pfauter rs used for sale

Pfauter RS 2 With accessories

PFAUTER RS 00 - Gear hobbing machine -Max. wheel diameter 250mm -Max. tooth width 160mm -Max. module 2.5 - 3mm -Approx. 65 change wheels + built-in change wheels in the machine - Table diameter approx. 200mm -Milling cutter speeds 200 - 1200 rpm -Digital display -Tangential milling device -Interchangeable wheels -Documentation -Machine enclosure Dimensions: LxWxH 1.6x1x1.7 meters / Weight 1800 kg

Zum Verkauf steht ein Fräskopf bei der Firma Pfauter ca.2012 komplett überholt.

For sale a milling head without counter bearing

Div. Interchangeable wheels for the gearbox Speed...

Various interchangeable wheels for the gearbox Speed...

Magnetic chip conveyor of a PFAUTER PA320 can be used universally. Length 135cm

One servo motor for each X/Z/A/ and C-Axis

max. wheel diameter: 3000 mm gear width: 1200 mm max. module: 30/40 min. module: 2 table diameter: 2500 mm table load capacity: 400 kN hob dia. - max.: 450 x 500 mm milling spindle speeds: 10 - 165 U/min hob length max.: 500 mm tip circle diameter: 2050 mm tooth helical angle min/max: 0 - 45 ° center distance betw. workpiece-tool min/max.: 150 - 1750 mm milling slide swivelling: 50 Grad distance table / counter stay: 1050 - 2050 mm shifting: 300 mm workpiece weight: 40 t table bore diameter: 800 mm depth of hole: 1100 mm main drive motor: 37 kW min. workpiece diameter: 290 mm min. number of teeth: Wälzfräsen 20 min. number of teeth: Formfräsen 2 taper: MK 100 feeds axial: 1 - 1800 mm/min radial feed: 1 - 500 mm/min feed: Tangential 1 - 450 mm/min rapid traverse: 1875 / 530 / 470 mm/min electrics - voltage/frequency: 380 / 50 V/Hz control: Siemens Sinumerik 3M total power requirement: ...

power capacity: 0 kW tool adaptor: 0 total power requirement: 0 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

amount: 36 STK. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter:300 mm gear width:110 mm max. module:6 weight of the machine ca.:10,5 t

Infeed and outfeed chain conveyor, with tool holders, chip conveyor, hydraulic unit and air conditioning.

max. wheel diameter:180 mm gear width: mm max. module:4 total power requirement:14 kW weight of the machine ca.:8 t slide travel axial ( Z-axis ):300 mm work piece - max.:490-640 mm

max. wheel diameter:275 mm gear width:58 mm max. module:8 min. module:0,5 weight of the machine ca.:10 t max. number of teeth:200 min. number of teeth:5

Generating Grinding Machine Grinding Machine Gleason Pfauter G320 CNC + Promot Automation Hersteller [manufacturer]: Gleason Pfauter G320 + with Promot Automation handling unit Type [ type]: G 320 Control unit: Siemens 840 Incl. control panel Baujahr[construction year]: 10/2001 Module [ ]: 0.5-7.0 Min. workpiece diameter [ ]: 10 mm Max. workpiece diameter [ ]: 380 mm Number of teeth [ ]: 10-600 Vertical carriage stroke "Z" [ ]: 200mm Horizontal carriage stroke "X" [ ]: 230mm Tangential carriage stroke (SHIFTING) "Y" [ ]: 135mm Swivel angle clamping head "A" [ ]: +-45° Tailstock tip stroke [ ]: 125mm tangential slide stroke – dressing [ ]: "V" 180mm radial carriage stroke – dressing [ ]: "U" 110mm Rotation speed – grinding wheel in progress [ ]: 3000rpm max - infinitely variable Egg speed - linear axes [ ]: 10000 mm/min Max. table rotation speed [ ]: 240 RP ...

max. wheel diameter: 630 mm gear width: 375 mm max. module: 10 clamping table: 550 mm table hole: 125 mm milling spindle speeds infinitely variable: 62 - 390 U/min taper: MORSE 5 axial-feeds: 0,40 - 6,80 mm/U radial feeds: 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle: 50 - 425 mm no. of teeth: min. 8 milling cutter dia. x width: 192 / 215 mm shifting: 200 mm main drive motor: 7,5 kW total power requirement: 21 kVa weight of the machine ca.: 8,2 t Main features: -Universal hob head with tangential movement -Automatic shifting -Automatic dwell attachment -Hydraulic clamping in table -Pressure reduce valve for outer steady -Magnetic swarf conveyor Accessory: 1 set of tools for operating and maintenance 1 set differential gears, module 1,75 1 set indexing change gears module 2,5 1 change gear cabinet The data for this ad was created with ModulMWS - the software solution of Lo ...

max. wheel diameter: 130 mm gear width: 25 mm max. module: 4 min. module: 0,5 Control: Siemens 840 D strokes - infinitely variable: 500-2500 Hub/min stroke: 30 mm work-spindle diameter: 85 mm total power requirement: 49 kW weight of the machine ca.: 11,5 t dimensions of the machine ca.: 6,4x4,5x4,4 m Counterhold without center hydraulically operated counter arm and Linear guides. For automatic ring loader, with 4 stations The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

amount: 2 STK weight - pallet system: 11 kg dimensions: 540 x 2000 x 100 mm Hobbing cutter possibly Pfauter P 400 - 2 pcs. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 4400 mm gear width: 645 mm max. module: 35 Control: Siemens main drive motor: 37 kW table diameter: 2500 mm max.helical angle: +/- 30 ° workpiece weight: 40000 kg total power requirement: 142 kVA weight of the machine ca.: 75 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 150 mm gear width: mm max. module: 4 min. module: control: Sinumerik 840 D table diameter: 140 mm maximum axial offset: 200 mm milling tool taper: ISO 40 diameter of hob: max. 130 mm cutter length max.: 220 mm milling spindle speeds (infinitely variable): 300 - 1200 U/min shifting: max. 170 mm milling head -swivable +/-: 45 ° feed speeds: 1 - 1500 mm/min rapid travel speed: 3000 m/min workpiece magazin: Stück max. workpiece diameter: im Magazin: 150 mm total power requirement: 50 kW weight of the machine ca.: 8,5 t dimensions of the machine ca.: 4,7 x 3,6 x 2,6 m Condition: ready for operation: Video(s) available on our website.: Electric 400 Volt: Used gear hobbing machine, Pfauter, completely overhauled in 2023 by the specialist company SerWeMa. There is another identical machine available, but the spindle needs to be overhauled. If you are interested, you ca ...

Gear hobbing machine PFAUTER 1200mm, modul 12, with change gears

max. wheel diameter: 160,175 mm gear width: 355 mm max. module: 4,5 spindle bore: 75 mm centre distance: 410 mm min. number of teeth: 2, 3 cutter diameter max.: 115 mm cutter length max.: 105 mm axis distance between cutter and workpiece - max.: 138 mm axis distance between cutter and workpiece - min.: 30 mm milling head -swivable: 120 ° milling spindle speeds: 70 - 400 U/min axial-feeds: 0,25 - 4,0 mm/U radial feeds: 0,09 - 1,5 mm/U total power requirement: ca. 9,5 kW weight of the machine ca.: 3,5 t dimensions of the machine ca.: 1730x1400x1440 mm Equipment/accessories: - Interchangeable wheels - Milling arbors - Clamping devices - Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Max. Pitch circle diameter External gearing: 300 mm Max. Pitch circle diameter internal gearing: 300 mm Max. Outer diameter of workpiece (equipment): 450 mm max. module: 6 gear hobbing width -max.: 100 mm Max. Helix angle (with tool Ø 125 mm): +/- 45 ° strokes - infinitely variable: 130 - 1300 Hub/min workpiece weight: 1000 kg Minimum distance table top - tool spindle: -55 / +300 mm Maximum distance table top - tool spindle: 200 mm Maximum distance table top - tool spindle: 350 mm Manual Upright side shift: +/- 25 mm Manual swivelling angle of the tool spindle: +/- 0,5 ° Max. Tool speed: 15 UpM Max. Workpiece speed: 27 UpM Max. Tool diameter: 7 Zoll voltage: 400 V frequency: 50 Hz Max. Line power: 70 A total power requirement: 48 kW weight of the machine ca.: 11 t dimensions of the machine ca.: 4,27 x 3,11 x 2,87 m control: Siemens Sinumerik 840 C table hole: 40 mm taper in main spind ...

Gear Hobbing Machine Pfauter P 400 With interchangeable wheels

Gear hobbing machine vertical Pfauter P251 With accessories

Gear hobbing machine horizontal Pfauter P160 With accessories

max. machining diameter: 3200 mm max. workpiecediameter: 3200 mm axial slide way: 2200 mm control: Siemens Sinumerik 840 D table diameter: 2500 mm boring diameter: 800 mm max. load: 40.000 kg table rotation speed: 2 U/min grinding head: grinding head - swivable: +45 / - 45 ° turning speed range - grinding wheel: 270 - 2700 U/min tip circle diameter: min. 1500 mm grinding spindel dia.: 100 mm Max. grinding wheel diameter: 450 mm Dressing diameter: min. 250 mm Planing width: min. 80 mm Fast feed speed: axial: 10 m/min Fast feed speed: radial: 3 m/min max. depth of profile: 100 mm tail stock: tailstock travel: 1410 mm total power requirement: 225 kVA weight of the machine ca.: 46 t dimensions of the machine ca.: 14,5 x 9,95 x 6,1 m Gear Profil-Grinding Machine - CNC Control Siemens 840D - Tailstock - Dressing Unit - Oil Mist suction - Coolant The data for this ad was created with Modul ...

max. wheel diameter: 100 mm gear width: 26 mm max. module: 31 min. module: 0,1 Control: Siemens 840 D SL total power requirement: 45 kW weight of the machine ca.: 7 t dimensions of the machine ca.: 4x3x2,5 m Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ ...

Diameter: 0 mm Width: 0 mm Bore: mm Tangential head for gear hobber RS 2 - also available: Tangential head for gear hobber RS 00 ! The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A Pfauter vertical CNC gear hobbing machine is available. Modules min./max.: 1/3, max. workpiece diameter: 150mm, max. tooth width: 150mm, milling head tilt: +/-45°, milling cutter axis-table axis distance: 10mm-160mm, table diameter: 160mm, table bore: 63mm. Tool holder: SK40, max. cutter diameter: 130mm, max. cutter length: 220mm, speed: 600rpm, feed: 1500mm/min, tangential path: 170mm, rapid traverse: 3m/min. Machine dimensions X/Y/Z: approx. 4000mm/3000mm/2500mm, weight: approx. 6500kg. On-site inspection is possible.

max. wheel diameter: 350 mm gear width: 350 mm max. module: 8 min. module: total power requirement: 7,5 - 22 kW weight of the machine ca.: t dimensions of the machine ca.: m Gear hobber with gear shaping device, 2-cut cycle The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 900 mm gear width: 500 mm max. module: 1 min. module: 10 total power requirement: 16 kW weight of the machine ca.: 8.500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 330 mm gear width: - mm max. module: 7 min. module: 0,5 Control: Siemens 840 C total power requirement: 72 kVA weight of the machine ca.: 11,7 t dimensions of the machine ca.: m We offer a Pfauter model G 320 gear grinding machine for sale numerical control on 8 axes for the machining of gears with straight and helical toothing, with rolled profile for enveloping cuts, the one Worm profile disc used. Technical specifications: CNC control Siemens 840 C Controlled axes: X Radial axis Y Tangential Shift Z Vertical axis A Workhead rotation B Worm rotation during processing C Table rotation U Radial axis dresser V Tangential axis dresser Module 0.5 – 7.0 Minimum workpiece diameter 10 mm Maximum workpiece diameter 330 mm Number of teeth 10 - 600 Vertical carriage thrust Z 200 mm Horizontal grinding wheel - carriage stroke X 230 mm Tangential slide stroke Y 135 mm Angle o ...

max. wheel diameter: 2800 mm gear width: - mm max. module: 20/30 min. module: Control: Siemens 840 D total power requirement: 40 kW weight of the machine ca.: 50 t The machine has only a few working hours and is like new. With internal milling head. Note: If you require an external milling head, we can offer it separately. - The price of the new machine of this caliber is 2.3 million Euro. - With minimal operating hours, the machine is essentially new. - It is one of Gleasons largest machines - It has the possibility of dry or wet milling, and internal and external gearing. - The machine underwent a comprehensive manufacturers inspection in July 2023 and is in impeccable working order. - Machine is currently partially assembled to allow potential buyers to verify all functionalities. If you wish to see the machine in operation, we have two identical machines running in our produc ...

max. wheel diameter: --- mm gear width: --- mm max. module: --- min. module: --- total power requirement: --- kW weight of the machine ca.: --- t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 900 mm y-travel: 300 mm z-travel: 1000 mm control: Siemens Sinumerik 840D max. workpiece diameter: 1600 mm max. module: 20 mm tip circle diameter: 350 mm Milling arbour diameter: 375 mm Total closing value: 80 kVa weight of the machine ca.: 33,5 t dimensions of the machine ca.: 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

workpiece diameter nominal: 2400 mm max. workpiece diameter: 2800 mm max. module: 30 mm control: Siemens Sinumerik 840 D dividing plate diameter: 2200 mm table diameter: 2500 mm Table hole Diameter / depth: 800 / 875 mm max. table load: 40000 kg Table rpm: 4,5 min-1 clamping length max.: 375 mm clamping diameter max.: 350 mm cutter diameter max.: 2800 mm Cutter arbor cone: HSK-B160 swivelling range milling head: + 30/-45° Distance Cutter - Workpiece: 615 / 1600 mm weight of the machine ca.: 57 t Slide drives: - Feed & rapid traverse speed: - axial 4000 mm/min - radial 3000 mm/min - tangential 3000 mm/min Equitment/Accessories: - IFK2 internal milling head - Milling arbor with spacers - chip conveyor - Oil mist extraction - technical Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Three milling heads for different machines of the brand Pfauter-Gleason are available. 1) Milling head for Gleason Genesis 130H. 2) Milling head for Pfauter P200, without counter bearing. 3) Milling head for Pfauter PE250. An on-site inspection is possible.

max. wheel diameter: 250 mm gear width: 242 mm max. module: 4 min. module: 0,5 table diameter: 250 mm table bore diameter: 68 mm milling cutter dia. x width: 130 x 130 mm spindle stroke - max.: 110 mm min. number of teeth: 6 center distance betw. workpiece-tool min/max.: 10 - 210 mm milling spindle speeds (infinitely variable): 80 - 500 U/min feeds axial: 0,32 - 4 mm/WU radial feed: 0,05 - 1,6 mm/WU feeds - tangential: 0,16 - 2 mm/WU Control: LAUER PCS table diameter: 250 mm table hole: 62 mm milling cutter dia. x width: 130 x 130 mm total power requirement: 16 kVa weight of the machine ca.: 3,6 t dimensions of the machine ca.: 2,8 x 2,4 x 1,9 m Machine ideal for electrical retrofitting Equipped with: - LAUER PCS NC control - Siemens Simatic S5 PLC - Loading device/magazine for workpiece size max. 140 mm Ø - Shifting - 2-cut cycle The data for this ad was created with ModulMWS - the s ...

Wheel diameter: 160mm, max. wheel width: 355mm, module range: 0.5-4.5, max. cutter diameter: 115mm, max. cutter length: 105mm, cutter head swivel range: 120°, speed: 400rpm, distance between centers: 410mm. Machine dimensions X/Y/Z: approx. 2000mm/1500mm/2000mm, weight: approx. 3500kg. An on-site inspection is possible.

Control: SIEMENS table surface area: 160 mm weight of the machine ca.: 10 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 5-axis CNC milling machine manufactured in 2007 features a Siemens SINUMERIK 840 D controller with electronic gear and integrated safety functions. It can handle workpieces up to 2800 mm in diameter and offers motorized milling heads with a swivel range of +30/-45 degrees. Ideal for both internal and external gears, consider the opportunity to buy this Gleason Pfauter P 2800 CNC milling machine. Contact us for more information about this machine.

max. wheel diameter: mm gear width: mm max. module: 0 min. module: 0 total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: mm gear width: mm max. module: 0 min. module: 0 total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cone distance min./max.: 0/108 mm Pitch angle min/max: 5°/84° Pitch diameter (1:1 ratio): 152 mm pitch diameter (10:1 ratio): 216 mm Diametral pitch (finest/coarsest): 1.3/8.5 Mod. Face width gear wheel max.: 35 mm speeds:: 98-286 weight of the machine ca.: 6577 kg dimensions of the machine ca.: 1560 x 2140 x 2200 mm Equipment/accessories: -Cutting tools -Spacer angle -Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cone distance min./max.: 0-108 mm Pitch angle min/max: 5°/84° Control: GE Fanuc Series 0-GC Pitch diameter (1:1 ratio): 152 mm pitch diameter (10:1 ratio): 216 mm Diametral pitch (finest/coarsest): 1.3/8.5 Mod. Face width gear wheel max.: 35 mm Knife spindle - Speed range: 41-121 U/min working spindle speed range: 0-33.33 U/min weight: 9025 kg dimensions of the machine ca.: 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: -Knife -Chip conveyor -Technical documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The machine is in good technical condition, testing is possible by prior arrangement.

This 5-axis Gleason PFAUTER G320 CNC + Promot Automation was manufactured in 2001. It features a Siemens 840 control unit, a maximum workpiece diameter of 380 mm, and a module range of 0.5-7.0. The system includes Promot Automation handling, a robotics system, and a cooling belt system. If you are looking to get high-quality gear grinding capabilities consider the Gleason PFAUTER G320 CNC machine we have for sale. Contact us for more information about this machine.

max. wheel diameter: 160 mm gear width: 355 mm max. module: 4,5 min. module: 0,5 centre distance: 450 mm total power requirement: 11 kW weight of the machine ca.: 3,8 t dimensions of the machine ca.: 2x17,1,6 m Wheel diameter - max. 160.175 mm Wheel width 355 mm Module - max. 4.5 Spindle bore 75 mm Center distance 410 mm Number of teeth - min. 2, 3 Cutter diameter max. 115 mm Cutter length max. 105 mm Center distance between milling cutter and workpiece - max. 138 mm Center distance between milling cutter and workpiece - min. 30 mm Milling head - swivels 120 ° Milling cutter speeds 70 - 400 rpm Axial feeds 0.25 - 4.0 mm/rev Radial feeds 0.09 - 1.5 mm/rev Total power requirement approx. 9.5 kW Machine weight approx. 3.5 t Space requirement approx. 1730x1400x1440 mm Equipment/accessories: - Changing wheels - milling arbors - Clamping device Dra8M7 - documentation The data for this ad wa ...
