Product number: 2522J Type: MI-450 Serial number: 9811.016.0070 Year of construction: 1998 Needles: 105 pieces, Ø 4 mm Belt width: 450 mm, walking beam Product height: max 200 mm Compressed air: 6 Bar Power: 3 x 400V, 50Hz, 21A Dimensions: 2250 x 1600 x 1900 mm With double head for tenderiser / double needle block With rotating filter Including trolleys for needles
Brine injector WANTED PSM 12-24-4.0
The injector is a device for introducing brine solution through point injection of the raw product. Producer: Fomaco; Model: FGM 208 B; Year of production 1997; The machine has 208 needles (4mm diameter); The width of the tape is 740mm; The conveyor belt is not complete; Without brine filter; Length: 2300 mm; Width: 1200 mm; Height: 2300 mm; Weight: 1500 kg.
Type: PI 17 Number of needles: 17 Needle diameter: 4 mm Max product: width 280 mm Tact per minute: 15 to 55 tact/min. Passage mechanism type: gear rack rail Product passage height: 220 mm Brine pressure: 0,5 to 4,0 bar Electric power: 2.5 kW Machine dimension in cm: Width: 57 Length: 150 Height: 176 Delivery time: 30 working days after advanced payment
Number of needles: 21 Needle diameter: 4 mm Max product: width 280 mm Tact per minute: 15 to 55 tact / min Passage mechanism type: gear rack rail Product passage height: 220 mm Brine pressure: 0,5 to 4,0 bar Electric power: 2,5 KW Machine dimension in cm: Width: 57 Lenght:150 Height: 176 Delivery time: 30 working days after advanced payment
Number of needles: 21 Needle diameter: 4 mm Max product: width 280 mm Tact per minute: 15 to 55 tact / min Passage mechanism type: gear rack rail Product passage height: 220 mm Brine pressure: 0,5 to 4,0 bar Electric power: 2,5 KW Machine dimension in cm: Width: 57 Lenght:150 Height: 176 Delivery time: 30 working days after advanced payment
injector Günther PI 17; curing injector with 17 needles, Connection 400V, year of construction 2009, Dimensions LxWxH approx. 140x58x180cm, weight approx. 260kg, very good used condition, fully functional
Injector Günther PI 17, curing injector with 17 needles, new hoses and pressure gauges, Dimensions LxWxH approx. 130x52x180cm, weight approx. 225kg, good condition, fully functional
injector Günther PI 8, curing injector with 8 needles, new hoses and belts, pump with new bearings, seals and impellers, Connection 400V, dimensions LxWxH approx. 135x55x180cm, weight approx. 200kg, good used condition, functional
Curing injector Günther PI8-16 in good used and functional condition. Completely made of stainless steel, 16 needles, width 26 cm. Dimensions W/D/H 60/140/170 cm. Connection values 400 volts, 1.5 kW. Workshop-tested, ready for immediate use. More on request.
Injector Günther PI 9, curing injector with 9 needles, new pump and hoses, Connection 400V, dimensions LxWxH approx. 130x55x175cm, weight approx. 225kg, good used condition, functional
Curing injector Günther PI9 in a very good used and functional condition. Completely made of stainless steel, 9 needles, width 26mm, power 300 - 500 kg/hr Dimensions B/D/H 55/140/170 cm. Connection values 400 volts, 16 A. Workshop tested, ready for immediate use. More on request.
Injector GUNTHER Type: PI16 Number of needles: 16 pcs. Device dimensions: 1500 x 550 x 1650 mm Working belt width: 270 mm Power supply: 380V Pressure regulation of the amount of injected brine Made of stainless steel Stock status: 1 piece Condition: Used We have many others machines for meat industry and cooling - nowicki, gunther, handtmann, seydelmann, inject-star, viessmann, bitzer, copeland, . Check our offers.
Curing injector GÜNTHER Type: PP3 Specifications: 400V / 50 Hz / 0.55 kW / 16 A Pressure variable, max. 3 bar Year of construction: 2017 Original price EUR 3.235,61 Function tested, device ready for use A needle is not included Condition see original pictures! If you have any questions, call or email.
Curing injector GÜNTHER Type: PP3 Specifications: 400V / 50 Hz / 0.55 kW / 16 A Pressure variable, max. 3 bar Year of construction: 2018 Original price EUR 3,235.61 Function checked, device ready for use Stock machine, immediately available! Condition & accessories see original pictures! If you have any questions, call or email.
Product number: 2486P Type: HPI650 Serial number: HPI-650-7208 Year of construction: 2018 Capacity: max 6000 kg/hr Needles: 243 pcs. Needle diameter: 3 mm Walking beam: 650 mm Product height: max 200 mm Brine pressure: 0.5 - 4 Bar Power: 3 x 400V, 50Hz, 18.5kW Dimensions: 3550 x 2700 x 2300 mm Weight: 1300 kg Including rotating filter/brine tank For boneless and bone-in products
Automatic injector INJECT STAR BI 124/248 needles. 2006 manufactured. The machine is complete with a rotary filtering system. Fully factory refurbished with 1 year warranty.
Curing Inject Star Type: BI-60/88 Power: 4kW 400v Dimensions: 1550 x 600 x 2100 mm 22 double needles 4mm Made of stainless steel Number of pieces in stock: 1 piece Condition : Used in good condition Price on request, We have many other kee lines and meat and fish processing machines : Bitzer,Copeland,Frascold,Lunite,Kueba,Guentner,Eco,Alfa-Laval,Goedhart ,Helpman
Type: PI 88 Number of needles: 88 Two pressure pump Needle diameter: 4 mm Max product: width 360 mm Tact per minute: 15 to 55 tact/min. Passage mechanism type: gear rack rail Product passage height: 220 mm Brine pressure: 0,5 to 4,0 bar Electric power: 6.5 kW Machine dimension in cm: Width: 60 Lenght: 210 Height: 190 Delivery time: 30 working days after advanced payment
– 36 needles – Completely factory refurbished – With 1 year warranty.
Injector Inject Star Type: PI 36 Number of needles: 36 Needle diameter: 4 mm Passage mechanism type: Gear rack rail Electric power: 3kW Machine dimension in cm: 50x160x200cm
Inwestpol ANs-25 Injector Number of measures: 0-60/min The width of the conveyor belt: 290 mm Stroke of the conveyor belt: 0-200 mm Max. needle height: 220 mm Brine pressure: 0-4 bar Pump efficiency: 0-60l / min Manufacturer: Inwestpol Model: ANs-25 Height: 1200 mm Width: 500 mm Length: 1900 mm Weight: 290 kg Electric power supply: 400V 50Hz 3N Total power: 3 kW Efficiency: do 2500 kg
Manufacturer: Karpowicz NK-17 Year of construction: 2015 Power supply: 400 V / 50Hz Power: 1.1 kW Dimensions: length 1740 x width 750 x height 2050 mm Weight: 320 kg Intended for injecting red meat, with or without bones Injection pressure adjustment Touch control panel PROFACE GP4100 The number of needles 17, needle thickness 4 mm The width of the conveyor belt 250 mm The height of the rise of the needles is 190 mm Adjustable belt travel: 9 + 35 mm Number of measures: 13 + 60 measures / min Maximum capacity up to 1 t/h Brine tank with filter system Request an offer iNTER-WiBA Sp.J. Ul. Krakowska 263 PL 43-305 Bielsko-Biala VAT ID: PL547-17-47-669 tel. 0048/33 812 58 60 Fax. 0048/33 812 58 36
Used Metalbud Nowicki MH140 injector is a high-performance device. It is equipped single head, easy and clear control using inituitive panel and efficient rotary drum filter for brine filtration. Using different parameters it is possible to adjust the belt speed and injecting pressure. Whole construction is made of acid resistant stainless steel which guarantees the ease of maintenance and maximum hygiene. Number of needles: 140 Max product height: 200mm Installed power: 11.7kw Belt width: 400mm Dimensions: L 1800 x W 1010mm x H 2015mm Weight: approx 550kg
Type: PR 15 Number of needles: 15 Needle diameter: 4 mm Max product: width 270 mm Tact per minute: 15 to 55 tact/min. Passage mechanism type: gear rack rail Product passage height: 220 mm Brine pressure: 0,5 to 4,0 bar Electric power: 1.5 kW Machine dimension in cm: Width: 50 Lenght: 125 Height: 150 Delivery time: 30 working days after advanced payment
We sell here a curing injector from the manufacturer Rühle, type IR 17 in a very good used and functional condition. The machine runs on 400 volts, 7.6 kW, built in 2012, 17 needles, 2 speeds, completely stainless steel, workshop tested, immediately ready for use, dimensions B/D/H 105/70/185 cm, more on request.
We sell here a curing injector from the manufacturer Rühle, type PR 15 in a good used and functional condition. The machine runs on 400 volts, 1.1 kW, year of construction 2001, 15 needles, completely stainless steel, workshop tested, ready for immediate use, dimensions W/D/H 40/140/140 cm, more on request.
Rühle injector PR 15 15 needles CW 1.1
We sell here a curing injector from the manufacturer Rühle, type PR 15 in a good used and functional condition. The machine runs on 400 volts, 1.1 kW, year of construction 99, 15 needles, complete stainless steel, workshop tested, immediately ready for use, dimensions B/D/H 40/140/140 cm, more on request.
Automatic injector 216 needles Type: ІМАХ 420 Product width: 420 мм. Cycles: from 15 to 60 Feed max.: 60 mm. Product height: 130÷220 mm Number of needles: 216, 3 mm. Brine pressure: 0,5-4,5 bar Machine charging height: 1150 mm Compressed air min. 6 bar Voltage: 230/400 V, 50/60 Hz Connection: 14,0 kW ; 32А Rotary brine filter: DF 510 Dimensions, mm: Machine length: approx. 2200 Machine width: approx. 1350 (approx. 2200 mm with filter) Machine height: approx. 2300 Weight: 1500 kg.
Type: IMAX 520 Working with boneless meat Product width: 520 мм Cycles: 15 to 60 per minute Feed: max. 60 mm Product height: 130÷230 mm Number of needles: 200 (2 х 100), 4 мм Brine pressure: 0,5-4,5 bar Machine charging height: 1170 mm Compressed air: 6bar Voltage: 230/400 V, 50/60 Hz Connection: 10,0 kW ; 23 А Rotary brine filter DF 510 Machine dimensions in mm: Length: approx. 2100 Width: approx. 1350 (about 2500 mm with filter) Height: approx. 2300
Product number: 2471J TypeI: MAX420 Serial number: 4201 1061 Year of construction: 2006 Needles: 108 pieces of 3 mm Walking beam: 420 mm Advance:50/100 mm Product height: max 140 mm Cycles: 15 to 60 per minute Compressed air: 6 Bar Power: 3 x 400V, 50Hz, 16kW Dimensions: 2300 x 2200 x 2300 mm Including rotating filter
Type: SCHRODER N 120 Number of needles: 120 Diameter of needles: 3 mm Product width: 620 mm Transportation type: walking beam Product passage height: 180 mm Brine pressure: 0,5 – 4,0 bar Machine dimensions in cm: Width: 120,0 Width with filter for brine: 200,0 Length: 220,0 Height: 225,0 Compressed air: 6,0 bar Power: 14,0 kW Voltage: 380 V, 50 Hz
Type: : Schröder N 138 Number of needles: 138 Diameter of needles: 4,0 mm Product width: 620 mm Transportation type: walking beam Product passage height: 200 mm Brine pressure: 0,5 – 4,0 bar Machine dimensions in cm: Width: 110,0 Length: 220,0 Height: 230,0 Power: 10,0 kW Voltage: 380 V, 50 Hz
Type: N 50 Number of needles: 50 Diameter of needles: 4,0 mm Max. product width: 350 mm Transportation type: walking beam Product passage height: max 180 mm Brine pressure: 0,5 - 4,0 bar Machine dimensions in mm: Width: 800,0 Length: 1600,0 Height: 1900,0 Power: 8,0 kW , 17 A Voltage: 380 V, 50Hz
