mechanical trim press used for sale

Supply system for sliding ring seals / pressure tank 12L Manufacturer: Fluiten Material: Stainless steel (1.4301) Built: 2000 Volume: 12 L Pressure (max): 16 bar Temperature (max): 99 °C Height: 430 mm (without gauge) Diameter: 219 mm incl. thermometer, gauge and sight glass Condition: new and unused Connections: see drawing Item can be inspected at any time in 76694 Forest by arrangement.

Qty. 1 Second-hand press for production of Aluminium pots and discs Mfc.: SITI Built: 2005 Renewed in by experts Duration: 3-4 months Force: 4000 Ton Production of Aluminium discs & induction & normal pots Pots height: 120 / 140 mm The press will be overhauled and revamped and sold as specified below: New Piston Grinding of cylinder New Flange Table modification New pumps New gaskets etc . New electric and electronical parts New program

BENELLI PEZM/800/600/4P 800T mechanical press was built in 1971 in Italy. The machine is designed for the precision cold working of metals. It enables the performance of demanding operations such as blanking, stamping and the forming of large-size components. Its high press force of 800 tonnes in combination with a wide range of machining capabilities makes it an excellent choice for industrial plants specialising in the mass production of parts for the automotive and machinery industries. The BENELLI PEZM/800/600/4P features a drive system based on a flywheel and an eccentric gearbox, which converts the rotational movement of the shaft into the reciprocating movement of the slider. This solution ensures smooth and repeatable operation throughout successive production cycles. Tools are positioned on the work table with centring pins and then fixed to the table and the slider with bolt ...

MOSSINI PDM/4B 1000T mechanical press was built in 2009 in Italy by Mossini SpA. The machine is designed for the precision blanking, stamping and forming of large-size components. The combination of high press force and wide machining capabilities makes the press ideal for the mass production of components used, among others, in the automotive and machinery industries. The MOSSINI PDM/4B 1000 is distinguished by its high press force of 1000 tonnes. Its drive system is based on a flywheel and an eccentric gearbox, which cooperate with four connecting rods. This solution enables uniform torque transmission and smooth control of the slider movement. Tools are positioned on the work table with centring pins and fixed with clamps, whilst they are fixed to the slider with bolts. The work table can be moved outside the press’s work area to carry out the assembly or disassembly of tooling,  ...

SPIERTZ F2E32-22 320T mechanical press was built in 1982 in Germany. The machine is designed for series and mass production of parts used in the automotive and machinery industries. It enables the cold forming of metals, such as blanking, stamping, and forming of large-sized parts. All these operations are performed with a press force of 320 tons. The drive system of the SPIERTZ F2E32-22 press is based on a flywheel and an eccentric gear that converts the rotational motion of the shaft into the reciprocating motion of the slider. This solution ensures smooth machine operation and high machining repeatability. Tools are positioned on the work table with centring pins and then fixed to the table and the slider with bolts. The SPIERTZ F2E32 320T press also stands out for its rigid design, which ensures reliable operation in demanding production conditions. Technical Specifications of the ...

VORONEZH K8544 Hot Forging press YEAR : 1980 / 2008 OVERHAUL AND INSTALLED FORCE : 2500ton RAM STROKE : 350 mm RAM SIZE : 1120X1070 mm TABLE OVERALL SIZE : 1400X1200 mm NUMBER OF STROKES IN CONTINUOUS MODE : 60 NUMBER OF STROKES IN MANUAL MODE : 26 SHUT HEIGHT : 890 mm STROKE OF UPPER KNOCK OUT : 60 mm STOROKE OF LOWER KNOCK OUT : 70 mm MAIN MOTOR : 132KW (CHANGED TO HYUDAI HEAVY Y2012) PRESS OVERALL DIMENSION : 5380X4680X6400 mm HYDRAULIC BOLSTER NEW IN 2007 CONDITION : VERY GOOD WORKING CONDITIONS Trimming press available

Maximum force of slide: T 250 Stroke of slide: mm 400 Stroke rate per min 12 Adjustability of slide: mm 120 Bed area (W x D): mm 2500x1400 Main motor power: kW 32 Max depth of extraction 100mm pressing force during the maximum depth of extraction T 100 Force holding extract unit: T 50 Height above ground: mm 5000 Weight: 66 ton

CONTROLS   PC controller BECKHOFF PRESS DESIGN   drive system: knuckle-joint SLIDE   total force (nominal): 250 to   stroke: 61 mm   stroke rate (max.): 60 /min COUNTER RAM   nominal force: 75 to   stroke: 15 mm V-RING   nominal force: 75 to   stroke: 13 mm TOOL DIMENSIONS   lower table (left-right): 540 mm   lower table (front-back): 540 mm   upper table (left-right): 540 mm   upper table (front-back): 540 mm   shut height max.: 320 mm   ram adjustment: 145 mm   distance between columns (H-frame): 560 mm   passline opening (free passage in side columns): 270 mm STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 250 mm   sheet thickness max.: 10 mm   feeding step max.: 999.99 mm   sheet length min: 1900 mm   pilot release system: yes   band lubrication system: yes Complete refurbished fineblanking press: disassembly into indivi ...

LVD brand press - type TPI 80/25 - 80 ton

CONTROLS   PLC SIEMENS S7 PRESS DESIGN   drive system: link drive   feedstock transport direction: left to right SLIDE   total force (nominal): 80 to   stroke: 50 mm   stroke rate (max.): 80 /min COUNTER RAM   nominal force: 22 to   stroke: 8 mm V-RING   nominal force: 25 to   stroke: 15 mm TOOL DIMENSIONS   lower table (left-right): 420 mm   lower table (front-back): 420 mm   upper table (left-right): 420 mm   upper table (front-back): 420 mm   shut height max.: 220 mm   ram adjustment: 80 mm   distance between columns (H-frame): 450 mm   passline opening (free passage in side columns): 200 mm OVERALL SPECIFICATIONS (COIL LINES)   sheet width max.: 180 mm   sheet thickness max.: 5 mm   feed velocity max.: 999 m/min STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 180 mm   sheet thickness max.: 5 mm   feeding step max.: 999 m ...

Mechanical Dorst TPA 45, Pressing Force max. 450 Kn, Withdrawal force max. 250 Kn, Supporting force in pressing position max. 130 Kn, Die return force max. 60 Kn, Upper punch stroke 120 mm, Upper punch adjusting travel 70 mm, Number of strokes 6-22 1/min, Filling height max. 120 mm, Pressing travel max. 60 mm, Withdrawal travel max. 60 mm, Top pressing travel max 6 mm, Upper punch pneumatic preload max. 30 mm, Compressed air supply , Air consumption , Intake air aprox. 70 l/min, Total connected load aprox. 14,0 Kw, Press dimensions:, Width aprox. 1550 mm, Depth aprox. 1650 mm, Height aprox. 2200 mm, Weight of the press aprox. 3900 Kg, Oil filling quantity :, Press housing 45 l (gear oil), Workplace-related sound 79 dB (A)

Pressing Force max: 1400 Kn, Withdrawal force max: 1100 Kn, Die return force max: 70 Kn, Upper punch stroke: 220 mm, Upper punch adjusting travel: 220 mm, Number of strokes: 5-18 1/min, Filling height max: 180 mm, Pressing travel max: 90 mm, Withdrawal travel max: 90 mm, Top pressing travel max: 18 mm, Total connected load aprox: 25,0 Kw, Width aprox: 1950 mm, Depth aprox: 1750 mm, ISO 9001: 2008 CERTIFIED COMPANY, Height aprox: 4380 mm, Press housing: 240 l (gear oil), Workplace-related sound: 78 dB A

CONTROLS   PLC SIEMENS S7 PRESS DESIGN   drive system: knuckle-joint   frame design: H-frame, monoblock   openings in uprights: yes   number of suspensions: 2   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 315 to   nominal work capacity: 38 kNm PRESS TABLE   table surface (left-right): 2000 mm   table surface (front-back): 1200 mm   thickness of bolster plate: 200 mm SLIDE   slide force: 315 to   table surface (left-right): 1995 mm   table surface (front-back): 1100 mm   stroke: 160 mm   stroke rate (max.): 80 /min SLIDE (MECHAN. PRESS)   slide adjustment: 140 mm   stroke rate (min.): 20 /min   stroke rate (max.): 80 /min   main drive power: 90 kW TOOL ASSEMBLY DIMENSIONS   shut height (stroke down, adjustment up), BDC: 555 mm   distance between columns (H-frame): 2060 mm   passline opening (free passag ...

The Dorst TPA 50/4 is a reliable, used mechanical powder compaction press designed for precision and efficiency. Offering a robust maximum pressing force of 500 kN and a maximum withdrawal force of 400 kN, it supports a variety of powder compaction tasks. With a filling height up to 180 mm and a pressing stroke of up to 90 mm, this machine is adaptable to diverse requirements. Equipped with an upper punch stroke of 120 mm and an adjustable travel of 220 mm, the Dorst TPA 50/4 provides flexibility for different applications. It operates at a speed of 7 to 32 strokes per minute, ensuring efficient production. The press requires a compressed air supply, consuming approximately 200 liters per minute, with a total connected load of around 18 kW. Constructed with durability in mind, the press measures approximately 2000 mm in width, 1700 mm in depth, and 3250 mm in height, and weighs around 5, ...

The Dorst TPA 5 is a refurbished mechanical powder compaction press, designed for precision and efficiency in industrial applications. It offers powerful performance with a maximum pressing force of 50 kN and a withdrawal force of up to 40 kN. This makes it suitable for a variety of powder compaction tasks, with a filling height of 50 mm and pressing travel capability of 25 mm. This machine provides flexibility with an upper punch stroke of 85 mm and an adjustable travel span of 70 mm, operating at 6 to 30 strokes per minute. It consumes around 50 liters of compressed air per minute and has a total electrical load of approximately 4.00 kW. With durable construction, the Dorst TPA 5 maintains a quiet operation at a sound level of 70 dB(A). The presss compact dimensions, approximately 1200 mm in both width and depth and a height of 2150 mm, with a weight of about 1,200 kg, make it a manage ...

gebr. Post-bending press Fabr. Graebener, Type GRNM, YOC 2005 max. bending force 16 t. Tool length 1,600 mm Adjustment of the underswing, hydraulic 2 cylinders Dimensions 5080 x 3290 x 2540 mm Kj Uovvlllerhyxkenb Weight 65 t.

Capacity: 1600 tons Slide stroke: 300 mm Slide stroke length at maximum force: 0,16 mm Distance adjustment between tableand slider: 10 mm Slide stroke number in 1 min: 75 Length of a rod: 920 mm The closed height: 660 mm Table overall dimensions: 940x1200 mm Table height above floor level: 450 mm Slide overall dimensions: 860x910 mm The size of lateral windows: -Height: 560 E5931468 mm -Width: 600 mm Main motor: 110 kW Press overall dimensions: -Length: 5060 mm -Width: 3940 mm -Height above floor level: 5125 mm Press weight: 120 tons

The Dorst TPA 15/3 is a used mechanical powder compaction press designed for precision and efficiency in industrial applications. It provides a maximum pressing force of 150 kN and a withdrawal force of 100 kN, supporting a variety of compaction tasks. With an upper punch stroke of 100 mm and a range of 70 mm for adjusting the travel, this machine offers flexibility for different requirements. Operating at speeds of 7 to 32 strokes per minute, it ensures a reliable production throughput. This press allows for a maximum filling height of 70 mm and pressing travel up to 35 mm, suitable for a range of powder compaction needs. The machine is fitted with a compressed air system that has an intake of around 70 liters per minute and a total connected load of approximately 6 kW. It is compact yet robust, with dimensions of about 1400 mm in width, 1300 mm in depth, and 2650 mm in height, weighing ...

The Dorst TPA 6 is a used mechanical powder compaction press suitable for various industrial applications due to its robust performance and flexibility. It boasts a maximum pressing force of 60 kN and a withdrawal force of 30 kN, addressing a wide range of compaction needs. The machine supports a maximum filling height of 70 mm and a pressing travel of 30 mm, with an upper punch stroke of 95 mm and an adjustable travel of 50 mm. This ensures precise control over the compaction process. Operating at speeds between 7 to 32 strokes per minute, the Dorst TPA 6 consumes approximately 70 liters of compressed air per minute and has a total connected load of about 3.5 kW. It measures 2220 mm in width, 1060 mm in depth, and 2250 mm in height, weighing around 1,200 kg. With a gear oil capacity of 12 liters and a workplace-related sound level of 75 dB(A), it is designed to endure continuous use whi ...

The Dorst TPA 4 is a used mechanical powder compaction press well-regarded for its sturdy performance in various industrial settings. It features a maximum pressing force of 40 kN and a withdrawal force of 30 kN, making it versatile for different compaction tasks. With a maximum filling height of 70 mm and a pressing travel of 30 mm, this machine efficiently handles varied operational demands. The upper punch has a stroke of 95 mm with an adjustable travel of 50 mm, enabling precise control during processes. The press operates within a speed range of 7 to 32 strokes per minute, consuming around 70 liters of compressed air per minute and requiring a total connected load of approximately 3.5 kW. It is designed with dimensions of 2220 mm in width, 1060 mm in depth, and 2250 mm in height, while weighing about 1,200 kg. The gear oil capacity is 12 liters, ensuring durability and the ability t ...

CONTROLS   PC controller BECKHOFF Offer for services of complete Overhaul of a Customer-Owned Fineblanking Press FEINTOOL GKP 160 Scope of Overhaul • Complete disassembly into individual components • Inspection of all parts, including crack testing of critical components • Overhaul of the drive system, new motors • Reworking and precise alignment of all guideways • Complete overhaul of the hydraulic cylinders • Overhaul of the clamping tables • Installation of a new hydraulic unit • Renewal of the pneumatic system • Renewal of the electrical system Modernisation / Retrofit • Combined table • Servo feed systems • Central lubrication system • RAZIOL band lubrication • New brake/clutch unit • BECKHOFF PC-based control system with touch panel • PILZ safety control system • Implementation of CE conformity Notes • Special options and customer-specific ext ...

CONTROLS   PC controller BECKHOFF PRESS DESIGN   number of slide actions: 13 SLIDE   slide force: 3 to   stroke: 60 mm   stroke rate (max.): 210 /min SLIDE (MECHAN. PRESS)   slide adjustment: 6 mm   variable speed: yes   stroke rate (min.): 70 /min   stroke rate (max.): 210 /min   main drive power: 4 kW DIMENSIONS / WEIGHTS   space requirements -left/right-: 2300 mm   space requirements -front/back-: 1000 mm   total height: 1900 mm   total weight approx.: 4000 kg

This SEYI SN1-110 was manufactured in 2002. It is a mechanical C-frame crank press with a 110 tons capacity and a stroke of 110 mm. The machine offers an adjustable speed range of 35–65 SPM, a maximum die height of 350 mm, and a main motor of approximately 11 kW (15 HP). Contact us for more information about this machine.

Capacity: 1600 tons Slide stroke: 300 mm Slide stroke length at maximum force: 0,16 mm Distance adjustment between table and slider: 10 mm Slide stroke number in 1 min: 75 Length of a rod: 920 mm The closed height: 660 mm Table overall dimensions: 940x1200 mm Table height above floor level: 450 mm Slide overall dimensions: 860x910 mm The size of lateral windows: -Height: 560 mm -Width: 600 mm Main motor: 110 kW Press overall dimensions: -Length: 5060 mm -Width: 3940 mm -Height above floor level: 5125 mm Press weight: 120 tons

CONTROLS   PLC SCHNEIDER PRESS DESIGN   drive system: eccentric / crank   number of slide actions: 11   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 66 to SLIDE   slide force: 6 to   stroke: 114 mm SLIDE (MECHAN. PRESS)   variable speed: yes   stroke rate (min.): 40 /min   stroke rate (max.): 130 /min   main drive power: 7.5 kW STRIP-FEEDER   feeder type: roll feeder TRANSFER SYSTEM   distance between tools, stroke X fixed: 82 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 2875 mm   space requirements -front/back-: 1500 mm   total height: 2900 mm   total weight approx.: 7500 kg ATTACHMENTS (PRESSES)   safety guard / safety door: yes   2-hand engagement: yes   noise protection cabin: yes   acc. to actual accident protection regulation: yes Specifications: Number of stations: 12 (11+1) Capacity  ...

The Dorst TPA 70 is a used powder compaction press, known for its precise and reliable performance. It delivers a maximum pressing force of 700 kN with a withdrawal force of 400 kN, making it suitable for diverse compaction needs. The machine features a pressing travel of up to 30 mm, with a maximum filling height of 70 mm and operates at speeds between 14 to 40 strokes per minute. This ensures efficient throughput, ideal for high-demand production environments. With an upper punch stroke of 120 mm and adjustable travel of 200 mm, the Dorst TPA 70S offers flexibility in application. It requires a compressed air supply with an intake of approximately 200 liters per minute, and operates on a total connected load of about 20 kW. To enhance functionality, the machine is constructed robustly, maintaining a workplace-related sound level of 78 dB(A), and features a press housing capacity of 190 ...

Crimping pliers, crimping pliers, cable lug pliers, mechanical crimping pliers, pressing jaws, pressing tool for cable end sleeves, wire end sleeves, cable lugs, hand crimping pliers, sleeve pliers, clamp sleeve pliers -Manufacturer: WMW, hand crimping pliers type PH 2.5C -Crimping: of cable lugs and cable connectors -Pressing force: 25.0 N -Pressing stroke: 15 mm -Transport case: incl. accessories, see photo -Quantity: 1x crimping pliers available -Price: per piece -Dimensions of pliers: 600/180/H25 mm -Total weight: 3.2 kg

The Dorst TPA 350 is a robust used powder compaction press, offering a maximum pressing force of 3500 kN. It is designed to handle demanding applications with efficiency, providing a maximum withdrawal force of 2500 kN and supporting force in pressing position up to 2000 kN. The die return force reaches a maximum of 80 kN. It features an upper punch stroke of 220 mm, with an adjusting travel of 200 mm, ensuring precision in operations. This press operates at a rate of 5-18 strokes per minute, catering to various production speeds. It accommodates a maximum filling height of 180 mm and allows a pressing travel and withdrawal travel both up to 90 mm. The top pressing travel is capped at 18 mm, with an upper punch pneumatic preload maximum of 60 mm, demonstrating versatility in its functioning. It operates with a compressed air supply consuming approximately 140 l/min, backed by a total con ...

CONTROLS   conventional PRESS FORCES   total force (nominal): 75 to PRESS TABLE   table surface (left-right): 1250 mm   table surface (front-back): 1110 mm SLIDE   table surface (left-right): 960 mm   table surface (front-back): 750 mm SLIDE (MECHAN. PRESS)   slide adjustment: 80 mm   stroke adjustment: yes   stroke min.: 10 mm   stroke max.: 50 mm   stroke rate (min.): 120 /min   stroke rate (max.): 600 /min STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 300 mm ELECTRICAL SPECIFICATIONS   total power consumption: 15.5 kW DIMENSIONS / WEIGHTS   total weight approx.: 13500 kg ATTACHMENTS (PRESSES)   strip feeder: yes   feeder type: roll feeder

Table dimensions ( x-y/mm) 2150 x 1200 Slide Dimensions X-Y (mm) 2000 x 1200 Stroke (mm) 300 Slide Adjustment (mm) 200 Stroke per minute 5 - 50 Lateral window dimensions ( x-y/mm) 800

Press force: 1,200 t Ram stroke: 600 mm Ram adjustment: 500 mm Stroke rate: approx. 10 – 16 strokes/min Shut height: approx. 1,250 mm Drawing equipment: Drawing cushion force: approx. 240 t Drawing cushion stroke: approx. 250 mm Pneumatic ejector in ram: Force: approx. 95 t Stroke: approx. 150 mm Table size: approx. 3,500 x 1,900 mm Heavy-duty mechanical eccentric press in robust double-column design from Schuler, suitable for industrial applications as well as classical forming and deep drawing processes. The machine features a press force of 1,200 t with a fixed ram stroke of 600 mm and a ram adjustment of 500 mm. The stroke rate ranges from approx. 10 to 16 strokes per minute, allowing flexible use depending on the application. The working area is designed with a table size of approx. 3,500 x 1,900 mm, offering sufficient space for medium to large tooling. A key feature is the ...

The Dorst TPA 20/3 is a reliable used powder compaction press known for its robust construction and precise operations. It offers a maximum pressing force of 200 kN and a withdrawal force of up to 100 kN. With a maximum filling height of 140 mm and pressing travel extending to 70 mm, it accommodates a range of powder compaction tasks efficiently. The press is capable of operating at speeds ranging from 5 to 22 strokes per minute, supporting a variety of production needs. It features an upper punch stroke of 200 mm, with an adjustable travel of 160 mm for flexibility across different applications. The machines air supply intake is approximately 160 liters per minute, and it has a connected load of about 15 kW. Constructed with dimensions of around 2000 mm in width, 1700 mm in depth, and 3250 mm in height, the Dorst TPA 20/3 weighs approximately 4,900 kg. It maintains a workplace sound lev ...

Mechanical stamping press manufactured in 2016. This AIDA 315/2MR/LD/TE3 features a press capacity of 315 tons and a stroke length of 250 mm. It includes a maximum die size of 2,250 × 750 mm and a maximum die weight on slide of 10,200 kg. If you are looking to get high-quality stamping capabilities, consider the AIDA 315/2MR/LD/TE3 machine we have for sale. Contact us for further details.

Mechanical stamping press manufactured in 2018. This AIDA 315/2MR/LD/TE 3 features a press capacity of 315 tons and a stroke length of 250 mm. It has a maximum die size of 2,250 × 750 mm and can accommodate a maximum die weight of 10,200 kg. If you are looking to get high-quality stamping capabilities, consider the AIDA 315/2MR/LD/TE 3 machine we have for sale. Contact us for further details regarding this machine.

Mechanical stamping press manufactured in 2013. This AIDA 315/2MR/LD/TE 3 features a press capacity of 315 tons and a stroke length of 250 mm. It is designed for high-precision stamping operations with a robust double-upright frame and integrated drawing cushion. If you are looking to get high-quality stamping capabilities, consider the AIDA 315/2MR/LD/TE 3 machine we have for sale. Contact us for further details regarding this machine.

Mechanical stamping press manufactured in 2012. This Colombo Agostino T231A315 features a nominal press capacity of 315 tons and a slide stroke of 250 mm. It includes a motorized slide adjustment of 315 mm and a bed dimension of 1120 mm x 960 mm. If you are looking to get high-quality stamping capabilities, consider the Colombo Agostino T231A315 machine we have for sale. Contact us for further details.

The used DORST DK 100 is a robust sizing and powder compaction press designed for high-performance industrial applications. Capable of a maximum pressing force of 1000 Kn and a withdrawal force of 500 Kn, this machine provides powerful and reliable operation. It accommodates a filling height of up to 110 mm with a pressing travel of 50 mm, ensuring versatility for various compaction tasks. The upper punch stroke is 140 mm, with adjustable travel up to 75 mm, allowing for precise control over pressing operations. This model offers between 5 and 22 strokes per minute, giving you flexibility in production rates. The die return force is 100 Kn, while the supporting force in the pressing position reaches 300 Kn. Pneumatic operations are supported with an upper punch preload of up to 30 mm and compressed air consumption of approximately 80 liters per minute. It requires a total connected load  ...

The Dorst TPA 15/3 is a used mechanical powder compaction press designed for precision and efficiency in industrial applications. It provides a maximum pressing force of 150 kN and a withdrawal force of 100 kN, supporting a variety of compaction tasks. With an upper punch stroke of 100 mm and a range of 70 mm for adjusting the travel, this machine offers flexibility for different requirements. Operating at speeds of 7 to 32 strokes per minute, it ensures a reliable production throughput. This press allows for a maximum filling height of 70 mm and pressing travel up to 35 mm, suitable for a range of powder compaction needs. The machine is fitted with a compressed air system that has an intake of around 70 liters per minute and a total connected load of approximately 6 kW. It is compact yet robust, with dimensions of about 1400 mm in width, 1300 mm in depth, and 2650 mm in height, weighing ...

pressure: 1000 t distance between columns: . mm stroke: . mm total power requirement: . kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SLIDE   total force (nominal): 40 to   stroke rate (max.): 110 /min TOOL DIMENSIONS   lower table (left-right): 300 mm   lower table (front-back): 280 mm   shut height max.: 180 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 1835 mm   space requirements -front/back-: 1500 mm   total height: 1800 mm   total weight approx.: 2500 kg

The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SCHMIDT EP345 ist eine Elektropresse, ausgelegt für präzise Bearbeitung mit hoher Genauigkeit und Zuverlässigkeit. Hub maximal 150 mm, Geschwindigkeit 200 mm/s, Presskraft 10 kN; Eigengewicht 59 kg. Technische Eckdaten: Geschwindigkeit 200 mm/s, Hub 150 mm, Presskraft 10 kN, Gewicht 59 kg. Ermöglicht das Erreichen enger Toleranzen und eignet sich für Automobilindustrie, Uhrenindustrie, Werkzeugmaschinenbau, Luft- und Raumfahrt sowie Medizintechnik. Technische Daten ohne Gewähr

CONTROLS   PC controller BECKHOFF PRESS DESIGN   drive system: knuckle-joint SLIDE   total force (nominal): 160 to   stroke: 60 mm   stroke rate (max.): 70 /min COUNTER RAM   nominal force: 40 to   stroke: 14 mm V-RING   nominal force: 50 to   stroke: 10 mm TOOL DIMENSIONS   lower table (left-right): 480 mm   lower table (front-back): 520 mm   upper table (left-right): 480 mm   upper table (front-back): 520 mm   shut height max.: 314 mm   ram adjustment: 80 mm   distance between columns (H-frame): 500 mm   passline opening (free passage in side columns): 220 mm STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 210 mm   sheet thickness max.: 6 mm   feeding step max.: 999.9 mm   sheet length min: 2000 mm   pilot release system: yes   band lubrication system: yes Complete refurbished fineblanking press: disassembly into individua ...

CONTROLS   PLC SIEMENS SIMATIC OP 47-12 PRESS FORCES   total force (nominal): 200 to PRESS TABLE   table surface (left-right): 2440 mm   table surface (front-back): 1500 mm SLIDE   table surface (left-right): 1500 mm   table surface (front-back): 1100 mm   stroke: 180 mm SLIDE (MECHAN. PRESS)   slide adjustment: 150 mm   stroke rate (min.): 20 /min   stroke rate (max.): 120 /min   main drive power: 45 kW OVERALL SPECIFICATIONS (COIL LINES)   sheet thickness max.: 2.5 mm DECOILER   sheet width max.: 300 mm   sheet width (min): 30 mm   coil weight max.: 3 to   max. diameter of coil: 1500 mm   mandrel expansion range from: 460 mm   mandrel expansion range up to: 530 mm LEVELLER UNIT   sheet width max.: 30 mm   sheet width (min): 300 mm   number of leveller rolls: 9   diameter of leveller rolls: 30 mm   number of intermediate rolls: 11   feed  ...

machine ready for transport and to be assessed on viewing day. machine has been repaired, see photos Auction-ID: A1-48648-7

PRESS DESIGN   drive system: hydraulic SLIDE   total force (nominal): 40 to   stroke: 45 mm   stroke rate (max.): 110 /min TOOL DIMENSIONS   lower table (left-right): 300 mm   lower table (front-back): 280 mm   shut height max.: 90 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 1835 mm   space requirements -front/back-: 1500 mm   total height: 1800 mm   total weight approx.: 2500 kg

SLIDE   total force (nominal): 80 to   stroke rate (max.): 120 /min V-RING   stroke: 90 mm TOOL DIMENSIONS   lower table (left-right): 420 mm   lower table (front-back): 420 mm   upper table (left-right): 420 mm   upper table (front-back): 420 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 2970 mm   space requirements -front/back-: 1665 mm   total height: 242 mm   total weight approx.: 6000 kg

Max plate thickness: 2.5mm. Max working width: 1020mm. In working order. Auction-ID: A3-46156-6141

Raskin mechanical press manufactured in Angleur (Belgium). Estimated capacity of 35 tons. Heavy cast iron machine equipped with flywheel, grooved table and mechanical clutch. Sold in the condition visible in photos. Ideal for punching, light cutting, stamping or workshop work. Auction-ID: A3-46126-35825

pressure:800 t distance between columns:2900 mm stroke:350 mm Controls:SIEMENS PRESS DESIGN:. - frame design : H-frame :. - Drive type : mechnical :. - openings in uprights : yes :. - number of cushions:0 - opening in table : yes :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):800 to PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - rectangular breakthrough (width):2000 mm - rectangular breakthrough (front-back):1800 mm - height above floor level:850 mm RAM:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):2900 mm - Free passage between side columns (width):2560 mm ...
