Max M20 Spindle MK III Drilling depth 125 mm Throat depth 260 mm Column diameter 110 mm Usable surface [BxL] 420 x 340 mm Speed display scale Drilling depth indicator scale Drilling depth stop with fine adjustment Table height with rack and pinion Motor three-phase 400 V pole changing bar 0.90/1.45 kW Spindle speed with idle, stepless 125-4000 1 / min in 2 levels I: 125-2000 1 / min II: 250-4000 1 / min The levels change via belt apportionment Warranty: 3 years Shipping time: immediately, free loaded DELIVERY: free House including packaging NOT THE RIGHT MACHINE? WE DO ALSO OTHER AFLOAT PRODUCTS - ASK FOR A QUOTE! FLOTT BASE PARTNER .

Description: with drill chuck, range 200 to 3000 rpm, type 15 pcs.weight approx.: 350 kg, dimensions (l x w x h) approx.: 900 x 500 x 1,900 mm

Description: Revolutions 400-4800 rpmweight approx.: 92 kg, dimensions (l x w x h) approx.: 800 x 600 x 1,550 mm

Description: Machine number 042665 Power 2.3 kVA technical data without guaranteetable surface area l x w : 400,400 mm, weight approx.: 400 kg, dimensions (l x w x h) approx.: 1,100 x 915 x 1,950 mm

taper MK: MK5 round table: ja weight of the machine ca.: 1.200 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Drilling diam. max. 28 resp. 32 mm, table clamping surface 400 x 315 mm, stroke approx. 150 mm, throat depth approx. 300 mm, speed range 150 - 3,000 rpmweight approx.: 350 kg, dimensions (l x w x h) approx.: 900 x 700 x 1,900 mm

Description: max. 3,000 rpm, lowering travel 170 mm, table diam. 400 mm, height adjustableweight approx.: 1,500 kg, dimensions (l x w x h) approx.: 700 x 1,000 x 2,000 mm

Description: Drill diameter max. 30 mm, stroke approx. 170 mm, table surface approx. 450 x 350 mm, throat approx. 320 mm, motor power 1.6 kWweight approx.: 350 kg, dimensions (l x w x h) approx.: 1,100 x 700 x 1,950 mm

Description: Automatic feed Column diameter: 130 mm Distance column to spindle: 320 mm Distance table to spindle: Max. 790 mm boring stroke: 175 mm, boring diameter: 32 mm, tool taper: MK$, turning speed range: 60-1600 rpm, table surface area l x w : 450x335 mm, total power requirement: 1.8 kW, weight approx.: 450 kg, dimensions (l x w x h) approx.: 850 x 650 x 1,950 mm

turning speed range: 700 bis 2800 rpm, table surface area l x w : 240x210 mm, weight approx.: 250 kg, dimensions (l x w x h) approx.: 500 x 430 x 1,900 mm

Description: Column drill Table measurements: 550 x 550 mm Vertical travel of the table: 500 mm approx. 9 working speeds: 58 - 1098 Rpm Clamping vise includedtable surface area l x w : 550 X 550 mm, weight approx.: 500 kg, dimensions (l x w x h) approx.: 1,100 x 550 x 2,400 mm

Description: Serial number 152-I Spindle speed 54-1032 r.p.m.weight approx.: 500 kg, dimensions (l x w x h) approx.: 6,200 x 1,100 x 2,500 mm

Description: Column drill Serial number 118 Table measurements: 540 x 440 mm Spindle travel: 260 mm Vertical travel of the table: 570 mm approx. It has 9 working speeds: 50 - 1084 Rpm Motor power: 5.5 kWtable surface area l x w : 540 x 440 mm, weight approx.: 500 kg, dimensions (l x w x h) approx.: 700 x 1,030 x 2,500 mm

bore capacity in steel (diameter): 32 mmthroat: 385 mmbore stroke: 200 mmspindle turning speed range: 75-2375 U/minspindle taper MT: 4 cross-moving table: 1200x360mm weight of the machine ca.: 1.3 tDigital read-outwww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table surface area l x w : 400x370 mm, weight approx.: 500 kg, dimensions (l x w x h) approx.: 1,200 x 800 x 2,500 mm

Description: Model: BS 15GL (with taping function) Serial number: 132730 Drilling capacity: 15 mm Tapping capacity: M3 – M10 Throat: 215 mm Table movement: 950 mm Spindle: MK-2 Spindle speed: 1600 1/min. (4 steps) Machine dimensions: Length x depth: 800x400 mm Height: 2100 mm Weight: 155 kg Including Safety screen Pedal control Note! Tools, clamps etc. are not included unless indicated otherwise.tool taper: MK2, turning speed range: 1,600 rpm, table surface area l x w : 310x280 mm, weight approx.: 155 kg, dimensions (l x w x h) approx.: 800 x 2,100 x 400 mm

bore capacity in steel (diameter): 3 - 16 mm: max. 1500 mmweight: 300 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Table dimensions about 300 x 220 mm, machine number 98963turning speed range: 320 bis 1600 rpm, weight approx.: 200 kg, dimensions (l x w x h) approx.: 600 x 340 x 1,700 mm

Description: Machine number 98 957turning speed range: 80 - 700 rpm, table surface area l x w : 540x320 mm, weight approx.: 400 kg, dimensions (l x w x h) approx.: 800 x 650 x 1,800 mm

Description: drilling diam. max. 35 mm, table clamping surface 470 x 470 mm, stroke approx. 160 mm, throat approx. 350 mm, speed range 150 - 1,180 rpmweight approx.: 325 kg, dimensions (l x w x h) approx.: 1,000 x 700 x 1,950 mm

Description: Factory number 14473 , Includes vice, jaw width 200 mmtable surface area l x w : 360x280 mm, total power requirement: 0,6 kW, weight approx.: 250 kg, dimensions (l x w x h) approx.: 650 x 450 x 1,700 mm
