Hemco hydraulic tracing lathe Hopper feed very good condition...$7,900 obo Contact Fred (716) 433 4224 (12:00 noon is best time to call)
ZUCKERMAN CHALLENGER- auto copy lathe and sander, capacity - ( mills 10" dia.by a max. of 120" long) mills using cup cutters- followed by (1) sanding station, unit has hopper feeder, mills & sands one part at a time, does parts like: boat oars, shovel handles, gunstocks, chair legs, ect. Price-$10,900
Reichenbacker copy lathe mills/ turns (6) concentric or non concentric pieces at a time (1) station for your model/sample (models may be wood or metal) complete set up for duck decoys various sizes - items like Queen Ann legs, ect (photos available) (6) milling /working stations
Lmacchia Barley twist lathe- model012/FE Spiral/rope turning lathe Barley twist with automatic indexing 67" max. length 8" max. working diameter as new condition...$9,500 obo Contact Fred (716) 433 4224 (12:00 noon is best time to call)
Double head lathe for milling and turning tubes Automatic (un)loading of workpieces nbsp;
Leopoldo Pontiggia V 350 Center height: 350 mm Maximum turning diameter: 700 mm Distance between centers: 6000 mm
Lathe LABOR E 300 Brand: LABOR Model: E 300 Year of construction: 1994 Chuck size: 380 mm Center height: 300 mm Maximum turning length: 4000 mm Bed length: 5250 mm Bar capacity (spindle bore): 100 mm Self-centering chuck: Yes Four-jaw chuck: No CE Certification: Yes Overall dimension: 7000 mm x 1500 mm x 1500 mm H Our internal ref. 779
Lathe LABOR E 300 Brand: LABOR Model: E 300 Year of construction: 1997 Chuck size: 370 mm Center height: 300 mm Maximum turning length: 5000 mm Bed length: 6250 mm Bar capacity (spindle bore): 100 mm Self-centering chuck: Yes Four-jaw chuck: No CE Certification: Yes Overall dimension: 8000 mm x 2000 mm x 1500 mm H Our internal ref. 787
Rotary Lathe with Staylog Bar and Longitudinal Cutting System
Reinbacker- rope turning lathe chuck up your part- twin routers transverse your material as lathe slowly rotates your material several passes give you a straight or tapered spiral like a rope turning or straight or spiral flutes
HAISHU CNC550T 4-axis CNC Lathe Producer- Taian HAISHU Machinery Co. Ltd YOM 2015 Condition- Never used Equipped with two spindle and an additional lower turret with 12 tools, providing automatic two-way processing of the workpiece in the achievement of maximum processing speed. Control CNC GSK988TD Additional Y axis Max. working length 750 mm Maximum turning diameter over bed 550 mm Maximum turning diameter pallet 500 mm Spindle type А12 Hydraulic Jaws: 2x 300 mm Front spindle bore taper 1:20 Spindle pass 75 mm Speed of Servo spindled 0-4000 mm/min Axis X/Z/B Quick moves 40 000 mm/min CS1, CS2 power of main motors: 15 kW Engine motor on axle C- 5.5 kW Moment by Axis X/Z: 15 Nm Movement on Y axis: + 55/-55 mm; Moment on axis B: 20 N. m; Time to change tool 1.6 sec Positioning accuracy 0.005 mm Moves on axes X1/X2- 350 mm Moves on axes Z1/Z2- 1100/1350/1850 mm ...
Calpe (5) station CNC lathe
3-points Steady Ø 350 mm for SCULFORT Lathe Centre height: 550 mm Maxi diameter: Ø 350 mm Distance between fixing V: 350 mm Width: 1200 mm Thickness: 300 mm Total height: 1300 mm Weight: approx 250 kg
Touches 3-points Steady Ø 800 mm for SCULFORT Lathe Centre height: 550 mm Maxi diameter: Ø 800 mm Base dimensions: L 635 x W 300 mm Distance between fixing V: 480 mm Width: 1600 mm Thickness: 350 mm Total height : 1500 mm Weight: approx 250 kg
Polish Lathe / Polishing Machine Between points: 1500 mm Centre height: 180 mm Spindle CM3 Spindle speed driven by speed variator Pneumatic tailstock Equipped with a vaccum system (only air hose to plug in) Machine was used to polish axes Voltage: 220 V mono Dimensions (L x W x H): 3200 x 1000 x 1900 mm Weight: 1,2 T
This 600 Lathes Multiturn 2000 was manufactured in 2004. A robust horizontal turning machine featuring a turning diameter above bed of 400 mm, and a length of 1250 mm. It operates at a spindle speed of 2700 rpm with an 8-position turret. Tailstock taper is Morse 5. If you are looking to get high quality turning capabilities consider the 600 Lathes Multiturn 2000 machine we have for sale. Contact us for more information.
ul> Distance between heads: 3000 mm Diameter above the bench: 800 mm Lathe equipped with a fixed bezel Digital visualization MINILEXPRO 3-jaw chuck Manual tailstock Lots sold as is, unchecked, without tools or tool holders.
Spacing : 2000 mm Permissible diameter on bench : 720 mm Diameter on straggler : 430 mm X stroke : 410 mm Z stroke : 2000 mm Spindle speed : 1 – 1800 rpm Spindle bore : 106 mm Spindle nose : DIN 55027 size 11 Installed power : 28 kW Power supply : 400 V Lots sold as is, unchecked, without tools or tool holders.
Ref. -No.: 10320 Manufacturer: TOS Type of control: Digitalanzeige - Mitutoyo Control: Konventionell Storage location: Halberstadt Country of origin: Tschechien Tip length: 1500 Centre Height: 280 mm Centre Distance: 750,1000,15000,2000 mm Spindle Bore: 56 mm Swing diameter over bed: 500 mm Number of speed levels: 18 Circumferential diameter over the support: 320 mm Circumferential diameter over the bed recess: 560 mm Bed length relieved from headstock: 300 mm Universal chuck diameter: 250 mm Diameter of the clamping disc: 500 mm Further information: Universal center lathe
Ref. -No.: 10319 Manufacturer: TAKANG Type of control: Digitalanzeige ACU-Rite Control: Konventionell Storage location: Halberstadt Country of origin: Taiwan Weight Of The Machine Ca.: 1,3 t Swing diameter over bed: 430 mm Bed width: 300 mm Tip length: 1500 Centre Height: 215 mm Bed length: 1600 mm
Ref. -No.: 10317 Manufacturer: NOSOTTI Type of control: Digitalanzeige - Mini wizard Control: Konventionell Storage location: Halberstadt Country of origin: Italy Tip length: 3000 Centre Height: 260 mm
turning diameter: mm turning length: mm swing diameter over bed slide: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Brand Takang Machine no D895 Type TR1200x6000 Year of make 2015 Oil country Lathe Distance between centers 6.000 mm Center height 600 mm Turning diameter above the bed 1.200 mm ø Turning diameter above the support 890 mm ø Passage 150 mm ø Bed width 560 mm Glasses 400 & 550 mm 4-Jaw Chuck 1.000 mm ø Digital readout Heidenhein Power on the top support Rapid traverse along and transverse movement 3 lane bed Machine size (lxwxh) 8.500 x 1.700 x 2.300 mm Machine weight 13.800 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
tail stock: ja : ja condition: nicht geprüft weight of the machine ca.: 3,8 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: 2 turning diameter: max. 250 mm toll turrets: 2 x 12 control: Fanuc 16 T tool taper: HSK 63 : 04800000181 frequency: 50 Hz ampere: 168 A The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
chucking diameter: 250 mm greates pass round over bed: 500 mm swing diameter over slide rest: 290 mm centre distance: 850 / 1350 mm weight of the machine ca.: 2700 KG dimensions of the machine ca.: 2900 x 1953 x 1825 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning length: 1000 mm turning diameter: 350 mm turning dia. in gap: 450 mm spindle bore: 40,0 mm turning speeds: 70 - 2000 U/min bed width: 180 mm spindle taper: 55029 D 1-4 taper in tailstock: 3 MK quill travel: 110 mm total power requirement: 1,5 kW weight of the machine ca.: 529 kg. range L-W-H: 1730x700x1340 mm Scope of delivery: - 3-axis digital display i200 with LCD display - 3-jaw chuck DK11-160 mm / D4 - Face plate 200 mm / D4, according to DIN 55029 - Fixed steady rest - passage diameter max. 60 mm - Follow-on steady rest - passage diameter max. 60 mm - Clamping plate 250 mm - Quadruple tool holder - Shaft fixing device - Protection device for tool holder - Slip clutch - Micrometer longitudinal stop - Coolant device - Extendable chip tray - Frequency converter - Foot pedal with brake function according to CE - Splash guard - Thread gauge - LED machine light - Digital speed dis ...
turning length: 850 mm turning diameter: 400 mm swing diameter over bed slide: 245 mm spindle bore: 52.0 mm turning speeds: 45 - 1800 U/min bed width: 260 mm spindle taper: DIN 55029 D 1-5 taper in tailstock: 3 MK quill travel: 120 mm total power requirement: 3.0 / 4.5 kW weight of the machine ca.: 1255 kg range L-W-H: 1900 x 1000 x 1610 mm Equipment: - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck PS3-200 mm / D5 - Clamping disk 320 mm - Fixed steady rest - passage diameter max. 130 mm - Follow-on steady rest - passage diameter max. 100 mm - Coolant system - Quick-change tool holder with 4 inserts - Protective device for quick-change tool holder - Micrometer longitudinal stop - Slip clutch - Motor with magnetic brake in accordance with CE standard - Initial filling with Shell Tellus 46 - Extendable chip tray - LED machine light - Change gears - Reduction sleeve - 2 cente ...
turning length: 1500 mm turning diameter: 420 mm swing diameter over bed slide: 255 mm turning dia. in gap: 580 mm spindle bore: 52.0 mm turning speeds: 45 - 1800 U/min bed width: 250 mm spindle taper: DIN 55029 D 1-6 taper in tailstock: 4 MK quill travel: 140 mm total power requirement: 3.0 / 4.5 kW weight of the machine ca.: 1400 kg range L-W-H: 2570 x 900 x 1600 mm Equipment: - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck DK11-200 mm / D6 - Clamping disk 350 mm - Fixed steady rest - passage diameter max. 135 mm - Follow-on steady rest - passage diameter max. 65 mm - Coolant system - Quadruple tool holder - Protective device for quadruple tool holder - Micrometer longitudinal stop - Slip clutch - Turret stop with fine adjustment - Thread gauge - Motor with magnetic brake according to CE standard - Foot pedal with brake function according to CE - Initial filling with Sh ...
turning length: 1500 mm turning diameter: 560 mm turning diameter over slide: 350 mm turning speeds: 25-220/220-1500 U/min swing diameter over bed slide: 350 mm turning dia. in gap: 785 mm quill travel: 185 mm spindle bore: 105,0 mm engine output: 7,5 kW spindle taper: DIN 55029 D 1-8 quill:: 5 MK weight of the machine ca.: 2420 kg. range L-W-H: 2840 x 1150 x 1610 mm Equipment: - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck PS3-315 mm / D8 - Fixed steady rest - passage diameter max. 180 mm - Follow-on steady rest - passage diameter max. 120 mm - Foot pedal with brake function according to CE - Protective device for quick-change tool holder - LED machine light - Initial filling with Shell Tellus 46 - Clamping disk 450 mm - 2 centering points - Frequency converter - Digital speed display - Slip clutch - Rapid traverse longitudinal and planar - Coolant system - Quick-change ...
turning length: 3000 mm turning diameter: 660 mm turning dia. in gap: 870 mm turning diameter over slide: 420 mm turning speeds: 36 - 1600 U/min quill:: 5 MK quill travel: 150 mm spindle bore: 105,0 mm engine output: 7,5 kW spindle taper: DIN 55029 D 1-8 weight of the machine ca.: 3990 kg. dimensions: 4500 x 1280 x 1650 mm Scope of delivery - Slip clutch - Rapid traverse longitudinal and planar - LED machine light - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck PS3-315 mm / D8 - Clamping disk 630 mm - Fixed steady rest - passage diameter max. 250 mm - Follow-on steady rest - passage diameter max. 110 mm - 1 centering point / 1 follow-on punch point - Motor with magnetic brake in accordance with CE standard - Foot pedal with brake function in accordance with CE - Initial filling with Shell Tellus 46 - Coolant system - Quick-change tool holder with 4 inserts - Protective de ...
turning length: 1500 mm turning diameter: 410 mm swing diameter over bed slide: 255 mm turning dia. in gap: 580 mm spindle bore: 52,0 mm turning speeds: 30 - 3000 U/min bed width: 250 mm spindle taper: 55029 D 1-6 taper in tailstock: 4 MK quill travel: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1400 kg. range L-W-H: 2530 x 1000 x 1450 mm Scope of delivery - 3-axis digital display ES-12 V with LCD display - 3-jaw steel chuck PO3-200 mm / D6 - Clamping disk 350 mm - Fixed steady rest - passage diameter max. 135 mm - Follow-on steady rest - passage diameter max. 65 mm - Foot pedal with brake function according to CE - Quadruple tool holder - Protective device for quadruple tool holder - Micrometer longitudinal stop - Turret stop with fine adjustment - Frequency converter - Initial filling with Shell Tellus 46 - Coolant system - Slip clutch - Thread gauge - LED machine ...
turning length: 1500 mm turning diameter: 560 mm turning diameter over slide: 350 mm turning speeds: 25 - 1600 U/min swing diameter over bed slide: 350 mm turning dia. in gap: 785 mm quill travel: 180 mm spindle bore: 105,0 mm engine output: 7,5 kW spindle taper: DIN 55029 D 1-8 quill:: 5 MK weight of the machine ca.: 2.370 kg. range L-W-H: 2.840 x 1.150 x 1.460 mm Scope of delivery: - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck PS3-315 mm / D8 - Clamping disk 450 mm - Fixed steady rest - passage diameter max. 180 mm - Follow-on steady rest - passage diameter max. 120 mm - 2 centering points - Initial filling with Shell Tellus 46 - Motor with magnetic brake in accordance with CE standard - Foot pedal with brake function in accordance with CE - Coolant system - Quick-change tool holder with 4 inserts - Protective device for quick-change tool holder - Slip clutch - LED ma ...
turning length: 1000 mm turning diameter: 420 mm swing diameter over bed slide: 255 mm turning dia. in gap: 580 mm spindle bore: 52.0 mm turning speeds: 45 - 1800 U/min bed width: 250 mm spindle taper: DIN 55029 D 1-6 taper in tailstock: 4 MK quill travel: 140 mm total power requirement: 3.0 / 4.5 kW weight of the machine ca.: 1220 kg range L-W-H: 2070 x 900 x 1600 mm Equipment: - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck DK11-200 mm / D6 - Clamping disk 350 mm - Fixed steady rest - passage diameter max. 135 mm - Follow-on steady rest - passage diameter max. 65 mm - Coolant system - Quadruple tool holder - Protective device for quadruple tool holder - Micrometer longitudinal stop - Slip clutch - Turret stop with fine adjustment - Thread gauge - Motor with magnetic brake according to CE standard - Foot pedal with brake function according to CE - Initial filling with Sh ...
turning length: 3000 mm turning diameter: 660 mm turning dia. in gap: 900 mm turning diameter over slide: 460 mm turning speeds: 25 - 1600 U/min quill:: 5 MK quill travel: 235 mm spindle bore: 105,0 mm engine output: 7,5 kW spindle taper: DIN 55029 D 1-8 weight of the machine ca.: 3.300 kg. dimensions: 4.630 x 1.200 x 1.529 mm Scope of delivery - 3-axis digital display ES-12 V with LCD display - Slip clutch - Rapid traverse longitudinal and planar - LED machine light - 3-jaw steel chuck PO3-315 mm / D8 - Clamping disk 450 mm - Fixed steady rest - passage diameter max. 180 mm - Follow-on steady rest - passage diameter max. 120 mm - 2 centering points - Motor with magnetic brake in accordance with CE standard - Foot pedal with brake function in accordance with CE - Initial filling with Shell Tellus 46 - Coolant system - Quick-change tool holder with 4 inserts - Protective device for quick- ...
turning length: 1000 mm turning diameter: 400 mm turning dia. in gap: 560 mm spindle bore: 52,0 mm turning speeds: 45 - 2.000 U/min bed width: 210 mm spindle taper: 55029 D 1-5 taper in tailstock: 4 MK quill travel: 100 mm total power requirement: 2,0 / 2,4 kW weight of the machine ca.: 810 kg. range L-W-H: 1.890x800x1.600 mm Equipment: - 3-axis digital display i200 with LCD display - 3-jaw chuck DK11-200 mm / D5 - Faceplate 200 mm / D5, according to DIN 55029 - Fixed steady rest - passage diameter max. 90 mm - Follow-on steady rest - passage diameter max. 70 mm - Coolant system - Initial filling with Shell Tellus 46 - Extendable chip tray - Clamping disk 320 mm - Quadruple tool holder - Protective device for quadruple tool holder - Slip clutch - Micrometer longitudinal stop - Thread gauge - LED machine light - Reducing sleeve - Change gears - 2 centering points - Foot pedal with brake f ...
turning length: 1000 mm turning diameter: 380 mm turning dia. in gap: 490 mm spindle bore: 51,0 mm turning speeds: 70 - 2000 U/min bed width: 185 mm spindle taper: 55029 D 1-5 taper in tailstock: 4 MK quill travel: 120 mm total power requirement: 1,5 / 2,2 kW weight of the machine ca.: 575 kg. range L-W-H: 1920 x 800 x 1660 mm Equipment: - 3-axis digital display i200 with LCD display - 3-jaw chuck DK11-200 mm / D5 - Faceplate 200 mm / D5, according to DIN 55029 - Fixed steady rest - passage diameter max. 70 mm - Follow-on steady rest - passage diameter max. 50 mm - Coolant system - Initial filling with Shell Tellus 46 - Extendable chip tray - Clamping disc 320 mm - Quadruple tool holder - Protective device for quadruple tool holder - Slip clutch - Micrometer longitudinal stop - Thread gauge - LED machine light - Reducing sleeve - Change gears - 2 centering points - Foot pedal with brake ...
turning length: 3000 mm turning diameter: 800 mm turning dia. in gap: 1000 mm turning diameter over slide: 540 mm turning speeds: 25 - 1600 U/min quill:: 5 MK quill travel: 235 mm spindle bore: 105,0 mm engine output: 7,5 kW spindle taper: DIN 55029 D 1-8 weight of the machine ca.: 3820 kg. dimensions: 4800 x 1320 x 1580 mm Scope of delivery - 3-axis digital display ES-12 V with LCD display - Cable routing via energy chain - 3-jaw chuck PS3-315 mm / D8 - Clamping disc 500 mm - Fixed steady rest - passage diameter max. 180 mm - Follow-on steady rest - passage diameter max. 100 mm - 2 centering points - Motor with magnetic brake in accordance with CE standard - Foot pedal with brake function in accordance with CE - Initial filling with Shell Tellus 46 - Rapid traverse lengthwise and facewise - Slip clutch - Coolant system - Quick-change tool holder with 4 inserts - Protective device for qu ...
turning length: 1000 mm turning diameter: 360 mm turning dia. in gap: 480 mm spindle bore: 51,0 mm turning speeds: 70 - 2000 U/min bed width: 185 mm spindle taper: 55029 D 1-5 taper in tailstock: 4 MK quill travel: 110 mm total power requirement: 1,5 kW weight of the machine ca.: 540 kg. range L-W-H: 1920 x 750 x 1600 mm Equipment: - 3-axis digital display i200 with LCD display - 3-jaw chuck DK11-200 mm / D5 - Faceplate 200 mm / D5, according to DIN 55029 - Fixed steady rest - passage diameter max. 70 mm - Follow-on steady rest - passage diameter max. 50 mm - Coolant system - Initial filling with Shell Tellus 46 - Extendable chip tray - Clamping disk 320 mm - Quadruple tool holder - Protective device for quadruple tool holder - Slip clutch - Micrometer longitudinal stop - Thread gauge - LED machine light - Reducing sleeve - Change gears - 2 centering points - Foot pedal with brake functi ...
turning length: 1000 mm turning diameter: 420 mm swing diameter over bed slide: 255 mm turning dia. in gap: 580 mm spindle bore: 52.0 mm turning speeds: 30-550 / 550-3000 U/min bed width: 250 mm spindle taper: 55029 D 1-6 taper in tailstock: 4 MK quill travel: 140 mm total power requirement: 5.5 kW weight of the machine ca.: 1145 kg. range L-W-H: 2090 x 1050 x 1600 mm Scope of delivery - 3-axis digital display ES-12 V with LCD display - 3-jaw steel chuck PO3-200 mm / D6 - Clamping disk 350 mm - Fixed steady rest - passage diameter max. 135 mm - Follow-on steady rest - passage diameter max. 65 mm - Foot pedal with brake function according to CE - Quadruple tool holder - Protective device for quadruple tool holder - Micrometer longitudinal stop - Turret stop with fine adjustment - Frequency converter - Initial filling with Shell Tellus 46 - Coolant system - Slip clutch - Thread gauge - LED ...
turning length: 1000 mm turning diameter: 360 mm swing diameter over bed slide: 220 mm turning dia. in gap: 502 mm spindle bore: 52,0 mm turning speeds: 70 - 2.000 U/min bed width: 185 mm spindle taper: 55029 D 1-5 taper in tailstock: 3 MK quill travel: 100 mm total power requirement: 1,5 / 2,2 kW weight of the machine ca.: 575 kg. range L-W-H: 1825 x 750 x 1600 mm Scope of delivery - 3-axis digital display i200 with LCD display - 3-jaw chuck DK11-200 mm / D5 - Face plate 200 mm / D5, according to DIN 55029 - Fixed steady rest - passage diameter max. 70 mm - Follow-on steady rest - passage diameter max. 60 mm - Coolant system - Initial filling with Shell Tellus 46 - Extendable chip tray - Clamping disc 280 mm - Quadruple tool holder - Protective device for quadruple tool holder - Slip clutch - Micrometer longitudinal stop - Thread gauge - LED machine light - Reducing sleeve - Change gear ...
centre distance: 1500 mm : 550 serial number: 20-08 documentation: ja digital: ja hollow: 88 mm multifix: ja : Auffang Wannen The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
CONTROLS conventional BASIC FUNCTIONS number of spindles: 6 WORKING RANGE TURNING turning diameter (max): 20 mm bar diameter (max): 20 mm worpiece length max.: 100 mm MAIN SPINDLE spindle revolutions (min): 214 /min spindle revolutions (max): 5168 /min number of gears: 81 drive power: 11 kW DIMENSIONS / WEIGHTS space requirements -left/right-: 6000 mm space requirements -front/back-: 2000 mm total weight approx.: 5600 kg Technical Data - Max. diameter of hexagonal rods: 17 mm - Max. diameter of square rods: 14 mm - Max. stroke of sidecars: 42 mm - Forward and backward movement of sidecars: +/- 8 mm - Max. stroke of axial carriages: 50 mm - Forward and backward offset of axial ca
CONTROLS conventional BASIC FUNCTIONS number of spindles: 6 WORKING RANGE TURNING swing diameter (max): 20 mm turning diameter (max): 20 mm bar diameter (max): 20 mm MAIN SPINDLE spindle revolutions (max): 5168 /min ELECTRICAL SPECIFICATIONS total power consumption: 11 kW mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 5680 mm space requirements -front/back-: 1400 mm total weight approx.: 5000 kg tech. details: - max diameter hexagonal bars 17 mm - max diameter square bars 14 mm - max advancement bars 100 mm - max stroke axial carriages 50 mm - Offset of axial carriages forwards and backwards +/- 8 mm - Max stroke tool holder spindles 86 mm - Offset of tool spindles forward and backward +/- 11 ...
CONTROLS PLC SIEMENS BASIC FUNCTIONS number of spindles: 6
CONTROLS conventional BASIC FUNCTIONS number of spindles: 6 WORKING RANGE TURNING turning diameter (max): 20 mm bar diameter (max): 20 mm worpiece length max.: 100 mm MAIN SPINDLE spindle revolutions (min): 214 /min spindle revolutions (max): 5168 /min number of gears: 81 drive power: 11 kW X/Z SLIDE number of tool positions (total): 12 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 6000 mm space requirements -front/back-: 2000 mm total weight approx.: 5600 kg Technical Data - Max. diameter of hexagonal rods: 17 mm - Max. diameter of square rods: 14 mm - Max. stroke of sidecars: 42 mm - Forward and backward movement of sidecars: + ...
CONTROLS electronic controls SIEMENS BASIC FUNCTIONS number of spindles: 6 WORKING RANGE TURNING turning diameter (max): 32 mm bar diameter (max): 32 mm worpiece length max.: 125 mm MAIN SPINDLE spindle revolutions (min): 260 /min spindle revolutions (max): 3080 /min number of gears: 2 ELECTRICAL SPECIFICATIONS total power consumption: 14 kW mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 5750 mm space requirements -front/back-: 1300 mm total weight approx.: 8200 kg Machine completely overhauled and NEW (still in packaging) Technical Data - Max. hexagonal bar diameter: 28 mm - Max. square bar diameter: 22 mm - Max. longitudinal slide stroke: 125 mm - Extraction thread u ...
CONTROLS electronic controls SIEMENS BASIC FUNCTIONS number of spindles: 6 WORKING RANGE TURNING swing diameter (max): 32 mm turning diameter (max): 32 mm bar diameter (max): 32 mm worpiece length max.: 125 mm MAIN SPINDLE spindle revolutions (min): 260 /min spindle revolutions (max): 3080 /min ELECTRICAL SPECIFICATIONS total power consumption: 14 kW mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 5750 mm space requirements -front/back-: 1300 mm total weight approx.: 8200 kg tech. details: - max. diameter hexagonal bars 28 mm - max. diameter square bars 22 mm - max advancement bars 175 mm - max length shooting 100 mm - max stroke longitudinal carriages 125 mm - Trigger t ...
turning diameter: - mm turning length: - mm swing diameter over bed slide: - mm digital readout: ja weight: 4,4 t rapid traverse: ja m/min The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
multifix: ja digital: ja centre distance: 1000 mm : 440 length: 2000 mm width: 1400 mm height: 1500 mm total power requirement: 5,5 kW weight of the machine ca.: 1,7 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
