longitudinal welding used for sale

Double gantry longitudinal seam welding machine Oerlikon/Cloos Year of manufacture: 2011, Retrofit 2019 Working range: welding length 32,000 mm, Ground chassis incl. ball bearing Travel: 32,000 mm Travel speed: 0.3-5.0 m/min Chassis dimensions: approx. 2,600 x 4,900 mm Track gauge: approx. 2,000 mm Platform incl. lifting column Stage dimensions : approx. 3,000 x 4,800 mm Total height: approx. 7,000 mm Rail height: approx. 420 mm Swivel range: +/- 90° Travel height: 3,200 mm Boom arm: 5,200 mm, Double gantry with two chassis and burner carriage 2x Cloos 600A welding machines The machine is capable of welding both transversely and longitudinally, as well as round seams in conjunction with a roller-turn device or a tilt-and-turn table. The travel distance of the system can be extended by adapting the rail system and energy chain on site.

CNC round seam welding machine make CLOOS type CD 500 / SR / 4LB / IA / BFabr. -No: 10005, wiring diagram -No: 86516 year 1986Center height: 450 mmTurntable diameter: 600 mTip width: 1500 mmDimensions L x W x H approx: 3000 x 1000 x 1300 mmused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Longitudinal carriage, chassis, welding carriage, longitudinal carriage, automatic welding machine, welding carriage, inert gas welding device, longitudinal seam welding system, longitudinal seam welding machine, longitudinal seam welding device, rail runner, welding tractor -Stable, compact and modular design -4-wheel drive via stepper motor -Wheels with polyurethane treads -Excellent directional stability -Viscose damper for constant driving -Integrated position measuring system -Reinforcement frame with mounting spigot for wire feed -4 pieces of lifting eyes -Power supply and PLC power unit integrated in the chassis -Power cord with plug: 12 m -Control line to the power source: 10 m -Incl. Hose package

Longitudinal circular saws with cutting length of 6.2 m Cutting width expanded to 2100 mm for plate cut 11 kw saw motor 170 mm cutting height Hydr. Feed up to 80 m / min Workpiece holders electron. Programming control

Longitudinal slitting machine for paper. NEW. Cutting to length (columns) paper or foil to approx. 70 cm width-Perforieren paper, labels, cards, forms -6 Circular blades (blades), or alternatively 6 perforating knife holder -Maximum paper width 70 cm Shipping is possible with extra charge.

2 Coilhaken 1 x 9 t 1 x 1 t

Unwinding reel / decoiler â?¢ Bandwidth / strip width max. 1,500 mm â?¢ Tape thickness / strip thickness (430 N/mm2) 0.5-2.0 mm â?¢ Coil outer diameter / coil outer - 1,300 mm â?¢ Coil inner diameter / coil inside - 470-520 mm â?¢ Coil weight / coil weight 10,000 kg â?¢ Side shift / side shift . . . . . . . . . . . . . . . . .

Longitudinal saw Irion Cutting length approx. 3 m Stop adjustable for cutting width by handwheel Saw blade diameter 550 mm Saw with hydraulic feed Saw drives up, drives through from front to back, lowers and goes back under the table

Longitudinal saw with milling unit Schirmer Cutting length approx. 2400 mm with milling unit

Technical data: Bandwidth / strip width min. 150mm Bandwidth / strip width max. 1,650 mm Strip thickness min. 0.4 mm Strip thickness max. 400 N/mm² 2.5 mm 300 N/mm² 3.0 mm Coil weight decoiler/ coil weight decoiler 12,000 kg Coil outer Ø / coil outer-Ø 1,600 mm

Cutting height: 205 mm Motor output: 11 kW cutting width: 450 mm Cutting length: 5200 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Cut-to length slitting machine SM-1250х8 Cut-to-length slitting machine is used for longitudinal cutting of the metal sheets with maximum thickness 1mm, aluminum composite panels, paper, polycarbonate thanks to special cutting knives that are fixed on rolls of the slitting machine. This cut-to-length slitting machine lets you to cut the material into eight strips. The diameter of the rolls is 56 mm There are four types of the sheet metal cut-to-length machines we make: The manual cut-to-length slitting machine (cutting for 2 strips) The electric cut-to-length slitting machine (cutting for 3-4 strips) The electric cut-to-length slitting machine (cutting for 6-10 strips) The electric cut-to-length slitting machine (cutting for 12-20 strips) The operator of cut-to-length slitting machine can easily change the width of the strips and their numbers. There are special scr ...

An indestructible machine for the toughest conditions. The machine is suitable for processing raw wood. The machine has no inclination. The saw blade is located directly on the motor. Technical parameters: Maximum saw blade diameter: ø 500/mm Power of the main motor: 5.5 kW Main speed of the saw blade: 2850 rpm Maximum cutting height: 85 mm (with 350 mm saw blade) Inclination of the saw unit: NO Dimensions of the iron table: 1050 × 600 mm Aluminium formatting table: 2000 × 360 mm / OPTION 3200 x 360 mm Formatting table for hardened rods (Altendorf principle) Cutting length: 2000 mm Weight of the machine: 450 kg Given the prices of new Chinese machines that cannot withstand the harsh conditions, this machine is the solution. Made in Slovakia in Europe

Machine for the processing of large-area composite panel materials With this machine you are able to process portrait panel semi-finished products that are otherwise difficult to process We offer you a technology that has already proven itself in practice and works. With this technique you can process semi-finished products up to a maximum height of 220 mm precisely and accurately The technical parameters are queried and measured as required.

12″ x .125″ x 4000Lb Bliss Slitting Line Make: Bliss Material Width: .075” – 12” Material Thickness: .008” – .125” Weight Capacity: 4,000Lb Coil ID: 16” – 20” Coil OD: 72”

18″ x .070″ x 6,000Lb Morvay Slitting Line Material Width: 18″, Weight Capacity: 6,000Lb, Material Thickness: .008″-.070″, Coil ID: 20″, Direction: Left to Right. Mandrel Uncoiler with Disc Brake, Powered Mandrel Expansion, Powered Hold-Down Roll, Driven Entry Pinch Rolls, Slitting Head with Adjustable Arbors, Knives & Tooling, Recoiler with Hydraulic Push-Off, Powered Over-Arm Separator, 50HP Motor, Exit 2-Arm Turnstile

60″ x .135″ x 20,000Lb Cincinnati – Forte Loop Slitting Line Material Width: 12″ – 60″ , Thickness: .010″ – .135″, Weight: 20,000Lb, Coil ID: 16″ – 24″, Coil OD: 72″, Speed: 600 fpm, Direction: Left to Right. Entry Turnstile, Entry L-Type Coil Car, Mandrel Uncoiler with Hold-Down Roll, Powered Peeler, Driven Pinch Rolls, PVC Applicator, Entry Shear, Two Slitting Heads, Injection Design, 5″ & 7″ Arbor Diameter, 75HP DC Motor, Two (2) Hydraulic Scrap Winders, Pit Cross Over Table, Drag Board & Rotary Tension Stand, Recoiler with Over-Arm Separator & Push-Off, 150HP DC Motor, Exit L-Type Coil Car & Turnstile. Electrics, Hydraulics, Controls, Tooling, Spare Parts

60″ x .135″ x 40,000Lbs Yoder Slitting Line Material Width: 12″ – 60″ Material Thickness: .010″ – .135″ Weight Capacity: 40,000Lbs Coil ID: 20″-24″ Coil OD: 72″ Pull Through Design Entry Coil Car Mandrel Uncoiler with Hold-Down Roll Hydraulic Peeler Driven Pinch Rolls Slitting Head with Gear Box and AC Feed-Up Motor Single Scrap Winder Recoiler with Over-Arm Separator DC Motor Drive Exit Turnstile Electrics, Hydraulics, Controls

72″ x .187″ x 50000Lb Paxson Loop Slitting Line Make: Paxson Material Width: 12″ – 72″ (Uncoiler 60″) Material Width: .010″ – .187″ Coil Weight: 50,000Lb Coil ID: 20″ – 24″ Coil OD: 72″ Speed: 500 /1000 fpm Direction: Right to Left Material Strength: 40,000 yield / 50,000 psi shear Material: CR, HR, Galvanized Entry Transfer Cart Entry Coil Car Mandrel Uncoiler Powered Hold-Down Roll Powered Expansion Sliding Base Hydraulic Peeling Table Driven Pinch Rolls

Universal Slitting Line 72″ x .187″ x 20,000Lb Material Width: 12″ – 72″ Material Thickness: .015″ – .187″ Coil Weight: 20,000Lb Coil ID: 20″ Coil OD: 72″ Direction: Left to Right Entry Floor Standing Coil Car L-Type Design Hydraulic Lift & Traverse Mandrel Uncoiler Powered Hold-Down Roll Hydraulic Expansion Air Cooling Brake Sliding Base Hydraulic Peeling Table Slitting Head Arbor Diameter: 7″ Powered Arbor Adjustment 100HP DC Motor Knives & Tooling Recoiler Powered Push-Off Hydraulic Over-Arm Separator Hydraulic Expansion 100HP DC Motor Exit 2-Arm Turnstile Arm Width: 72″ Powered Rotation Complete Slitter with Electrics, Hydraulics, Controls, Tooling

approx. 2,700 longitudinal bracing, for longitudinal bracing as an alternative to cross bracing, LV 3134 for span length 1,282mm – used - : Price per piece ex site: only 4.- € (net)! 4 pieces are needed per field! Manufacturer: SSI Schaefer Type: LV 3134 Year of construction: 2021 Field length 1,282mm Shelf height 40mm Original price per piece: approx. 12.-€ (net) Longitudinal braces Sheet steel, painted light silver. For longitudinal bracing as an alternative to cross bracing, if cross braces in the double rack interfere with storage or if both sides are to be operated in the single rack. In order to ensure subsequent height adjustability, the frame distance for double racks must be at least 30 mm. In each shelf space of a rack row, the lower and upper shelves are to be provided with 2 longitudinal supports (for shelf heights up to 2967 mm). The form-fittin ...

approx. 800 pieces of longitudinal braces for R8000, for longitudinal bracing as an alternative to the cross bracing for span length: 994mm – used - : Price per piece ex site: only 3.- € (net)! 4 pieces are needed per field! Manufacturer: SSI Schaefer Type: LV 8000 Year of manufacture: unknown Field Length: 994 (mm) Shelf height: 30 (mm) Original price per piece: approx. 12.-€ (net) Longitudinal braces Sheet steel, painted light silver. For longitudinal bracing as an alternative to cross bracing, if cross braces in the double rack interfere with storage or if both sides are to be operated in the single rack. In order to ensure subsequent height adjustability, the frame distance for double racks must be at least 30 mm. In each shelf space of a rack row, the lower and upper shelves are to be provided with 2 longitudinal supports (for shelf heights up to 2967 mm ...

Paxson Loop Slitting Line 72″ x 0.375″ x 50,000Lb (A3754) Make: Paxson Material Width: 12″ – 72″ Weight Capacity: 50,000Lb Thickness: .050″ – .375″ Coil ID: 20″ – 30″ Coil OD: 72″ Line Speed: 850 feet per minute Direction: Right to Left Entry L-Type Coil Car Floor Standing Design Hydraulic Lift & Traverse Self Contained Hydraulics Mandrel Uncoiler Powered Hold-Down Roll Hydraulic Expansion Water Cooled Brake Feed-Up Motor Sliding Base Hydraulic Peeling Table Driven Pinch Rolls Adjustable Edge Guides 4-Roll Coil Breaker Mechanical Entry Crop Shear Two (2) Slitting Heads Arbor Diameter: 9″ and 12″ Crane Removable Type Adjustable Arbors 150HP DC Motor Drive Multi Speed Gear Lots of Knives and Tooling Two Pro-Eco Scrap Winders Max Thickness: .500″ 25HP Motor for Each Unit Powered Open / Close Pit Cross Over Table Drag Bo ...

Bandwidth.. 870 mm Band thickness 0.2-3.0 mm Coil weight 10 to. Coil ID Unwinder... 400/508/750 mm Coil ADBewinder.. 1,500 mm Cutting performance. 110 N/mm2 Velocity 120 m/min.

Cut-to-length line Auxmet strip line Unwinding reel for max 4to coil weight Bandwidth 50-1000mm Material thickness 0.5-3mm at 600N/mm2 Line speed 60m/min Number of stripes 1-11 Reel reel up to 4to coil weight with foiling unit without knife with retrofitted photoelectric sensors The offer is aimed exclusively at traders within the meaning of §14 BGB

Vertical band saw PEHAKA - Petzing & Hartmann Kassel Type SLA 8 Masch. No. 39150 Year of construction 1995 Projection in width 780 mm Table size (work table) 1500 x 600 mm Hydraulic table movement 500 mm Table height 1080 mm Projection in height max 475 mm Table load max. 500 kg Roll diameter 800 mm Band saw blade dimension 6300 x 32 x 1.2 mm Belt speed 1400 m/min. Motor power 5.5 kW Mains connection 400 Volt, 50 Hz - Working table with 13 T-slots for clamping - hydraulic table movement 500 mm - infinitely adjustable feed speed via throttle valve 0-3000 mm /min. - 2x suction nozzle in the machine stand- hydraulic power pack permanently installed at the bottom of the machine stand - operating instructions, electrical plan, hydraulic plan available Space requirement L x W x H 2200 x 1500 x 2820 mm Weight 2000 Kg very good condition; used

SECOND-HAND LONGITUDINAL SANDER COMEC MOD. LON LS - CE RULES -Volt. 380/50 - S/N 970408 - Year 1997

Stock number: 3778 CUTTING LINE Manufacturer: MORGAN , Type: 1330 x 0.7 - 3.2 mm Specifications: Size scissors length 1330 mm Size sheet thickness 0.7 - 3.2 mm - Roller feed 2 pc dia. 100 rools Composed of: - Straightening machine 5 pc. dia 100 Reels - Drain reel 5 ton dia. 530-610 mm tone - Scissors Morgan 1500 x 3.2 mm Accessories: Coil trolley 5 ton Length: 6500 mm, Height: , Width: 33.00 mm, Weight:

Slitting line Pro-Eco 72″ x .250″ x 74,000Lb (A3774) Slitting line Pro-Eco 72″ x .250″ x 74,000Lb (A3774) is perfect solution for longitudinal cutting of coil metal into strips. This line can work with very big coils up to 74,000 Lb weight and 0.25 inches maximum metal thickness. Line is strong enough to make cutting speed 200 – 600 fpm depends on metal thickness and width you work with Slitting line Pro-Eco 72″ x .250″ x 74,000Lb (A3774) Manufacturer: PRO ECO Material: CRS, HRS, HPP & O Material Width: 12″ – 72″ Material Thickness: .060″ – .250″ Coil Weight: 74,000Lb Coil ID: 20″ – 30″ / 20″ – 24″ Coil OD: 72″ Line Speed: 200 – 600 fpm Direction: L-R Three (3) Coil Storage Ramp Coil Car Powered Lift & Traverse Double Cone Uncoiler Sliding Base Dual Water Cooled Brake Feed-Up Motor Powered  ...

Longitudinal circular saw Irion Cutting height 140 mm Cutting length 6000 mm Parallel cutting width 400 mm L x W x H: 8.0 x 1.6 x 1.2 m Year of construction: 1968 Weight approx. 2000 kg The machine is in good condition, operational. Subject to changes, errors and prior sale! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system+technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Phone: 0041 62 966 18 32 Fax 0041 62 966 21 12

Cutting length: 5320mm; Cutting height: 160mm; Feed rate: 0 - 80m/min; Width stop adjustment: electric; Display Cutting width: digital; Motor power: 11kW; Machine length: 7135mm;

Storti wood cutting line - Italian production - edger with a central disc with a pneumatic jump RM 400 S - crosscut saw TP2 - multisaw Multibi R16 - minimum material length 700 mm - maximum element width 500 mm - maximum element height 140 mm - line feed speed 30 m/min - total power 110 kW - space requirement 26 x 5.5 m TECHNICAL PARAMETERS: 1 Strorti RM400 S edger - cutting width max 330 mm - cutting height max 140 mm - element width max 500 mm - maximum element length 5000 mm - engine power 3 x 11 kW - seven steel toothed bottom pulling rollers - two upper toothed pulling rollers - pneumatic material pressure - the jump of the central disc is pneumatic - feed table 5000 mm roll width 500 mm diameter 80 mm - receiving table with edging 5200 mm roll width 500 mm roll diameter 140 mm 2 Storti TP2 crosscut saw - width of the finished element max 1600 mm - wi ...

directional control valve, hydraulic valve, with piston longitudinal gate valve ORSTA 04-307.51/81.1-0 TGL 26223/20 nominal diameter: 0.4 32 MPa ( 320 bar ) 10 dm3/min ( 10 l/min ) 1 x control magnet G35-H 24 V DC width across flats: 24 mm screw thread: M20 x 1,5 New ! Dimensions: 132 x 36 x 74 mm
