Manufacturer:
(Category: 101-7)
used
CNC machining centre for doors, windows and façade elements. Swivel worktop, with pneumatic rotation in the angular range -90°/0°/+90°. Machining at any intermediate angles. Equipped with a 4 kW electrospindle with 24,000 revolutions per minute and an automatic tool change system with 6 positions from the magazine. X/Y/Z axis interpolation numerically controlled. 11.5'' color monitor (touch screen) with simplified Windows-based graphics. Possibility of machining profiles longer than the overall dimensions of the machine. Feed of the X/Y/Z axes via brushless Yaskawa motors. 4 pneumatic clamps manually positioned. Drip cooling. Feed on linear guides. Zero Profile Reference Bumper – Left Side. No.6 ISO 30. Options on request: tool set + flat cutter with a diameter of Ø 120 mm. Barcode reader. ISO 30 mount. Set of 6 ER 32 clamps per spindle (No. 1 Ø 3 mm – No. 1 Ø 5 mm – N ...
used
Ref. -No.: 10339Manufacturer: AGIE CHARMILLESYear of construction: 2008Type of control: CNCControl: Heidenhain iTNC 530 (2P)Storage location: HalberstadtCountry of origin: Schweizserial number: 107.20.00.040 X-Travel: 650 mmY-Travel: 600 mmZ-Travel: 500 mmMain spindle drive power: 30/39 kWMain spindle speed range: 20.000 RPMTable Dimensions (Lengthxwidth): 800 x 600 mmTable Load: 500 kgMax. Workpiece Weight: 6,5 kgTool change time (chip-to-chip): 7 sMax. Tool Length: 300 mmMax. Tool Diameter: 130 mmTool change time: 1,5 sWorkpiece Diameter At Full Load: 80 mmWorkpiece Diameter With 2 Vacant Positions: 130 mmT - groove width: 14 mmT - slot spacing: 63 mmTool Taper: HSK-A63 Numbers Of Tools In Magazin: 60 Tool changer: CT-60 Feed Speeds X/Y/Z Axis: 40/40/30 mm / minFeed Capacities X/Y/Z: 4/4/6 NFurther information:Laser tool measuring system Type = BLUM laser systems type P87.0634belt filt ...
used
Key data: 500 mm, 250 mm, 400 mm
Machine Details Stock-No. 1105-03925 Type of machine milling machining centers - universal Make AKIRA SEIKI Type RMV 250 RT 5 AXIS Year of manufacture 2014 Type of control CNC Storage location FRANCE Country of origin Taiwan Delivery time immediately Freight basis ex stock Dreieich Technical details X-Travel 500 mm Y-Travel 250 mm Z-Travel 400 mm table-size ROUND TABLE 250 mm spindle taper ISO HSK 63 spindle turning speed range 45 - 12000 rpm spindle drive motor 11 kW tool change unit 24 CNC-control FANUC OIMD voltage 380 V max. table load 200 kg Throat 380 mm total power requirement 17 kVA Weight of the machine approx. 5 t dimensions of the machine approx. 3.5x 2.5x 2.60 m Additional information AKIRA SEIKI TYPE RMV 250 RT FROM YEAR 2014 - coolant equipment TROUGHT THE SPINDLE 20 BARS CGIP CO? VOYER 5 AXIS MACHINE IN GOOD CONDITION
used
Key data: 600 mm, 400 mm, 600 mm
Control Heidenhain iTNC 530 Travel x/y/z 600 mm / 400 mm / 600 mm Tool changer with 24 positions Table clamping surface / max. table load 450 mm x 750 mm / 500 kg Spindle speed range / tool holder 50 – 9,000 rpm / SK 40 Rapid traverses up to 40 m/min Total power requirement / machine weight 13 kW / 3.2 t Machine dimensions L/W/H 2.7 m / 1.8 m / 2.8 m Accessories: Chip collection device, electronic handwheel, IKZ, 3D touch probe
used
Key data: 460 mm, 600 mm, 400 mm
5-Axis CNC Machining Center Alzmetall GS 600 E/5 Year of construction: 2019 Control: Heidenhain TNC 640 x-travel: 460 mm Y-travel: 600 mm z-travel: 400 mm a-travel (swivel axis): -140 / +140 c-travel (axis of rotation): 360° Table surface: Ø 320 mm Spindle: HSK 63 A Rapid traverse: 30 m/min Speed: 18,000 rpm Tool changer: 76x Space requirements: 2.5 x 2.2 x 2.2 m Weight: Approx. 7,000 kg
used
Vertical machining center ARES SEIKI S6040 with roto pallet Make: ARES SEIKI Model: S6040 YEAR 2019 X-AXIS TRAVEL 600 mm Y-AXIS TRAVEL 400 mm Z-AXIS TRAVEL 500 mm DISTANCE SPINDLE NOSE-TABLE 180-680 mm RAPID FEEDS X-Y-Z 36 – 36 – 48 m/min SPINDLE 12000 rpm; 5,5-7,5 kW; ISO 40 – DIN PALLET N.2 ; 700X400 mm MAX ADMITTED LOAD 250 Kg TOOL MAGAZINE CHAIN-TYPE ; 24 POS CONTROL UNIT MITSUBISHI M80 WEIGHT 6600 Kg OVERALL DIMENSIONS 3660 x 2585 x 2780 mm ACCESSORIES HIGH PRESSURE COOLANT ; SWARF CONVEYOR ; PAPER FILTER ; PORTABLE HANDWHEEL ; ETHERNET PORT ; RS 232 SERIAL PORT NOTE MACCHINA COMPLETA DI N.13 CONI PORTAPINZA; N.1 CONO PORTAFRESA; N.1 TASTATORE 3d.
new
Machine vice ATS NC-160VH Year of construction 2024 Jaw width: 160 mm Jaw height: 58 mm max. span inside: 300 mm max. wingspan outside:480 mm with pull-down function Clamping force: 40kN Weight: 60 kg Delivery possible Price per piece
new
Machine vice ATS NC-200VH Year of construction 2024 Jaw width: 200 mm Jaw height: 63 mm Total height: 173 mm Total length: 700 mm max. wingspan inside: 330 mm max. wingspan outside:540 mm with pull-down function Clamping force: 45kN Weight: 81 kg Delivery possible Price per piece
new
CNC control: Heidenhain TNC640, 19" touchscreen -Stainless steel cabin floor -Stainless steel cover under machine doors -Enclosure of the pumps -Chip rinsing system -Double arm tool changer with 30 places -Direct drive 15,000 rpm -complete coolant device (coolant nozzles distributed in a ring around the spindle) -Chip conveyor (screw) -Workspace lighting -3 colors signal light -Compressed air and coolant gun -Full fairing -Suit bolt ISO 7388/B Type B, 6 pcs. -Blow-out device (spindle) -Emergency off button and button, "Release tool" on the spindle -Portable electronic handwheel -Limit switch -Transport device (for crane transport) -User Manual -CE Declaration of Conformity Specifications: Workbench: Clamping surface: 800 x 550 mm T-Benefit: Number/ Width/ Distance: 5/18/100 mm workpiece weight: 700 kg Travel X-axis: 650 mm Y-axis: 600 mm Z-axis: 620 m ...
used
Key data: 2 mm, 600 mm, 600 mm
AXA DBZ 2/50 double workstation machining center, Year of construction 2012, Siemens 840 control system, Travel X/Y/Z 2x800/600/600 mm, Tool changer 16-speed, Tool holder SK 50, Spindle speed up to 4,000 rpm, Milling spindle - hollow shaft motor water-cooled, you. measuring systems, Conveyor Heat exchanger control cabinet, Oil mist lubrication, Rittal refrigeration system,
used
CNC vertical travel stand machining center with 4th axis Table size 2380 x 5000 mm. Movement x-axis 1760 mm. Movement y-axis 500 mm. Movement z-axis 780 mm. table load 800 kg Number of tools in the magazine 36 pieces. Maximum spindle speed 10,000 1/min. Tool cone DIN 69871A-40. CNC control Heidenhain TNC 430 M. If you have any questions about the machine, as well as a scheduling for the inspection, we ask you to contact us by phone or e-mail.
used
Ref. -No.: 10201Manufacturer: AXAYear of construction: 2007Type of control: CNCControl: Siemens 840DStorage location: HalberstadtCountry of origin: DeutschlandX-Travel: 5000 mmY-Travel: 600 mmZ-Travel: 800 mmMachine length: 9400 mmMachine width: 3500 mmMachine Height: 3300 mmTable Dimensions (Lengthxwidth): 6325 x 1050 mmSwivelling: +/-90 °Numbers Of Tools In Magazin: 120 Turning Speeds: 30-9000 RPMTool changer: SK 50 Drive Capacity - Spindle Motor: 45 kWWeight Of The Machine Ca.: 23 tTool change time: 6 sVertical working height: 0-740 mmWorking height horizontal: 250-1050 mmSpace requirement (LxWxH): 11000 x 5090 x 3300 mmFeed rate: X/Y/Z: 40 m / min
used
x-travel: 620 mmy-travel: 520 mmz-travel: 460 mmCNC-control: iTNC 640 HEIDENHAINTable dimensions: Ø 650 mmmax. table load: 300 kgspindle taper: SK 40 spindle turning speed range: 12.000 U/minfeed range: 1 - 20.000 mm/minrapid traverse: 36 m/mincoolant: IKZ 30 barvoltage: 400 Vtotal power requirement: 25 kVAweight of the machine ca.: 9,2 tdimensions of the machine ca.: 2,35 x 4,15 x 2,95 mchip conveyor: 2,60 x 1,65 x 1,20 mOil cooler: 0,50 x 0,70 x 1,45 mwater cooling unit: 0,70 x 0,70 x 0,80 m- Serial-No.: 6LUD00185- Control ON: 10.918 h- Spindle ON: 2.725 h- Control: HEIDENHAIN iTNC 640- 3-D touch probe HEIDENHAIN TS 740- Travel distance B-Axis 50º/+110º,C-Axis 360º- Internal coolant supply through spindle 30 bar- Electr. handwheel- Laser tool measurement- chip conveyor- suctionThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 1020 mm, 510 mm, 510 mm
Machine Details Stock-No. 1105-03962 Type of machine Machining Center - Vertical Make BEMATO Type BMT 1020CJ Year of manufacture 2003 Type of control CNC Storage location HAGUENAU Country of origin Taiwan Delivery time IMMIDIATELY Freight basis EX WORK Price Technical details x-travel 1020 mm y-travel 510 mm Z-Travel 610 mm table-size 1070 X 510 mm spindle taper BT 40 number of spindle speeds 80 - 8000 min-1 tool piece magazine with 20 seats total power requirement 20 kVA Additional information FANUC OMD CONTROL
used
Machine Details Stock-No. 1105-03755 Type of machine CNC Lathe - Inclined Bed Type Make BIGLIA Type B 501 MB Year of manufacture 2002 Type of control CNC Storage location HAGUENAU FRANCE Country of origin ITALY Delivery time by arrangement Freight basis At Place of the machine Price Technical details turning diameter 500 mm turning length 500 mm control FANUC 18 IT Spindle Bore: 60 mm turning speed range - spindle 5000 rpm Feed Range - Turret / Stepless 1 - 12000 mm/min Rapid Traverse 20 / 12 m/min tool taper direct recording total power requirement 20 kW Weight of the machine approx. 5 t dimensions of the machine approx. 4900x1800x1800 mm Additional information CNC FANUC 18 IT 3AXIS MACHINE
used
Machine Details Stock number 1105-03797 Machine type machining center - vertical Make BRIDGEPORT Type VMC 600 2 DIGITAL Year of construction 1999 Control type CNC Control HEIDENAHAIN TNC 426 PB Storage location FRANCE Country of origin UK Delivery time immediately Freight base from stock HAGUENAU FRANCE Technical details x-travel 600 mm y-travel 510 mm z-travel 600 mm Control HEIDENAHAIN TNC 426 PB Table clamping surface 800 X 500 mm Rapid traverse 30/30/30 m/min Speed range 40- 1000 rpm Drive power - milling spindle 13 kW Number of tools in the magazine 22 pieces Information 3-axis CNC machining center m Accessories: HEIDENHAIN TNC 426 PB - Synchronized tapping - flat guides in all three Axes - RS-232 interface SPAENEFOEDERER
used
Key data: 760 mm, 610 mm, 610 mm
Bridgeport XR 760 Machine 1 Year of construction 2012, Control Heidenhain iTNC 530, Travel X/Y/Z 760/610/610 mm, Tool changer 30 times, Mounting SK 40, Spindle speed up to 12,000 rpm, Blowing air through the spindle, Gxayoni IKZ 20 bar, Clamping surface table 1000 x 600 mm, max. table load 700 Kg, Scraper tape chip conveyor, 3 D touch probe, Toolsetter, infrared receiver, Radiator Thermal compensation, new spindle 02/2024
used
Key data: 760 mm, 610 mm, 610 mm
Bridgeport XR 760 Engine 2, Year of construction 2012, Control Heidenhain iTNC 530, Travel X/Y/Z 760/610/610 mm, Tool changer 30 times, Mounting SK 40, Spindle speed up to 12,000 rpm, Blowing air through the spindle, IKZ 20 bar, Clamping surface table 1000 x 600 mm, max. table load 700 Kg, Scraper tape chip conveyor, 3 D touch probe, Toolsetter, infrared receiver, Radiator F3goue9 Thermal compensation, Spindle replacement 07/2023
used
aschinella details Warehouse number 1105-03656 Machine Type Machining Center - Vertical Make BROTHER Type TC 211 Year of construction 1987 Control type CNC Storage location HAGUENAU Country of origin Japan Delivery time immediately Freight base freely loaded from stock Price Technical details x-travel 420 mm y-travel 220 mm z-travel 200 mm Spindle cone 30 NT Speed range 1-4000 rpm Spindle motor 3.5 kW Table clamping surface 600 x 300 mm Number of tools in the magazine 10 pieces Rapid traverse 20 / 15 m/min Information WELL PRESERVED MACHINE
used
Key data: 300 mm, 220 mm, 200 mm
Table 400x200 , 10-10,000 rpm , BT 30 , 3.5 kW
used
Key data: 300 mm, 220 mm, 200 mm
Table 400x200 , 10-10.000 rpm , BT 30 , 3.5 kW , Tool turret with 10 places , 4th axis
used
x-travel: 1600 mmy-travel: 1250 mmz-travel: 1800 mmControl: Siemens 840D b-axis: 36000 x 0,001 °spindle speed max.: 6000 U/mindrive capacity: 60 kWtool taper: HSK 100-A length in total: 350 mmdiameter: 150 mmmax. boring power axial: 37 kWmax. milling power radial / at tool length: 10 kW / 150 mmmax. tool weight: 30 kgtool clamping power: 40 kNtotal power requirement: 100 kWdimensions of the machine ca.: 9,2 x 8,8 x 6,3 mThis machine is sold together with:- another identical machine type MCR 120/80, year 2007,- two further horizontal machining centres, Burkhardt+Weber, type MCX 900, year 2007 (our stock no. 03253),- and a Fastems rack system.All four machines are connected to this Fastems system.Equipment / Accessories:- tool changer with rack magazine, 208 places- max. tool-Ø: bar tool Ø 750 mm- mechanical borer breakage control upto 750 mm- pallet changer 2-fold with 2 pallets, pall ...
used
x-travel: 1600 mmy-travel: 1400 mmz-travel: 1500 mmControl: Siemens 840D b-axis: 360000 x 0,001 °spindle speed max.: 6000 U/mindrive capacity: 37 kWtool taper: HSK 100-A length in total: 350 / 1200 mmdiameter: 150 mmmax. boring power axial: 37 kWmax. milling power radial / at tool length: 10 kW / 150 mmmax. tool weight: 30 / 60 kgtool clamping power: 40 kNtotal power requirement: 80 kWdimensions of the machine ca.: 9,6 x 8,5 x 5,5 mThis machine is sold together with:- another identical machine type MCX 900, year 2007,- two further horizontal machining centres, Burkhardt+Weber, type MCR 120/80, year 2007 (our stock no. 03258),- and a Fastems rack system.All four machines are connected to this Fastems system.Equipment / Accessories:- tool changer with rack magazine, 298 places- max. tool-Ø: bar tool Ø 750 mm- mechanical borer breakage control upto 1200 mm- pallet changer 2-fold with 2 ...
used
Key data: 450 mm, 350 mm, 380 mm
X-axis: 450 mm Y-axis: 350 mm Z-axis: 380 mm Work table: 700 x 320 mm Spindle speeds: 10,000 rpm. Spindle Adapter: ISO40 Tool changer: 12 places CNC Control: Siemens Shopmill Equipped with: - Spindle cooling - ISO40 tools -Vice Country of origin: Taiwan Motor power: 8.5 kW Machine LxWxH: 2450 x 1550 x 2200 mm Machine weight: 2000 kg
used
CNC control Sinumerik 810 M Travel x/y/z 400 mm / 400 mm / 630 mm Tool holder SK 40 Max. spindle speed 10,500 rpm Fourth / fifth axle with Peiseler NC – table AWU 160 with counter holder Machine weight 6 t Accessories: Chip conveyor, six SK 40 ER 32 tool holders incl. clamping bolts, without cutting tools
used
Machine Details Warehouse number 1105-03697 Machine Type Machining Center - Vertical Brand CHIRON Type FZ 08 S Year of construction 1998 Control type CNC Storage location HAGUENAU Country of origin Germany Delivery time immediately - pre-sale Freight base from stock HAGUENAU FRANCE Technical details x-travel 300 mm y-travel 250 mm z-travel 250 mm Total power requirement 8 kW Machine weight approx. 1.8 t Information very well maintained 3 axles BZ CHIRON FZ 08 with FANUC 18 I M - speeds up to 10000 rpm - rapid traverses up to 60 m ! HSK 30
used
Machine Details Warehouse number 1105-03697 Machine Type Machining Center - Vertical Brand CHIRON Type FZ 08 S Year of construction 1998 Control type CNC Storage location HAGUENAU Country of origin Germany Delivery time immediately - pre-sale Freight base from stock HAGUENAU FRANCE Technical details x-travel 300 mm y-travel 250 mm z-travel 250 mm Total power requirement 8 kW Machine weight approx. 1.8 t Information very well maintained 5 axis BZ CHIRON FZ 08 with FANUC 21 M - speeds up to 10000 rpm - rapid traverses up to 60 m ! HSK 30 integrated with 4/5 axe peiseler SPAENEWANNE
used
x-travel: 300 mmy-travel: 250 mmz-travel: 250 mmtable surface area: 2 x 550 x 300 mmspindle taper: HSK-A 32 spindle taper: DIN 69893 spindle turning speed - stepless: 20 - 15.000 U/minspindle motor: 7,4 kWmax. torque on the spindle: max. 23 Nmspindle throat: 200 - 450 mmdistance table - lower edge spindle: 170 - 420 mmpower feed x/y/z: 2000 / 2000 / 3000 Nrapid traverse longitudinal and cross: 40 m/minrapid traverse vertical: 60 m/mincoolant tank: 100 lcontrol: SIEMENS, 840 D total power requirement: kWweight of the machine ca.: 2,2 tdimensions of machine L x W x H: 2,75 x 1,45 x 2,25 mAccessories: various tool fixtures, coolantThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Machine details Bearing number 1105-03038 Machine type Machining Center - Vertical Make CHIRON Type FZ12 WM Built in 1997 Control type CNC Warehouse FRANCE Country of origin Germany Delivery time immediately Freight base freely loaded from location Technical details x-path 550 mm y-path 300 mm z-way 425 mm Tool holder SK 40 Control Siemens 810 Total power requirement 12 KVA Machine weight approx. 4.0 t Transport dimensions LxWxH 2.05x3.05x3.0 m Information Machine is located in the technical GOOD CONDITION with interchangeable plate 2 X 4th axis PEISELET PT 160 WITH SIEMENS 810 WITH HYDROLIC CLAMPING IN THE TABLE 24 FACH WERCKZEUGWECHSLER
used
Machine Details Stock-No. 1105-03574 Type of machine Machining Center - Vertical Make CHIRON Type FZ12 WM Year of manufacture 1995 Type of control CNC Storage location HAGUENAU Country of origin Germany Delivery time immediately Freight basis EXW -free on truck Technical details x-travel 550 mm y-travel 300 mm z-travel 425 mm tool taper SK 40 control Siemens 810 total power requirement 12 KVA weight of the machine approx. 4.0 t transport dimensions LxWxH 2,05x3,05x3,0 m Additional information chiron fz 12 wm with changeable plate with 2 x 4. axis PEISELER WIth CONTROL SIEMENS 810 TOOLS SK 40
used
Machine Details Warehouse number 1105-03698 Machine Type Machining Center - Vertical Brand CHIRON Type FZ 15 K S 5 AXIS Year of construction 2001 Control type CNC Control HEIDENHAIN TMC 530 Storage location FRANCE Country of origin france Delivery time ready for shipment Freight base EX WORK Price Technical details x-travel 550 mm y-travel 400 mm z-travel 425 mm Control HEIDENHAIN TMC 530 Table clamping surface 600 X 350 mm Tool holder ISO SK 40 Spindle speeds - infinitely variable 20 - 12,000 rpm Feed infinitely variable 0 - 60,000 mm/min Rapid traverse 60 m/min Feed force X/Y axis 5,000 N Feed force Z-axis 10,000 N Tool magazine: 20 Tool diameter max. 65 mm Tool diameter with 2 free spaces 150 mm Tool length - max. 220 mm Spindle diameter in the vord. Bearing 70 mm Torque at the spindle max. 180 Nm Distance spindle/table 280 - 705 mm Distance spindle/ ...
used
Machine Details Stock number 1105-03839 Machine type machining center - vertical Brand CHIRON Type FZ 15 W Year of construction 2004 Control type CNC SIEM 840D controller Storage location FRANCE Country of origin france Delivery time ready for shipment Freight Base EX WORK Technical details x-travel 550 mm y-travel 400 mm z-travel 425 mm SIEM 840D controller Table clamping surface 2x 660 x 400 mm Tool holder ISO SK 40 Spindle speeds - infinitely variable 20 - 12,000 rpm Feed infinitely variable 0 - 60,000 mm/min Rapid traverse 60 m/min Feed force X/Y-axis 5,000 N Feed force Z-axis 10,000 N Tool magazine: 20 Tool diameter max. 65 mm Tool diameter with 2 free spaces 150 mm Tool length - max. 220 mm Spindle diameter in the front. Bearing 70 mm Torque at the spindle max. 180 Nm Distance spindle/table 280 - 705 mm Spindle/stand distance 480 mm Milling capacit ...
used
Machine Type: CNC Machining Center Manufacturer: Chiron Type: FZ08 KW Magnum Year of construction: 2006 Condition: used / ready for use Offer will only be sent if a complete imprint is provided! Price .VB Location Warstein , Germany Reference MV-CHI-1123 DESCRIPTION We offer you a used CNC machining center from the manufacturer Chiron. Specifications Control Siemens 840D Spindle 15,000 rpm Travel: X 450 / Y 270 / Z 310 Tool change HSK40/ 24 positions Chip conveyor / coolant system 500l Weight approx. 3.5t Complete Documentation Special features / new spindle motor at the end of 2021 (approx. 14,000 euros). Activated option of bar machining from the manufacturer Chrion / incl. precast slide and program-controlled connection to the table (pneumatic) on each side. Condition: well-maintained and maintained Availability: immediately The machine can ...
used
Machine control unit and electric cabin retrofitted with Siemens 828D Table size 2280x450 mm Spindle speed 8000 rpm Spindle taper : SK40 Travel X,Y,Z 2000,400,425 mm Machine size 3900x2450x2800 mm Machine weight 6700 kg
used
Machine Details Stock-No. 1105-03827 Type of machine Machining Center - Vertical Make CINCINNATI Type ARROW 750 Year of manufacture 1997 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Great Britain Delivery time immediately Freight basis EX WORKS Technical details X-Travel 762 mm Y-Travel 380 mm Z-Travel 510 mm Table-size 865 x 510 mm spindle taper ISO 40 spindle turning speed range 60 - 8000 rpm Rapid traverse 24 m/min spindle drive motor 9 kW Tool Change Unit 21 fold CNC-control HEIDENHAIN TNC 426 voltage 380 V table load 750 kg Throat 550 mm coolant yes total power requirement 30 kVA weight of the machine approx. 4.3 t Additional information - control: HEIDENHAIN TNC 426 - Coolant Equipment - machine lamp Lot Off Tools
used
CNC Vertical Maintenance Center Cincinnati CFV-1050i Y.O.M. 2008 Heidenhain iTNC530 Control Table size 1,120 x 600 mm Travel X/Y/Z 1.050/540/720 mm Max table balast 1,000 kg Rapid speed X/Y/Z 36 m/min Spindle motor 12/16 kW Max spindle speed 10,000 rpm Spindle cone SK-40 Tool changer with 30 stations Glass scales X/Y axes Spindle cooler Termical Comp. Cooling by the spindle, 10 bar Pushbutton Renishaw TS27R Extended Z-axis 127-847 mm Conveyor Heidenhain SmartT.NC Handwheel Tools Losma suction
used
Machine Details Stock-No. 1105-03789 Type of machine Machining Center - Vertical Make CINCINNATI Type sabre 1250 Year of manufacture 1995 Type of control CNC Storage location HAGUENAU Country of origin UK Delivery time immediatly Freight basis FOT Technical details X-Travel 1270 mm Y-Travel 762 mm Z-Travel 820 mm spindle 11 kW spindle turning speed range 60-8,000 rpm toolpiece magazine: chain magazine 21 pieces tool taper DIN 69871 ISO 40 table-size 1,370 x 760 mm control fanuc om total power requirement 30 kVA weight of the machine approx. 9 t Additional information FANUC OM Technical details and information subject to amendments and errors.
used
Machine Details Stock number 1105-03824 Machine type machining center - vertical Make CINCINNATI Type SABRE 500 Year of construction 1995 Control type CNC Storage location HAGUEANU FRANCE Country of origin Great Britain Delivery time immediately Freight base AB HAGUENAU FRANCE Technical details x-travel 500 mm y-travel 510 mm z-travel 510 mm Table size 950 x 520 mm Spindle holder ISO 40 Spindle speeds 60 - 6000 rpm Spindle drive motor 5.5 kW Rapid traverse 24 m/min Tool changing device 21-fold CNC control HEIDENHAIN TNC 415 Operating voltage 380 V table load 750 kg Projection 550 mm Total power requirement 30 kVA Machine weight ca. 4 t Information - Control: HEIDENHAIN 415 - Coolant device - Machine light
used
Machine Details Stock number 1105-03832 Machine type machining center - vertical Make CINCINNATI Type SABRE 500 Year of construction 1995 Control type CNC Storage location FRANCE Country of origin Great Britain Delivery time immediately Freight base EX LOCATION HAGUENAU Technical details x-travel 500 mm y-travel 510 mm z-travel 510 mm Table size 950 x 520 mm Spindle holder ISO 40 Spindle speeds 60 - 6000 rpm Rapid traverse 24 m/min Spindle drive motor 5.5 kW Tool changing device 21-fold CNC control FANUC OM Operating voltage 380 V table load 750 kg Projection 550 mm Total power requirement 30 kVA Machine weight ca. 4 t Information - Control: HEIDENHAIN 415 - Coolant device - Machine light
used
Machine Details Stock-No. 1105-03852 Type of machine milling machining centers - vertical Make DAH LIH SONGS Type LIEDER MCV 2600 Year of manufacture 2015 Type of control CNC Storage location FRANCE Country of origin taiwan Delivery time immediately Freight basis free loaded on truck, ex works Price Technical details X-Travel 2600 mm Y-Travel 870 mm Z-Travel 760 mm table surface area 2800 x 970 mm control HEIDENHAIN TNC 530 spindle turning speed range 12000 rpm spindle drive 15 kW tool adaptor BT 40 Internal Coolant System Feed 20 bar Feed 10 m/min Rapid Traverse 20/20/30 m/min total power requirement 25 kW Additional information used vertical machinig centre witH dual arm toolchanger BT 40 HEIDENHAIN TNC 530 - Dual toolchanger - synchronised tapping - internal coolant with filter - Spindle Oil Cooling 32 TOOLS MAGASIN COOLING TROUGHT THE SPINDLE 20 BAR ...
used
3-axis machining center X: 560 mm Y: 500 mm Z: 390 mm Rapid traverse rate: 4 m / min Table load: 800 kg Speed range: 4000 RPM Spindle retainer: SK 40 Headstock speed range: 4000 RPM Spindle drive: 4 kW Control: Dialog 11 Electr. Handwheel Coolant system direct measuring system Documentation Total power: 19 kW Machine weight: approx. 2.8 kg Dimensions (W x D x H): 3.66 x 3.5 x 2.1 m
used
Key data: 560 mm, 600 mm, 600 mm
- 3D control Siemens 840D Solution Line - Reinforced main drive: Integrated motor spindle SK 40 Spindle speed up to 18,000 rpm incl. active cooling - Travel: X= 560, Y= 600, Z= 600 mm - Tool holder SK 40 - Tool clamping according to DIN 69872 - Tool changing device Vertical chain magazine with 60 magazine slots - NC rotary table with pallet carrier Permissible load 500 kg - Rotary pallet changer 2 pallets 400 mm x 400 mm with T-slots according to DIN 55201-A2 - Coolant tank 500 l -Conveyor Tool measurement in the working area Fabr. Blum Laser NT-Hybrid Automatic retraction of the measuring unit in a protected enclosure Tool length and diameter measurement horizontal/vertical Production package Coolant system 980 litres, paper belt filter IKZ 40 bar/23 l/min through the centre of the spindle (AD) Roof flushing of the working area (Figures as theoretica ...
used
Description: SPECIFICATIONS Brand: Deckel Maho Type: DMC 80 U hi-dyn CNC Brand: Siemens CNC Type: 840D Year of construction: 2003 Table width: 800 mm Table width: 630 mm Number of pallets: 2 Displacement: X = 800 mm, Y = 700 mm, Z = 600 mm Spindle drive: HSK-A 100 Tool changer: 60 positions Maximum pallet load: 800 kg Clamping transport Machine dimensions: 4600 x 2400 x 2700 mm Machine weight: 10,500 kg Measuring probe: Heidenhain TS 642 Approx. Onsite Dimension. (l x w x h): 4,600 x 2,400 x 2,700 mm, weight approx.: 10,500 kg
used
Description: Serial number: 11430000953 Spindle hours: 17445 Feed rate X-, Y-, Z-axis: 20 - 15000 mm/min Rapid traverse X-, Y-, Z-axis: 15 m/min Path measuring system: Resolution X-, Y-, Z-axis: 0.001 mm Position tolerance X-, Y-, Z-axis: 0.01 mm Travel: X-axis: 780 mm Y-axis: 560 mm Z-axis: 560 mm Work spindle: HSK-A63 Number of magazine slots: 60 Max. Tool diameter when all positions are occupied: 80 mm With free adjacent positions: 160 mm Max. Max. tool length from spindle nose: 315 mm Max. tool weight: 8 kg Tool weight: 8 kg Pallet changer: Number of pallets: 2 Permissible load of the pallet changer: One side: 400 kg Both sides: 800 kg With NC rotary table Clamping surface, pallet: 500 x 630 mm With T-slots Permissible load of the table: 400 kg Rotary feed: 7200°/min Max. table plate revolutions: 30 mm Rotations of the table top: 30 rpm Spindle speed: 12000 rpm The accessories or cl ...
used
Travels: X-axis 2,200 mm; Y-axis 560 mm; Z-axis 720 mm Control 840 D Powerline ShopMill Siemens Main Spindle: Speed range - main spindle 20 - 12,000 min/-1 Drive power - main spindle 35 / 25 kW Max. torque 130 / 87 Nm Tool holder SK 40 Inner coolant supply 40 bar Workbench: Table clamping surface 2,600 x 600 mm max. table load 2,200 kg Tool changer: Number of tool slots 30 pos. max. tool length 300 mm max. tool weight 6 kg max. tool diameter 80 / 125 mm Spindle hours: approx. 13,326 h Switch-on hours: ca.36167 Feeds: Feed speed 20,000 mm/min Input fineness 0.01 mm Rapid traverse ( X / Y / Z ) 100 / 50 / 50 m/min Total power requirement 60 kVA Machine weight approx. 12.5 t Space requirement approx. 6.0 x 3.7 x 2.9 m Documentation Conveyor Coolant system High-pressure cooling Inner coolant supply 40 bar electr. Handwheel Workspace lighting
used
Key data: 1250 mm, 710 mm, 710 mm
5-Axis CNC Machining Center Lid Maho DMU 100 monoBLOCK Year of construction: 2009 Control: Heidenhain iTNC 530 x-travel: 1250 mm Y-travel: 710 mm z-travel: 710 mm Speed: 18,000 rpm Drive power main spindle: 15 / 10 kW Max. torque: 130 / 87 Nm Tool changer: SK 40 Swivel man.: +12° / -91° Table clamping surface: 1500 x 800 mm Max. table load: 1100 kg Number of tool slots: 32 pos. Chip-to-chip changeover time: 11.0 sec. Rapid traverse (X/Y/Z): 30 m/min Feed speed max.: 30,000 mm/min Total power requirement: 40 kW Dimensions: 6000 x 5000 x 2700 mm Weight: Approx. 10,000 kg
used
Key data: 1250 mm, 710 mm, 710 mm
5-Axis CNC Machining Center Lid Maho DMU 100 monoBLOCK Year of construction: 2007 Control: Heidenhain iTNC 530 x-travel: 1250 mm Y-travel: 710 mm z-travel: 710 mm Speed: 18,000 rpm Drive power main spindle: 15 / 10 kW Max. torque: 130 / 87 Nm Tool changer: SK 40 Swivel man.: +12° / -91° Table clamping surface: 1500 x 800 mm Max. table load: 1100 kg Number of tool slots: 32 pos. Chip-to-chip changeover time: 11.0 sec. Rapid traverse (X/Y/Z): 30 m/min Feed speed max.: 30,000 mm/min Total power requirement: 40 kW Dimensions: 6000 x 5000 x 2700 mm Weight: Approx. 10,000 kg
used
x-travel: 1.250 mmy-travel: 880 mmz-travel: 800 mmcontrol: TNC 430 HeidenhainMain spindle:: turning speed range - main spindle: max. 12.000 min/-1power capacity - main spindel: 15 / 10 kWmax. Torque: 500 Nmtool taper: SK 40 work table:: table surface area: 1.500 x 1.050 mmmax. table load: 2.500 kgnumber of T-slots: 10 T-slot - width: 18 H7 mmT-slot - distance: 100 mmTool-Presetter:: number of toolpositions: 60 pos.max. tool diameter: 80 mmmax. tool-dia with free toolbox: 160 mmmax. tool length: 315 mmmax. tool weight: 8 kgmax. total weight: 100 kgfeeds:: rapid traverse ( X / Y / Z ): 15 m/minfeed speeds: 10.000 mm/mintotal power requirement: 29 kWweight of the machine ca.: 16,0 tdimensions of the machine ca.: 7,0 x 5,0 x 3,3 mDocuments: Chip conveyor: Coolantsystem: Automatic Tool Changer: elektr. hand wheel: CNC - Machining Center VerticalDECKEL MAHO - DMU 125 TThe data for th ...
used
Universal machining center Manufacturer Lid Maho Type DMU 35M Control Siemens 810 D Shopmill Travel : 350x240x340mm Speed :20-6300rpm Year of construction 2000 Spindle speeds 20-6300rpm Feed rates 2-5000mm/min Table 400x280mm Motor 5,5Kw Longitudinal travel (X,Y,Z) 350x240x340mm Machine weight ca 1600kg Tool holder SK 40 Dimensions 2000x2000x2000mm Machine has milled 100% only aluminum. Machine was only used when needed and did not run in shifts. Technical and geometrical in top condition.
used
Description: Control: 426 Heidenhain 5 axes (3+2) traverse path: X-axis: 500 mm Y-axis: 400 mm Z-axis: 400 mm  , Rapid traverse: 12m/min Max. workpiece weight: 200 kg Rotary table: Clamping surface: 700 x 500 mm Distance of T-slots / size: 63 /14 H7 mm Rotation range: 360 Table clamping: mechanical Swivel range: +95 / -10 Spindle: Max. Speed 9000 rpm Power: 13 kW Spindle mounting: SK 40 Number of tools: 16 Approx. Onsite Dimension. (l x w x h): 2,100 x 2,000 x 2,400 mm, weight approx.: 3,500 kg
