machining centers used for sale

CONTROLS   CNC controls SIEMENS SOLUTION LINE WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 3   X-axis travel: 600 mm   Y-axis travel: 560 mm   Z-axis travel: 510 mm TABLE   table surface (left-right): 900 mm   table surface (front-back): 560 mm   workpiece load (max): 600 kg SPINDLE / HEAD   spindle revolutions (min): 20 /min   spindle revolutions (max): 12000 /min   tool fixture: ISO SK 40   drive power S6 40%: 13 kW   drive power S1 100%: 9 kW   spindle torque S6 40%: 82 Nm   spindle torque S1 100%: 54 Nm AXIS DRIVES   traverse velocity X (max): 20000 mm/min   traverse velocity Y (max): 20000 mm/min   traverse velocity Z (max): 20000 mm/min   rapid traverse X: 30000 mm/min   rapid traverse Y: 30000 mm/min   rapid traverse Z: 30000 mm/min TOOL MAGAZINE   number of positions: 30   tool diameter max.: 80 mm   - wi ...

CONTROLS   CNC controls HELLER UNI-PRO CNC 90 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 4   X-axis travel: 800 mm   Y-axis travel: 800 mm   Z-axis travel: 710 mm TABLE   table surface (left-right): 630 mm   table surface (front-back): 500 mm SPINDLE / HEAD   spindle revolutions (max): 12000 /min AUTOMATIC WORKLOAD EQUIPMENT   store type: pallet changer   number of store positions: 2 ATTACHMENTS   chip conveyor: yes   European CE standards: yes Machine in production, under power Still available for sale: HELLER MCS-H 400 2001 DECKEL MAHO FP5-80 1994 HELLER MCH 200 1998

CONTROLS   CNC controls GRUNDIG DIALOG 12 WORKING RANGE -CUBIC-   X-axis travel: 800 mm   Y-axis travel: 550 mm   Z-axis travel: 500 mm SPINDLE / HEAD   spindle revolutions (max): 5000 /min   tool fixture: ISO SK 40 DIMENSIONS / WEIGHTS   total weight approx.: 4500 kg The machine needs a new control card (price €2,000).

vertical machining center, year 2001, CNC 18i MA. Used machine. More info & price on IndustrialBuyer.

axis stroke (X,Y,Z): 5.910,1.815,655 mm Number of spindle head vertical: 14 St. Number of spindles head horizontal: 4 St. main drive: 12 kW tool taper: HSK F63 Number of axles: 5 St. Number of tools: 20 St. working area: 5005 x 1450 x 200 mm Number of working hours: 3108 h Masterwood Project 455 L, 5-axis CNC machining center ----------------------------------------------------- Machine can be viewed while still in operation! Sold ex-site. Dismantling and reinstallation by experienced Masterwood technicians available as an option! The Masterwood Project 455 L is a highly flexible, numerically controlled 5-axis machining center featuring a robust gantry design. It has been specifically developed for the sophisticated, complete processing (drilling, milling, grooving) of solid wood, panel materials, windows, doors, and stairs. Thanks to its extended L configuration, the machine offers an e ...

axis stroke (X,Y,Z): 6175x1550x300 mm Number of spindle head vertical: 20 St. Number of spindles head horizontal: 10 St. Number of milling agregates: 1 St. Speed: 24.000 U/min. Capacity: 300 kg/h Sawing unit: ja_yes 0 Control: Homag PC85 CNC powerTouch HOMAG BMG 511 /60/12/F/K Profi ----------------------------------- Machine already professionally dismantled and stored at our warehouse in Oberkochen: - 5-axis CNC processing center - Moving gantry machine (dual-drive gantry system) - 1 HOMAG DRIVE 5 C+ routing spindle, 5-axis, HSK-F63, 15 kW, max. 24,000 rpm - 1 HOMAG Multi Processing Unit Drilling head with 30 spindles: V20 / H10 / S360° MPU MultiProcessingUnit with C-axis +/- 185° - 1 Chain tool changer, 30-position - Includes SL laser projector - Includes vacuum suction cups (as available) - Spare parts and accessories as shown in photos - Last HOMAG 5-axis service: 2024 - Last HOMA ...

Auction-ID: A1-50373-8031

USED AKIRA SEIKI PERFORMA V2.5XP MACHINING CENTER Year: 2011 Table dimensions: 910 x 400 mm Weight allowed on the table: 960 Kg Spindle power: 15 kW Spindle speed: 12,000 rpm Axis travel: X=760 - Y=445 - Z=520 mm Cone type: BT 40 Tool changer: 28 tools Equipped with 1 MITSUBISHI M70 CNC 1 Center coolant 1 Chip conveyor Auction-ID: A1-50950-1

USED MORI SEIKI NHX 5000 HORIZONTAL MACHINING CENTER Year: 2011 4 Axis Table Table dimensions: 500 x 500 mm Weight allowed on the table: 500 kg Maximum rotational diameter to be machined: 800 mm Maximum height to be machined: 1000 mm Indexing time: 1.49 seconds Spindle Spindle speed: 12,000 rpm Spindle cone: BT 40 Front bearing diameter: 80 mm Axes B-axis : 360,000 positions Axis travel: X=730 - Y=730 - Z=680 mm Fast feed: X - Y - Z = 60,000 mm/min Tool magazine Tool holder type: BT 40 Tool changer: 60 tools Tool-to-tool change time: 0.9 seconds Maximum tool weight: 12 Kg Pallets Number of pallets: 2 Pallet change time: 9 seconds Dimensions of the machine: 3100 x 4855 x H2850 mm Machine weight: 11,100 kg Equipped with 1 CN MORI SEIKI M730BM 1 Set of tool holders 1 Watering by shower 1 Hydro fluid high-pressure unit 1 Automatic centering and measuring system1 Tool break detector  ...

HAAS VF2SS VERTICAL MACHINING CENTER NEW Serial No.: 1166625 Year: 2020 Number of spindle hours: 1,000 hours Table Table dimensions: 914 x 356 mm Table weight: 680 kg Spindle Maximum spindle speed: 15,000RPM option Spindle taper: BT 40 Axes Axis travel: X=762 - Y=406 - Z=508 mm Fast feeds: X=35.6 - Y=35.6 - Z=35.6 m/min Tool magazine Tool changer: 30 tools Maximum tool weight: 5.4 Kg Equipped with 1 HAAS CNC 1 Spindle center coolant system 1 Chip conveyor Auction-ID: A1-50950-22

Manufacturer: SCM Model No.: Tech 99L Machine Type: CNC Machining Center Year of Make: 2000 Machine weight: approx. 2,600 kg Electrical connection: 400 V / 3 phases / 50 Hz / 35 A Working range X: 3,000 mm, expandable to 3,800 mm Working range Y: 979 mm drilling / 1,200 mm milling Max. panel thickness: 180 mm Vertical spindles: 10 Horizontal spindles: 1+1 in X / 1 in Y Spindle speed: 4,000 rpm Drilling unit: 2.2 kW Z-stroke: 200 mm Feed axes: X/Y/Z 67 / 67 / 22.5 m/min Milling unit: ISO 30, 6.6 kW Tool changer: 4-fold, for tools up to Ø 120 mm Grooving and sawing unit: Ø 200 mm, bore 30 mm, 2.2 kW, 6,000 rpm 6 workpiece supports: 1,030 mm Vacuum pump: 100 cbm/h Working range X: 3,800 mm with roller conveyor according to equipment 4 positioning aids for heavy workpieces Control: PC-NUM 1040 Additional features: 10. ...

USED FAMUP MMV 160-65 MACHINING CENTER Serial No.: M-165.027.07 Year: 2007 Spindle Spindle speed: 12000 rpm Spindle power: 35/22.5 kW Spindle taper: ISO 40 Axes Axis stroke: X=1600 - Y=650 - Z=600 mm Table Dimensions: 2000 x 650 mm Max. weight on the table: 2000 kg Tool magazine Tool changer: 30 tools Equipped with 1 FANUC 18i-MB CNC Coolant in the center 1 Chip conveyor Dimensions and weight Machine: 4300x2500xH3060mm - Conveyor: 5500x2050mm - 3 pallets: 900x2350mm - 1100x2500mm - 1300x2200mm - total weight: 14000 kg Auction-ID: A1-50950-14

USED SERRTECH M1 VERTICAL MACHINING CENTER Serial No.: M1.005.06 Year: 2006 Table Table dimensions: 1200 x 600 mm Spindle Spindle speed: 12,000 RPM Spindle taper: LV 40 Axes Axis stroke: X=1000 - Y=600 - Z=640 mm Tool magazine Tool changer: 30 tools Footprint Machine dimensions: 4450 x 2770 x H2450 mm Machine weight: 9,000 kg Equipped with 1 FANUC 18i-MB NC 1 HP pump 1 Chip conveyor Dimensions and weight 5000x2750xH2790mm - 1 pallet weight 9000 kg Auction-ID: A1-50950-69

DMG DMF 360-11 linearYear of manuf. : 2012 Control : Heidenhain iTNC 530 Speed : 18000 rpmMovement X/Y/Z : 3600/1100/900 mmTool holder : HSK 63 ____________Description:In General:Year of manufacture:2012Control system:Heidenhain iTNC 530Travel range X/Y/Z:3,600/1,100/900 mmSpeed:18,000 rpmTool holder:HSK 63Spindle:Technology:Motorised spindleSpeed:18,000 rpmMax. power:35 kWMax. torque:130 NmTool holder:HSK 63NC swivel head:B-axis:+/- 100°Resolution:0.001°NC rotary table:C-axis:360°Resolution:0.001°Clamping surface:1,050 mmMax. table load:1,200 kgFixed table:Clamping area:4,200 x 1,100 mmMax. table load:1,200 kg/mTool magazin:Technology:Chain magazineNumber of stations:60Tool changer:Double gripperMax. tool length:300 mmMax. tool diameter:80 (130) mmEquipment:Positioning sensors:Direct scalesX-Axis:Direct driveChip removal:Chip conveyorCoolant supply:Internal cooling system, 40  ...

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm Control: SIEMENS 840 D control: Powerline Shop Mill table surface area: ø 630 x 500 mm table swivelling +/-: 110/5 Grad spindle taper: SK 40 spindle turning speed - stepless: 20 - 10.000 U/min spindle drive: 13 kW max. torque on the spindle: 82 Nm feed speeds: max. 20.000 mm/min rapid traverse: 24 m/min no. of tools in magazin: 30 wotkpiece diameter with 2 vacant positions: max. 130 mm tool length - max.: 290 mm weight of tools max.: 6 kg total power requirement: 17 kVA weight of the machine ca.: 4,05 t dimensions of machine L x W x H: 2,21 x 2,12 x 2,15 m = 5-axis machining center (5 axis simultaneously) with 2-axis NC swivelling rotary table - only 9.609 spindle hours - - the machine was used for sample and prototype production, 3D machine model for kinematic simulation in a CAM programming system (available in IGES and STEP format ...

CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 1.200 Y-axis travel mm: 900 Z-axis travel mm: 500 Rapid traverse m/min: 30 Worktable Table dimensions mm: 1.400 × 900 Max. workpiece weight kg: 1.800 Maximum workpiece size (W x L x H ) mm: 1.400 × 900 x 240 Spindle Spindle speed rpm: 10.000 - 16.000 - 24.000 Spindle drive power kW: 32 Spindle torque Nm: 200 Tool system Tool holder: HSK-A63 Tool magazine slots: 30 Max. Tool Diameter: 125 Max. Tool Length mm: 300 Max tool weight kg: 4 Chip-to-chip time s: 6,5 Equipment Electronic Handwheel Chip conveyor Workarea light Cooling Tank capacity: 300 L Machine running times Under power: 103.179 Rated power kVA: 31 Operating Time: 23.273 Basic machine dimensions / weight Length mm: 4.000 Width mm: 3.000 Height mm: 2.800 Weight kg: 13.200

CHIRON MODEL FZ18W MAGNUM 4 axis Vertical machining center with rotopallet and double 4th axis 20 TOOLS ISO 40 Toolchange: 2.1 sec Spindle: 20 - 8000 RPM, 18,5k kW X = 625 Y = 400 Z = 400 Rapids 40m/min Table area: 2 x 900 x 470 - TSUDAKOMA heavy duty double 4th axis (Japan) 360.000 pos. - original HAWE hydraulic unit - FANUC 0M 1995 Can be inspected under power in our warehouse Mimu machine tools (Italy), X: 625, Y: 400, Z: 600, 4th axis: Yes, (2x) Tsudakoma 360 000 pos.

This 4-axis Okuma SPACE CENTER MA-500HA was manufactured in 2004. It features a spindle speed of 20,000 rpm and a tool magazine capacity of 40 tools, ensuring efficient machining operations. The machine is equipped with a BLUM laser tool measuring system and includes two-sided fixture blocks for versatility. If you are looking to get high-quality machining capabilities, consider the Okuma SPACE CENTER MA-500HA horizontal machining centre we have for sale. Contact us for further details.

This 3-axis DMG DECKEL MAHO DMU 105 V Linear was manufactured in 2004. It features a robust CNC control system, HEIDENHAIN iTNC 530, and has a machine weight of approximately 12,200 kg. The required installation space is 5,700 × 4,700 mm, making it suitable for various machining tasks. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMU 105 V Linear vertical machining centre we have for sale. Contact us for further details.

GROB G 350Year of manuf. : 2008 Control : Heidenhain iTNC 530 Speed : 18000 rpmMovement X/Y/Z : 600/770/805 mmTool holder : HSK 63 ____________Description:In General:Year of manufacture:2008Control system:Heidenhain iTNC 530X/Y/Z travel:600/770/805 mmSpindle speed:18,000Tool holder:HSK 63Spindle:Technology:Direct drive spindleSpeed:18,000 rpmPower:36 kWTorque:47 NmTool holder:HSK 63NC swivel t able:A-axis:240°B-axis:360°Pallet size:400 x 400 mmMax. table load:300 kgClearance:600 mmTool magazine:Technology:RadmagazinTool changer:Pick-UpNumber of stations:40Max. tool length:365 mmMax. tool diameter:72 (160) mmEquipment:Position Measurement Systems:Direct on all axes (glass scales)Automation:2-position pallet changerChip Removal:Chip conveyorCoolant Supply:Internal coolant systemWorkpiece Measurement:Probe preparationEmulsion Mist Separator:MechanicalSetup Mode:Electronic handwheel

x-travel:800 mm y-travel:410 mm z-travel:510 mm control:Fanuc 10 MA rapid travel x/y/z:20/20/15 mm/min table surface area:1100 x 450 mm tool taper:BT 40 tool magazin::30 BT 40 max. tool length:250 mm max. tool weight:8 kg power requirement:7,5/5,5 kW turning speed range:6000 1/min weight of the machine ca.:6,3 t Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup"

x-travel:1100 mm y-travel:600 mm z-travel:510 mm control:Heidenhain iTNC 530 table-size:1050 x 600 mm table load:500 kg spindle taper:SK 40 turning speeds:10000 1/min power capacity at 100 % load:9 kW rapid travel x/y/z:24 m/min feed:24 m/min Tool changer:40 SK 40 dimensions of the machine ca.:4,3 x 2,6 x 2,25 m weight of the machine ca.:8,8 t POS mill 1100 vertical machining center in very good condition from 2009 Options: - parts measuring M&H receiver without probe - external hand wheel Heidenhain HR 410 - Air supply through spindle - air gun - paperfilter system with coolant through spindle 40 bar -

x-travel:1400 mm y-travel:1200 mm z-travel:1350 mm control:MSX- 701 Mapps III table surface area:800 x 800 mm rapid traverse:50 m/min table rotating:360.000 x 0,001 B-Achse ° table load:2,0 t numbers of pallets:2 turning speed range:8000 1/min power capacity - milling spindle:37 kW no. of tools in the magazine:60 Stück tool taper:HSK-A 100 weight:31 t dimensions:5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis

x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,

x-travel:630 mm y-travel:630 mm z-travel:630 mm control:Unipro 90 Pallet changer 2x:400 x 500 workpiece - installed height:800 mm max. clampable workpiece diameter:720 - 850 mm spindle taper::SK 40 spindle turning speed - stepless:10 - 8000 1/min Spindle power:20 / 30 kW Spindle Torque:95/143 Nm tool magazin::80 SK 40 total power requirement:55 kW weight of the machine ca.:11 t Machine with Unipro 90 control for 5 axis - twin palette changer - tool magazine 80 HSK-A 63 - coolant device with coolant through spindle 7 pressure levels - full A & B-axis - chip conveyor

x-travel:630 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:6,5 t Number of axles:5 St. spindle turning speed range:18.000 U/min numbers of tools in magazin:24 tool taper:SK 40 Round Table B-Axis

x-travel:800 mm y-travel:400 mm z-travel:350 mm total power requirement:44 kW weight of the machine ca.:8,8 t dimensions of the machine ca.:6,1 x 4,1 x 3,3 m tool taper:HSK63 number of spindle speeds:36-12.000 Number of tools:2 x 21 St. rotary table diameter:1340 mm

x-travel:600 mm y-travel:770 mm z-travel:675 mm A-Axis travel:-180 ... +45 ° b-axis:360,000 ° spindle drive:40 / 52 (100% / 40% ED) kW spindle turning speed range:10000 U/min Tool bore:HSK-A63 numbers of tools in magazin:40 total power requirement:47 kW weight of the machine ca.:13 t including additional tool magazine ZM 182 1 spindle , 5 axes

x-travel:630 mm y-travel:630 mm z-travel:500 mm number of spindle speeds:0 - 15000 spindle motor:32 kW size of pallet:500 x 500 mm b-axis:36000 x 0,001 ° no. of workpieces in the magazine:61 Stück tool taper:HSK 63 weight of the machine ca.:15 t Single-Spindle Mechanical processing cylinder head VR6

x-travel:1000 mm y-travel:800 mm z-travel:1100 mm weight of the machine ca.:20 t dimensions of the machine ca.:6,80 x 3,0 x 3,20 m Tool bore:SK50 Tool taper:HSK-A 100 turning speed range:45-6.000 U/min size of pallet:630x800 mm change time of pallets:21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to

x-travel:1000 mm y-travel:800 mm z-travel:1100 mm weight of the machine ca.:15,2 t Tool bore:SK50 Tool taper:HSK-A 100 turning speed range:45-6.000 U/min size of pallet:630x800 mm change time of pallets:21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to

spindle speed::max. 12000 tool taper:HSK 80 . b-axis:360 x 0,001 ° worktool support (A-axis):+40 / -95 ° weight of the machine ca.:25 500 Kgs. x-travel:800 mm y-travel:700 mm z-travel:630 mm dimensions of the machine ca.:6200 x 3000 x 3200 mm pallet size::500 x 500 mm no. of tools in the magazine:61 Nos. Weight approx.:23,5 t Horizontal Machining Center with CNC Control System SIEMENS 840 C in well maintained condition. Single spindle

x-travel:800 mm y-travel:950 mm z-travel:1020 mm weight of the machine ca.:17 t dimensions of the machine ca.:6 x 3 x 3,2 m Diameter of the table:770 mm max. table load:800 kg tool taper:HSK-A63 max. tool length:465 mm no. of tools in magazin:60 spindle turning speed range:12.000 U/min feed power:8 kN kp power capacity:25/35 kW 5 axis G550-1024 HSK A-63 Grob (Bezeichnung G550-1024) 1 spindle

x-travel:780 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:10 t Number of axles:5 St. spindle turning speed range:20-12.000 U/min numbers of tools in magazin:30 tool taper:SK 40 surface area:500 x 630 mm Round Table B-Axis Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2026, Josef Weber. All rights reserved.

x-travel:700 mm y-travel:630 mm z-travel:700 mm weight of the machine ca.:15 t dimensions of the machine ca.:4,20 x 2,90 x 2,90 m pallet size::500 x 500 mm tool taper:SK 40 Tool taper:HSK-A 63 turning speed range:10.000 U/min

x-travel:2000 mm y-travel:1600 mm z-travel:1140 mm b-axis:0.0001° x 360° ° number of pallets:4 table surface area:1000 x 1450 mm max. table load:6.000 kg turning speed range:4 - 10000 U/min power capacity at 100 % load:40 kW kW tool taper:HSK100 DIN69893A machine weight ab.:63.000 kg space required L x W X H:12320 x 11000 x 4700 mm incl. 50 x HSK100 tool tapers

x-travel:760 mm y-travel:760 mm z-travel:760 mm b-axis:360.000 x 0.001 ° spindle drive:26 / 18,5 (40% / 100%) kW spindle turning speed range:50 - 15000 U/min Tool bore:KSK-A63 max. table loading capacity:500 kg total power requirement:43 kW weight of the machine ca.:11,5 t dimensions of the machine ca.:2,7 x 4,73 x 2,87 m

x-travel:450 mm y-travel:450 mm z-travel:450 mm b-axis:360.000 x 0.001 ° main spindle speeds::45-10000 1/min weight of the machine ca.:14 t dimensions of the machine ca.:7 x 2.45 x 3.4 m size of pallet:320 x 320 mm number of spindles:2 tool taper:HSK63 tool numbers:2 x 40 spindle drive motor:25/36 (100% / 40% ED) kW Double spindle 4-axis machining center Horizontal 4 machine plates Renishaw probe Control Siemens Sinumerik 840D Working space (X / Y / Z): 450x450x450 mm Load pallet / table max .: 300 kg Acceleration: 10 m / s² Rapid traverse: 60 m / min Pallet size: 320 x 320 mm Chip-to-chip time: 2.6 s Workpiece height max .: 700 mm Tool holder: HSK 63 Tool places: 2x 60 Tool spindle: 10,000 rpm, 95 Nm Speed increase to 18,000 rpm Infrared receiver for probe, Make Renishaw Vaf72a0p Tool magazine with 60 places Control panel on the workstation Control panel on the tool installation site  ...

x-travel:800/945 mm y-travel:800 mm z-travel:600 mm spindle motor:27 kW spindle turning speed range:10 - 8000 U/min spindle taper ISO:40 c-axis:360.000 x 0,001 table load capacity:600 kg table clamping surface::800 630 mm total power requirement:55 kW weight of the machine ca.:16 t Machine with Heidenhain iTNC 530 CNC control for 5 axis - pendulum operation with turn- swivil table left and fixed table right - tool changer for 30 tools - coolant device, chip conveyor - complete splash housing

x-travel:635 mm y-travel:510 mm z-travel:460 mm turning speed range:20 - 10.000 U/min tool taper:SK 40 table clamping surface LxW:790 x 560 mm Machine with glass scales Full safety cabin with sliding doors + interior lighting Height-adjustable machine shoes 3 pcs.

travel -x axis:800/1825 mm travel -y axis:800/460 mm travel -z axis:600 mm Feeding X,Y,Z up to:0 - 40/40/40 mm/min. swival range +/-:+10 bis -90 x 360 Grad Rotary-table:800 x 630 mm number of T-slots:5 T-slot - distance:125 mm T-Slots:18 mm center hole:30H7X15 mm swival range +/-:90 Grad turning speed:20 m/min. Number of axles:3-7 St. Spindle RPM:12.000 1/min max. tool weight:10 kg max. tool length:330 mm diameter of tools max.:80 mm tool changing time:4 sec CNC control with 15.1" color flat-screen 19" machine control panel PCU 50 with Intel Pentium II Windows XP 10.0 GB hard drive

x-travel:1.250 mm y-travel:880 mm z-travel:800 mm spindle turning speed range:1 - 10.000 U/min high speed spindle taper ISO:50 table-size:1.250 x 1.000 mm max. workpiece weight: 2.000 kg feed speeds infinitely variable:1 - 30.000 mm/min rapid traverse speed:40 m/min weight of the machine ca.:16 t dimensions of the machine ca.:7,2 x 4,4 x 2,9 m

x-travel:3500 mm y-travel:2500 mm z-travel:1250 mm weight of the machine ca.:50 t JOBS JO?MACH 241 ? CNC gantry machining centre The JOBS JO?MACH 241 is a high-performance CNC gantry machining centre designed for the precise machining of large, heavy and complex workpieces. The robust design, featuring a fixed gantry and a movable worktable, ensures high rigidity and stable machining conditions. With travel ranges of 3,500 mm on the X-axis, 2,500 mm on the Y-axis and 1,250 mm on the Z-axis, the machine offers a generous working area. The clearance between the columns is approximately 2,200 mm. The worktable, measuring approximately 3,000 × 1,500 mm, is designed to accommodate workpieces weighing up to 12,000 kg. The two-axis, swivelling milling head enables the machining of complex contours and hard-to-reach surfaces in multiple spatial directions. This makes the JO?MACH 241 particularl ...

distance spindle /table:min /max 190 / 570 mm distance spindle /table:190 - 570 mm surface area:650 x 300 mm Boring power:in GG 20 40 mm bore capacity in steel:ST 60 32 mm turning speed range::50 - 5000 UpM total power requirement:2,2 kW threading:GG 20 M30 threading::ST 60 M 24 weight of the machine ca.:1400 kg table load:max. 150 kg table height:770 mm traversing speed:max X-, Y- u. W-Achse 5 m/min max. traversing speed:Z-Achse 3 m/min w-axis:380 mm workpiece height max.:495 mm tool changing time:ca. 3 sec x-travel:450 mm y-travel:300 mm z-travel:180 mm workpiece weight:1,5 kg

x-travel:800 mm y-travel:690 mm z-travel:630 mm total power requirement:76 kW weight of the machine ca.:25,5 t b-axis:630 Rundeinheit control:Siemens 840 D workpiece weight:max . 1.100 kg spindle turning speed range:15000 U/min Boring power:30 mm plate size:630 x 630 mm Dimension:6000 x 2900 x 2400 mm spindle taper::HSK 63 Documents:vorhanden

x-travel:550 mm y-travel:300 mm z-travel:425 mm CNC-control:Sinumerik table-size:950 x 350 mm max. table load:500 kg spindle taper ISO:30 spindle turning speed range:20 - 10500 U/min spindle drive motor:5,5 kW tool change unit:12 Pos. coolant:inkl. voltage:380 V tool adaptor:Steilkegel 40 groove width:32/28 mm no. of flutes:3 rapid speed:40.000 mm/min total power requirement:15 kVA weight of the machine ca.:3,3 t chip conveyor:inkl. dimensions of the machine ca.:2000x 3000 x2500 mm Documents:vorhanden - Serial Number: 186 - 78 - Control: FANUC O-M - with various tool holders - coolant equipment

x-travel:2500 mm y-travel:1000 mm z-travel:750 mm table surface area:3220 x 1000 mm Workpiece weight approx.:3000 kg spindle taper ISO:50 milling spindle turning speeds:20 - 5000 U/min feed speeds:1- 30000 mm/min rapid traverse:30 m/min total power requirement:40 kW dimensions of the machine ca.:6,9 x 4,1 x 3,7 m weight of the machine ca.:21 t with CNC HEIDENHAIN TNC 426 30-pockets autom. toolchanger RENISHAW measuring probe coolant attachment with TSC and chip conveyor diverse toolholders

x-travel:600 mm y-travel:580 mm z-travel:580 mm numbers of pallets:2 pallet size::400 x 400 mm max. workpiece weight:400 kg spindle taper ISO:40 spindle speeds::35 - 12000 feed speeds:1 - 50000 mm/min rapid speed:50 m/min total power requirement:25 kW weight of the machine ca.:12 t dimensions of the machine ca.:3,6 x 3,6 x 2,9 m with CNC SEICOS 16 M ( FANUC base ) autom. toolchanger 61-pockets pallet indexing 1° chip conveyor and coolant attachment exhauster clamping cube and diverse toolholders

x-travel:1250 mm y-travel:880 mm z-travel:800 mm spindle turning speed range:1 - 10.000 U/min spindle taper ISO:50 table-size:1250 x 1000 mm max. workpiece weight:2000 kg feed speeds infinitely variable:1 - 30.000 mm/min rapid speed:40 m/min weight of the machine ca.:16 t dimensions of the machine ca.:7,2 4,4 x 2,9 m 5-axes Machining Center with CNC SIEMENS 840 D A-axis 0,001°, C-axis 0,001° autom. toolchanger30-pockets NC table through spindle coolant 40 Bar , chip conveyor

x-travel:1800 mm y-travel:1600 mm z-travel:1400 mm B-axis (table):360° size of pallet:1000 x 1250 mm workpiece swing dia.:2100 mm workpiece weight:3500 kg spindle taper ISO:50 spindle drive motor:37 kW spindle turning speed range:25 - 10000 U/min feed range:40/50 m/min rapid power traverse circular:10 U/min total power requirement:90 kVA weight of the machine ca.:43 t dimensions of the machine ca.:11 x 9 x 4,5 m Machine with SIemens 840 D control for 4 axis - full B-axis - palette changer - tool changer for 150 tools - coolant device with coolant through spindle - chip conveyor
