Vision Wide VF4000 portal milling machine for sale. 2-axis milling head (1 degree C-axis and 1 degree B-axis) with position determination Encoder SK50 VTEC VF4000 Dimensions X-axis 4200 Y-axis 2300 Z-Axis 1020 Tool magazine 40WZ Control Siemens 840D SL
x-travel: 2000 mm y-travel: 1600 mm z-travel: 800 mm control: Siemens 840 D boring spindle diameter: 150 mm bore spindle turning speed range: 4-1500 U/min Feeds, stepless (Y, Z): 1-9999 mm/min Rapid Feed Y, Z, W: 10000 mm/min Boring spindle taper: ISO 50 Milling spindle taper: ISO 60 surface area: 1600 x 2000 mm workpiece weight max.: 12500 kg total connected load: 90 kW weight of the machine ca.: 32200 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
A Deckel Maho 5-axis CNC milling machine in need of repair is offered. Travel X/Y/Z: 1080mm/710mm/710mm, NC-mounted rotary table C-axis X/Y: 800mm/620mm, swiveling milling head B-axis: 90°, max. spindle speed: 12000rpm, tool taper: SK40, tool positions: 32, control: Heidenhain iTNC 530, control-on hours: 75100h, program run hours: 24720h. Equipped with internal air blast supply, external coolant supply, Heidenhain infrared touch probe, Heidenhain electronic handwheel, Rotoclear rotating inspection window, chip conveyor, oil mist extraction system, coolant system with paper band filter, chip flushing gun, work area light and clamping support next to the mounted rotary table for longer workpieces. The milling head clamping system is leaking, but the machine is still operational. An on-site inspection is possible.
X-axis: 500mm, y-axis: 430mm, z-axis: 400mm, table dimensions: 510x450x410mm, max. table load: 250kg, angular clamping table: 800x390mm, feed rate x-/y-axis: 4-1600mm/min, z-axis: 4-1000mm/min, feed force: 5000N on all axes, rapid traverse x-/y-axis: 1.6m/min, z-axis: 1m/min, tool holder (DIN 2079): ISO 40, cutter drawbar thread: M16, hydromechanical tool clamping: 12,000Nm, quill stroke: 80mm, drive power: 3kW, 18-speed sliding-gear transmission: manually or automatically selectable, torque: 5Nm, spindle speed: 50-2500rpm, connected load: 6kW, control: Heidenhain TNC 114B (hand control type HS262), display resolution: 0.005mm, length: 1400mm, width: 1300mm, height: 1830mm, weight: 1.6t, space requirement: 2300x2300x2400mm, equipment: machine light, coolant tank: 18l, external coolant supply: 3bar, various tool holders, spindle tool. On-site inspection is possible.
CMZ TD-30-TM-800 CNC Turning-Milling Center Technical Specifications Manufacturer: CMZ Model: TD-30-TM-800 Year of Manufacture: 2021 Control System: FANUC 32i-TB Plus Maximum Turning Length: 800 mm Maximum Turning Diameter: 550 mm Spindle Power: 42 kW Bar Capacity: 82 mm Tool Turret: 16 positions Machine Weight: 8,700 kg Equipment: Driven Tools, C-axis, Chip Conveyor
Fräsmaschine Macmon M 434 NC Hersteller: Macmon Typ: 434 NC Steuerung: Heidenhain TNC 124 Baujahr: 2008 Zustand: gebraucht X-Achse: 400 mm Y-Achse: 250 mm Z-Achse: 400 mm Aufspannfläche 600 x 320 mm Hauptantrieb: AC-Motor kW 3 Drehzahlbereich: Vertikal stufenlos 30 ? 6300 Horizontal stufenlos 0 ? 4200 ? Vorschub 0 ? 10 m/min Werkzeugaufnahme ISO 40 Betriebsspannungn 400 / 50 Volt / Hz Steuerspannung 24V Gewicht 1200 kg Lieferumfang: ? Dokumentation ? Maschinenfüße ? Kühlmittelanlage ? Spindelschutz ? Maschinenleuchte ? HR410 Handrad ? Horizontalspindel Gegenhalter
Kunzmann WF 4/3 Fräsmaschine TNC 320 Hersteller: Kunzmann Typ: WF 4/3 Fräsmaschine Baujahr: 2009 Zustand: gebraucht, aus Lehrwerkstatt, gereinigt und unter Strom, vorführbereit Spindelstunden: 2.542h x-Weg: 400 mm y-Weg: 350 mm z-Weg: 400 mm Werkzeugaufnahme SK 40 Spindeldrehzahlen 1,0 ? 4.500 U/min Vorschübe 0 ? 2000 mm/min Pinolenhub 60,0 mm Tischgröße 650 x 350 mm T-Nuten 14 H7 Steuerung TNC 320 Motorleistung 5,5 kW Gewicht 1920 kg Raumbedarf ca. 2000 x 2000 x 2100 mm Gesamtleistungsbedarf: ca.7 kVA Zentralschmierung Kühlmitteleinrichtung CE-Konform Lieferumfang: ? Technische Dokumentation ? Vollschutzkabine ? LED Maschinenleuchte
4 Spindle High Speed Train Milling Machine, ANGER, HCP 10/5, 2005 Control : NUM, very few operating hours. Methods: X-300, Y-1130, Z-300, 4-axis +/- 180 degrees 4 high frequency spindles : Precise 60000 / 160000 / 18000 / 16000 rpm , rpm Tool holder : Collets depending on the spindle Chip conveyor, ATC, recooling unit, external measuring system Renishaw Power consumption 41 kw
ABENE VHF 360 TI ist eine CNC Fräsmaschine für präzise Bearbeitung mit hoher Genauigkeit und Zuverlässigkeit. Kapazitäten: Tisch 1200x450 mm, Wege X650 Y480 Z475 mm, max. Werkstückgewicht 400 kg, Pinolenhub 75 mm, Schwenkbereich 0–140°, Aufnahme ISO40. Technik: stufenloser Spindeldrehzahlbereich 55–4000 t/min, Vorschübe stufenlos bis 4000 mm/min (X/Y) und 1500 mm/min (Z), Frässpindelmotor 7,5 kW, Gesamtleistung 14 kW, 3x400 V 50 Hz, Maschinengewicht ~2300 kg, Platzbedarf 3000x3000 mm. Zubehör: Bohrspindel, mechanische Handräder, Kühlmitteleinrichtung, Maschinenlampe. Erreicht enge Toleranzen; geeignet für Automotive, Uhrenindustrie, Werkzeugbau, Luftfahrt und Medizintechnik. Technische Daten ohne Gewähr
Tool milling machine Maho, 700C Control : Maho 432, Year of construction 1989, Mounting SK40, Process : X-700, Y-450, Z-500, quill Machine can no longer be viewed under power. Has lost parameters! Would also sell spare parts, table, milling head, drives, control, ...
Key data: 1600 mm, 800 mm
CNC bed milling machine with Heidenhain control 415, good condition, hydraulic tool clamping, coolant device, central lubrication, lighting,.. Travel X1600/y800/z650/ Spindle holder SK 50 Spin elder speed 60-1800rpm Working feed rate 10-3000mm/min Rapid traverse 10m/min Table clamping surface 1800x610mm Machine weight 9500kg Table load 3000kg
FLOOR TYPE CNC D-ELECTRON Z32 Longitudinal stroke axis X mm 8300 Cross stroke axis Y mm 1000 Vertical stroke axis Z mm 1900 Table dimensions mm 10.000x1060 T-slots mm 22H7 T-slots distance mm 175 Spindle motor Kw 36 Spindle speed Rpm 10:2000 Spindle taper ISO 50 DIN 69871 Automatic universal milling head: -A Axis indexing 1° -B Axis indexing 3° Tool changer 40 positions Max installed power kW 160 EQUIPPED WITH: -Rotary table diameter 400 mm and counter-support -Chip conveyor RETROFIT 2019 Auction-ID: A1-48745-12
Machine number: 34101101 Operating voltage: 400 V Rated current: 128 A Frequency: 50 Hz Power: 89 kVA Operating hours read: 2782 Turning length: 3000 mm Center height above floor: 1270 mm Circulation diameter over slide top: 520 mm Circulation diameter over telescopic left: 520 mm Circulation diameter over steady rest slide: 520 mm Main spindle left, spindle diameter in front bearing: 160 mm Spindle bore: 77 mm Spindle speed: 4000 rpm Torque: max. 630 Nm tailstock moving built-in centering tip: MK 5 tailstock Quill diameter: 135 mm Starting force: 200 to 1200 daN Max. workpiece weight: 1000 kg Turning-drilling-milling unit Drive power: 15 kW Torque: max. 190 Nm Tool holder: HSK 63 The machine is equipped with a tailstock, a moving steady rest SMW Autoblock and a three-jaw chuck RÖHM, diameter: 310 mm incl. matching workshop cabinet and workbench with large items Documentation max. tool ...
X-axis: 500mm, Y-axis: 450mm, Z-axis: 400mm, swivel rotary table dimensions: 630x500mm, max. table load: 200kg, swivel range: -5 to 110°, continuously variable speed: 20-10,000/min, drive power (100%/40% duty cycle): 9kW/13kW, torque (40% duty cycle): 82Nm, input resolution: 0.01mm, positioning tolerance: 0.010mm, rapid traverse: 24m/min, feed speed: 20m/min, number of SK40 tool positions (DIN 69871): 30, tool diameter (speed-dependent): D80-D130, max. tool length: 290mm, max. tool weight: 6kg, connected load: 17kW, control: Siemens 840D Powerline ShopMill, length: 4860mm, width: 4350mm, height: 2424mm, transport dimensions: 2210x2120x2150mm, weight: 4.05t, operating hours power-on time: 35,880h, spindle hours: 9609h. Equipment: digital drive and hydraulic clamping (positioning operation only), electronic angle display and plane transformation, chain magazine with double gripper, additi ...
Key data: 1300 mm, 630 mm, 630 mm
Bed milling machine Manufacturer: Correa Type: A10 Year of Make: 1988 Control: HEIDENHAIN TNC 355 Travel X/Y/Z: 1,300 x 630 x 630 mm Clamping area: 1,700 x 630 mm Workpiece weight: 3,000 kg Hours: 25,845 Power: 19 kW Spindle Type: ISO 40 Dimensions L/W/H: 3,870 × 2,630 × 2,200 mm Machine weight: 6,800 kg
Key data: 1800 mm, 800 mm, 800 mm
Bed milling machine Manufacturer: Correa Type: A16 Year of Make: 1988 Control: HEIDENHAIN TNC415 Travel distances X/Y/Z: 1,800 x 800 x 800 mm Clamping area: 2,000 x 630 mm Workpiece weight: 3,000kg Hours: 12,103 Power: 19 kW Spindle Type: ISO 50 Dimensions L/W/H:4,886 × 2,720 × 2,500 mm Machine weight: 7,500 kg
Machine number: F39455 Operating voltage: 400 V Control voltage: 230 V Frequency: 50 Hz Rated current: 100 A Connection: 50 kVA Control: SIEMENS SINUMERIK 840 C Travel X-axis: 5000 mm Travel Y-axis: 1200 mm Travel Z-axis: 1000 mm Rapid traverse: 0 - 10 m/min Feed: 0 - 4 m/min Speed: from 20 to 2800 rpm Milling head position vertical/horizontal/middle/horizontal right/horizontal left/horizontal top Universal milling head particularly suitable for milling with 5-fold spindle positioning Drilling Table dimensions: 3750 x 1250 mm with 9 grooves Tool holder: SK 50 Rotary table dimensions: 1250 x 1250 mm with 9 grooves and an attached RÖHM three-jaw chuck, diameter: 500 mm incl. large batch of clamping devices and a large batch of SK 50 tool holders, corresponding carriers incl. 60-fold tool changer incl. the tool holders in the tool changer shown in the photos incl. chip conveyor and coolant ...
Huvema X: 790 - Y: 420 - Z: 420 mm Max longitudinal travel X-axe: 790 mm Max cross-travel Y-axe: 420 mm Max travel Z-axe: 420 mm Max height workpiece: 440 mm Power on spindle: 3 HP Max quill travel Z´: 127 mm Admission in boring head (ISO): ISO 40 Spindlespeeds: 50 > 3750 rpm Table size: 1300 x 260 mm Digital screen: yes Weight: 1760 kg
Key data: 2800 mm, 1000 mm, 1000 mm
CNC Bed Milling Machine Manufacturer: Zayer Year of manufacture 1989 Control Heidenhain TNC155 Monitor has already been replaced Table size 800 x 3000mm Travel X/Y/Z 2800/1000/1000 24 Way Tool Changer Tool holder SK50 Head swivels over program The machine is in a 100% functional condition. Machine is sold from the Saarland Illingen site. Loading can be done by us for an extra charge
X-axis travel: 1,050 mm Y-axis travel: 550 mm Travel Z-axis: 520 mm Spindle speed (max.): 12,000 rpm Overall height: 2,778 mm Overall width: 2,977 mm Overall length: 3,635 mm Total weight: 6,700 kg Workpiece weight (max.): 800 kg - Control: SIEMENS 828 D incl. OPERATE and ShopMill - Number of magazine slots: 30 - Tool holder: BBT 40 - Internal cooling: 20 bar - Tool weight: max. 8 kg - Tool change time: 3 s - Chip-to-chip time: 5.5 s - Blum probe ZX-Speed IR - Blum 3-D touch probe TC-52 LF
MAKTEK VM 400 CNC vertical machining center was built in 2015 in Poland by MAKTEK Jerzy Zalewski (currently CORMAK). The machine is suitable for both unit and series production, particularly for manufacturing components requiring high precision and repeatability. It enables precise milling, threading and drilling of workpieces using a reliable spindle. The spindle, driven by a high-power motor, reaches a maximum speed of 4000 rpm. It cooperates with an automatic, 10-position tool magazine, streamlining the subsequent machining operations. The rigid design of the MAKTEK VM 400 CNC milling machine ensures stable operation even during intensive use. The machine is equipped with a SIEMENS SINUMERIK 808D MILLING CNC controller with an intuitive interface. The VM400 CNC machining center weighs 1850 kg. Technical specifications of the MAKTEK VM 400 milling center - CNC controller: SIEMENS S ...
spindle diameter: 115 mm x-travel: 2000 mm y-travel: 1200 mm control: Heidenhain TNC 355 Lotse z-travel: 1200 mm w-axis: 590 mm total power requirement: 48 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Used machine DMU 40eVo linear Machine Type: CNC 5-Axis Milling Center Model: DMU 40eVo linear Manufacturer: DMGMORI Control:CELOS Siemens 840D sl Operate Year of Make: 2022 #001431 Location: Germany Technical data Travel range X-axis approx. 400 mm Y-axis approx. 400 mm Z-axis approx. 375 mm C-axis 360° B-axis -5/+110 ° Workpiece diameter approx. 450 mm Workpiece weight max. approx. 250 kg Speed max. approx. 20,000 rpm Spindle motor approx. 35/25 KW Number of tool positions approx. 120 Rapid traverse approx. 80 m/min Pick-up taper approx. HSK63 Additional axles approx. 2 4th/5th Compressed air bar,L/min approx. 5, 300 bar,L/min Power consumption approx. 32 kVA Footprint L x W x H approx. 2.05x2.85x2.53 m (without pallet pool) Machine weight approx. 7,500 kg Facilities Dynamic Package for DMU 40 eVo linear - Motor Spindle speedMASTER® HSK-A63 RPM 20-20,0 ...
Manufacturer: Haas Automation Model: VF-2SS-EU Type: CNC vertical machining center (3-axis) Year: 2018 Serial number: 1148203 Condition: Used, good industrial condition Operating hours: Approx. 1,056 h (power-on time) Tool changes: 32,413 Voltage: 400 V / 3-phase Configuration: Super Speed variant Automatic tool changer (approx. 24–30 tools) Enclosed machining area with coolant system Haas NextGen control system Equipment: Tool holders included Machine vice Probe system Application: CNC milling and precision machining operations Additional notes: Machine shows normal wear (coolant residue, light oxidation on table), no visible structural damage; low operating hours for year → likely lightly used and well maintained
Year of manufacture 2010 TOP condition! Siemens Control Spindle 18000 rpm 10610 Spindle hours Tool changer for 30 tools IKZ el. Handwheel Chip conveyor
Used machine DMF200/8 Machine type: Universal milling center Model No.:DMF200/8 Manufacturer: DMGMORI Control: CELOS with Siemens 840D sl Operate Year of manufacture: 2023 Location:Germany Equipment: - Travelling column milling machine DMF 200/8 - NC swivel milling head (B-axis) - Motor spindle speedMASTER® - Tool holder SK40 DIN - Spindle speed 20 - 15,000 rpm 21 kW/16 kW - Chain magazine for 40 tools, - Chip conveyor (scraper belt) - Fixed table with integrated rotary table - Internal coolant supply 40 bar/600ll with paper belt filter - Oil and emulsion mist separators - Blowing air through the spindle center - Infrared probe PP60 optical - 3D quickSET - Laser tool measurement Blum LC50 Technical data Travel range X-axis approx. 2000 mm Y-axis approx. 800 mm Z-axis approx. 850 mm B-axis (head) +-120° ° Rotary table in table 800 mm Table size appro ...
Stock No.: 4041 MACHINING CENTER Manufacturer: FANUC, Type: ROBODRILL D21 Serial No.: P156YG066, Year of manufacture: 2015 Specifications: Longitudinal movement (X) 500 mm Transverse movement (Y) 500 mm Vertical movement (Z) 330 mm Spindle Taper 30 ISO Stepless spindle speeds 10000 rpm Tool Changer 21 Rapid traverse 54 Control FANUC 31i - B5 Controlled in axles 4 Operating hours spindle 12401 hours Accessories: Cooling by spindle CNC rotary table. Tool holders Tools Robot FANUC M-710 ic Dimensions: Weight: 2100 kg
Key data: 20000 mm, 7900 mm, 2500 mm
CNC Gantry Milling Machine Waldrich Coburg PowerTec 4500 Built in 1999 with Siemens 840C CNC control X 20,000 mm (longitudinal gantry) Y 7,900 mm (transverse travel of the milling ram) Z 2,500 mm (vertical travel of the milling ram) W 2,500 mm (transverse beam perpendicular) Distance between uprights 4,380 mm Distance from spindle to table max. 4,000 mm Spindle overhauled in 2023 Spindle motor power 105 KW Spindle speeds 2 – 2,500 rpm (2-stage gearbox) Torque S1 9,000 Nm Spindle holder ISO 60 / ISO 50 405-speed tool changer 5 milling heads Universal milling head automatic indexing 1° / 1° Offer number V(F)-7155
Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Rated current: 50 A Control: PHILIPS Tool holder: SK 40 Table dimensions: 550 x 280 m with 4 grooves and a vise attached, jaw width: 125 mm Travel X-axis: approx. 800 mm Travel Y-axis: approx. 400 mm Travel Z-axis: approx. 300 mm incl. documentation Reference: Süßen - Lot 12 Auction-ID: A7-49882-260
Universal Milling Machine Deckel Maho DMU 50 BJ 2004
CNC mortising milling machine MASTERWOOD OMB1 CN3KF • Year : 2005 • Working dimensions: 5600 × 300 mm • Numerical control: SINCRO on Windows PC • Router head: 4 kW • Vertical bar presser for top routing • Digitally controlled retractable backgauges • Table with motorized belt and side stops• Motorized vertical loader and side unloader• Automatic horizontal press (20–220 mm) • Vertical press (18–160 mm) – working up to 33 mm from the milling pin • Power supply : 400 V / 13.4 A / 50 Hz • Weight : 2000 kg Auction-ID: A1-50215-36
DECKEL MAHO DMC 63 V CNC vertical machining center was built in 2003 in Germany by DECKEL MAHO Geretsried GmbH. The machine has been regularly serviced and maintained throughout its entire service life. As part of the service work carried out, the CNC controller power supply, the coolant pump in the cooling system and the Y-axis cover scrapers were replaced. The gripper clamping force was adjusted and a new spindle covered by a one-year warranty was installed. The DECKEL MAHO DMC 63 V is designed for precision milling, drilling and threading of metal workpieces. Machining is performed by a spindle cooperating with an automatic, 24-position tool magazine. The spindle, driven by a high-power motor, reaches a maximum speed of 10000 rpm. The tool measuring probe, together with the readout system supports correct tool setting, ensuring high precision of the operations performed. All proces ...
Equipped with: INCL ALL TOOLS, X/Y/Z range of 500/400/400 mm, table of approx. 680 × 380 mm, ISO 40 tool holder, spindle speed 20–3,150 rpm, feed range 1–3,000 mm/min, rapid traverse 6 m/min, swivelling milling head ±90°, main spindle motor 5 kW, total connected load approx. 12 kW Auction-ID: A1-47363-78
Equipped with: Renovated in 2019 with a different Siemens control cabinet, several tools (see last photos) a boring spindle of Ø90 mm, Morse 5/ISO 40 taper, spindle speed of 28–1,400 rpm, spindle extension of 700–710 mm, table travels of 1,250 mm across, 1,400 mm longitudinally and 1,120 mm vertically, a table of approximately 1,800 × 1,120 mm, maximum workpiece weight of 3,000 kg, 7.5 kW main motor, front plate of Ø480 mm, weight of approx. 11,200 kg Auction-ID: A1-47363-76
x-travel: 800 mm y-travel: 340 mm z-travel: 460 mm Control: Fanuc total power requirement: kW weight of the machine ca.: 3,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Technical data Manufacturer: Haas Automation, Inc. Model No.: VF-3YT Serial Number: 1126820 Date of manufacture: 03/2015 Travels: X 1,016 mm / Y 660 mm / Z 635 mm Table: approx. 1,372 × 610 mm, 7 T-slots, 80 mm spacing Spindle holder: 40-taper Power supply: 3-phase, 50/60 Hz, 354-488 V AC Full load current: 40 A Maximum load current: 70 A Control: Haas CNC Control Version: Vertical CNC machining center, YT version with extended Y-travel Configuration Equipment: Tool changer with tool holders, T-slot table, work area with cooling/lubrication device. Remarks - 2026 Buffer battery replaced - Without clamped or surface-mounted tools! Offer refers to the machine only! Note Only operating instructions, but no technical documents available. Information researched to the best of our knowledge and belief. No guarantee is assumed for completeness and corre ...
x-travel: 2000 mm y-travel: 1250 mm z-travel: 1108 mm turning speeds: 60 - 4000 U/min spindle motor: 38 / 24 kW tool taper: SK 50 tool change unit: 40 Pos. table surface area: 1600 x 1250 mm table load: 7 t c-axis: +/- 120 ° B-axis (table): 360.000 pos control: Heidenhain ITNC 530 total power requirement: - kVA weight of the machine ca.: 16,5 t dimensions of the machine ca.: 5,5 x 4 x 2,9 m 5-axis machining center with - CNC control Heidenhain iTNC 530 - NC rotary table with B-axis - Automatic swivel milling head (C-Axis) - 40-fold tool changer (SK 50) - Electronic handwheel - 2 Chip conveyor - Coolant device 30 l/min - Coolant through Center The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
for sale is a MAHO600E which is currently not running because the emergency committee reports an error (ERR 0 23,M 02).
Key data: 880 mm, 630 mm, 630 mm
CNC Universal – Milling & Drilling Machine DECKEL MAHO DMU 80 T With track control Heidenhain iTNC 530 Year of Make: 2002 Travel: X 880 Y 630 Z 630 Speed range: 0 – 18,000 rpm infinitely variable ( SK 40 ) With the following accessories: NC Rotary Table 0 700 mm integrated into Rigid Angle Table 1250 mm x 700 mm Clamping surface Vertical tool changer with 32 magazine positions (SK 40) Full protection cabin with sliding doors and interior lighting Electronic handwheel Operating mode 3 + 4 Spiral Screw Conveyor Coolant Setup 3-Piece Height Adjustable Machine Shoes Spindle Oil Cooler Control cabinet cooling unit (Rittal) Operating Instructions
x-travel: 1250 mm y-travel: 500 mm z-travel: 500 mm Control: Heidenhain tnc 124 serial number: 5277 table size: 1800 - 360 mm taper ISO: 50 weight of the machine ca.: 3 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 3500 mm y-travel: 2500 mm z-travel: 1000 mm Control: HEIDENHAIN iTNC-530 table-size: 4.500 x 1.500 mm distance between columns: 2300 mm rapid travel x/y/z: 15/12.000 mm/min feeds: 5.000 mm/min tool taper: ISO 50 number of spindle speeds: 5000 U/min/rpm Spindle power: 30 kW table weight: 10 t handwheel: HR- 410 weight of the machine ca.: 31 t dimensions of the machine ca.: 11 x 3,44 x 4,9 m - CNC control Heidenhain iTNC 530 - Tool changer 30-fold (ISO 50) - Milling head CH -45 - Coolant through spindle - Chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
X-axis: 2000mm, Y-axis: 1200mm, Z-axis: 1500mm, table surface: 2200x1200mm, number and width of T-slots: 7x22mm, distance between T-slots: 140mm, max. workpiece weight on table: 7.2t, working feed rate: 0-12,000mm/min, rapid traverse: 15m/min, acceleration: 1.5m/s², hydraulic unit power: 5.5kW, pump flow rate: 25l/min, working pressure: 110bar, tank capacity: 180l, cooling unit capacity: 6,100W, compressor power: 2.61kW, length: 5820mm, width: 6723mm, height: 3602mm, weight: 17t, spindle operating hours: 5,000h, with documentation, an on-site inspection is possible.
