Bridgeport EZ Path S Used machine (very good) Control type Cnc Built 2001 Hours K.a. Price 12,500 € net plus VAT Dimensions 3100x1850x1500 Weight 2500 kg Location Haiger Description Universal CNC cycle deer of the brand Bridgeport suitable for tooling, fixture construction, training as well as mold making • Circulation diameter: 430mm • Control: Fanuc 20T Technical data • Circulation diameter 430mm • Peak width 1000mm • Control Siemens Fanuc 20 T • Reitstock MK 4 • Multifix tool station • Speed 1-4000rpm • Connection 380V - 7.5 KW

Merli Clovis 70 heavy lathe. Distance between centers: 8000mm. Swing: 1650mm. Swing in carriage: 1170mm. Bore: 206mm. Bed width: 1000mm. Speeds: 16.(3-300). Maximun weight without steady rest: 15.000Kgs. Maximun weight with 1 steady rest: 20.000Kgs. Equipped with chuck of 1400mm. Equipped with DRO. Equipped with 2 steady rest. Equipped with CE protections and CE certificate for second hand machines.

Technical data: Turning diameter over bed: 520 mm Turning diameter via support: 310 mm Turning length: 1000 mm Circulation diameter in recess: 580 mm Peak height: 250 mm Bed width: 410 mm Spindle bore: 62 mm Spindle flange: Camlock Gr. 8 Spindle speeds: 24: 9 - 1800 rpm Machine weight approx.: 2.75 t Space requirements approx.: 2.8 x 1.3 x 1.3 m Electrics 380 Volt: 32A Three-jaw lining: 315 mm Forkart Coolant device Measuring system: Glasstab 0.005mm resolution on all 3 axes Quick-release steel holder " Multifix ": C

harden machine 1x1x2m temperature max 1200C PLC Wärmebehandlungs Kammeröfen Wärmebehandlungs gienanth Schachtöfen Haubenöfen Härten Anlassen bei niedriger und hoher Temperatur Glühen Normalglühen Austenitisieren Spannungsfreiglühen Vorwärmen vor dem Schmieden Rollenherdöfen Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemeister Doosan Daewoo traub hwacheon index Wema zeulenroda mueller Erfurt t ...

Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 4000mm. Spindle nose: 51mm. Motor power: 12,5cv. Equipped with universal chuck of 250mm and steady rest. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.

Cazeneuve HB500 rebuilt lathe. Distance between centers: 2000mm. Swing over bed: 500mm. Swing over carriage: 220mm. Motor power: 10cv. Spindle nose: 40,5mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Equipped with universal chuck of 250mm and steady rest. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.

Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 750mm. Motor power: 12,5cv. Spindle nose: 51mm. Equipped with universal chuck of 250mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: Steady rest. Optional: CE back guard

Code 93024 Description Chucking lathe Make Warner & Swaswy Model 0 - AC Serial No. 2083651 Year 1972 Swing over bed 200 mm Swing over gap 200 mm Swing over crossslide 200 mm Spindle bore --- mm Longitude: 140 mm Cross: 100 mm Chuck : 160 mm Bore: 20 mm Number of spindle speeds 32 Spindle speeds 58 - 2507 rpm Feeds Longitude and cross Motor power 5,5 kW – 380 Volts Accessoiries hydraulic 3 chuck coolant Condition Machine is in good condition.

turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1000 mm spindle bore: 58 mm spindle turning speed range: 25 - 2000 U/min turning dia. in gap: 690 mm metric threading: 41 / 0,1 - 14 mm thread - inch: 60 / 2 - 112 inch. thread - module: 34 / 0,1 - 7 mm Whitworth-thread: 60 / 2 - 112 TPI adjustment of the upper slide: 140 mm dia. of quill: 60 mm quill stroke: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1,7 / 2,0 t dimensions of the machine ca.: 2,2 x 1,0 x 1,3 m A comprehensive range of quality centre lathes characterised by wide versatility,high accuracy and extremely rigid construction. The machines are well equipped with a multi-fix quick change tool post and 2-axis Newall digital readout fitted as standard and a variable speed option is available. Huvema lathes fully conform to CE regulations. Also available in: 1,5m 3 ja ...

turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1000 mm turning dia. in gap: 690 mm spindle bore: 58 mm spindle turning speed range: 25-2000 U/min feeds - longitudinal: 0,031-1,7 mm/U voltage: 400 V / 50 Hz total power requirement: 5,5 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2,3 x 1,0 x 1,5 m • with 3- and 4- jaw chuck, • 2 axis-digital display NEWALL, • fixed and live steady, • Machine light. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1500 mm spindle bore: 58 mm spindle turning speed range: 25 - 2000 U/min turning dia. in gap: 690 mm metric threading: 41 / 0,1 - 14 mm thread - inch: 60 / 2 - 112 inch. thread - module: 34 / 0,1 - 7 mm Whitworth-thread: 60 / 2 - 112 TPI adjustment of the upper slide: 140 mm dia. of quill: 60 mm quill stroke: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1,7 / 2,0 t dimensions of the machine ca.: 2,2 x 1,0 x 1,3 m A comprehensive range of quality centre lathes characterised by wide versatility,high accuracy and extremely rigid construction. The machines are well equipped with a multi-fix quick change tool post and 2-axis Newall digital readout fitted as standard and a variable speed option is available. Huvema lathes fully conform to CE regulations. Also available in: 1,5m 3 ja ...

turning diameter over bed: 360 mm turning diameter over slide rest: 220 mm turning length: 1000 mm turning dia. in gap: 515 mm spindle bore: 38 mm spindle turning speed range: 30 - 2200 U/min feeds - longitudinal: 0,067 - 1,485 mm/U feeds - cross: 0,033 - 0,742 mm/U voltage: 400 V / 50 Hz total power requirement: 2,5 kW weight of the machine ca.: 0,75 t dimensions of the machine ca.: 2,3 x 1,0 x 1,5 m • with 3- and 4- jaw chuck, • 2 axis-digital display NEWALL, • fixed and live steady, • Machine light. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 2000 mm spindle bore: 58 mm spindle turning speed range: 25 - 2000 U/min turning dia. in gap: 690 mm metric threading: 41 / 0,1 - 14 mm thread - inch: 60 / 2 - 112 inch. thread - module: 34 / 0,1 - 7 mm Whitworth-thread: 60 / 2 - 112 TPI adjustment of the upper slide: 140 mm dia. of quill: 60 mm quill stroke: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1,7 / 2,0 t dimensions of the machine ca.: 2,2 x 1,0 x 1,3 m A comprehensive range of quality centre lathes characterised by wide versatility,high accuracy and extremely rigid construction. The machines are well equipped with a multi-fix quick change tool post and 2-axis Newall digital readout fitted as standard and a variable speed option is available. Huvema lathes fully conform to CE regulations. Also available in: 1,5m 3 ja ...

turning diameter over bed: 1090 mm turning diameter over slide rest: 690 mm turning length: 5000 mm spindle bore: 146 mm spindle taper: DIN 55027/15 turning diameter in the gap: 1250 mm bed width: 700 mm quick change tool holder: Größe D1 spindle turning speed range: 3,5 - 1000, stufenlos U/min feeds - longitudinal: 1-3000 mm/min feeds - cross: 1-3000 mm/min rapid travel - longitudinal/face: 6000 mm/min thread - mm pitch: 0,5 - 480 mm thread - inch: 60 - 1/16 Gang / inch. thread - module: 0,125 - 120 voltage: 400 V / 50 Hz main drive: 30 kW Control: total power requirement: 35 KVA weight of the machine ca.: 7,2 t dimensions of the machine ca.: 7,2 x 1,75 x 1,9 m • new heavy duty lathe with infinetely variable rotation speed via frequency converter, • at basic price with normal accessories according to list, • possible special acccessories according to separate make-up. The dat ...

turning diameter over bed: 460 mm turning diameter over slide rest: 274 mm turning length: 1000 mm spindle bore: 58 mm turning dia. in gap: 690 mm spindle taper: Größe 6, DIN 55029 spindle turning speed - stepless: 30 - 2000 U/min feeds - longitudinal: 0,031 - 1,7 mm/U thread - mm pitch: 0,1 - 14 mm thread - inch: 2 - 112 Gang / inch. tailstock quill diameter: 60 mm tailstock quill taper metric: MT 4 tailstock quill stroke: 120 mm max. workpiece weight between centres: 500 kg voltage: 400 V / 50 Hz spindle motor: 5,5 kW total power requirement: 6 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2,9 x 1,2 x 1,5 m • stepless adjustable turning speed via frequency converter, digital display, 2-axe-DRO, Made:NEWALL The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 400 mm turning diameter over slide rest: 235 mm turning length: 1000 mm turning dia. in gap: 560 mm spindle bore: 52 mm spindle taper: Größe 6, DIN 55029 spindle turning speed - stepless: 18 - 2120 U/min feeds - longitudinal: 0,015 - 0,6 mm/U face feeds: 0,0075 - 0,3 thread - mm pitch: 0.25 - 7,5 mm thread - inch: 4 - 120 Gang / inch. tailstock quill diameter: 50 mm tailstock quill taper metric: MT 4 tailstock quill stroke: 120 mm max. workpiece weight between centres: 500 kg voltage: 400 V / 50 Hz spindle motor: 5,5 kW total power requirement: 7,5 kW weight of the machine ca.: 1,85 t dimensions of the machine ca.: 2,9 x 1,2 x 1,5 m • stepless adjustable turning speed via frequency converter, digital display, 2-axe-DRO, Made:NEWALL The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 720 mm turning length: 4000 mm control: Siemens 805 turn - diameter over facing slide: 360 mm spindle diameter: 100 mm spindle passage: 100 mm 3-jaw-chuck diameter: 400 mm 4-jaw-chuck diameter: 250 mm steady: 360 mm total power requirement: 22 kW weight of the machine ca.: t dimensions of the machine ca.: m 3- jaw chuck diameter: 400 mm 4- jaw chuck diameter: 250 mm Fixed bezel diameter: 360 mmIncludes: 4 jaw turrets and coolant. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 2100 mm turning diameter over slide rest: 1300 mm turning length: 6800 mm workpiece weight: 25000 kg main drive motor: 140 kW Control: Siemens type: 840 C faceplate: 1100 mm bed width: 2500 mm steady: 800 mm steady: 800 mm steady: 800 mm steady: 600 mm chip conveyor: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
