Cat.-Nr. 11-3200 new Necessary space for mash and lauter tun: LxWxH: 3 x 2 x 2,80 m Necessary space for tanks: LxWxH: 4,0 x 5,0 m complete 2 brews / day = 10hl Basic Equipment The Brew House is complete with all equipment. All equipment are with high standard an very simple to use. This 5 hl Brew House is built as 2 devices-brew house manual version with manual butterfly valve. It is possible to make 2 brews/day (10 hl) Technology All the pipes can be cleaned and sterilized in the circuit over the pump included. a) In the mash boiler the mash will be cooked, then it will be pumped with one beer pump made of stainless steel from mash boiler to the lauter tun. b) After the lauter wort will be pumped back to the mash boiler. c) After emptying the lauter tun the grit floor will be removed. The lauter tun will be changed to a whirlpool. d) After cooking th ...

Cat.-Nr. 11-3210 new Basic Equipment The Brew House is complete with all equipment. All equipment are with high standard an very simple to use. This 10 hl Brew House is built as 2 devices-brew house manual version with manual butterfly valve. It is possible to make 2 brews/day (40 hl) Technology All the pipes can be cleaned and sterilized in the circuit over the pump included. a) In the mash boiler the mash will be cooked, then it will be pumped with one beer pump made of stainless steel from mash boiler to the lauter tun. b) After the lauter wort will be pumped back to the mash boiler. c) After emptying the lauter tun the grit floor will be removed. The lauter tun will be changed to a whirlpool. d) After cooking the hops a special injection valve is introduced inside the lauter tun so that it can be used as a whirlpool. Mashing Tun / Wort Boiler Volume brutto: ...

3-vessel brewhouse with malting and wort cooling consisting of: Grist mill: - Grist mill (750 kg/h) - grist bin (1000 kg) - Hydrator for pre-mashing Brewhouse: - Mash tun (gross volume 48 hl, with stainless steel agitator) - Lauter tun (gross volume 70 hl, with stainless steel chopper and false bottom) - Wort kettle/whirlpool (gross volume 48 hl) Wort cooling: - Alfa Laval type M6-MBASE plate heat exchanger., Additional title: 3 vessel brewhouse, Cold wort quantity: 25 hl, Heating rate: 1 °C/min, Dimensions mash tun: 1850 mm diameter (outside), 1750 mm diameter (inside), 3200 mm height (outside), Dimensions lauter tun: 2350 mm diameter (outisde), 2200 mm diameter (inside), 3450 mm height (outside), Material: brew vessels from stainless steel 1.4301, Base construction: mounted on frame, Features: mash tun, lauter tun, combined wort kettle/whirlpool, 3 x flow meters, 5 x pumps, vorious ot ...

Additional title: y. o. c.: mostly 2003, Finished wort: 150 hl , Grist: 2500 kg, Current: three-phase A.C. current, Voltage: 400 V, Frequency: 50 Hz, Features: lauter tun, low pressure cooking wort copper-whirlpool system with external wort boiling system, additional whirlpool, trub collecting unit, hop dosage , Periphery: lauter wort heater, vapor condenser, Code: 539

Copper 4-vessel brewhouse for a production of approx. 100 hl / brew consisting of mash kettle, mash tun, lauter tun and wort kettle as well as a whirlpool. The brewhouse was rebuilt and modernized several times in the years 1990-2001., Additional title: 1958-2001, Capacity: 100 hl/batch , Features: mash tun (copper), mash kettle (stainless steel, 1977), lauter tun (copper, false bottom made of stainless steel), wort kettle (stainless steel and copper cladded) with inner cooker (modification 1999), vapor condenser (Nerb, 2001), wort cooling heat exchanger, Schmidt-Bretten, type Sigma37H, Periphery: spindle station, wort pumps, cast wort pumps, warm water storage, CIP (for wort kettle), 2 tuns (caustic and acid) every with 20 hl. incl. cleaning pumps), y.o.c.: 1989, Code: 890

Due to our rapid growth and expansion, our complete new brewing equipment is sold! Complete BREWHOUSE 10 HL Year of construction 2018/19 Type: 10HL (3 units) - Mash pan - Lauter tun incl. lauter lantern - Seasoning pan incl. whirlpool function Year of construction: 18/19 Amount of deflection per brew: 10hl Vessel material: stainless steel Material of hoods: stainless steel Heating Steam Siemens Simatic S7 control system Accessories: Stainless steel cabinet incl. control terminal brewhouse + fermentation cellar (up to 15 tanks) Automatic control of brewhouse (pneumatic valves) Control unit for brewhouse control incl. all pumps Steam Envy Strike Platform Plate apparatus (wort cooler) Manufacturer: NANHUA Type: 2 circuits (glycol and water) Hourly output in litres: 10 HL 60min 8-10°C Cooling media: glycol and water Year of construction: 2019 Number o ...

Beer Brewery Two Vessel VELO 15hl/brew, two brews/day, up to 4000hl/annum Complete two vessel beer brew line made by Italian VELO (currently TMCI Padovan) suitable for various beer types from ALEs to LAGER’s, non-alcoholic beers to strong, over 10% Imperial Stouts. Normal brew size has been 1500 liters and during high season, they have brewed 2 brews during 10-hour day. Maximum batch of malt is 600 kg. Without adding sugar beer wort has been from 18.5 to 21 Plato and with sugar added, up to 35 Plato. One complete brew batch with CIP will take about 5-6 hours. In operation, this brewery has overlapped brew batches so that once the first batch of the day has been lautered and spend grain has been unloaded, they started next brew. Maximum weekly brewing capacity with 10 hour working days has been 6 brews (3x3000 liters CCT) due to fermenting tank capacity which leads to theoretical 40 ...

Craft Beer Brewhouse Kaspar Schulz 30hl, 4 brew/day - 2014 Complete 5-vessel brew house consisting of German Kaspar Schulz in year 2010 made 2-vessel Brew Block, one dual functioning mash tun / wort kettle and the one lauter tun (originally also dual functioning lauter tun / whirlpool) brew vessels. In year 2014 the capacity was increased by adding third Kaspar Schulz made wort kettle / whirlpool brew vessel which is steam heated with an external heat exchanger. At that time completely new brewing process control system was added and now it is fully automatic, running with Phenning Braumatik brew program installed in a Siemens S7-300 PLC. Brewing operations can be made either from a large Simens Colour Touch Screen of from connected PC. Changing recipes and creating new ones is very easy with Braumatik and can be done without any programming knowledge. Delivery includes complete brew  ...

Copper-clad brewing block with mash and wort kettle, lauter tun and whirlpool Discharge volume 10 hl, Additional title: compact brewhouse, Discharge volume: 10 hl at 12° Plato, Total mass brewblock full: 7 to, Transport height appr.: 2600 mm, Length: 4000 mm, Width: 1500 mm, Height: 3580 mm, Weight: 3400 kg, Operation / Control: will be renewed by arrangement, Material: Stainless steel, copper-clad vessels, Base construction: Stainless steel frame construction with assembly of all plant components such as mash tun, lauter tun and whirlpool underneath; , Features: Pumps, valves and control cabinet; roped stainless steel staircase with access to the operating platform

100hl Complete Brewery Location: UK SCADA Controlled 100HL SPR UK brewery capable of 3 brew cycles per day Mash Conversion Vessel Lauter Tun Copper Kettle Whirlpool Porteus Mill System Scada Control System 100hl FV x 4 200hl FV x 3 200hl MV x 6 200hl Bright Beer Tanks x 2 50hl Rough Beer Tanks x 2 50hl Bright Beer Tank FV 50hl Schenk Filtration System Yeast tanks x 5 CIP System x 2 Heat Exchanger x 5 Stainless Steel mixing tanks Stainless Steel buffer tanks Spirax Condensate recovery x 2 Babcock Wanson Steam Generator Abac Air Compressor Water Treatment Plant Various Stainless Steel Pumps Laboratory Equipment CO2 Tank Glycol Chiller

BAVARIAN BREWERY TECHNOLOGY - 80HL BREWERY WITH TANKFARM YEAR 2009, UPGRADED 2020 FORMER DARK STAR UK BREWERY Alan Ruddock Complete Malt Milling System with Steels Masher Bavarian Brewery Techology Mash Mixer Bavarian Brewery Techology Lauter Tun Bavarian Brewery Techology Brew Kettle Bavarian Brewery Techology Whirlpool Scada Control System (2020) HLT Vessel 1 8500 Litre HLT Vessel 2 8500 Litre CLT Vessel 20,000 Litre Brewhouse Pumps, Flowmeters, Valves, Pipework TANK FARM 6x Bavarian Brewery Technology Stainless Steel Jacketed Conical Fermenter, 9,000 litre 4x Biomashin Stainless Steel Jacketed Conical Fermenter 9375 litre, 2011 4x Biomashin Stainless Steel Jacketed Dish bottom tank, 9200 litre, Year 2012 TMINOX 20,500 litre CCT Jacketed Stainless Steel Conical Fermenter TMINOX 20,500 litre CCT Jacketed Stainless Steel Conical Fermenter Also 37 bbl, ...

Additional title: with whirlpool, Capacity: 150 hl/brew, Operation / Control: ProLeit / Siemens S7, Material: brew house vessels copper-covered, Features: mash/wort kettle, mash/lauter tun, hop addition, vapor condenser system, whirlpool, wort cooler, various pumps and fittings

Overview This is a new brewhouse, which has already been partially completed. If necessary, the brewhouse can be completed within 3-4 months. It has a fully automatic control with the option to reduce to semi-automatic Technical data Maximum quantity of malt 350 k g / 1 brewing run of 10 hl Original gravity up to 22 ° Heating system with steam multipliers Steam requirement: 150 kg / h Heating capacity in the mash tun / wort kettle: 1°C / min and faster Temperature of cold wort 6 ° C (adjusted according to customer requirements) Wort cooling within 50 min. Number of brewing passes during infusion mashing: 3-4 Stainless steel operational platform Scope of Delivery Malt handling and milling system incl. Malt mill, malt tank and transport Brewhouse with 3-vessel-system consisting of:  Hydrator Mash tun with net volume of 10 hl Lauter tun with net volume of 15 hl Whirlpool with net volume ...

Beautiful copper 2 vessel brewhouse with additional whirlpool for production of 83 hl/brew., Additional title: output 83 hl, Capacity: 83 hl/batch, Operation / Control: Semi-automatic, Features: Mash-wort-kettle, lauter tun, whirlpool, automatic hop dosage, vapour condenser, plate heat exchanger , Periphery: 2 CIP-vessels

Overview The micro brewery was manufactured in 1999 by theGerman manufacturer BERAPLAN. All equipment is in good condition. A new wort copper was added in 2018.  List of equipment: 1. Mash Tun Made by Beraplan in 1999 Cylindric shape with conical ground Material: stainless steel AISI 304 Inner diameter: 2000 mm Height: 1600 mm Height conical part: 20 0mm Volume: maximum 38 Hl Double sidewall Insulation Heated by steam, which can be regulated Hot and cold water inlet at the bottom Can be emptied through the bottom 4 CIP balls PT100 2 agitators Mach pump with variable speed drive 2. Lauter Tun Made by Beraplan in 1999 Cylindric shape with flat ground Material: stainless steel AISI 304 Inner diameter: 2000 mm Height: 1200 mm Volume: maximum 37 Hl Filtering ground with trapezoidal perforations High precision valve to regulate the flow rate Hot and cold water inlet at the bottom 4 CIP ball ...

System includes (1) Pan, year of construction: 1990 (2) Lauter tun, year of construction 1970 (3) Whirlpool, year of construction: 80s, controls: WAGO, with hop dosing system, plate cooler and various pumps.

Overview The brewhouse, including fermentation and storage tanks and a KEG washer, was built in 2013 by the Austrian manufacturer Flecks. The whole equipment is in a very good condition and can be visited. Equipment Mash and brew kettle incl. whirlpool function, agitator, stainless: 1.000 L net Lauter tun, stainless: 1000 L net Calandria system (outdoor cooker), electrical heating, stainless. Integration of existing gas, heating + electrical: 72 kW Vapour-condensation system Whirlpool- system Mash and wort pump: 2,2 kW Hot water tank with electrical heating, stainless: 1000 L, 9 kW Wortcooler GEA 2-stages pT 100, electron. Thermometers Incl. all pipes, fittings, valves in stainless. Full automation upgrade: electrical switch board for full automatic process control switches, fuses: 100 kW Main connection 400 V Emergency switch PC-databus and modem Visualisations and automation software  ...

Classic Czech compact 11HL two-vessel steam heated brewhouse with platform. Wort cooler included. Vessel 1: Mashing/boiling/whirlpool with mixer on the bottom. Steam heated with automatic temperature control. Vessel 2: Lauter (or filter) tun. Works much like a large sieve. It has rotating rake arms with a central drive unit. Cutting blades hang from these arms. Easy automatic expulsion of spent grain by a removable piece on the turning device. It pushes the spent grain through the door on the front. 1500L/h wort cooler. Manufacturer: TENEZ (CZ). Reason of sale: installation of 25HL brewhouse. Will be in operation until January 12th.

For museum lovers! Brewhouse 2 Devices 30 hl Built in 1958 Manufacturer: Ziemann / Germany Brewing pan, lauter tun, both copper-clad and with many accessories Further information and price on request

Capacity: 40 hl, Features: mash/wort tun, lauter tun, whirlpool, wort cooling pump, plate heat exchanger, hot water tank. cold water tank, CIP station, various valves, pumps and measuring equipment

Brewing plant 2,5 hl - Malt mill - Mash/wort kettle - Lauter tun - 3 x fermentation vessels, open - 3 x storage tanks - Cold water tank - Cooler - Beer pump, Additional title: 2,5 hl, Capacity: 250 l, Features: Beer pump

Complete microbrewery - brewhouse with 10 hl output and up to 1500 hl annual production. High-quality brew kettle made by Schulz, double-walled with internal boiler, lauter tun and whirlpool, complete piping, hoses. Fully automatic with control cabinet, Manual mashing, hop addition and decoction, malt mill, small equipment, wort cooler and wort aeration. Fermentation and storage cellar: 1 open fermentation vat 10 hl, 2 flat-conical fermentation tanks 20 and 30 hl net capacity, 4 storage tanks 20 hl, 6 dispensing tanks/pressure tanks 10 hl, 1 pressure tank 30 hl, automatic temperature control for fermentation tanks and ZKT, 2 cellar pumps, hoses, 1 desi tub. Filling area: 1 cabin washer with hot water tank for KEG and bottle cleaning; 1 siphon filler. Many accessories, small parts, hoses etc. Utilities: 1 steam generator 120 kg/h 1 ice storage refrigeration system 1 compressed air system  ...

consisting of: - Malt milll - Mash-/Wortkettle/Whirlpool - Lauter tun - Warmwater vessel - Wort cooler - Wort aeration - Siemens touch screen - 4 x Fermenting vessel - 8 x Storage tanks with shell cooling surface - Icewater vessel - mobile beerpump - Steam boiler - 2 Bottle-filler + 1 Can-filler by Fillmatic, Additional title: 5 hl-Brewery, with Grist Mill, Compact-Brewhouse, Fermenting vats, Storage tanks, Cast out wort: 5 hl, Heating rate: °C/min., Capacity wort cooler: 750 l/h, Wort cooling time: 40 min., Material: Brewing vessel, hotwater tank, fermenting and storage tanks in stainless steel, 1.4301, Base construction: Brewhouse compact unit on stainless steel frame, vertical Fermenting vats on feet, horizontal storage tanks on two layer in a stainless steel frame., Features: mobile grist mill, mash-/wortkettle, lautertun, warmwatertank, wort-cooling and aeration, 4 fermenting vats, ...

Cat. No. 11-3210 New Plant description Sudwerk This small-sud plant comprises all components for a complete and fully functional brewing plant. All system parts used have a high quality standard and are characterized by their ease of use. The two-device brewhouse consists of a mash/spice pan and a purified vat, which is also used as a hot tub. Technical description All pipes are cleaned by a circulation pumping system. a) In the mash pan, the mash is boiled, then the mash is pumped with the beer pump into the purifier pond. b) When bluish, the wort is pumped back into the mash pan. c) After bluish, the purified vat is cleaned and the sieve bottom removed. A special injection nozzle is installed on the cylinder wall at the bottom of the läuterbottich. As a result, it can also be used as a hot tub after removing the mobile screen floor. d) After boiling the hops  ...

20 hl brewhouse delivered by ANT in 2014, available - 20 hl 3-vessel, mash mixer, lautertun, brewkettle/whirlpool, steam heated, with semi-automation. - 25 hl HLT - 200 kW natural gas steam generator (made by Manara, Italy) - Plate HX for cooling wort, with aeration system and 30 l in-line yeast vessel - Glycol chiller with tank - Brewhouse platform - Malt mill (made by Sommer, Germany) - Various piping, valves etc. The equipment is of good quality
