mori seiki nv used for sale

Vertical Machining Center MORI SEIKI GV-503/5ax x-travel 610 mm y-travel 765 mm z-travel 460 mm pallet table size 550 x 550 mm taper BT 40

A Mori Seiki CNC turning and milling center with counter spindle including automation is available. Tool turrets: 3, tool stations: 3×16, live tools: all stations, X-axis travel: 210mm, Z1/Z2/Z3-axis travel: 300mm/810mm/300mm, main spindle bore: 55mm, spindle speed: 6000rpm, automation robot: LR Mate 200iC 5L, payload: 5kg, reach: 892mm, repeatability: 0.03mm. Machine dimensions X/Y/Z: approx. 3800mm/2700mm/2500mm, weight: approx. 8900kg, control: Fanuc 31i-A, power-on hours: 101035h, operating hours: 68322h, process hours: 34697h. Including an automated CO2 fire detection system, transformer, machine extraction system, 4× workpiece carriers and an automatic diameter detection system. Documentation available. An on-site inspection is possible.

This 4-axis MORI SEIKI NLX 2500Y was manufactured in 2013. It features a maximum swing over bed of 742 mm and a maximum turning diameter of 366 mm. The machine includes a powerful spindle motor with 18.5 kW and a maximum spindle speed of 4,000 rpm. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI NLX 2500Y horizontal turning machine we have for sale. Contact us for further details.

A Mori Seiki CNC turning and milling center with counter spindle including automation is available. Tool turrets: 3, tool stations: 3×16, live tools: all stations, X-axis travel: 210mm, Z1/Z2/Z3-axis travel: 300mm/810mm/300mm, main spindle bore: 55mm, spindle speed: 6000rpm, automation robot: LR Mate 200iC 5L, payload: 5kg, reach: 892mm, repeatability: 0.03mm. Machine dimensions X/Y/Z: approx. 3800mm/2700mm/2500mm, weight: approx. 8900kg, control: Fanuc 31i-A, power-on hours: 101035h, operating hours: 68322h, process hours: 34697h. Including an automated CO2 fire detection system, transformer, machine extraction system, 4× workpiece carriers and an automatic diameter detection system. Documentation available. An on-site inspection is possible.

This 5-axis MORI SEIKI NL 2500 SY was manufactured in 2009. It features a maximum spindle speed of 4,000 rpm, a Y-axis travel of ±60 mm, and a Z-axis travel of 795 mm. The machine is equipped with a robust turret capacity of 12 stations and offers simultaneous turning and milling capabilities. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NL 2500 SY turn-mill centre we have for sale. Contact us for further details.

turning diameter: 190 mm turning length: 210 - 230 mm x-axis: 125 mm z-axis: 195 mm turning speed range: 6.000 U/min greates pass round over bed: 190 - 200 mm spindle bore: 43 mm machine weight ab.: 2.500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 3-axis MORI SEIKI DuraVertical 5100 was manufactured in 2007. It features an X-axis travel of 1,050 mm, Y-axis travel of 530 mm, and Z-axis travel of 510 mm. The machine has a robust table size of 1350 x 600 mm and a maximum table load capacity of 1000 kg. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI DuraVertical 5100 vertical machining center we have for sale. Contact us for further details.

This 3-axis MORI SEIKI NLX 2500M was manufactured in 2011. It features a maximum turning diameter of 366 mm and a maximum turning length of 705 mm. The machine is equipped with a powerful spindle motor of 18.5 kW and a turret with 12 positions for enhanced productivity. If you are looking to get high-quality turning capabilities, consider the MORI SEIKI NLX 2500M horizontal turning machine we have for sale. Contact us for further details.

The machine is in good technical condition; testing is possible by prior arrangement. SPACESAVER SS 2101. Fanuc MSX-850 system.

A Mori Seiki CNC lathe is available. Swing diameter over bed/slide: 450mm/300mm, max. turning diameter: 160mm, turning length: 525mm, travel X/Z: 135mm/560mm, bar capacity: 42mm, spindle bore: 52mm, spindle nose: JIS A2-5, spindle speed: 5000rpm, power: 7.5kW, torque: 172Nm, tool stations: 12, tailstock taper: MK4, quill diameter: 75mm, quill stroke: 80mm, rapid traverse: 12m/min. Machine dimensions X/Y/Z: approx. 2500mm/1500mm/1700mm, weight: approx. 3250kg, control: Fanuc Series 15-T. Documentation available. An on-site inspection is possible.

turning diameter: ca. 570 mm turning length: ca. 530-610 mm control: FANUC : ohne Gewähr x-travel: ca 160-200 mm y-travel: ca. 560 mm weight of the machine ca.: 4,5 - 5 t : ca 10 oder 12 spindle bore: 52-76 mm total power requirement: - kW weight of the machine ca.: 4 t dimensions of the machine ca.: - m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 510 mm y-travel: 510 mm z-travel: 510 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control MSC 803 25-fold automatic tool changer coolant device Technische Daten / technical details: Verfahrweg X / X-Travel 510 mm Verfahrweg Y / Y-Travel 510 mm Verfahrweg Z / Z-Travel 510 mm Tischgröße / table size 750x548 mm Drehzahlbereich / spindle speed 8000 UpM /rpm Anzahl der Werkzeugplätze / tool places in changer 25 fach Antriebsleistung Spindel / drive capacity spindle 11 kW Gewicht der Maschine ca. / weight 4500 Kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 660/275 mm turning length: 1498 mm control: Fanuc/Mori Seiki MSX 701 total power requirement: 90 kVA weight of the machine ca.: 26,6 t dimensions of the machine ca.: 5301 x 2997 x 2788 mm 9-axis CNC turning and milling centre Fanuc MSX-701 CNC control Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. 40-position tool magazine 10-position turret at bottom, all positions driven 2 x 3-jaw quick-change chuck KNCS-N 315/91 KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system Chip conveyor Drain system for main spindle chuck (controlled via M function) Drain system for tool cutting edge (controlled via M function) Coolant gun incl. accessories Oil mist extraction Direct measuring system X1, X2, Y-axis Bar loader interface Double foot switch for both spindles Island ...

x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...

x-travel: 800 mm y-travel: 530 mm z-travel: 510 mm Control: MSC 504 Mori Seiki Main spindle:: turning speeds: max. 10.000 min/-1 power capacity - main spindel: 15 / 11 kW tool taper: SK 40 spindle bearing diameter: 70 mm distance spindle /table: 150 - 660 mm work table:: table surface area: 1.100 x 600 mm max. table load: 800 kg T-slots: 6x 18 mm table height over floor: 900 mm turret:: number of toolpositions: 30 pos. tool taper: SK 40 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,3 sec change-time chip to chip: 4,1 - max. 9,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 20 m/min feed speeds: max. 6.000 mm/min Tipp feed: 1 - 5.000 mm/min total power requirement: 27 kVA weight of the machine ca.: 6,1 t dimensions of the machine ca.: 3,5 x 3,0 x 2,8 m Documents: Chip conveyor: Co ...

x-travel: 560 mm y-travel: 560 mm z-travel: 630 mm Control: MSX 701 III MAPPS Main spindle:: Max. rpm: 14.000 min/-1 power capacity - main spindel: 18,5 / 11 kW max. Torque: 120 Nm tool taper: MAS BT 40 distance spindle center to table: 80 - 640 mm distance Spindlenose and center of table: 100 - 730 mm pallet changer:: numbers of pallets: 2 size of pallet: 400 x 400 mm max. workpiece weight: 400 kg max. workpiecediameter: 630 mm max. workpiece height: 900 mm change time of pallets: 6,0 sec b - axis: 0,001 ° Tool-Presetter:: number of toolpositions: 60 pos. tool taper: MAS BT 40 max. tool diameter: 70 / (140) mm max. tool length: 400 mm max. tool weight: 8,0 kg feeds:: rapid traverse ( X / Y / Z ): 50 m/min feed speeds: 0 - 50.000 mm/min Tipp feed: 0 - 1.260 mm/min total power requirement: 35 kVA weight of the machine ca.: 9,8 t dimensions of the machine ca.: 5,5 x 3,5 x 2,8 m Docume ...

turning diameter: 390 mm turning length: 507 mm control: MSG 805 MAPPS max. turning diameter: 390 mm greates pass round over bed: 680 mm Swing dia. over traverse guideway: 510 mm centre distance: 618 mm Main spindle:: turning speed range - main spindle: 45 - 4.500 min/-1 power capacity - main spindel: 11 / 7,5 kW spindle bearing diameter: 110 mm spindle bore: 73 mm max. bar capacity: 51 mm spindle nose: JIS A2-6 chucking diameter: 210 mm C-Axis: 0,001 ° axis stroke:: x-axis: 235 (195+40) mm z-axis: 520 mm turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Spindle speed - driven tool stations: max. 3.000 min -1 power capacity driven tool-stations: 5,9 / 4,5 kW Shank height for square tool: 25 mm Drill shank diameter: max. 50 mm turret change time: 0,2 sec. Tailstock:: tailstock adjustment: 490 mm dia. of quill: 85 mm taper of center: MT 4 quill stroke: ...

turning diameter: max. 320 mm turning length: 810 mm control: MSX 701 MAPPS III standard turning dia.: 200 mm Main spindle:: Number of revolutions: max. 6.000 min/-1 power capacity - main spindel: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Subspindel:: Number of revolutions: max. 6.000 min/-1 power capacity - Sub spindle: 22 / 18,5 kW Bar feed: max. 52 mm spindle bore: 61 mm C-Axis: 0,001 ° Turret 1 + 3:: number of toolpositions: je 16 pos. Number of driven toolspositions: je 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+65 / -45) mm Turret 2:: number of toolpositions: 16 pos. Number of driven toolspositions: 16 pos. Spindle speed - driven tools: max. 6.000 min -1 power capacity - driven tools: 7,5 / 5,5 kW Y - Axis: 110 (+45 / -65) mm axis stroke:: x-travel: 1-3: 210 mm y-travel: 1-3: ...

turning diameter: 370 mm turning length: 424 mm control: MSX-711-IV Mori Seiki swing diameter: 370 mm X1- Axis: 380 mm X2- Axis: 155 mm Z1- Axis: 460+155 mm Z2- Axis: 610 mm y-axis: +/- 105 mm B - axis: +/- 120 ° bar material dia.: 65 mm speed spindle max.: S1 5.000 / S2 6.000 U/min. spindle bore: S1/S2 65/38 mm : 12000 1/min tool taper: Capto C5 toolpiece magazine: chain magazine: 76 Stück tool turret with 10 work positions: total power requirement: 45 kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: 2,71 x 2,43 x 2,40 m MAPPS control system Renishaw HPRA (manual tool presetter) Blum Laser Control Direct measuring system X,Y,Z,B Collet chuck SMW Autoblok KSZ-MB-040-Z140 Workpiece conveyor belt Bar feeder Breuning Irco ILS-RBK-10012 Knoll band filter KF10/500 / IKZ with milling spindle 7 stages up to 70 bar Chip conveyor ConSep 2000 The data for this ad was create ...

turning diameter: 176 mm turning length: 570 mm swing diameter: 510 mm working diameter: 420 mm travel -z axis: 570 mm travel -x axis: 245 mm spindle bore: 43 mm diameter of quill: 85 mm quill stroke: 120 mm Spindle Speed: 60-6.000 U/min. rapid power traverse in X-and Z direction: 24 m/min total power requirement: 5,5 kW control: MSG-805 V weight of the machine ca.: 3.400 kg dimensions of the machine ca.: 2000x1700x1800 mm Features/Accessories: - Integrated CNC control - Bed guides and cross-slide guides are induction-hardened and designed as flat guides - Continuously variable AC main spindle drive - Constant cutting speed programming - Cold light lamp integrated into the machine - Power meter for the main spindle drive (ammeter) - Control units for automatic and manual operation, as well as a CNC programming unit and control panel - Tailstock with hydraulically actuated MK 4 tailstock ...

MORI SEIKI SV-503B/40 is a 4-Achsen Bearbeitungszenter, entwickelt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Tisch 1320×600 mm, max Werkstückgewicht 1200 kg; Wege X1050, Y510, Z510 mm; Magazin 30 Plätze, BT40. Spindel 0–10.000 min-¹, 22 kW; Anschluss 3x200V 50Hz; 58 kVA; Gewicht ~8030 kg; Abmessungen 2500×2350×2700 mm. Zubehör: Satz Werkzeughalter, Kühlmitteleinrichtung mit 30 bar IKZ, Späneförderer, Teilapparat NIKKEN, Lampe, Zustandsleuchte. Geeignet für präzise Fertigung in Automotive, Luftfahrt, Medizintechnik und Maschinenbau. Technische Daten ohne Gewähr

MORI SEIKI NH 4000 DCG ist ein Horizontal Bearbeitungszenter von MORI SEIKI, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Angaben zu Arbeitskapazitäten (Verfahrwege, Durchmesser, Werkstücklängen) sind nicht vorhanden. Haupttechnische Daten (Spindeldrehzahlen, Vorschubgeschwindigkeiten, Stromversorgung, Abmessungen, Gewicht) sind nicht angegeben. Angaben zu Ausstattung oder Zubehör sind nicht aufgeführt. Entwickelt, um enge Toleranzen zu erreichen; typisch eingesetzt in Automobil-, Luftfahrt-, Medizin-, Uhren- und Werkzeugmaschinenbereichen Technische Daten ohne Gewähr

Key data: 440 mm, 363 mm

Manufacturer: Mori Seiki Model No.: CL2000B Year: 2014 Condition: Used Stock number: 9456 Control system: MORI SEIKI M65V Switch-on hours: 61927 h Hours: 25326 h Maximum turning length: 363 mm Max. turning diameter: 440 mm Weight: 2800 kg

Manufacturer: MORI SEIKI Model: NL 2000 SY Year: 2005 Condition: Used Stock number: 9458 Control system: FANUC MSX-850 Maximum turning length: 510 mm Max. turning diameter: 356 mm Travel X: 260 mm Travel Y: 100 mm Travel Z: 590 mm Weight: 5800 kg Equipment: Bar Feeder SPACESAVER SS 2101

Mori Seiki NL2500Y/700 CNC Drehmaschine (02/2008) Hersteller: Mori Seiki Typ: NL2500Y/700 Baujahr: 02/2008 Zustand: gebraucht, sehr gut, in Produktion Drehdurchmesser 275 mm Drehlänge 705 mm Steuerung MAPPS II MSX 850 Umlaufdurchmesser über Bett 923,8 mm Umlaufdurchmesser über Planschlitten 755 mm max. Drehdurchmesser 356 mm max. Stangendurchmesser 80 mm Hauptspindel Drehzahlbereich ? Hauptspindel 4.000 U/min Antriebsleistung ? Hauptspindel 26 / 22 kW Spindelnase JIS A2-8 Spindelbohrung 91 mm Spindellagerdurchmesser 140 mm C-Achse 0,001 ° Verfahrweg x-Achse 260 mm z-Achse 795 mm y-Achse 100 (+/- 50) mm Revolver Werkzeugplätze 12 Pos. Schafthöhe für Vierkantwerkzeug 25 mm Schaftdurchmesser für Bohrstange max. 50 mm Revolverschaltzeit 0,25 sec. Drehzahlbereich der angetr. Werkzeuge 6.000 min -1 Antriebsleistung ? angetr. Werkzeuge 5,5 / 3,7 kW Vorschub ...

Mori Seiki ZL 250 CNC Drehmaschine Hersteller Mori Seiki Typ: ZL 250 Baujahr: 1998 Zustand: gebraucht, unter Strom und in Produktion. Zubehör optional Weitere Informationen auf Anfrage

Mori Seiki DuraVertikal 5080 3Achs Bearbeitungszentrum (11/2006) Hersteller: Mori Seiki Typ: DuraVertikal 5080 Baujahr: 11/2006 Zustand: gebraucht, gut, in Produktion

x-travel: 735 mm y-travel: 650 mm z-travel: 560 mm control: 840D sl FD operate Siemens Main spindle:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 35 / 24 kW max. Torque: 119 Nm tool taper: HSK-A63 DIN 69893 swiveling-rotary-table:: table diameter: 680 mm max. table load: 600 kg max. workpiece sizes: 650 x 650 x 500 mm swivellable: +/- 120 ° rotatable: 360 ° tool magazin:: number of toolpositions: 30 pos. tool taper: HSK-A63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool length: 315 mm max. tool weight: 8,0 kg change-time chip to chip: ca. 4,9 sec feeds:: feed speeds: max. 40.000 mm/min rapid traverse: 40 m/min total power requirement: 65 kVA weight of the machine ca.: 11,6 t dimensions of the machine ca.: 4,0 x 3,0 x 2,95 m Documents: Chip conveyor: Coolantsystem: 600 L through spindle coolant: 40 bar paper ba ...

CNC controller: FS-31IA5 (MAPPS 3) Capacity Z-axis travel mm: 1.550 + 100 Turning length mm: 1.542 Max. turning diameter mm: ø: 660 Swing over bed mm: ø: 730 Bar work capacity mm: 80 / 80 Turning diameter f. lower turret mm: 350 Distance between spindle centers mm: 1.862 Turn-mill spindle X-axis travel mm: 750 Y-axis travel mm: ±210 B-axis degree: ±120° (Index 1°) C-axis degree: 360º (0,001º) Speed spindle rpm: 12.000 Drive power kW: 18,5 / 11 (30min/cont) Tool magazine Magazine places: 100 Tool holder: CAPTO C6 Tool length max. mm: 400 Tool diameter max. mm: 140 Tool weight max kg: 8 Lower turret X-axis travel mm: 195 Z-axis travel mm: 1.525 Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Milling function: PROVIDED Main spindle Speed spindle rpm: 4.000 Drive power spindle kW: 22 / 18,5 (30min/cont) Spindle bore mm: 91 Counter spindle  ...

turning diameter: 310 mm turning length: 1000 mm control: MSX 501 total power requirement: --- kW weight of the machine ca.: 6,6 t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 14.000 min/-1 power capacity - main spindel: 18,9 / 14 kW max. Torque: 100 Nm tool taper: HSK A-63 NC-Rotary table:: table surface area: 630 x 500 mm max. table load: 300 kg Swivel range: -5 / +110 ° rotation range: 360 ° T-slots: 7x 14 x 63 mm tool magazin:: number of toolpositions: 30 pos. max. tool weight: 6 kg max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. workpiece length: 300 mm feeds:: rapid traverse: 24 m/min Feed force: 4,8 kN feed speeds: 1 - 24.000 mm/min total power requirement: 25 kVA weight of the machine ca.: 5,0 t dimensions of the machine ca.: 4,5 x 3,5 x 2,3 m Documents: Chip conveyor: Coolantsystem: elektr. hand wheel: hydraulic system: elektr. hand wheel: exhaust fan: 3D quickSET: test probe: DMG  ...

turning diameter: 170 mm Max. Turning length: 120 mm bar capacity: 52 mm control: FANUC MSX-501 travel -x1 axis: 140 mm travel -x2 axis: 140 mm travel -z1 axis: 450 mm travel -z2 axis: 410 mm travel -y axis: +/- 40 mm travel - b axis (spindle 2): 525 mm speeds station 1: 60 - 6000 U/min spindle bore 1: 62 mm speeds station 2: 60 - 6000 U/min spindle bore 2: 62 mm driven tools turning speeds: 6.000 U/min CNC Turning- and Milling Center | ZT 1500 Y - 2005 equipped with 2 turrets for driven tools, Y-axis and bar loader. The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ZT1500Y | ZT-1500 Y | ZT 1500Y | ZT-1500-Y The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

multitasking turning center, year 2010, CNC Mapp. Used machine in good condition. More info & price on IndustrialBuyer.

CNC bar-fed lathe, year 1999, CNC MSD-501II. Used machine in good condition. More info & price on IndustrialBuyer.

Manufacturer: MORI SEIKI Model No.: SH 633 Year: 1999 Condition: Used Stock number: 9496 Control system: MORI SEIKI MSG-502 Work table length: 700 mm Work table width: 500 mm Maximum table load (uniform): 1200 kg Maximum spindle speed: 10000 1/min X-axis travel: 840 mm Y-axis travel: 760 mm Travel distances Z-axis: 840 mm Machine weight: 18500 kg

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS IV greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm D ...

standard turning dia.:200 turning length:max. 810 mm control:MSX-701 MAPPS III greates pass round over bed:800 mm Max. distance between centres:1130 mm max. turning diameter:320 mm max. workpiecediameter:300 mm bar material dia.:65 mm Traverse X-Axis 1:210 Traverse X-Axis 2:210 mm Traverse X-Axis 3:210 mm Traverse Y-Axis 1:110 (+65/-45) mm Traverse Y-Axis 2:110 (+45,/-65) mm Traverse Z-Axis 1:300 mm Traverse Z-Axis 3:300 mm Traverse Z-Axis 2:810 mm Traverse B-Axis:870 mm turning speed range - spindle:5.000 1/min Number of spindle speed ranges:2 . spindle nose:JIS A2-6 spindle bore:73 mm spindle bearing diameter:120 mm C-Axis:0,001 ° turning speed range - spindle:5.000 1/min spindle nose:JIS A2-6 spindle bore:73 mm bar material dia. max:65/52 mm spindle bearing diameter:120 mm C-Axis:0,001 ° Number of Turrets:3 . Number of tool stations:16 x 3=48 pos Schank height for square tool:20 mm  ...

x-travel:800 mm y-travel:410 mm z-travel:510 mm control:Fanuc 10 MA rapid travel x/y/z:20/20/15 mm/min table surface area:1100 x 450 mm tool taper:BT 40 tool magazin::30 BT 40 max. tool length:250 mm max. tool weight:8 kg power requirement:7,5/5,5 kW turning speed range:6000 1/min weight of the machine ca.:6,3 t Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup"

x-travel:1400 mm y-travel:1200 mm z-travel:1350 mm control:MSX- 701 Mapps III table surface area:800 x 800 mm rapid traverse:50 m/min table rotating:360.000 x 0,001 B-Achse ° table load:2,0 t numbers of pallets:2 turning speed range:8000 1/min power capacity - milling spindle:37 kW no. of tools in the magazine:60 Stück tool taper:HSK-A 100 weight:31 t dimensions:5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis

x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,

turning diameter:356 mm turning length:700 mm y-axis:±60 mm spindle drive:18 kW counterspindle motor:15 kW Direct drive for driven tools:5,5 kW Motor starting torque:640 Nm Main spindle mount:A2-8 counter spindle mount:A2-6 Rod passage:80 mm main spindle speeds::4.000 U/min Drehzahl angetriebene Werkzeuge :6.000 U/min rapid traverse speed:30 m/min auf X- und Z-Achse machine weight ab.:5.800 kg 12-station turret, all positions driven C-axis on both spindles Belt-driven and infinitely variable drive on all motors Prismatic guideways on all axes Oil cooler for both spindles, manufacturer Daikin Automatic, dialog-guided programming system MAPPS Automatic monitoring of tool load and tool wear Two Renishaw measuring arms for automatic tool measurement Interfaces: USB, PCMCIA card, and RS-232 port Interface for bar feeder Automatic parts catcher Dual foot pedal for independent opening and clos ...

CONTROLS   CNC controls FANUC 18 MB WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 4   .. among of them simultaneous CNC axes: 3   X-axis travel: 900 mm   Y-axis travel: 800 mm   Z-axis travel: 980 mm   rotating range B-axis from: 0 °   rotating range B-axis up to: 360 ° TABLE   table surface (left-right): 630 mm   table surface (front-back): 630 mm   workpiece load (max): 1200 kg SPINDLE / HEAD   spindle type: horizontal   spindle revolutions (max): 10000 /min AXIS DRIVES   rapid traverse: 50000 mm/min TOOL MAGAZINE   number of positions: 140 AUTOMATIC WORKLOAD EQUIPMENT   store type: table changer   number of store positions: 2 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 19000 kg ATTACHMENTS   chip conveyor: yes   coolant unit: yes   ban ...

CONTROLS   CNC controls MORI SEIKI MSG-501 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 4   X-axis travel: 1300 mm   Y-axis travel: 1200 mm   Z-axis travel: 1100 mm TABLE   table surface (left-right): 800 mm   table surface (front-back): 800 mm   workpiece load (max): 2000 kg SPINDLE / HEAD   spindle revolutions (max): 0 /min   spindle revolutions (max): 6000 /min   tool fixture: ISO BT 50 AXIS DRIVES   rapid traverse: 42000 mm/min TOOL MAGAZINE   number of positions: 60 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 7400 mm   space requirements -front/back-: 4300 mm   total height: 3750 mm   total weight approx.: 23500 kg ATTACHMENTS   chip conveyor: yes   coolant unit: yes   band filtration unit: yes   through spindle coolant att ...

CONTROLS   CNC controls MITSUBISHI M720BM BASIC FUNCTIONS   number of spindles: 2   number of turrets: 1   live positions: yes   number of c-axes: 2 WORKING RANGE TURNING   swing diameter (max): 700 mm   turning diameter (max): 350 mm MAIN SPINDLE   spindle revolutions (max): 4000 /min   spindle bore diameter: 90 mm   c-axis: yes X/Z SLIDE   - rotation speeds (max): 6000 /min TOOL MAGAZINE   number of positions: 24 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 7500 kg ATTACHMENTS (TURNING)   chip conveyor: yes   coolant unit: yes   hydraulic system: yes   European CE standards: yes Machine in a good condition The spindle guides need to be replaced. Machine equipment (1500.- CHF (below)): - 1x double face and longitudinal turning tool holder - 3x face and longitudinal turnin ...

CNC controller: Siemens 840D sl with CELOS ERGOline Capacity X-axis travel mm: 480 (–10) Y-axis travel mm: ±100 Z-axis travel mm: 845 B-axis travel mm: ±110° (0,001º) C-axis: 360º (0,001º) Turning length mm: 800 Max. turning diameter mm: ø: 500 Distance between spindle centers mm: 1.020 Turn-mill spindle Speed spindle rpm: 12.000 Drive power kW: 22 / 19 Tool magazine Magazine places: 24 Tool holder: HSK-A63 Tool length max. mm: 300 Tool diameter max. mm: 125 Tool weight max kg: 7 Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 25 / 34 (100 / 40%) Spindle bore mm: 67 Maximun torque Nm: 380 / 280 Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 20 / 27 (100 % / 40%) Spindle bore mm: 52 Maximun torque Nm: 170 Counter spindle travel mm: 800 Coolant system Tank capacity liter: 600 L High-pre ...

Codice: 0222 - AI

Tool pressetter Needs new computer and software Estimated price 2022 from producer € 4500,--

DMG Mori Seiki LaserTec 50 FineCutting Sauer CNC Laser Precision Machine Year / Model: 2019 Control: Celos with Siemens 840D sl Operate CELOS with Siemens 840D sl Operate including 2l .5 ERGOline Control with multi-touch screen CNC Laser Precision Machine with High Speed Machining LASERTEC 50 FineCutting for laser fine cutting, laser drilling, laser welding NC swivel rotary table highly dynamic and precise Travel: 500 mm x 500 mm x 700 mm travel integrated ytterbium cw fiber laser 450W qcw ytterbium fiber laser with 4500W Pulse peak power and 450 W power Processing head (80 mm focal length), 5-axis transformation 100 working hours (new-new) Kaufpreis neu/Buying price in year 2020: 890.000,- Eur, Made in DMG Germany. Included: Fanuc robot automation + Keller autom. Extraction system solid machine base frame made of mineral casting, Camera through optical path for fib ...

DMG MORI NTX 2000/1500 SZM CNC turn-mill center was built in 2018 in Japan by DMG MORI CO., LTD. The machine on offer is an excellent choice for the mass production of precision parts, which are used in such industries as automotive or aerospace. This is because the NTX 2000/1500 SZM enables simultaneous turning and milling of workpieces with even the most complex geometries, in a single working cycle. The combination of these two processes significantly reduces production costs, as well as overall working time. The machining process is performed by using the state-of-the-art technology available on the market. It includes, among others, two spindles with a labyrinth cooling system. This system was designed for frequent use of high-pressure coolant. It ensures a constant zero-point height throughout the working cycle, regardless of the amount of generated heat. To limit the effect of  ...

Year of manufacture: 2013 CNC Controller: FAGOR 8055TCO Capacity Distance between centers (mm): 3000 Height between centers (mm): 300 Height between centers from the ground (mm): 1200 Grinding diameter (mm): ø 595 Max. workpiece weight between centers (kg): 2000 Max. Workpiece weight with tool (kg): 200 Table (Z-axis) Maximum travel (mm): 3350 Rotating table plate ±5° Feed rate (mm/min): 0.01 ÷ 6000 Minimum programmable increment (mm): 0.001° Grinding carriage (X-axis) Maximum travel (mm): 500 Feed rate (mm/min): 0.01 ÷ 6000 Minimum programmable increment (mm): 0.001° Resolution (mm): 0.0005° Grinding head Left grinding wheel diameter (mm): 600 Peripheral speed (m/s): 45 Workpiece head Spindle speed (rpm): 9 ÷ 250 CM taper: 5 Spindle type: 8" Tailstock Type: Manual handwheel Spindle taper (cm): 6 Maximum spindle travel (mm): 60 Quill diameter (mm):  ...
