x-travel: 600 mm
y-travel: 410 mm
z-travel: 500
mm
Control: HEIDENHAIN TNC 530 HSCI
table surface area:
800x400 mm
T-slots: 3
T - slots distance: 125 mm
table
weight: 450 Kg
rapid traverse: 30.000 mm/min
taper ISO: ISO
40 DIN 69871
number of spindle speeds: 12.000
U/min/rpm
Spindle power: 10/17
magazine: 20
Internal
cooling system: 20 bar
Chip coveyor: inkl.
handwheel:
HEIDENHAIN HR-410
total power requirement: 25 kW
weight of
the machine ca.: 4.150 kg
dimensions of the machine ca.:
m
-T-slots (width, spacing) 18, 125 mm
-Distance from table
to floor 885 mm
-Distance from table to spindle nose
(min./max.) 140 / 650 mm
-Type Chain
-Tool selection
Random
-Max. tool diameter with adjacent pockets empty 135
mm
-Max. tool diameter without adjacent pockets empty 85
mm
-Max. tool length 250 mm Max. tool weight 6
kg
-Workpiece cleaning gun Included
-Optical measuring
systems (glass scales) Includ
