machining centers used for sale

Fanuc + 3 Breton machining centers

Boring power:10 mm weight:590 kg connected load:2 kW dimensions::1500 x 1300 x 2300 mm

Manufacturer: Biesse Model: C6.50 WMS Year of Manufacture: 2009 Type of Machine: Machining center with automatic loading Working Field: - X-axis: 6400 mm - Y-axis: 1650 mm - Z-axis: 350 mm Drilling Head: - Vertical spindles: 16 - Horizontal spindles: 6 (X and Y directions) - Integrated grooving saw on X-axis Electrospindle: - 1x HSK F63, 13.2 kW, air-cooled - 0–24,000 RPM Tool Changer: - Rotary 16-position tool changer Worktable: - ATS (Advanced Table Setting) with manual positioning pods and rails Control System: - NC 500 / XP600 with BiesseWorks software Safety: - Full perimeter safety bumpers with sensors Vacuum System: - High-capacity vacuum pump for strong hold-down Find more here - .ucymachines/ Contact us at - sales@ucymachines

Manufacturer: WEEKE Model: OPTIMAT BHT 500 Year of Manufacture: 2009 Technical Specifications: - Voltage: 400 V - Frequency: 50/60 Hz - Phases: 3 + N (three-phase with neutral) - Power Consumption: 45 kW - Current Rating: 100 A - Control Voltage: 24 V Find more here - .ucymachines/ Contact us at - sales@ucymachines

Type: XCEEDER 900/RT Een hoogwaardig multitasking bewerkingscentrum met 5 geïnterpoleerde assen. Ontworpen voor de hoogste prestaties bij het bewerken van 3D-vormen die draaien, frezen, boren en slijpen vereisen. Speciaal afgestemd op toepassingen variërend van complexe tandwielen en waaiers tot mallen, matrijzen en gereedschappen, voor projecten in de lucht- en ruimtevaart, automotive en energieopwekking. maximale werkstukdiameter: 900 mm A-as: -30° / 110° C-as: continu: 100 RPM maximale afstand tussen spindel en tafel: 700 mm Opties gemonteerd op de machine: 1 - hogesnelheidsspindel van 40.000 tpm 2 - tafel met diameter 700 mm 3 - gereedschapswisselaar met 150 posities 4 - spaantransportband 5 - koelsysteem met recuperatie 6 - temperatuurregeling voor koelmiddel 7 - hoge druk koeling (40 tot 70 bar) door spindel 8 - rookafzuigsysteem 9 - chipverzamelbox 10 - Voorinstelling syste ...

Freesrobot Staubli RX170HM Deze robot is voorzien van gaten om te frezen in mallen van banden, maar ook in andere zaken is dit mogelijk. Koeling door de spindel en de koelmelk is luchtgekoeld. Smering Gebeurde met vet. spindelopname: HSK E 32 Werd gebruikt in Tire Mold fabriek Mecamold Herstal. Max weight on the table: 300 kg Admission in spindle (ISO): HSK E 32 Power on the spindle: 8 kW Drilling-capacity: 80 mm Tapping-capacity: 80 mm Control : Fanuc Number of axes: 6 Toolchanger: nee Number of toolholders: nee Number of rotations: 500 - 20 000 rpm Power principal motor : 5 kW

Paletchanger 2 tafels Hoge druk koeling 15 bar Schroottransportband Maximale werkstukafmetingen: 3240 x 880 x 640 mm X-axis: 3000 mm Y-axis: 800 mm Z-axis: 585 mm Table dimensions: 3240 x 750 mm Max weight on the table: 3 ton Passage between uprights: 860 mm Admission in spindle (ISO): ISO 50 Power on the spindle: 30 kW Control : Mazatrol 640 Toolchanger: yes Number of toolholders: 40 positions Number of rotations: max 6000 rpm Number of pallets: (2x) 750 x 3240 mm Length: 3274 mm Depth: 8100 mm Height: 3546 mm Weight: 19 ton

A complete machining line consisting of four Toyoda machining centers, Palltec transport and automation system, filter systems, chip conveyors and coolant supply systems is available. 1) 4x CNC horizontal machining center Toyoda FH 630 SX, year of manufacture 3/1: 2007/2008, control: Fanuc 31i, pallet dimensions X/Y: 630mm/630mm, travel X/Y/Z: approx. 1050mm/900mm/1050mm, max. workpiece diameter: 1170mm, max. workpiece height: 1250mm, max. pallet load: 1500kg, spindle taper: BT50, speed: 6000rpm, tool magazine: Fanuc FTS 330, tool positions: 330, operating hours range: approx. 65000h-76000h. All machining centers have the same tool management, but different operating hours within the above-mentioned range. 2) Rail-guided-vehicle system RGV Palltec FPA 630, year of manufacture: 2006. 3) Master computer system with Windows 7 Professional, interfaces: CNC/RGV/peripherals. The production lin ...

Manufacturer: Weeke Model: Optimat BHC Venture 1 Year of Manufacture: 2006 Operating Hours: 20000h Electrical: - Power Supply: 400V / 50 Hz / 3-phase + N - Total Power: 18 kW - Current: 35 A - Control Voltage: 24V Find more here - .ucymachines/ Contact us at - sales@ucymachines

hogedrukkoeling via de spindel spanentransporteur X-axis: 1660 mm Y-axis: 510 mm Z-axis: 510 mm Table dimensions: 2000 x 510 mm Max weight on the table: 1000 kg Admission in spindle (ISO): BT-40 Power on the spindle: 18,5 kW Control : Mazatrol 640M Toolchanger: yes Number of toolholders: 30 positions Number of rotations: 12 000 rpm Weight: 8250 kg

Maximale afmetingen van het werkstuk: 800 x 1000 mm tabelindexering elke 0,001° afstand van palletcentrum tot spindelneus: 70 gt; 810 mm afstand van palletoppervlak tot spindelcentrum: 100 gt; 830 mm Hogedrukkoeling via de spindel (70 bar) Uitgerust met Palletech High Rise System = uitbreidbare palletopslag met 2 niveaus voor 12 pallets. spanentransporteur X-axes: 730 mm Y-axes: 730 mm Z-axes: 740 mm Table dimensions: 500 x 500 mm (2x) Max weight on the table: 700 kg Admission in spindle (ISO): BT40 Power on the spindle: 30 kW Toolstore: yes Tools: 160 positions Frequency : 18000 rpm Number of pallets : 12 pallets Length: 9000 mm Depth: 8000 mm Height: 2850 mm Weight: 12,4 ton

UNIT 1 - Weeke Profiline ABL 210 - Manufacturer: Weeke - Model/Type: Profiline ABL 210 - Year of manufacture: 2007 - Made in Germany - Power: 17 KW - Voltage: 400 V - Frequency: 50 Hz, 3 phase + N - Current: 35 A - Control voltage: 24 V UNIT 2 - Ligmatech MDE 110 loading system - Manufacturer: Ligmatech - Model/Type: MDE 110/28/08 - Year of manufacture: 2007 - Made in Germany - Voltage: 400 V - Frequency: 50 Hz, 3 phase + N - Current: 12 A - Fuse: 25 A - Control voltage: 24 V - Max pressure: 10 bar - Air consumption: 8 Nm3/h - Weight: 6500 kg UNIT 3 - Ligmatech control system - Manufacturer: Ligmatech - Model/Type: Steuerung - Year of manufacture: 2007 - Made in Germany - Voltage: 400 V - Frequency: 50 Hz, 3 phase + N - Current: 8 A - Fuse: 16 A - Control voltage: 24 V Find more here - .ucymachines/ Contact us at - sales@ucymachines

200623,792 h11 mapprox. 12,100 mmapprox. 2,350 mmapprox. 800 mm+/- 98°Rotary axis45 m/min24 m/min10,000 mm/minWater-cooled, rated power 20 kW from 12,000 rpm, integrated swivel and rotary axis, left/right rotationInfinitely variable up to 24,000 rpmBWO 930, in mobile control desk34 kW400 V / 50 Hz24 V80 A5 bar100 barTravelling gantry design with drive on both sides (gantry drive)HydraulicFor aluminium sheets / plates10 support traverses, 4 hydraulically swivelling workpiece stops, NC support-traverse positioningCoolant spray system with minimum-quantity mistingNC data format; 3D data converted via STEP files and CAD/CAM software08.12.20222019-2023: milling motor and Z-axis ball screw replaced; hollow shaft drive incl. brake replaced; safety screens renewed; harmonic drive replaced; Z-axis motor replaced; water recooling unit renewed; new oil mist extraction; controller assembly and X/U- ...

HERMLE C 42 U 5-axis CNC machining center equipped with an automated cell with robotic palletizer and large tool magazine, intended for intensive industrial production. This configuration allows: Automated Manufacturing Without Operator Serial or continuous production (24/7) Reduced parts changeover times Productivity Optimization Ideal machine for: Advanced CNC Workshops Industrial production Mechanical subcontracting demanding sectors: medical, aeronautics, watchmaking, precision mechanics The presence of the robotic system and the high-capacity magazine represents a major added value compared to a standard machine. Auction-ID: A1-48554-1

TOYODA FH400J horizontal CNC machining center equipped with a 58-position tool magazine, ideal for industrial production and machining of complex parts. Thanks to its high-capacity magazine, this machine allows: Automatic sequence of many operations Reduced machine downtime series production with long cycles High machining flexibility Coupled with its turntable and multi-piece clamping system, this horizontal center offers high productivity and optimal precision. Machine perfectly suited for: CNC machine shops Industrial production Precision mechanics Subcontracting Automotive, energy, general mechanical engineering sectors TOYODA centers are known for their robustness, rigidity and reliability in continuous production. Auction-ID: A1-48554-8

Tool changer 30+1 pieces. Includes chest of drawers with necessities. Auction-ID: A1-49659-7

Hermle C800U X: 800 - Y: 600 - Z:500 mm CNC X-axis: 800 mm Y-axis: 600 mm Z-axis: 500 mm Table dimensions: 800 x 700 mm Admission in spindle (ISO): SK40 Power on the spindle: 23 kW Control : Heidenhain iTNC 530 Number of axes: 5 axis Toolchanger: yes Number of toolholders: 30 tools Number of rotations: 10 0000 rpm Power principal motor : 31 kVa Weight: 9 ton

Hermle C30U X: 650 - Y: 600 - Z: 500 mm CNC X-axis: 650 mm Y-axis: 600 mm Z-axis: 500 mm Table dimensions: Ø 630 mm Admission in spindle (ISO): SK40 Power on the spindle: 26 kW Control : Heidenhain iTNC 530 Number of axes: 5 axis Toolchanger: yes Number of rotations: 18 000 rpm Length: 3500 mm Depth: 2480 mm Height: 2950 mm Weight: 9,5 ton ACCESSORIES: yes

Type: UMC-750 5-assige verticale bewerking X-axis: 762 mm Y-axis: 508 mm Z-axis: 508 mm Table dimensions: Ø 630 mm Admission in spindle (ISO): BT40 Power on the spindle: 22,4 kW Control : Haas Number of axes: 5 axis Toolchanger: yes Number of toolholders: 40 positions Number of rotations: 8100 rpm (122 Nm) Weight: 6 ton

Type: EC-1600ZT voor het bewerken van grote onderdelen met geïntegreerde draaitafel met 4e as Tafeldiameter: 760 mm X-axes: 1626 mm Y-axes: 1270 mm Z-axes: 1016 mm Table dimensions: 1626 x 914 mm Max weight on the table: 4536 kg Admission in spindle (ISO): BT50 Power on the spindle: 22,4 kW Control: Haas Toolstore: yes Tools: 50 positions Frequency : 7500 rpm (460Nm) Length: 3378 mm Depth: 4928 mm Height: 4674 mm Weight: 14 ton ACCESSORIES: yes

Type: EC-1600ZT voor het bewerken van grote onderdelen met geïntegreerde draaitafel met 4e as Tafeldiameter: 760 mm X-axes: 1626 mm Y-axes: 1270 mm Z-axes: 1016 mm Table dimensions: 1626 x 914 mm Max weight on the table: 4536 kg Admission in spindle (ISO): BT50 Power on the spindle: 22,4 kW Control: Haas Toolstore: yes Tools: 50 positions Frequency : 7500 rpm (460Nm) Length: 3378 mm Depth: 4928 mm Height: 4674 mm Weight: 14 ton ACCESSORIES: yes

x-travel:600 mm y-travel:580 mm z-travel:530 mm distance spindle center to column:630 mm distance spindle center to table:100-600 mm milling feed range:1-10.000 mm/min max. table load:200/100 kg max. tool weight:8 kg positioning accuracy:+/- 0,01 mm :8000/15000 1/min spindle drive:7,5/11,5 /5,5 kW repeating accuracy:+/- 0,008 mm weight of the machine ca.:7,4 / 7,65 t Brand-new CNC vertical machining center with CNC control FANUC or HEIDENHAIN Warranty: 12 months More information can be found in the Appendix.

x-travel:1000 mm y-travel:1150 mm z-travel:700 mm table-size:900 mm table load:1500 kg spindle speeds:10.000 1/min spindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nm spindle taper:A100 HSK T-slots:18mm/7/100 mm milling feed range:20.000 mm/min rapid traverse feeds:X/Y/Z: 24 m/min diameter of tools max.:150 mm workpiece length:300 mm weight of tools max.:20 kg weight of the machine ca.:15 t dimensions of the machine ca.:s. Katalog m CNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fach Scales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20

x-travel:1660 mm y-travel:760 mm z-travel:660 mm weight of the machine ca.:8700 t dimensions of the machine ca.:4.320 x 3.380 mm distance spindlenose - table min./max.:808 mm distance work spindle /surface of the table:155 - 815 mm Machine height:2850 mm floor space required (w/o switchgear cabinet):4.320 x 3.380 mm spindle motor:11 (10 Minuten) /7,5 (30 Minuten)/ 5,5 (Dauerbetrieb) kW tool taper:SK 40 Spindle RPM:40 - 7.000 (Standard ) / 40 - 10.000 ( Option ) 1/min surface area:2.000 x 760 mm max. table load:1.000 kg feeds X-axis:1 - 5.000 mm/min rapid traverse X-axis:24.000 m/min rapid traverse Y-axis:24.000 feeds Y-axis:1 - 5.000 mm/min feeds Z-axis:1 - 5.000 mm/min rapid traverse Z-axis:20.000 m/min

Table clamping surface: 2 x 350 x 300 mm traverse path x/y/z: 700/300/250 mm spindle retainer: BT 30 ISA kl. / gr. Table/spindle distance: 450 mm spindle speeds: 6-6000 rpm number of tool stations: 10 pieces feeds: 5-10000 mm / min rapid traverse: x & y/z 25/20 m / min spindle drive: 3,1/4,1 kW Electr. Supply: 400 V kW weight: 2600 kg

5 axis machininng center (milling/turning from bar) multitasking Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 ? 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min ...

STAMA Mod. MC 2 1997-325S pallet (Pendeltisch Peiseler ATK 520) Aufspannflaeche Pallet: 2 x 550 mm x 330 mm Max Werkstueckgewicht: 2x180kgs X = Y = Z 500 300 = 350 mm Min/Max Distance Spindelnase-Tisch: 200-550 mm rapid traverse X, Y, Z = 40/40/45 36 40 36 Werkzeuge ISO-9000 RPM Spindle IKZ CNC SIEMENS 840 c # 2 LEHMANN doppel 4. Achsen IKZ Unter Strom in unserem Lager It machined \\input shafts\\ (car power steering component) Special price for quick removal

Weight: approx.4500 KG mash. No.: 6517991 General/technical data: Vertical CNC machining center in a very good, almost new condition, first-hand with very little operating hours. Travel: X= 670 Y=450 Z=470 mm Rapid response: in X and Y = 24m/min, in Z =20m/min Spindle motor: 10 KW Spindle speed: from 50 to 4,500 rpm Spindle cone: SK 40 Control: Siemens 810 M GA 2 Dimensions clamping table: 900 x 420mm max table load: 300 kg Distance spindle head to top of the table: 630mm spindle center to stand face: 470mm Tool slots in the magazine: 24 pieces DIN ISO 40 max. tool diameter: 110mm to 125mm tool length 100mm to 280mm tool length Beuvvquh2i Dimensions of the machine approx.: 2200 x 3000 x 2950 mm (without operator, service and chip conveyor environment) Accessories/ Optional equipment: â?¢ external coolant system with 2 pumps â?¢ Chip conveyor with ...

ertikal machining center, used, from location vertical machining center, used, Model/ model: VS 500 SPEED Fabr./ make: NORTE Year built/ year: 1999 Control/ control: SIEMENS 840D x-Way /x-travel 2000 mm y-way / y-travel 500 mm z-way / z-travel 500 mm Feed: 1 - 8000 mm/min Table size / table-size 2120 x 550 mm Table load / table load 2000 kp Rapid gear X-axis / rapid traverse X-axis 40 m/min Rapid gear Z-axis/ rapid traverse Z-axis 20 m/min Tool holder / tool taper HSK 63 A Spindle speeds - infinitely variable/ spindle turning speed 0 - 15000 rpm Spindle drive/spindle motor 20 kW Spindle bearing diameter / spindle bearing diam. 70 mm Position accuracy / position accuracy: 0.020 mm Control SIEMENS 840D Tool diameter: 63 / 126 mm Tool Magazine: Chain Magazine/ toolpiece magazine: 40 pieces Total power requirementm.65 kVA Machine w ...

Technical details x-travel 600 mm y-travel 560 mm z-travel 510 mm Steuerung Siemens Slim Line Multi Touch Control Main spindle: Max. speed 15,000 rpm/-1 Drive power - main spindle 20 / 14.5 kW Max. torque 121 / 84 Nm Tool holder SK 40 Distance between spindle nose and table 120 - 630 mm Workbench: Table clamping area 900 x 560 mm max. table load 600 kg T-slots 5 Working height 850 mm Tool magazine: Number of tool positions 60 pos. Tool holder SK 40 max. tool diameter 80 mm max. tool diameter. with a free neighboring box. 130 mm max. tool length 300 mm max. tool weight 8.0 kg Tool-tool changeover time 2.4 sec Changeover time chip - chip 6.7 sec Feeds: Rapid traverse 30 m/min Feed force 5 kN Feed speed max. 30,000 mm/min Total power requirement 32 kVA Machine weight approx. 5.0 t Space requirements approx. 4.0 x 5.0 x 3.0 m

With Indumatik Automation x-travel 500mm Y travel 450mm z-travel 400mm Control Siemens 810 D Shopmill Main spindle: Speed Range - Main Spindle ((( 20 - 8,000 )))min/-1 Drive power - main spindle 13 / 9kW Tool holder SK 40 Max. torque 83Nm NC rotary table: Table clamping area 630 x 500mm Max. table load 200kg Swivel range -5 / +110° Rotation range 0.001° T-slots 7x 14 x 63mm Tool magazine: Number of tool locations 16pos. max. tool weight 6kg max. tool diameter 80mm max. tool diameter. with a free neighboring box. 130mm max. workpiece length 300mm Feeds: Rapid traverse 12m/min Feed force 4.5kN Feed speed 1 - 12,000mm/min Total power requirement 18kW Machine weight approx. 5.0t Space requirements approx. 4.5 x 3.5 x 2.3m

FZ15KS HIGH SPEED 4 axis vertical machining center X: 550mm Y: 400mm Z: 360mm 4th axis original Peiseler CNC Siemens 840D Table surface 1050 x 450mm Toolchanger 48 posts ISO 40 Spindle speeds up to 12000 1/min with 4th axis Renishaw broken tool detector Coolant through spindle swarf conveyor Can be inspected under power in our warehouse. Mimu machine tools (Italy)

CONTROL .. CNC Control HEIDENHAIN TNC426 WORKSPACE -CUBIC- .. Number of machining axes (without parallel axes): 3 .. X-axis travel: 500 mm .. Y-axis travel: 400 mm .. Travel Z-axis: 400 mm TABLE .. Clamping surface (left-right): 700 mm .. Clamping surface (front-rear): 500 mm SPINDLE / HEAD .. Speed range up to: 9000 rpm .. Tool holder: ISO SK 40 TOOL MAGAZINE .. Number of tool positions: 16 ELECTRICAL CONNECTION DATA .. Connection voltage: 400 V .. Mains frequency: 50 Hz DIMENSIONS / WEIGHTS Bsicvzmv7Vm .. Space requirement -left/right-: 5000 mm .. Space requirement -front/rear-: 3700 mm .. Total height: 2500 mm .. Total weight approx.: 4500 kg

Table size: 1000 x 490 mm traverse path x/y/z: 800/510/500 mm spindle retainer: ISO 40 ISA kl. / gr. Table/spindle distance: 120/620 mm spindle speeds: 40-6000 rpm number of tool stations: 22 pieces feeds: x/y 1-3200 / z 1-2000 mm / min rapid traverse: x/y 1-3.2, z 1-2 m / min. Supply: 380 V, 19 kW space: 2850 x 2150 x 2600 mm weight: 3800 kg

This 3-axis EMCO EmcoMill E900 was manufactured in 2018. The vertical machining center is equipped with a Siemens 828D control system and offers a spindle speed of up to 12,000 rpm and a torque of 83 Nm. It has a travel of X 900mm, Y 500mm, Z 500mm and a rapid traverse speed of 24m/min. The machine has a 360l coolant pan and a 20-cavity tool magazine. If you are looking for a high-quality milling machine, you should consider the EMCO EmcoMill E900 machine that we have for sale. Contact us for more information. Brand: SIEMENS Model: 828 D Spindle Speed Range: 50-12000 Number of axes: 3 X-axis travel: 900 mm X-axis rapid traverse: 24 m/min Y-axis travel: 500 mm Rapid traverse Y-axis: 24 m/min Z-axis travel: 500 mm Rapid traverse Z-axis: 24 m/min Outer length: 1000 mm Outer width: 520 mm Minimum distance between vertical spindle and table: 100 mm Maximum distance between ver ...

Technical data: -Drilling capacity in steel ST 60 25 mm -Spindle mount MT 3 8 spindle speed 100 2700 RPM - spindle stroke 130 mm -4 feeds 0.1-0.3 m / U -RADIUS 270 mm -Column diameter 115 mm -Boring Unit + table height adjustable with hand crank on rack -Table dimensions 350 mm -Drive: 400 V / 0.8 / 1.1 kW -Space requirement approx. B H 800 x 1850 X 900 mm -Weight approx. 250 kg

Table size 2400 x 810 mm Feed speed 1 - 10000 mm/min Headstock travel 810 mm (Z-axis) Height of the machine 4000 mm Pull bolts MAS 403-P40T-I Table longitudinal displacement 2000 mm (X-axis) Table Transverse Displacement 810 mm (Y-axis) Spindle front face to table top 100 - 910 mm Distance from the floor to the table 1200 mm Distance between spindle center and column front 825 mm T - Slot No. 5 T - Slot Size 18 mm T - Slot Pitch 150 Max. load on the table 2500 kg Spindle cone BT-40 Hourly spindle speed 6000 rpm Footprint (L x W) 5400 x 3450 mm Weight of the basic machine 17000 kg Total connected load 50 kVA (basic standard machine), 60 kVA (basic standard machine with high-power spindle)

CNC Milling-Turning Center Alzmetall GS 600/5-FDT Milling-turning machine Commissioning 05/2021 At call! Heidenhain TNC640 Spindle HSK-T 63 / 18,000 rpm Balancing system (only for FDT) Kinematics Opt Electr. Handwheel Skiving (only for FDT) Dyn. Collision Monitoring Heidenhain DNC Heidenhain Remote Desktop 3D model of the machine Advanced tool management Operating mode 3 Probe Heidenhain Tool Measurement Blum Laser Signal tower on the machine 18,000 spindle HSK-T 63 Continuous air through the spindle (with lubrication interval) Continuous air from the outside 76 mm tool magazine Spray gun Chip flushing of the working area (recommended for Al) Emulsion Mist Extraction Production package C, 80 bar, hinged belt conveyor Machine Interior Trim Remote diagnostics The options list is complete! No interest in dealer enquiries! No separate dealer price! WB me ...

CNC Milling-Turning Center Alzmetall GS 600/5-FDT Milling-turning machine Commissioning 03/2019 At call! Heidenhain TNC640 Spindle HSK-T 63 / 18,000 rpm Balancing system (only for FDT) Kinematics Opt Electr. Handwheel Skiving (only for FDT) Dyn. Collision Monitoring Heidenhain DNC Heidenhain Remote Desktop 3D model of the machine Advanced tool management Operating mode 3 Probe Heidenhain Tool Measurement Blum Laser Signal tower on the machine 18,000 spindle HSK-T 63 Continuous air through the spindle (with lubrication interval) Continuous air from the outside 76 mm tool magazine Spray gun Chip flushing of the working area (recommended for Al) Emulsion Mist Extraction Production package C, 80 bar, hinged belt conveyor Machine Interior Trim Remote diagnostics The options list is complete! No interest in dealer enquiries! No separate dealer price! WB me ...

The machine is in good technical condition, a test run is possible by prior arrangement. OKUMA 5-axis vertical machining center MU-400VII with OSP-P300M-H – Tool magazine for 48 tools, BT40 (or Big Plus) – Tool breakage detection incl. automatic length measurement – Preparation for the function of automatic zero point shift (incl. software) – Collision avoidance system for 4-/5-axis milling centers – Coolant pump 0.8 kW instead of the standard version 0.25 kW – Flush cooling – Function for automatic zero point displacement incl. workpiece measurement, Renishaw OMP60 probe – Cutting edge control for 5-axis machining – Super NURBS Type A for 5-axis centers –Conveyor

BAZ Chiron FZ18W

MODEL: VERSAMATIC 400 TYPE: TV-MO SERIAL NUMBER: VS4 166 YEAR OF BUILD: 1995 CNC: HEIDENHAIN

Key data: 762 mm, 460 mm, 460 mm

Vertical machining center Okuma MB-46UAE Year of Make: 2004 Control OSP U100M Machinery ▪ Spindle – speed 8000 rpm. ▪ High-speed machining (Hi-Cut) ▪ Spindle load monitor (load monitoring) ▪ Thread milling (Herical-Cut) ▪ Workpiece zero points 50 pieces ▪ 200 Tool Corrections ▪ Manuals available (documentation) ▪ Tool changer with 32 positions ▪ Internal coolant supply Technical details ▪ Travel X-axis (column right-left): 762 mm ▪ Travel Z-axis: (table forward-backward): 460 mm ▪ Y-axis travel (spindle up-down): 460 mm ▪ Distance table surface to spindle nose: 150~610 mm Table ▪ Table size: 1000 x 460 mm ▪ Distance from the floor to the table surface: 800 mm ▪ Max. load capacity: 700 kg Spindle ▪ Spindle speed: 8,000 rpm ▪ Number of gears: infinitely variable ▪ Front bearing diameter: 70 mm ▪ Spindle: 11/7.5 kW � ...

General Manufacturer: Chiron Type: DZ 28 P five axis Year of manufacture: 2023 Control: Siemens Sinumerik 840D SL Travels: X 1,200 mm Y 1,100 mm Z 800 mm Rapid traverse: X 120 m/min Y 75 m/min Z 75 m/min Axle acceleration: X 1.0 g Y 0.8 g Z 1.5 g Main spindle drive Speed: up to 20,000 rpm 2-axis torque swivel device 2 x face plates diameter: 479 mm Swivel axis as A-axis Swivel angle: ± 120° Swivel radius: 700 mm Bridge dimension: max. 2,400 mm Repeatability: ± 5" Speed: 42 1/min NC rotary table as C-axis Clamping force: 25 kN +/- 15 % per clamping segment Repeatability: ± 5" Speed: 100 1/min Loading and unloading station for tools Tool Stations: 2 x 36 Tool shank: HSK-A 63 DIN 69893 Tool diameter: max. 78 mm Tool diameter with free adjacent spaces: max. 160 mm Tool length: max. 450 mm Tool weight: max. 10 kg Tool change time: approx. 0.9 s Ma ...

Key data: 762 , 508 , 508

HAAS UMC-750SS Machining Center TECHNICAL FEATURES: Year: 2019 Number of continuous axes: 5 X-axis stroke: 762 [mm] Y-axis travel: 508 [mm] Z-axis travel: 508 [mm] C-axis angular travel: 360 [°] Table dimensions: Ø630 x 500 [mm] Maximum weight Tabletop Allowance: 300 [Kg] B-axis angular travel: +110 [°] / 350 [°] Pin Attachment: CT 40 Maximum speed Spindle: 15000 [rpm] Spindle power: 22.4 [kW] Number of tool magazine stations: 40 Capacity of the garden tray: 284 [l] Number of hours in operation: 5277 [h] EQUIPMENT INCLUDED: x1 Center-Spindle Watering x1 High Pressure Coolant Pump 21 [bar] x1 RENISHAW Wireless Coin Probe x1 Calibration Sphere x1 RENISHAW Tool Probe x1 HAAS Oil Mist Vacuum x1 HAAS offset crank x1 HENNIG Chip Conveyor Type 101435 Machine visible under tension for testing at our premises, by appointment. Price excl. VAT on request,  ...

3 pcs double spindle machining centers SW BA422 built 2015/2014/2014 - 4-axis version Workspace x-axis 400 mm y-axis (tool change position) 500 (775) mm z-axis 425 mm Spindle spacing 400 mm Double swivel beam (Q-axis) 0 – 180° with NC rotary axes and counter bearings ----- Number of spindles 2 Spindle speeds up to 17,500 1/min Power 40/ 100% ED 2x 35/26 KW / 80 Nm ----- Feed/rapid traverse x/ y/ z 55/ 70/ 70 m/min Tool magazine 2 x 60 tool positions Tool holder HSK 63 Max. tool diameter 80 / 160 mm Max. tool length 300 mm Max. tool weight 10 kg Installation area L x W x H approx. 7.0 x 4.0 x 4.38 m Machine weight approx. 18,000 kg Transport weight approx. 15,000 kg Equipment: - Expansion of the tool magazine to 2 x 60 tool positi ...

Key data: 2500 mm, 1240 mm, 200 mm

CNC Machining Center SCM Type Z 25 PLUS R4R4 Year of manufacture 2005 Working range X between stops 2500 mm Vertical bores Y 1018 mm Milling Y 1240 mm Plate throughput maximum 180 mm Maximum panel thickness Z = 100 mm Stroke Z axis 200 mm Central lubrication at the top and bottom Drilling unit with 15 vertical spindles 6 horizontal spindles, 4 in the X direction and 2 in the Y direction Spindle speed 4000 rpm. Motor power spindle rotation 2.2 kW Travel speed of the X-Y axes 42.4 m/min. Travel speed Z axis 11.5 m/min. Main spindle approx. 6.6 kW Maximum speed of the main spindle 24000 rpm. Front tool changer with 4 tool holders Rear tool changer with 4 tool holders Rectangular Vacuum Cups 16 Pieces Tool holder HSK 63 Compressed air 6/7 bar, compressed air consumption 150 l Vacuum pump 40 m³/h 3/3.6 kW Air intake speed 30 m/h Suction nozzle diameter 160 +  ...

-X-Way-700mm -Y-way-700mm -Z-way-700mm -Control-ITNC 530 -Spindle holder HSK A63 -Spindle speed-12000rpm -Plate changer with 7 pallets -Tool magasin with 120 -Internal cooling feeder-40bar -Spindle motor-20kW -Pallet size 500x500mm -Machine weight approx.16t -Top condition,to be visited under electricity

Control type: CNC Sinumerik 840D-SL x-way 1135 mm y-way 1050 mm z-way 750 mm table size 1400 x 1050 mm Table load 2500 kg max. workpiece size LxWxH 1400 x 1240 x 750 mm Speed 10000 rpm feed speeds X/Y/Z Axis 40000 mm/min Expressspeeds x/y/z 40000 mm/min Tool holder HSK-A100 HSK Number of places in the tool magazine 30 places max. tool weight 20 kg max. tool length 395 mm max. tool diameter 110 mm Machine height 3294 mm Drive power - spindle motor 44 kW machine weight approx. 17.9 t Space requirements approx. 15 m2 Information: Universal milling machine in mono BLOCK design (3-axis) - available September 2019 - only 3800 spindle hours, 13400 power-on hours Equipment / Accessories: - Coolant system - High-pressure pump - Chip conveyor - Hand-held panel - BALLUFF option - Documentation

YEAR: 08/2004 LONGITUDINAL CORSA: X 800 MM TRANSVERSE COURSE: Y 700 MM VERTICAL COURSE: Z 700 MM ASSE B INDEXED 1st PALLET (2) 500X500 MM CNC MAPPS MSG-501 TOOL WAREHOUSES 60 LOCATIONS ATTACK MANDRINO BT40 MANDRINO MASSIMA VELOCITY 12000 RPM POWER OF MANDRINO'S POWER 26 KW
